Datasheet PIC18F23K20, PIC18F24K20, PIC18F25K20, PIC18F26K20, PIC18F43K20 Datasheet

PIC18F2XK20/4XK20

28/40/44-Pin Flash Microcontrollers

with XLP Technology

High-Performance RISC CPU

• C Compiler Optimized Architecture:

- Optional extended in struct ion set designed to
optimize re-entrant code

• Up to 1024 bytes Data EEPROM

• Up to 64 Kbytes Linear Program Memory
Addressing

• Up to 3936 bytes Lin ear Data Mem ory Addressin g

• Up to 16 MIPS Operation

• 16-bit Wide Instructions, 8-bit Wide Data Path

• Priority Levels for Interrupts

• 31-Level, Software Accessible Hardware Stack

• 8 x 8 Single-Cycle Hardware Multiplier

Flexible Oscillator Struc ture

• Precision 16 MHz Internal Oscillator Block:

- Factory calibrated to ± 1%

- Software selectable frequencies range of

31 kHz to 16 MHz

- 64 MHz performance available using PLL –

no external components required

• Four Crystal Modes up to 64 MHz

• Two External Clock Modes up to 64 MHz

• 4X Phase Lock Loop (PLL)

• Secondary Oscillator using Timer1 @ 32 kHz

• Fail-Safe Clock Monitor:

- Allows for safe shutdown, if peripheral clock

stops

- Two-Speed Oscillator Start-up

Special Microcontroller Features

• Operating Voltage Range: 1.8V to 3.6V

• Self-Programmable under Software Control

• Programmable 16-Level High/Low-Voltage
Detection (HLVD) module:

- Interrupt on High/Low-Voltage Detection

• Programmable Brown-out Reset (BOR):

- With software enable option

• Extended Watchdog Timer (WDT):

- Programmable period from 4 ms to 131s

• Single-Supply 3V In-Circuit Serial
Programming™ (ICSP™) via Two Pins

• In-Circuit Debug (ICD) via Two Pins

Extreme Low-Power Management with XLP

• Sleep Mode: < 100 nA @ 1.8V

• Watchdog Timer: < 800 nA @ 1.8V

• Timer1 Oscillator: < 800 nA @ 32 kHz and 1.8V

Analog Features

• Analog-to-Digital Converter (ADC) Module:

- 10-bit resolution, 13 External Channels

- Auto-acquisition capability

- Conversion available during Sleep

- 1.2V Fixed Voltage Reference (FVR) channel

- Independent input multiplexing

• Analog Comparator Module:

- Two rail-to-rail analog comparators

- Independent input multiplexing

• Volt a ge Refere nc e (CV

- Programmable (% VDD), 16 steps

- Two 16-level voltage ranges using V

REF) Module

REF pins

Peripheral Highlight s

• Up to 35 I/O Pins plus 1 Input-only Pin:

- High-Current Sink/Source 25 mA/25 mA

- Three programmable external interrupts

- Four pr ogrammable interrupt-on-change

- Eight programmable weak pull-ups

- Programmable slew rate

• Capture/Compare/PWM (CCP) Module

• Enhanced CCP (ECCP) module:

- One, two or four PWM outputs

- Selectable polarity

- Programmable dead time

- Auto-shutdown and auto-restart

• Master Synchronous Serial Port (MSSP) Module

- 3-wire SPI (supports all four modes)

2

-I

C™ Master and Slave modes with address

mask

• Enhanced Universal Synchronous Asynchronous
Receiver Transmitter (EUSART) Module:

- Supports RS-485, RS-232 and LIN

- RS-232 operation using internal oscillator

- Auto-Wake-up on Break

- Auto-Baud Detect

 2010-2015 Microchip Technology Inc. DS40001303H-page 1

PIC18F2XK20/4XK20

-

PIC18F2XK20/4XK20 Family Types

Program Memory Data Memory

Device

PIC18F23K20 8K 4096 512 256 25 11 1/1 Y Y 1 2 1/3
PIC18F24K20 16K 8192 768 256 25 11 1/1 Y Y 1 2 1/3
PIC18F25K20 32K 16384 1536 256 25 11 1/1 Y Y 1 2 1/3
PIC18F26K20 64k 32768 3936 1024 25 11 1/1 Y Y 1 2 1/3
PIC18F43K20 8K 4096 512 256 36 14 1/1 Y Y 1 2 1/3
PIC18F44K20 16K 8192 768 256 36 14 1/1 Y Y 1 2 1/3
PIC18F45K20 32K 16384 1536 256 36 14 1/1 Y Y 1 2 1/3
PIC18F46K20 64k 32768 3936 1024 36 14 1/1 Y Y 1 2 1/3

Note 1: One pin is input-only.

2: Channel count includes internal Fixed Voltage Reference channel.

Flash

(bytes)

# Single-Word

Instructions

SRAM
(bytes)

EEPROM

(bytes)

I/O

10-bit

(1)

A/D

(ch)

CCP/

ECCP

(2)

(PWM)

Note: For other small form-factor package availability and marking information, please visit

http://www.microchip.com/packaging or contact your local sales office.

SPI

MSSP

Master

2

I

C™

Comp.

EUSART

Timers

8/16-bit

DS40001303H-page 2  2010-2015 Microchip Technology Inc.

Pin Diagrams

10
11

2
3
4
5
6

1

8

7

9

12
13
14

15

16

17

18

19

20

23

24

25

26

27

28

22
21

MCLR/VPP/RE3
AN0/C12IN0-/RA0
AN1/C12IN1-/RA1

AN2/V

REF-/CVREF/C2IN+/RA2

AN3/V

REF+/C1IN+/RA3

T0CKI/C1OUT/RA4

AN4/SS

/HLVDIN/C2OUT/RA5

V

SS

OSC1/CLKIN/RA7

OSC2/CLKOUT/RA6
T1OSO/T13CKI/RC0

T1OSI/CCP2

(1)

/RC1

CCP1/P1A/RC2

SCK/SCL/RC3

RB7/KBI3/PGD
RB6//KBI2/PGC
RB5/KBI1/PGM
RB4/KBI0/AN11/P1D
RB3/AN9/C12IN2-/CCP2

(1)

RB2/INT2/AN8/P1B
RB1/INT1/AN10/C12IN3-/P1C
RB0/INT0/FLT0/AN12
V

DD

VSS
RC7/RX/DT
RC6/TX/CK
RC5/SDO
RC4/SDI/SDA

PIC18F23K20

PIC18F24K20

PIC18F25K20

PIC18F26K20

Note: See Table1 for pin allocation table.

1011

2
3

6

1

18

19

20

21

22

121314

15

8

7

16

17

232425262728

9

T1OSO/T13CKI/RC0

5

4

RB7/KBI3/PGD

RB6/KBI2/PGC

RB5/KBI1/PGM

RB4/KBI0/AN11/P1D

RB3/AN9/C12IN2-/CCP2

(1)

RB2/INT2/AN8/P1B
RB1/INT1/AN10/C12IN3-/P1C
RB0/INT0/FLT0/AN12
V

DD

VSS
RC7/RX/DT

TX/CK/RC6

SDO/RC5

SDI/SDA/RC4

RE3/

MCLR/VPP

RA0/AN0/C12IN0-

RA1/AN1/C12IN1-

AN2/VREF-/CVREF/C2IN+/RA2

AN3/V

REF+/C1IN+/RA3

T0CKI/C1OUT/RA4

AN4/SS

/HLVDIN/C2OUT/RA5

V

SS

OSC1/CLKIN/RA7

OSC2/CLKOUT/RA6

T1OSI/CCP2

(1)

/RC1

CCP1/P1A/RC2

SCK/SCL/RC3

PIC18F23K20
PIC18F24K20
PIC18F25K20
PIC18F26K20

Note 1: RB3 is the alternate pin for CCP2 multiplexing.

2: UQFN package availability applies only to PIC18F23K20.
3: See Table 1 for pin allocation table.
4: The exposed pad should be connected to V

SS.

FIGURE 1: 28-PIN SPDIP, SOIC, SSOP

FIGURE 2: 28-PIN QFN/UQFN

PIC18F2XK20/4XK20

 2010-2015 Microchip Technology Inc. DS40001303H-page 3

PIC18F2XK20/4XK20

RB7/KBI3/PGD
RB6/KBI2/PGC

RB5/KBI1/PGM
RB4/KBI0/AN11
RB3/AN9/C12IN2-/CCP2

(1)

RB2/INT2/AN8
RB1/INT1/AN10/C12IN3-

RB0/INT0/FLT0/AN12
V

DD

VSS
RD7/PSP7/P1D
RD6/PSP6/P1C

RD5/PSP5/P1B
RD4/PSP4
RC7/RX/DT
RC6/TX/CK
RC5/SDO
RC4/SDI/SDA
RD3/PSP3
RD2/PSP2

MCLR/VPP/RE3

AN0/C12IN0-/RA0
AN1/C12IN1-/RA1

AN2/V

REF-/CVREF/C2IN+/RA2

AN3/V

REF+/C1IN+/RA3

T0CKI/C1OUT/RA4

AN4/SS

/HLVDIN/C2OUT/RA5

R

D/AN5/RE0

W

R/AN6/RE1

C

S/AN7/RE2

V

DD

VSS

OSC1/CLKIN/RA7

OSC2/CLKOUT/RA6

T1OSO/T13CKI/RC0

T1OSI/CCP2

(1)

/RC1

CCP1/P1A/RC2

SCK/SCL/RC3

PSP0/RD0
PSP1/RD1

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21

PIC18F43K20

PIC18F44K20

PIC18F45K20

PIC18F46K20

Note: See Table 2 for pin allocation table.

10

11

2
3

4
5
6

1

18 19 20

21

22

12 13 14 15

38

8

7

40 39

16 17

29

30

31

32

33

23

24

25

26

27

28

363435

9

37

AN1/C12/IN1-/RA1

AN0/C12IN0-/RA0

M

CLR/VPP/RE3

AN9/C12IN2-/CCP/RB3

KBI3/PGD/RB7

KBI2/PGC/RB6

KBI1/PGM/RB5

KBI0/AN11/RB4

RC6/TX/Ck

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1/P1A

RC1/T1OSI/CCP2

RC0/T1OSO/T13CKI
RA6/OSC2/CLKOUT
RA7/OSC1/CLKIN
V

SS

VDD
RE2/CS/AN7
RE1/WR/AN6
RE0/RD

/AN5

RA5/AN4/SS

/HLVDIN/C2OUT

RA4/T0CKI/C1OUT

RX/DT/RC7

RD4/PSP4/RD4

PSP5/P1B/RD5

RD6/PSP6/P1C/RD6

PSP7/P1D/RD7

V

SS

VDD

INT0/FLT0/AN12/RB0

INT1/AN10/C12IN3-/RB1

INT2/AN8/RB2

AN3/VREF+/C1IN+/RA3

AN2/V

REF-/CVREF/C2IN+/RA2

PIC18F4XK20

Note 1: See Table 2 for location of all peripheral functions.

2: It is recommended that the exposed bottom pad be connected to V

SS.

FIGURE 3: 40-PIN PDIP

FIGURE 4: 40-PIN UQFN

DS40001303H-page 4  2010-2015 Microchip Technology Inc.

FIGURE 5: 44-PIN QFN

10
11

2
3
4
5
6

1

1819202122

121314

15

38

8

7

4443424140

39

16

17

29

30

31

32

33

23

24

25

26

27

28

363435

9

37

AN3/V

REF+/C1IN+/RA3

AN2/V

REF-/CVREF/C2IN+/RA2

AN1/C12IN1-/RA1

AN0/C12IN0-/RA0

MCLR

/VPP/RE3

AN9/C12IN2-/CCP2

(1)

/RB3

KBI3/PGD/RB7

KBI2/PGC/RB6

KBI1/PGM/RB5

KBI0/AN11/RB4

NC

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1/P1A

RC1/T1OSI/CCP2

(1)

RC0/T1OSO/T13CKI

RA6/OSC2/CLKOUT
RA7/OSC1/CLKIN
V

SS

VSS
VDD
VDD
RE2/CS/AN7
RE1/WR

/AN6

RE0/RD

/AN5

RA5/AN4/SS

/HLVDIN/C2OUT

RA4/T0CKI/C1OUT

RX/DT/RC7

RD4/PSP4/RD4

PSP5/P1B/RD5
PSP6/P1C/RD6
PSP7/P1D/RD7

V

SS

VDD
VDD

INT0/FLT0/AN12/RB0

INT1/AN10/C12IN3-/RB1

INT2/AN8/RB2

PIC18F43K20
PIC18F44K20
PIC18F45K20
PIC18F46K20

Note 1: RB3 is the alternate pin for CCP2 multiplexing.

2: The exposed pad should be connected to V

SS.

3: See Table 2 for pin allocation table.

10
11

2
3
4
5
6

1

1819202122

121314

15

38

8

7

4443424140

39

16

17

29

30

31

32

33

23

24

25

26

27

28

363435

9

37

AN3/VREF+/C1IN+/RA3

AN2/V

REF-/CVREF/C2IN+/RA2

AN1/C12IN1-/RA1

AN0/C12IN0-/RA0

MCLR

/VPP/RE3

NC

KBI3/PGD/RB7

KBI2/PGC/RB6

KBI1/PGM/RB5

KBI0/AN11/RB4

NC

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1/P1A

RC1/T1OSI/CCP2

(1)

NC

NC
RC0/T1OSO/T13CKI
RA6/OSC2/CLKOUT
RA7/OSC1/CLKIN
V

SS

VDD
RE2/CS/AN7
RE1/WR

/AN6

RE0/RD

/AN5

RA5/AN4/SS

/HLVDIN/C2OUT

RA4/T0CKI/C1OUT

RX/DT/RC7

PSP4/RD4

PSP6/P1C/RD6
PSP7/P1D/RD7

V

SS

VDD

INT0/FLT0/AN12/RB0

INT1/AN10/C12IN3-/RB1

INT2/AN8/RB2

AN9/C12IN2-/CCP2

(1)

/RB3

PIC18F43K20
PIC18F44K20
PIC18F45K20
PIC18F46K20

Note 1: RB3 is the alternate pin for CCP2 multiplexing.

2: See Table 2 for pin allocation table.

PSP5/P1B/RD5

PIC18F2XK20/4XK20

FIGURE 6: 44-PIN TQFP

 2010-2015 Microchip Technology Inc. DS40001303H-page 5

PIC18F2XK20/4XK20

Pin Allocation Tables

TABLE 1: 28-PIN ALLOCATION TABLE (PIC18F2XK20)

I/O

28-Pin SPDIP, SOIC, SSOP

RA0 2 27 AN0 C12IN0- — — — — — — — — —
RA1 3 28 AN1 C12IN1- — — — — — — — — —
RA2 4 1 AN2 C2IN+ V

RA3 5 2 AN3 C1IN+ VREF+ — — — — — — — —
RA4 6 3 — C1OUT — — — — T0CKI — — — —

RA5 7 4 AN4 C2OUT HLVDIN
RA6 10 7 — — — — — — — — — — OSC2/

RA7 9 6 — — — — — — — — — — OSC1/

RB0 21 18 AN12 — — FLT0 — — — — INT0 Yes —
RB1 22 19 AN10 C12IN3- — P1C — — — — INT1 Yes —
RB2 23 20 AN8 — — P1B — — — — INT2 Yes —
RB3 24 21 AN9 C12IN2- CCP2
RB4 25 22 AN11 — — P1D — — — — KBI0 Yes —
RB5 26 23 — — — — — — — — KBI1 Yes PGM
RB6 27 24 — — — — — — — — KBI2 Yes PGC
RB7 28 25 — — — — — — — — KBI3 Yes PGD
RC0 11 8 — — — — — — T1OSO/

RC1 12 9 — — — CCP2
RC2 13 10 — — — CCP1/

RC3 14 11 — — — — — SCK/

RC4 15 12 — — — — — SDI/

RC5 16 13 — — — — — SDO — — — — —
RC6 17 14 — — — — TX/CK — — — — — —
RC7 18 15 — — — — RX/DT — — — — — —

(3)

RE3

Note 1: CCP2 multiplexed with RB3 when CONFIG3H<0> = 0

126

8 5 — — — — — — — — — — VSS
19 16 — — — — — — — — — — V SS
20 17 — — — — — — — — — — VDD

2: CCP2 multiplexed with RC1 when CONFIG3H<0> = 1
3: Input-only

Analog

Comparator

28-Pin QFN/UQFN

—— ————————

CV

Reference

REF-/

REF

ECCP

——— ———— —

— —

(1)

(2)

P1A

EUSART

— — — — — Yes —

— — T1OSI — — — —
—— — ——— —

SS

SCL

SDA

MSSP

Timers

— — — — —

T13CKI

— — — — —

———— —

Slave

Interrupts

——— —

Pull-up

CLKOUT

CLKIN

MCLR

V

Basic

/

PP

DS40001303H-page 6  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 2: 40/44-PIN ALLOCATION TABLE (PIC18F4XK20)

I/O

40-Pin PDIP

RA0 2 17 19 19 AN0 C12IN0-— — — — — — — — —

RA1 3 18 20 20 AN1 C12IN1-———————— —

RA2 4 19 21 21 AN2 C2IN+ VREF-/

RA3 5 20 22 22 AN3 C1IN+ V
RA4 6 21 23 23 — C1OUT — — — — T0CKI — — — —

RA5 7 22 24 24 AN4 C2OUT HLVDIN
RA6 14 29 31 33 — — — — — — — — — — OSC2/

RA7 13 28 30 32 — — — — — — — — — — OSC1/

RB0 33 8 8 9 AN12 — — FLT0 — — — — INT0 Yes —
RB1 34 9 9 10 AN10 C12IN3-——————INT1Yes —

RB2 35 10 10 11 AN8 — — — — — — — INT2 Yes —
RB3 36 11 11 12 AN9 C12IN2-— CCP2

RB4 37 12 14 14 AN11 — — — — — — — KBI0 Yes —
RB5 38 13 15 15 — — — — — — — — KBI1 Yes PGM
RB6 39 14 16 16 — — — — — — — — KBI2 Yes PGC
RB7 40 15 17 17 — — — — — — — — KBI3 Yes PGD
RC0 15 30 32 34 — — — — — — T1OSO/

RC1 16 31 35 35 — — — CCP 2
RC2 17 32 36 36 — — — CCP1/

RC3 18 33 37 37 — — — — — SCK/

RC4 23 38 42 42 — — — — — SDI/

RC5 24 39 43 43 — — — — — SDO — — — — —
RC6 25 40 44 44 — — — — TX/CK— — — — — —

40-Pin UQFN

44-Pin TQFP

Analog

44-Pin QFN

Comp.

Reference

CV

REF

REF+— — — — — — — —

ECCP

— — — — — — — —

——

(1)

—— — — —Yes —

(2)

——T1OSI— — — —
— — — — — — —

P1A

EUSART

SS

SCL

SDA

MSSP

Timers

———— —

T13CKI

———— —

— — — — —

Slave

— — — —

Pull-up

Interrupts

CLKOUT

CLKIN

Basic

RC7 26 1 1 1 — — — — RX/DT————— —

RD0 19 34 38 38 — — — — — — — PSP0 — — —
RD1 20 35 39 39 — — — — — — — PSP1 — — —
RD2 21 36 40 40 — — — — — — — PSP2 — — —
RD3 22 37 41 41 — — — — — — — PSP3 — — —
RD4 27 2 2 2 — — — — — — — PSP4 — — —
RD5 28 3 3 3 — — — P1B — — — PSP5 — — —
RD6 29 4 4 4 — — — P1C — — — PSP6 — — —

Note 1: CCP2 multiplexed with RB3 when CONFIG3H<0> = 0

2: CCP2 multiplexed with RC1 when CONFIG3H<0> = 1
3: Input-only.

 2010-2015 Microchip Technology Inc. DS40001303H-page 7

PIC18F2XK20/4XK20

TABLE 2: 40/44-PIN ALLOCATION TABLE (PIC18F4XK20) (CONTINUED)

I/O

40-Pin PDIP

RD7 30 5 5 5 — — — P1D — — — PSP7 — — —
RE0 8 23 25 25 AN5

RE1 9 24 26 26 AN6
RE2 10 25 27 27 AN7

(3)

RE3

Note 1: CCP2 multiplexed with RB3 when CONFIG3H<0> = 0

1161818

— 11 7 7 7 — — — — — — — — — — VDD
—32262828 — — — — — — — — — — VDD
— 12 6 6 6 — — — — — — — — — — VSS
—31272930 — — — — — — — — — — VSS
— – — NC 8 — — — — — — — — — — VDD
—–—NC29— — — — — — — — — — VDD
— –- — NC 31 — — — — — — — — — — VSS

2: CCP2 multiplexed with RC1 when CONFIG3H<0> = 1
3: Input-only.

40-Pin UQFN

44-Pin TQFP

Analog

44-Pin QFN

——————————

Comp.

— — — — — —
——————
— — — — — —

Reference

ECCP

EUSART

MSSP

Timers

RD
WR

CS

Slave

— — —
—— —
— — —

Pull-up

Interrupts

MCLR

Basic

/VPP

DS40001303H-page 8  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

Table of Contents

1.0 Device Overview .............................................................................................................................. .. .............. ............. .. .......... 11

2.0 Oscillator Module (With Fail-Safe Clock Monitor)...................................................................................................................... 26

3.0 Power-Managed Modes............................................................................................................................................................ 41

4.0 Reset......................................................................................................................................................................................... 48

5.0 Memory Organization . ............................................................................................................................................................... 61

6.0 Flash Program Memory......... ....................................................... ............... ......................... ..................................................... 84

7.0 Data EEPROM Memory ............................. ............................ .............. ............................ ........................ ............. .. .............. .... 93

8.0 8 x 8 Hardware Multiplier............................................................................................................... ............. ............. .. .............. .. 98

9.0 Interrupts................................................................................................................................................................................. 100

10.0 I/O Ports.................. ........................... ........................... ............... ........................................................................................... 113

11.0 Capture/Compare/PWM (CCP) Modules ................................................................................................................................ 134

12.0 Timer0 Module ................................................................................................................................. .. .............. .. ............. ........ 145

13.0 Timer1 Module ................................................................................................................................. .. .............. .. ............. ........ 148

14.0 Timer2 Module ................................................................................................................................. .. .............. .. ............. ........ 155

15.0 Timer3 Module ................................................................................................................................. .. .............. .. ............. ........ 157

16.0 Enhanced Capture/Compare/PWM (ECCP) Module................................................................................................... .. .......... 161

17.0 Master Synchronous Serial Port (MSSP) Module ................................................................................................................... 179

18.0 Enhanced Universal Synchronous Asynchronous Receiver Transmitter (EUSART).............................................................. 222

19.0 Analog-to-Digital Converter (ADC) Module ............................................................................................................................. 249

20.0 Comparator Module................................................................................................................................................................. 262

21.0 Voltage References.................................................................. .. .. .... .. .. ....... .... .. .... .. .. ............................. .. ............. .............. .. .. 27 2

22.0 High/Low-Voltage Detect (HLVD)............................................................................................................................................ 276

23.0 Special Features of the CPU......................... ...................................................... ............... ..................................................... 281

24.0 Instruction Set Summary......................................................................................................................................................... 296

25.0 Development Support............................................................................................................................. .. ............. .. .............. .. 34 6

26.0 Electrical Characteristics.......................................................................................................................... .. ............. .. .............. 35 0

27.0 DC and AC Characteristics Graphs and Tables...................................................................................................................... 387

28.0 Packaging Information. ............... ...................................................... ............... ........................................................................ 410

Appendix A: Revision History............................................................................................................................................................ 435

Appendix B: Device Differences ............................................................................................................. .. ............. .. ............. .. .......... 436

The Microchip Web Site.............. ............... ........................... ............................ ................................................................................ 437

Customer Change Notification Service ..................................................................................................... . .............. ............. .. .......... 437

Customer Support............................................................................................................................................................................. 437

Product Identification System........................................................................................................................................................... 438

 2010-2015 Microchip Technology Inc. DS40001303H-page 9

PIC18F2XK20/4XK20

TO OUR VALUED CUSTOMERS

It is our intention to provide our valued customers with the best documentation possible to ensure successful use of your Microchip
products. To this end, we will continue to improve our publications to better suit your needs. Our publications will be refined and
enhanced as new volumes and updates are introduced.

If you have any questions or c omm ents r egarding t his publication, p lease c ontact the M arket ing Communications Department via
E-mail at [e-mail]. We welcome your feedback.

Most Current Data Sheet

To obtain the most up-to-date version of this data sheet, please register at our Worldwide Web site at:

http://www.microchip.com

You can determine the version of a data sheet by examining its literature number found on the bottom outside corner of any page.
The last character of the literature number is the version number, (e.g., DS30000000A is version A of document DS30000000).

Errata

An errata sheet, describing minor operational differences from the data sheet and recommended workarounds, may exist for current
devices. As device/documentation issues become known to us, we will publish an errata sheet. The errata will specify the revision
of silicon and revision of document to which it applies.

To determine if an errata sheet exists for a particular device, please check with one of the following:

• Microchip’s Worldwide Web site; http://www.microchip.com

• Your local Microchip sales office (see last page)
When contacting a sales office, please specify which device, revision of silicon and data sheet (include literature number) you are

using.

Customer Notification System

Register on our web site at www.microchip.com to receive the most current information on all of our products.

DS40001303H-page 10  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

1.0 DEVICE OVERVIEW

This document co nta i ns dev ic e spec if i c in for m at ion fo r
the following devices:

• PIC18F23K20 • PIC18F43K20

• PIC18F24K20 • PIC18F44K20

• PIC18F25K20 • PIC18F45K20

• PIC18F26K20 • PIC18F46K20

This family offers the advantages of all PIC18
microcontrollers – namely, high computational
performance at an economical price – with the addition
of high-endurance, Flash program memory. On top of
these features, the PIC18F2XK20/4XK20 family
introduces design enhancements that make these
microcontrollers a logical choice for many
high-performance, power sensitive applications.

1.1 New Core Features

1.1.1 XLP TECHNOLOGY

All of the devices in the PIC18F2XK20/4XK20 family
incorporate a range of features that can significantly
reduce power consumption during operation. Key
items include:

• Alternate Run Modes: By clocking the controller
from the Timer1 source or the internal oscillator
block, power consumption during code execution
can be reduced by as much as 90%.

• Multiple Idle Modes: The controller can also run
with its CPU core disabled but the peripherals still
active. In these st ates, powe r consumpt ion can be
reduced even further, to as little as 4% of normal
operation requirements.

• On-the-fly Mode Switching: The power­managed modes a re invo ked b y user code durin g
operation, allowing the user to incorporate
power-saving ideas into their application’s
software design.

• Low Consumption in Key Modules: The
power requirements for both Timer1 and the
Watchdog Timer are minimized. See

Section 26.0 “Electrical Specifications”

for values.

1.1.2 MULTIPLE OSCILLATOR OPTIONS AND FEATURES

All of the devices in the PIC18F2XK20/4XK20 family
offer ten different oscillator options, allowing users a
wide range of choices in developing application
hardware. These include:

• Four Crystal modes, using crystals or ceramic

resonators

• Two External Clock modes, offering the option of

using two pins (oscillator input and a divide-by-4
clock output) or one pin (oscillator input, with the
second pin reassigned as general I/O)

• Two External RC Oscillator modes with the same

pin options as the External Clock modes

• An internal oscillator block which contains a

16 MHz HFINTOSC oscillator and a 31 kHz
LFINTOSC oscillator which together provide 8
user selectable clock frequencies, from 31 kHz to
16 MHz. This option frees the two oscillator pins
for use as additional general purpose I/O.

• A Phase Lock Loop (PLL) frequency multiplier,

available to both the high-speed crystal and inter­nal oscillator m odes, which a llows clo ck speeds o f
up to 64 MHz. Used with t he internal oscillator, the
PLL gives users a complete selection of clock
speeds, from 31 kHz to 64 MHz – all without using
an external crystal or clock circuit.

Besides its ava ilability as a cloc k source, the intern al
oscillator block pro vid es a s t ab le re ference source that
gives the family additional features for robust
operation:

• Fail-Safe Clock Monitor: This option constantly

monitors the main clock source against a
reference signal provided by the LFINTOSC. If a
clock failure occurs, the controller is switched to
the internal oscillato r block, al lowing f or continue d
operation or a safe application shutdown.

• T wo-S pe ed S tart-up: This option allows the

internal oscillator to serve as the clock source
from Power-on Reset, or wake-up from Sleep
mode, until the primary clock source is available.

 2010-2015 Microchip Technology Inc. DS40001303H-page 11

PIC18F2XK20/4XK20

1.2 Other Special Features

• Memory Endurance: The Flash cells for both
program memory and data EEPROM are rated to
last for many thousands of erase/write cycles – up to
10K for program memory and 100K for EEPROM.
Data retention without refresh is conservatively
estimated to be greater than 40 years.

• Self-programmability: These devices can write
to their own program mem ory spaces under
internal software control. By using a bootloader
routine located in the protected Boot Block at the
top of program memory, it becomes possible to
create an application that can update itself in the
field.

• Extended Instruction Set: The PIC18F2XK20/
4XK20 family introduces an optional extension to
the PIC18 instruction set, which adds eight new
instructions and an Indexed Addressing mode.
This extension, en abled as a de vi ce conf igurati on
option, has been specifi cally des igned to opt imize
re-entrant applica tion cod e origina lly deve loped in
high-level languages, such as C.

• Enhanced CCP module: In PWM mode, this
module provides 1, 2 or 4 modulated outputs for
controlling half-bridge and full-bridge drivers.
Other features include:

- Auto-Shutdown, for disabling PWM outputs

on interrupt or other select conditions

- Auto-Restart, to reactivate outputs once the

condition has cleared

- Output steering to selectively enable one or

more of four outputs to provide the PWM
signal.

• Enhanced Addressable EUSART: This serial
communication module is capable of standard
RS-232 operation an d provides support for th e LIN
bus protocol. Other enhancements include
automatic baud rate detection and a 16-bit Baud
Rate Generator for improved resolu tion. When the
microcontroller is using the internal oscillator
block, the EUSART provides stable operation for
applications that talk to the outside world without
using an external crystal (or its accompanying
power requirement).

• 10-bit A/D Converter: This module incorporates
programmable acquisition time, allowing for a
channel to be selected and a conversion to be
initiated withou t wai ting for a sampling perio d an d
thus, reduce code overhead.

• Extended Watchdog Timer (WDT): This
enhanced version incorporates a 16-bit
postscaler, allowing an extended time-out range
that is stable across operati ng vol t age and
temperature. See Section 26.0 “Electrical

Specifications” for time-out periods.

1.3 Details on Individual Family Members

Devices in the PIC18F2XK20/4XK20 family are
available in 28-pin and 40/44-pin packages. Block
diagrams for the two groups are shown in Figure 1-1
and Figure 1-2.

The devices are differentiated from each other in five
ways:

1. Flash program memory (8 Kbytes for

PIC18F23K20/43K20 devices, 16 Kbytes for
PIC18F24K20/44K20 devices, 32 Kbytes for
PIC18F25K20/45K20 AND 64Kbytes for
PIC18F26K20/46K20).

2. A/D channels (11 for 28-pin devices, 14 for

40/44-pin devices).

3. I/O ports (three bidirectional ports on 28-pin

devices, five bidirectional ports on 40/44-pin
devices).

4. Parallel Slave Port (present only on 40/44-pin

devices).

All other features fo r device s in this family are identi cal.
These are summarized in Table 1-1.

The pinouts for al l devices are lis ted in the pin summar y
tables: Table and Table , and I/O description tables:

Table 1-2 and Table 1-3.

DS40001303H-page 12  2010-2015 Microchip Technology Inc.

 2010-2015 Microchip Technology Inc. DS40001303H-page 13

TABLE 1-1: DEVICE FEATURES

Features PIC18F23K20 PIC18F24K20 PIC18F25K20 PIC18F26K20 PIC18F43K20 PIC18F44K20 PIC18F45K20 PIC18F46K20

Operating Frequency
Program Memory (Bytes) 8192 16384 32768 65536 8192 16384 32768 65536
Program Memory

(Instructions)
Data Memory (Bytes) 512 768 1536 3936 512 768 1536 3936
Data EEPROM Memory

(Bytes)
Interrupt Sources 19 19 19 19 20 20 20 20
I/O Ports A, B, C, (E)
Timers 4 4 44 44 44
Capture/Compare/PWM

Modules
Enhanced Capture/

Compare/PWM Modules
Serial Communications MSSP, Enhanced

Parallel Communica­tions (PSP)

10-bit Analog-to-Digital
Module

Resets (and Delays) POR, BOR, RESET

Programmable High/
Low-Voltage Detect

Programmable Brown­out Reset

Instruction Set 75 Instructions; 83

Packages 28-pin PDIP

Note 1: PORTE contains the single RE3 read-only bit. The LATE and TRISE registers are not implemented.

2: Frequency range shown applies to industrial range devices only. Maximum frequency for extended range devices is 48 MHz.

(2)

DC – 64 MHz DC – 64 MHz DC – 64 MHz DC – 64 MHz DC – 64 MHz DC – 64 MHz DC – 64 MHz DC – 64 MHz

EUSART

1 internal plus 10

Input Channels

Instruction, Stack

Full, Stack Underflow

(PWRT, OST),

MCLR

with Extended

Instruction Set

28-pin SOIC

28-pin QFN
28-pin SSOP
28-pin UQFN

4096 8192 16384 32768 4096 8192 16384 32768

256 256 256 1024 256 256 256 1024

(1)

11111111

1 1 11 11 11

No No No No Yes Yes Yes Yes

(optional),

WDT

Yes Yes Yes Yes Yes Yes Yes Yes

Yes Yes Yes Yes Yes Yes Yes Yes

enabled

A, B, C, (E)

MSSP, Enhanced

1 internal plus 10

Input Channels

POR, BOR, RESET

Instruction, Stack

Full, Stack Underflow

(PWRT, OST), MCLR

(optional), WDT

75 Instructions; 83

with Extended

Instruction Set

28-pin PDIP

28-pin SOIC

28-pin QFN

28-pin SSOP

EUSART

enabled

(1)

MSSP, Enhanced

1 internal plus 10

POR, BOR, RESET

Instruction, Stack

Full, Stack Underflow

75 Instructions; 83

A, B, C, (E)

EUSART

Input Channels

(PWRT, OST),

(optional),

MCLR

WDT

with Extended

Instruction Set

enabled

28-pin PDIP
28-pin SOIC

28-pin QFN

28-pin SSOP

(1)

MSSP, Enhanced

1 internal plus 10

POR, BOR, RESET

Instruction, Stack
Full, Stack Underflow
(PWRT, OST), MCLR

(optional), WDT

75 Instructions; 83

A, B, C, (E)

Input Channels

with Extended
Instruction Set

28-pin PDIP

28-pin SOIC

28-pin QFN

28-pin SSOP

(1)

EUSART

enabled

A, B, C, D, E A, B, C, D, E A, B, C, D, E A, B, C, D, E

MSSP, Enhanced

EUSART

1 internal plus 13

Input Channels

POR, BOR, RESET

Instruction, Stack

Full, Stack Underflow

(PWRT, OST),

(optional),

MCLR

WDT

75 Instructions; 83

with Extended
Instruction Set

enabled

40-pin PDIP

44-pin QFN

44-pin TQFP

40-pin UQFN

MSSP, Enhanced

EUSART

1 internal plus 13

Input Channels

POR, BOR, RESET

Instruction, Stack

Full, Stack Underflow

(PWRT, OST),

(optional),

MCLR

WDT

75 Instructions; 83

with Extended
Instruction Set

enabled

40-pin PDIP

44-pin QFN
44-pin TQFP
40-pin UQFN

MSSP, Enhanced

EUSART

1 internal plus 13

Input Channels

POR, BOR, RESET

Instruction, Stack

Full, Stack Underflow

(PWRT, OST),

(optional),

MCLR

WDT

75 Instructions; 83

with Extended
Instruction Set

enabled

40-pin PDIP

44-pin QFN
44-pin TQFP
40-pin UQFN

POR, BOR, RESET

MSSP, Enhanced

EUSART

1 internal plus 13

Input Channels

Instruction, Stack

Full, Stack

Underflow (PWRT,

OST), MCLR

(optional), WDT

75 Instructions; 83

with Extended
Instruction Set

enabled

40-pin PDIP

44-pin QFN
44-pin TQFP
40-pin UQFN

PIC18F2XK20/4XK20

PIC18F2XK20/4XK20

Instruction

Decode and

Control

PORTA

PORTB

PORTC

RA4/T0CKI/C1OUT
RA5/AN4/SS

/HLVDIN/C2OUT

RB0/INT0/FLT0/AN12

RC0/T1OSO/T13CKI
RC1/T1OSI/CCP2

(1)

RC2/CCP1
RC3/SCK/SCL
RC4/SDI/SDA
RC5/SDO
RC6/TX/CK
RC7/RX/DT

RA3/AN3/VREF+

RA2/AN2/VREF-/CVREF

RA1/AN1

RA0/AN0

RB1/INT1/AN10/C12IN3-

Data Latch

Data Memory

Address Latch

Data Address< 12>

12

Access

BSR

FSR0
FSR1
FSR2

inc/dec

logic

Address

4

12

4

PCH PCL

PCLATH

8

31-Level Stack

Program Counter

PRODLPRODH

8 x 8 Multiply

8

BITOP

8

8

ALU<8>

20

8

8

T able Pointer<21>

inc/dec logic

21

8

Data Bus<8>

Table Latch

8

IR

12

3

ROM Latch

RB2/INT2/AN8
RB3/AN9/CCP2

(1)

/C12IN2-

PCLATU

PCU

OSC2/CLKOUT

(3)

/RA6

Note 1: CCP2 is multiplexed with RC1 when Configuration bit CCP2MX is set, or RB3 when CCP2MX is not set.

2: RE3 is only available when MCLR

functionality is disabled.

3: OSC1/CLKIN and OSC2/CLKOUT are only available in select oscillator modes and when these pins are not being used as digital I/O.

Refer to Section 2.0 “Oscillator Module (With Fail- Safe Clock Mo nitor )” for additional information.

RB4/KBI0/AN11
RB5/KBI1/PGM
RB6/KBI2/PGC
RB7/KBI3/PGD

EUSARTComparator

MSSP

10-bit

ADC

Timer2Timer1 Timer3Timer0

CCP2

HLVD

ECCP1

BOR

Data

EEPROM

W

Instruction Bus <16>

STKPTR

Bank

8

State machine
control signals

Decode

8

8

Power-up

Timer

Oscillator

Start-up Timer

Power-on

Reset

Watchdog

Timer

OSC1

(3)

OSC2

(3)

VDD,

Brown-out

Reset

Internal

Oscillator

Fail-Safe

Clock Monitor

Precision

Reference

Band Gap

V

SS

MCLR

(2)

Block

LFINTOSC

Oscillator

16 MHz

Oscillator

Single-Supply
Programming

In-Circuit

Debugger

T1OSO

OSC1/CLKIN

(3)

/RA7

T1OSI

PORTE

MCLR/VPP/RE3

(2)

FVR

FVR

FVR

CVREF

Address Latch

Program Memory

(8/16/32/64 Kbytes)

Data Latch

FIGURE 1-1: PIC18F2XK20 (28-PIN) BLOCK DIAGRAM

DS40001303H-page 14  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

Instruction

Decode and

Control

Data Latch

Data Memory

Address Latc h

Data Address< 12>

12

Access

BSR

FSR0
FSR1
FSR2

inc/dec

logic

Address

4

12

4

PCH PCL

31-Level Stack

Program Counter

PRODLPRODH

8 x 8 Multiply

8

BITOP

8

8

ALU<8>

Address Latch

Program Memory

(8/16/32/ 64Kbytes)

Data Latch

20

8

8

T able Pointer<21>

inc/dec logic

21

Data Bus<8>

Table Latch

8

IR

12

3

ROM Latch

PORTD

RD0/PSP0

PCU

PORTE

MCLR/VPP/RE3

(2)

RE2/CS/AN7

RE0/RD/AN5
RE1/WR/AN6

Note 1: CCP2 is multiplexed with RC1 when Configuration bit CCP2MX is set, or RB3 when CCP2MX is not set.

2: RE3 is only available when MCLR

functionality is disabled.

3: OSC1/CLKIN and OSC2/CLKOUT are only available in select oscillator modes and when these pins are not being used as digital I/O.

Refer to Section 2.0 “Oscillator Module (With Fail-Safe Clock Monitor)” for additional information.

EUSARTComparator

MSSP

10-bit

ADC

Timer2Timer1 Timer3Timer0

CCP2

HLVD

ECCP1

BOR

Data

EEPROM

W

Instruction Bus <16>

STKPTR

Bank

8

State machine
control signals

Decode

8

8

Power-up

Timer

Oscillator

Start-up Timer

Power-on

Reset

Watchdog

Timer

OSC1

(3)

OSC2

(3)

VDD,

Brown-out

Reset

Internal

Oscillator

Fail-Safe

Clock Monitor

Precision

Reference

Band Gap

V

SS

MCLR

(2)

Block

LFINTOSC

Oscillator

16 MHz

Oscillator

Single-Supply
Programming

In-Circuit

Debugger

T1OSI

T1OSO

RD1/PSP1
RD2/PSP2
RD3/PSP3

PORTA

PORTB

PORTC

RA4/T0CKI/C1OUT
RA5/AN4/SS

/HLVDIN/C2OUT

RB0/INT0/FLT0/AN12

RC0/T1OSO/T13CKI
RC1/T1OSI/CCP2

(1)

RC2/CCP1/P1A
RC3/SCK/SCL

RC4/SDI/SDA
RC5/SDO
RC6/TX/CK
RC7/RX/DT

RA3/AN3/VREF+

RA2/AN2/VREF-/CVREF

RA1/AN1

RA0/AN0

RB1/INT1/AN10/C12IN3­RB2/INT2/AN8
RB3/AN9/CCP2

(1)

/C12IN2-

OSC2/CLKOUT

(3)

/RA6

RB4/KBI0/AN11
RB5/KBI1/PGM
RB6/KBI2/PGC
RB7/KBI3/PGD

OSC1/CLKIN

(3)

/RA7

RD4/PSP4
RD5/PSP5/P1B
RD6/PSP6/P1C
RD7/PSP7/P1D

FVR

FVR

PSP

FVR

CVREF

PCLATH

8

8

PCLATU

FIGURE 1-2: PIC18F4XK20 (40/44-PIN) BLOCK DIAGRAM

 2010-2015 Microchip Technology Inc. DS40001303H-page 15

PIC18F2XK20/4XK20

TABLE 1-2: PIC18F2XK20 PINOUT I/O DESCRIPTIONS

Pin Number

Pin Name

MCLR

/VPP/RE3
MCLR
VPP
RE3

OSC1/CLKIN/RA7

OSC1
CLKIN

RA7

OSC2/CLKOUT/RA6

OSC2
CLKOUT
RA6

Legend: TTL= TTL compatible input CMOS = C MOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

Note 1: Default assi gnment for CCP2 when Configur ation bit CCP2MX is set.

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP,
SOIC

126

96

10 7

QFN

Pin

Type

I

P

I

I
I

I/O

O
O

I/O

Buffer

Type

ST
ST

ST

CMOS

TTL

—
—

TTL

Description

Master Clear (input) or programming voltage (input)

Active-low Master Clear (device Reset) input
Programmin g voltage input
Digital input

Oscillator crystal or external clock input

Oscillator crystal input or external clock source input
ST buffer when configured in RC mode; CMOS otherwise
External clock source input. Always associated with pin
function OSC1. (See related OSC1/CLKIN, OSC2/CLKOUT
pins)
General purpose I/O pin

Oscillator crystal or clock output

Oscillator crystal output. Connects to crystal or
resonator i n Crystal Oscillat or mode
In RC mode, OSC2 pin out put s CLKOUT which h as 1/4 th e
frequency of OSC1 and denotes the instruction cycle rate
General purpose I/O pin

DS40001303H-page 16  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 1-2: PIC18F2XK20 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Number

Pin Name

RA0/AN0/C12IN0-

RA0
AN0
C12IN0-

RA1/AN1/C12IN1-

RA1
AN1
C12IN1-

RA2/AN2/V
C2IN+

RA2
AN2
V
CV
C2IN+

RA3/AN3/V

RA3
AN3
V
C1IN+

RA4/T0CKI/C1OUT

RA4
T0CKI
C1OUT

RA5/AN4/SS
C2OUT

RA5
AN4
SS
HLVDIN

C2OUT
RA6 See the OSC2/CLKOUT/RA6 pin
RA7 See the OSC1/CLKIN/RA7 pin

Legend: TTL= TTL compatible input CMOS = CMOS compatible input or output

Note 1: Default assignment for CCP2 when Configuration bit CCP2MX is set.

REF-/CVREF/

REF-

REF

REF+/C1IN+

REF+

/HLVDIN/

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP,

QFN

SOIC

227

328

41

52

63

74

Pin

Type

I/O

I
I

I/O

I
I

I/O

I
I

O

I

I/O

I
I
I

I/O

I

O

I/O

I
I
I

O

Buffer

Type

TTL
Analog
Analog

TTL
Analog
Analog

TTL
Analog
Analog
Analog
Analog

TTL
Analog
Analog
Analog

ST
ST

CMOS

TTL
Analog

TTL
Analog
CMOS

Description

PORTA is a bidirectional I/O port.

Digital I/O
Analog input 0, ADC channel 0
Comparators C1 and C2 inverting input

Digital I/O
ADC input 1, ADC channel 1
Comparators C1 and C2 inverting input

Digital I/O
Analog input 2, ADC channel 2
A/D reference voltage (low) input
Comparator reference voltage output
Comparator C2 non-inverting input

Digital I/O
Analog input 3, ADC channel 3
A/D reference voltage (high) input
Comparator C1 non-inverting input

Digital I/O
Timer0 external clock input
Comparator C1 output

Digital I/O
Analog input 4, ADC channel 4
SPI slave select input
High/Low-Voltage Detect inpu t
Comparator C2 output

 2010-2015 Microchip Technology Inc. DS40001303H-page 17

PIC18F2XK20/4XK20

TABLE 1-2: PIC18F2XK20 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Number

Pin Name

RB0/INT0/FLT0/AN12

RB0
INT0
FLT0
AN12

RB1/INT1/AN10/C12IN3­/P1C

RB1
INT1
AN10
C12IN3­P1C

RB2/INT2/AN8/P1B

RB2
INT2
AN8
P1B

RB3/AN9/C12IN2-/CCP2

RB3
AN9
C12IN2-

(2)

CCP2

RB4/KBI0/AN11/P1D

RB4
KBI0
AN11
P1D

RB5/KBI1/PGM

RB5
KBI1
PGM

RB6/KBI2/PGC

RB6
KBI2
PGC

RB7/KBI3/PGD

RB7
KBI3
PGD

Legend: TTL= TTL compatible input CMOS = C MOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

Note 1: Default assi gnment for CCP2 when Configur ation bit CCP2MX is set.

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP,
SOIC

21 18

22 19

23 20

24 21

25 22

26 23

27 24

28 25

QFN

Pin

Type

I/O

I
I
I

I/O

I
I
I

O

I/O

I
I

O

I/O

I
I

I/O

I/O

I
I

O

I/O

I

I/O

I/O

I

I/O

I/O

I

I/O

Buffer

Type

TTL

ST
ST

Analog

TTL

ST
Analog
Analog

CMOS

TTL

ST
Analog

CMOS

TTL
Analog
Analog

ST

TTL

TTL
Analog

CMOS

TTL

TTL

ST

TTL

TTL

ST

TTL

TTL

ST

Description

PORTB is a bidirectional I/O port. PORTB can be software
programmed for internal weak pull-up on each input.

Digital I/O
External interrupt 0
PWM Fault input for CCP1
Analog input 12, ADC channel 12

Digital I/O
External interrupt 1
Analog input 10, ADC channel 10
Comparators C1 and C2 inverting input
Enhanced CCP1 PWM output

Digital I/O
External interrupt 2
Analog input 8, ADC channel 8
Enhanced CCP1 PWM output

Digital I/O
Analog input 9, ADC channel 9
Comparators C1 and C2 inverting input
Capture 2 input/Compare 2 output/PWM 2 output

Digital I/O
Interrupt-on-change pin
Analog input 11, ADC channel 11
Enhanced CCP1 PWM output

Digital I/O
Interrupt-on-change pin
Low-Voltage ICSP™ Programming enable pin

Digital I/O
Interrupt-on-change pin
In-Circuit Debugger and ICSP™ programming clock pin

Digital I/O
Interrupt-on-change pin
In-Circuit Debugger and ICSP™ programming data pin

DS40001303H-page 18  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 1-2: PIC18F2XK20 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Number

Pin Name

RC0/T1OSO/T13CKI

RC0
T1OSO
T13CKI

RC1/T1OSI/CCP2

RC1
T1OSI

(1)

CCP2

RC2/CCP1/P1A

RC2
CCP1
P1A

RC3/SCK/SCL

RC3
SCK
SCL

RC4/SDI/SDA

RC4
SDI
SDA

RC5/SDO

RC5
SDO

RC6/TX/CK

RC6
TX
CK

RC7/RX/DT

RC7
RX

DT
RE3 — — — — See MCLR
V

SS 8, 19 5, 16 P — Ground reference for logic and I/O pins
DD 20 17 P — Positive supply for logic and I/O pins

V
Legend: TTL= TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

Note 1: Default assignment for CCP2 when Configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP,
SOIC

11 8

12 9

13 10

14 11

15 12

16 13

17 14

18 15

QFN

Pin

Buffer

Type

I/O

O

I

I/O

I

Analog

I/O

I/O
I/O

O

CMOS

I/O
I/O
I/O

I/O

I

I/O

I/OOST

I/O

O

I/O

I/O

I

I/O

Type

PORTC is a bidirectional I/O port.

ST

—

ST

ST
ST

ST
ST

ST
ST
ST

ST
ST
ST

—

ST

—

ST

ST
ST
ST

Digital I/O
Timer1 oscillator output
Timer1/Timer3 external clock input

Digital I/O
Timer1 oscillator input
Capture 2 input/Compare 2 output/PWM 2 output

Digital I/O
Capture 1 input/Compare 1 outpu t
Enhanced CCP1 PWM output

Digital I/O
Synchronous serial clock input/output for SPI mode
Synchronous serial clock input/output for I

Digital I/O
SPI data in

2

C™ data I/O

I

Digital I/O
SPI data out

Digital I/O
EUSART asynchronous transmit
EUSART synchronous clock (see related RX/DT)

Digital I/O
EUSART asynchronous receive
EUSART synchronous data (see related TX/CK)

/VPP/RE3 pin

Description

2

C™ mode

 2010-2015 Microchip Technology Inc. DS40001303H-page 19

PIC18F2XK20/4XK20

TABLE 1-3: PIC18F4XK20 PINOUT I/O DESCRIPTIONS

Pin Name

/VPP/RE3

MCLR

MCLR
VPP
RE3

OSC1/CLKIN/RA7

OSC1

CLKIN

RA7

OSC2/CLKOUT/
RA6

OSC2
CLKOUT

RA6

Legend: TTL= TTL compatible input CMOS = C MOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

Note 1: Default assi gnment for CCP2 when Configur ation bit CCP2MX is set.

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP QFN TQFP UQFN

Pin Number

1181816

13 32 30 28

14 33 31 29

Pin

Type

I

P

I

I

I

I/O

O
O

I/O

Buffer

Type

ST
ST

ST

CMOS

TTL

—
—

TTL

Description

Master Clear (input) or programming voltage
(input)

Active-low Master Clear (device Reset) input
Programming voltage input
Digital input

Oscillator crystal or external clock input

Oscillator crystal input or external clock source
input
ST buffer when configured in RC mode;
analog otherwise
External clock source input. Always associated

with

pin function OSC1 (See related OSC1/CLKIN,
OSC2/CLKOUT pins)
General purpose I/O p i n

Oscillator crystal or clock output

Oscillator crystal output. Connects to crystal
or resonator in Crystal Oscillator mode
In RC mode, OSC2 pin outputs CLKOUT which
has 1/4 the frequency of OSC1 and denotes
the instruction cycle rate
General purpose I/O p i n

DS40001303H-page 20  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 1-3: PIC18F4XK20 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RA0/AN0/C12IN0-

RA0

AN0

C12IN0­RA1/AN1/C12IN0-

RA1

AN1

C12IN0­RA2/AN2/V

REF/C2IN+

CV

RA3/AN3/V
C1IN+

RA4/T0CKI/C1OUT

RA5/AN4/SS
DIN/C2OUT

RA6 See the OSC2/CLKOUT/RA6 pin
RA7 See the OSC1/CLKIN/RA7 pin

Legend: TTL= TTL compatible input CMOS = CMOS compatible input or output

Note 1: Default assignment for CCP2 when Configuration bit CCP2MX is set.

REF-/

RA2

AN2

REF-

V

REF

CV

C2IN+

REF+/

RA3

AN3

VREF+

C1IN+

RA4

T0CKI

C1OUT

/HLV-

RA5

AN4

SS

HLVDIN

C2OUT

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP QFN TQFP UQFN

Pin Number

21919

32020

42121

52222

62323

72424

Pin

Type

I/O

I
I

I/O

I
I

I/O

I
I

O

I

I/O

I
I
I

I/O

I

O

I/O

I
I
I

O

Buffer

Type

TTL
Analog
Analog

TTL
Analog
Analog

TTL
Analog
Analog
Analog
Analog

TTL
Analog
Analog
Analog

ST
ST

CMOS

TTL
Analog

TTL
Analog
CMOS

Description

PORTA is a bidirectional I/O port.

Digital I/O
Analog input 0, ADC channel 0
Comparator C1 and C2 inverting input

Digital I/O
Analog input 1, ADC channel 1
Comparator C1 and C2 inverting input

Digital I/O
Analog input 2, ADC channel 2
A/D reference voltage (low) input
Comparator reference voltage output
Comparator C2 non-inverting input

Digital I/O
Analog input 3, ADC channel 3
A/D reference voltage (high) input
Comparator C1 non-inverting input

Digital I/O
Timer0 external clock input
Comparator C1 output

Digital I/O
Analog input 4, ADC channel 4
SPI slave select input
High/Low-Voltage Detect input
Comparator C2 output

 2010-2015 Microchip Technology Inc. DS40001303H-page 21

PIC18F2XK20/4XK20

TABLE 1-3: PIC18F4XK20 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RB0/INT0/FLT0/
AN12

RB0
INT0
FLT0
AN12

RB1/INT1/AN10/
C12IN3-

RB1
INT1
AN10
C12IN3-

RB2/INT2/AN8

RB2
INT2
AN8

RB3/AN9/C12IN2-/
CCP2

RB3
AN9
C12IN23-

(2)

CCP2

RB4/KBI0/AN11

RB4
KBI0
AN11

RB5/KBI1/PGM

RB5
KBI1
PGM

RB6/KBI2/PGC

RB6
KBI2
PGC

RB7/KBI3/PGD

RB7
KBI3
PGD

Legend: TTL= TTL compatible input CMOS = C MOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

Note 1: Default assi gnment for CCP2 when Configur ation bit CCP2MX is set.

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP QFN TQFP UQFN

Pin Number

33 9 8

34 10 9

35 11 10

36 12 11

37 14 14

38 15 15

39 16 16

40 17 17

Pin

Type

I/O

I
I
I

I/O

I
I
I

I/O

I
I

I/O

I
I

I/O

I/O

I
I

I/O

I

I/O

I/O

I

I/O

I/O

I

I/O

Buffer

Type

TTL

ST
ST

Analog

TTL

ST
Analog
Analog

TTL

ST
Analog

TTL
Analog
Analog

ST

TTL

TTL
Analog

TTL

TTL

ST

TTL

TTL

ST

TTL

TTL

ST

Description

PORTB is a bidirectional I/O port. PORTB can
be software programmed for internal weak
pull-up on each input.

Digital I/O
External interrupt 0
PWM Fault input for Enhanced CCP1
Analog input 12, ADC channel 12

Digital I/O
External interrupt 1
Analog input 10, ADC channel 10
Comparator C1 and C2 inverting input

Digital I/O
External interrupt 2
Analog input 8, ADC channel 8

Digital I/O
Analog input 9, ADC channel 9
Comparator C1 and C2 inverting input
Capture 2 input/Compare 2 output/PWM 2
output

Digital I/O
Interrupt-on-change pin
Analog input 11, ADC channel 11

Digital I/O
Interrupt-on-change pin
Low-Volt age ICSP™ Programming enabl e p in

Digital I/O
Interrupt-on-change pin
In-Circuit Debugger and ICSP™
programming clock pin

Digital I/O
Interrupt-on-change pin
In-Circuit Debugger and ICSP™

programming data pin

DS40001303H-page 22  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 1-3: PIC18F4XK20 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RC0/T1OSO/
T13CKI

RC0
T1OSO
T13CKI

RC1/T1OSI/CCP2

RC1
T1OSI

(1)

CCP2

RC2/CCP1/P1A

RC2
CCP1
P1A

RC3/SCK/SCL

RC3
SCK

SCL

RC4/SDI/SDA

RC4
SDI
SDA

RC5/SDO

RC5
SDO

RC6/TX/CK

RC6
TX
CK

RC7/RX/DT

RC7
RX
DT

Legend: TTL= TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

Note 1: Default assignment for CCP2 when Configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP QFN TQFP UQFN

Pin Number

15 34 32

16 35 35

17 36 36

18 37 37

23 42 42

24 43 43

25 44 44

26 1 1

Pin

Buffer

Type

I/O

O

I

I/O

I

CMOS

I/O

I/O
I/O

O

I/O
I/O

I/O

I/O

I

I/O

I/OOST

I/O

O

I/O

I/O

I

I/O

Type

PORTC is a bidirectional I/O port.

ST

—

ST

ST
ST

ST
ST

—

ST
ST

ST

ST
ST
ST

—

ST

—

ST

ST
ST
ST

Digital I/O
Timer1 oscilla tor output
Timer1/Timer3 external clock input

Digital I/O
Timer1 oscillator input
Capture 2 input/Compare 2 output/PWM 2
output

Digital I/O
Capture 1 input/Compare 1 output/PWM 1
output
Enhanced CCP1 output

Digital I/O
Synchronous serial clock input/output for
SPI mode
Synchronous serial clock input/output for I

mode

Digital I/O
SPI data in

2

C™ data I/O

I

Digital I/O
SPI data out

Digital I/O
EUSART asynchronous transm it
EUSART sync hronous clock (see related RX/
DT)

Digital I/O
EUSART asynchronous receive
EUSART synchronous data (see related TX/

CK)

Description

2

C™

 2010-2015 Microchip Technology Inc. DS40001303H-page 23

PIC18F2XK20/4XK20

TABLE 1-3: PIC18F4XK20 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RD0/PSP0

RD0
PSP0

RD1/PSP1

RD1
PSP1

RD2/PSP2

RD2
PSP2

RD3/PSP3

RD3
PSP3

RD4/PSP4

RD4
PSP4

RD5/PSP5/P1B

RD5
PSP5
P1B

RD6/PSP6/P1C

RD6
PSP6
P1C

RD7/PSP7/P1D

RD7
PSP7
P1D

Legend: TTL= TTL compatible input CMOS = C MOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

Note 1: Default assi gnment for CCP2 when Configur ation bit CCP2MX is set.

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

PDIP QFN TQFP UQFN

Pin Number

19 38 38

20 39 39

21 40 40

22 41 41

27 2 2

28 3 3

29 4 4

30 5 5

Pin

Buffer

Type

Type

I/O
I/OSTTTL

I/O
I/OSTTTL

I/O
I/OSTTTL

I/O
I/OSTTTL

I/O
I/OSTTTL

I/O
I/O

O

I/O
I/O

O

I/O
I/O

O

Description

PORTD is a bidirectional I/O port or a Parallel
Slave Port (PSP) for interfacing to a
microprocessor port. Th es e p ins ha ve TTL input
buffers when PSP module is enabled.

Digital I/O
Parallel Slave Port data

Digital I/O
Parallel Slave Port data

Digital I/O
Parallel Slave Port data

Digital I/O
Parallel Slave Port data

Digital I/O
Parallel Slave Port data

ST

TTL

—

ST

TTL

—

ST

TTL

—

Digital I/O
Parallel Slave Port data
Enhanced CCP1 output

Digital I/O
Parallel Slave Port data
Enhanced CCP1 output

Digital I/O
Parallel Slave Port data
Enhanced CCP1 output

DS40001303H-page 24  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 1-3: PIC18F4XK20 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RE0/RD

RE1/WR/AN6

RE2/CS/AN7

RE3 — — — — — See MCLR
VSS 12, 31 6, 30, 316, 29 P — Ground reference for logic and I/O pins

/AN5
RE0
RD

AN5

RE1
WR

AN6

RE2
CS

AN7

PDIP QFN TQFP UQFN

Pin Number

82525

92626

10 27 27

Pin

Type

I/O

I
I

I/O

I
I

I/O

I
I

Buffer

Type

ST

TTL

Analog

ST

TTL

Analog

ST

TTL

Analog

Description

PORTE is a bidirectional I/O port

Digital I/O
Read control for Parallel Slave Port
(see related WR
Analog input 5, ADC channel 5

Digital I/O
Write control for Parallel Slave Port
(see related CS
Analog input 6, ADC channel 6

Digital I/O
Chip Select control for Parallel Slave Port
(see related RD
Analog input 7, ADC channel 7

/VPP/RE3 pin

and CS pins)

and RD pins)

and WR)

V

DD 11, 32 7, 8,

28, 29

NC — 13 12, 13,

Legend: TTL= TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input
O = Output P = Power

Note 1: Default assignment for CCP2 when Configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when Configuration bit CCP2MX is cleared.

7, 28 P — Positive supply for logic and I/O pins

— — No connect

33, 34

 2010-2015 Microchip Technology Inc. DS40001303H-page 25

PIC18F2XK20/4XK20

4 x PLL

FOSC<3:0>

Secondary Oscillator

T1OSCEN
Enable
Oscillator

T1OSO

T1OSI

Clock Source Option
for other Modules

OSC1

OSC2

Sleep

HSPLL, HFINTOSC/PLL

LP, XT, HS, RC, EC

T1OSC

CPU

Peripherals

IDLEN

Postscaler

MUX

MUX

16 MHz

8 MHz
4 MHz
2 MHz
1 MHz

250 kHz

500 kHz

OSCCON<6:4>

111
110
101
100

011
010
001
000

31 kHz

31 kHz
Source

Internal

Oscillator

Block

WDT, PWRT, FSCM

16 MHz

Internal Oscillator

(HFINTOSC)

Clock

Control

OSCCON<1:0>

Source

16 MHz

31 kHz (LFINTOSC)

OSCTUNE<6>

(1)

0

1

OSCTUNE<7>

and Two-Speed Start-up

Primary Oscillator

PIC18F2XK20/4XK20

Sleep

Sleep

Main

FOSC<3:0> OSCCON<1:0>

Note 1: Operates only when HFINTOSC is the primary oscillator.

2.0 OSCILLATOR MODULE (WITH FAIL-SAFE CLOCK MONITOR)

2.1 Overview

The oscillator module has a wide variety of clock
sources and selection features that allow it to be used
in a wide range of applications while maximizing
performance and minimizing power consumption.

Figure 2-1 illustrates a block diagram of the oscillator

module.
Clock sources can be configured from external

oscillators, quar tz cryst al resonator s, cerami c resonato rs
and Resistor-Capacitor (RC) circuits. In addition, the
system clock source can be configured from one of two
internal oscillators, with a choice of speeds select able via
software. Additional clo ck feat ures inc lud e:

• Selectable system clock source between external

or intern al via software.

• Tw o-Speed Start-up mode, which min im iz es

latency between external oscillator start-up and
code execution.

• Fail-Safe Clock Monitor (FSCM) designed to

detect a failure of the external clock source (LP,
XT, HS, EC or RC modes) and switch
automatically to the internal oscillator.

The oscillator module can be configured in one of ten
primary clock modes.

1. LP Low-Power Crystal

2. XT Crystal/Resonator

3. HS High-Speed Crystal/Resonator

4. HSPLL High-Speed Crystal/Resonator
with PLL enabled

5. RC External Resistor/Capacitor with

OSC/4 output on RA6

F

6. RCIO External Resistor/Cap acitor with I/O
on RA6

7. INTOSC Internal Oscillator with F

OSC/4

output on RA6 and I/O on RA7

8. INTOSCIO Internal Oscillator with I/O on RA6
and RA7

9. EC External Clock with F

OSC/4 output

10. ECIO External Clock with I/O on RA6

Primary Clock modes are selected by the FOSC<3:0>
bits of the CONFIG1H Configuration Register. The
HFINTOSC and LFINTOSC are factory calibrated
high-frequency and low-frequency oscillators,
respectively, which are used as the internal clock
sources.

FIGURE 2-1: PIC® MCU CLOCK SOURCE BLOCK DIAGRAM

DS40001303H-page 26  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

2.2 Oscillator Control

The OSCCON register (Register 2-1) controls several
aspects of the device clock’s operation, both in full
power operation and in power-ma nag ed mo des .

• Main System Clock Selection (SCS)

• Internal Frequency selection bits (IRCF)

• Clock Status bits (OSTS, IOFS)

• Power management selection (IDLEN)

2.2.1 MAIN SYSTEM CLOCK SELECTION

The System Clock Select bits, SCS<1:0>, select the
main clock source. The available clock sources are

• Primary clock defined by the FOSC<3:0> bits of
CONFIG1H. The primary clock can be the primary
oscillator, an external clock, or the internal
oscillator block.

• Secondary clock (Timer1 oscillator)

• Internal oscillator block (HFINTOSC and
LFINTOSC).

The clock source changes immediately after one or
more of the bits is written to, following a brief clock
transition interval. The SCS bits are cleared to select
the primary clock on all forms of Reset.

2.2.4 CLOCK STATUS

The OSTS and IOFS bits of the OSCCON reg ister , an d
the T1RUN bit of the T1CON register, indicate which
clock source is c urr e ntl y pr ov id in g the ma i n clo ck. The
OSTS bit indicates that the Oscillator Start-up Timer
has timed out and the primary clock is providing the
device cloc k. T he I OFS b it i ndi cat es wh en t he in ter nal
oscillator block has stabilized and is providing the
device clock in HFINTOSC Clock modes. The IOFS
and OSTS Status bits will both be set when
SCS<1:0> = 00 and HFINTOSC is the primary clock.
The T1RUN bi t indi cat es w hen t he Timer1 o sci llat or is
providing the device clock in secondary clock modes.
When SCS<1:0>  00, only one of these three bits will
be set at any time. If none of these bits are set, the
LFINTOSC is provid ing the clock or the HFINTO SC has
just started and is not yet stable.

2.2.5 POWER MANAGEMENT

The IDLEN bit of the OSCCON register determines if
the device goes into Sleep mode or one of the Idle
modes when the SLEEP instruction is executed.

The use of the flag and control bits in the OSCCON
register is discussed in more detail in Section 3.0

“Power-Managed Modes”.

2.2.2 INTERNAL FREQUENCY

SELECTION

The Internal Oscillator Frequency Select bits
(IRCF<2:0>) select the fr equenc y output of th e interna l
oscillator block. The choices are th e LFINTOSC source
(31 kHz), the HFINTOSC source (16 MHz) or one of
the frequencies derived from the HFINTOSC
postscaler (31.25 kHz to 8 MHz). If the internal
oscillator block is supplying the main clock, changing
the states of these bits will have an immediate change
on the internal oscillator’s output. On device Resets,
the output frequency of the internal oscillator is set to
the default frequency of 1 MHz.

2.2.3 LOW FREQUENCY SELECTION

When a nominal ou tput frequenc y of 31 kHz is selected
(IRCF<2:0> = 000), users may choo se which inte rnal
oscillator acts as the source. This is done with the
INTSRC bit of the OSCTUNE register. Setting this bit
selects the HFINTOSC as a 31.25 kHz clock source by
enabling the divide-by-512 output of the HFINTOSC
postscaler. Clearing INTSRC selects LFINTOSC
(nominally 31 kHz) as the clock source.

This option allows users to select the tunable and more
precise HFINTOSC as a clock source, while
maintaining p ower savings w ith a very lo w clock spee d.
Regardless of the setting of INTSRC, LFINTOSC
always remains the clock source for features such as
the Watchdog Timer and the Fail-Safe Clock Monitor.

Note 1: The Timer1 os ci ll ator must be enabled to

select the s econdary clock source. The
Timer1 os cillator is enabled by s etting the
T1OSCEN bit of the T1CON register. If
the Timer1 oscillator is not enabled, then
the main oscillator will continue to run
from the previ o us ly sel e ct ed so ur c e. The
source will then switch to the secondary
oscillator after the T1OSCEN bit is set.

2: It is recommended that the Timer1

oscillator be operating and stable before
selecting the secondary clock source or a
very long delay may occur while the
Timer1 oscillator starts.

 2010-2015 Microchip Technology Inc. DS40001303H-page 27

PIC18F2XK20/4XK20

REGISTER 2-1: OSCCON: OSCILLATOR CONTROL REGISTER

R/W-0 R/W-0 R/W-1 R/W-1 R-q R-0 R/W-0 R/W-0
IDLEN IRCF2 IRCF1 IRCF0 OSTS

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’ q = depends on condition

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 IDLEN: Idle Enable bit

1 = Device enters Idle mode on SLEEP instruction
0 = Device enters Slee p mode on SLEEP instruction

bit 6-4 IRCF<2:0>: Internal Oscillator Frequency Select bits

111 = 16 MHz (HFINTOSC drives clock directly)
110 = 8 MHz
101 = 4 MHz
100 = 2 MHz
011 = 1 MHz
010 = 500 kHz
001 = 250 kHz
000 = 31 kHz (from either HFINTOSC/512 or LFINTOSC directly)

bit 3 OSTS: Oscillator Start-up Time-out Status bit

1 = Device is running from the clock defined by FOSC<2:0> of the CONFIG1 register
0 = Device is running from the internal oscillator (HFINTOSC or LFINTOSC)

bit 2 IOFS: HFINTOSC Frequency Stable bit

1 = HFINTOSC frequency is stable
0 = HFINTOSC frequency is not stable

bit 1-0 SCS<1:0>: System Clock Select bits

1x = Internal oscillator block
01 = Secondary (Timer1) oscillator
00 = Primary clock (determined by CONFIG1H[FOSC<3:0>]).

(3)

(1)

(1)

IOFS SCS1 SCS0

(2)

Note 1: Reset state depends on state of the IESO Configuration bit.

2: Source selected by the INTSRC bit of the OSCTUNE register, see text.
3: Default output frequency of HFINTOSC on Reset.

DS40001303H-page 28  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

OSC1/CLKIN

OSC2/CLKOUT

(1)

I/O

Clock from
Ext. System

PIC

®

MCU

Note 1: Alternate pin functions are listed in

Section 1.0 “Device Overview”.

2.3 Clock Source Modes

Clock Source modes can be classified as external or
internal.

• External Clock mod es re ly on external circ uitry for
the clock source. Examples are: Clock modules
(EC mode), quartz crystal resonators or ceramic
resonators (LP, XT and HS modes) and Resistor­Capacitor (RC mode) circuits.

• Internal clock sources are contained internally
within the Oscillator block. The Oscillator block
has two internal oscillators: the 16 MHz
High-Frequency Internal Oscillator (HFINTOSC)
and the 31 kHz Low-Frequency Internal Os cillator
(LFINTOSC).

The system clock can be selected between external or
internal clock sources via the System Clock Select
(SCS<1:0>) bits of the OSCCON register. See

Section 2.9 “Clock Switching” for additional

information.

2.4 External Clock Modes

2.4.1 OSCILLATOR START-UP TIMER (OST)

When the oscil lat or modu le i s conf igu red f or LP, XT or
HS modes, th e Osc illa tor Start-up Timer (O ST) c oun ts
1024 oscillations from OSC1. This occurs following a
Power-on Reset (POR) and when the Power-up Timer
(PWRT) has expired (if configured), or a wake-up from
Sleep. During this time, the program counter does not
increment and program execution is suspended. The
OST ensures that the oscillator circuit, using a quartz
crystal resonator o r ce ramic res onator, has started and
is providing a stable system clock to the oscillator
module. When switching between clock sources, a
delay is required to allow the new clock to stabilize.
These oscillator delays are shown in Table 2-1.

In order to minimize laten cy between externa l oscillator
start-up and code execution, the Two-Speed Clock
Start-up mode can be selected (see Section 2.10

“Two-Speed Clock Start-up Mode”).

TABLE 2-1: OSCILLATOR DELAY EXAMPLES

Switch From Switch To Frequency Oscillator Delay

Sleep/POR
Sleep/POR EC, RC DC – 64 MHz 2 instructi on cycles

LFINTOSC (31 kHz) EC, RC DC – 64 MHz 1 cycle of each

Sleep/POR LP, XT, HS 32 kHz to 40 MHz 1024 Clock Cycles (OST)
Sleep/POR HSPLL 32 MHz to 64 MHz 1024 Clock Cycles (OST) + 2 ms

LFINTOSC (31 kHz) HFINTOSC 250 kHz to 16 MHz 1 s (approx.)

LFINTOSC

HFINTOSC

31 kHz

250 kHz to 16 MHz

Oscillator Warm-Up Delay (T

WARM)

2.4.2 EC MODE

The External Clock (EC) mode allows an externally
generated logic level as the system clock source. When
operating in this mode, an external clock source is
connected to the OSC1 input and the OSC2 is available
for general purpose I/O. Figure 2-2 shows the pin
connections for EC mode.

The Oscillator Start-up Timer (OST) is disabled when
EC mode is selected. Therefore, there is no delay in
operation after a Power-on Reset (POR) or wake-up
from Sleep. Because the PIC
static, stopping the external clock input will have the
effect of halting the device while leaving all data intact.
Upon restarting the external clock, the device will
resume operation as if no time had elapsed.

 2010-2015 Microchip Technology Inc. DS40001303H-page 29

FIGURE 2-2: EXTERNAL CLOCK (EC)

MODE OPERATION

®

MCU design is fully

PIC18F2XK20/4XK20

Note 1: A series resistor (RS) may be required for

quartz crystals with low drive level.

2: The value of R

F varies with the Oscillator mode

selected (typically between 2 M to 10 M.

C1

C2

Quartz

R

S

(1)

OSC1/CLKIN

RF

(2)

Sleep

To Internal
Logic

PIC® MCU

Crystal

OSC2/CLKOUT

Note 1: A series resistor (RS) may be required for

ceramic resonators with low drive level.

2: The value of R

F varies with the Oscillator mode

selected (typically between 2 M to 10 M.

3: An additional parallel feedback resistor (R

P)

may be required for proper ceramic resonator
operation.

C1

C2

Ceramic

R

S

(1)

OSC1/CLKIN

RF

(2)

Sleep

To Internal
Logic

PIC® MCU

RP

(3)

Resonator

OSC2/CLKOUT

2.4.3 LP, XT, HS MODES

The LP, XT and HS modes support the use of quartz
crystal resonators or ceramic resonators connected to
OSC1 and OSC2 (Figure 2-3). The mode selects a low ,
medium or high gain setting of the internal inverter­amplifier to support v arious resonato r types and spee d.

LP Oscillator mode selects the lowest gain setting of the
internal inverter-amplifier. LP mode current consum ption
is the least of the three modes. This mode is best suited
to drive resonators with a l ow drive level specification , for
example, tuning fork type crystals.

XT Oscillator mode selects the intermediate gain
setting of the internal inverter-amplifier. XT mode
current consumption is the medi um of the three modes.
This mode is best suited to drive resonators with a
medium drive level specification.

HS Oscillator mode select s the highest gain setting of the
internal inverter-amplifie r. H S mode current consum ption
is the highest of the three modes. This mode is best
suited for resonators that require a high drive setting.

Figure 2-3 and Figure 2-4 show typical circuits for

quartz crystal and ceramic resonators, respectively.

FIGURE 2-3: QUARTZ CRYSTAL

OPERATION (LP, XT OR
HS MODE)

Note 1: Quartz crystal characteristics vary

according to type, package and
manufacturer. The u ser should consult th e
manufacturer data sh eets for specif ica tions
and recommended appl ication .

2: Always verify oscillator perform ance ov er

DD and temperature range that is

the V
expected for the application.

3: For oscillator design assistance, reference

the following Microchip Applications Notes:

• AN826, “Crystal Oscillator Basics and

Crystal Selection for rfPIC

®

and PIC®

Devices” (DS00826)

®

• AN849, “Basic PIC

Oscillator Design”

(DS00849)

®

• AN943, “Practical PIC

Oscillator

Analysis and Design” (DS00943)

• AN949, “Making Your Oscillator Work”
(DS00949)

FIGURE 2-4: CERAMIC RESONATOR

OPERATION
(XT OR HS MODE)

DS40001303H-page 30  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

OSC2/CLKOUT

(1)

CEXT

REXT

PIC® MCU

OSC1/CLKIN

F

OSC/4 or

Internal

Clock

VDD

VSS

Recommended values: 10 k  REXT  100 k

C

EXT > 20 pF

Note 1: Alternate pin functions are listed in

Section 1.0 “Device Overview”.

2: Output depends upon RC or RCI O clock mod e.

I/O

(2)

2.4.4 EXTERNAL RC MODES

The external Resistor-Capacitor (RC) modes support
the use of an external RC circuit. This allows the
designer maximum flexibility in frequency choice while
keeping costs to a minimum when clock accuracy is not
required. There are two modes: RC and RCIO.

2.4.4.1 RC Mode

In RC mode, the RC circuit connects to OSC1. OSC2/
CLKOUT outputs the RC oscillator frequency divided
by 4. This signal may be used to provide a clock for
external circuitry, synchronization, calibration, test or
other application requirements. Figure 2-5 shows the
external RC mode connections.

FIGURE 2-5: EXTERNAL RC MODES

2.4.4.2 RCIO Mode

In RCIO mode, the RC circuit is connected to OSC1.
OSC2 becomes an additional general purpose I/O pin.

The RC oscillator frequency is a function of the supply
voltage, the resistor (R
and the operating temperature. Other factors affecting
the oscillator frequency are:

• input threshold voltage variation

• component tolerances

• packaging variations in capacitance
The user also needs to take into account variation due

to tolerance of external RC components used.

EXT) and capacitor (CEXT) values

2.5 Internal Clock Modes

The oscillator module has two independent, internal
oscillators that can be configured or selected as the
system clock sou rce.

1. The HFINTOSC (High-Frequency Internal
Oscillator) is factory calibrated and operates at
16 MHz. The frequency of the HFINTOSC can
be user-adjusted via software using the
OSCTUNE register (Register 2-2).

2. The LFINTOSC (Low-Frequency Internal
Oscillator) operates at 31 kHz.

The system cloc k speed can be selecte d via softwar e
using the Internal Oscillator Frequency Select bits
IRCF<2:0> of the OSCCON register.

The system clock ca n be se lec ted betw ee n external or
internal cloc k sourc es via th e System Cl ock Select ion
(SCS<1:0>) bits of the OSCCON register. See

Section 2.9 “Clock Switching” for more information.

2.5.1 INTOSC AND INTOSCIO MODES

The INTOSC and INTOSCIO modes configure the
internal oscillators as the primary clock source. The
FOSC<3:0> bits in the CONFIG1H Configuration
register determine which mode is selected. See

Section 23.0 “Special Feat ures of the CPU” for more

information.
In INTOSC mode, OSC1/CLKIN is available for general

purpose I/O. OSC2/CLKOUT outputs the selected
internal oscillator fre quency div ided by 4. The C LKOUT
signal may be used to provide a clock for external
circuitry, synchronization, calibration, test or other
application requirements.

In INTOSCIO mode, OSC1/CLKIN and OSC2/CLKOUT
are available for general purpose I/O.

2.5.2 HFINTOSC

The output of the HFINTOSC connects to a postscaler
and multiplexer (see Figure 2-1). One of eight
frequencies can be selected via software using the
IRCF<2:0> bits of the OSCCON register. See

Section 2.5.4 “Frequency Select Bits (IRCF)” for

more information.
The HFINTOSC is enabled when:

•SCS1 = 1 and IRCF<2:0>  000

•SCS1 = 1 and IRCF<2:0> = 000 and INTSRC = 1

• IESO bit of CONFIG1H = 1 enabling Two-Speed

Start-up.

• FCMEM bit of CONFIG1H = 1 enabling

Two-Speed Start-up and Fail-Safe mode.

• FOSC<3:0> of CONFIG1H selects the internal

oscillator as the primary clock

The HF Internal Oscillator (IOFS) bit of the OSCCON
register indicates whether the HFINTOSC is stable or not.

 2010-2015 Microchip Technology Inc. DS40001303H-page 31

PIC18F2XK20/4XK20

2.5.2.1 OSCTUNE Register

The HFINTOSC is factory calibrated but can be
adjusted in software by writing to the TUN<5:0> bits of
the OSCTUNE register (Register 2-2).

The defaul t value of the TUN<5: 0> is ‘000000’. The
value is a 6-bit two’s complement number.

When the OSCTUNE register is modified, the
HFINTOSC frequency will begin shifting to the new
frequency. Code execution continues during this shift.
There is no indication that the shift has occurred.

OSCTUNE does not affect the LFINTOSC frequency.
Operation of features that depend on the LFINTOSC
clock source frequency, such as the Power-up Timer

(PWRT), Watchdog Timer (WDT), Fail-Safe Clock
Monitor (FSCM) and peripherals, are not af fected by the
change in frequency.

The OSCTUNE register also implements the INTSRC
and PLLEN bits, which control certain features of the
internal oscillator block.

The INTSRC bit allows users to select which internal
oscillator pr ovides the clock sourc e when the 31 kHz
frequency option is se lected . This is c overed in great er
detail in Section 2.2.3 “Low Frequency Selection”.

The PLLEN bit controls the operation of the frequency
multiplier, PLL, in internal oscillator modes. For more
details about the function of the PLLEN bit see

Section 2.6.2 “PLL in HFINTOSC Modes”

REGISTER 2-2: OSCTUNE: OSCILLATOR TUNING REGISTER

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

INTSRC PLLEN

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

(1)

TUN5 TUN4 TUN3 TUN2 TUN1 TUN0

bit 7 INTSRC: Internal Oscillator Low-Frequency Source Select bit

1 = 31.25 kHz device clock derived from 16 MHz HFINTOSC source (divide-by-512 enabled)
0 = 31 kHz device clock derived directly from LFINTOSC internal oscillator

bit 6 PLLEN: Frequency Multiplier PLL for HFINTOSC Enable bit

1 = PLL enabled for HFINTOSC (8 MHz and 16 MHz only)
0 = PLL disabled

bit 5-0 TUN<5:0>: Frequency Tuning bits

011111 = Maximum frequency
011110 =

• • •

000001 =
000000 = Oscillator module is running at the factory calibrated frequency.
111111 =

• • •
100000 = Minimum frequen cy

Note 1: The PLLEN bit is active only when the HFINTOSC is the primary clock source (FOSC<2:0> = 100X) and

the selected frequ ency is 8 M Hz or 16 MHz . Othe rwise, th e PLLEN bit is unav ailabl e and a lways reads ‘ 0’.

(1)

DS40001303H-page 32  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

2.5.3 LFINTOSC

The Low-Frequency Internal Oscillator (LFINTOSC) is
a 31 kHz internal clock source.

The output of the LFINTOSC connects to internal
oscillator block frequency selection multiplexer (see

Figure 2-1). Select 31 kHz, via software, using the

IRCF<2:0> bits of the OSCCON register and the
INTSRC bit of the OSCTUNE register. See

Section 2.5.4 “Frequency Select Bits (IRCF)” for

more information. The LFINTOSC is also the frequency
for the Power-up Timer (PWRT), Watchdog Timer
(WDT) and Fail-Safe Clock Monitor (FSCM).

The LFINTOSC is enabled when any of the following
are enabled:

• IRCF<2:0> bits of the OSCCON register = 000 and
INTSRC bit of the OSCTUNE register = 0

• Power-up Timer (PWRT)

• Watchdog Timer (WDT)

• Fail-Safe Clock Monitor (FSCM)

2.5.4 FREQUENCY SELECT BITS (IRCF)

The output of the 16 MHz HFINTOSC and 31 kHz
LFINTOSC connects to a postscaler and multiplexer
(see Figure 2-1). The Internal Oscillator Frequency
Select b its IRCF<2:0> of the OSCCON register select
the output frequency of the internal oscillators. One of
eight frequencies can be selected via software:

•16 MHz

•8 MHz

•4 MHz

•2 MHz

• 1 MHz (Default after Reset)

• 500 kHz

• 250 kHz

• 31 kHz (LFINTOSC or HFINTOSC/512)

Note: Following any Reset, the IRCF<2:0> bits

of the OSCCON register are set to ‘011’
and the frequency selection is set to
1 MHz. The user can modify the IRCF bi ts
to select a different frequency.

2.5.5 HFINTOSC FREQUENCY DRIFT

The factory calibrates the internal oscillat or block output
(HFINTOSC) for 16 MHz. However, this frequency may
drift as V
controller operation in a variety of ways. It is possible to
adjust the HFINTOSC frequency by modifying t he value
of the TUN<5:0> bits in the OSCTUNE register. This has
no effect on the LFINTOSC clock source frequency.

Tuning the HFINT OSC source requires knowing when to
make the adjustment, in which direction it should be
made and in some cases, how large a change is
needed. Three possible compensation techniques are
discussed in the following sections, however other
techniques may be used.

DD or temperature changes, which can affect the

2.5.5.1 Compensating with the EUSART

An adjustment may be required when the EUSART
begins to generate fra ming errors or recei ves dat a with
errors while in Asynchronous mode. Framing errors
indicate that the device clock frequency is too high; to
adjust for this, decrement the value in OSCTUNE to
reduce the clock frequency. On the other hand, errors
in data may suggest that the clock speed is too low; to
compensate, increment OSCTUNE to increase the
clock frequency.

2.5.5.2 Compensating with the Timers

This technique compares device clock speed to some
reference clock. Two timers may be used; one timer is
clocked by the peripheral clock, while the other is
clocked by a fixed reference source, such as the
Timer1 oscillator.

Both timers are cleared, but the timer clocked by the
reference generates interrupts. When an interrupt
occurs, the internally clocked timer is read and both
timers are cleared. If the internally clocked timer value
is greater than expected, then the internal oscillator
block is r unni ng to o fas t. To adjust for thi s, d ecrem ent
the OSCTUNE register.

2.5.5.3 Compensating with the CCP Module
in Capture Mode

A CCP module can use f r ee ru nnin g Timer1 (or Timer3),
clocked by th e internal osci llator block and an external
event with a known period (i.e., AC power frequency).
The time of the first event is captured in the
CCPRxH:CCPRxL registers and is recorded for use la ter .
When the second event causes a capture, the time of the
first event is subtracted from the time of the second
event. Since the period of the external event is known,
the time difference between events can be calculated.

If the measured time is much greater than the calcu­lated time, the internal oscillator block is running too
fast; to compensate, decrement the OSCTUNE register.
If the measured time is much less than the calculate d
time, the internal oscillator block is runn ing t oo slow; to
compensate, increment the OSCTUNE register.

 2010-2015 Microchip Technology Inc. DS40001303H-page 33

PIC18F2XK20/4XK20

MUX

VCO

Loop
Filter

Crystal

Osc

OSC2

OSC1

PLL Enable

F

IN

FOUT

SYSCLK

Phase

Comparator

HS Oscillator Enable

4

(from Configuration Register 1H)

HS Mode

2.6 PLL Frequency Multiplier

A Phase-Locked Loop (PLL) circuit is provided as an
option for users who wish to use a lower frequency
oscillator circuit or to clock the device up to its highest
rated frequency from the crys ta l osci lla tor. This may be
useful for customers who are concerned with EMI due
to high-frequency crystals or users who require higher
clock speeds from an internal oscillator. There are
three cond itions when the PLL can be used:

• When the primary clock is HSPLL

• When the primary clock is HFINTOSC and the
selected frequency is 16 MHz

• When the primary clock is HFINTOSC and the
selected frequency is 8 MHz

2.6.1 HSPLL OSCILLATOR MODE

The HSPLL mode mak es use of the HS mode os cillator
for frequencies up t o 16 MHz. A PLL then multipl ies the
oscillator output frequency by 4 to produce an internal
clock frequency up to 64 MHz. The PLLEN bit of the
OSCTUNE register is a ctive on ly w hen the HFINT OSC
is the primary clock and is not available in HSPLL
oscillator mode.

The PLL is only available to the primary oscillator when
the FOSC<3:0> Configurat ion bit s are p rogramm ed for
HSPLL mode (= 0110).

2.6.2 PLL IN HFINTOSC MODES

The 4x frequency multiplier can be used with the
internal oscillator block to produce faster device clock
speeds than are normally possible with an internal
oscillator. When enabled, the PLL produces a clock
speed of up to 64MHz.

Unlike HSPLL mode, the PLL is controlled through
software. The PLLEN control bit of the OSCTUNE
register is used to enable or disable the PLL operation
when the HFINTOSC is used.

The PLL is available when the device is configured to
use the internal oscillator block as its primary clock
source (FOSC<3:0> = 1001 or 1000). Additionally, the
PLL will only function when the selected output fre­quency is either 8 MHz or 16 MHz (OSCCON<6:4> =
111 or 110). If both of these conditions are not met, the
PLL is disabled.

The PLLEN control bit is only functional in those
internal oscillator m ode s w h ere t he PL L is av ai lab le. In
all other modes, it is forced to ‘0’ and is effectively
unavailable.

FIGURE 2-6: PLL BLOCK DIAGRAM

(HS MODE)

DS40001303H-page 34  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

2.7 Effects of Power-Managed Modes on the Various Clock Sources

For more information about the modes discussed in this
section see Section 3.0 “Power-Managed Modes”. A
quick reference list is also available in Table 3-1.

When PRI_IDLE mode is selected, the designated
primary oscillator continues to run without interruption.
For all other power-managed modes, the oscillator
using the OSC1 pin is disabled. The OSC1 pin (and
OSC2 pin, if used by the o scillat or) will sto p oscil lating.

In secondary clock modes (SEC_RUN and
SEC_IDLE), the Timer1 oscillator is operating and
providing the device clock. The Timer1 oscillator may
also run in all power-managed modes if required to
clock Timer1 or Timer3.

In internal oscillator modes (INTOSC_RUN and
INTOSC_IDLE), the internal oscillator block provides
the device clock source. The 31 kHz LFINTOSC output
can be used directly to provide the clock and may be
enabled to support variou s special feature s, regardless
of the power-managed mode (see Section 23.2

“Watchdog Timer (WDT)”, Section 2.10 “Two­Speed Clock S t art-up Mo de” and Se ction 2.11 “Fail­Safe Clock Monitor” for more information on WDT,

Fail-Safe Clock Monitor and Two-Speed Start-up). The
HFINTOSC output at 16MHz may be used directly to
clock the device or may be divided down by the
postscaler. The HFINTOSC output is disabled if the
clock is provided directly from the LFINTOSC output.

If the Sleep mode is selected, all clock sources are
stopped. Since all the transistor switching currents
have been stopped, Sleep mode achieves the lowest
current consumption of the device (only leakage
currents).

Enabling any on-chip feature that will operate during
Sleep will increas e the current cons umed during S leep.
The LFINTOSC is required to support WDT operation.
The Timer1 oscillator may be operating to support a
real-time clock. Other features may be operating that
do not require a device clock source (i.e., SSP slave,
PSP, INTn pins and others). Peripherals that may add

significant current consumption are listed in

Section TABLE 26-8: “Peripheral Supply Current,
PIC18F2XK20/4XK20”.

2.8 Power-up Delays

Power-up delays are controlled by two timers, so that
no external Rese t c ircui try is required for mos t a ppl ic a­tions. The delays ensure that the device is kept in
Reset until the device powe r supply i s stable under nor­mal circumstan ces and the pri mary clock is ope rating
and stable. For additional information on power-up
delays, see Section 4.5 “Device Reset Timers”.

The first timer is the Power-up Timer (PWRT), which
provides a fixed delay on power-up (parameter 33,

Table ). It is enabled by clearing (= 0) the PWRTEN

Configuration bit.
The second timer is the Oscillator Start-up Timer

(OST), intended to keep the chip in Reset until the
crystal oscillator is stable (LP, XT and HS modes). The
OST does this by counting 1024 oscillator cycles
before allowing the oscillator to clock the device.

When the HSPLL Oscillator mode is selected, the
device is kept in Res et for an add iti onal 2ms, following
the HS mode OST delay, so the PLL can lock to the
incoming clock frequ enc y.

There is a delay of interval T
following POR, while the controller becomes ready to
execute instructions. This delay runs concurrently with
any other delays. This may be the only delay that
occurs when any of the EC, RC or INTIO modes are
used as the primary clock source.

When the HFINTOSC is selecte d as the prim ary clo ck ,
the main system clock can be delayed until the
HFINTOSC is stable. This is user selectable by the
HFOFST bit of the CONFIG3H Configuration register.
When the HFOFST bit is cleare d the main system cloc k
is delayed until the HFINTOSC is stable. When the
HFOFST bit is set the main system clock starts
immediately. In either case the IOFS bit of the
OSCCON register can be read to determine whether
the HFINTOSC is operating and stable.

CSD (parameter 38, Table ),

TABLE 2-2: OSC1 AND OSC2 PIN STATES IN SLEEP MODE

OSC Mode OSC1 Pin OSC2 Pin

RC, INTOSC Floating, external resistor should pull high At logic low (clock/4 output)
RCIO Floating, external resistor should pull high Configured as PORTA, bit 6
INTOSCIO Configured as PORTA, bit 7 Configured as PORTA, bit 6
ECIO Floating, pulled by external clock Configured as PORTA, bit 6
EC Floating, pulled by external clock At logic low (clock/4 output)
LP, XT, HS and HSPLL Feedback inverter disabled at quiescent

voltage level

Note: See Table 4-2 in Section 4.0 “Reset” for time-outs due to Sleep and MCLR

 2010-2015 Microchip Technology Inc. DS40001303H-page 35

Feedback inverter disabled at quiescent
voltage level

Reset.

PIC18F2XK20/4XK20

2.9 Clock Switching

The system clock source can be switched between
external and internal clock sources via software using
the System Clock Select (SCS<1:0>) bits of the
OSCCON register.

PIC18F2XK20/4XK20 devices contain circuitry to
prevent clock “glitches” when switching between clock
sources. A short pause in the device clock occurs
during the clock switch. The length of this pause is the
sum of two cycles of the old clock source and three to
four cycles of the new clock source. This formula
assumes that the new clock source is stable.

Clock transitions are discussed in greater detail in

Section 3.1.2 “Entering Power-Managed Modes”.

2.9.1 SYSTEM CLOCK SELECT (SCS<1:0>) BITS

The System Clock Select (SCS<1:0>) bits of the
OSCCON register select the system c lock sou rce that
is used for t he CPU and peripherals.

• When SCS<1:0> = 00, the system clock source is

determined by configuration of the FOSC<2:0>
bits in the CONFIG1H Configuration register.

• When SCS<1:0> = 10, the system clock source is

chosen by the internal oscillator frequency
selected by the INTSRC bit of the OSCTUNE
register and the IRC F < 2 : 0 > bits of the O S CCON
register.

• When SCS<1:0> = 01, the system clock source is

the 32.768 kHz secondary oscillator shared with
Timer1.

After a Reset, the SCS<1:0> bits of the OSCCON
register are always cleared.

Note: Any automatic clock switch, which may

occur from Two-Speed Start-up or Fail­Safe Clock Monitor, does not update the
SCS<1:0> bits of the OSCCON register.
The user can monitor the T1RUN bit of the
T1CON register and the IOFS and OSTS
bits of the OSCCON register to determine
the current system clock source.

2.9.3 CLOCK SWITCH TIMING

When switching between one oscillator and another,
the new oscillator may not be operating which saves
power (see Figure 2-7). If this is the case, there is a
delay afte r the SCS<1:0> bits of the OSCCON register
are modified before the f requency change takes pl ac e.
The OSTS and IOFS bits of the OSCCON register will
reflect the current active status of the external and
HFINTOSC oscillators. The timing of a frequency
selection is as follows:

1. SCS<1:0> bits of the OSCCON register are mod­ified.

2. The ol d c lo ck co nti nue s to ope rate until the new
clock is ready.

3. Clock switch circuitr y waits for two cons ecutive
rising edges of the old clock after the new clock
ready signal goes true.

4. The s yst e m clo ck is h eld low starting at t he nex t
falling edge of the old clock.

5. Clock switc h cir cui try waits for an additional two
rising edges of the new clock.

6. On the next falling e dge of th e new clo ck the l ow
hold on the system clock is released and new
clock is switched in as the syst em cl ock .

7. Clock switch is complete.

See Figure 2-1 for more details.
If the HFINTOSC i s the so urc e of b oth th e o ld an d new

frequency, there is no start-up delay before the new
frequency is active. This is because the old and new
frequencies are derived from the HFINTOSC via the
postscaler and multiplexer.

Start-up delay specifications are located in

Section 26.0 “Electrical Specifications”, under AC

Specifications (Oscillator Module).

2.9.2 OSCILLATOR START-UP TIME-OUT STATUS (OSTS) BIT

The Oscillator Start-up Time-out Status (OSTS) bit of
the OSCCON register indicates whether the system
clock is running from the external clock source, as
defined by the FOSC<3:0> bits in the CONFIG1H
Configuration register, or from the internal clock
source. In particular, when the primary oscillator is the
source of the primary clock, OSTS indicates that the
Oscillator Start-up Timer (OST) h as timed out for LP,
XT or HS modes.

DS40001303H-page 36  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

2.10 Two-Speed Clock Start-up Mode

Two-Speed Start-up mode provides additional power
savings by minimizing the latency between external
oscillator start-up and code execution. In applications
that make heavy use of the Sleep mode, Two-Speed
Start-up will remove the external oscillator start-up
time from the time spent awake and can reduce the
overall power consumption of the device.

This mode allows the application to wake-up from
Sleep, perform a few instructions using the HFINTOSC
as the clock source and go back to Sleep without
waiting for the primary oscillator to become stable.

Note: Executing a SLEEP instruction will abort

the oscillator start-up time and will cause
the OSTS b it of the OSCCON register to
remain clear.

When the oscillator module is configur ed for LP, XT or
HS modes, the Oscillator Start-up Timer (OST) is
enabled (see Section 2.4.1 “Oscillator Start-up Timer

(OST)”). The OST will suspend program execution until

1024 oscillations are counted. Two-Speed Start-up
mode minimizes the delay in code execution by
operating from the internal oscillator as the OST is
counting. When the OST count reaches 102 4 and the
OSTS bit of the OSCCON register is set, program
execution switches to the external oscillator.

2.10.2 TWO-SPEED START-UP SEQUENCE

1. Wake-up from Power-on Reset or Sleep.

2. Instructions begin executing by the internal

oscillator at the frequency set in the IRCF<2:0>
bits of the OSCCON register.

3. OST enabled to count 1024 external clock

cycles.

4. OST timed out. External clock is ready.

5. OSTS is set.

6. Clock switch finishes according to FIGURE 2-7:

“Clock Switch Timing”

2.10.3 CHECKING TWO-SPEED CLOCK STATUS

Checking th e state of the OSTS bit of the OSCCON
register will confirm if the microcontroller is running
from the external clock source, as defined by the
FOSC<2:0> bits in CONFIG1H Configuration register,
or the internal oscillator. OSTS = 0 when the external
oscillator is not ready, which indicates that the system
is running from the internal oscillator.

2.10.1 TWO-SPEED START-UP MODE CONFIGURATION

Two-Speed Start-up mode is enabled when all of the
following settings are configured as noted:

• Two-Speed Start-up mode is enabled by setting

the IESO of the CONFIG1H Configuration register
is set. Fail-Safe mode (FCMEM = 1) also enables
two-speed by default.

• SCS<1:0> (of the OSCCON register) = 00.

• FOSC<2:0> bits of the CONFIG1H Configuration

register are configured for LP, XT or HS mode.

Two-Speed Start-up mode becomes active after:

• Power-on Reset (POR) and, if enab led, after

Power-up Timer (PWRT) has expired, or

• Wake-up from Sleep.

If the external clock oscillator is configured to be
anything other than LP, XT or HS mode, then
Two-Speed Start-up is disabled. This is because the
external clock oscillator does not require any
stabilization time after POR or an exit from Sleep.

 2010-2015 Microchip Technology Inc. DS40001303H-page 37

PIC18F2XK20/4XK20

Old Clock

New Clock

IRCF <2:0>

System Clock

Start-up Time

(1)

Clock Sync Running

High Speed Low Speed

Select Old

Select New

New Clk Ready

Low Speed High Speed

Old Clock

New Clock

IRCF <2:0>

System Clock

Start-up Time

(1)

Clock Sync Running

Select Old Select New

New Clk Ready

Note 1: Start-up time includes TOST (1024 TOSC) for external clocks, plus TPLL (approx. 2 ms) for HSPLL mode.

FIGURE 2-7: CLOCK SWITCH TIMING

DS40001303H-page 38  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

External

LFINTOSC

÷ 64

S

R

Q

31 kHz

(~32 s)

488 Hz

(~2 ms)

Clock Monitor

Latch

Clock

Failure

Detected

Oscillator

Clock

Q

Sample Clock

2.11 Fail-Safe Clock Monitor

The Fail-Safe Clock Monit or (FSCM) al low s the dev ic e
to continue operat ing sh ould the external oscillator fail.
The FSCM can detect oscillator failure any time after
the Oscillator Start-up Timer (OST) has expired. The
FSCM is enabled by setting the FCMEN bit in the
CONFIG1H Configuration register. The FSCM is
applicable to all external oscillator modes (LP, XT, HS,
EC, RC and RCIO).

FIGURE 2-8: FSCM BLOCK DIAGRAM

2.11.1 FAIL-SAFE DETECTION

The FSCM module detects a failed oscillator by
comparing the ex tern al osci llator to the FS CM samp le
clock. The sample clock is generated by dividing the
LFINTOSC by 64. See Figure 2-8. Inside the fail
detector block is a latch. The external clock sets the
latch on each falling edge of the external clock. The
sample clock cle ars the latch on each ris ing edge of th e
sample clock. A fail ure is d ete cte d w h en an ent ire half­cycle of the sample clock elapses before the primary
clock goes low.

2.11.3 FAIL-SAFE CONDITION CLEARING

The Fail-Safe condition is cleared by either one of the
following:

•Any Reset

• By toggli ng the SCS1 bi t of the OSCCON register
Both of these conditions restart the OST. While the

OST is running, the device continues to operate from
the INTOSC selected in OSCCON. When the OST
times out, the Fail-Safe condition is cleared and the
device automati cally switches over to the ex ternal clock
source. The Fail-Safe condition need not be cleared
before the OSCFIF flag is cleared.

2.11.4 RESET OR WAKE-UP FROM SLEEP

The FSCM is designed to detect an oscillator failure
after the Oscillator Start-up Timer (OST) has expired.
The OST is used after waking up from Sleep and after
any type of Reset. The OST is not used with the EC or
RC Clock modes so that the FSCM will be active as
soon as the R eset or wake- up has complet ed. When
the FSCM is enabled, the Tw o-Speed Start-up is also
enabled. Therefore, the device will always be executing
code while the OST is operating.

Note: Due to the wide range of oscillator start-up

times, the Fail-Safe circuit is not active
during oscillator start-up (i.e., after exiting
Reset or Sleep). After an appropriate
amount of time, the user should check the
OSTS bit of the OSCCON register to verify
the oscillator start-up and that the system
clock switchover has successfully
completed.

2.11.2 FAIL-SAFE OPERATION

When the external clock fails, the FSCM switches the
device clock to an internal cl ock sourc e and set s the b it
flag OSCFIF of the PIR2 register. The OSCFIF flag will
generate an interrupt if the OSCFIE bit of the PIE2
register is also set. The device firmware can then take
steps to mitigate the problems that may arise from a
failed clock. The system clock will continue to be
sourced from the internal clock source until the device
firmware successfully restarts the external oscillator
and switches back to external operation. An automatic
transition back to the failed clock source will not occur.

The internal clock source chosen by the FSCM is
determined by the IRCF<2:0> bits of the OSCCON
register. This allows the internal oscillator to be
configured before a failure occurs.

 2010-2015 Microchip Technology Inc. DS40001303H-page 39

PIC18F2XK20/4XK20

OSCFIF

System

Clock

Output

Sample Clock

Failure

Detected

Oscillator
Failure

Note: The system clock is normally at a much higher frequency than the sam ple clock. The relative frequencies in

this example have been chosen for clarity.

(Q)

Test

Test Test

Clock Monitor Output

FIGURE 2-9: FSCM TIMING DIAGRAM

TABLE 2-3: SUMMARY OF REGISTERS ASSOCIATED WITH CLOCK SOURCES

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

CONFIG1H IESO FCMEN — — FOSC3 FOSC2 FOSC1 FOSC0 — —
INTCON GIE/GIEH PEIE/GIEL
OSCCON IDLEN IRCF2 IRCF1 IRCF0 OSTS IOFS SCS1 SCS0 0011 q000 0011 q000
OSCTUNE INTSRC P LLEN TUN5 TUN4 TUN3 TUN2 TUN1 TUN0 0000 0000 000u uuuu
PIE2 OSCFIE
PIR2 OSCFIF
IPR2 OSCFIP

Legend: x = unknown, u = unchanged, – = unimplemented locations read as ‘0’. Shaded cells are not used by oscillators.
Note 1: Other (non Power-up) Resets include MCLR

C1IE C2IE EEIE BCLIE HLVDIE TM R3IE CCP2IE 0000 0000 0000 0000

C1IF C2IF EEIF BCLIF HLVDIF TMR3IF CCP2IF 0000 0000 0000 0000

TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 0000 000x 0000 000x

— — — — — — — 1111 1111 1111 1111

Reset and Watchdog Timer Reset during normal operation.

Val ue on

POR, BOR

Val ue on

all other

Resets

(1)

DS40001303H-page 40  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

3.0 POWER-MANAGED MODES

PIC18F2XK20/4XK20 devices offer a total of seven
operating modes for more efficient power
management. These modes provide a variety of
options for selective p ower conservation i n applications
where resources may be limited (i.e., battery-powered
devices).

There are three categories of power-managed modes:

• Run modes

• Idle modes

• Sleep mode

These categories define which portions of the device
are clocked and some times , what sp eed. The R un and
Idle modes may use any of the three available clock
sources (primary, secondary or internal oscillator
block); the Sleep mode does not use a clock source.

The power-managed modes include several
power-saving features offered on previous PIC
microcontroller devices. One is the clock switching
feature which allows the controller to use the Timer1
oscillator in place of the primary oscillator . Also inc luded
is the Sleep mode, offered by all PIC
devices, where all device clocks are stopped.

3.1 Selecting Power-Managed Modes

Selecting a power-managed mode requires two
decisions:

• Whether or not the CPU is to be clocked

• The selection of a clock sou rce

The IDLEN bit of the OSCCON register controls CPU
clocking, while the SCS<1:0> bits of the OSCCON
register select the clock source. The individual modes,
bit settings, clock sources and affected modules are
summarized in Table 3-1.

®

microcontroller

3.1.1 CLOCK SOURCES

The SCS<1:0> bits allow the selection of one of three
clock sources for power-managed modes. They are:

• the primary clock, as defined by the FOSC<3:0>
Configuration bits

• the secondary clock (the Timer1 oscillator)

• the internal oscillator block

3.1.2 ENTERING POWER-MANAGED

MODES

Switching from one power-managed mode to another
begins by loading the OSCCON register. The
SCS<1:0> bits select the clock source and determine
which Run or Idle mode is to be used. Changing these
bits causes an immediate switch to the new clock
source, assuming that it is running. The switch may
also be sub ject to clock tr ansition delays. T hese are

®

discussed in Section 3.1.3 “Clock Transitions and

Status Indicators” and subsequent sections.

Entry to the power-managed Idle or Sleep modes is
triggered by the execution of a SLEEP instruction. The
actual mode that results depends on the status of the
IDLEN bit of the OSCCON register.

Depending on the current mode and the mode being
switched to, a change to a power-managed mode does
not always require setting all of these bits. Many
transitions may be done by changing the oscillator select
bits, or changing the IDLEN bit, prior to issuing a SLEEP
instruction. If the IDLEN bit is already configured
correctly, it may only be necessary to perform a SLEEP
instruction to switch to the desired mode.

TABLE 3-1: POWER-MANAGED MODES

Mode

Sleep 0 N/A Off Off None – All clocks are disabled
PRI_RUN N/A 00 Clocked Clocked Primary – LP, XT, HS, HSPLL, RC, EC and

SEC_RUN N/A 01 Clocked Clocked Secondary – Timer1 Oscillator
RC_RUN N/A 1x Clocked Clocked Internal Oscillator Block
PRI_IDLE 100Off Clocked Primary – LP, XT, HS, HSPLL, RC, EC
SEC_IDLE 101Off Clocked Secondary – Timer1 Oscillator
RC_IDLE 11xOff Clocked Internal Oscillator Block

Note 1: IDLEN reflects its value when the SLEEP instruction is executed.

2: Includes HFINTOSC and HFINTOSC postscaler, as well as the LFINTOSC source.

 2010-2015 Microchip Technology Inc. DS40001303H-page 41

OSCCON Bits Module Clocking

(1)

IDLEN

SCS<1:0> CPU Peripherals

Available Clo ck and Os cill ator Source

(2)

Internal Oscillator Block
This is the normal full power execution mode.

.

(2)

(2)

PIC18F2XK20/4XK20

3.1.3 CLOCK TRANSITIONS AND S TATUS INDICATORS

The length of the transition between clock sources is
the sum of:

• Start-up time of the new clock

• Two and one half cycles of the old clock source

• Two and one half cycles of the new clock

Three flag bits indicate the current clock source and its
status. They are:

• OSTS (of the OSCCON register)

• IOFS (of the OSCCON register)

• T1RUN (of the T1CON register)

In general, only one of these bits will be set while in a
given power-managed mode. Table 3-2 shows the
relationship o f the flag s to th e active main sy stem cl ock
source.

TABLE 3-2: SYSTEM CLOCK INDICATORS

OSTS IOFS T1RUN Main System Clock Source

10 0 Primary Oscillator
01 0 HFINTOSC
00 1 Secondary Oscillator
11 0 HFINTOSC as primary clock

00 0

.

Note 1: Executing a SLEEP instruction does not

necessarily place the device into Sleep
mode. It acts as the trigger to place the
controller into either the Sleep mode or
one of the Idle modes, depending on the
setting of the IDLEN bit.

LFINTOSC or

HFINTOSC is not yet stable

3.1.4 MULTIPLE FUNCTIONS OF THE SLEEP COMMAND

The power-managed mode that is invoked with the
SLEEP instruction is determined by the setting of the
IDLEN bit of the OSCCON register at the time the
instruction is executed. All clocks stop and minimum
power is consumed when SLEEP is executed with the
IDLEN bit cleared. The system clock continues to
supply a clock to the peripherals but is disconnected
from the CPU when SLEEP is executed wi th the IDLEN
bit set.

3.2 Run Modes

In the Run modes, clocks to both the core and
peripherals are active. The difference between these
modes is the clock source.

3.2.1 PRI_RUN MODE

The PRI_RUN mode is the normal, full power execution
mode of the microcontroller. This is also the default
mode upon a devi ce Reset, u nless T wo- Sp eed S tart-u p
is enabled (see Section 2.10 “Two-Speed Clock

Start-up Mode” for detail s). In this mo de, the O STS bit

is set. The IOFS bit will be set if the HFINTOSC is the
primary clock source and the oscillator is stable (see

Section 2.2 “Oscillator Control”).

3.2.2 SEC_RUN MODE

The SEC_RUN mode is the mode compatible to the
“clock switching” feature offered in other PIC18
devices. In this mode, the CPU and peripherals are
clocked from the T imer1 os cillator. This gives users th e
option of lower power consumption w hile still u sing a
high accuracy clock source.

SEC_RUN mod e is entered by setting t he SCS<1:0>
bits to ‘01’. When SEC_RUN mode is active all of the
following are true:

• The main clock source is switch ed to the Timer1
oscillator

• Primary oscillator is shut down

• T1RUN bit of the T1CON register is set

• OSTS bit is cleared.
Note: The Timer1 oscillator should already be

running prior to entering SEC_RUN
mode. If the T1OSCEN bit is not set when
the SCS<1:0> bits are set to ‘01’, entry to
SEC_RUN mode will not occur until
T1OSCEN bi t i s se t an d Timer1 osc ill ato r
is ready.

On transitions from SEC_RUN mode to PRI_RUN, the
peripherals and CPU continue to be clocked from the
Timer1 oscillator while the primary clock is started.
When the primary clo ck bec omes r eady, a clock switch
back to the primary clock occurs (see Figure 2-7).
When the clock switch is complete, the T1RUN bit is
cleared, the OSTS bit is set and the primary clock is
providing the main system clock. The Timer1 oscillator
continues to run as long as the T1OSCEN bit is set.

DS40001303H-page 42  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

3.2.3 RC_RUN MODE

In RC_RUN mode, the CPU and peripherals are
clocked from the internal oscillator block using one of
the selections from the HFINTOSC multiplexer. In this
mode, the primary oscillator is shut down. RC_RUN
mode provid es the best pow er conservat ion of all the
Run modes when the LFINTOSC is the main clock
source. It wo rks well for use r applic ations which are not
highly timing sensitive or do not require high-speed
clocks at all times.

If the primary clock source is the internal oscillator
block (either LFINTOSC or HFINTOSC), there are no
distinguishable differences between PRI_RUN and
RC_RUN modes during execution. Howe ver, a clock
switch delay will occur during entry to and exit from
RC_RUN mode. Therefore, if the primary clock source
is the internal oscillator block, the use of RC_RUN
mode is not recommended. See 2.9.3 “Clock Switch

Timing” for details about clock switching.

RC_RUN mode is entered by setting the SCS1 bit to
‘1’. The SCS0 bit can be either ‘0’ or ‘1’ but should be
‘0’ to maintain software compatibility with future
devices. When the clock source is swi tched from the
primary oscillator to the HFINTOSC multiplexer, the
primary oscillator is shut down and the OSTS bit is
cleared. Th e I RC F bi ts m ay be mo d ifi ed a t a ny tim e t o
immediately change the clock speed.

On transitions from RC_RUN mode to PRI_RUN mode,
the device continues to be clocked from the internal
oscillator block while the primary oscillator is started.
When the primary oscillator becomes ready, a clock
switch to the primary clock occurs. When the clock
switch is complete, the IOFS bit is cleared, the OSTS
bit is set and the pri mary oscil lator is provi ding the mai n
system clock. The H FINTOSC will continue to run if any
of the conditions noted in Section 2.5.2 “HFINTOSC”
are met. The LFINTOSC source will continue to run if
any of the conditions noted in Section 2.5.3 “LFIN-

TOSC” are met.

3.3 Sleep Mode

The Power-Managed Sleep mode in the PIC18F2XK20/
4XK20 devices is identical t o the legacy Sleep mode
offered in all other PIC
entered by clearing th e IDLEN bit (the default state on
device Reset) and executing the SLEEP instruction.
This shuts down the selected oscillator (Figure 3-1). All
clock source Status bits are cleared.

Entering the Sleep mo de from any other mo de does not
require a clock switch. This is because no clocks are
needed once the controller has entered Sleep. If the
WDT is selected, the LFINTOSC sour ce will continue to
operate. If the Timer1 oscillator is enabled, it will also
continue to run.

When a wake event occurs in Slee p mode (by interrupt,
Reset or WDT time-out), the device wil l not be clocke d
until the clock source selected by the SCS<1:0> bits
becomes ready (see Figure 3-2), or it will be clocked
from the internal osc illator block i f either the T wo-S peed
Start-up or the Fail-Safe Clock Monitor are enabled
(see Sectio n 23.0 “Special Features of the CPU ”). In
either case, the O STS bit is set whe n the p rimary clock
is providing the device clo cks. The IDLEN and SCS bits
are not affected by the wake-up.

®

microcontroller devi ces. It is

3.4 Idle Modes

The Idle modes allow the controller’s CPU to be
selectively shut down while the peripherals continue to
operate. Selecting a particular Idle mode allows users
to further manage power consumption.

If the IDLEN bit i s set to a ‘1’ when a SLEEP inst ruction is
executed, the periph erals will be cloc ked fro m the cloc k
source selected by the SCS<1:0> bit s; however , the CPU
will not be clocked. The clock source Status bits are not
affected. Setting IDLEN and executing a SLEEP instruc-
tion provides a quick method of switching from a given
Run mode to i t s c orre s pon di ng I dl e m o de.

If the WDT is selected, the LFINTOSC source will
continue to operate. If the Timer1 oscillator is enabled,
it will also continue to run.

Since the CPU is not executing instructions, the only
exits from any of the Idle modes are by interrupt, WDT
time-out, or a Reset. When a wake event occurs, CPU
execution is delayed by an interval of T
(parameter 38, Table ) while it becomes ready to exe­cute code. When the CPU begins executing code, it
resumes with the same clock source for the current Idle
mode. For example, when waking from RC_IDLE
mode, the internal oscillator block will clock the CPU
and peripherals (in other words, RC_RUN mode). The
IDLEN and SCS bits are not affected by the wake-up.

While in any Idle mode or the S leep mode, a WDT
time-out will result in a WDT wake-up to the Run mode
currently specified by the SCS<1:0> bits.

CSD

 2010-2015 Microchip Technology Inc. DS40001303H-page 43

PIC18F2XK20/4XK20

Q4Q3Q2

OSC1

Peripheral

Sleep

Program

Q1Q1

Counter

Clock

CPU

Clock

PC + 2PC

Q3 Q4 Q1 Q2

OSC1

Peripheral

Program

PC

PLL Clock

Q3 Q4

Output

CPU Clock

Q1 Q2 Q3 Q4 Q1 Q2

Clock

Counter

PC + 6

PC + 4

Q1 Q2 Q3 Q4

Wake Event

Note 1: T

OST = 1024 TOSC; TPLL = 2 ms (approx). These intervals are not shown to scale.

TOST

(1)

TPLL

(1)

OSTS bit set

PC + 2

FIGURE 3-1: TRANSITION TIMING FOR ENTRY TO SLEEP MODE

FIGURE 3-2: TRANSITION TIMING FOR WAKE FROM SLEEP (HSPLL)

DS40001303H-page 44  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

Q1

Peripheral

Program

PC PC + 2

OSC1

Q3

Q4

Q1

CPU Clock

Clock

Counter

Q2

OSC1

Peripheral

Program

PC

CPU Clock

Q1 Q3 Q4

Clock

Counter

Q2

Wake Event

TCSD

3.4.1 PRI_IDLE MODE

This mode is uni que among the thre e low-power Idle
modes, in that it does not disable the primary device
clock. For timing sensitive applications, this allows for
the fastest resump tion of devic e operation w ith its mo re
accurate pri mary clock source, si nce the cl ock source
does not have to “warm-up” or transition from another
oscillator.

PRI_IDLE mode is entered from PRI_RUN mode by
setting the IDLEN bit and executing a SLEEP instruc­tion. If the device is in another Run mode, set IDLEN
first, then clear the SCS bits and execute SLEEP.
Although the CPU i s disab led, th e peri pherals cont inue
to be clocked from the primary clock source specified
by the FOSC<3:0> Configuration bits. The OSTS bit
remains set (see Figure 3.3).

When a wake event occurs, the CPU is clocked from the
primary clock source. A delay of interval T
required between the wake event and when code
execution starts. This is required to allo w the CPU to
become ready to execut e instructions. After the wake­up, the OSTS bit remains set. The IDLEN and SCS bits
are not affected by the wake-up (see Figure 3-4).

CSD is

3.4.2 SEC_IDLE MODE

In SEC_IDLE mode, the CPU is disabled but the
peripherals continue to be clocked from the Timer1
oscillator. This mode is entered from SEC_RUN by
setting the IDLEN bit and executing a SLEEP
instruction. If the d evice is in ano ther Run mode, set th e
IDLEN bit first, then set the SCS<1:0> bits to ‘01’ and
execute SLEEP. When the clock source is switched to
the Timer1 oscillator, the primary oscillator is shut
down, the OSTS bit is cleared an d the T1RUN bit is set.

When a wake event occurs, the peripherals continue to
be clocked from the Timer1 oscillator. After an interval

CSD following the wake event, the CPU b egins exe-

of T
cuting code being cloc ked by the Timer1 oscillat or . Th e
IDLEN and SCS bits are not affected by the wake-up;
the Timer1 oscillator continues to run (see Figure 3-4).

Note: The Timer1 oscillator should already be

running prior to entering SEC_IDLE
mode. If the T1OSCEN bit is not set when
the SLEEP instruction is executed, the
main system clock will continue to operate
in the previously selected mode and the
corresponding IDLE mode will be entered
(i.e., PRI_IDLE or RC_IDLE).

FIGURE 3-3: TRANSITION TIMING FOR ENTRY TO IDLE MODE

FIGURE 3-4: TRANSITION TIMING FOR WAKE FROM IDLE TO RUN MODE

 2010-2015 Microchip Technology Inc. DS40001303H-page 45

PIC18F2XK20/4XK20

3.4.3 RC_IDLE MODE

In RC_IDLE mode, the CPU is disabled but the
peripherals continue to be clocked from the internal
oscillator block from the HFINTOSC multiplexer output.
This mode allows for controllable power conservation
during Idl e periods.

From RC_RUN, this mode is entered by setting the
IDLEN bit and executing a SLEEP instruction. If the
device is in a nother Run mode, first s et IDLEN, th en set
the SCS1 bi t and execute SLEEP. It is recommended
that SCS0 also be cleared, although its value is
ignored, to maintain software compatibility with future
devices. The HFINTOSC multiplexer may be used to
select a higher clock frequency by modifying the IRCF
bits before exec uti ng th e SLEEP instruction. When the
clock source is switched to the HFINTOSC multiplexer,
the primary oscillator is shut down and the OSTS bit is
cleared.

If the IRCF bits are set to any non-zero value, or the
INTSRC bit is set, the HFINTOSC output is enabled.
The IOFS bit beco mes s et, af ter t he HFINT OSC o utput
becomes stable, after an interval of T
(parameter 39, Table ). Clocks to the perip herals c on­tinue while the HFINTOSC source stabilizes. If the
IRCF bits were previously at a non-zero value, or
INTSRC was set before the SLEEP inst ruction was ex e­cuted and the HFINTOSC source was already stable,
the IOFS bit will remain set. If the IRCF bits and
INTSRC are all clear, the HFINTOSC output will not be
enabled, the IOF S bit will remain c lear and t here will b e
no indication of the current clock source.

When a wake event o ccurs, the pe ripherals co ntinue to
be clocked from the HFINTOSC multiplexer output.
After a delay of T
begins executing code being clocked by the
HFINTOSC multiplexer. The IDLEN and SCS bits are
not affected by the wake-up. The LFINTOSC source
will continue to run if either the WDT or the Fail-Safe
Clock Monitor is enabled.

CSD following th e wake event, the CP U

IOBST

3.5 Exiting Idle and Sleep Modes

An exit from Sleep mode or any of the Idle modes is
triggered by any one of the following:

• an interrupt

•a Reset

• a watchdog time-out
This section discusses the triggers that cause exits

from power-managed modes. The clocking subsystem
actions are discussed in each of the power-managed
modes (see Section 3.2 “Run Modes”, Section 3.3

“Sleep Mode” and Section 3.4 “Idle Modes”).

3.5.1 EXIT BY INTERRUPT

Any of the available interrupt sources can cause the
device to exit from an Idle mode or the Sleep mode to
a Run mode. To enable this functionality, an interrupt
source must be enabled by s etti ng its enable bit in one
of the INTCON or PIE registers. The PEIE bit mus t also
be set If the desired interrupt enable bit is in a PIE
register. The exit sequence is initiated when the
corresponding interrupt flag bit is set.

The instruction immediately following the SLEEP
instruction is execute d on all exit s by interru pt from Idle
or Sleep modes. Code execution then branches to the
interrupt vector if the GIE/GIEH bit of the INTCON
register is set, otherwise code execution continues
without branching (see Section 9.0 “Interrupts”).

A fixed delay of interval T
is required when leaving Sleep and Idle modes. This
delay is required for the CPU to prepare for execution.
Instructio n execution r esumes on th e first clock c ycle
following this delay.

CSD following th e wake event

3.5.2 EXIT BY WDT TIME-OUT

A WDT time-out will cause different actions depending
on which power-managed mode the device is in when
the time-out occurs.

If the device i s not exec uti ng code (al l Idle mode s and
Sleep mode), the time-out will res ul t in an exit from the
power-managed mode (see Section 3.2 “Run

Modes” and Section 3.3 “Sleep Mode”). If the device

is executing code (all Run modes), the time-out will
result in a WDT Reset (see Section 23.2 “Watchdog

Timer (WDT)”).

The WDT timer and postscaler are cleared by any one
of the following:

• executing a SLEEP instruction

• executing a CLRWDT instruction

• the loss of the currently selected cloc k source
when the Fail-Safe Clock Monitor is enabled

• modifying the IRCF bits in the OSCCON register
when the internal oscillator block is the device
clock source

3.5.3 EXIT BY RESET

Exiting Sleep and Idle modes by Reset causes code
execution to restart at address 0. See Section 4.0

“Reset” for more details.

The exit delay time from Reset to the start of code
execution depends on both the clock sources before
and after the wake-up and the type of oscillator. Exit
delays are summarized in Table 3-3.

DS40001303H-page 46  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

3.5.4 EXIT WITHOUT AN OSCILLATOR START-UP DELAY

Certain exits from power-managed modes do not
invoke the OST at all. There are two cases:

• PRI_IDLE mode, where the primary clock source

is not stopped and

• the primary clock source is not any of the LP, XT,

HS or HSPLL modes.

In these instances, the primary clock source either
does not require an oscillator start-up delay since it is
already running (PRI_IDLE), or normally does not
require an oscillator start-up delay (RC, EC, INTOSC,
and INTOSCIO modes). However, a fixed delay of
interval T

CSD following the wake event is still required

when leaving Sleep and Idle modes to allow the CPU
to prepare for execution. Instruction execution resumes
on the first clock cycle following this delay.

TABLE 3-3: EXIT DELAY ON WAKE-UP BY RESET FROM SLEEP MODE OR ANY IDLE MODE

(BY CLOCK SOURCES)

Clock Source

before Wake-up

Primary Device Clo ck

(PRI_IDLE mode)

T1OSC or LFINTOSC

HFINTOSC

None

(Sleep mode)

Note 1: T

CSD (parameter 38) is a require d del ay w hen wa king from Sl eep an d all Idle modes and runs conc urr ently

with any other required delays (see Section 3.4 “Idle Modes”). On Reset, HFINTOSC defaults to 1 MHz.

2: Includes both the HFINTOSC 16 MHz source and postscaler derived frequencies.
3: TOST is the Osci llator Start-up Timer (param eter 32). t
4: Execution continues during the HFINTOSC stabilization period, T

(1)

(2)

Clock Source

after Wake-up

Exit Delay

LP, XT, HS

EC, RC

HFINTOSC

(2)

LP, XT, HS TOST

EC, RC TCSD

HFINTOSC

(1)

LP, XT, HS TOST

EC, RC TCSD

HFINTOSC

(1)

LP, XT, HS TOST

EC, RC TCSD

HFINTOSC

(1)

is the PLL Lock-out Timer (param eter F12).

PLL

Clock Ready Status

Bit (OSCCON)

T

CSD

TIOBST

(1)

(3)

PLL

(1)

(4)

(4)

PLL

(1)

(3)

(3)

OSTSHSPLL

OSTSHSPLL TOST + t

OSTSHSPLL TOST + t

None IOFS

(3)

(3)

PLL

(1)

(4)

TIOBST

IOBST (parameter 39).

OSTSHSPLL TOST + t

IOFS

IOFS

IOFS

 2010-2015 Microchip Technology Inc. DS40001303H-page 47

PIC18F2XK20/4XK20

External Reset

MCLR

VDD

OSC1

WDT

Time-out

V

DD

Detect

OST/PWRT

LFINTOSC

POR

OST

(2)

10-bit Ripple Counter

PWRT

(2)

11-bit Ripple Counter

Enable OST

(1)

Enable PWRT

Note 1: See Table 4-2 for time-out situations.

2: PWRT and OST counters are reset by POR and BOR. See Sections 4.3 and 4.4.

Brown-out

Reset

BOREN

RESET

Instruction

Stack

Pointer

Stack Full/Underflow Reset

Sleep

( )_IDLE

1024 Cycles

65.5 ms

32 s

MCLRE

S

R

Q

Chip_Reset

4.0 RESET

A simplified block di agram of the On-Chip Reset Circu it
is shown in Figure 4-1.

The PIC18F2XK20/4XK20 devices differentiate
between various kinds of Reset:

a) Power-on Reset (POR)
b) MCLR

Reset during normal operation
c) MCLR Reset during power-managed modes
d) Watchdog Timer (WDT) Reset (during

execution)
e) Programmable Brown-out Reset (BOR)
f) RESET Instruction
g) Stack Full Reset
h) Stack Underflow Reset

This section discusses Resets generated by MCLR
POR and BOR and covers the ope rati on o f the various
start-up timers. Stack Reset events are covered in

Section 5.1.2.4 “Stack Full and Underflow Resets”.

WDT Resets are co v ere d i n Section 23.2 “Watchdog

,

4.1 RCON Register

Device Reset events are tracked through the RCON
register (Register 4-1). The lower five bits of the regis­ter indicate that a specif ic Reset eve nt has occu rred. In
most cases, thes e bits c an only be cl eared by the e vent
and must be set by the ap pli ca tio n af ter the event. The
state of these flag bits, taken together, can be read to
indicate the type of Reset that just occurred. This is
described in more detail in Section 4.6 “Rese t State

of Registers”.

The RCON register also has control bits for setting
interrupt priority (IPEN) and software control of the
BOR (SBOREN). Interrupt priority is discussed in

Section 9.0 “Interrupts”. BOR is covered in
Section 4.4 “Brown-out Reset (BOR)”.

Timer (WDT)”.

FIGURE 4-1: SIMPLIFIED BLOCK DIAGRAM OF ON-CHIP RESET CIRCUIT

DS40001303H-page 48  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

REGISTER 4-1: RCON: RESET CONTROL REGISTER

R/W-0 R/W-1 U-0 R/W-1 R-1 R-1 R/W-0 R/W-0

IPEN SBOREN

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 IPEN: Interrupt Priority Enable bit

1 = Enable priority levels on interrupts
0 = Disable priority levels on interrupts (PIC16CXXX Compatibility mode)

bit 6 SBOREN: BOR Software Enable bit

If BOREN<1:0> =

1 = BOR is enabled
0 = BOR is disabled

If BOREN<1:0> =

Bit is disabled and read as ‘0’.
bit 5 Unimplemented: Read as ‘0’
bit 4 RI

bit 3 TO

bit 2 PD

bit 1 POR

bit 0 BOR

: RESET Instruction Flag bit

1 = The RESET instruction was not executed (set by firmware or Power-on Reset)

0 = The RESET instruction was executed causing a device Reset (must be set in firmware after a

1 = Set by power-up, CLRWDT instruction or SLEEP instruction

0 = A WDT time-out occurred

1 = Set by power-up or by the CLRWDT instructi on

0 = Set by execution of the SLEEP instruction

1 = No Power-on Reset occurred

0 = A Power-on Reset occurred (must be set in software after a Power-on Reset occurs)

1 = A Brown-out Reset has not occurred (set by firmware only)

0 = A Brown-out Reset occurred (must be set by firmware after a POR or Brown-out Reset occurs)

(1)

code-executed Reset occurs)

: Watchdog Time-out Flag bit

: Power-down Detection Flag bit

: Power-on Reset Status bit

: Brown-out Reset Status bit

—RITO PD POR

(1)

01:

00, 10 or 11:

(2)

(3)

(2)

BOR

Note 1: When CONFIG2L[2:1] = 01, then the SBOREN Reset state is ‘1’; otherwise, it is ‘0’.

2: The actual Reset value of POR

register and Section 4.6 “Reset State of Registers” for additional information.

3: See Table 4-3.

Note 1: Brown-out Reset is ind icated when BOR is ‘0’ and POR is ‘1’ (assumin g that both PO R and BOR were set

to ‘1’ by firmware immediately after POR).

2: It is recommended that the PO R

Power-on Resets may be detected.

 2010-2015 Microchip Technology Inc. DS40001303H-page 49

is determined by the type of device Reset. See the notes following this

bit be set after a Power-on Reset has bee n dete cted so that su bsequ ent

PIC18F2XK20/4XK20

Note 1: External Power-on Reset circuit is required

only if the V

DD power-up slope is too slow.

The diode D helps discharge the capacitor
quickly when V

DD powers down.

2: 15 k < R < 40 k is recommended to make

sure that the voltage drop across R does not
violate the device’s electrical specification.

3: R1  1 k will limit any current flowing into

MCLR

from external capacitor C, in the event

of MCLR

/VPP pin breakdown, due to
Electrostatic Discharge (ESD) or Electrical
Overstress (EOS).

C

R1

R

D

V

DD

MCLR

VDD

PIC® MCU

4.2 Master Clear (MCLR)

The MCLR pin provides a method for triggering an
external Reset of the device. A Reset is generated by
holding the pin low. These devices have a noise filter i n
the MCLR

Reset path which detects and ignores small

pulses.
The MCLR

pin is not drive n low by any inter nal Reset s,

including the WDT.
In PIC18F2XK20/4XK20 devices, the MCLR

input can
be disabled with the MCLRE Configuration bit. When
MCLR is disabled, the pin becomes a digit a l input . See

Section 10.6 “PORTE, TRISE and LATE Registers”

for more information.

4.3 Power-on Reset (POR)

A Power-on Reset pulse is generated on-chip
whenever V
allows the device to start in the initialized state when
VDD is adequate for operation.

To take advantage of the POR circuitry, tie the MCLR
pin through a r esi stor t o VDD. This will eliminate exter­nal RC components usually needed to create a
Power-on Reset delay. A minimum rise rate for VDD is
specified (parameter D004). For a slow rise time, see

Figure 4-2.

When the device st arts normal operati on (i.e ., ex its the
Reset condition), device operating parameters
(voltage, frequency, temperature, etc.) must be met to
ensure proper operation. If these conditions are not
met, the device must be held in Reset until the
operating conditions are met.

POR events are captured by the POR
register. The state of the bit is set to ‘0’ whenever a
POR occurs; it does not change for any other Reset
event. POR
To capture multiple events, the us er m us t ma nu all y s et
the bit to ‘1’ by software following any POR.

DD rises above a certain threshold. This

bit of the RCON

is not reset to ‘1’ by any hardware event.

FIGURE 4-2: EXTERNAL POWER-ON

RESET CIRCUIT (FOR
SLOW V

DD POWER-UP)

DS40001303H-page 50  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

4.4 Brown-out Reset (BOR)

PIC18F2XK20/4XK20 devices implement a BOR circuit
that provides the user with a nu mber of co nfigurati on and
power-saving options. The BOR is controlled by the
BORV<1:0> and BOREN<1:0> bits of the CONFIG2L
Configuration register. There are a total of four BOR
configuratio ns w h ic h are s um m ari ze d in Table 4-1.

The BOR threshold is set by the BORV<1:0> bits. If
BOR is enabled (any values of BOREN<1:0>, except
‘00’), any drop of V
for greater than T
device. A Reset m ay or may not occur i f V

BOR for less than TBOR. The chip will remain in

V
Brown-out Reset until V

If the Power-up T imer is enabled , it will be invoke d after

DD rises above VBOR; it then will keep the chip in

V
Reset for an additional time delay, T
(parameter 33). If VDD drops below VBOR while the
Power-up Timer is running, the chip will go back into a
Brown-out Reset and the Power-up Timer will be
initialized. Once V
Timer will execute the additional time delay.

BOR and the Power-on Timer (PWRT) are
independently configured. Enabling BOR Reset does
not automat ically enable the PWRT.

The BOR circuit has an output th at fee ds into the POR
circuit and rearms the POR within th e operating range
of the BOR. This early r earming of the POR ensures
that the device will remain in Reset in the event that V
falls below the operating range of the BOR circuitry.

4.4.1 DETECTING BOR

When BOR is enab led, the BOR bit alway s re set s to ‘0’
on any BOR or PO R event. This makes it difficult to
determine if a BOR event has occ urr ed jus t by rea din g
the state of BOR
simultaneously check the state of both POR
This assumes that the POR
‘1’ by software immediately after any POR event. If

is ‘0’ while POR is ‘1’, it can be reliably assumed

BOR
that a BOR event has occurred.

DD below VBOR (parameterD005)

BOR (parameter 35) will reset the

DD falls below

DD rises above VBOR.

PWRT

DD rises above VBOR, the Power-up

DD

alone. A more reliable method is to

and BOR.

and BOR bits are reset to

4.4.2 SOFTWARE ENABLED BOR

When BOREN<1:0> = 01, the BOR can be enabled or
disabled by the user in software. This is done with the
SBOREN control bit of the RCON register. Setting
SBOREN enables the BOR to function as previously
described. Clearing SBOREN disables the BOR
entirely. The SBOREN bit operates only in this mode;
otherwise it is read as ‘0’.

Placing the BOR under software control gives the user
the additional flexibility of tailoring the application to its
environment without having to reprogram the device to
change BOR configuration. It also allows the user to
tailor device power consumption in software by
eliminating the incremental current that the BOR
consumes. While the BOR current is typically very small,
it may have some impact in low-power applic ations.

Note: Even when BOR is under software

control, the BOR Reset v oltage level is still
set by the BORV<1:0> Configuration bits.
It cannot be changed by software.

4.4.3 DISABLING BOR IN SLEEP MODE

When BOREN<1:0> = 10, the BOR remains under
hardware control and operates as previously
described. Whenever the device enters Sleep mode,
however, the BOR is automatically disabled. When the
device returns to any other operating mode, BOR is
automatically re-enabled.

This mode allows for applications to recover from
brown-out situations, while actively executing code,
when the device requires BOR protection the most. At
the same time, it save s additional po wer in Sleep mod e
by eliminating the small incremental BOR current.

4.4.4 MINIMUM BOR ENABLE TIME

Enabling the BOR also enables the Fixed Voltage
Reference (FVR) when no other peripheral requiring the
FVR is active. The BOR be comes active only afte r the
FVR stabilizes. There fore, to ensure BOR protection,
the FVR settling time must be considered when
enabling the BOR in software or when the BOR is
automatically enabled after w aking from Sleep. If the
BOR is disabled, in software or by reentering Sleep
before the FVR stabilizes, the BOR circuit will not sense
a BOR condition. The FVRST bit of the CVRCON2
register can be used to determine FVR stability.

TABLE 4-1: BOR CONFIGURATIONS

BOR Configuration Status of

BOREN1 BOREN0

00Unavailable BOR disabled; must be enabled by reprogramming the Configuration bits.
01Available BOR enabled by software; operation controlled by SBOREN.
10Unavailable BO R enabled by hardware in Run and Idle modes, disabled during

11Unavailable BOR enabled by hardware; must be disabled by reprogramming the Configuration bits.

 2010-2015 Microchip Technology Inc. DS40001303H-page 51

SBOREN

(RCON<6>)

BOR Operation

Sleep mode.

PIC18F2XK20/4XK20

4.5 Device Reset Timers

PIC18F2XK20/4XK20 devices incorporate three
separate on-chip timers that help regulate the
Power-on Reset process. Their main function is to
ensure that the device clock is stable before code is
executed. These timers are:

• Power-up Timer (PWRT)

• Oscillator Start-up Timer (OST)

• PLL Lock Time-out

4.5.1 POWER-UP TIMER (PWRT)

The Power-up Timer (PWRT) of
PIC18F2XK20/4XK20 devices is an 11-bit counter
which uses the LFINTOSC source as the clock input.
This yields an approximate time interval of
2048 x 32 s = 65.6 ms. While the PWRT is counting,
the device is held in Reset.

The power-up time delay depends on the LFINTOSC
clock and will vary from chi p-to-chip due to tempe rature
and process variation. See DC parameter 33 for
details.

The PWRT is enabled by clearing the PWRTEN
Configuration bit.

4.5.2 OSCILLATOR START-UP TIMER

(OST)

The Oscillator Start-up Timer (OST) provides a 1024
oscillator cycle (from OSC1 input) delay after the
PWRT delay is ov er ( para me t er 33). This ensures that
the crystal oscillator or resonator has started and
stabilized.

The OST time-out is invoked only for XT, LP, HS and
HSPLL modes and only on Power-on Reset, or on exit
from all powe r-manag ed modes t hat stop t he extern al
oscillator.

4.5.3 PLL LOCK TIME-OUT

With the PLL enabled in its PLL mode, the time-out
sequence following a Power-on Reset is slightly
different from other oscillator modes. A separate timer
is used to provide a fixed time-out that is sufficient for
the PLL to lock to the main oscillator frequency. This
PLL lock time-out (T
the oscillator start-up time-out.

PLL) is typically 2 ms and follows

4.5.4 TIME-OUT SEQUENCE

On power-up, the time-out sequence is as follows:

1. After the POR pulse has clea red, PWRT time-out
is invoked (if enabled).

2. Then, the OST is activated.

The total time-out will vary based on oscillator
configuration and the status of the PWRT. Figure 4-3,

Figure 4-4, Figure 4-5, Figure 4-6 and Figure 4-7 all

depict time-out sequences on power-up, with the
Power-up Timer enabled and the device operating in
HS Oscillator mode. Figures 4-3 through 4-6 also
apply to devices operating in XT or LP modes. For
devices in RC mode and with the PWRT disabled, on
the other hand, there will be no time-out at all.

Since the time-outs occur from the POR pulse, if MC LR
is kept low long enough, all time-outs will expire, after
which, bringing MCLR
execution to begin immediately (Figure 4-5). This is
useful for testing purpo ses or to synchroniz e more than
one PIC18FXXK20 device operating in parallel.

high will allow program

TABLE 4-2: TIME-OUT IN VARIOUS SITUATIONS

(2)

Oscillator

Configuration

HSPLL 66 ms
HS, XT, LP 66 ms
EC, ECIO 66 ms
RC, RCIO 66 ms
INTIO1, INTIO2 66 ms

Note 1: 66 ms (65.5 ms) is the nominal Power-up Timer (PWRT) delay.

2: 2 ms is the nominal time required for the PLL to lock.

DS40001303H-page 52  2010-2015 Microchip Technology Inc.

PWRTEN

(1)

+ 1024 TOSC + 2 ms

Power-up

= 0 PWRTEN = 1

(1)

+ 1024 TOSC 1024 TOSC 1024 TOSC

(1)
(1)
(1)

and Brown-out

(2)

1024 TOSC + 2 ms

Exit from

Power-Managed Mode

(2)

——
——
——

1024 TOSC + 2 ms

(2)

PIC18F2XK20/4XK20

TPWRT

TOST

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

TPWRT

TOST

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

TPWRT

TOST

FIGURE 4-3: TIME-OUT SEQUENCE ON POWER-UP (MCLR TIED TO VDD, VDD RISE < TPWRT)

FIGURE 4-4: TIME-OUT SEQUENCE ON POWER-UP (MCLR

FIGURE 4-5: TIME-OUT SEQUENCE ON POWER-UP (MCLR

NOT TIED TO VDD): CASE 1

NOT TIED TO VDD): CASE 2

 2010-2015 Microchip Technology Inc. DS40001303H-page 53

PIC18F2XK20/4XK20

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RES ET

0V

5V

T

PWRT

TOST

TPWRT

TOST

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

PLL TIME-OUT

TPLL

Note: TOST = 1024 clock cycles.

T

PLL  2 ms max. First three stages of the PWRT timer.

FIGURE 4-6: SLOW RISE TIME (MCLR TIED TO VDD, VDD RISE > TPWRT)

FIGURE 4-7: TIME-OUT SEQUENCE ON POR W/PLL ENABLED (MCLR

TIED TO VDD)

DS40001303H-page 54  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

4.6 Reset State of Registers

Some registers are unaffected by a Reset. Their status
is unknown on POR and unchanged by all other

Table 4-4 describes the Reset states for all of the

Special Function Registers. These are categorized by
Power-on and Brown-out Resets, Master Clear and
WDT Resets and WDT wake-ups.

Resets. All othe r reg is ters are forc ed to a “R eset s t ate”
depending on the type of Reset that occurred.

Most registers are not affected by a WDT wake-up,
since this is viewed as the resumption of normal
operation. Status bits from the RCON register, RI
PD

, POR and BOR, are set or cleared differently in

, TO,

different Reset situations, as indicated in Table 4-3.
These bits are used by software to determine the
nature of the Reset.

TABLE 4-3: STATUS BITS, THEIR SIGNIFICANCE AND THE INITIALIZATION CONDITION

FOR RCON REGISTER

Condition

Program

Counter

SBOREN RI TO PD POR BOR STKFUL STKUNF

Power-on Reset 0000h 1 11100 0 0
RESET Instruction 0000h u

Brown-out Reset 0000h u

during Power-Managed

MCLR

0000h u

(2)
(2)

(2)

Run Modes
MCLR

during Power-Managed

0000h u

(2)

Idle Modes and Sleep Mode
WDT Time-ou t during Full Power

0000h u

(2)

or Power-Managed Run Mode
MCLR

during Full Power

0000h u

(2)

Execution
Stack Full Reset (STVREN = 1) 0000h u
Stack Underflow Reset

0000h u

(2)
(2)

(STVREN = 1)
Stack Underflow Error (not an

0000h u

(2)

actual Reset, STVREN = 0)
WDT Time-out during

PC + 2 u

(2)

Power-Managed Idle or Sleep
Modes

Interrupt Exit from

PC + 2

(1)

(2)

u

Power-Managed Modes

Legend: u = unchanged
Note 1: When the wake-up is due to an interrupt and the GIEH or GIEL bits are set, the PC is loaded with the

interrupt vector (008h or 0018h).

2: Reset state is ‘1’ for SBOREN and unchanged for all other Resets when software BOR is enabled

(BOREN<1:0> Configuration bits = 01). Otherwise, the Reset state is ‘0’.

RCON Register STKPTR Register

0uuuu u u
111u0 u u

u1uuu u u

u10uu u u

u0uuu u u

uuuuu u u

uuuuu 1 u
uuuuu u 1

uuuuu u 1

u00uu u u

uu0uu u u

 2010-2015 Microchip Technology Inc. DS40001303H-page 55

PIC18F2XK20/4XK20

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS

MCLR

Register Applicable Devices

TOSU PIC18F2XK20 PIC18F4XK20 ---0 0000 ---0 0000 ---0 uuuu
TOSH

TOSL
STKPTR
PCLATU
PCLATH
PCL
TBLPTRU
TBLPTRH
TBLPTRL
TABLAT
PRODH
PRODL
INTCON
INTCON2
INTCON3
INDF0
POSTINC0
POSTDEC0
PREINC0
PLUSW0
FSR0H
FSR0L
WREG
INDF1
POSTINC1
POSTDEC1
PREINC1
PLUSW1

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

4: See Table 4-3 for Reset value for specific condition.
5: Bits 6 and 7 of PORT A, LA TA and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

6: All bits of the ANSELH register initialize to ‘0’ if the PBADEN bit of CONFIG3H is ‘0’.

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20

Shaded cells indicate conditions do not apply for the designated device.

(0008h or 0018h).

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

PORTA pins, they are disabled and read ‘0’.

Power-on Reset,
Brown-out Reset

0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
00-0 0000 uu-0 0000 uu-u uuuu

---0 0000 ---0 0000 ---u uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 PC + 2

--00 0000 --00 0000 --uu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
0000 000x 0000 000u uuuu uuuu
1111 -1-1 1111 -1-1 uuuu -u-u
11-0 0-00 11-0 0-00 uu-u u-uu

N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A

---- 0000 ---- 0000 ---- uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu

N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A

RESET Instruction,

Resets,

WDT Reset,

Stack Resets

Wake-up via WDT

or Interrupt

(3)
(3)

(3)

(3)

(2)

(1)

(1)

(1)

DS40001303H-page 56  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

MCLR

Register Applicable Devices

FSR1H
FSR1L
BSR
INDF2
POSTINC2
POSTDEC2
PREINC2
PLUSW2
FSR2H
FSR2L
STATUS
TMR0H
TMR0L
T0CON
OSCCON
HLVDCON
WDTCON

(4)

RCON
TMR1H
TMR1L
T1CON
TMR2
PR2
T2CON
SSPBUF
SSPADD
SSPSTAT
SSPCON1
SSPCON2

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

4: See Table 4-3 for Reset value for specific condition.
5: Bits 6 and 7 of PORT A, LA TA and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

6: All bits of the ANSELH register initialize to ‘0’ if the PBADEN bit of CONFIG3H is ‘0’.

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20

Shaded cells indicate conditions do not apply for the designated device.

(0008h or 0018h).

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

PORTA pins, they are disabled and read ‘0’.

Power-on Reset,

Brown-out Reset

---- 0000 ---- 0000 ---- uuuu
xxxx xxxx uuuu uuuu uuuu uuuu

---- 0000 ---- 0000 ---- uuuu

N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A

---- 0000 ---- 0000 ---- uuuu
xxxx xxxx uuuu uuuu uuuu uuuu

---x xxxx ---u uuuu ---u uuuu
0000 0000 0000 0000 uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
1111 1111 1111 1111 uuuu uuuu
0011 qq00 0011 qq00 uuuu uuuu
0-00 0101 0-00 0101 u-uu uuuu

---- ---0 ---- ---0 ---- ---u
0q-1 11q0 0u-q qquu uu-u qquu
xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
0000 0000 u0uu uuuu uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
1111 1111 1111 1111 1111 1111

-000 0000 -000 0000 -uuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu

RESET Instruction,

Resets,

WDT Reset,

Stack Resets

Wake-up via WDT

or Interrupt

 2010-2015 Microchip Technology Inc. DS40001303H-page 57

PIC18F2XK20/4XK20

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

MCLR

Register Applicable Devices

ADRESH
ADRESL
ADCON0
ADCON1
ADCON2
CCPR1H
CCPR1L
CCP1CON
CCPR2H
CCPR2L
CCP2CON
PSTRCON
BAUDCON
PWM1CON
ECCP1AS
CVRCON
CVRCON2
TMR3H
TMR3L
T3CON
SPBRGH
SPBRG
RCREG
TXREG
TXSTA
RCSTA
EEADR
EEADRH
EEDATA
EECON2
EECON1

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

4: See Table 4-3 for Reset value for specific condition.
5: Bits 6 and 7 of PORT A, LA TA and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

6: All bits of the ANSELH register initialize to ‘0’ if the PBADEN bit of CONFIG3H is ‘0’.

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F26K20 PIC18F46K20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20

Shaded cells indicate conditions do not apply for the designated device.

(0008h or 0018h).

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

PORTA pins, they are disabled and read ‘0’.

Power-on Reset,
Brown-out Reset

xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu

--00 0000 --00 0000 --uu uuuu

--00 0qqq --00 0qqq --uu uuuu
0-00 0000 0-00 0000 u-uu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu

--00 0000 --00 0000 --uu uuuu

---0 0001 ---0 0001 ---u uuuu
0100 0-00 0100 0-00 uuuu u-uu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
00-- ---- 00-- ---- uu-- ---­xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
0000 0000 uuuu uuuu uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0010 0000 0010 uuuu uuuu
0000 000x 0000 000x uuuu uuuu
0000 0000 0000 0000 uuuu uuuu

---- --00 ---- --00 ---- --uu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 0000 0000
xx-0 x000 uu-0 u000 uu-0 u000

RESET Instruction,

Resets,

WDT Reset,

Stack Resets

Wake-up via WDT

or Interrupt

DS40001303H-page 58  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

MCLR

Register Applicable Devices

IPR2
PIR2
PIE2

IPR1

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20

PIR1

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20

PIE1

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20

OSCTUNE
TRISE
TRISD
TRISC
TRISB

(5)

TRISA
LATE
LATD
LATC
LATB

(5)

LATA

PORTE

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20

PORTD
PORTC
PORTB

(5)

PORTA
ANSELH
ANSEL
IOCB
WPUB
CM1CON0
CM2CON0

(6)

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20

PIC18F4XK20

PIC18F4XK20

PIC18F4XK20

Power-on Reset,
Brown-out Reset

RESET Instruction,

1111 1111 1111 1111 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
1111 1111 1111 1111 uuuu uuuu

-111 1111 -111 1111 -uuu uuuu
0000 0000 0000 0000 uuuu uuuu

-000 0000 -000 0000 -uuu uuuu
0000 0000 0000 0000 uuuu uuuu

-000 0000 -000 0000 -uuu uuuu
0000 0000 0000 0000 uuuu uuuu

---- -111 ---- -111 ---- -uuu
1111 1111 1111 1111 uuuu uuuu
1111 1111 1111 1111 uuuu uuuu
1111 1111 1111 1111 uuuu uuuu
1111 1111

(5)

---- -xxx ---- -uuu ---- -uuu
xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx

(5)

---- x000 ---- u000 ---- uuuu

---- x--- ---- u--- ---- u--­xxxx xxxx uuuu uuuu uuuu uuuu
xxxx xxxx uuuu uuuu uuuu uuuu
xxx0 0000 uuu0 0000 uuuu uuuu
xx0x 0000

(5)

---1 1111 ---1 1111 ---u uuuu
1111 1111 1111 1111 uuuu uuuu
0000 ---- 0000 ---- uuuu ---­1111 1111 1111 1111 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu
0000 0000 0000 0000 uuuu uuuu

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Shaded cells indicate conditions do not apply for the designated device.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

(0008h or 0018h).

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

4: See Table 4-3 for Reset value for specific condition.
5: Bits 6 and 7 of PORT A, LA TA and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

PORTA pins, they are disabled and read ‘0’.

6: All bits of the ANSELH register initialize to ‘0’ if the PBADEN bit of CONFIG3H is ‘0’.

Resets,

WDT Reset,

Stack Resets

1111 1111

uuuu uuuu

uu0u 0000

Wake-up via WDT

or Interrupt

(5)

(5)

(5)

uuuu uuuu

uuuu uuuu

uuuu uuuu

(1)

(1)

(1)

(5)

(5)

(5)

 2010-2015 Microchip Technology Inc. DS40001303H-page 59

PIC18F2XK20/4XK20

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

MCLR

Register Applicable Devices

CM2CON1
SLRCON
SSPMSK

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

4: See Table 4-3 for Reset value for specific condition.
5: Bits 6 and 7 of PORT A, LA TA and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

6: All bits of the ANSELH register initialize to ‘0’ if the PBADEN bit of CONFIG3H is ‘0’.

PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20
PIC18F2XK20 PIC18F4XK20

Shaded cells indicate conditions do not apply for the designated device.

(0008h or 0018h).

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

PORTA pins, they are disabled and read ‘0’.

Power-on Reset,
Brown-out Reset

0000 ---- 0000 ---- uuuu ----

---1 1111 ---1 1111 ---u uuuu
1111 1111 1111 1111 uuuu uuuu

RESET Instruction,

Resets,

WDT Reset,

Stack Resets

Wake-up via WDT

or Interrupt

DS40001303H-page 60  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

PC<20:0>

Stack Level 1



Stack Level 31

Reset Vector

Low Priority Interrupt Vector




CALL,RCALL,RETURN
RETFIE,RETLW

21

0000h

0018h

On-Chip

Program Memory

High Priori ty In terrupt Vector

0008h

User Memory Space

1FFFFFh

4000h

3FFFh

Read ‘0’

200000h

8000h

7FFFh

On-Chip

Program Memory

Read ‘0’

1FFFh

2000h

On-Chip

Program Memory

Read ‘0’

PIC18F25K20/
45K20

PIC18F24K20/
44K20

PIC18F23K20/
43K20

Read ‘0’

FFFFh

PIC18F26K20/
46K20

On-Chip

Program Memory

10000h

5.0 MEMORY ORGANIZATION

There are three types of memory in PIC18 Enhanced
microcontroller devices:

• Program Memory

• Data RAM

• Data EEPROM
As Harvard architecture dev ices, the dat a and progra m

memories use separate busses; this allows for
concurrent access of the two memory s paces. The dat a
EEPROM, for practical purposes, can be regarded as
a peripheral device, since it is addresse d and accessed
through a set of control registers.

Additional detailed information on the operation of the
Flash program memory is provided in Section 6.0

“Flash Program Memory”. Data EEPROM is

discussed s eparately in Section 7.0 “Data EEPROM

Memory”.

5.1 Program Memory Organization

PIC18 microcontrollers implement a 21-bit program
counter, which is capable of addressing a 2-Mbyte
program memory sp ace. Accessi ng a loca tion betwee n
the upper boundary of the physically implemented
memory and the 2-Mbyte address will return all ‘0’s (a
NOP instruction).

This family of devices contain the following:

• PIC18F23K20, PIC18F43K20: 8 Kbytes of Flash

Memory , up to 4,096 single-word instructions

• PIC18F24K20, PIC18F44K20: 16 Kbytes of Flash

Memory , up to 8,192 single-word instructions

• PIC18F25K20, PIC18F45K20: 32 Kbytes of Flash

Memory , up to 16,384 single-word instructions

• PIC18F26K20, PIC18F46K20: 64 Kbytes of Flash

Memory , up to 37,768 single-word instructions

PIC18 devices have two interrupt vectors. The Reset
vector address is at 0000h and the interrupt vector
addresses are at 0008h and 0018h.

The program memory map for PIC18F2XK20/4XK20
devices is shown in Figure 5-1. Me mory block details
are shown in Figure23-2.

FIGURE 5-1: PROGRAM MEMORY MAP AND STACK FOR PIC18F2XK20/4XK20 DEVICES

 2010-2015 Microchip Technology Inc. DS40001303H-page 61

PIC18F2XK20/4XK20

00011

001A34h

11111
11110
11101

00010
00001
00000

00010

Return Address Stack <20:0>

Top-of-Stack

000D58h

TOSLTOSHTOSU

34h1Ah00h

STKPTR<4:0>

T op -of-Stack Registers Stack Pointer

5.1.1 PROGRAM COUNTER

The Program Counter (PC ) specifies the address of th e
instruction to fetch for execu tion. The PC is 21 bits wide
and is contained in three separate 8-bit registers. The
low byte, known as the PCL register, is both readable
and writable. The high byt e, or PCH re gister, contains
the PC<15:8> bits; i t is not directly re adable or writ able.
Updates to the PCH register are perfo rmed through the
PCLATH register. The upper byte is called PCU. This
register contains the PC<20:16> bits; it is also not
directly readable or writable. Updates to the PCU
register are performed through the PCLATU register.

The contents of PCLATH and PCLATU are transferred
to the program counter by any operation that writes
PCL. Similarly, the upper two bytes of the program
counter are transferred to P CLATH and PCLATU by an
operation that reads PCL. This is useful for computed
offsets to the PC (see Section 5.1.4.1 “Computed

GOTO”).

The PC addresses bytes in the program memory. To
prevent the PC from becoming misaligned with word
instructions, the Least Significant bit of PCL is fixed to
a value of ‘0’. The PC increments by two to address
sequential instructions in the program memory.

The CALL, RCALL, GOTO and program branch
instructions write to the program counter directly. For
these instructions, the contents of PCLATH and
PCLATU are not transferred to the program counter.

5.1.2 RETURN ADDRESS STACK

The return address s tack allows any co mb in atio n of up
to 31 program calls and interrupts to occur. The PC is
pushed onto the stack when a CALL or RCALL
instruction is execut ed or an interrupt is Acknow ledged.
The PC value is pulled off the stack on a RETURN,
RETLW or a RETFIE instruct ion. PC LATU and PCLATH
are not affected by any of the RETURN or CALL
instructions.

The stack operates as a 31-word by 21-bit RAM and a
5-bit Stack Pointer, STKPTR. The stac k space is not
part of either program or da ta sp ace. The Stack Point er
is readable and writable and the address on the top of
the stack is readable and writable through the Top-of­Stack (TOS) Special File Registers. Data can also be
pushed to, or popped from the stack, using these
registers.

A CALL type instru ctio n cau ses a pu sh ont o the stack;
the Stack Pointer is first incremented and the location
pointed to by the Stack Pointer is written with the
contents of the PC (already pointing to the instruction
following the CALL). A RETURN type instruction causes
a pop from the stack; the contents of the location
pointed to by the STKPTR are transferred to the PC
and then the Stack Pointer is decremented.

The Stack Pointer is initialized to ‘00000’ after all
Resets. There is no RAM associated with the location
corresponding to a Stack Pointer value of ‘00000’; this
is only a Reset value. Status bits indicate if the stac k i s
full or has overflowed or has underflowed.

5.1.2.1 Top-of-Stack Access

Only the top of the return address stack (TOS) is readable
and writable. A set of three registers, TOSU:TOSH:TOSL,
hold the contents of the stack location pointed to by the
STKPTR register (Figure 5-2). This allows users to
implement a software stack if necessary. After a CALL,
RCALL or interrupt, the software can read the pushed
value by reading the TOSU:TOSH:TOSL registers. These
values can be placed on a user defined software stack. At
return time, the software can return these values to
TOSU:TOSH:TOSL and do a return.

The user must disable the global interrupt enable bits
while accessing the stack to prevent inadvertent stack
corruption.

FIGURE 5-2: RETURN ADDRESS STACK AND ASSOCIATED REGISTERS

DS40001303H-page 62  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

5.1.2.2 Return Stack Pointer (STKPTR)

The STKPTR register (Register5-1) contains the S tack
Pointer value, the STKFUL (stack full) Status bit and
the STKUNF (stack underflow) S ta tus bits . The value of
the Stack Pointer can be 0 through 31. The Stack
Pointer increments before values are pushed onto the
stack and decrements after values are popped off the
stack. On Reset, the Stack Pointer value will be zero.
The user may read and write the Stack Pointer value.
This feature can be used by a Real-Time Operating
System (RTOS) for return stack maintenance.

After the PC is pu sh ed ont o the s ta ck 31 time s (witho ut
popping any values off the stack), the STKFUL bit is
set. The STKFUL bit is cleared by software or by a
POR.

The action that takes place when the stack becomes
full depends on the state of the STVREN (Stack Over­flow Reset Enable) Configuration bit. (Refer to

Section 23.1 “Configuration Bits” for a de scription of

the device Configuration bits.) If STVREN is set
(default), the 31st push will push the (PC + 2) value
onto the stack, set the STKFUL bit and reset the
device. The STKFUL bit will remain set and the Stack
Pointer will be set to zero.

If STVREN is cleared, the STKFUL bi t will be set on the
31st push and the Stack Pointer will increment to 31.
Any additional pushes will not overwrite the 31st push
and STKPTR will remain at 31.

When the stack has been popped enough times to
unload the stac k, the next pop will ret urn a value of zero
to the PC and sets the STKUNF bit, while the Stack
Pointer remains at zero. The STKUNF bit will remain
set until cleared by software or until a POR occurs.

Note: Returning a value of zero to the PC on an

5.1.2.3 PUSH and POP Instructions

Since the Top-of-Stack is readable and writable, the
ability to push value s on to the st ac k an d pul l values off
the stack without disturbing normal program execution
is a desirable feature. The PIC18 instruction set
includes two instructions, PUSH and POP, that permit
the TOS to be manipulated under software control.
TOSU, TOSH and T OS L can be m odifie d to plac e dat a
or a return address on the stack.

The PUSH instruction places the current PC value onto
the stack. This increments the Stack Pointer and loads
the current PC value onto the stack.

The POP instruction discards the current TOS by
decrementing the Stack Pointer. The previous value
pushed onto the stack then becomes the TOS value.

REGISTER 5-1: STKPTR: STACK POINTER REGISTER

underflow has the effect of vectoring the
program to the Reset vector, where the
stack conditions can be verified and
appropriate actions can be taken. This is
not the same as a Rese t, as th e cont ents
of the SFRs are not affected.

R/C-0 R/C-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

STKFUL

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented C = Clearable only bit

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 STKFUL: Stack Full Flag bit

bit 6 STKUNF: Stack Underflow Flag bit

bit 5 Unimplemented: Read as ‘0’
bit 4-0 SP<4:0>: Stack Pointer Location bits

Note 1: Bit 7 and bit 6 are cleared by user software or by a POR.

(1)

STKUNF

1 = Stack became full or overflowed
0 = Stack has not become full or overflowed

1 = Stack und erfl ow occurred
0 = Stack underflow did not occur

(1)

— SP4 SP3 SP2 SP1 SP0

(1)

(1)

 2010-2015 Microchip Technology Inc. DS40001303H-page 63

PIC18F2XK20/4XK20

CALL SUB1, FAST ;STATUS, WREG, BSR

;SAVED IN FAST REGISTER
;STACK




SUB1 



RETURN, FAST ;RESTORE VALUES SAVED

;IN FAST REGISTER STACK

MOVF OFFSET, W

CALL TABLE
ORG nn00h
TABLE ADDWF PCL

RETLW nnh

RETLW nnh

RETLW nnh

.

.

.

5.1.2.4 Stack Full and Underflow Resets

Device Resets on stack overflow and stack underflow
conditions are enabled by setting the STVREN bit in
Configuration Register 4L. When STVREN is set, a ful l
or underflow will set the appropriate STKFUL or
STKUNF bit and then cause a device Reset. When
STVREN is cleared, a full or underflow condi tion will set
the appropriate STKFUL or STKUNF bit but not cause
a device Reset. The STKFUL or STKUNF bits are
cleared by the user software or a Power-on Reset.

5.1.3 FAST REGISTER STACK

A fast register stack is provided for the Status, WREG
and BSR registers, to provide a “fast return” option for
interrupts. The stack for each register is only one level
deep and is neither readable nor writable. It is loaded
with the current value of the corresponding register
when the processor vectors for an interrupt. All inter­rupt sources will push values into the stack registers.
The values in the registers are then loaded back into
their associated registers if the RETFIE, FAST
instruction is used to return from the interrupt.

If both low and high priority interrupts are enabled, the
stack registers cannot be used reliably to return from
low priority interrupts. If a high priority interrupt occurs
while servicing a low priori ty interrupt, the stack register
values stored by the low priority interrupt will be
overwritten. In these cases, users must save the key
registers by software during a low priority interrupt.

If interrupt priority is not used, all interrupts ma y use the
fast register stack for returns from interrupt. If no
interrupts are used, the fast register stack c an be use d
to restore the Status, WREG and BSR registers at the
end of a subroutine call. To use the fast register stack
for a subroutine call, a CALL label, FAST instru ction
must be executed to save the Status, WREG and BSR
registers to the fast register stack. A RETURN, FAST
instruction is then executed to restore these registers
from the fast register stack.

Example 5-1 shows a source cod e exampl e that uses

the fast register stack during a subroutine call and
return.

EXAMPLE 5-1: FAST REGISTER STACK

CODE EXAMPLE

DS40001303H-page 64  2010-2015 Microchip Technology Inc.

5.1.4 LOOK-UP TABLES IN PROGRAM MEMORY

There may be programming situations that require the
creation of data structures, or look-up tables, in
program memory. For PIC18 devices, look-up tables
can be implemented in two ways:

• Computed GOTO

• Table Reads

5.1.4.1 Computed GOTO

A computed GOTO is accompli shed by adding an of fs et
to the program counter. An example is shown in

Example 5-2.

A look-up table can be formed with an ADDWF PCL
instruction and a group of RETLW nn instructions. The
W register is loaded with an of fs et into the table before
executing a call to tha t t a ble . The first instruction o f th e
called routine is the ADDWF PCL instruction. The next
instruction executed will be one of the RETLW nn
instructions that returns the value ‘nn’ to the calling
function.

The offset value (in WREG) specifies the number of
bytes that the program counter should advance and
should be multiples of 2 (LSb = 0).

In this method, only one data byte may be stored in
each instruction location and room on the return
address stack is required.

EXAMPLE 5-2: COMPUTED GOTO USING

AN OFFSET VALUE

5.1.4.2 Table Reads and Table Writes

A better method of storing data in program memory
allows two bytes of dat a to be stored in each instruction
location.

Look-up table data may be stored two bytes per
program word by using table reads and writes. The
Table Pointer (TBLPTR) register specifies the byte
address and the Table Latch (TABLAT) register
contains the da ta that is read from o r written to program
memory. Data is transferred to or from program
memory one byte at a time.

Table read and table write operations are discussed
further in Section 6.1 “Table Reads and Table

Writes”.

PIC18F2XK20/4XK20

Q1

Q2 Q3 Q4

Q1

Q2 Q3 Q4

Q1

Q2 Q3 Q4

OSC1

Q1
Q2
Q3
Q4

PC

OSC2/CLKOUT

(RC mode)

PC PC + 2 PC + 4

Fetch INST (PC)

Execute INST (PC – 2)

Fetch INST (PC + 2)

Execute INST (PC)

Fetch INST (PC + 4)

Execute INST (PC + 2)

Internal
Phase
Clock

All instructions are single cycle, except for any program branche s. These tak e two cycles since the fetch instruct ion
is “flushed” from the pipeline while the new instruction is being fetched and then executed.

TCY0TCY1TCY2TCY3TCY4TCY5

1. MOVLW 55h

Fetch 1 Execute 1

2. MOVWF PORTB

Fetch 2 Execute 2

3. BRA SUB_1

Fetch 3 Execute 3

4. BSF PORTA, BIT3 (Forced NOP)

Fetch 4 Flush (NOP)

5. Instruction @ address SUB_1

Fetch SUB_1 Execute SUB_1

5.2 PIC18 Instruction Cycle

5.2.1 CLOCKING SCHEME

The microcontroller clock input, whether from an
internal or external source, is internally divided by four
to generate four non-overlapping quadrature clocks
(Q1, Q2, Q3 and Q 4). Internall y, the program counter i s
incremented on every Q1; the instruction is fetched
from the program memory and latched into the
instruction register during Q4. The instruction is
decoded and execute d during the followin g Q1 throug h
Q4. The clocks and instruction execution flow are
shown in Figure 5-3.

FIGURE 5-3: CLOCK/INSTRUCTION CYCLE

5.2.2 INSTRUCTION FLOW/PIPELINING

An “Instruction Cycle” consists of four Q cycles: Q1
through Q4. The instruction fetch and execute are
pipelined in such a manner that a fetch takes one
instruction cycle, while the decode and execute take
another instruction cycle. However, due to the
pipelining, each instruction effectively executes in one
cycle. If a n instruc tion caus es the pro gram coun ter to
change (e.g., GOTO), then two cycles are required to
complete the instruction (Example 5-3).

A fetch cycle begins with the Program Counter (PC)
incrementing in Q1.

In the execution cy cle, the fetch ed instruction i s latched
into the Instruction Register (IR) in cycle Q1. This
instruction is then decoded and executed during the
Q2, Q3 and Q4 c ycles. Dat a m emory is read during Q2
(operand read) and written during Q4 (destination
write).

EXAMPLE 5-3: INSTRUCTION PIPELINE FLOW

 2010-2015 Microchip Technology Inc. DS40001303H-page 65

PIC18F2XK20/4XK20

Word Address

LSB = 1 LSB = 0 
Program Memory
Byte Locations



000000h
000002h
000004h

000006h
Instruction 1: MOVLW 055h 0Fh 55h 000008h
Instruction 2: GOTO 0006h EFh 03h 00000Ah

F0h 00h 00000Ch

Instruction 3: MOVFF 123h, 456h C1h 23h 00000Eh

F4h 56h 000010h

000012h

000014h

5.2.3 INSTRUCTIONS IN PROGRAM MEMORY

The program memory is addressed in bytes.
Instructions are sto red as either two bytes or four bytes
in program memory. The Least Significant Byte of an
instruction word is alway s stored in a program me mo ry
location with an even address (LSb = 0). To maintain
alignment with instruction boundaries, the PC
increments in steps of 2 and the LSb will always read
‘0’ (see Section 5.1.1 “Program Counter”).

Figure 5-4 shows an example of how instruction w ord s

are stored in the program memory.

The CALL and GOTO instructions have the absolute
program memory address embedded into the
instruction. Since instructions are always stored on word
boundaries, the data contained in the instruction is a
word address. The word address is written to PC<20:1>,
which accesses the desired byte address in program
memory. Instruction #2 in Figure 5-4 shows how the
instruction GOTO 0006h is encoded in the program
memory. Program branch instructions, which encode a
relative address offset, operate in the same ma nner. The
offset value stored in a branch instruction represents the
number of single-word instructions that the PC will be
offset by. Section 24.0 “Instruction Set Summary”
provides further details of the instruction set.

FIGURE 5-4: INSTRUCTIONS IN PROGRAM MEMORY

5.2.4 TWO-WORD INSTRUCTIONS

The standard PIC18 instruction set has four two-word
instructions: CALL, MOVFF, GOTO and LSFR. In all
cases, the second word of the instruction always has
‘1111’ as its four M ost Signi fican t bit s; the other 12 bit s
are literal data, usually a data memory address.

The use of ‘1111’ in the 4 MSbs of an instruction
specifies a special form of NOP. If the instruction is
executed in proper sequence – immediately after the
first word – the data in the second word is accessed

and used by the instruction sequence. If the first word
is skipped for some reason and the second word is
executed by itself, a NOP is executed instead. This is
necessary for case s when the two-word ins truction is
preceded by a co nd i tio na l in str u ct ion t h at c h an ge s the
PC. Example 5-4 shows how this works.

Note: See Section 5.6 “PIC18 Instruction

Execution and the Extended Instruc­tion Set” for information on two-word

instructions in the extended instruction set.

EXAMPLE 5-4: TWO-WORD INSTRUCTIONS

CASE 1:
Object Code Source Code

0110 0110 0000 0000 TSTFSZ REG1 ; is RAM location 0?
1100 0001 0010 0011 MOVFF REG1, REG2 ; No, skip this word
1111 0100 0101 0110 ; Execute this word as a NOP
0010 0100 0000 0000 ADDWF REG3 ; continue code

CASE 2:
Object Code Source Code

0110 0110 0000 0000 TSTFSZ REG1 ; is RAM location 0?
1100 0001 0010 0011 MOVFF REG1, REG2 ; Yes, execute this word
1111 0100 0101 0110 ; 2nd word of instruction
0010 0100 0000 0000 ADDWF REG3 ; continue code

DS40001303H-page 66  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

5.3 Data Memory Organization

Note: The operation of some aspects of data

memory are changed when the PIC18
extended instruction set is enabled. See

Section 5.5 “Data Memory and the
Extended Instruction Set” for more

information.

The data memory in PIC18 devices is implemented as
static RAM. Each register in the data memory has a
12-bit address, allowing up to 4096 bytes of data
memory . The m emory sp ace is div ided into as many as
16 banks that contain 256 bytes each. Figures 5-5
through 5-7 show the da ta mem ory organi zation for th e
PIC18F2XK20/4XK20 devices.

The data memory contains Special Function Registers
(SFRs) and General Purpose Registers (GPRs). The
SFRs are used for control and status of the controller
and peripheral functio ns, while GPRs are us ed for data
storage and scratchpad operations in the user’s
application. Any re ad of an unimpl emented location will
read as ‘0’s.

The instruction set and architecture allow operations
across all banks. The entire data memory may be
accessed by Direct, Indirect or Indexed Addressing
modes. Addressing modes are discussed later in this
subsection.

To ensure that commonly used registers (SFRs and
select GPRs) c an b e ac cess ed i n a si ngle cycle, PI C18
devices impl em ent an Ac ce ss Ba nk . Th is i s a 256-byte
memory space that pr ovid es fa st acc ess to SFRs a nd
the lower portion of G PR Bank 0 without usin g the Bank
Select Register (BSR). Section 5.3.2 “Access Bank”
provides a detailed description of the Access RAM.

5.3.1 BANK SELECT REGISTER (BSR)

Large areas of data memory require an efficient
addressing scheme to make rapid access to any
address possible. Ideally, this means that an entire
address does not need to be provided for each read or
write operation. For PIC18 devices, this is accom­plished with a RAM banking scheme. This divides the
memory space into 16 contiguous banks of 256 bytes.
Depending on the instruction, each location can be
addressed directly by its full 12-bit address, or an 8-bit
low-order address and a 4-bit Bank Pointer.

Most instruct ions in th e PIC18 in struct ion set ma ke us e
of the Bank Pointer , known as the Ba nk Select Reg ister
(BSR). This SFR holds the four Most Significant bit s of
a location’s address; the instruction itself includes the
eight Least Significant bits. Only the four lower bits of
the BSR are implemented (BSR <3:0 >). T he upp er fo ur
bits are unused; the y will always read ‘ 0’ and cannot be
written to. The BSR can be l oaded direc tly b y using the
MOVLB instruction.

The value of the BSR indicates the bank in data
memory; the eight bits in the instruction show the
location in the bank and can be thought of as an offset
from the bank’s lower boundary. The relationship
between the BSR’s valu e an d the ba nk div is ion in data
memory is shown in Figures 5-5 through 5-7.

Since up to 16 reg isters m ay sh are the same l ow-ord er
address, the user must alway s be careful to ensure that
the proper bank is selected before performing a data
read or write. For example, writing what should be
program data to an 8 -bi t ad dres s of F 9h w h ile th e BSR
is 0Fh will end up resetting the program counter.

While any bank can be s el ec ted, only those banks th at
are actually implemented can be read or written to.
Writes to unimplemented banks are ignored, while
reads from unimplemented banks will return ‘0’s. Even
so, the STATUS register will still be affected as if the
operation was successful. The data memory maps in
Figures 5-5 through 5-7 indicate which banks are
implemented.

In the core PIC18 instruction set, only the MOVFF
instruction fully specifies the 12-bit address of the
source and target registers. This i nstruction ig nores the
BSR completely when it ex ecutes. All o ther instruction s
include only the low-order address as an operand and
must use either the BSR or the Access Bank to locate
their target registers.

 2010-2015 Microchip Technology Inc. DS40001303H-page 67

PIC18F2XK20/4XK20

Bank 0

Bank 1

Bank 14

Bank 15

Data Memory Map

BSR<3:0>

= 0000

= 0001

= 1111

060h

05Fh

F60h
FFFh

00h
5Fh

60h

FFh

Access Bank

When ‘a’ = 0:

The BSR is ignored an d the
Access Bank is used.

The first 96 bytes are
general purpose RAM
(from Bank 0).

The second 160 bytes are
Special Function Registers
(from Bank 15).

When ‘a’ = 1:

The BSR specifies the Ban k
used by the instruction.

F5Fh

F00h

EFFh

1FFh

100h

0FFh

000h

Access RAM

FFh

00h

FFh

00h

FFh

00h

GPR

GPR

SFR

Access RAM High

Access RAM Low

Bank 2

= 0110

= 0010

(SFRs)

2FFh

200h

3FFh

300h

4FFh

400h

5FFh

500h

6FFh

600h

7FFh

700h

8FFh

800h

9FFh

900h

AFFh

A00h

BFFh

B00h

CFFh

C00h

DFFh

D00h

E00h

Bank 3

Bank 4

Bank 5

Bank 6

Bank 7

Bank 8

Bank 9

Bank 10

Bank 11

Bank 12

Bank 13

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

= 0011

= 0100

= 0101

= 0111

= 1000

= 1001

= 1010

= 1011

= 1100

= 1101

= 1110

Unused

Read 00h

Unused

FIGURE 5-5: DATA MEMORY MAP FOR PIC18F23K20/43K20 DEVICES

DS40001303H-page 68  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

Bank 0

Bank 1

Bank 14

Bank 15

Data Memory Map

BSR<3:0>

= 0000

= 0001

= 1111

060h

05Fh

F60h
FFFh

00h
5Fh

60h

FFh

Access Bank

When ‘a’ = 0:

The BSR is ignored an d the
Access Bank is used.

The first 96 bytes are
general purpose RAM
(from Bank 0).

The second 160 bytes are
Special Function Registers
(from Bank 15).

When ‘a’ = 1:

The BSR specifies the Ban k
used by the instruction.

F5Fh

F00h

EFFh

1FFh

100h

0FFh

000h

Access RAM

FFh

00h

FFh

00h

FFh

00h

GPR

GPR

SFR

Access RAM High

Access RAM Low

Bank 2

= 0110

= 0010

(SFRs)

2FFh

200h

3FFh

300h

4FFh

400h

5FFh

500h

6FFh

600h

7FFh

700h

8FFh

800h

9FFh

900h

AFFh

A00h

BFFh

B00h

CFFh

C00h

DFFh

D00h

E00h

Bank 3

Bank 4

Bank 5

Bank 6

Bank 7

Bank 8

Bank 9

Bank 10

Bank 11

Bank 12

Bank 13

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

GPR

FFh

00h

= 0011

= 0100

= 0101

= 0111

= 1000

= 1001

= 1010

= 1011

= 1100

= 1101

= 1110

Unused

Read 00h

Unused

FIGURE 5-6: DATA MEMORY MAP FOR PIC18F24K20/44K20 DEVICES

 2010-2015 Microchip Technology Inc. DS40001303H-page 69

PIC18F2XK20/4XK20

Bank 0

Bank 1

Bank 14

Bank 15

Data Memory Map

BSR<3:0>

= 0000

= 0001

= 1111

060h

05Fh

F60h
FFFh

00h
5Fh

60h

FFh

Access Bank

When ‘a’ = 0:

The BSR is ignored an d the
Access Bank is used.

The first 96 bytes are
general purpose RAM
(from Bank 0).

The second 160 bytes are
Special Function Registers
(from Bank 15).

When ‘a’ = 1:

The BSR specifies the Ban k
used by the instruction.

F5Fh

F00h

EFFh

1FFh

100h

0FFh

000h

Access RAM

FFh

00h

FFh

00h

FFh

00h

GPR

GPR

SFR

Access RAM High

Access RAM Low

Bank 2

= 0110

= 0010

(SFRs)

2FFh

200h

3FFh

300h

4FFh

400h

5FFh

500h

6FFh

600h

7FFh

700h

8FFh

800h

9FFh

900h

AFFh

A00h

BFFh

B00h

CFFh

C00h

DFFh

D00h

E00h

Bank 3

Bank 4

Bank 5

Bank 6

Bank 7

Bank 8

Bank 9

Bank 10

Bank 11

Bank 12

Bank 13

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

GPR

FFh

00h

= 0011

= 0100

= 0101

= 0111

= 1000

= 1001

= 1010

= 1011

= 1100

= 1101

= 1110

Unused

Read 00h

Unused

GPR

GPR

GPR

FIGURE 5-7: DATA MEMORY MAP FOR PIC18F25K20/45K20 DEVICES

DS40001303H-page 70  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

Bank 0

Bank 1

Bank 14

Bank 15

Data Memory Map

BSR<3:0>

= 0000

= 0001

= 1111

060h

05Fh

F60h
FFFh

00h
5Fh

60h

FFh

Access Bank

When ‘a’ = 0:

The BSR is ignored an d the
Access Bank is used.

The first 96 bytes are
general purpose RAM
(from Bank 0).

The second 160 bytes are
Special Function Registers
(from Bank 15).

When ‘a’ = 1:

The BSR specifies the Ban k
used by the instruction.

F5Fh

F00h

EFFh

1FFh

100h

0FFh

000h

Access RAM

FFh

00h

FFh

00h

FFh

00h

GPR

GPR

SFR

Access RAM High

Access RAM Low

Bank 2

= 0110

= 0010

(SFRs)

2FFh

200h

3FFh

300h

4FFh

400h

5FFh

500h

6FFh

600h

7FFh

700h

8FFh

800h

9FFh

900h

AFFh

A00h

BFFh

B00h

CFFh

C00h

DFFh

D00h

E00h

Bank 3

Bank 4

Bank 5

Bank 6

Bank 7

Bank 8

Bank 9

Bank 10

Bank 11

Bank 12

Bank 13

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

GPR

FFh

00h

= 0011

= 0100

= 0101

= 0111

= 1000

= 1001

= 1010

= 1011

= 1100

= 1101

= 1110

GPR

GPR

GPR

GPR

GPR

GPR

GPR

GPR

GPR

GPR

GPR

GPR

GPR

FIGURE 5-8: DATA MEMORY MAP FOR PIC18F26K20/46K20 DEVICES

 2010-2015 Microchip Technology Inc. DS40001303H-page 71

PIC18F2XK20/4XK20

Note 1: The Access RAM bit of the instruction can be used to force an override of the selected bank (BSR<3:0>) to

the registers of the Access Bank.

2: The MOVFF instruction embeds the entire 12-bit address in the instruction.

Data

Memory

Bank Select

(2)

7

0

From Opcode

(2)

0000

000h

100h

200h

300h

F00h

E00h

FFFh

Bank 0
Bank 1

Bank 2

Bank 14

Bank 15

00h
FFh

00h
FFh

00h
FFh

00h
FFh

00h
FFh

00h

FFh

Bank 3

through

Bank 13

0011

11111111

7

0

BSR

(1)

FIGURE 5-9: USE OF THE BANK SELECT REGISTER (DIRECT ADDRESSING)

DS40001303H-page 72  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

5.3.2 ACCESS BANK

While the use of the BSR with an embedded 8-bit
address allows users to address the entire range of
data memory, it also means th at the user must a lways
ensure that the correct bank is selected. Otherwise,
data may be read from or written to the wrong location.
This can be disastrous if a GPR is the intended target
of an operation, but an SFR is written to instead.
Verifying and/or changing the BSR for each read or
write to data memory can become very inefficient.

T o stre amline acces s for the most commonl y used data
memory locations, the data memory is configured with
an Access Bank, which allows users to access a
mapped block of memory without specifying a BSR.
The Access Bank c onsist s o f the f irst 96 byte s of mem­ory (00h-5Fh) in Bank 0 and the last 160 bytes of mem­ory (60h-FFh) in Block 15. The lower half is known as
the “Access RAM” and is composed of GPRs. This
upper half is also where the device’s SFRs are
mapped. These two areas are mapped contiguously in
the Access Bank and can be addressed in a linear
fashion by an 8-bit address (Figures 5-5 through 5-7).

The Access Bank is used by core PIC18 instructions
that include the Access RAM bit (the ‘a’ parameter in
the instruction). When ‘a’ is equal to ‘1’, the instru ct i on
uses the BSR and the 8-bit address included in the
opcode for the data memory address. When ‘a’ is ‘0’,
however, the instruction is forced to use the Access
Bank address map; the current value of the BSR is
ignored entirely.

Using this “forced” addressing allows the instruction to
operate on a data address in a single cycle, without
updating the BSR first. For 8-bit addresses of 60h and
above, this mean s that use rs can ev aluate an d opera te
on SFRs more efficiently. The Access RAM below 60h
is a good place for da ta values that the use r might need
to access rapidly, such as immediate computational
results or common program variables. Access RAM
also allows for faster and more code efficient context
saving and switching of variables.

The mapping of the Access Bank is slightly different
when the extended instruction set is enabled (XINST
Configuration bit = 1). This is discussed in more deta il
in Section 5.5.3 “Mapping the Access Bank in

Indexed Literal Offset Mode”.

5.3.3 GENERAL PURPOSE REGISTER FILE

PIC18 devices may have banked memory in the GPR
area. This is data RAM, which is available for use by all
instructions. GPRs start at the bottom of Bank 0
(address 000h) and grow upwards towards the bottom of
the SFR area. GPRs are not initialized by a Power-on
Reset and are unchanged on all other Resets.

5.3.4 SPECIAL FUNCTION REGISTERS

The Special Function Registers (SFRs) are registers
used by the CPU an d peripheral mod ules for controllin g
the desired operation of the device. These reg isters are
implemented as static RAM. SFRs start at the top of
data memory (F FFh) an d exte nd dow nward to occu py
the top portion of Bank 15 (F60h to FFFh). A list of
these registers is given in Table 5-1 and Table 5-2.

The SFRs can be classified into two sets: those
associated with the “core” device functionality (ALU,
Resets and interrupts) and those related to the
peripheral functions. The Reset and interrupt registers
are described in their respective chapters, while the
ALU’s STATUS register is described later in this
section. Registers related to the operation of a
peripheral feature are described in the chapter for that
peripheral.

The SFRs are typically distributed among the
peripherals whose fun cti ons th ey c ontr ol. U nus ed SFR
locations are unimplemented and read as ‘0’s.

 2010-2015 Microchip Technology Inc. DS40001303H-page 73

PIC18F2XK20/4XK20

TABLE 5-1: SPECIAL FUNCTION REGISTER MAP FOR PIC 18F2XK2 0/4XK2 0 DEVI CES

Address Name Address Name Address Name Address Name

FFFh TOSU FD7h TMR0H FAFh SPBRG F87h

FFEh TOSH FD6h TMR0L FAEh RCREG F86h —
FFDh TOSL FD5h T0CON FADh TXREG F85h —
FFCh STKPTR FD4h —

FFBh PCLATU FD3h OSCCON FABh RCSTA F83h PORTD

FFAh PCLATH FD2h HLVDCON FAAh EEADRH

FF9h PCL FD1h WDTCON FA9h EEADR F81h PORTB
FF8h TBLPTRU FD0h RCON FA8h EEDATA F80h PORTA
FF7h TBLPTRH FCFh TMR1H FA7h EECON2
FF6h TBLPTRL FCEh TMR1L FA6h EECON1 F7Eh ANSEL
FF5h TABLAT FCDh T1CON FA5h —
FF4h PRODH FCCh TMR2 FA4h
FF3h PRODL FCBh PR2 FA3h
FF2h INTCON FCAh T2CON FA2h IPR2 F7Ah CM2CON0
FF1h INTCON2 FC9h SSPBUF FA1h PIR2 F79h CM2CON1
FF0h INTCON3 FC8h SSPADD FA0h PIE2 F78h SLRCON

(1)

FEFh INDF0
FEEh POSTINC0
FEDh POSTDEC0
FECh PREINC0
FEBh PLUSW0

FC7h SSPSTAT F9Fh IPR1 F77h SSPMSK

(1)

(1)

(1)

(1)

FC6h SSPCON1 F9Eh PIR1 F76h —
FC5h SSPCON2 F9Dh PIE1 F75h —
FC4h ADRESH F9Ch —
FC3h ADRESL F9Bh OSCTUNE F73h —

FEAh FSR0H FC2h ADCON0 F9Ah —

FE9h FSR0L FC1h ADCON1 F99h —

FE8h WREG FC0h ADCON2 F98h —

FE7h INDF1

FE6h POSTINC1

FE5h POSTDEC1

FE4h PREINC1

FE3h PLUSW1

(1)

(1)

(1)

(1)

(1)

FBFh CCPR1H F97h —

FBEh CCPR1L F96h TRISE
FBDh CCP1CON F95h TRISD
FBCh CCPR2H F94h TRISC F6Ch —

FBBh CCPR2L F93h TRISB F6Bh —

FE2h FSR1H FBAh CCP2CON F92h TRISA F6Ah —
FE1h FSR1L FB9h PSTRCON F91h —

FE0h BSR FB8h BAUDCON F90h —
FDFh INDF2
FDEh POSTINC2

FDDh POSTDEC2
FDCh PREINC2

FDBh PLUSW2

(1)

FB7h PWM1CON F8Fh —

(1)

(1)

(1)

(1)

FB6h ECCP1AS F8Eh —
FB5h CVRCON F8Dh LATE
FB4h CVRCON2 F8Ch LATD
FB3h TMR3H F8Bh LATC F63h —

FDAh FSR2H FB2h TMR3L F8Ah LATB F62h —

FD9h FSR2L FB1h T3CON F89h LATA F61h —

FD8h STATUS FB0h SPBRGH F88h —

(2)

FACh TXSTA F84h PORTE

(4)

(1)

(2)
(2)

—

(2)

—

(2)

(2)
(2)
(2)
(2)

(3)
(3)

(2)
(2)
(2)
(2)

(3)

F65h —

(3)

F64h —

(2)

F82h PORTC

F7Fh ANSELH

F7Dh IOCB
F7Ch WPUB

F7Bh CM1CON0

F74h —

F72h —
F71h —
F70h —
F6Fh —
F6Eh —

F6Dh —

F69h —
F68h —
F67h —
F66h —

F60h —

—

(2)
(2)
(2)

(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)

(3)

Note 1: This is not a physical register.

2: Unimplemented r egisters are read as ‘0’.

3: This register is not available on PIC18F2XK20 devices.

4: This register is only implemented in the PIC18F46K20 and PIC18F26K20 devices.

DS40001303H-page 74  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 5-2: REGISTER FILE SUMMARY (PIC18F2XK20/4XK20)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TOSU
TOSH Top-of-Stack, High Byte (TOS<15:8>) 0000 0000 56, 62
TOSL Top-of-Stack, Low Byte (TOS<7:0>) 0000 0000 56, 62
STKPTR STKFUL STKUNF
PCLATU
PCLATH Holdi ng Register for PC<15:8> 0000 0000 56, 62
PCL PC, Low Byte (PC<7:0>) 0000 0000 56, 62
TBLPTRU
TBLPTRH Program Memory Table Pointer, High Byte (TBLPTR<15:8>) 0000 0000 56, 87
TBLPTRL Program Memory Table Pointer, Low Byte (TBLPTR<7:0>) 0000 0000 56, 87
TABLAT Program Memory Table Latch 0000 0000 56, 87
PRODH Product Register, High Byte xxxx xxxx 56, 98
PRODL Product Register, Low Byte xxxx xxxx 56, 98
INTCON GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 0000 000x 56, 102
INTCON2 RBPU
INTCON3 INT2IP INT1IP
INDF0 Uses contents of FSR0 to address data memory – value of FSR0 not changed (not a physical register) N/A 56, 80
POSTINC0 Uses contents of FSR0 to add ress data memory – value of FSR0 post-incremented (not a physical register) N/A 56, 80
POSTDEC0 Uses contents of FSR0 to address data memory – value of FSR0 post-decremented (not a physical register) N /A 56, 80
PREINC0 Uses contents of FSR0 to address data memory – value of FSR0 pre-incremented (not a physical register) N/A 56, 80
PLUSW0 Uses contents of FSR0 to address data memory – value of FSR0 offset by W (not a physical register) – N/A 56, 80
FSR0H
FSR0L Indirect Data Memory Address Pointer 0, Low Byte xxxx xxxx 56, 80
WREG Working Register xxxx xxxx 56
INDF1 Uses contents of FSR1 to address data memory – value of FSR1 not changed (not a physical register) N/A 56, 80
POSTINC1 Uses contents of FSR1 to add ress data memory – value of FSR1 post-incremented (not a physical register) N/A 56, 80
POSTDEC1 Uses contents of FSR1 to address data memory – value of FSR1 post-decremented (not a physical register) N /A 56, 80
PREINC1 Uses contents of FSR1 to address data memory – value of FSR1 pre-incremented (not a physical register) N/A 56, 80
PLUSW1 Uses contents of FSR1 to address data memory – value of FSR1 offset by W (not a physical register) – value of N/A 56, 80
FSR1H
FSR1L Indirect Data Memory Address Pointer 1, Low Byte xxxx xxxx 57, 80
BSR
INDF2 Uses contents of FSR2 to address data memory – value of FSR2 not changed (not a physical register) N/A 57, 80
POSTINC2 Uses contents of FSR2 to add ress data memory – value of FSR2 post-incremented (not a physical register) N/A 57, 80
POSTDEC2 Uses contents of FSR2 to address data memory – value of FSR2 post-decremented (not a physical register) N /A 57, 80
PREINC2 Uses contents of FSR2 to address data memory – value of FSR2 pre-incremented (not a physical register) N/A 57, 80
PLUSW2 Uses contents of FSR2 to address data memory – value of FSR2 offset by W (not a physical register) – value of N/A 57, 80
FSR2H
FSR2L Indirect Data Memory Address Pointer 2, Low Byte xxxx xxxx 57, 80
STATUS

Legend: x = unknown, u = unchanged, — = unimplemented, q = value depends on condition
Note 1: The SBOREN bit is only available when the BOREN<1:0> Configuration bits = 01; otherwise it is disabled and reads as ‘0’. See

2: These registers and/ or bits are not implemented on 28-pin devices and are read as ‘0’. Reset values are shown for 40/44-pin devices;
3: The PLLEN bit is only available in specific oscillator configuration; otherwise it is disabled and reads as ‘0’. See Section 2.6.2 “PLL in
4: The RE3 bit is only available when Master Clear Reset is disabled (MCLRE Configuration bit = 0). Otherwise, RE3 reads as ‘0’. This bit is
5: RA6/RA7 and their associated latch and direction bits are individually configured as port pins based on various primary oscillator modes.
6: All bits of the ANSELH register initialize to ‘0’ if the PBADEN bit of CONFIG3H is ‘0’.

7: This register is only implemented in the PIC18F46K20 and PIC18F26K20 devices.

— — — Top-of-Stack Upper Byte (TOS<20:16>) ---0 0000 56, 62

— SP4 SP3 SP2 SP1 SP0 00-0 0000 56, 63

— — — Holding Register for PC<20:16> ---0 0000 56, 62

— — bit 21 Program Memory Table Pointer Upper Byte (TBLPTR<20:16>) --00 0000 56, 87

INTEDG0 INTEDG1 INTEDG2 —TMR0IP—RBIP1111 -1-1 56, 103

—INT2IEINT1IE— INT2IF INT1IF 11-0 0-00 56, 104

— — — — Indirect Data Memory Address Pointer 0, High Byte ---- 0000 56, 80

— — — — Indirect Data Memory Address Pointer 1, High Byte ---- 0000 57, 80

— — — — Bank Select Register ---- 0000 57, 67

— — — — Indirect Data Memory Address Pointer 2, High Byte ---- 0000 57, 80

— — —NOVZDCC---x xxxx 57, 78

Section 4.4 “Brown-out Reset (BOR)”.

individual unimplemented bits should be interpreted as ‘-’.

HFINTOSC Modes”.

read-only.
When disabled, these bits read as ‘0’.

Value on

POR, BOR

Details

on page:

 2010-2015 Microchip Technology Inc. DS40001303H-page 75

PIC18F2XK20/4XK20

TABLE 5-2: REGISTER FILE SUMMARY (PIC18F2XK20/4XK20) (CONTINUED)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TMR0H Timer0 Register, High Byte 0000 0000 57, 147
TMR0L Timer0 Register, Low Byte xxxx xxxx 57, 147
T0CON TMR0ON T08BIT T0CS T0SE PSA T0PS2 T0PS1 T0PS0 1111 1111 57, 145
OSCCON IDLEN IRCF2 IRCF1 IRCF0 OSTS IOFS SCS1 SCS0 0011 qq00 28, 57
HLVDCON VDIRMAG
WDTCON

RCON IPEN SBOREN

TMR1H Timer1 Register, High Byte xxxx xxxx 57, 154
TMR1L Timer1 Register, Low Bytes xxxx xxxx 57, 154

T1CON RD16 T1RUN T1CKPS1 T1CKPS0 T1OSCEN T1SYNC
TMR2 Timer2 Register 0000 0000 57, 156
PR2 Timer2 Period Register 1111 1111 57, 156
T2CON
SSPBUF SSP Receive Buffer/Transmit Register xxxx xxxx 57, 188,

SSPADD SSP Address Register in I
SSPSTAT SMP CKE D/A

SSPCON1 WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 57, 182,

SSPCON2 GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN 0000 0000 57, 193
ADRESH A/D Result Register, High Byte xxxx xxxx 58, 261
ADRESL A/D Result Register, Low Byte xxxx xxxx 58, 261

ADCON0
ADCON1
ADCON2 ADFM
CCPR1H Capture/Co mpar e/P WM R egis ter 1, Hig h Byt e xxxx xxxx 58, 135
CCPR1L Captur e/C o mpar e/PW M Regi s ter 1, Low Byt e xxxx xxxx 58, 135
CCP1CON P1M1 P1M0 DC1B1 DC1B0 CCP1M3 CCP1M2 CCP1M1 CCP1M0 0000 0000 58, 161
CCPR2H Capture/Co mpar e/P WM R egis ter 2, Hig h Byt e xxxx xxxx 58, 135
CCPR2L Captur e/C o mpar e/PW M Regi s ter 2, Low Byt e xxxx xxxx 58, 135
CCP2CON
PSTRCON
BAUDCON ABDOVF RCIDL DTRXP CKTXP BRG16
PWM1CON PRSEN PDC6 PDC5 PDC4 PDC3 PDC2 PDC1 PDC0 0000 0000 58, 174
ECCP1AS ECCPASE ECCPAS2 ECCPAS1 ECCPAS0 PSSAC1 PSSAC0 PSSBD1 PSSBD0 0000 0000 58, 171
CVRCON CVREN CVROE CVRR CVRSS CVR3 CVR2 CVR1 CVR0 0000 0000 58, 274
CVRCON2 FVREN FVRST
TMR3H Timer3 Register, High Byte xxxx xxxx 58, 160
TMR3L Timer3 Register, Low Byte xxxx xxxx 58, 160
T3CON RD16 T3CCP2 T3CKPS1 T3CKPS0 T3CCP1 T3SYNC

Legend: x = unknown, u = unchanged, — = unimplemented, q = value depends on condition
Note 1: The SBOREN bit is only available when the BOREN<1:0> Configuration bits = 01; otherwise it is disabled and reads as ‘0’. See

2: These registers and/ or bits are not implemented on 28-pin devices and are read as ‘0’. Reset values are shown for 40/44-pin devices;
3: The PLLEN bit is only available in specific oscillator configuration; otherwise it is disabled and reads as ‘0’. See Section 2.6.2 “PLL in
4: The RE3 bit is only available when Master Clear Reset is disabled (MCLRE Configuration bit = 0). Otherwise, RE3 reads as ‘0’. This bit is
5: RA6/RA7 and their associated latch and direction bits are individually configured as port pins based on various primary oscillator modes.
6: All bits of the ANSELH register initialize to ‘0’ if the PBADEN bit of CONFIG3H is ‘0’.

7: This register is only implemented in the PIC18F46K20 and PIC18F26K20 devices.

— — — — — — —SWDTEN--- ---0 57, 291

— T2OUTPS3 T2OUTPS2 T2OUTPS1 T2OUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 57, 155

— — CHS3 CHS2 CHS1 CHS0 GO/DONE ADON --00 0000 58, 255
— —VCFG1VCFG0— — — — --00 ---- 59, 256

— — DC2B1 DC2B0 CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 58, 134
— — — STRSYNC STRD STRC STRB STRA ---0 0001 58, 175

Section 4.4 “Brown-out Reset (BOR)”.

individual unimplemented bits should be interpreted as ‘-’.

HFINTOSC Modes”.

read-only.
When disabled, these bits read as ‘0’.

— IRVST HLVDEN HLVDL3 HLVDL2 HLVDL1 HLVDL0 0-00 0101 57, 276

(1)

—RITO PD POR BOR 0q-1 11q0 48, 55,

TMR1CS TMR1ON 0000 0000 57, 148

2

C™ Slave Mode. SSP Baud Rate Reload Register in I2C Master Mode. 0000 0000 57, 189

PSR/WUA BF 0000 0000 57, 181,

— ACQT2 ACQT1 ACQT0 ADCS2 ADCS1 ADCS0 0-00 0000 58, 257

— WUE ABDEN 0100 0-00 58, 233

— — — — — — 00-- ---- 58, 275

TMR3CS TMR3ON 0000 0000 58, 157

Value on

POR, BOR

Details

on page:

111

189

191

192

DS40001303H-page 76  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 5-2: REGISTER FILE SUMMARY (PIC18F2XK20/4XK20) (CONTINUED)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Value on

POR, BOR

SPBRGH EUSART Baud Rate Generator Register, High Byte 0000 0000 58, 226
SPBRG EUSART Baud Rate Generator Register, Low Byte 0000 0000 58, 226
RCREG EUSART Receive Register 0000 0000 58, 223
TXREG EUSART Transmit Register 0000 0000 58, 222
TXSTA CSRC TX9 TXEN SYNC SENDB BRGH TRMT TX9D 0000 0010 58, 231
RCSTA SPEN RX9 SREN CREN ADDEN FERR OERR RX9D 0000 000x 58, 232
EEADR EEADR7 EEADR6 EEADR5 EEADR4 EEADR3 EEADR2 EEADR1 EEADR0 0000 0000 58, 85, 93

(7)

EEADRH

— — — — — — EEADR9 EEADR8 ---- --00 58, 85, 93
EEDATA EEPROM Data Register 0000 0000 58, 85, 93
EECON2 EEPROM Control Register 2 (not a physical register) 0000 0000 58, 85, 93
EECON1 EEPGD CFGS

— FREE WRERR WREN WR RD xx-0 x000 58, 86, 93
IPR2 OSCFIP C1IP C2IP EEIP BCLIP HLVDIP TMR3IP CCP2IP 1111 1111 59, 110
PIR2 OSCFIF C1IF C2IF EEIF BCLIF HLVDIF TMR3IF CCP2IF 0000 0000 59, 106
PIE2 OSCFIE C1IE C2IE EEIE BCLIE HLVDIE TMR3IE CCP2IE 0000 0000 59, 108
IPR1 PSPIP
PIR1 PSPIF
PIE1 PSPIE
OSCTUNE INTSRC PLLEN

(2)

TRISE

(2)

TRISD

(2)

ADIP RCIP TXIP SSPIP CCP1IP TMR2IP TMR1IP 1111 1111 59, 109

(2)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 59, 105

(2)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 59, 107

(3)

TUN5 TU N4 TUN3 TUN2 TUN1 TUN0 0q00 0000 32, 59

IBF OBF IBOV PSPMODE — TRISE2 TRISE1 TRISE0 0000 -111 59, 126

PORTD Data Direction Control Register 1111 1111 59, 122
TRISC PORTC Data Direction Control Register 1111 1111 59, 119
TRISB PORTB Data Direction Control Register 1111 1111 59, 116
TRISA TRISA7

(2)

LATE

LATD

(2)

— — — — — PORTE Data Latch Register

PORTD Data Latch Register (Read and Write to Data Latch) xxxx xxxx 59, 122

(5)

TRISA6

(5)

Data Direction Control Register for PORTA 1111 1111 59, 113

(Read and Write to Data Latch)

---- -xxx 59, 125

LATC PORTC Data Latch Register (Read and Write to D ata Latch) xxxx xxxx 59, 119
LATB PORTB Data Latch Register (Read and Write to Data Latch) xxxx xxxx 59, 116
LATA LATA7
PORTE
PORTD

(2)

— — — —RE3

RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0 xxxx xxxx 59, 122

(5)

LATA6

(5)

PORTA Data Latch Register (Read and Write to Data Latch) xxxx xxxx 59, 113

(4)

RE2

(2)

RE1

(2)

RE0

(2)

---- x000 59, 125

PORTC RC7 RC6 RC5 RC4 RC3 RC2 RC1 RC0 xxxx xxxx 59, 119
PORTB RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 xxx0 0000 59, 116
PORTA RA7

(6)

ANSELH
ANSEL ANS7

(5)

— — — ANS12 ANS11 ANS10 ANS9 ANS8 ---1 1111 59, 129

(2)

IOCB IOCB7 IOCB6 IOCB5 IOCB4

RA6

ANS6

(5)

(2)

RA5 RA4 RA3 RA2 RA1 RA0 xx0x 0000 59, 113

(2)

ANS5

ANS4 ANS3 ANS2 ANS1 ANS0 1111 1111 59, 128

— — — — 0000 ---- 59, 116
WPUB WPUB7 WPUB6 WPUB5 WPUB4 WPUB3 WPUB2 WPUB1 WPUB0 1111 1111 59, 116
CM1CON0 C1ON C1OUT C1OE C1POL C1SP C1R C1CH1 C1CH0 0000 0000 59, 267
CM2CON0 C2ON C2OUT C2OE C2POL C2SP C2R C2CH1 C2CH0 0000 0000 59, 268
CM2CON1 MC1OUT MC2OUT C1RSEL C2RSEL
SLRCON

— — —SLRE

(2)

— — — — 0000 ---- 60, 270

(2)

SLRD

SLRC SLRB SLRA ---1 1111 60, 130

SSPMSK MSK7 MSK6 MSK5 MSK4 MSK3 MSK2 MSK1 MSK0 1111 1111 60, 200

Legend: x = unknown, u = unchanged, — = unimplemented, q = value depends on condition
Note 1: The SBOREN bit is only available when the BOREN<1:0> Configuration bits = 01; otherwise it is disabled and reads as ‘0’. See

Section 4.4 “Brown-out Reset (BOR)”.

2: These registers and/ or bits are not implemented on 28-pin devices and are read as ‘0’. Reset values are shown for 40/44-pin devices;

individual unimplemented bits should be interpreted as ‘-’.

3: The PLLEN bit is only available in specific oscillator configuration; otherwise it is disabled and reads as ‘0’. See Section 2.6.2 “PLL in

HFINTOSC Modes”.

4: The RE3 bit is only available when Master Clear Reset is disabled (MCLRE Configuration bit = 0). Otherwise, RE3 reads as ‘0’. This bit is

read-only.

5: RA6/RA7 and their associated latch and direction bits are individually configured as port pins based on various primary oscillator modes.

When disabled, these bits read as ‘0’.

6: All bits of the ANSELH register initialize to ‘0’ if the PBADEN bit of CONFIG3H is ‘0’.
7: This register is only implemented in the PIC18F46K20 and PIC18F26K20 devices.

Details

on page:

 2010-2015 Microchip Technology Inc. DS40001303H-page 77

PIC18F2XK20/4XK20

5.3.5 STATUS REGISTER

The STATUS register, shown in Register 5-2, contains
the arithmetic status of the ALU. As wi th any other SFR,
it can be the operand for any instruction.

If the STATUS register is the destination for an
instruction that affects the Z, DC, C, OV or N bits, the
results of the instruction are not written; instead, the
STATUS register is updated according to the
instruction performed. Therefore, the result of an
instruction with the STATUS register as its destination
may be different than intended. As an example, CLRF
STATUS will set the Z bit and leave the remaining
Status bits unchanged (‘000u u1uu’).

It is recommended that only BCF, BSF, SWAPF, MOVFF
and MOVWF instructions are used to alter the STATUS
register , b ecaus e thes e ins tructi ons d o not af fect t he Z,
C, DC, OV or N bits in the STATUS register.

For other instructions that do not affect Status bi t s , see
the instruction set summaries in Table 24-2 and

Table 24-3.

Note: The C and DC bits operate as the borrow

and digit borrow bits, respectively, in
subtraction.

REGISTER 5-2: STAT US : STATUS REGISTER

U-0 U-0 U-0 R/W-x R/W-x R/W-x R/W-x R/W-x

— — —

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

NOV ZDC

(1)

(1)

C

bit 7-5 Unimplemented: Read as ‘0’
bit 4 N: Negative bit

This bit is used for sign ed arith metic (two’ s co mpl ement). It i ndi cates w hether t he resu lt was negat ive
(ALU MSB = 1).

1 = Result was negative
0 = Result was positive

bit 3 OV: Overflow bit

This bit is used for signed arithmetic (two’s complement). It indicates an overflow of the 7-bit magni­tude which causes the sign bit (bit 7 of the result) to change state.

1 = Overflow occurred for signed arithmetic (in this arithmetic operation)
0 = No overflow occurred

bit 2 Z: Zero bit

1 = The result of an arithmetic or logic operation is zero
0 = The result of an arithmetic or logic operation is not zero

bit 1 DC: Digit Carry/Borrow

1 = A carry-out from the 4th low-order bit of the result occurred
0 = No carry-out from the 4th low-order bit of the result

bit 0 C: Carry/Borrow

1 = A carry-out from the Most Significant bit of the result occurred
0 = No carry-out from the Most Significant bit of the result occurred

Note 1: For Borrow

second operand. For rotate (RRF, RLF) instructions , this b it is loaded with ei ther the hi gh-order or low-orde r
bit of the source register.

, the polarity is reversed. A subtraction is executed by adding the two’s complement of the

bit (ADDWF, ADDLW,SUBLW,SUBWF inst ructions)

bit (ADDWF, ADDLW, SUBLW, SUBWF instructions)

(1)

(1)

DS40001303H-page 78  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

LFSR FSR0, 100h ;

NEXT CLRF POSTINC0 ; Clear INDF

; register then
; inc pointer

BTFSS FSR0H, 1 ; All done with

; Bank1?

BRA NEXT ; NO, clear next

CONTINUE ; YES, continue

5.4 Data Addressing Modes

Note: The execution of some instructions in the

core PIC18 instruction set are changed
when the PIC18 extended instruction set is
enabled. See Section 5.5 “Data Memory

and the Extended Instruction Set” for

more information.

While the program memory can be addressed in only
one way – through the program counter – information
in the data memory sp ace c an be a ddress ed in severa l
ways. For most instructions, the addressing mode is
fixed. Other instructions may use up to three modes,
depending on whic h operands are used and whe ther or
not the extended instruction set is enabled.

The addressing modes are:

• Inherent

• Literal

•Direct

•Indirect
An additional addressing mode, Indexed Literal Offset,

is available when the extended instruction set is
enabled (XINST Configuration bit = 1). Its operation is
discussed in greater detail in Section 5.5.1 “Indexed

Addressing with Literal Offset”.

5.4.1 INHERENT AND LITERAL ADDRESSING

Many PIC18 control instru ctions do not need any argu­ment at all; they either perform an operation that glob­ally affects the device or they operate implicitly on one
register. This addressing mode is known as Inherent
Addressing. Examples include SLEEP, RESET and DAW.

Other instructions work in a similar way but require an
additional explicit argument in the opcode. This is
known as Literal Addressing mode because they
require some literal value as an argument. Examples
include ADDLW and MOVLW, which respectively, add or
move a literal value to the W register. Other examples
include CALL and GOTO, which include a 20-bit
program memory address.

The Access RAM bit ‘a’ determines how the a ddre ss is
interpreted. When ‘a’ is ‘1’, the contents of the BSR
(Section 5.3.1 “Bank Select Register (BSR)”) are
used with the address t o determin e the comple te 12-bit
address of the reg ister. When ‘a’ is ‘0’, the address is
interpreted as being a register in the Access Bank.
Addressing that uses the Access RAM is sometimes
also known as Direct Forced Addressing mode.

A few instructions, such as MOVFF, include the entire
12-bit address (either source or destination) in their
opcodes. In these cases, the BSR is ignored entirely.

The destination of the operati on’s results is determined
by the destination bit ‘d ’. Wh en ‘d’ is ‘1’, the results are
stored back in th e s o ur c e re g is ter, overw rit i n g i ts or i gi­nal contents. When ‘d’ is ‘0’, the results are stored in
the W register. Instructions without the ‘d’ argument
have a destin ation tha t is i mplicit in the inst ruction; their
destination is either the target register being operated
on or the W register.

5.4.3 INDIRECT ADDRESSING

Indirect addressi ng allows the user to acces s a locatio n
in data memory without giving a fixed address in the
instruction. This is done by using File Select Registers
(FSRs) as pointers to th e locations wh ich are to be read
or written. Since the FSRs are themselves located in
RAM as Special File Registers, they can also be
directly manipulated under program control. This
makes FSRs very useful in implementing data
structures, such as tables and arrays in data memory.

The registers for indirect addressing are also
implemented with Indirect File Operands (INDFs) that
permit automatic mani pulati on of the poi nter value with
auto-incrementing, auto-decrementing or offsetting
with another va lue . Th is al lo ws f or e fficient code, us in g
loops, such as the example of clearing an entire RAM
bank in Example 5-5.

EXAMPLE 5-5: HOW TO CLEAR RAM

(BANK 1) USING
INDIRECT ADDRESSING

5.4.2 DIRECT ADDRESSING

Direct addressing specifies all or part of the source
and/or destination address of the operation within the
opcode itself. The options are specified by the
arguments accompanying the instruction.

In the core PIC18 inst ruct ion se t, bit-ori ented and by te­oriented instructions use some version of direct
addressing by default. All of these instructions include
some 8-bit literal address as their Least Significant
Byte. This address spec ifies either a re gister address in
one of the banks of d ata RAM ( Section 5.3.3 “General

Purpose Register File”) or a location in the Access

Bank (Section 5.3.2 “Access Bank”) as the data
source for the instruction.

 2010-2015 Microchip Technology Inc. DS40001303H-page 79

PIC18F2XK20/4XK20

FSR1H:FSR1L

0

7

Data Memory

000h

100h

200h

300h

F00h

E00h

FFFh

Bank 0
Bank 1

Bank 2

Bank 14

Bank 15

Bank 3
through

Bank 13

ADDWF, INDF1, 1

07

Using an instruction with one of the
indirect addressing registers as the

operand....

...uses the 12-bit address stored in
the FSR pair associated with that

register....

...to determine the data memory
location to be used in that operation.

In this case, the FSR1 pair contains
ECCh. This means the contents of
location ECCh will be added to that
of the W register and stored back in
ECCh.

xxxx1110 11001100

5.4.3.1 FSR Regist er s and the INDF
Operand

At the core of indirect addressing are three sets of
registers: FSR0, FSR1 and FSR2. Each represents a
pair of 8-bit registers, FSRnH and FSRnL. Each FSR
pair holds a 12-bit value, therefore the four upper bits
of the FSRnH register are not used. The 12-bit FSR
value can address the ent ire range o f the da ta memo ry
in a linear fashion. The FSR register pairs, then, serve
as pointers to data memory locations.

Indirect addressing is accomplished with a set of
Indirect File Operands, INDF0 through INDF2. These
can be thought of as “virtual” registers: they are
mapped in the SFR space but are not physically
implemented. Reading or writing to a particular INDF
register actually accesses its corresponding FSR
register pair. A read from INDF1, for example, reads
the data at the address indicated by FSR1H:FSR1L.
Instructions that use the INDF registers as operands
actually use the co ntents of their corresponding FSR a s
a pointer to the instruction’s target. The INDF operand
is just a convenient way of using the pointer.

Because indirec t addre ssing us es a full 1 2-bit a ddress ,
data RAM banking is not necessary. Thus, the current
contents of the BSR and the Access RAM bit have no
effect on determining the target address.

5.4.3.2 FSR Regi s ters and PO STINC,
POSTDEC, PREINC and PLUSW

In addition to the IND F operand, eac h FSR register pair
also has four additional indirect operands. Like INDF,
these are “virtual” registers which cannot be directly
read or written. Accessing these registers actually
accesses the location to which the associated FSR
register pair po in t s, and also performs a spe ci fic ac tio n
on the FSR value. They are:

• POSTDEC: accesses the location to which the

FSR points, then automatic al ly dec rem en t s the
FSR by 1 afterwards

• POSTINC: accesses the locati on to which the

FSR points, then automatic al ly inc rem en ts the
FSR by 1 afterwards

• PREINC: automatically inc r ements the FSR by 1,

then uses the location to which the FSR points in
the operation

• PLUSW: adds the signed value of the W register

(range of -127 to 128) t o that of th e FSR and uses
the location to which the result points in the
operation.

In this context, accessing an INDF register uses the
value in the associated FSR register without changing
it. Similarly, accessing a PLUSW register gives the
FSR value an offs et by tha t in the W register; however,
neither W nor the FSR is actually changed in the
operation. Accessing the other virtual registers
changes the value of the FSR register.

FIGURE 5-10: INDIRECT ADDRESSING

DS40001303H-page 80  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

Operations on the FSRs with POSTDEC, POSTINC
and PREINC affect the entire register pair; that is, roll­overs of the FSRnL register from FFh to 00h carry over
to the FSRnH register. On the other hand, results of
these operations do not change the value of any flags
in the STATUS register (e.g., Z, N, OV, etc.).

The PLUSW register can be used to implement a form
of indexed addressing in t he data memory space. By
manipulating the value in the W register, users can
reach addresses that are fixed offsets from pointer
addresses. In some applications, this can be used to
implement some powerful program control structure,
such as software stacks, inside of data memory.

5.4.3.3 Operations by FSRs on FSRs

Indirect addressing operations that target other FSRs
or virtual registers represent special cases. For
example, using an FSR to point to one of the virtual
registers will not result in successful operations. As a
specific case, assume that FSR0H:FSR0L contains
FE7h, the address of INDF1. Attempts to read the
value of the INDF1 using INDF0 as an operand will
return 00h. Attempts to write to INDF1 using INDF0 as
the operand will result in a NOP.

On the other ha nd, u sing the v irtual reg isters to w rite to
an FSR pair may n ot oc cur as plan ned. I n t hese cases ,
the value will be written to the FSR p air bu t withou t an y
incrementing or decrementing. Thus, writing to either
the INDF2 or POSTDEC2 register will write the same
value to the FSR2H:FSR2L.

Since the FSRs are physical registers mapped in the
SFR space, they can be manipulated through all direct
operations. Users should proceed cautiously when
working on these registers, particularly if their code
uses indirect addressing.

Similarly, operations by indirect addressing are generally
permitted on all othe r SFRs. Us ers shoul d exercise the
appropriate ca ution that they do not inad vertently c hange
settings tha t m i ght a ffect the opera ti on o f th e de vi c e.

5.5 Data Memory and the Extended Instruction Set

Enabling the PIC18 extended instruction set (XINST
Configuration bit = 1) significantly changes certain
aspects of data memory and its addressing. Specifi­cally, the use of the Access Bank for many of the core
PIC18 instructions is different; this is due to the intro­duction of a n ew add ressing mode fo r the dat a me mory
space.

What does not change is just as im po rtant. The size of
the data memory space is unchanged, as well as its
linear addressing. The SFR map remains the same.
Core PIC18 instructions can still operate in both Direct
and Indirect Addressing mode; inherent and literal
instructions do not change at all. Indirect addressing
with FSR0 and FSR1 also remain unchanged.

5.5.1 INDEXED ADDRESSING WITH LITERAL OFFSET

Enabling the PIC18 extended instruction set changes
the behavior of indirect addressing using the FSR2
register pair within Access RAM. Under the proper
conditions, instruc tions that us e the Access Ban k – that
is, most bit-oriented and byte-oriented instructions –
can invoke a form of indexed addressing using an
offset specified in the instruction. This special
addressing mode i s known as Inde xed Ad dressing w ith
Literal Offset, or Indexed Literal Offset mode.

When using the extended instruction set, this
addressing mode requires the following:

• The use of the Access Ban k i s forced (‘a’ = 0) and

• The file address arg um ent is less than or equal to

5Fh.

Under these conditions, the file address of the
instruction is not interpreted as the lower byte of an
address (used with the BSR in direc t addressing), or a s
an 8-bit address in t he Acces s Bank. In stead, the value
is interpreted as an offset value to an Address Pointer,
specified by FSR2. The offset and the contents of
FSR2 are added to obtain the target address of the
operation.

5.5.2 INSTRUCTIONS AFFECTED BY INDEXED LITERAL OFFSET MODE

Any of the core PIC18 instructions that can use direct
addressing are potentially affected by the Indexed
Literal Offset Addressing mode. This includes all
byte-oriented and bit-oriented instructions, or almost
one-half of the standard PIC18 instruction set.
Instructions that onl y use Inherent or Literal Addr essing
modes are unaffecte d.

Additionally, byte-oriented and bit-oriented instructions
are not affected if they do not use the Access Bank
(Access RAM bit is ‘1’), or include a fi le address of 60h
or above. Instructions meeting these criteria will
continue to execute as before. A comparison of the
different possible addressing modes when the
extended instruction set is enabled is shown in

Figure 5-11.

Those who desire to use byte-oriented or bit-oriented
instructions in the Indexed Literal Offset mode should
note the changes to assembler syntax for this mode.
This is described in more detail in Section 24.2.1

“Extended Instruction Syntax”.

 2010-2015 Microchip Technology Inc. DS40001303H-page 81

PIC18F2XK20/4XK20

EXAMPLE INSTRUCTION: ADDWF, f, d, a (Opcode: 0010 01da ffff ffff)

When ‘a’ = 0 and f  60h:

The instruction executes in
Direct Forced mode. ‘f’ is inter­preted as a location in the
Access RAM between 060h
and 0FFh. This is the sam e as
locations F60h to FFFh
(Bank 15) of data memory.

Locations below 60h are not
available in this addressing
mode.

When ‘a’ = 0 and f5Fh:

The instruction executes in
Indexed Literal Offset mode. ‘f’
is interpreted as an offset to the
address value in FSR2. The
two are added together to
obtain the address of the target
register for the instruction. The
address can be anywhere in
the data memory space.

Note that in this mode, the
correct syntax is now:

ADDWF [k], d

where ‘k’ is the same as ‘f ’.

When ‘a’ = 1 (all values of f):

The instruction executes in
Direct mode (also known as
Direct Long mode). ‘f’ is inter­preted as a location in one of
the 16 banks of the data
memory space. The bank is
designated by the Bank Sel ect
Register (BSR). The address
can be in any implemented
bank in the data memory
space.

000h
060h

100h

F00h

F60h

FFFh

Valid range

00h
60h

FFh

Data Memory

Access RAM

Bank 0

Bank 1

through

Bank 14

Bank 15

SFRs

000h

060h

100h

F00h

F60h

FFFh

Data Memory

Bank 0

Bank 1

through

Bank 14

Bank 15

SFRs

FSR2H FSR2L

ffffffff001001da

ffffffff001001da

000h

060h

100h

F00h

F60h

FFFh

Data Memory

Bank 0

Bank 1

through

Bank 14

Bank 15

SFRs

for ‘f’

BSR

00000000

FIGURE 5-11: COMPARING ADDRESSING OPTIONS FOR BIT-ORIENTED AND

BYTE-ORIENTED INSTRUCTIONS (EXTENDED INSTRUCTION SET ENABLED)

DS40001303H-page 82  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

Data Memory

000h

100h

200h

F60h

F00h

FFFh

Bank 1

Bank 15

Bank 2

through

Bank 14

SFRs

ADDWF f, d, a

FSR2H:FSR2L = 120h

Locations in the region
from the FSR2 pointer
(120h) to the pointer plus
05Fh (17Fh) are mapped
to the bottom of the
Access RAM (000h-05Fh).

Special File Registers at
F60h through FFFh are
mapped to 60h through
FFh, as usual.

Bank 0 addresses below
5Fh can still be addressed
by using the BSR.

Access Bank

00h

60h

FFh

SFRs

Bank 1 “Window”

Bank 0

Window

Example Situation:

120h
17Fh

5Fh

Bank 1

5.5.3 MAPPING THE ACCESS BANK IN INDEXED LITERAL OFFSET MODE

The use of Indexed Literal Offset Addressing mode
effectively chan ges how the first 96 locati ons of Access
RAM (00h to 5Fh) are m ap ped . R at her tha n c on taining
just the contents of the bottom section of Bank 0, this
mode maps the conte nts from a user defined “wind ow”
that can be located anywhere in the data memory
space. The value o f FSR2 establish es the lower bound­ary of the addresses ma pped into the window , while the
upper boundary is defined by FSR2 plus 95 (5Fh).
Addresses in the Acces s RAM above 5Fh are mapped

Remapping of the Access Bank applies only to
operations using the Indexed Literal Offset mode.
Operations that use the BSR (Access RAM bit is ‘1’) will
continue to use direct addressing as before.

5.6 PIC18 Instruction Execution and the Extended Instruction Set

Enabling the extended instruction set adds eight
additional commands to the existing PIC18 instruction
set. These instructions are executed as described in

Section 24.2 “Extended Instruction Set”.

as previously described (see Section 5.3.2 “Access

Bank”). An example of Access Bank remappin g in this

addressing mode is shown in Figure 5-12.

FIGURE 5-12: REMAPPING THE ACCESS BANK WITH INDEXED LITERAL OFFSET

ADDRESSING

 2010-2015 Microchip Technology Inc. DS40001303H-page 83

PIC18F2XK20/4XK20

Table Pointer

(1)

Table Latch (8-bit)

Program Memory

TBLPTRH TBLPTRL

TABLAT

TBLPTRU

Instruction: TBLRD*

Note 1: Table Pointer register points to a byte in program memory.

Program Memory
(TBLPTR)

6.0 FLASH PROGRAM MEMORY

The Flash program memory is readable, writable and
erasable during normal operation over the entire V
range.

A read from program memory is executed one byte at
a time. A write to program memory is executed on
blocks of 64, 32 or 16 byt es at a time, depend ing on the
specific device (See Table 6-1). Program memory is
erased in blocks of 64 bytes at a time. The difference
between the write and erase block sizes requires from
1 to 4 block writes to restore the contents of a single
block erase. A bulk erase operation cannot be issued
from user code.

TABLE 6-1: WRITE/ERASE BLOCK SIZES

Device

PIC18F43K20,
PIC18F23K20

PIC18F24K20,
PIC18F25K20,
PIC18F44K20,
PIC18F45K20

PIC18F26K20,
PIC18F46K20

Writing or erasing program memory will cease
instruction fetches until the operation is complete. The
program memory cannot be accessed during the write
or erase, therefore, code cannot execute. An internal
programming timer terminates program memory writes
and erases.

Write Block

Size (bytes)

16 64

32 64

64 64

Erase Block

Size (by tes)

DD

A value written to progra m memory does not n eed to be
a valid instruction. Executing a program memory
location that forms an invalid instruction results in a
NOP.

6.1 Table Reads and Table Writes

In order to read and write program memory, there are
two operations that allow the processor to move bytes
between the program memory sp ace and the dat a RAM:

• Table Read (TBLRD)

• Table Write (TBLWT)
The program memory space is 16 bits wide, while the

data RAM space is eight bits wide. Table reads and
table writes move data between these two memory
spaces through an 8-bit register (TABLAT).

The table read operation retrieves one byte of data
directly from program memory and places it into the
TABLAT register. Figure 6-1 shows the operation of a
table read.

The table write operation stores one byte of data from the
TABLAT register into a write block holding register. The
procedure to write the contents of the holding registers
into program memory is detailed in Section 6.5 “Writing

to Flash Program Memory”. Figure 6-2 shows the

operation of a table write with program memory and data
RAM.

Table operations work with byte entities. Tables
containing data, rather than program instructions, are
not required to be word aligned. Therefore, a table can
start and end at any byte address. If a t able write is being
used to write executable code into program memory,
program instructions will need to be word aligned.

FIGURE 6-1: TABLE READ OPERATION

DS40001303H-page 84  2010-2015 Microchip Technology Inc.

FIGURE 6-2: TABLE WRITE OPERATION

Table Pointer

(1)

Table Latch (8-bit)

TBLPTRH TBLPTRL

TABLAT

Program Memory

(TBLPTR<MSBs>)

TBLPTRU

Instruction: TBLWT*

Note 1: During table writes the Table Pointer does not point directly to Program Memory. The LSBs of TBLPRTL

actually point to an address within the write block holding registers. The MSBs of the T able Pointer deter­mine where the write block will eventually be written. The process for writing the holding registers to the
program memory array is discussed in Section 6.5 “Writing to Flash Program Memory”.

Holding Registers

Program Memory

PIC18F2XK20/4XK20

6.2 Control Registers

Several control registers are used in conjunction with
the TBLRD and TBLWT instructions. These include the:

• EECON1 register

• EECON2 register

• TABLAT register

• TBLPTR registers

6.2.1 EECON1 AND EECON2 REGISTERS

The EECON1 register (Register 6-1) is the control
register for memory acce sses. The EECO N2 register is
not a physical register; it is used exclusively in the
memory write and erase sequences. Reading
EECON2 will read all ‘0’s.

The EEPGD control bit determines if th e access will be
a program or data EEPROM memory access. When
EEPGD is clear, any subsequent operations will
operate on the data EEPROM memory. When EEPGD
is set, any subsequent operations will operate on the
program memory.

The CFGS control bit determines if the access will be
to the Configuration/C alib ration re giste rs or to pro gram
memory/data EEPROM memory. When CFGS is set,
subsequent operations will operate on Configuration
registers regardless of EEPGD (see Section 23.0

“Special Features of the CPU” ). When CFGS is clea r,

memory selection access is determined by EEPGD.

The FREE bit allows the program memory erase
operation. When FREE is set, an erase operation is
initiated on the next WR command. When FREE is
clear, only writes are enabled.

The WREN bit, when set, will allow a write operation.
The WREN bit is clear on power-up.

The WRERR bit is set by hardware w he n the WR bit i s
set and cleared when the internal programming timer
expires and the write operation is complete.

Note: During normal operation, the WRERR is

The WR control bit initiates write operations. The WR
bit cannot be cleared, only set, by firmware. Then WR
bit is cleared b y hardware at the co mpletion of the write
operation.

Note: The EEIF interrupt flag bit of the PIR2

read as ‘1’. This can indicate that a write
operation was prematurely terminated by
a Reset, or a write operation was
attempted improperly.

register is set when the write is complete.
The EEIF flag stays set until cleared by
firmware.

 2010-2015 Microchip Technology Inc. DS40001303H-page 85

PIC18F2XK20/4XK20

REGISTER 6-1: EECON1: DATA EEPROM CONTROL 1 REGISTER

R/W-x R/W-x U-0 R/W-0 R/W-x R/W-0 R/S-0 R/S-0

EEPGD CFGS — FREE WRERR WREN WR RD

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit
S = Bit can be set by software, but not cleared U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 EEPGD: Flash Program or Data EEPROM Memory Select bit

1 = Access Flash program memory
0 = Access data EEPROM memory

bit 6 CFGS: Flash Program/Data EEPROM or Configuration Select bit

1 = Access Configuration register s
0 = Access Flash program or data EEPROM memory

bit 5 Unimplemented: Read as ‘0’
bit 4 FREE: Flash Row (Block) Erase Enable bit

1 = Erase the program memory block addressed by TBLPTR on the next WR command

(cleared by completion of erase operation)

0 = Perform write-only

bit 3 WRERR: Flash Program/Data EEPROM Error Flag bit

1 = A write operation is prematurely terminated (an y R ese t duri ng se lf-t im ed pro gram m ing in norm al

operation, or an improper write attempt)

0 = The write operation completed

(1)

bit 2 WREN: Flash Program/Data EEPROM Write Enable bit

1 = Allows write cycles to Flash program/data EEPROM
0 = Inhibits write cycles to Flash program/data EEPROM

bit 1 WR: Write Control bit

1 = Initiates a data EEPROM erase/write cycle or a program memory erase cycle or write cycle.

(The operation is self-timed and the bit is cleared by hardware once write is complete.
The WR bit can only be set (not cleared) by software.)

0 = Write cycle to the EEPROM is complete

bit 0 RD: Read Control bit

1 = Initiates an EEPROM read (Read takes one cycle. RD is cleared by hardware. The RD bit can only

be set (not cleared) by software. RD bit cannot be set when EEPGD = 1 or CFGS = 1.)

0 = Does not initiate an EEPROM read

Note 1: When a WRERR occurs, the EEPGD and CFGS bits are not cleared. This allows tracing of the

error condition.

DS40001303H-page 86  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

21 16 15 87 0

TABLE ERASE/WRITE

TABLE WRITE

TABLE READ – TBLPTR<21:0>

TBLPTRLTBLPTRH

TBLPTRU

TBLPTR<n:0>

(1)

TBLPTR<21:n+1>

(1)

Note 1: n = 3, 4, 5, or 6 for block sizes of 8, 16, 32 or 64 bytes, respectively.

6.2.2 TABLAT – TABLE LATCH REGISTER

The Table Latch (TABLAT) is an 8-bit register mapped
into the SFR space. The Table Latch register is used to
hold 8-bit data during data transfers between program
memory and data RAM.

6.2.3 TBLPTR – TABLE POINTER REGISTER

The Table Pointer (TBLPTR) register addresses a byte
within the program memory. The TBLPTR is comprised
of three SFR registers : Table Pointer Upper Byte, Table
Pointer High Byte and Table Pointer Low Byte
(TBLPTRU:TBLPTRH:TBLPTRL). These three regis­ters join to form a 22-bit wide po inter. The low-o rder
21 bits allow the device to address up to 2 Mbytes of
program memory sp ace. Th e 22nd b it allow s acce ss to
the device ID, the user ID and the Configuration bits.

The Table Pointer register, TBLPTR, is used by the
TBLRD and TBLWT instructi ons . T hes e i ns truc tio ns ca n
update the TBLPTR in one of four ways based on the
table operation. These operations are shown in

Table 6-2. These operations on the TBLPTR affect only

the low-order 21 bits.

6.2.4 TABLE POINTER BOUNDARIES

TBLPTR is used in reads, writes and erases of the
Flash program memory.

When a TBLRD is executed, al l 22 bits of th e T BLPT R
determine which byte is read from program memory
directly into the TABLAT register .

When a TBLWT is executed the byte in the TABLAT
register is written, not to Flas h memory but, to a holdin g
register in prepar ation for a program m emory write. The
holding registers constitute a write block which varies
depending on the dev ice (See Table 6-1).The 3, 4, or 5
LSbs of the TBLPTRL register determine which specific
address within the holding register block is written to.
The MSBs of t he Table Pointe r have no effec t during
TBLWT operations.

When a program memory write is executed the entire
holding register blo ck i s wri tten to the Flash me mo ry at
the address determined by the MSbs of the TBLPTR.
The 3, 4, or 5 LSBs are ignored during Flash memory
writes. For more detail, see Section 6.5 “Writing to

Flash Program Memory”.

When an erase of program memory is executed, the
16 MSbs of the Table Pointer register (TBLPTR<21:6>)
point to the 64-byte block that will be erased . The Least
Significant bits (TBLPTR<5:0>) are ignored.

Figure 6-3 describes the relevant boundaries of

TBLPTR based on Flash program memory operations.

TABLE 6-2: TABLE POINTER OPERATIONS WITH TBLRD AND TBLWT INSTRUCTIONS

Example Operation on Table Pointer

TBLRD*
TBLWT*

TBLRD*+
TBLWT*+

TBLRD*­TBLWT*-

TBLRD+*
TBLWT+*

TBLPTR is incremented after the read/write

TBLPTR is decremented after the read/write

TBLPTR is incremented before the read/write

TBLPTR is not modified

FIGURE 6-3: TABLE POINTER BOUNDARIES BASED ON OPERATION

 2010-2015 Microchip Technology Inc. DS40001303H-page 87

PIC18F2XK20/4XK20

(Even Byte Address)

Program Memory

(Odd Byte Address)

TBLRD

TABLAT

TBLPTR = xxx xx1

FETCH

Instruction Register

(IR)

Read Register

TBLPTR = xxxxx0

MOVLW CODE_ADDR_UPPER ; Load TBLPTR with the base
MOVWF TBLPTRU ; address of the word
MOVLW CODE_ADDR_HIGH
MOVWF TBLPTRH
MOVLW CODE_ADDR_LOW
MOVWF TBLPTRL

READ_WORD

TBLRD*+ ; read into TABLAT and increment
MOVF TABLAT, W ; get data
MOVWF WORD_EVEN
TBLRD*+ ; read into TABLAT and increment
MOVFW TABLAT, W ; get data
MOVF WORD_ODD

6.3 Reading the Flash Program Memory

The TBLRD instruction retrieves data from program
memory and places it in to da t a RA M . Table reads from

The internal program memory is typically organize d by
words. The Least Sig nificant b it of th e address selects
between the high and low bytes of the word. Figure 6-4
shows the interface between the internal program
memory and the TABLA T.

program memory are performed one byte at a time.
TBLPTR points to a byte address in program space.

Executing TBLRD places the byte pointed to into
TABLAT. In addition, TBLPTR can be modified
automatically for the next table read operation.

FIGURE 6-4: READS FROM FLASH PROGRAM MEMORY

EXAMPLE 6-1: READING A FLASH PROGRAM MEMORY WORD

DS40001303H-page 88  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

MOVLW CODE_ADDR_UPPER ; load TBLPTR with the base
MOVWF TBLPTRU ; address of the memory block
MOVLW CODE_ADDR_HIGH
MOVWF TBLPTRH
MOVLW CODE_ADDR_LOW
MOVWF TBLPTRL

ERASE_BLOCK

BSF EECON1, EEPGD ; point to Flash program memory
BCF EECON1, CFGS ; access Flash program memory
BSF EECON1, WREN ; enable write to memory
BSF EECON1, FREE ; enable block Erase operation
BCF INTCON, GIE ; disable interrupts

Required MOVLW 55h
Sequence MOVWF EECON2 ; write 55h

MOVLW 0AAh
MOVWF EECON2 ; write 0AAh
BSF EECON1, WR ; start erase (CPU stall)
BSF INTCON, GIE ; re-enable interrupts

6.4 Erasing Flash Program Memory

The minimum eras e block is 32 wo rds or 64 b ytes. Only
through the use of an external programmer, or through
ICSP™ control, can larger blocks of program memory
be bulk erased. Word erase in the Flash array is not
supported.

When initiating an erase sequence from the
Microcontroller itself, a block of 64 bytes of program
memory is erased. The Most Significant 16 bits of the
TBLPTR<21:6> point to the block being erased. The
TBLPTR<5:0> bits are ignored.

The EECON1 register comma nds the erase operation.
The EEPGD bit must be set to point to the Flash pro­gram memory. The WREN bit must be set to enable
write operations. The F REE bit is set to select an erase
operation.

The write initiate sequence for EECON2, shown as
steps 4 through 6 in Section 6.4.1 “Flash Program

Memory Erase Sequence”, is used to guard against

accidental writes. This is sometimes referred to as a
long write.

A long write is nec essa ry for erasin g the i nternal Flash.
Instruction execution is halted during the long write
cycle. The long write is terminated by the internal
programming timer.

6.4.1 FLASH PROGRAM MEMORY ERASE SEQUENCE

The sequence of events for erasing a block of internal
program memory is:

1. Load Table Pointer register with address of

block being erased.

2. Set the EECON1 register for the erase operation:

• set EEPGD bit to point to program memory;

• clear the CFGS bit to access program memory;

• set WREN bit to enable writes;

• set FREE bit to enable the erase.

3. Disab le int errupts.

4. Write 55h to EECON2.

5. Write 0AAh to EECON2.

6. Set the WR bit. This will begin the block erase

cycle.

7. The CPU will stall for duration of the erase

(about 2 ms using internal timer).

8. Re-enable interrupts.

EXAMPLE 6-2: ERASING A FLASH PROGRAM MEMORY BLOCK

 2010-2015 Microchip Technology Inc. DS40001303H-page 89

PIC18F2XK20/4XK20

TABLAT

TBLPTR = xxxx YY

(1)

TBLPTR = xxxx01TBLPTR = xxxx00

Write Register

TBLPTR = xxxx0 2

Program Memory

Holding Register Holding Register Holding Register Holding Register

8

8 8 8

Note 1: YY = x7, xF, or 1F for 8, 16 or 32 byte write blocks, respectively.

6.5 Writing to Flash Program Memory

The programming block size is 16, 32 or 64 bytes,
depending on th e dev ice (Se e Table 6-1). Word or byte
programming is not suppo rted.

Table writes are used internally to load the holding
registers needed to program the Flash memory. There
are only as many holding registers as there are bytes
in a write block (See Table 6-1).

Since the Table Latch (TABLAT) is only a single byte,
the TBLWT instruction may need to be executed 16, 32
or 64 times, depending on the device, for each pro­gramming operation. All of the table write operations
will essentially be short wri tes because only the hol ding
registers are writt en. After all t he holding regi sters have
been written, the programming operation of that block
of memory is st arted by config uring the EECON1 regi s­ter for a program memory write and perf orming the long
write sequence.

The long write is necessary for programming the
internal Flash. Instruc tion ex ecution is ha lted dur ing a
long write cycle. The long write will be terminated by
the internal programming timer.

The EEPROM on-chip timer controls the write time.
The write/erase voltages are generated by an on-chip
charge pump, rated to operate over the voltage range
of the device.

Note: The default value of the holding re gisters on

device Resets an d afte r wr ite op e rat io ns is
FFh. A write of FFh to a holding register
does not modify that byte. This means that
individual bytes of program memory may
be modified, provid ed tha t the c hange d oes
not attempt to chang e any bi t from a ‘0’ to a
‘1’. When modifying individual bytes, it is
not necessar y to load all holding re gisters
before executing a lon g writ e opera tion.

FIGURE 6-5: TABLE WRITES TO FLASH PROGRAM MEMORY

6.5.1 FLASH PROGRAM MEMORY WRITE SEQUENCE

The sequence of events for programming an internal
program memory location should be:

1. Read 64 bytes into RAM.

2. Update data values in RAM as necessary.

3. Load Table Pointer register with address being

erased.

4. Execute the block erase procedure.

5. Load Table Pointer register with address of first

byte being written.

6. W rite the 1 6, 32 or 64 byte blo ck into the holdin g

registers with auto-increment.

7. Set the EEC ON1 register for th e write operatio n:

DS40001303H-page 90  2010-2015 Microchip Technology Inc.

• set EEPGD bit to point to program memory;

• clear the CFGS bit to access program memory;

• set WREN to enable byte writes.

8. Disab le int errupts.

9. Write 55h to EECON2.

10. Write 0AAh to EECON2.
1 1. Set the WR bit. This will begin the w rite cy cl e.

12. The C PU will stall for dura tion of t he write (about
2 ms using internal timer).

13. Re-enable interrupts.

14. Repeat steps 6 to 13 for each block until all 64
bytes are written.

15. Verify the memory (table read).

This procedure will require about 6ms to update each
write block of memory. An example of the required code
is given in Example 6-3.

Note: Before setting the WR bit, the Table

Pointer address needs to be within the
intended address ra nge of the bytes i n the
holding registers.

EXAMPLE 6-3: WRITING TO FLASH PROGRAM MEMORY

MOVLW D'64’ ; number of bytes in erase block
MOVWF COUNTER
MOVLW BUFFER_ADDR_HIGH ; point to buffer
MOVWF FSR0H
MOVLW BUFFER_ADDR_LOW
MOVWF FSR0L
MOVLW CODE_ADDR_UPPER ; Load TBLPTR with the base
MOVWF TBLPTRU ; address of the memory block
MOVLW CODE_ADDR_HIGH
MOVWF TBLPTRH
MOVLW CODE_ADDR_LOW
MOVWF TBLPTRL

READ_BLOCK

TBLRD*+ ; read into TABLAT, and inc
MOVF TABLAT, W ; get data
MOVWF POSTINC0 ; store data
DECFSZ COUNTER ; done?
BRA READ_BLOCK ; repeat

MODIFY_WORD

MOVLW BUFFER_ADDR_HIGH ; point to buffer
MOVWF FSR0H
MOVLW BUFFER_ADDR_LOW
MOVWF FSR0L
MOVLW NEW_DATA_LOW ; update buffer word
MOVWF POSTINC0
MOVLW NEW_DATA_HIGH
MOVWF INDF0

ERASE_BLOCK

MOVLW CODE_ADDR_UPPER ; load TBLPTR with the base
MOVWF TBLPTRU ; address of the memory block
MOVLW CODE_ADDR_HIGH
MOVWF TBLPTRH
MOVLW CODE_ADDR_LOW
MOVWF TBLPTRL
BSF EECON1, EEPGD ; point to Flash program memory
BCF EECON1, CFGS ; access Flash program memory
BSF EECON1, WREN ; enable write to memory
BSF EECON1, FREE ; enable Erase operation
BCF INTCON, GIE ; disable interrupts
MOVLW 55h

Required MOVWF EECON2 ; write 55h
Sequence MOVLW 0AAh

MOVWF EECON2 ; write 0AAh
BSF EECON1, WR ; start erase (CPU stall)
BSF INTCON, GIE ; re-enable interrupts
TBLRD*- ; dummy read decrement
MOVLW BUFFER_ADDR_HIGH ; point to buffer
MOVWF FSR0H
MOVLW BUFFER_ADDR_LOW
MOVWF FSR0L

WRITE_BUFFER_BACK

MOVLW BlockSize ; number of bytes in holding register
MOVWF COUNTER
MOVLW D’64’/BlockSize ; number of write blocks in 64 bytes
MOVWF COUNTER2

WRITE_BYTE_TO_HREGS

MOVF POSTINC0, W ; get low byte of buffer data
MOVWF TABLAT ; present data to table latch
TBLWT+* ; write data, perform a short write

; to internal TBLWT holding register.

 2010-2015 Microchip Technology Inc. DS40001303H-page 91

PIC18F2XK20/4XK20

PIC18F2XK20/4XK20

DECFSZ COUNTER ; loop until holding registers are full
BRA WRITE_WORD_TO_HREGS

PROGRAM_MEMORY

BSF EECON1, EEPGD ; point to Flash program memory
BCF EECON1, CFGS ; access Flash program memory
BSF EECON1, WREN ; enable write to memory
BCF INTCON, GIE ; disable interrupts
MOVLW 55h

Required MOVWF EECON2 ; write 55h
Sequence MOVLW 0AAh

MOVWF EECON2 ; write 0AAh
BSF EECON1, WR ; start program (CPU stall)
DCFSZ COUNTER2 ; repeat for remaining write blocks
BRA WRITE_BYTE_TO_HREGS ;
BSF INTCON, GIE ; re-enable interrupts
BCF EECON1, WREN ; disable write to memory

EXAMPLE 6-3: WRITING TO FLASH PROGRAM MEMORY (CONTINUED)

6.5.2 WRITE VERIFY

Depending on the application, good programming
practice may dictate that the value written to the
memory should be verified against the original value.
This should be used in applications where excessive
writes can stress bits near the specification limit.

6.5.3 UNEXPECTED TERMINATION OF WRITE OPERATION

If a write is termin ate d b y a n u np lanned event, such as
loss of power or an unexpected Reset, the memory
location just programmed should be verified and
reprogrammed if needed. If the write operation is
interrupted by a MCL R Reset or a WDT Time-out Reset
during normal operation, the WRERR bit will be set
which the us er can c heck to decide whether a rewrit e
of the location(s) is needed.

TABLE 6-3: REGISTERS ASSOCIATED WITH PROGRAM FLASH MEMORY

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TBLPTRU — — bit 21 Program Memory T able Pointer Upper Byte (TBLPTR<20:16>) 56
TBPLTRH Program Memory Table Pointer High Byte (TBLPTR<15:8>) 56
TBLPTRL Program Memory Table Pointer Low Byte (TBLPTR<7:0>) 56
TABLAT Program Memory Table Latch 56
INTCON GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 56
EECON2 EEPROM Control Register 2 (not a physical register) 58
EECON1 EEPGD CFGS
IPR2
PIR2
PIE2 OSCFIE C1IE C2IE EEIE BCLIE HLVDIE TMR3IE CCP2IE 59
Legend: — = unimplemented, read as ‘0’. Shaded cells are not used during Flash/EEPROM access.

DS40001303H-page 92  2010-2015 Microchip Technology Inc.

OSCFIP C1IP C2IP EEIP BCLIP HLVDIP TMR3IP CCP2IP 59
OSCFIF C1IF C2IF EEIF BCLIF HLVDIF TMR3IF CCP2IF 59

— FREE WRERR WREN WR RD 58

6.5.4 PROTECTION AGAINST SPURIOUS WRITES

To protect against spurious writes to Flash program
memory, the write initiate sequence must also be
followed. See Section 23.0 “Special Features of the

CPU” for more detail.

6.6 Flash Program Operation During

Code Protection

See Section 23.3 “Program Verification and Code

Protection” for details on code protection of Flash

program memory.

Reset

Values on

page

PIC18F2XK20/4XK20

7.0 DATA EEPROM MEMORY

The data EEPROM is a nonvolatil e memory array, sep­arate from the data RAM and program memory, which
is used for long-term storage of program data. It is not
directly mapped in either the register file or program
memory space but is indirectly addressed through the
Special Function Registers (SFRs). The EEPROM is
readable and writab le during no rmal operati on over the
entire V

Four SFRs are used to read and write to the data
EEPROM as well as the program memory. They are:

• EECON1

• EECON2

• EEDA TA

• EEADR

• EEADRH
The data EEPROM allows byte read and write. When

interfaci ng to the data mem ory block, EEDATA holds
the 8-bit data for read/write and the EEADR:EEADRH
register pair hold the address of the EEPROM location
being accessed.

The EEPROM data memory is rated for high erase/write
cycle endurance. A byte write automatically erases the
location and writes the new data (erase-before-write).
The write time is controlled by an on-chip timer; it will
vary with voltage and temperature as well as from chip­to-chip. Please refer to parameter D122 (Table 26-10 in

Section 26.0 “Electrical Specifications”) for exact

limits.

DD range.

The EECON1 register (Register 7-1) is the control reg-
ister for data and program memory access. Control bit
EEPGD determines if the access will be to program or
data EEPROM memory. When the EEPGD bit is clear,
operations will access the data EEPROM memory.
When the EEPGD bit is set, program memory is
accessed.

Control bit, CFGS, determines if the access will be to
the Configuration reg ist ers or to pro gram m em ory/data
EEPROM memory. When the CFGS bit is set,
subsequent operations acce ss Confi gur ation reg isters .
When the CFGS bit is clear, the EEPGD bit selects
either program Flash or data EEPROM memory.

The WREN bit, when set, will allow a write operation.
On power-up, the WREN bit is clear.

The WRERR bit is set by hardware w he n the WR bit i s
set and cleared when the internal programming timer
expires and the write operation is complete.

Note: During normal operation, the WRERR

may read as ‘1’. This can indicate that a
write operation was prematurely termi­nated by a Reset, or a write operation was
attempted improperly.

The WR control bit initiates write operations. The bit
can be set but no t cleared b y software . It is cle ared only
by hardware at the completion of the wri te operation.

Note: The EEIF interrupt flag bit of the PIR2

register is set when the write is complete.
It must be cleared by software.

7.1 EEADR and EEADRH Registers

The EEADR register is used to address the data
EEPROM for read and write operations. The 8-bit
range of the register can address a memory range of
256 bytes (00h to FFh). The EEADRH register e xpands
the range to 1024 bytes by adding an additional two
address bits.

7.2 EECON1 and EECON2 Registers

Access to the data EEPROM is controlled by two
registers: EECON1 and EECO N2. These are the same
registers which control access to the program memory
and are used in a similar manner for the data
EEPROM.

Control bits, RD and WR, start read and erase/write
operations, respec tively . These bits a re set by firmwa re
and cleared by hardware at the completion of the
operation.

The RD bit cannot be set when accessing program
memory (EEPGD = 1). Program memory is read using
table read instructions. See Section 6.1 “Tabl e Reads

and Table Writes” regarding table reads.

The EECON2 register is not a physical register. It is
used exclusively in the memory write and erase
sequences. Reading EECON2 will read all ‘0’s.

 2010-2015 Microchip Technology Inc. DS40001303H-page 93

PIC18F2XK20/4XK20

REGISTER 7-1: EECON1: DATA EEPROM CONTROL 1 REGISTER

R/W-x R/W-x U-0 R/W-0 R/W-x R/W-0 R/S-0 R/S-0

EEPGD CFGS — FREE WRERR WREN WR RD

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit
S = Bit can be set by software, but not cleared U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 EEPGD: Flash Program or Data EEPROM Memory Select bit

1 = Access Flash program memory
0 = Access data EEPROM memory

bit 6 CFGS: Flash Program/Data EEPROM or Configuration Select bit

1 = Access Configuration register s
0 = Access Flash program or data EEPROM memory

bit 5 Unimplemented: Read as ‘0’
bit 4 FREE: Flash Row (Block) Erase Enable bit

1 = Erase the program memory block addressed by TBLPTR on the next WR command

(cleared by completion of erase operation)

0 = Perform write-only

bit 3 WRERR: Flash Program/Data EEPROM Error Flag bit

1 = A write operation is prematurely terminated (an y R ese t duri ng se lf-t im ed pro gram m ing in norm al

operation, or an improper write attempt)

0 = The write operation completed

(1)

bit 2 WREN: Flash Program/Data EEPROM Write Enable bit

1 = Allows write cycles to Flash program/data EEPROM
0 = Inhibits write cycles to Flash program/data EEPROM

bit 1 WR: Write Control bit

1 = Initiates a data EEPROM erase/write cycle or a program memory erase cycle or write cycle.

(The operation is self-timed and the bit is cleared by hardware once write is complete.
The WR bit can only be set (not cleared) by software.)

0 = Write cycle to the EEPROM is complete

bit 0 RD: Read Control bit

1 = Initiates an EEPROM read (Read takes one cycle. RD is cleared by hardware. The RD bit can only

be set (not cleared) by software. RD bit cannot be set when EEPGD = 1 or CFGS = 1.)

0 = Does not initiate an EEPROM read

Note 1: When a WRERR occurs, the EEPGD and CFGS bits are not cleared. This allows tracing of the

error condition.

DS40001303H-page 94  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

MOVLW DATA_EE_ADDR ;
MOVWF EEADR ; Data Memory Address to read
BCF EECON1, EEPGD ; Point to DATA memory
BCF EECON1, CFGS ; Access EEPROM
BSF EECON1, RD ; EEPROM Read
MOVF EEDATA, W ; W = EEDATA

MOVLW DATA_EE_ADDR_LOW ;
MOVWF EEADR ; Data Memory Address to write
MOVLW DATA_EE_ADDR_HI ;
MOVWF EEADRH ;
MOVLW DATA_EE_DATA ;
MOVWF EEDATA ; Data Memory Value to write
BCF EECON1, EEPGD ; Point to DATA memory
BCF EECON1, CFGS ; Access EEPROM
BSF EECON1, WREN ; Enable writes
BCF INTCON, GIE ; Disable Interrupts
MOVLW 55h ;

Required MOVWF EECON2 ; Write 55h
Sequence MOVLW 0AAh ;

MOVWF EECON2 ; Write 0AAh
BSF EECON1, WR ; Set WR bit to begin write
BSF INTCON, GIE ; Enable Interrupts

; User code execution

BCF EECON1, WREN ; Disable writes on write complete (EEIF set)

7.3 Reading the Data EEPROM Memory

T o read a d ata memory loca tion, the user must write the
address to the EEADR register, clear the EEPGD con­trol bit of the EECON1 register and then set control bit,
RD. The data is available on the very next instruction
cycle; therefore, the EEDATA register can be read by
the next instruction. EEDATA will hold this value until
another read operation, or until it is written to by the
user (during a write operation).

The basic process is shown in Example 7-1.

7.4 Writing to the Data EEPROM Memory

To write an EEPROM data location, the address must
first be written to the EEADR r egiste r and the da t a writ­ten to the EEDATA register. The sequence in

Example 7-2 must be followe d to initiate the write cycle.

The write will not begin if this sequence is not exactly
followed (write 55h to EECON2, write 0AAh to
EECON2, then set WR bit) for each byte. It is strongly
recommended that interrupts be disabled during this
code segment.

Additionally, the WREN bit in EECON1 must be set to
enable writes. This mechanism prevents accidental
writes to data EEPROM due to unexpected code
execution (i.e., runaway programs). The WREN bit
should be kept clear at all times , exc ept whe n u pdatin g
the EEPROM. The WREN bit is not cleared by
hardware.

After a write sequence has been initiated, EECON1,
EEADR and EEDATA cannot be modified. The WR bit
will be inhibited from being set unless the WREN bit is
set. Both WR and WREN cannot be set with the same
instruction.

At the completion of the write cycle, the WR bit is
cleared by hardware and the EEPROM Interrupt Flag
bit, EEIF, is set. The user may either enable this
interrupt or poll this bit. EEIF must be cleared by
software.

7.5 Write Verify

Depending on the application, good programming
practice may dictate that the value written to the
memory should be verified against the original value.
This should be used in applications where excessive
writes can stress bits near the specification limit.

EXAMPLE 7-1: DATA EEPROM READ

EXAMPLE 7-2: DATA EEPROM WRITE

 2010-2015 Microchip Technology Inc. DS40001303H-page 95

PIC18F2XK20/4XK20

CLRF EEADR ; Start at address 0
BCF EECON1, CFGS ; Set for memory
BCF EECON1, EEPGD ; Set for Data EEPROM
BCF INTCON, GIE ; Disable interrupts
BSF EECON1, WREN ; Enable writes

Loop ; Loop to refresh array

BSF EECON1, RD ; Read current address
MOVLW 55h ;
MOVWF EECON2 ; Write 55h
MOVLW 0AAh ;
MOVWF EECON2 ; Write 0AAh
BSF EECON1, WR ; Set WR bit to begin write
BTFSC EECON1, WR ; Wait for write to complete
BRA $-2
INCFSZ EEADR, F ; Increment address
BRA LOOP ; Not zero, do it again

BCF EECON1, WREN ; Disable writes
BSF INTCON, GIE ; Enable interrupts

7.6 Operation During Code-Protect

Data EEPROM memory has its own code-protect bit s in
Configuration Words. External read and write
operations are disabled if code protection is enabled.

The microcontroller i tself can both re ad and wr ite to the
internal data EEPROM, regardless of the state of the
code-protect Configuration bit. Refer to Section 23.0

“Special Features of the CPU” for additional

information.

7.7 Protection Against Spurious Write

There are c onditions when the user may no t want to
write to the data EEPROM memory. To protect against
spurious EEPROM writes, various mechanisms have
been implemented. On power-up, the WREN bit is
cleared. In addition, writes to the EEPROM are b locked
during the Power-up Timer period (T
parameter 33).

PWRT,

The write initiate seq ue nce an d the WREN bi t tog eth er
help prevent an accidental write during brown-out,
power glitch or software malfunction.

7.8 Using the Data EEPROM

The data EEPROM is a high-endurance, byte
addressable array that has been optimized for the
storage of frequently changing information (e.g.,
program variables or other data that are updated often).
When variables in one section change frequently, while
variables in another section do not c hange, it is possible
to exceed the total number of write cycles to the
EEPROM (specification D124) without exceeding the
total number of write cycles to a single byte (specification

D120). If this is the case, then an array refresh must be

performed. For this reason, variables that change
infrequently (such as constants, IDs, calibration, etc.)
should be stored in Flash program memory.

A simple data EEPROM refresh routine is shown in

Example 7-3.

Note: If data EEPROM is only used to store

constants and /or data th at change s rarely,
an array refresh is l ike ly n ot requ ire d. See
specification.

EXAMPLE 7-3: DATA EEPROM REFRESH ROUTINE

DS40001303H-page 96  2010-2015 Microchip Technology Inc.

PIC18F2XK20/4XK20

TABLE 7-1: REGISTERS ASSOCIATED WITH DATA EEPROM MEMORY

Reset

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

INTCON GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 56
EEADR EEADR7 EEADR6 EEADR5 EEADR4 EEADR3 EEADR2 EEADR1 EEADR0 58
EEADRH
EEDATA EEPROM Data Register 58
EECON2 EEPROM Control Register 2 (not a physical register) 58
EECON1 EEPGD CFGS
IPR2
PIR2 OSCFIF C1IF C2IF EEIF BCLIF HLVDIF TMR3IF CCP2IF 59
PIE2 OSCFIE C1IE C2IE EEIE BCLIE HLVDIE TMR3IE CCP2IE 59

Legend: — = unimplemented, read as ‘0’. Shaded cells are not used during Flash/EEPROM access.
Note 1: PIC18F26K20/PIC18F46K20 only.

(1)

— — — — — — EEADR9 EEADR8 58

— FREE WRERR WREN WR RD 58

OSCFIP C1IP C2IP EEIP BCLIP HLVDIP TMR3IP CCP2IP 59

Values

on page

 2010-2015 Microchip Technology Inc. DS40001303H-page 97

PIC18F2XK20/4XK20

MOVF ARG1, W ;
MULWF ARG2 ; ARG1 * ARG2 ->

; PRODH:PRODL

MOVF ARG1, W
MULWF ARG2 ; ARG1 * ARG2 ->

; PRODH:PRODL
BTFSC ARG2, SB ; Test Sign Bit
SUBWF PRODH, F ; PRODH = PRODH

; - ARG1
MOVF ARG2, W
BTFSC ARG1, SB ; Test Sign Bit
SUBWF PRODH, F ; PRODH = PRODH

; - ARG2

8.0 8 x 8 HARDWARE MULTIPLIER

8.1 Introduction

All PIC18 devices include an 8 x 8 hardware multiplier
as part of the ALU. The multiplier pe rforms an unsigned
operation and yields a 16-bit result that is stored in the
product register pair, PRODH:PRODL. The multiplier’s
operation does not affect any flags in the STATUS
register.

Making multiplication a hardware operation allows it to
be completed in a single instructi on cy cl e. Thi s has th e
advantages of higher computational throughput and
reduced code size for multiplication algorithms and
allows the PIC18 devices to be used in many applica­tions previously reserved for digital signal processors.
A comparison of various hardware and software
multiply operations, along with the savings in memory
and execution time, is shown in Table 8-1.

8.2 Operation

Example 8-1 shows the instruc tion sequen ce for an 8 x 8

unsigned multiplication. Only one instruction is required
when one of the arguments is already loaded in the
WREG register.

Example 8-2 shows the sequ ence to do an 8 x 8 signe d

multiplication. To account for the sign bits of the argu­ments, each argument’s Most Significant bit (MSb) is
tested and the appropriate subtractions are done.

EXAMPLE 8-1: 8 x 8 UNSIGNED

MULTIPLY ROUTINE

EXAMPLE 8-2: 8 x 8 SIGNED MULTIPLY

ROUTINE

TABLE 8-1: PERFORMANCE COMPARISON FOR VARIOUS MULTIPLY OPERATIONS

Routine Multiply Method

8 x 8 unsigned

8 x 8 signed

16 x 16 unsigned

16 x 16 signed

DS40001303H-page 98  2010-2015 Microchip Technology Inc.

Without hardware multiply 13 69 6.9 s27.6 s69 s

Without hardware multiply 33 91 9.1 s36.4 s91 s

Without hardware multiply 21 242 24.2 s96.8 s 242 s

Without hardware multiply 52 254 25.4 s 102.6 s 254 s

Program

Memory

(Words)

Hardware multiply 1 1 100 ns 400 ns 1 s

Hardware multiply 6 6 600 ns 2.4 s6 s

Hardware multiply 28 28 2.8 s 11.2 s28 s

Hardware multiply 35 40 4.0 s16.0 s40 s

Cycles

(Max)

@ 40 MHz @ 10 MHz @ 4 MHz

Time

PIC18F2XK20/4XK20

RES3:RES0 = ARG1H:ARG1L  ARG2H:ARG2L

= (ARG1H  ARG2H  2

16

) +

(ARG1H  ARG2L  2

8

) +

(ARG1L  ARG2H  2

8

) +

(ARG1L  ARG2L)

MOVF ARG1L, W
MULWF ARG2L ; ARG1L * ARG2L->

; PRODH:PRODL
MOVFF PRODH, RES1 ;
MOVFF PRODL, RES0 ;

;

MOVF ARG1H, W
MULWF ARG2H ; ARG1H * ARG2H->

; PRODH:PRODL
MOVFF PRODH, RES3 ;
MOVFF PRODL, RES2 ;

;

MOVF ARG1L, W
MULWF ARG2H ; ARG1L * ARG2H->

; PRODH:PRODL
MOVF PRODL, W ;
ADDWF RES1, F ; Add cross
MOVF PRODH, W ; products
ADDWFC RES2, F ;
CLRF WREG ;
ADDWFC RES3, F ;

;

MOVF ARG1H, W ;
MULWF ARG2L ; ARG1H * ARG2L->

; PRODH:PRODL
MOVF PRODL, W ;
ADDWF RES1, F ; Add cross
MOVF PRODH, W ; products
ADDWFC RES2, F ;
CLRF WREG ;
ADDWFC RES3, F ;

RES3:RES0 = ARG1H:ARG1L  ARG2H:ARG2L

= (ARG1H  ARG2H  2

16

) +

(ARG1H  ARG2L  2

8

) +

(ARG1L  ARG2H  2

8

) +
(ARG1L  ARG2L) +
(-1  ARG2H<7>  ARG1H:ARG1L  2

16

) +

(-1  ARG1H<7>  ARG2H:ARG2L  2

16

)

MOVF ARG1L, W
MULWF ARG2L ; ARG1L * ARG2L ->

; PRODH:PRODL
MOVFF PRODH, RES1 ;
MOVFF PRODL, RES0 ;

;

MOVF ARG1H, W
MULWF ARG2H ; ARG1H * ARG2H ->

; PRODH:PRODL
MOVFF PRODH, RES3 ;
MOVFF PRODL, RES2 ;

;

MOVF ARG1L, W
MULWF ARG2H ; ARG1L * ARG2H ->

; PRODH:PRODL
MOVF PRODL, W ;
ADDWF RES1, F ; Add cross
MOVF PRODH, W ; products
ADDWFC RES2, F ;
CLRF WREG ;
ADDWFC RES3, F ;

;

MOVF ARG1H, W ;
MULWF ARG2L ; ARG1H * ARG2L ->

; PRODH:PRODL
MOVF PRODL, W ;
ADDWF RES1, F ; Add cross
MOVF PRODH, W ; products
ADDWFC RES2, F ;
CLRF WREG ;
ADDWFC RES3, F ;

;

BTFSS ARG2H, 7 ; ARG2H:ARG2L neg?
BRA SIGN_ARG1 ; no, check ARG1
MOVF ARG1L, W ;
SUBWF RES2 ;
MOVF ARG1H, W ;
SUBWFB RES3

;
SIGN_ARG1

BTFSS ARG1H, 7 ; ARG1H:ARG1L neg?
BRA CONT_CODE ; no, done
MOVF ARG2L, W ;
SUBWF RES2 ;
MOVF ARG2H, W ;
SUBWFB RES3

;
CONT_CODE

:

Example 8-3 shows the sequence to do a 16 x 16

unsigned multiplication. Equation 8-1 shows the
algorithm that is used . The 32-bit re sult is st ored in four
registers (RES<3:0>).

EQUATION 8-1: 16 x 16 UNSIGNED

MULTIPLICATION
ALGORITHM

EXAMPLE 8-3: 16 x 16 UNSIGNED

MULTIPLY ROUTINE

Example 8-4 shows the sequence to do a 16 x 16

signed multiply. Equation 8-2 shows the algorithm
used. The 32-bit result is stored in four registers
(RES<3:0>). To account for the sign bits of the argu­ments, the MSb for each argument pair is tested and
the appropriate subtractions are done.

 2010-2015 Microchip Technology Inc. DS40001303H-page 99

EQUATION 8-2: 16 x 16 SIGNED

MULTIPLICATION
ALGORITHM

EXAMPLE 8-4: 16 x 16 SIGNED

MULTIPLY ROUTINE

PIC18F2XK20/4XK20

9.0 INTERRUPTS

The PIC18F2XK20/4XK20 devices have multiple
interrupt sources and an interrupt priority feature that
allows most interrupt sources to be assigned a high
priority level or a low priority level. The high priority
interrupt vector is at 0008h and the low priorit y interrupt
vector is at 0018h. A high priority interrupt event will
interrupt a low pri ority interrupt that may be in p rogress.

There are ten registers which are used to control
interrupt operation. These registers are:

• RCON

•INTCON

• INTCON2

• INTCON3

• PIR1, PIR2

• PIE1, PIE2

• IPR1, IPR2
It is recommended that the Microchip header files sup-

plied with MPLAB
names in these registers. This allows the assembler/
compiler to automatical ly ta ke care of the pla ceme nt of
these bits within the specified register.

In genera l, inte rru pt so urces have thre e bits to cont rol
their operation. They are:

• Flag bit to indicate that an interrupt event
occurred

• Enable bit that allows program execution to
branch to the interrupt vector address when the
flag bit is set

• Priority bit to select high priority or low priority

9.1 Mid-Range Compatibility

When the IPEN bit is cleared (default st ate), the interrupt
priority feature is disabled and interrupts are compatible
with PIC
Compatibility mode, the interrupt priority bits of the IPRx
registers have no effect. The PEIE bit of the INTCON
register is the global interrupt enable for the p eripherals.
The PEIE bit disables only the peripheral interrupt
sources and enables the peripheral interrupt sources
when the GIE bit is also set. The GIE bit of the INTCON
register is the global interrupt enable which enables all
non-peripheral interrupt sources and disables all
interrupt sources, including the peripherals. All interrupts
branch to address 0008h in Compatibility mode.

®

®

IDE be used for the symbolic bit

microcontroller mid-range devices. In

9.2 Interrupt Priority

The interrupt priority feature is enabled by setting the
IPEN bit of the RCON register. When interrupt priority
is enabled the GIE and PEIE global interrupt enable
bits of Compatibility mode are replaced by the GIEH
high priority, and GIEL low priority, global interrupt
enables. When set, the GIEH bit of the INTCON regis­ter enables all interrupts that have their associated
IPRx register or INTCONx register priority bit set (high
priority). When clear, the GIEH bit disables all interrupt
sources including those selected as low priority. When
clear , the GIEL bit of the INTCON register disa bles only
the interrupts that have their associated priority bit
cleared (low priority). When set, the GIEL bit enables
the low priority sources when the GIEH bit is also set.

When the interrupt flag, enable bit and appropriate
global interrupt enable bit are all set, the interrupt will
vector immediately to address 0008h for high priority,
or 0018h for low priority, depending on level of the
interrupting source’s priority bit. Individual interrupts
can be disabled through their corresponding interrupt
enable bits.

9.3 Interrupt Response

When an interrupt is responded to, the global interrupt
enable bit is cleared to disable further interrupts. The
GIE bit is the globa l i nte rrupt enable when the IPEN b it
is cleared. When the IPEN bit is set, enabling interrupt
priority levels, the GIEH bit is the high priority global
interrupt enable and the GIEL bit is the low priority
global interrupt enable. High priority interrupt sources
can interrupt a low priority interrupt. Low priority
interrupts are not processed while high priority
interrupts are in progress.

The return address is pushed onto the stack and the
PC is loaded with the interrupt vector address (0008h
or 0018h). Once in the Interrupt Service Routine, the
source(s) of the interrupt can be determined by polling
the interrupt flag bits in the INTCONx and PIRx
registers. The interrupt flag bits must be cleared by
software before re-enabling interrupts to avoid
repeating the same interrupt.

The “return from interrupt” instruction, RETFIE, exits
the interrupt routine and set s the GIE bit (GIEH or GI EL
if priority levels are used), which re-enables interrupts.

For external interrupt events, such as the INT pins or
the PORTB interrupt-on-change, the interrupt latency
will be three to four instruction cycles. The exact
latency is th e same fo r one-c ycle or tw o-cycl e instr uc­tions. Individual int errupt fla g bit s are s et, regard less of
the status of their corresponding enable bits or the
global interrupt enable bit.

DS40001303H-page 100  2010-2015 Microchip Technology Inc.
