Datasheet PIC16F873, PIC16F874, PIC16F876, PIC16F877 Datasheet

Download

PIC16F87X

RB7/PGD RB6/PGC RB5 RB4 RB3/PGM RB2

RB1 RB0/INT VDD VSS RD7/PSP7 RD6/PSP6 RD5/PSP5 RD4/PSP4 RC7/RX/DT RC6/TX/CK RC5/SDO RC4/SDI/SDA RD3/PSP3 RD2/PSP2

MCLR/VPP

RA0/AN0 RA1/AN1

RA2/AN2/V

REF-

RA3/AN3/VREF+

RA4/T0CKI

RA5/AN4/SS

RE0/RD/AN5

RE1/WR/AN6

RE2/CS/AN7

VDD VSS

OSC1/CLKIN

OSC2/CLKOUT

RC0/T1OSO/T1CKI

RC1/T1OSI/CCP2

RC2/CCP1

RC3/SCK/SCL

RD0/PSP0 RD1/PSP1

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21

PIC16F877/874

PDIP

28/40-Pin 8-Bit CMOS FLASH Microcontr ollers

Devices Included in this Data Sheet:

•PIC16F873

•PIC16F874

•PIC16F876

•PIC16F877

Pin Diagram

Microcontroller Core Features:

• High performance RISC CPU

• Only 35 single word instructions to learn

• All single cycle instructions except for program branches which are two cycle

• Operating speed: DC - 20 MHz clock input

DC - 200 ns instruction cycle

• Up to 8K x 14 words of FLASH Progr am M emory, Up to 368 x 8 bytes of Data Memory (RAM) Up to 256 x 8 bytes of EEPROM Data Memory

• Pinout compatible to the PIC16C73B/74B/76/77

• Interrupt capability (up to 14 sources)

• Eight level deep hardware stack

• Direct, indirect and relative addressing modes

• Power-on Reset (PO R)

• Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

• Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation

• Programmable code protection

• Power saving SLEEP mode

• Selectable oscillator options

• Low power, high speed CMOS FLASH/EEPROM technology

• Fully static design

• In-Circuit Serial Programming(ICSP)via two pins

• Single 5V In-Circu it Seria l P r ogra mmin g c apability

• In-Circuit Debugging via two pins

• Processor read/write access to program memory

• Wide operating voltage range: 2.0V to 5.5V

• High Sink/Source Current: 25 mA

• Commercial, Industria l and Extended temp erature ranges

• Low-power consumption:

- < 0.6 mA typical @ 3V, 4 MHz

-20 A typical @ 3V, 32 kHz

-< 1 A typical standby current

 1998-2013 Microchip Technology Inc. DS30292D-page 1

Peripheral Features:

• Timer0: 8-bit timer/counter with 8-bit prescaler

• Timer1: 16-bit timer/counter with prescaler, can be incremented during SLEEP via external crystal/clock

• Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

• Two Capture, Compare, PWM modules

- Capture is 16-bit, max. resolution is 12.5 ns

- Compare is 16-bit, max. resolution is 200 ns

- PWM max. resolution is 10-bit

• 10-bit multi-channel Analog-to-Digital converter

• Synchronous Serial Port (SSP) with SPI (Master mode) and I

• Universal Synchronous Asynchronous Receiver Transmitter (USART/SCI) with 9-bit address detection

• Parallel Slave Port (PSP) 8-bits wide, with external RD

• Brown-out detection circuitry for Brown-out Reset (BOR)

2C

(Master/Slave)

, WR and CS controls (40/44-pin only)

PIC16F87X

PIC16F876/873

10 11

2 3 4 5 6

12 13 14

22 21

MCLR/VPP

RA0/AN0 RA1/AN1

RA2/AN2/V

REF-

RA3/AN3/V

REF+

RA4/T0CKI

RA5/AN4/SS

VSS

OSC1/CLKIN

OSC2/CLKOUT

RC0/T1OSO/T1CKI

RC1/T1OSI/CCP2

RC2/CCP1

RC3/SCK/SCL

RB7/PGD RB6/PGC RB5 RB4 RB3/PGM RB2 RB1 RB0/INT V

VSS RC7/RX/DT RC6/TX/CK RC5/SDO RC4/SDI/SDA

10 11 12 13 14 15 16 17

181920212223242526

65432

PIC16F877

RA4/T0CKI

RA5/AN4/SS

RE0/RD/AN5

OSC1/CLKIN

OSC2/CLKOUT

RC0/T1OSO/T1CK1

RE1/WR

/AN6

RE2/CS

/AN7

VSS

RB3/PGM RB2 RB1 RB0/INT V

VSS RD7/PSP7 RD6/PSP6 RD5/PSP5 RD4/PSP4 RC7/RX/DT

RA3/AN3/VREF+

RA2/AN2/V

REF-

RA1/AN1

RA0/AN0

MCLR

/VPP

RB7/PGD

RB6/PGC

RB5

RB4

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1

RC1/T1OSI/CCP2

10 11

2 3 4 5 6

1819202122

121314

4443424140

363435

PIC16F877

RA3/AN3/VREF+

RA2/AN2/V

REF-

RA1/AN1

RA0/AN0

MCLR

/VPP

RB7/PGD

RB6/PGC

RB5

RB4

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1

RC1/T1OSI/CCP2

NC RC0/T1OSO/T1CKI OSC2/CLKOUT OSC1/CLKIN V

VDD RE2/AN7/CS RE1/AN6/WR RE0/AN5/RD RA5/AN4/SS RA4/T0CKI

RC7/RX/DT

RD4/PSP4 RD5/PSP5 RD6/PSP6 RD7/PSP7

VDD

RB0/INT

RB1 RB2

RB3/PGM

PLCC

QFP

PDIP, SOIC

PIC16F874

Pin Diagrams

DS30292D-page 2  1998-2013 Microchip Technology Inc.

PIC16F87X

Key Features

MCU Mid-Range Reference

PIC

Manual (DS33023)

Operating Frequency DC - 20 MHz DC - 20 MHz DC - 20 MHz DC - 20 MHz

RESETS (and Delays) POR, BOR

FLASH Program Memory

(14-bit words)

Data Memory (bytes) 192 192 368 368

EEPROM Data Memory 128 128 256 256

Interrupts 13 14 13 14

I/O Ports Ports A,B,C Ports A,B,C,D,E Ports A,B,C Ports A,B,C,D,E

Timers 3333

Capture/Compa re/PWM Modules 2 2 2 2

Serial Communications MSSP, USART MSSP, USART MSSP, USART MSSP, USART

Parallel Communications — PSP — PSP

10-bit Analog-to-Digital Module 5 input channels 8 input channels 5 input channels 8 input channels

Instruction Set 35 instructions 35 instructions 35 instructions 35 instructions

PIC16F873 PIC16F874 PIC16F876 PIC16F877

POR, BOR

(PWRT, OST)

4K 4K 8K 8K

(PWRT, OST)

POR, BOR

(PWRT, OST)

POR, BOR

(PWRT, OST)

 1998-2013 Microchip Technology Inc. DS30292D-page 3

PIC16F87X

1.0 Device Overview................................................................................................................................................... 5

2.0 Memory Organization.......................................................................................................................................... 11

3.0 I/O Ports.............................................................................................................................................................. 29

4.0 Data EEPROM and FLASH Program Memory.................................................................................................... 41

5.0 Timer0 Module.................................................................................................................................................... 47

6.0 Timer1 Module.................................................................................................................................................... 51

7.0 Timer2 Module.................................................................................................................................................... 55

8.0 Capture/Compare/PWM Modules....................................................................................................................... 57

9.0 Master Synchronous Serial Port (MSSP) Module............................................................................................... 65

10.0 Addressable Universal Synchronous Asynchronous Receiver Transmitter (USART) ........................................ 95

11.0 Analog-to-Digital Converter (A/D) Module......................................................................................................... 111

12.0 Special Features of the CPU............................................................................................................................. 119

13.0 Instruction Set Summary................................................................................................................................... 135

14.0 Deve lo pme nt Supp ort........................... ...... ..... ...... .................................. ..... ...... .............................................. 143

15.0 Electrical Characteristics................................................................................................................................... 149

16.0 DC and AC Characteristics Graphs and Tables................................................................................................ 177

17.0 Packaging Information...................................................................................................................................... 189

Appendix A: Revision History .................................................................................................................................... 197

Appendix B: Device Differences ................................................................................................................................ 197

Appendix C: Conversion Considerations................................................................................................................... 198

Index .......................................................................................................................................................................... 199

On-Line Support......................................................................................................................................................... 207

Reader Response...................................................................................................................................................... 208

PIC16F87X Product Identification System................................................................................................................. 209

TO OUR VALUED CUSTOMERS

It is our intention to provide our valued customers with the best documentation possible to ensure successful use of your Microchip products. To this end, we will continue to improve our publications to better suit your needs. Our publications will be refined and enhanced as new volumes and updates are introduced.

If you have any questions or c omm ents r egarding t his publication, p lease c ontact the M arket ing Communications Department via E-mail at docerrors@mail.microchip.com or fax the Reader Response Form in the back of this data sheet to (480) 792-4150. We welcome your feedback.

Most Current Data Sheet

To obtain the most up-to-date version of this data sheet, please register at our Worldwide Web site at:

http://www.microchip.com

You can determine the version of a data sheet by examining its literature number found on the bottom outside corner of any page. The last character of the literature number is the version number, (e.g., DS30000A is version A of document DS30000).

Errata

An errata sheet, describing minor operational differences from the data sheet and recommended workarounds, may exist for current devices. As device/documentation issues become known to us, we will publish an errata sheet. The errata will specify the revision of silicon and revision of document to which it applies.

To determine if an errata sheet exists for a particular device, please check with one of the following:

• Microchip’s Worldwide Web site; http://www.microchip.com

• Your local Microchip sales office (see last page)

• The Microchip Corporate Literature Center; U.S. FAX: (480) 792-7277 When contacting a sales office or the literature center, please specify which device, revision of silicon and data sheet (include liter-

ature number) you are using.

Customer Notification System

DS30292D-page 4  1998-2013 Microchip Technology Inc.

PIC16F87X

FLASH

Program

Memory

Data Bus

Program

Bus

Instruction reg

Program Counter

8 Level Stack

(13-bit)

RAM

File

Registers

Direct Addr

RAM Addr

(1)

Addr MUX

Indirect

Addr

FSR reg

STATUS reg

MUX

ALU

W reg

Power-up

Timer

Oscillator

Start-up Timer

Power-on

Reset

Watchdog

Timer

Instruction

Decode &

Control

Timing

Generation

OSC1/CLKIN OSC2/CLKOUT

MCLR

VDD, VSS

PORTA

PORTB

PORTC

RA4/T0CKI RA5/AN4/SS

RB0/INT

RC0/T1OSO/T1CKI RC1/T1OSI/CCP2 RC2/CCP1

RC3/SCK/SCL RC4/SDI/SDA RC5/SDO RC6/TX/CK RC7/RX/DT

Brown-out

Reset

Note 1: Higher order bits are from the STATUS register.

USART

CCP1,2

Synchronous

10-bit A/DTimer0 Timer1 Timer2

Serial Port

RA3/AN3/VREF+

RA2/AN2/VREF-

RA1/AN1

RA0/AN0

Data EEPROM

RB1 RB2 RB3/PGM RB4 RB5 RB6/PGC RB7/PGD

Device

Program

FLASH

Data Memory

Data

EEPROM

PIC16F873 4K 192 Bytes 128 Bytes PIC16F876 8K 368 Bytes 256 Bytes

In-Circuit

Debugger

Low Voltage

Programming

1.0 DEVICE OVERVIEW

This document contains device specific information. Additional information may be found in the PIC Mid-Range Reference Manual (DS33023), which may be obtained from your local Microchip Sales Representative or downloaded from the Microchip website. The Reference Manual should be considered a complementary document to this data sheet, and is highly recommended reading for a better understanding of the device architecture and operation of the peripheral modules.

FIGURE 1-1: PIC16F873 AND PIC16F876 BLOCK DIAGRAM

MCU

There are four devices (PIC16F873, PIC16F874, PIC16F876 and PIC16F877) covered by this data sheet. The PIC16F876/873 devices come in 28-pin packages and the PIC16F877/874 devices come in 40-pin packages. The Parallel Slave Port is not implemented on the 28-pin devic es .

The following device bloc k diagrams are s orted by pin number; 28-pin for Figure 1-1 and 40-pin for Figure 1-2. The 28-pin and 40-pin pin outs are listed in Table 1-1 and Table 1-2, respectively.

 1998-2013 Microchip Technology Inc. DS30292D-page 5

PIC16F87X

FLASH Program

Memory

Data Bus

Program

Bus

Instruction reg

Program Counter

8 Level Stack

(13-bit)

RAM

File

Registers

Direct Addr

RAM Addr

(1)

Addr MUX

Indirect

Addr

FSR reg

STATUS reg

MUX

ALU

W reg

Power-up

Timer

Oscillator

Start-up Timer

Power-on

Reset

Watchdog

Timer

Instruction

Decode &

Control

Timing

Generation

OSC1/CLKIN OSC2/CLKOUT

MCLR

VDD, VSS

PORTA

PORTB

PORTC

PORTD

PORTE

RA4/T0CKI RA5/AN4/SS

RC0/T1OSO/T1CKI RC1/T1OSI/CCP2 RC2/CCP1 RC3/SCK/SCL RC4/SDI/SDA RC5/SDO RC6/TX/CK RC7/RX/DT

RE0/AN5/RD RE1/AN6/WR

RE2/AN7/CS

Brown-out

Reset

Note 1: Higher order bits are from the STATUS register.

USART

CCP1,2

Synchronous

10-bit A/DTimer0 Timer1 Timer2

Serial Port

RA3/AN3/VREF+

RA2/AN2/VREF-

RA1/AN1

RA0/AN0

Parallel Slave Port

Data EEPROM

RB0/INT RB1 RB2 RB3/PGM RB4 RB5 RB6/PGC RB7/PGD

Device

Program

FLASH

Data Memory

Data

EEPROM

PIC16F874 4K 192 Bytes 128 Bytes PIC16F877 8K 368 Bytes 256 Bytes

In-Circuit

Debugger

Low-Voltage

Programming

RD0/PSP0 RD1/PSP1 RD2/PSP2 RD3/PSP3 RD4/PSP4 RD5/PSP5 RD6/PSP6 RD7/PSP7

FIGURE 1-2: PIC16F874 AND PIC16F877 BLOCK DIAGRAM

DS30292D-page 6  1998-2013 Microchip Technology Inc.

T ABLE 1-1: PIC16F873 AND PIC16F876 PINOUT DESCRIPTION

PIC16F87X

Pin Name

DIP

Pin#

OSC1/CLKIN 9 9 I ST/CMOS

SOIC

Pin#

I/O/P Type

Buffer

Type

Description

(3)

Oscillator crystal input/external clock source input.

OSC2/CLKOUT 10 10 O — Oscillator crystal output. Connects to crystal or resonator in

crystal oscillator mode. In RC mode, the OSC2 pin outputs CLKOUT which has 1/4 the frequency of OSC1, and denotes the instruction cycle rate.

/VPP 1 1 I/P ST Master Clear (Reset) input or programming voltage input. This

MCLR

pin is an active low RESET to the device.

PORTA is a bi-directional I/O port. RA0/AN0 2 2 I/O TTL RA0 can also be analog input0. RA1/AN1 3 3 I/O TTL RA1 can also be analog input1. RA2/AN2/V

REF- 4 4 I/O TTL RA2 can also be analog input2 or negative analog

reference voltage.

RA3/AN3/V

REF+ 5 5 I/O TTL RA3 can also be analog input3 or positive analog

reference voltage.

RA4/T0CKI 6 6 I/O ST RA4 can also be the clock input to the Timer0

module. Output is open drain type.

/AN4 7 7 I/O TTL RA5 can also be analog input4 or the slave select

RA5/SS

for the synchronous serial port.

PORTB is a bi-directional I/O port. PORTB can be software

programmed for internal weak pull-up on all inputs. RB0/INT 21 21 I/O TTL/ST

(1)

RB0 can also be the external interrupt pin. RB1 22 22 I/O TTL RB2 23 23 I/O TTL RB3/PGM 24 24 I/O TTL RB3 can also be the low voltage programming input. RB4 25 25 I/O TTL Interrupt-on-change pin. RB5 26 26 I/O TTL Interrupt-on-change pin. RB6/PGC 27 27 I/O TTL/ST

(2)

Interrupt-on-change pin or In-Circuit Debugger pin. Serial

programming clock. RB7/PGD 28 28 I/O TTL/ST

(2)

Interrupt-on-change pin or In-Circuit Debugger pin. Serial

programming data.

PORTC is a bi-directional I/O port.

RC0/T1OSO/T1CKI 11 11 I/O ST RC0 can also be the Timer1 oscillator output or Timer1

clock input. RC1/T1OSI/CCP2 12 12 I/O ST RC1 can also be the Timer1 oscillator input or Capture2

input/Compare2 output/PWM2 output. RC2/CCP1 13 13 I/O ST RC2 can also be the Capture1 input/Compare1 output/

PWM1 output. RC3/SCK/SCL 14 14 I/O ST RC3 can also be the synchronous serial clock input/output

for both SPI and I RC4/SDI/SDA 15 15 I/O ST RC4 can also be the SPI Data In (SPI mode) or

data I/O (I

C mode).

C modes.

RC5/SDO 16 16 I/O ST RC5 can also be the SPI Data Out (SPI mode). RC6/TX/CK 17 17 I/O ST RC6 can also be the USART Asynchronous Transmit or

Synchronous Clock. RC7/RX/DT 18 18 I/O ST RC7 can also be the USART Asynchronous Receive or

Synchronous Data.

SS 8, 19 8, 19 P — Ground reference for logic and I/O pins.

DD 20 20 P — Positive supply for logic and I/O pins.

V Legend: I = input O = output I/O = input/output P = power

— = Not used TTL = TTL input ST = Schmitt Trigger input

Note 1: This buffer is a Schmitt Trigger input when configured as the external interrupt.

2: This buffer is a Schmitt Trigger input when used in Serial Programming mode. 3: This buffer is a Schmitt Trigger input when configured in RC oscillator mode and a CMOS input otherwise.

 1998-2013 Microchip Technology Inc. DS30292D-page 7

PIC16F87X

TABLE 1-2: PIC16F874 AND PIC16F877 PINOUT DESCRIPTION

DIP

Pin Name

OSC1/CLKIN 13 14 30 I ST/CMOS OSC2/CLKOUT 14 15 31 O — Oscillator crystal output. Connects to crystal or resonator

/VPP 1 2 18 I/P ST Master Clear (Reset) input or programming voltage input.

MCLR

RA0/AN0 2 3 19 I/O TTL RA0 can also be analog input0. RA1/AN1 3 4 20 I/O TTL RA1 can also be analog input1. RA2/AN2/V

RA3/AN3/V

RA4/T0CKI 6 7 23 I/O ST RA4 can also be the clock input to the Timer0 timer/

RA5/SS/

RB0/INT 33 36 8 I/O TTL/ST RB1 34 37 9 I/O TTL RB2 35 38 10 I /O TTL RB3/PGM 36 39 11 I/O TTL RB3 can also be the low voltage programming input. RB4 37 41 14 I/O TTL Interrupt-on-change pin. RB5 38 42 15 I/O TTL Interrupt-on-change pin. RB6/PGC 39 43 16 I/O TTL/ST

RB7/PGD 40 44 17 I/O TTL/ST

Legend: I = input O = output I/O = input/output P = power

Note 1: This buffer is a Schmitt Trigger input when configured as an external interrupt.

REF- 4 5 21 I/O TTL RA2 can also be analog input2 or negative

REF+ 5 6 22 I/O TTL RA3 can also be analog input3 or positive

AN4 7 8 24 I/O TTL RA5 can also be analog input4 or the slave select for

2: This buffer is a Schmitt Trigger input when used in Serial Programming mode. 3: This buffer is a Schmitt Trigger input when configured as general purpose I/O and a TTL input when used in the Parallel

Slave Port mode (for interfacing to a microprocessor bus).

4: This buffer is a Schmitt Trigger input when configured in RC oscillator mode and a CMOS input otherwise.

PLCC

Pin#

— = Not used TTL = TTL input ST = Schmitt Trigger input

Pin#

QFP Pin#

I/O/P Type

Buffer

Type

Description

(4)

Oscillator crystal input/external clock source input.

in crystal oscillator mode. In RC mode, OSC2 pin outputs CLKOUT which has 1/4 the frequency of OSC1, and denotes the instruction cycle rate.

This pin is an active low RESET to the device. PORTA is a bi-directional I/O port.

analog reference voltage.

counter. Output is open drain type.

the synchronous serial port.

PORTB is a bi-directional I/O port. PORTB can be software programmed for internal weak pull-up on all inputs.

(1)

(2)

RB0 can also be the external interrupt pin.

Interrupt-on-change pin or In-Circuit Debugger pin. Serial programming clock.

Interrupt-on-change pin or In-Circuit Debugger pin. Serial programming data.

DS30292D-page 8  1998-2013 Microchip Technology Inc.

PIC16F87X

T ABLE 1-2: PIC16F874 AND PIC16F877 PINOUT DESCRIPTION (CONTINUED)

DIP

Pin Name

Pin#

PLCC

Pin#

RC0/T1OSO/T1CKI 15 16 32 I/O ST RC0 can also be the Timer1 oscillator output or a

RC1/T1OSI/CCP2 16 18 35 I/O ST RC1 can also be the Timer1 oscillator input or

RC2/CCP1 17 19 36 I/O ST RC2 can also be the Capture1 input/Compare1

RC3/SCK/SCL 18 20 37 I/O ST RC3 can also be the synchronous serial clock input/

RC4/SDI/SDA 23 25 42 I/O ST RC4 can also be the SPI Data In (SPI mode) or

RC5/SDO 24 26 43 I/O ST RC5 can also be the SPI Data Out (SPI mode). RC6/TX/CK 25 27 44 I/O ST RC6 can also be the USART Asynchronous Transmit

RC7/RX/DT 26 29 1 I/O ST RC7 can also be the USART Asynchronous Receive

RD0/PSP0 19 21 38 I/O ST/TTL RD1/PSP1 20 22 39 I/O ST/TTL RD2/PSP2 21 23 40 I/O ST/TTL RD3/PSP3 22 24 41 I/O ST/TTL RD4/PSP4 27 30 2 I/O ST/TTL RD5/PSP5 28 31 3 I/O ST/TTL RD6/PSP6 29 32 4 I/O ST/TTL RD7/PSP7 30 33 5 I/O ST/TTL

/AN5 8 9 25 I/O ST/TTL

RE0/RD

RE1/WR

RE2/CS

V V

/AN6 9 10 26 I/O ST/TTL

/AN7 10 11 27 I/O ST/TTL

SS 12,31 13,34 6,29 P — Ground reference for logic and I/O pins. DD 11,32 12,35 7,28 P — Positive supply for logic and I/O pins.

NC — 1,17,28,4012,13,

Legend: I = input O = output I/O = input/output P = power

— = Not used TTL = TTL input ST = Schmitt Trigger input

Note 1: This buffer is a Schmitt Trigger input when configured as an external interrupt.

Slave Port mode (for interfacing to a microprocessor bus).

4: This buffer is a Schmitt Trigger input when configured in RC oscillator mode and a CMOS input otherwise.

QFP Pin#

33,34

I/O/P Type

Buffer

Type

Description

PORTC is a bi-directional I/O port.

Timer1 clock input.

Capture2 input/Compare2 output/PWM2 output.

output/PWM1 output.

output for both SPI and I

data I/O (I

C mode).

C modes.

or Synchronous Clock.

or Synchronous Data.

PORTD is a bi-directional I/O port or parallel slave port when interfacing to a microprocessor bus.

(3) (3) (3) (3) (3) (3) (3) (3)

PORTE is a bi-directional I/O port.

(3)

RE0 can also be read control for the parallel slave port, or analog input5.

(3)

RE1 can also be write control for the parallel slave port, or analog input6.

(3)

RE2 can also be select control for the parallel slave port, or analog input7.

— These pins are not internally connected. These pins

should be left unconnected.

 1998-2013 Microchip Technology Inc. DS30292D-page 9

PIC16F87X

NOTES:

DS30292D-page 10  1998-2013 Microchip Technology Inc.

PIC16F87X

PC<12:0>

0000h

0004h

0005h

Stack Level 1

Stack Level 8

RESET Vector

Interrupt Vector

On-Chip

CALL, RETURN RETFIE, RETLW

1FFFh

Stack Level 2

Program Memory

Page 0

Page 1

Page 2

Page 3

07FFh

0800h

0FFFh

1000h

17FFh

1800h

PC<12:0>

0000h

0004h

0005h

Stack Level 1

Stack Level 8

RESET Vector

Interrupt Vector

On-Chip

CALL, RETURN RETFIE, RETLW

1FFFh

Stack Level 2

Program

Memory

Page 0

Page 1

07FFh

0800h

0FFFh

1000h

2.0 MEMORY ORGANIZATION

There are three memory blocks in each of the PIC16F87X MCUs. The Program Memory and Data Memory have separate buses so that concurrent access can oc cur and is detailed in this section. The EEPROM data memory bl ock is detailed in Se ction 4.0.

Additional informa tion on devi ce memory may be found in the PIC (DS33023).

FIGURE 2-1: PIC16F877/876 PROGRAM

MCU Mid-Range Reference Manual,

MEMORY MAP AND STACK

2.1 Program Memory Organization

The PIC16F87X devic es have a 13-b it program count er capable of addressing an 8K x 14 program memory space. The PIC16F877/876 devices have 8K x 14 words of FLASH program memory, and the PIC16F873/874 devices have 4K x 14. Accessing a location above the ph ysicall y implem ented addres s will cause a wraparound.

The RESET vector is at 0000h and the interrupt vector is at 0004h.

FIGURE 2-2: PIC16F874/873 PROGRAM

MEMORY MAP AND STACK

 1998-2013 Microchip Technology Inc. DS30292D-page 11

PIC16F87X

2.2 Data Memory Organization

The data memory is partitioned into multiple banks which contain the General Purpose Registers and the Special Function Registers. Bits RP1 (STATUS<6>) and RP0 (STATUS<5>) are the bank select bits.

RP1:RP0 Bank

00 0 01 1 10 2

11 3

Each bank extends up to 7Fh (128 bytes). The lower locations of each bank are reserved for the Special Function Registers. Above the Special Function Registers are Gener al Purpose Registers, implemented as static RAM. All implemented banks contain Special Function Registers. Some frequently used Special Function Registers from one bank may be mirrored in another bank for code reduction and quicker access.

Note: EEPROM Data Memory de scription can b e

found in Section 4.0 of this data sheet.

2.2.1 GENERAL PURPOSE REGISTER FILE

The register file can be acces sed either directly, or indirectly through the File Select Register (FSR).

DS30292D-page 12  1998-2013 Microchip Technology Inc.

FIGURE 2-3: PIC16F877/876 REGISTER FILE MAP

Indirect addr.

(*)

TMR0

PCL

STATUS

FSR PORTA PORTB PORTC

PCLATH INTCON

PIR1

TMR1L

TMR1H

T1CON

TMR2

T2CON

SSPBUF

SSPCON

CCPR1L

CCPR1H

CCP1CON

OPTION_REG

PCL

STATUS

FSR TRISA TRISB TRISC

PCLATH

INTCON

PIE1

PCON

PR2

SSPADD

SSPSTAT

00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh 10h 11h 12h 13h 14h 15h 16h 17h 18h 19h 1Ah 1Bh 1Ch 1Dh 1Eh 1Fh

80h 81h 82h 83h 84h 85h 86h 87h 88h 89h 8Ah 8Bh 8Ch 8Dh 8Eh 8Fh 90h 91h 92h 93h 94h 95h 96h 97h 98h 99h 9Ah 9Bh 9Ch 9Dh 9Eh 9Fh

20h

A0h

7Fh

FFh

Bank 0

Bank 1

Unimplemented data memory locations, read as '0'.

* Not a physical register.

Note 1: These registers are not implemented on the PIC16F876.

2: These registers are reserved, maintain these registers clear.

File

Address

Indirect addr.

(*)

Indirect addr.

(*)

PCL

STATUS

FSR

PCLATH

INTCON

PCL

STATUS

FSR

PCLATH INTCON

100h 101h 102h 103h 104h 105h 106h 107h 108h 109h 10Ah 10Bh 10Ch 10Dh 10Eh 10Fh 110h 111h 112h 113h 114h 115h 116h 117h 118h 119h 11Ah 11Bh 11Ch 11Dh 11Eh 11Fh

180h 181h 182h 183h 184h 185h 186h 187h 188h 189h 18Ah 18Bh 18Ch 18Dh 18Eh 18Fh 190h 191h 192h 193h 194h 195h 196h 197h 198h 199h 19Ah 19Bh 19Ch 19Dh 19Eh 19Fh

120h

1A0h

17Fh

1FFh

Bank 2

Bank 3

Indirect addr.

(*)

PORTD

(1)

PORTE

(1)

TRISD

(1)

ADRESL

TRISE

(1)

TMR0

OPTION_REG

PIR2

PIE2

RCSTA TXREG RCREG

CCPR2L

CCPR2H

CCP2CON

ADRESH ADCON0

TXSTA

SPBRG

ADCON1

General Purpose Register

1EFh 1F0h

accesses

70h - 7Fh

EFh F0h

accesses

70h-7Fh

16Fh 170h

accesses

70h-7Fh

General Purpose Register

TRISB

PORTB

96 Bytes

80 Bytes 80 Bytes 80 Bytes

16 Bytes

SSPCON2

EEDATA

EEADR

EECON1 EECON2

EEDATH EEADRH

Reserved

(2)

Reserved

(2)

File

Address

File

Address

File

Address

File

Address

PIC16F87X

 1998-2013 Microchip Technology Inc. DS30292D-page 13

PIC16F87X

Indirect addr.

(*)

TMR0

PCL

STATUS

FSR PORTA PORTB PORTC

PCLATH

INTCON

PIR1

TMR1L TMR1H T1CON

TMR2

T2CON

SSPBUF

SSPCON

CCPR1L

CCPR1H

CCP1CON

OPTION_REG

PCL

STATUS

FSR TRISA TRISB TRISC

PCLATH INTCON

PIE1

PCON

PR2

SSPADD

SSPSTAT

00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh 10h 11h 12h 13h 14h 15h 16h 17h 18h 19h 1Ah 1Bh 1Ch 1Dh 1Eh 1Fh

80h 81h 82h 83h 84h 85h 86h 87h 88h 89h 8Ah 8Bh 8Ch 8Dh 8Eh 8Fh 90h 91h 92h 93h 94h 95h 96h 97h 98h 99h 9Ah 9Bh 9Ch 9Dh 9Eh 9Fh

20h

A0h

7Fh

FFh

Bank 0

Bank 1

Indirect addr.

(*)

Indirect addr.

(*)

PCL

STATUS

FSR

PCLATH INTCON

PCL

STATUS

FSR

PCLATH

INTCON

100h 101h 102h 103h 104h 105h 106h 107h 108h 109h 10Ah 10Bh

180h 181h 182h 183h 184h 185h 186h 187h 188h 189h 18Ah 18Bh

17Fh

1FFh

Bank 2

Bank 3

Indirect addr.

(*)

PORTD

(1)

PORTE

(1)

TRISD

(1)

ADRESL

TRISE

(1)

TMR0

OPTION_REG

PIR2

PIE2

RCSTA TXREG

RCREG

CCPR2L

CCPR2H

CCP2CON

ADRESH ADCON0

TXSTA

SPBRG

ADCON1

General Purpose Register

1EFh 1F0h

accesses

A0h - FFh

16Fh 170h

accesses

20h-7Fh

TRISB

PORTB

96 Bytes

SSPCON2

10Ch 10Dh 10Eh 10Fh 110h

18Ch 18Dh 18Eh 18Fh 190h

EEDATA

EEADR

EECON1 EECON2

EEDATH EEADRH

Reserved

(2)

Reserved

(2)

Unimplemented data memory locations, read as '0'.

* Not a physical register.

Note 1: These registers are not implemented on the PIC16F873.

2: These registers are reserved, maintain these registers clear.

120h

1A0h

File

Address

File

Address

File

Address

File

Address

FIGURE 2-4: PIC16F874/873 REGISTER FILE MAP

DS30292D-page 14  1998-2013 Microchip Technology Inc.

PIC16F87X

2.2.2 SPECIAL FUNCTION REGISTERS

The Special Function Registers are registers used by the CPU and peripheral modules for controlling the desired operation of the device. These registers are implemented as static RAM. A list of these registers is given in Table 2-1.

The Special Function Registers can be classified into two sets: core (CPU) and peripheral. Those registers associated with the core functions are described in detail in this section. Those related to the operation of the peripheral features are described in detail in the peripheral features section.

TABLE 2-1: SPECIAL FUNCTION REGISTER SUMMARY

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 0

(3)

00h 01h TMR0 Timer0 Module Register xxxx xxxx 47 02h 03h 04h 05h PORTA 06h PORTB PORTB Data Latch when written: PORTB pins when read xxxx xxxx 31 07h PORTC PORTC Data Latch when written: PORTC pins when read xxxx xxxx 33 08h 09h 0Ah 0Bh 0Ch PIR1 PSPIF 0Dh PIR2 0Eh TMR1L Holding register for the Least Significant Byte of the 16-bit TMR1 Register xxxx xxxx 52 0Fh TMR1H Holding register for the Most Significant Byte of the 16-bit TMR1 Register xxxx xxxx 52 10h T1CON 11h TMR2 Timer2 Module Register 0000 0000 55 12h T2CON 13h SSPBUF Synchronous Serial Port Rece i ve Buffer/Transmit Regi ste r xxxx xxxx 70, 73 14h SSPCON WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 67 15h CCPR1L Capture/Compare/PWM Register1 (LSB) xxxx xxxx 57 16h CCPR1H Capture/Compare/PWM Register1 (MSB) xxxx xxxx 57 17h CCP1CON 18h RCSTA SPEN RX9 SREN CREN ADDEN FERR OERR RX9D 0000 000x 96 19h TXREG USART Transmit Data Register 0000 0000 99 1Ah RCREG USART Receive Data Register 0000 0000 101 1Bh CCPR2L Capture/Compare/PWM Register2 (LSB) xxxx xxxx 57 1Ch CCPR2H Capture/Compare/PWM Register2 (MSB) xxxx xxxx 57 1Dh CCP2CON 1Eh ADRESH A/D Result Register High Byte xxxx xxxx 116 1Fh ADCON0 ADCS1 ADCS0 CHS2 CHS1 CHS0 GO/DONE Legend: x = unknown, u = unchanged, q = value depends on condition, - = unimplemented, read as '0', r = reserved.

Note 1: The upper byte of the program counter is not directly accessible. PCLATH is a holding register for the PC<12:8> whose

INDF Addressing this location uses contents of FSR to address data memory (not a physical register) 0000 0000 27

(3)

PCL Program Counter (PC) Least Significant Byte 0000 0000 26

(3)

STATUS IRP RP1 RP0 TO PD ZDCC0001 1xxx 18

(3)

FSR Indirect Data Memory Address Pointer xxxx xxxx 27

— — PORTA Data Latch when written: PORTA pins when read --0x 0000 29

(4)

PORTD PORTD Data Latch when written: PORTD pins when read xxxx xxxx 35

(4)

PORTE — — — — — RE2 RE1 RE0 ---- -xxx 36

(1,3)

PCLATH — — — Write Buffer for the upper 5 bits of the Program Counter ---0 0000 26

(3)

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 20

Shaded locations are unimplemented, read as ‘0’.

contents are transferred to the upper byte of the program counter.

2: Bits PSPIE and PSPIF are reserved on PIC16F873/876 devices; always maintain these bits clear . 3: These registers can be addressed from any bank. 4: PORTD, PORTE, TRISD, and TRISE are not physically implemented on PIC16F873/876 devices; read as ‘0’. 5: PIR2<6> and PIE2<6> are reserved on these devices; always maintain these bits clear.

(3)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 22

— (5) — EEIF BCLIF — — CCP2IF -r-0 0--0 24

— — T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON --00 0000 51

— TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 55

— — CCP1X CCP1Y CCP1M3 CCP1M2 CCP1M1 CCP1M0 --00 0000 58

— — CCP2X CCP2Y CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 58

—ADON0000 00-0 111

Value on:

POR,

BOR

Details

page:

 1998-2013 Microchip Technology Inc. DS30292D-page 15

PIC16F87X

TABLE 2-1: SPECIAL FUNCTION REGISTER SUMMARY (CONTINUED)

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 1

(3)

80h 81h OPTION_REG RBPU 82h 83h 84h 85h TRISA 86h TRISB PORTB Data Direction Register 1111 1111 31 87h TRISC PORTC Data Direction Register 1111 1111 33 88h 89h 8Ah 8Bh 8Ch PIE1 PSPIE 8Dh PIE2 8Eh PCON 8Fh — Unimplemented — — 90h — Unimplemented — — 91h SSPCON2 GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN 0000 0000 68 92h PR2 Timer2 Period Register 1111 1111 55 93h SSPADD Sy nchr on ous Se ri a l Port (I 94h SSPSTAT SMP CKE D/A 95h — Unimplemented — — 96h — Unimplemented — — 97h — Unimplemented — — 98h TXSTA CSRC TX9 TXEN SYNC 99h SPBRG Baud Rate Generator Register 0000 0000 97 9Ah — Unimplemented — — 9Bh — Unimplemented — — 9Ch — Unimplemented — — 9Dh — Unimplemented — — 9Eh ADRESL A/D Result Register Low Byte xxxx xxxx 116 9Fh ADCON1 ADFM Legend: x = unknown, u = unchanged, q = value depends on condition, - = unimplemented, read as '0', r = reserved.

Note 1: The upper byte of the program counter is not directly accessible. PCLATH is a holding register for the PC<12:8> whose

INDF Addressing this location uses contents of FSR to address data memory (not a physical register) 0000 0000 27

(3)

PCL Program Counter (PC) Least Significant Byte 0000 0000 26

(3)

STATUS IRP RP1 RP0 TO PD ZDCC0001 1xxx 18

(3)

FSR Indirect Data Memory Address Pointer xxxx xxxx 27

(4)

TRISD PORTD Data Direction Register 1111 1111 35

(4)

TRISE IBF OBF IBOV PSPMODE — PORTE Data Direction Bits 0000 -111 37

(1,3)

PCLATH — — — Write Buffer for the upper 5 bits of the Program Counter ---0 0000 26

(3)

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 20

Shaded locations are unimplemented, read as ‘0’.

contents are transferred to the upper byte of the program counter.

INTEDG T0CS T0SE PSA PS2 PS1 PS0 1111 1111 19

— — PORTA Data Direction Register --11 1111 29

(2)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 21 — (5) —EEIEBCLIE— — CCP2IE -r-0 0--0 23 — — — — — —PORBOR ---- --qq 25

C mode) Address Register 0000 0000 73, 74

PSR/WUA BF 0000 0000 66

— BRGH TRMT TX9D 0000 -010 95

— — — PCFG3 PCFG2 PCFG1 PCFG0 0--- 0000 112

Value on:

POR,

BOR

Details

page:

DS30292D-page 16  1998-2013 Microchip Technology Inc.

PIC16F87X

TABLE 2-1: SPECIAL FUNCTION REGISTER SUMMARY (CONTINUED)

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 2

(3)

100h 101h TMR0 Timer0 Module Register xxxx xxxx 47 102h 103h 104h 105h — Unimplemented — — 106h PORTB PORTB Data Latch when written: PORTB pins when read xxxx xxxx 31 107h — Unimplemented — — 108h — Unimplemented — — 109h — Unimplemented — — 10Ah 10Bh 10Ch EEDATA EEPROM Da ta Register Low Byte xxxx xxxx 41 10Dh EEADR EEPROM Address Register Low Byte xxxx xxxx 41 10Eh EEDATH 10Fh EEADRH Bank 3 180h 181h OPTION_REG RBPU INTEDG T0CS T0SE PSA PS2 PS1 PS0 1111 1111 19 182h 183h 184h 185h — Unimplemented — — 186h TRISB PORTB Data Direction Register 1111 1111 31 187h — Unimplemented — — 188h — Unimplemented — — 189h — Unimplemented — — 18Ah 18Bh 18Ch EECON1 EEPGD 18Dh EECON2 EEPROM Control Register2 (not a physical register) ---- ---- 41 18Eh — Reserved maintain clear 0000 0000 — 18Fh — Reserved maintain clear 0000 0000 — Legend: x = unknown, u = unchanged, q = value depends on condition, - = unimplemented, read as '0', r = reserved.

Note 1: The upper byte of the program counter is not directly accessible. PCLATH is a holding register for the PC<12:8> whose

INDF Addressing this location uses contents of FSR to address data memory (not a physical register) 0000 0000 27

(3)

PCL Program Counter's (PC) Least Significant Byte 0000 0000 26

(3)

STATUS IRP RP1 RP0 TO PD ZDCC0001 1xxx 18

(3)

FSR Indirect Data Memory Address Pointer xxxx xxxx 27

(1,3)

PCLATH — — — Write Buffer for the upper 5 bits of the Program Counter ---0 0000 26

(3)

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 20

— — EEPROM Data Register High Byte xxxx xxxx 41 — — — EEPROM Address Register High Byte xxxx xxxx 41

(3)

INDF Addressing this location uses contents of FSR to address data memory (not a physical register) 0000 0000 27

(3)

PCL Program Counter (PC) Least Significant Byte 0000 0000 26

(3)

STATUS IRP RP1 RP0 TO PD ZDCC0001 1xxx 18

(3)

FSR Indirect Data Memory Address Pointer xxxx xxxx 27

(1,3)

PCLATH — — — Write Buffer for the upper 5 bits of the Program Counter ---0 0000 26

(3)

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 20

— — — WRERR WREN WR RD x--- x000 41, 42

Shaded locations are unimplemented, read as ‘0’.

contents are transferred to the upper byte of the program counter.

Value on:

POR,

BOR

Details

page:

 1998-2013 Microchip Technology Inc. DS30292D-page 17

PIC16F87X

2.2.2.1 STATUS Register

The STATUS register contains the arithmetic status of the ALU, the RESET statu s and the b ank sele ct bit s for data memory.

The STATUS register can be the destination for any instruction, as with any other register. If the STATUS register is the destination for an instruction that affects the Z, DC or C bits, then the write to these three bits is disabled. These bit s are set or cleared ac cording to the device logic. Furthermore, the TO writable, therefore, the result of an instruction with the STATUS register as des tination ma y be different than intended.

and PD bits are not

For example, CLRF STATUS will clear the upper three bits and set t he Z bit. T his leaves the STATUS register as 000u u1uu (where u = unchanged).

It is recommended, therefore, that only BCF, BSF, SWAPF and MOVWF instructions are used to alter the STATUS register, because these instructions do not affect the Z, C or D C bits from the ST ATUS register. For other instructions not affecting any status bits, see the “Instruction Set Summary."

Note: The C and DC bits operate as a borrow

and digit borrow bit, respectively, in subtraction. See the SUBLW and SUBWF instructions for examples.

R/W-0 R/W-0 R/W-0 R-1 R-1 R/W-x R/W-x R/W-x

IRP RP1 RP0 TO

bit 7 bit 0

bit 7 IRP: Register Bank Select bit (used for indirect addressing)

1 = Bank 2, 3 (100h - 1FFh) 0 = Bank 0, 1 (00h - FFh)

bit 6-5 RP1:RP0: Register Bank Select bits (used for direct addressing)

11 = Bank 3 (180h - 1FFh) 10 = Bank 2 (100h - 17Fh) 01 = Bank 1 (80h - FFh) 00 = Bank 0 (00h - 7Fh)

Each bank is 128 bytes

bit 4 TO

bit 3 PD

bit 2 Z: Zero bit

bit 1 DC: Digit carry/borrow

bit 0 C: Carry/borrow

: Time-out bit

1 = After power-up, CLRWDT instruction, or SLEEP instruction 0 = A WDT time-out occurred

: Power-down bit

1 = After power-up or by the CLRWDT instruction 0 = By execution of the SLEEP instruction

1 = The result of an arithmetic or logic operation is zero 0 = The result of an arithmetic or logic operation is not zero

bit (ADDWF, ADDLW,SUBLW,SUBWF instructions)

(for borrow

1 = A carry-out from the 4th low order bit of the result occurred 0 = No carry-out from the 4th low order bit of the result

1 = A carry-out from the Most Significant bit of the result occurred 0 = No carry-out from the Most Significant bit of the result occurred

Note: For borrow

, the polarity is reversed)

bit (ADDWF, ADDLW,SUBLW,SUBWF instructions)

, the polarity is reversed. A subtraction is executed by adding the two’s complement of the second operand. For rotate (RRF, RLF) instructions, this bit is loaded with either the high, or low order bit of the source register.

PD ZDCC

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292D-page 18  1998-2013 Microchip Technology Inc.

PIC16F87X

000 001 010 011 100 101 110 111

1 : 2 1 : 4 1 : 8 1 : 16 1 : 32 1 : 64 1 : 128 1 : 256

1 : 1 1 : 2 1 : 4 1 : 8 1 : 16 1 : 32 1 : 64 1 : 128

Bit Value TMR0 Rate WDT Rate

2.2.2.2 OPTION_REG Register

The OPTION_REG Re gister is a re adable and w rit able register , which cont ains various contr ol bits to conf igure the TMR0 prescaler/WDT postscaler (single assignable register k nown als o as th e presca ler), t he Externa l INT Interrupt, TMR0 and the w eak pull-up s on PORTB.

R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1

RBPU INTEDG T0CS T0SE PSA PS2 PS1 PS0

bit 7 bit 0

Note: To achieve a 1:1 prescaler assignment for

the TMR0 register, assign the prescaler to the Watchdog Timer.

bit 7 RBPU

bit 6 INTEDG: Interrupt Edge Select bit

bit 5 T0CS: TMR0 Clock Source Select bit

bit 4 T0SE: TMR0 Source Edge Select bit

bit 3 PSA: Prescaler Assignment bit

bit 2-0 PS2:PS0: Prescaler Rate Select bits

: PORTB Pull-up Enable bit

1 = PORTB pull-ups are disabled 0 = PORTB pull-ups are enabled by individual port latch values

1 = Interrupt on rising edge of RB0/INT pin 0 = Interrupt on falling edge of RB0/INT pin

1 = Transition on RA 4/T0CKI pi n 0 = Internal instruction cycle clock (CLKOUT)

1 = Increment on high-to-low transition on RA4/T0CKI pin 0 = Increment on low-to-high transition on RA4/T0CKI pin

1 = Prescaler is assigned to the WDT 0 = Prescaler is assigned to the Timer0 module

Note: When using low volt age ICSP p rogramming (LVP) and the pull-ups on PORTB are enab led, bit3

 1998-2013 Microchip Technology Inc. DS30292D-page 19

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

in the TRISB register m ust be cleared to disa ble th e pull -up on R B3 and ensu re the p rope r operation of th e device

PIC16F87X

2.2.2.3 INTCON Register

The INTCON Register is a readabl e and writ able register, which contains various enable and flag bits for the TMR0 register overflow, RB Port change and External RB0/INT pin interrupts.

Note: Interrupt flag bits are set when an in terrupt

condition occurs, re gardless of the st a te of its corresponding enable bit or the global enable bit, GIE (INTCON<7>). User software should ensure the appropriate interrupt flag bits are clear prior to enabling an interrupt.

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-x

GIE PEIE T0IE INTE RBIE T0IF INTF RBIF

bit 7 bit 0

bit 7 GIE: Global Interrupt Enable bit

1 = Enables all unmasked interrupts 0 = Disables all interrupts

bit 6 PEIE: Peripheral Interrupt Enable bit

1 = Enables all unmasked peripheral interrupts 0 = Disables all peripheral interrupts

bit 5 T0IE: TMR0 Overflow Interrupt En able bit

1 = Enables the TMR0 interrupt 0 = Disables the TMR0 in terrupt

bit 4 INTE: RB0/INT External Interrupt Enable bit

1 = Enables the RB0/INT external interrupt 0 = Disables the RB0/INT external interrupt

bit 3 RBIE: RB Port Change Interrupt Enable bit

1 = Enables the RB port change interrupt 0 = Disables the RB port change interrupt

bit 2 T0IF: TMR0 Overflow Interrupt Flag bit

1 = TMR0 register has overflowed (must be clea red in software) 0 = TMR0 register did not overflow

bit 1 INTF: RB0/INT External Interrupt Flag bit

1 = The RB0/INT external interru pt occurred (must be cleared in software) 0 = The RB0/INT external interrupt did not occur

bit 0 RBIF: RB Port Change Interrupt Flag bit

1 = At least one of the RB 7:RB4 pins changed st ate; a mismatch cond iti on wi ll c on t in ue t o se t

the bit. Reading PORTB will end the mismatch condition and allow the bit to be cleared (must be cleared in s oftware).

0 = None of the RB7:RB4 pins have changed state

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292D-page 20  1998-2013 Microchip Technology Inc.

2.2.2.4 PIE1 Register

The PIE1 register cont ains the ind ividual enab le bits for the periph eral interrupts.

Note: Bit PEIE (INTCON<6>) must be set to

enable any peripheral interrupt.

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

(1)

PSPIE

bit 7 bit 0

bit 7 PSPIE

1 = Enables the PSP read/write interrupt 0 = Disables the PSP read/write interrupt

bit 6 ADIE: A/D Converter Interrupt Enable bit

1 = Enables the A/D converter interrupt 0 = Disables the A/D converter interrupt

bit 5 RCIE: USART Receive Interrupt Enable bit

1 = Enables the USART receive interrupt 0 = Disables the USART receive interrupt

bit 4 TXIE: USART Transmit Interrupt Enable bit

1 = Enables the USART transmit interrupt 0 = Disables the USART transmit interrupt

bit 3 SSPIE: Synchronous Serial Port Interrupt Enable bit

1 = Enables the SSP interrupt 0 = Disables the SSP inte rrupt

bit 2 CCP1IE: CCP1 Interrupt Enable bit

1 = Enables the CCP1 interrupt 0 = Disables the CCP1 interrupt

bit 1 TMR2IE: TMR2 to PR2 Match Interrupt Enable bit

1 = Enables the TMR2 to PR2 match interrupt 0 = Disables the TMR2 to PR2 match interrupt

bit 0 TMR1IE: TMR1 Overflow Interrupt Enable bit

1 = Enables the TMR1 overflow interrupt 0 = Disables the TMR1 overflow interrupt

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE

(1)

: Parallel Slave Port Read/Write Interrupt Enable bit

PIC16F87X

Note 1: PSPIE is reserved on PIC16F873/876 devices; always maintain this bit clear.

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 1998-2013 Microchip Technology Inc. DS30292D-page 21

PIC16F87X

2.2.2.5 PIR1 Register

The PIR1 register contains the individual flag bits for the periph eral interrupts.

R/W-0 R/W-0 R-0 R-0 R/W-0 R/W-0 R/W-0 R/W-0

(1)

PSPIF

bit 7 bit 0

bit 7 PSPIF

bit 6 ADIF: A/D Converter Interrupt Flag bit

bit 5 RCIF: USART Receive Interrupt Flag bit

bit 4 TXIF: USART Transmit Interrupt Flag bit

bit 3 SSPIF: Synchronous Serial Port (SSP) Interrupt Flag

bit 2 CCP1IF: CCP1 Interrupt Flag bit

bit 1 TMR2IF: TMR2 to PR2 Match Interrupt Flag bit

bit 0 TMR1IF: TMR1 Overflow Interrupt Flag bit

(1)

1 = A read or a write operation has taken place (must be cleared in software) 0 = No read or write has occurred

1 = An A/D conversion completed 0 = The A/D conversion is not complete

1 = The USART receive buffer is full 0 = The USART receive buffer is empty

1 = The USART transmit buffer is empty 0 = The USART transmit buffer is full

1 = The SSP interrupt condition has occurred, and must be cleared in software b efore returning

from the Interrupt Service Routine. The conditions that will set this bit are:

• SPI

• I

•I

0 = No SSP interrupt condition has occurred.

Capture mode:

1 = A TMR1 register capture occurred (must be cleared in software) 0 = No TMR1 register capture occurred

Compare mode:

1 = A TMR1 register compare match occ urred (must be cleared in software) 0 = No TMR1 register compare match occurred

PWM mode: Unused in this mode

1 = TMR2 to PR2 match occurred (must be cleared in software) 0 = No TMR2 to PR2 match occurred

1 = TMR1 register overflowed (must be cleared in software) 0 = TMR1 register did not overflow

Note 1: PSPIF is reserved on PIC16F873/876 devices; always maintain this bit clear.

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF

: Parallel Slave Port Read/Write Interrupt Flag bit

- A transmission/reception has taken place.

C Slave

- A transmission/reception has taken place.

C Master

- A transmission/reception has taken place.

- The initiated START condition was completed by the SSP module.

- The initiated STOP condition was completed by the SSP module.

- The initiated Restart condition was completed by the SSP module.

- The initiated Acknowledge condition was completed by the SSP module.

- A START condition occ urred whil e the SSP module was idle (Mul ti-Master sy stem).

- A STOP condition occurred wh ile th e SSP module was idle (Multi-Master system).

Note: Interrupt flag bits are set when an interrupt

condition occurs, regardless of the state of its corresponding enable bit or the global enable bit, GIE (INTCON<7>). User software should en sure the approp riate interrup t bits are cle ar pri or to en ab li ng an interrupt.

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292D-page 22  1998-2013 Microchip Technology Inc.

2.2.2.6 PIE2 Register

The PIE2 register cont ains the ind ividual enab le bits for the CCP2 peripheral interrupt, the SSP bus collision interrupt, and the EEPROM write operation interrupt.

U-0 R/W-0 U-0 R/W-0 R/W-0 U-0 U-0 R/W-0

— Reserved — EEIE BCLIE — — CCP2IE

bit 7 bit 0

bit 7 Unimplemented: Read as '0' bit 6 Reserved: Always maintain this bit clear bit 5 Unimplemented: Read as '0' bit 4 EEIE: EEPROM Write Operation Interrupt Enable

1 = Enable EE Write Interrupt 0 = Disable EE Write Interr upt

bit 3 BCLIE: Bus Collision Interrupt Enable

1 = Enable Bus Collision Interrupt 0 = Disable Bus Collision Interrupt

bit 2-1 Unimplemented: Read as '0' bit 0 CCP2IE: CCP2 Interrupt Enable bit

1 = Enables the CCP2 interrupt 0 = Disables the CCP2 interrupt

PIC16F87X

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 1998-2013 Microchip Technology Inc. DS30292D-page 23

PIC16F87X

2.2.2.7 PIR2 Register

The PIR2 register contains the flag bits for the CCP2 interrupt, the SSP bus collision interrupt and the EEPROM write operation interrupt.

Note: Interrupt flag bits are set when an in terrupt

U-0 R/W-0 U-0 R/W-0 R/W-0 U-0 U-0 R/W-0

— Reserved — EEIF BCLIF — — CCP2IF

bit 7 bit 0

bit 7 Unimplemented: Read as '0' bit 6 Reserved: Always maintain this bit clear bit 5 Unimplemented: Read as '0' bit 4 EEIF: EEPROM Write Operation Interrupt Flag bit

1 = The write operation completed (must be cleared in software) 0 = The write operation is not complete or has not been started

bit 3 BCLIF: Bus Collision Interrupt Flag bit

1 = A bus collision has occurred in the SSP, when configured for I2C Master mode 0 = No bus collision has occurred

bit 2-1 Unimplemented: Read as '0' bit 0 CCP2IF: CCP2 Interrupt Flag bit

Capture mode:

1 = A TMR1 register capture occurred (must be clea red in software) 0 = No TMR1 regi ster capture occurred

Compare mode:

1 = A TMR1 register compare match occurred (must be cleared in software) 0 = No TMR1 register compare match occurred

PWM mode: Unused

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292D-page 24  1998-2013 Microchip Technology Inc.

PIC16F87X

2.2.2.8 PCON Register

The Power Control (PCON) Register contains flag bits to allow differentiation between a Power-on Reset (POR), a Brown-out Reset (BOR), a Watchdog Reset (WDT), and an external MCLR

Reset.

Note: BOR is unknown on P OR. It mus t be set by

the user and checked on subsequent RESETS to see if BOR is clear, indicating a brown-out has occurre d. The BOR st atus bit is a “don’t care” and is n ot pre dictable if the brown-out circuit is disabled (by clearing the BODEN bit in the configuration word).

U-0 U-0 U-0 U-0 U-0 U-0 R/W-0 R/W-1

— — — — — —PORBOR

bit 7 bit 0

bit 7-2 Unimplemented: Read as '0' bit 1 POR

bit 0 BOR

: Power-on Reset Status bit

1 = No Power-on Reset occurred 0 = A Power-on Reset occurred (must be set in software after a Power-on Reset occurs)

: Brown-out Reset Status bit

1 = No Brown-out Reset occurred 0 = A Brown-out Reset occurred (must be set in software after a Brown-out Reset occurs)

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 1998-2013 Microchip Technology Inc. DS30292D-page 25

PIC16F87X

12 8 7 0

PCLATH<4:0>

PCLATH

Instruction with

ALU

GOTO,CALL

Opcode <10:0>

12 11 10 0

PCLATH<4:3>

PCH PCL

PCLATH

PCH PCL

PCL as Destination

ORG 0x500 BCF PCLATH,4 BSF PCLATH,3 ;Select page 1

;(800h-FFFh) CALL SUB1_P1 ;Call subroutine in : ;page 1 (800h-FFFh) : ORG 0x900 ;page 1 (800h-FFFh)

SUB1_P1

: ;called subroutine

;page 1 (800h-FFFh) : RETURN ;return to

;Call subroutine

;in page 0

;(000h-7FFh)

2.3 PCL and PCLATH

The program counter (PC) is 13-bits wid e. The low byte comes from the PCL register, which is a readable and writable register. The upper bits (PC<12:8>) are not readable, but are indirectly writable through the PCLA TH reg is ter. On any RESET, the upper bi t s of the PC will be cleared. Fig ure2-5 shows the two situations for the loading o f the PC. The up per ex ample in th e figure shows how the PC is loaded on a write to PCL (PCLATH<4:0>  PCH). The lower exam pl e i n th e fi gure shows how the PC is loaded during a CALL or GOTO instruction (PCLATH<4:3>  PCH).

FIGURE 2-5: LOADING OF PC IN

DIFFERENT SITUATIONS

2.3.1 COMP UT ED GOTO

A computed GOTO is accomplish ed by adding an of fs et to the progr am counter (ADDWF PCL). When doing a table read using a computed GOTO method, care should be exercise d i f the t able loca tio n cros ses a PCL memory boundary (each 256 byte block). Refer to the application note, “Implementing a Table Read" (AN556).

Note 1: There are no status bits to indicate stack

overflow or stack underflow conditions.

2: There are no instructions/mnemonics

called PUSH or POP. These are actions that occur from the execution of the CALL, RETURN, RETLW and RETFIE instructions, or the vectoring to an interrupt address.

2.4 Program Memory Paging

All PIC16F87X devices are capable of addressing a continuous 8K word block of program memory. The CALL and GOTO instructions provide only 11 bits of address to allow branching within any 2K program memory page. When doing a CALL or GOTO instruction, the upper 2 bits of the address are provided by PCLATH<4:3>. When doing a CALL or GOTO instruction, the user must ensu re tha t the page select bit s are programmed so that the desired program memory page is addressed. If a return from a CALL instruction (or interrupt) is execute d, the entire 13-bit PC is popped off the stack. Therefore, manipulation of the PCLA TH<4:3> bits is not required for the return instructions (which POPs the address from the stack).

Note: The contents of the PCLATH register are

unchanged after a RETURN or RETFIE instruction is executed. The user must rewrite the contents of the PCLATH register for any subsequent subroutine calls or GOTO instructions.

Example 2-1 shows the calling of a subroutine in page 1 of the prog ram memory. This example assumes that PCLATH is saved and restored by the Interrupt Service Routine

EXAMPLE 2-1: CALL OF A SUBROUTINE

(if interrupts are used).

IN PAGE 1 FROM PAGE 0

2.3.2 STACK

The PIC16F87X family has an 8-level deep x 13-bit wide hardware stack. The stack space is not part of either program or data space and the stack pointer is not readable or writable. The PC is PUSHed onto the stack when a CALL instruction is executed, or an interrupt causes a branch. The stack is POPed in the event of a RETURN,RETLW or a RETFIE instruction execution. PCLA TH is not affected by a PUSH or POP operation.

The stack opera tes as a circular buf fer . This means that after the st ack h as be en PUSHed eigh t time s, th e nin th push overwrites the v alue tha t was stored fro m the first push. The tenth pus h ov erwrites the second p us h (an d so on).

DS30292D-page 26  1998-2013 Microchip Technology Inc.

PIC16F87X

MOVLW 0x20 ;initialize pointer MOVWF FSR ;to RAM

NEXT CLRF INDF ;clear INDF register

INCF FSR,F ;inc pointer BTFSS FSR,4 ;all done? GOTO NEXT ;no clear next

CONTINUE

: ;yes continue

Note 1: For register file map detail, see Figure 2-3.

Data Memory

(1)

Indirect AddressingDirect Addressing

Bank Select Location Select

RP1:RP 0 6

From Opcode

IRP FSR register

Bank Select

Location Select

00 01 10 11

Bank 0 Bank 1 Bank 2 Bank 3

FFh

80h

7Fh

00h

17Fh

100h

1FFh

180h

2.5 Indirect Addressing, INDF and FSR Registers

The INDF register is not a physi cal register. Addressing the INDF register will cause indirect addressing.

Indirect addressing is possible by using the INDF register. Any instruc tion using the INDF register actual ly accesses the register pointed to by the File Sele ct Register, FSR. Reading the INDF register itself, indirectly (FSR = '0') will read 00h. Writing to the INDF register indirectly result s in a no op era tion (although status bits may be affected ). An eff ective 9- bit add ress is obt ained by concatenating the 8 -bit FSR regi ster and the IRP b it (STAT US<7>), as shown in Figure 2-6.

FIGURE 2-6: DIRECT/INDIRECT ADDRESSING

A simple program to clear RAM locations 20h-2Fh using indirect addressing is shown in Example 2-2.

EXAMPLE 2-2: INDIRECT ADDRESSING

 1998-2013 Microchip Technology Inc. DS30292D-page 27

PIC16F87X

NOTES:

DS30292D-page 28  1998-2013 Microchip Technology Inc.

PIC16F87X

BCF STATUS, RP0 ; BCF STATUS, RP1 ; Bank0 CLRF PORTA ; Initialize PORTA by

; clearing output

; data latches BSF STATUS, RP0 ; Select Bank 1 MOVLW 0x06 ; Configure all pins MOVWF ADCON1 ; as digital inputs MOVLW 0xCF ; Value used to

; initialize data

; direction MOVWF TRISA ; Set RA<3:0> as inputs

; RA<5:4> as outputs

; TRISA<7:6>are always

; read as '0'.

Data Bus

WR Port

WR TRIS

Data Latch

TRIS Latch

RD Port

VDD

I/O pin

(1)

Note 1: I/O pins have protection diodes to VDD and VSS.

Analog Input Mode

TTL Input Buffer

To A/D Converter

TRIS

Data Bus

WR Port

WR TRIS

RD Port

Data Latch

TRIS Latch

Schmitt Trigger Input Buffer

I/O pin

(1)

TMR0 Clock Input

Note 1: I/O pin has protection diodes to VSS only.

TRIS

3.0 I/O PORTS

Some pins for th ese I/O ports are multiplexed with an alternate function for the peripheral features on the device. In general, when a peripheral is enabled, that pin may not be used as a general purpose I/O pin.

Additional inform atio n o n I/O ports ma y b e f oun d in the

MCU Mid-Range Reference Manual, (DS33023).

PIC

3.1 PORTA and the TRISA Register

PORTA is a 6-bit wide, bi-directional port. The corresponding data direction register is TRISA. Setting a TRISA bit (= 1) wi ll make the correspondin g PORTA pin an input (i.e., put the corresponding output driver in a Hi-Impedance mode). Clearing a TRISA bit (= 0) will make the correspondin g POR TA pin an output (i.e., put the contents of the output latch on the selected pin).

Reading the PORTA register reads the status of the pins, whereas writing to i t will write to the port latch. All write operations are read-modify-write operations. Therefore, a write to a port implies that the port pins are read, the value is modified and then written to the port data latch.

Pin RA4 is multiplexed with the Timer0 module clock input to become the RA4/T0CKI pin. The RA4/T0CKI pin is a Schmitt Trigger input and an open drain outpu t. All other PORTA pins have TTL input levels and full CMOS output drivers.

Other PORTA pins are multiplexed with analog inputs and analog V selected by clearing/setting the control bits in the ADCON1 register (A/D Control Register1).

Note: On a Power-on Reset, these pins are con-

The TRISA register controls the direction of the RA pins, even when they are be ing us ed as ana log inputs. The user must ensure the bits in the TRISA regi ster are maintained se t when using t hem as analog inputs.

EXAMPLE 3-1: INITIALIZING PORTA

 1998-2013 Microchip Technology Inc. DS30292D-page 29

REF input. The operation of each pin is

figured as analog inputs and read as '0'.

FIGURE 3-1: BLOCK DIAGRAM OF

RA3:RA0 AND RA5 PINS

FIGURE 3-2: BLOCK DIAGRAM OF

RA4/T0CKI PIN

PIC16F87X

TABLE 3-1: PORTA FUNCTIONS

Name Bit# Buffer Function

RA0/AN0 bit0 TTL Input/output or analog input. RA1/AN1 bit1 TTL Input/output or analog input. RA2/AN2 bit2 TTL Input/output or analog input. RA3/AN3/V RA4/T0CKI bit4 ST Input/output or external clock input for Ti mer0. Output is open drain type. RA5/SS/AN4 bit5 TTL Input/output or slave select input for synchronous serial port or analog input. Legend: TTL = TTL input, ST = Schmitt Trigger input

TABLE 3-2: SUMMARY OF REGISTERS ASSOCIATED WITH PORTA

REF bit3 TTL Input/output or analog input or VREF.

Value on:

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

05h PORTA 85h TRISA — — PORTA Data Directio n Re gis ter 9Fh ADCON1 ADFM — — — PCFG3 PCFG2 PCFG1 PCFG0

Legend: x = unknown, u = unchanged, - = unimplemented locations read as '0'.

Shaded cells are not used by PORTA.

Note: When using the SSP module in SPI Slave mode and SS enabled, the A/D converter must be set to one of

the following modes, where PCFG3:PCFG0 = 0100,0101, 011x, 1101, 1110, 1111.

— — RA5 RA4 RA3 RA2 RA1 RA0

POR,

BOR

--0x 0000 --0u 0000

--11 1111 --11 1111

--0- 0000 --0- 0000

Value on al l

other

RESETS

DS30292D-page 30  1998-2013 Microchip Technology Inc.

PIC16F87X

Data Latch

RBPU

(2)

Data Bus

WR Port

WR TRIS

RD TRIS

RD Port

Weak Pull-up

RD Port

RB0/INT

I/O pin

(1)

TTL Input Buffer

Schmitt Trigger Buffer

TRIS Latch

Note 1: I/O pins have diode protection to V

DD and VSS.

2: To enable weak pull-ups, set the appropriate TRIS

bit(s) and clear the RBPU

bit (OPTION_REG<7>).

RB3/PGM

Data Latch

From other

RBPU

(2)

I/O

Data Bus

WR Port

WR TRIS

Set RBIF

TRIS Latch

RD TRIS

RD Port

RB7:RB4 pins

Weak Pull-up

RD Port

Latch

TTL Input Buffer

(1)

Buffer

RB7:RB6

Note 1: I/O pins have diode protec tion to V

DD and VSS.

2: To enable weak pull-ups, set the app ropriate TRIS

bit(s) and clear the RBPU

bit (OPTION_REG<7>).

In Serial Programming Mode

3.2 PORTB and the TRISB Register

PORTB is an 8-bit wide, bi-directional port. The corresponding data direction register is TRISB. Setting a TRISB bit (= 1) will mak e the corresponding PORTB pin an input (i.e., put the corresponding output driver in a Hi-Impedance mode). Clearing a TRISB bit (= 0) will make the corresponding POR TB pin an output (i.e. , put the contents of the output latch on the selected pin).

Three pins of PORTB are multiplexed with the Low Voltage Programming function: RB3/PGM, RB6/PGC and RB7/PGD. The alternate functions of these pins are described in the S p ec ial Features Section.

Each of the PORTB pi ns has a w eak i nternal pul l-up. A single control bit can turn on all the pull-ups. This is performed by clearing bit RBPU weak pull-up is automatically turned off when the port pin is configured as an output. The pull-ups are disabled on a Power-on Reset.

FIGURE 3-3: BLOCK DIAGRAM OF

(OPTION_REG<7>). The

RB3:RB0 PINS

This interrupt can wake the device from SLEEP. The user, in the Interrupt Service Routine, can clear the interrupt in the following manner:

a) Any read or write of PORTB. This will end the

mismatch condition.

b) Clear flag bit RBIF. A mismatch c ond it i on wi ll cont i n ue to s et f lag bi t RB IF.

Reading PORTB will end the mismatch condition and allow flag bit RBIF to be cleared.

The interrupt-on-change feature is recommended for wake-up on key depression operation and operations where PORTB is only used for the interrupt-on-change feature. Polling of PORTB is not recommended while using the interrupt-on-change feature.

This interrupt-on-mismatch feature, together with software configureable pull-ups on these four pins, allow easy interface to a keypad and make it possible for wake-up on key depression. Refer to the Embedded Control Handbook, “Implementing Wake-up on Key Strokes” (AN552).

RB0/INT is an ext ernal i nterrupt input pin a nd is confi gured using the INTEDG bit (OPTION_REG<6>).

RB0/INT is discussed in detail in Section 12.10.1.

Four of the PORTB pins, RB7:RB4, have an interrupton-change feature. Only pins configured as inputs can cause this interrupt to occur (i.e., any RB7:RB4 pin configured as an output is excluded from the interrupton-change comparison). The input pins (of RB7:RB4) are compared with the old value latched on the last read of PORTB. The “mismatch” outputs of RB7:RB4 are OR’ed together to generate the RB Port Change Interrupt with flag bit RBIF (INTCON<0>).

 1998-2013 Microchip Technology Inc. DS30292D-page 31

FIGURE 3-4: BLOCK DIAGRAM OF

RB7:RB4 PINS

PIC16F87X

TABLE 3-3: PORTB FUNCTIONS

Name Bit# Buffer Function

RB0/INT bit0 TTL/ST

RB1 bit1 TTL Input/output pin. Internal software programmable weak pull-up. RB2 bit2 TTL Input/output pin. Internal software programmable weak pull-up.

(3)

RB3/PGM

RB4 bit4 TTL Input/output pin (with in terrupt-on-c hange). I nternal soft ware progra mmable

RB5 bit5 TTL Input/output pin (with in terrupt-on-c hange). I nternal soft ware progra mmable

RB6/PGC bit6 TTL/ST

RB7/PGD bit7 TTL/ST

Legend: TTL = TTL input, ST = Schmitt Trigger input

Note 1: This buffer is a Schmitt Trigger input when configured as the external interrupt.

2: This buffer is a Schmitt Trigger input when used in Serial Programming mode. 3: Low Voltage ICSP Programming (LVP) is enabled by default, which disables the RB3 I/O function. LVP

bit3 TTL Input/output pin or programming pin in LVP mode. Internal software

must be disabled to enable RB3 as an I/O pin and allow maximum compatibility to the other 28-pin and 40-pin mid-range devices.

(1)

Input/output pin or external interrupt input. Internal software programmable weak pull-up.

programmable weak pull-up.

weak pull-up.

(2)

Input/output pin (with interrupt-on-change) or In-Circuit Debugger pin. Internal software programmable weak pull-up. Serial programming clock.

(2)

Input/output pin (with interrupt-on-change) or In-Circuit Debugger pin. Internal software programmable weak pull-up. Serial programming data.

TABLE 3-4: SUMMARY OF REGISTERS ASSOCIATED WITH PORTB

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

06h, 106h PORTB RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 86h, 186h T RISB PORTB Data Direction Register 81h, 181h OPTION_REG RBPU INTEDG T0CS T0SE PSA PS2 PS1 PS0 Legend: x = unknown, u = unchanged. Shaded cells are not used by PORTB.

Value on:

POR,

BOR

xxxx xxxx uuuu uuuu

1111 1111 1111 1111

Value on

all other

RESETS

DS30292D-page 32  1998-2013 Microchip Technology Inc.

PIC16F87X

Port/Peripheral Select

(2)

Data Bus WR

Port

WR TRIS

Data Latch

TRIS Latch

Schmitt Trigger

QD Q

Peripheral Data Out

QD Q

VSS

Port

Peripheral OE

(3)

Peripheral Input

I/O pin

(1)

Note 1: I/O pins have diode protection to VDD and VSS.

2: Port/Peripheral select signal selects between port

data and peripheral output.

3: Peripheral OE (output enable) is only activated if

peripheral select is active.

TRIS

Port/Peripheral Select

(2)

Data Bus WR

Port

WR TRIS

Data Latch

TRIS Latch

Schmitt Trigger

QD Q

Peripheral Data Out

QD Q

Vss

Port

Peripheral OE

(3)

SSPl Input

I/O pin

(1)

Note 1: I/O pins have diode protection to VDD and VSS.

2: Port/Peripheral select signal selects between port data

and peripheral outpu t.

3: Peripheral OE (output enable) is only activated if

peripheral select is active.

CKE

SSPSTAT<6>

Schmitt Trigger with SMBus levels

TRIS

3.3 PORTC and the TRISC Register

PORTC is an 8-bit wide, bi-directional port. The corresponding data direction register is TRISC. Setting a TRISC bit (= 1) will make the corresponding PORTC pin an input (i.e., put the corresponding output driver in a Hi-Impedance mode). Clearing a TRISC bit (= 0) will make the correspondi ng PORTC pin an output (i.e., p ut the contents of the output latch on the selected pin).

PORTC is mul tiplexed with s everal peri pheral function s (Table 3-5). PORTC pins have Schmitt Trigger input buffers.

When the I pins can be configured with normal I SMBus levels by using the CKE bit (SSPSTAT<6>).

When enabling peripheral functions, care should be taken in defining TRIS bit s fo r each POR TC pin. Some peripherals override the TRIS bit to make a pin an output, while other peripherals override the TRIS bit to make a pin an input. Since the TRIS bit override is in effect while the peripheral is enabled, read-modifywrite instructions (BSF, BCF, XORWF) with TRISC as destination, should be avoided. The user should refer to the corresponding peripheral section for the correct TRIS bit settings.

C module is enabled, the PORTC<4:3>

C levels, or with

FIGURE 3-6: PORTC BLOCK DIAGRAM

(PERIPHERAL OUTPUT OVERRIDE) RC<4:3>

FIGURE 3-5: PORTC BLOCK DIAGRAM

(PERIPHERAL OUTPUT OVERRIDE) RC<2:0>, RC<7:5>

 1998-2013 Microchip Technology Inc. DS30292D-page 33

PIC16F87X

TABLE 3-5: PORTC FUNCTIONS

Name Bit# Buffer Type Function

RC0/T1OSO/T1CKI bit0 ST Input/output port pin or Ti mer1 oscillator output/Timer1 clock input. RC1/T1OSI/CCP2 bit1 ST Input/output port pin or Timer1 oscillator input or Capture2 input/

Compare2 output/PWM2 output.

RC2/CCP1 bit2 ST Input/output port pin or Capture1 input/Compare1 output/

PWM1 output.

RC3/SCK/SCL bit3 ST RC3 can also be the synchronous serial clock for both SPI

RC4/SDI/SDA bit4 ST RC4 can also be the SPI Data In (SPI mode) or data I/O (I2C mode). RC5/SDO bit5 ST Input/output port pin or Synchronous Serial Port data output. RC6/TX/CK bit6 ST Input/output port pin or USART Asynchronous Transmit or

RC7/RX/DT bit7 ST Input/output port pin or USART Asynchronous Receive or

Legend: ST = Schmitt Trigger input

TABLE 3-6: SUMMARY OF REGISTERS ASSOCIATED WITH PORTC

C modes.

and I

Synchronous Clock.

Synchronous Data.

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

07h PORTC RC7 RC6 RC5 RC4 RC3 RC2 RC1 RC0 87h TRISC PORTC Data Direction Register Legend: x = unknown, u = unchanged

Value on:

POR,

BOR

xxxx xxxx uuuu uuuu

1111 1111 1111 1111

Value on all

other

RESETS

DS30292D-page 34  1998-2013 Microchip Technology Inc.

PIC16F87X

Data Bus

WR Port

WR TRIS

RD Port

Data Latch

TRIS Latch

Schmitt Trigger Input Buffer

I/O pin

(1)

Note 1: I/O pins have protection diodes to VDD and VSS.

TRIS

3.4 PORTD and TRISD Registers

PORTD and TRISD are not implemented on the PIC16F873 or PIC16F876.

PORTD is an 8-bit port with Schmitt Trigger input buffers. Each pin is in dividually co nfigureable as a n input or output.

PORTD can be configured as an 8-bit wide microprocessor port (parallel slave p ort) by setting c ontrol bit PSPMODE (TRISE<4>). In this mode, the input buffe rs are TTL.

FIGURE 3-7: PORTD BLOCK DIAGRAM

(IN I/O PORT MODE)

TABLE 3-7: PORTD FUNCTIONS

Name Bit# Buffer Type Function

RD0/PSP0 bit0 ST/TTL RD1/PSP1 bit1 ST/TTL RD2/PSP2 bit2 ST/TTL RD3/PSP3 bit3 ST/TTL RD4/PSP4 bit4 ST/TTL RD5/PSP5 bit5 ST/TTL RD6/PSP6 bit6 ST/TTL RD7/PSP7 bit7 ST/TTL

(1) (1) (1) (1) (1) (1) (1) (1)

Input/output port pin or parallel slave port bit0. Input/output port pin or parallel slave port bit1. Input/output port pin or parallel slave port bit2. Input/output port pin or parallel slave port bit3. Input/output port pin or parallel slave port bit4. Input/output port pin or parallel slave port bit5. Input/output port pin or parallel slave port bit6. Input/output port pin or parallel slave port bit7.

Legend: ST = Schmitt Trigger input, TTL = TTL input

Note 1: Input buffers are Schmitt Triggers when in I/O mode and TTL buffers when in Parallel Slave Port mode.

T ABLE 3-8: SUMMARY OF REGISTERS ASSOCIATED WITH PORTD

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

08h PORTD RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0 88h TRISD PORTD Data Direction Register 89h TRISE IBF OBF IBOV PSPMODE — PORTE Data Direc tio n Bit s Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by PORTD.

Value on:

POR,

BOR

xxxx xxxx uuuu uuuu

1111 1111 1111 1111

0000 -111 0000 -111

Value on

all other

RESETS

 1998-2013 Microchip Technology Inc. DS30292D-page 35

PIC16F87X

Data Bus

WR Port

WR TRIS

RD Port

Data Latch

TRIS Latch

Schmitt Trigger Input Buffer

I/O pin

(1)

Note 1: I/O pins have protection diodes to VDD and VSS.

TRIS

3.5 PORTE and TRISE Register

PORTE and TRISE are not implemented on the PIC16F873 or PIC16F876.

PORTE has three pins (RE0/RD and RE2/CS

/AN7) which are ind iv idu all y co nfi gure able as inputs or outputs. These pins have Schmitt Trigger input buffers.

The PORTE pins become the I/O control inputs for the microprocessor port when bit PSPMODE (TRISE<4>) is set. In this mode, the user must make certain that the TRISE<2:0> bits are set, and that the pins are configured as digital input s. Also ensure that ADCON1 is co nfigured for digital I/O. In this mo de, th e in put bu ffers are TTL.

PORTE pins are multiplexed with analog inputs. When selected for analog input, these pins will read as '0's.

TRISE controls the direction of the RE pins, even when they are being used as analog inputs. The user must make sure to keep the pins configured as inputs when using them as analog inputs.

Note: On a Power-on Reset, these pins are con-

figured as analog inputs, and read as ‘0’.

/AN5, RE1/WR/AN6,

FIGURE 3-8: PORTE BLOCK DIAGRAM

(IN I/O PORT MODE)

TABLE 3-9: PORTE FUNCTIONS

Name Bit# Buffer Type Function

I/O port pin or read control input in Parallel Slave Port mode or analog input: RD

RE0/RD

/AN5 bit0 ST/TTL

(1)

1 =Idle 0 = Read operation. Contents of PORTD register are output to PORTD

I/O pins (if chip selected)

I/O port pin or write control input in Parallel S lave Port mode or analog input: WR

RE1/WR/AN6 bit1 ST/TTL

(1)

1 =Idle 0 = Write operation. Value of PORTD I/O pins is latched into PORTD

I/O port pin or ch ip sele ct co ntrol in put in Para llel Sl ave Port m ode or an alog in put:

RE2/CS

/AN7 bit2 ST/TTL

(1)

1 = Device is not selected 0 = Device is selected

Legend: ST = Schmitt Trigger input, TTL = TTL input

Note 1: Input buffers are Schmitt Triggers when in I/O mode and TTL buffers when in Parallel Slave Port mode.

TABLE 3-10: SUMMARY OF REGISTERS ASSOCIATED WITH PORTE

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

09h PORTE 89h TRISE 9Fh ADCON1

Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by PORTE.

ADFM — — — PCFG3 PCFG2 PCFG1 PCFG0 --0- 0000 --0- 0000

Val ue on:

POR, BOR

— — — — — RE2 RE1 RE0 ---- -xxx ---- -uuu

IBF OBF IBOV PSPMODE — PORT E D a ta Dir e ction Bits 0000 -111 0000 -111

Value on all other RESETS

DS30292D-page 36  1998-2013 Microchip Technology Inc.

R-0 R-0 R/W-0 R/W-0 U-0 R/W-1 R/W-1 R/W-1 IBF OBF IBOV PSPMODE

bit 7 bit 0

Parallel Slave Port Status/Control Bits:

bit 7 IBF: Input Buffer Full Status bit

1 = A word has been received and is waiting to be read by the CPU 0 = No word has been received

bit 6 OBF: Output Buffer Full Status bit

1 = The output buffer still holds a previously written word 0 = The output buffer has been read

bit 5 IBOV: Input Buffer Overflow Detect bit (in Microprocessor mode)

1 = A write occurred when a previously input word has not been read (must be cleared in

software)

0 = No overflow occurred

bit 4 PSPMODE: Parallel Slave Port Mode Select bit

1 = PORTD functions in Parallel Slave Port mode 0 = PORTD functions in general purpose I/O mode

bit 3 Unimplemented: Read as '0 '

PORTE Data Direction Bits:

bit 2 Bit2: Direction Control bit for pin RE2/CS/AN7

1 = Input 0 = Output

bit 1 Bit1: Direction Control bit for pin RE1/WR

1 = Input 0 = Output

bit 0 Bit0: Direction Control bit for pin RE0/RD

1 = Input 0 = Output

/AN6

/AN5

PIC16F87X

— Bit2 Bit1 Bit0

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 1998-2013 Microchip Technology Inc. DS30292D-page 37

PIC16F87X

Data Bus

WR Port

RDx

Port

One bit of PORTD

Set Interrupt Flag PSPIF(PIR1<7>)

Read

Chip Select

Write

TTL

Note 1: I/O pins have protection diodes to V

DD and VSS.

3.6 Parallel Slave Port

The Parallel Slave Port (PSP) is not implemented on the PIC16F873 or PIC16F876.

PORTD operates as an 8 -bit wide Parallel Slav e Port or microprocessor port, when control bit PSPMODE (TRISE<4>) is set. I n Sl av e mo de, it is asynchro nou sl y readable and writa ble by the ex ternal world throu gh RD control input pin RE0/RD and WR control input pin RE1/WR

The PSP can directly interfac e to an 8-bit m icroproce ssor data bus. The external microprocessor can read or write the PORTD latch as an 8-bit latch. Setting bit PSPMODE enables port pin RE0/RD input, RE1/WR to be the WR input and RE2/CS to be the CS responding data direction bits of the TRISE register (TRISE<2:0>) must be configured as inputs (set). The A/D port configuration bits PCFG3:PCFG0 (ADCON1<3:0>) must be set to configure pins RE2:RE0 as digital I/O.

There are actually two 8-bit latches: one for data output, and one for data input. The user writes 8-bit data to the PORTD data latch and reads data from the port pin latch (note that they ha ve the same address). In thi s mode, the TRISD registe r is ignore d, since the externa l device is controlling the direction of data flow.

A write to the PSP occurs when both the CS lines are first detected low. When either the CS or WR lines become hi gh (level triggered ), the Input Buffe r Full (IBF) status flag bit (TRISE<7>) is set on the Q4 clock cycle, following the next Q2 cycle, to signal the write is complete (Figure 3-10). The interrupt flag bit PSPIF (PIR1<7>) is also set on the same Q4 clock cycle. IBF can only be cle are d b y re adi ng the PO R TD i npu t l atc h. The Input Buffer Overflow (IBOV) status flag bit (TRISE<5>) is set if a second write to the PSP is attempted w hen the pre vious byte has not bee n read out of the buffer.

A read from the PSP occurs when both the CS lines are first detected low. The Output Buffer Full (OBF) status flag bit (TRISE<6>) is cleared immediately (Figure 3-11), indicating that the PORTD latch is waiting to be read by the ext ernal bus . When ei ther the CS rupt flag bit PSPIF is set on the Q4 clock cycle, following the next Q2 cycle, indicating that the read is complete. OBF remains low until data is written to PORTD by the user firmware.

to be the RD

(chip select) input. Fo r this function ality , th e cor-

and WR

and RD

or RD pin becomes high (level triggered), th e in ter-

When not in PSP mode, the IBF and OBF bits are hel d clear. However, if flag bit IBOV was previously set, it must be cleared in firmware.

An interrupt is generated and latched into flag bit PSPIF when a read or write operation is completed. PSPIF must be cleared by the user in fi rmware an d the interrupt can be disabled by clearing the interrupt enable bit PSPIE (PIE1<7>).

FIGURE 3-9: PORTD AND PORTE

BLOCK DIAGRAM (PARALLEL SLAVE PORT)

DS30292D-page 38  1998-2013 Microchip Technology Inc.

FIGURE 3-10: PARALLEL SLAVE PORT WRITE WAVEFORMS

Q1 Q2 Q3 Q4

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

WR RD

IBF

OBF

PSPIF

PORTD<7:0>

Q1 Q2 Q3 Q4

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

IBF

PSPIF

OBF

PORTD<7:0>

FIGURE 3-11: PARALLEL SLAVE PORT READ WAVEFORMS

PIC16F87X

TABLE 3-11: REGISTERS ASSOCIATED WITH PARALLEL SLAVE PORT

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

08h PORTD Port Data Latch when written: Port pins when read xxxx xxxx uuuu uuuu 09h PORTE 89h TRISE IBF OBF IBOV PSPMODE 0Ch PIR1 PSPIF 8Ch PIE1 PSPIE 9Fh ADCON1 Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the Parallel Slave Port.

Note 1: Bits PSPIE and PSPIF are reserved on the PIC16F873/876; always maintain these bits clear.

 1998-2013 Microchip Technology Inc. DS30292D-page 39

— — — — —RE2RE1RE0---- -xxx ---- -uuu

(1)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

ADFM — — — PCFG3 PCFG2 PCFG1 PCFG0 --0- 0000 --0- 0000

— PORTE Data Direction Bits 0000 -111 0000 -111

Value on:

POR, BOR

Value on

all other RESETS

PIC16F87X

NOTES:

DS30292D-page 40  1998-2013 Microchip Technology Inc.

PIC16F87X

4.0 DATA EEPROM AND FLASH PROGRAM MEMORY

The Data EEPROM and FLASH Program Memory are readable and writab le during no rmal operati on over the entire V gle byte for Data EEPROM memory and a single word for Program memory. A write operation causes an erase-then-write operation to take place on the specified byte or word. A bulk erase operation may not be issued from user code (which includes removing code protection).

Access to program memory all ows for che cksum calc ulation. The values written to program memory do not need to be valid instructions. Therefore, up to 14-bit numbers can be stored in memory for use as calibration parameters, serial numbers, packed 7-bit ASCII, etc. Executing a program memory location containing data that form an invalid instruction, results in the execution of a NOP instruction.

The EEPROM Data memory is rated for high erase/ write cycles (specif ica tio n D 120 ). The FLAS H pro gra m memory is rated much lower (specification D130), because EEPROM data memory can be used to store frequently updated values. An on-chip timer controls the write time and it w ill v ary with v olt age and tempe rature, as well as from chip to chip. Please refer to the specifications for exact limits (specifications D122 and D133).

A byte or word write automatically erases the location and writes the new value (erase before write). Writing to EEPROM data memory does not impact the operation of the device. Writing to program memory will cease the execution of instructions until the write is complete. The program memory cannot be accessed during the write. During the write operation, the oscillator continues to run, the peripherals continue to function and interrupt events will be detected and essentially “queued” until the write is complete. When the write completes, the next instruction in the pipeline is executed and the branch to the interrupt vector will take place, i f the i nte rrupt is enabled a nd oc cu rred d uring the write.

Read and write access to both memories take place indirectly through a set of Special Function Registers (SFR). The six SFRs used are:

• EEDATA

• EEDATH

• EEADR

• EEADRH

• EECON1

• EECON2

DD range. These opera tions take place on a si n-

The EEPROM data memory allows byte read and write operations without interfering with the normal operation of the microcontroller. When interfacing to EEPROM data memory, the EEADR register holds the address to be accessed. Depending on the operation, the EEDATA register holds the data to be written, or the data read, at the address in EEADR. The PIC16F873/874 devices have 128 bytes of EEPROM data memory and therefore, require that the MSb of EEADR remain clear. The EEPROM data memory on these devices do not wrap around to 0, i.e., 0x80 in the EEADR does not map to 0x00. The PIC16F876/877 devices have 256 bytes of EEPROM data memory and therefore, uses all 8-bits of the EEADR.

The FLASH program memory allows non-intrusive read access, but write operations cause the device to stop executing instructions, until the write completes. When interfacing to the program memory, the EEADRH:EEADR registers form a two-byte word, which holds the 13-bit address of the memory location being accessed. The register combination of EEDATH:EEDATA holds the 14-bit data for writes, or reflects the val ue of program m emory after a read operation. Just as in EEPROM data memory accesses, the value of the EEADRH:EEADR registers must be within the valid range of program memory, depending on the device: 0000h to 1FFFh for the PIC16F873/874, or 0000h to 3FFFh for the PIC16F876/877. Addresses outside of this ran ge do no t wrap around t o 0000h (i.e., 4000h does not map to 0000h on the PIC16F877).

4.1 EECON1 and EECON2 Registers

The EECON1 register is the control register for configuring and initiatin g the acces s. The EECON2 reg ister is not a physically implemented register, but is used exclusively in the memory write sequence to prevent inadvertent writes.

There are many bits used to control the read and write operations to EEPROM data and FLASH program memory. The EEPGD bit determines if the access will be a program or data memory access. When clear, any subsequent operations will work on the EEPROM data memory. When set, all subsequent operations will operate in the program memory.

Read operations only us e one additio nal bit, RD, whic h initiates the read operation from the desired memory location. Once this bit is set, the value of the desired memory location will be available in the data registers. This bit cannot be cleared by firmware. It is automatically cleared at the end of the read operation. For EEPROM data memory reads, the data will be available in the EEDATA register in the very next i nstructio n cycle after the RD bit is set. For program memory reads, the data will be loaded into the EEDATH:EEDATA registers, following the second instruction after the RD bit is set.

 1998-2013 Microchip Technology Inc. DS30292D-page 41

PIC16F87X

Write operations have two control bit s, WR and WREN, and two status bits, WRERR and EEIF. The WREN bit is used to enable or disable the write operation. When WREN is clear, the write operation will be disabled. Therefore, the WREN bit must be set befo re ex ec utin g a write operation. Th e WR bit is used to in itiate the write operation. It also is automatically cleared at the end of the write operation. The interrupt flag EEIF is used to determine when the mem ory write comp letes . This fla g must be cleared in software before setting the WR bit. For EEPROM data memory, once the WREN bit and the WR bit have been set, the desired memory addres s in EEADR will be erased, followed by a wri te of the data in EEDATA. This operation takes place in parallel with the microcontroller continuing to execute normally. When the write is c omplete, the EEIF flag bit will be set. For program memory, once the WREN bit and the WR bit have been set, the m icrocontr oller will cease to ex e-

cute instructions. T he de sired mem ory l ocatio n poi nted to by EEADRH:EEADR will be erased. Then, the data value in EEDATH:EEDATA will be programmed. When complete, the EEIF flag bi t will be set and the microcontroller will continue to execute code.

The WRERR bit is used to indicate when the PIC16F87X device has be en re set during a write op eration. WRERR should be cleared after Power-on Reset. Thereafter, it should be checked on any other RESET. The WRERR bit is set when a write operation is interrupted by a MCLR Reset, during normal o peration. In these situati ons, following a RESET , the user should check the WRERR bit and rewrite the memory locati on, if set. The c ontents of the data registers, address registers and EEPGD bit are not affected by either MCLR out Reset, during normal operation.

R/W-x U-0 U-0 U-0 R/W-x R/W-0 R/S-0 R/S-0

EEPGD — — — WRERR WREN WR RD

bit 7 bit 0

Reset, or a WDT Time-out

Reset, or WDT Time-

bit 7 EEPGD: Program/Data EEPROM Select bit

1 = Accesses program memory 0 = Accesses data memory

(This bit cannot be changed while a read or write operati on is in progress) bit 6-4 Unimplemented: Read as '0' bit 3 WRERR: EEPROM Error Flag bit

1 = A write operation is prematurely termina ted

(any MCLR

0 = The write operation completed bit 2 WREN: EEPROM Write Enable bit

1 = Allows write cycles

0 = Inhibits write to the EEPROM

bit 1 WR: Write Control bit

1 = Initiates a write cycle. (The bit is cleared by hardware once write is complete. The WR bit

can only be set (not cleared) in software.)

0 = Write cycle to the EEPROM is complete bit 0 RD: Read Control bit

1 = Initiates an EEPROM read. (RD is cleared in hardware. The RD bit can only be set (not

cleared) in software.)

0 = Does not initiate an EEPROM read

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

Reset or any WDT Reset during normal operation)

DS30292D-page 42  1998-2013 Microchip Technology Inc.

PIC16F87X

BSF STATUS, RP1 ; BCF STATUS, RP0 ;Bank 2 MOVF ADDR, W ;Write address MOVWF EEADR ;to read from BSF STATUS, RP0 ;Bank 3 BCF EECON1, EEPGD ;Point to Data memory BSF EECON1, RD ;Start read operation BCF STATUS, RP0 ;Bank 2

MOVF EEDATA, W ;W = EEDATA

BSF STATUS, RP1 ; BSF STATUS, RP0 ;Bank 3 BTFSC EECON1, WR ;Wait for GOTO $-1 ;write to finish BCF STATUS, RP0 ;Bank 2 MOVF ADDR, W ;Address to MOVWF EEADR ;write to MOVF VALUE, W ;Data to MOVWF EEDATA ;write BSF STATUS, RP0 ;Bank 3 BCF EECON1, EEPGD ;Point to Data memory BSF EECON1, WREN ;Enable writes ;Only disable interrupts BCF INTCON, GIE ;if already enabled, ;otherwise discard MOVLW 0x55 ;Write 55h to MOVWF EECON2 ;EECON2 MOVLW 0xAA ;Write AAh to MOVWF EECON2 ;EECON2 BSF EECON1, WR ;Start write operation ;Only enable interrupts BSF INTCON, GIE ;if using interrupts, ;otherwise discard BCF EECON1, WREN ;Disable writes

4.2 Reading the EEPROM Data Memory

Reading EEPROM data memory only requires that the desired address to access be written to the EEADR register and clear the EEPGD bit. After the RD bit is set, data will be av ailable in the EEDATA register on the very next instruction cycle. EEDAT A will hold this value until another read ope rati on is in iti ated or until it is written by firmware.

The steps to reading the EEPROM data memory are:

1. Write the address to EEDATA. Make sure that

the address is not larger than the memory size of the PIC16F87X device.

2. Clear the EEPGD bit to point to EEPROM data

memory.

3. Set the RD bit to start the read operation.

4. Read the data from the EEDATA register.

EXAMPLE 4-1: EEPROM DATA READ

The steps to write to EEPROM data memory are:

1. If step 10 is not implemented, check the WR bit to see if a write is in progress.

2. Write the address to EEADR. Make sure that the address is not larger than the memory size of the PIC16F87X device.

3. Write the 8-bit data value to be programmed in the EEDATA register.

4. Clear the EEPGD bit to point to EEPROM data memory.

5. Set the WREN bit to enable program operati ons.

6. Disable interrupts (if enabled).

7. Execute the special five instruction sequence:

• Write 55h to EECON2 in two steps (first to W,

then to EECON2)

• Write AAh to EECON2 in two steps (first to

W, then to EECON2)

• Set the WR bit

8. Enable interrupts (if using interrupts).

9. Clear the WREN bit to disable program operations.

10. At the completion of the write cycle, the WR bit is cleared and the EEIF interrupt flag bit is set. (EEIF must be cleared by firmware.) If step 1 is not implemented, then firmware should check for EEIF to be set, or WR to clear , to indica te the end of the program cycle.

4.3 Writing to the EEPROM Data Memory

There are many steps in writing to the EEPROM data memory . Both address and dat a valu es must be writte n to the SFRs. The EEPGD bit must be cleared, and the WREN bit must be set, t o enab le w rites. The WREN b it should be kept clear at all times, ex cept when writi ng to the EEPROM data. The WR bit can only be set if the WREN bit wa s set in a previous operation, i.e., they both cannot be set in the same operation. The WREN bit should then be cleared by firmware after the write. Clearing the WREN bit before the write actually completes wil l not terminate the write in progre ss.

Writes to EEPROM data memory must also be prefaced with a special sequence of instructions, that prevent inadvertent wri te operatio ns. This is a s equence of five instructions that m ust be executed without in terruptions. The firmware should verify that a write is not in progress, before starting another cycle.

 1998-2013 Microchip Technology Inc. DS30292D-page 43

EXAMPLE 4-2: EEPROM DATA WRITE

PIC16F87X

BSF STATUS, RP1 ; BCF STATUS, RP0 ;Bank 2 MOVF ADDRL, W ;Write the MOVWF EEADR ;address bytes MOVF ADDRH,W ;for the desired MOVWF EEADRH ;address to read BSF STATUS, RP0 ;Bank 3 BSF EECON1, EEPGD ;Point to Program memory BSF EECON1, RD ;Start read operation NOP ;Required two NOPs NOP ; BCF STATUS, RP0 ;Bank 2 MOVF EEDATA, W ;DATAL = EEDATA MOVWF DATAL ; MOVF EEDATH,W ;DATAH = EEDATH MOVWF DATAH ;

4.4 Reading the FLASH Program Memory

Reading FLASH program memory is much like that of EEPROM data memory , only two NOP instructions must be inserted afte r the RD bit is set. These two i nstruction cycles that t he NOP instructions execute, will be used by the micr ocontr olle r to r ead th e data out o f prog ram memory and insert the value into the EEDATH:EEDATA registers. Data will be available following the second NOP instruction. EEDATH and EEDATA will hold their value until another read operation is initiated, or until they are written by firmware.

The steps to rea din g the FLASH program mem ory a re:

1. Write the address to EEADRH:EEADR. Make

sure that the address is not larger than the memory size of the PIC16F87X device.

2. Set the EEPGD bit to point to FLASH program

memory.

3. Set the RD bit to start the read operation.

4. Execute two NOP instructions to allow the micro-

controller to read out of program memory.

5. Read the data from the EEDATH:EEDATA

registers.

EXAMPLE 4-3: FLASH PROGRAM READ

DS30292D-page 44  1998-2013 Microchip Technology Inc.

4.5 Writing to the FLASH Program Memory

Writing to FLASH program memory is unique, in that the microcontroller does not execute instructions while programming is taking place. The oscillator continues to run and all peripherals continue to operate and queue interrupts, if enabled. Once the write operation completes (specification D133), the processor begins executing code from where it left off. The other important difference when writing to FLASH program memory, is that the WRT configuration bit, when clear, prevents any writes to program memory (see Table 4-1).

Just like EEPROM data memory, there are many steps in writing to the FLASH program mem ory . Bot h address and data values must be written to the SFRs. The EEPGD bit must be set, and the WREN bit must be s et to enable writes. The WREN bit shou ld b e kept cl ear at all times, except when writing to the FLASH Program memory. The WR bit can only be set if the WREN bit was set in a previous operation, i.e., they both cannot be set in the same operation. The WREN bit should then be cleared by firmwa re after the writ e. Clearing the WREN bit before the write actually completes will not terminate the write in progress.

Writes to program memory must also be prefaced with a special sequence of instructions that prevent inadvertent write operations. This is a sequence of five instructio ns t h at mu st be e xe cu t ed w ith ou t i nte r ru pt i on for each byt e writ ten. Th ese ins truct ions must then be followed by two NOP instructions to allow the microcontroller to setup for th e writ e opera tion. Onc e the w rite i s complete, the execution of instructions starts with the instruction after the second NOP.

The steps to write to program memory are:

1. Write the address to EEADRH:EEADR. Make

sure that the address i s not larger than the m emory size of the PIC16F87X device.

2. Write the 14-bit data value to be prog ram me d i n

the EEDATH:EEDATA registers.

3. Set the EEPGD bit to point to FLASH program

memory.

4. Set the WREN bit to enable program operati ons.

5. Disable interrupts (if enabled).

6. Execute the special five instruction sequence:

• Write 55h to EECON2 in two step s (first to W , then to EECON2)

• Write AAh to EECON2 in two steps (first to W , then to EECON2)

• Set the WR bit

7. Execute two NOP instruction s to allow the mic rocontroller to setup for write operation.

8. Enable interrupts (if using interrupts).

9. Clear the WREN bit to disable program operations.

PIC16F87X

BSF STATUS, RP1 ; BCF STATUS, RP0 ;Bank 2 MOVF ADDRL, W ;Write address MOVWF EEADR ;of desired MOVF ADDRH, W ;program memory MOVWF EEADRH ;location MOVF VALUEL, W ;Write value to MOVWF EEDATA ;program at MOVF VALUEH, W ;desired memory MOVWF EEDATH ;location BSF STATUS, RP0 ;Bank 3 BSF EECON1, EEPGD ;Point to Program memory BSF EECON1, WREN ;Enable writes ;Only disable interrupts BCF INTCON, GIE ;if already enabled, ;otherwise discard MOVLW 0x55 ;Write 55h to MOVWF EECON2 ;EECON2 MOVLW 0xAA ;Write AAh to MOVWF EECON2 ;EECON2 BSF EECON1, WR ;Start write operation NOP ;Two NOPs to allow micro NOP ;to setup for write ;Only enable interrupts BSF INTCON, GIE ;if using interrupts, ;otherwise discard

BCF EECON1, WREN ;Disable writes

At the completion of the write cycle, the WR bit is cleared and the EEIF interrupt flag bit is set. (EEIF must be cleared by firmware. ) Since the microcont roller does not execute in structions duri ng the write cy cle, the firmware does not necessarily have to check either EEIF, or WR, to determine if the write had finished.

EXAMPLE 4-4: FLASH PROGRAM WRITE

4.6 Write Verify

The PIC16F87X device s do not automatic ally verify the value written during a write operation. Depending on the application, good programming practice may dictate that the value written to memory b e verified against the original value. This should be used in applications where excessive writes can stress bits near the specified endurance limit s.

 1998-2013 Microchip Technology Inc. DS30292D-page 45

4.7 Protection Against Spurious

Writes

There are conditions when the device may not want to write to the EEPROM data memory or FL ASH program memory. To protect against these spurious write conditions, various mechanisms have been built into the PIC16F87X devices. On power-up, the WREN bit is cleared and the Power-up Timer (if enabled) prevents writes.

The write initiate sequence, and the WREN bit together, help prevent any accidental writes during brown-out, power glitches, or firmware malfunction.

4.8 Operation While Code Protected

The PIC16F87 X devi ce s ha ve tw o c ode pr o tec t mec ha nisms, one bit for EEPROM dat a memory and two bi ts for FLASH program memory. Data can be read and written to the EEPROM data memory, regardless of the state of the code protection bit, CPD. When code protection is enabled and CPD cleared, external access via ICSP is disabled, regardles s of the sta te of the prog ram memory code protect bits. This prevents the contents of EEPROM data memory fro m bei ng rea d o ut of the device.

The state of the program memory code protect bits, CP0 and CP1, do not affect the execution of instructions out of program mem ory. The PIC16F87X devices can always read the values in program memory, regardless of the state of the code protect bits. However , the st a te of th e c ode protect bits and the WRT bit will have diffe rent effects on wr iting to prog ram memory. Table 4-1 shows the effect of the code protect bits and the WRT bit on program memory.

Once code protection has been enabled for either EEPROM data memory or FLASH program memory, only a full erase of the entire device will disable code protection.

PIC16F87X

4.9 FLASH Program Memory Write Protection

The configuration word contains a bit that write protects the FLASH program memory, called WRT. This bit can only be accessed when programming the PIC16F87X device via ICSP. Once write protection is enable d, only an erase of the entire device will disable it. When enabled, write protec tion prevent s any writes to FLASH program memory. Write protection does not affect program memory reads.

TABLE 4-1: READ/WRITE STATE OF INTERNAL FLASH PROGRAM MEMORY

Configuration Bits

CP1 CP0 WRT

00x All program memory Yes No No No 010 Unprotected areas Yes No Yes No 010 Protected areas Yes No No No 011 Unprotected areas Yes Yes Yes No 011 Protected areas Yes No No No 100 Unprotected areas Yes No Yes No 100 Protected areas Yes No No No 101 Unprotected areas Yes Yes Yes No 101 Protected areas Yes No No No 110 Al l program mem ory Yes No Yes Yes 111 Al l program mem ory Yes Yes Yes Yes

Memory Location

TABLE 4-2: REGISTERS ASSOCIATED WITH DATA EEPROM/PROGRAM FLASH

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh, 8Bh, 10Bh, 18Bh

10Dh EEADR EEPROM Address Register, Low Byte 10Fh EEADRH 10Ch EEDATA EEP ROM Data Register, Low Byte 10Eh EEDATH 18Ch EECON1 EEPGD 18Dh EECO N2 EEP ROM Cont rol Register2 (not a physical register) 8Dh PIE2 0Dh PIR2 Legend: x = unknown, u = unchanged, r = reserved, - = unimplemented, read as '0'.

Note 1: These bits are reserved; always maintain these bits clear.

INTCON GIE PEIE

— — — EEPROM Address, High Byte

— — EEPROM Data Register, High Byte

— (1) —EEIEBCLIE — — CCP2IE — (1) —EEIFBCLIF — — CCP2IF

Shaded cells are not used during FLASH/EEPROM access.

T0IE INTE RBIE T0IF INTF RBIF

— — — WRERR WREN WR RD

Internal

Read

Internal

Write

ICSP Read ICSP Write

Value on:

POR, BOR

0000 000x 0000 000u

xxxx xxxx uuuu uuuu

x--- x000 x--- u000

——

-r-0 0--0 -r-0 0--0

Val ue on all other RESETS

DS30292D-page 46  1998-2013 Microchip Technology Inc.

PIC16F87X

RA4/T0CKI

T0SE

M U

CLKOUT (= F

OSC/4)

SYNC

Cycles

TMR0 Reg

8-bit Prescaler

8 - to - 1MUX

U X

M U X

Watchdog

Timer

PSA

WDT

Time-out

PS2:PS0

Note: T0CS, T0SE, PSA, PS2:PS0 are (OPTION_REG<5:0>).

PSA

WDT Enable bit

M U

Data Bus

Set Flag Bit T0IF

on Overflow

PSA

T0CS

PRESCALER

5.0 TIMER0 MODULE

Counter mode is selected by setting bit T0CS (OPTION_REG<5>). In Counter mode, Timer0 will

The Timer0 module timer/co unter has the follow ing features:

• 8-bit timer/counter

• Readable and writable

• 8-bit software programmable prescaler

• Internal or external clock select

• Interrupt on overflow from FFh to 00h

• Edge select for external clock Figure 5-1 is a bloc k diagram o f the T imer0 mod ule and

increment either o n every rising , or fal ling ed ge of pin RA4/T0CKI. The incrementing edge is determined by the Timer0 Source Edge Select bit, T0SE (OPTION_REG<4>). Clearing bit T0SE selects the rising edge. Restrictions on the external clock input are discussed in detail in Section5.2.

The prescaler is mutually exclusively shared between the Timer0 modu le and t he W a tch dog Timer . The prescaler is not readabl e or w rit able. Sectio n 5.3 details the operation of the prescaler.

the prescaler shared with the WDT. Additional information on the Timer0 module is avail-

able in the PIC® MCU Mid-Range Family Reference Manual (DS33023).

Timer mode is selected by clearing bit T0CS (OPTION_REG<5>). In Timer mode, the Timer0 module will incremen t every ins tru ction cycle (without pre scaler). If the TMR0 register is written, the increment is inhibited for the following two instruction cycles. The user can work around this by writing an adjusted value

5.1 Timer0 Interrupt

The TMR0 interrupt is generated when the TMR0 register overflows from FFh to 00h. This overflow sets bit T0IF (INTCON<2>). The interrupt can be masked by clearing bit T0IE (INTCON<5>). Bit T0IF must be cleared in soft ware by the T imer0 mo dule Interrupt Service Routine before re-enabling this interrupt. The TMR0 interrupt cannot awaken the processor from SLEEP, since the timer is shut-off during SLEEP.

to the TMR0 register.

FIGURE 5-1: BLOCK DIAGRAM OF THE TIMER0/WDT PRESCALER

 1998-2013 Microchip Technology Inc. DS30292D-page 47

PIC16F87X

000 001 010 011 100 101 110 111

1 : 2 1 : 4 1 : 8 1 : 16 1 : 32 1 : 64 1 : 128 1 : 256

1 : 1 1 : 2 1 : 4 1 : 8 1 : 16 1 : 32 1 : 64 1 : 128

Bit Value TMR0 Rate WDT Rate

5.2 Using Timer0 with an External Clock

When no pres caler is us ed, t he ex ternal clock inpu t is the same as the prescaler outp ut. Th e sy nch ron iz atio n of T0CKI with the internal phase clocks is accomplished by sampli ng the prescale r output on the Q2 and Q4 cycles of the internal phase clocks. Therefore, it is necessary f or T 0 CK I t o be hi g h f or a t le as t 2Tosc (and a small RC delay of 20 ns) and low for at least 2Tosc (and a small RC delay of 20 ns). Refer to the electrical specification of the desired device.

Timer0 module means that there is no prescaler for the Watchdog Timer, and vice-versa. This prescaler is not readable or writable (see Figure 5-1).

The PSA and PS2:PS0 bits (OPTION_REG<3:0>) determine the prescaler assignment and pre scale ratio.

When assigned to the Timer0 module, all instructions writing to the TMR0 register ( e.g. CLRF

BSF

to WDT, a CLRWDT instr uction will clea r the prescaler along with the Watchdog Timer. The prescaler is not readable or writable.

5.3 Prescaler

There is only one pres caler a vailable , which i s mutu ally exclusively sha red between the T imer0 mod ule and the Watchdog Timer. A prescaler assignment for the

R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 RBPU

bit 7 bit 0

bit 7 RBPU bit 6 INTEDG bit 5 T0CS: TMR0 Clock Source Select bit

1 = Transition on T0CKI pin 0 = Internal instruction cycle clock (CLKOUT)

bit 4 T0SE: TMR0 Source Edge Select bit

1 = Increment on high-to-low transition on T0CKI pin 0 = Increment on low-to-high transition on T0CKI pin

bit 3 PSA: Prescaler Assignment bit

1 = Prescaler is assigned to the WDT 0 = Prescaler is assigned to the Timer0 module

bit 2-0 PS2:PS0: Prescaler Rate Select bits

INTEDG T0CS T0SE PSA PS2 PS1 PS0

1, MOVWF 1,

1,x.. ..etc.) will clear the pre scaler . When assigne d

Note: Writing to TMR0, when the prescaler is

assigned to T imer0, will clear the pre scaler count, but will not change the prescaler assignment.

Note: To avoid an unintended device RESET, the instruction sequence shown in the PIC® MCU Mid-Range Fam-

DS30292D-page 48  1998-2013 Microchip Technology Inc.

ily Reference Manual (DS33023) must be executed when changing the prescaler assignment from Timer0 to the WDT. This sequence must be followed even if the WDT is disabled.

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

TABLE 5-1: REGISTERS ASSOCIATED WITH TIMER0

PIC16F87X

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

01h,101h TMR0 Timer0 Module’s Register 0Bh,8Bh,

10Bh,18Bh 81h,181h OPTION_REG RBPU INTEDG T0CS T0SE PSA PS2 PS1 PS0 Legend: x = unknown, u = unchanged, - = unimplemented locations read as '0'.

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF

Shaded cells are not used by T ime r0.

Value on:

POR,

BOR

xxxx xxxx uuuu uuuu

0000 000x 0000 000u

1111 1111 1111 1111

Value on

all other

RESETS

 1998-2013 Microchip Technology Inc. DS30292D-page 49

PIC16F87X

NOTES:

DS30292D-page 50  1998-2013 Microchip Technology Inc.

PIC16F87X

6.0 TIMER1 MODULE

The Timer1 mod ule is a 16-bit timer/counter consistin g of two 8-bit registers (TMR1H and TMR1L), which are readable and writable. The TMR1 Register pair (TMR1H:TMR1L) increments from 0000h to FFFFh and rolls over to 0000 h. The TMR1 Inte rrupt, if enabled, is generated on overflow, which is latched in interrupt flag bit TMR1IF (PIR1<0>). This interrupt can be enabled/disabled by setting/clearing TMR1 interrupt enable bit TMR1IE (PIE1<0>).

Timer1 can operate in one of two modes:

•As a timer

•As a counter The operating mode is determined by the clock select

bit, TMR1CS (T1CON<1>).

In Timer mode, Timer1 increments every instruction cycle. In Counter mode, it increments on every rising edge of the external clock input.

Timer1 can be enabled/disabled by setting/clearing control bit TMR1ON (T1CON<0> ) .

Timer1 also has an internal “RESET input”. This RESET can be generated by either of the two CCP modules (Section 8.0). Register 6-1 shows the Timer1 control register.

When the Timer1 oscillator is enabled (T1OSCEN is set), the RC1/T1OSI/CCP2 and RC0/T1OSO/T1CKI pins become inputs. That is, the TRISC<1:0> value is ignored, and these pins read as ‘0’.

Additional information on timer modules is available in the PIC (DS33023).

MCU Mid-Range Family Reference Manual

U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

— — T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON

bit 7 bit 0

bit 7-6 Unimplemented: Read as '0' bit 5-4 T1CKPS1:T1CKPS0: Timer1 Input Clock Prescale Select bits

11 = 1:8 Prescale value 10 = 1:4 Prescale value 01 = 1:2 Prescale value 00 = 1:1 Prescale value

bit 3 T1OSCEN: Timer1 Oscillator Enable Control bit

1 = Oscillator is enabled 0 = Oscillator is shut-off (t he oscillat or inverter is turned off t o eliminat e power drain)

bit 2 T1SYNC

When TMR1CS = 1:

1 = Do not synchronize external clock input 0 = Synchronize external cl ock input

When TMR1CS = 0 This bit is ignored. Timer1 uses the internal clock when TMR1CS = 0.

bit 1 TMR1CS: Timer1 Clock Source Select bit

1 = External clock from pin RC0/T1OSO/T1CKI (on the rising edge) 0 = Internal clock (F

bit 0 TMR1ON: Timer1 On bit

1 = Enables Timer1 0 = Stops Timer1

: Timer1 External Clock Input Synchronization Control bit

OSC/4)

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 1998-2013 Microchip Technology Inc. DS30292D-page 51

PIC16F87X

T1CKI (Default High)

T1CKI (Default Low)

Note: Arrows indicate counter increments.

TMR1H

TMR1L

T1OSC

T1SYNC

TMR1CS

T1CKPS1:T1CKPS0

Q Clock

T1OSCEN Enable

Oscillator

(1)

FOSC/4 Internal Clock

TMR1ON

On/Off

Prescaler

1, 2, 4, 8

Synchronize

det

Synchronized

Clock Input

RC0/T1OSO/T1CKI

RC1/T1OSI/CCP2

(2)

Note 1: When the T1OSCEN bit is cleared, the inverter is turned off. This eliminates power drain.

Set Flag bit TMR1IF on Overflow

TMR1

6.1 Timer1 Operation in Timer Mode

Timer mode is selected by clearing the TMR1CS (T1CON<1>) bit. In this mode, the input clock to the timer is F (T1CON<2>) has no effect, since the internal clock is always in sync.

FIGURE 6-1: TIMER1 INCREMENTING EDGE

OSC/4. The synchronize control bit T1SYNC

6.2 Timer1 Counter Operation

Timer1 may operate in either a Synchronous, or an Asynchronous mode, depending on the setting of the TMR1CS bit.

When Timer1 is being incremented via an external source, increment s occur on a rising edg e. After T imer1 is enabled in Coun ter mode, the module mus t first have a falling edge before the counter begins to increment.

6.3 Timer1 Operation in Synchronized

Counter mode is selected by setting bit TMR1CS. In this mode, the timer increm ents on every risin g edge of clock input on pin RC1/T1OSI/CCP2, when bit T1OSCEN is set, or on pi n RC0/T1 OSO/T 1CKI , when bit T1OSCEN is cleared.

FIGURE 6-2: TIMER1 BLOCK DIAGRAM

DS30292D-page 52  1998-2013 Microchip Technology Inc.

Counter Mode

If T1SYNC is cleared, the n the externa l clock input is synchronized with internal phase clocks. The synchronization is done after the prescaler stage. The prescaler stage is an asynchronous ripple-counter.

In this configuration, during SLEEP mode, Timer1 will not increment even if the external clock is present, since the synchronization circuit is shut-off. The prescaler, however, will continue to increment.

PIC16F87X

6.4 Timer1 Operation in Asynchronous Counter Mode

If control bit T1SYNC (T1CON<2>) is set, the external clock input is not synchronized. The timer continues to increment asynchronous to the internal phase clocks. The timer will continue to run during SLEEP and can generate an interrupt-on-overflow, which will wake-up the processor. However, special precautions in software are needed to read/write the time r (Section 6.4.1).

In Asynchronous Counter mode, Timer1 cannot be used as a time-base for capture or compare operations.

6.4.1 READING AND WRITING TIMER1 IN

ASYNCHRONOUS COUNTER MODE

Reading TMR1H or TMR1L while the timer is running from an external asynchronous clock, will guarantee a valid read (taken care of in hardware). However, the user should keep i n mind that r eadin g the 16-bit time r in two 8-bit values itself, poses cert a in pro bl em s, s inc e the timer may overflow between the reads.

For writes, it is recomm ended that the us er simply stop the timer and write the desired values. A write contention may occur by writing to the timer registers, while the register is incrementing. This may produce an unpredictable value i n the timer register.

Reading the 16-bit value requires some care. Examples 12-2 and 12-3 in the PIC Reference M anual (DS33 023) show how t o read and write Ti mer1 wh en it i s runni ng in Async hronou s mode.

MCU Mid-Range Family

6.5 Timer1 Oscillator

A crystal oscillator ci rcuit is built-in betwee n pins T1OSI (input) and T1OSO (amplifier output). It is enabled by setting control bit T1OSCEN (T 1CON<3>). The oscill ator is a low power oscillator, rated up to 200 kHz. It will continue to run during SLEEP. It is primarily intended for use with a 32 kHz crystal. Table 6-1 shows the capacitor selection for the Timer1 oscillator.

The Timer1 oscillator is identical to the LP oscillator. The user must provide a so f t ware time delay to ensure proper oscillator start-up.

T ABLE 6-1: CAPACITOR SELECTION FOR

THE TIMER1 OSCILLATOR

Osc T y pe Freq. C1 C2

LP 32 kHz 33 pF 33 pF

100 kHz 15 pF 15 pF 200 kHz 15 pF 15 pF

These values are for design guidance only.

Crystals Tested:

32.768 kHz Epson C-001R32.768K-A ± 20 PPM 100 kHz Epson C-2 100.00 KC-P ± 20 PPM 200 kHz STD XTL 200.000 kHz ± 20 PPM

Note 1: Higher capacitance increases the stability

of oscillator , b ut also inc rease s the st art-up time.

2: Sin ce each resonator/crystal has its own

characteristics, the u ser shoul d consult th e resonator/crystal manufacturer for appropriate values of external components.

6.6 Resetting Timer1 using a CCP Trigger Output

If the CCP1 or CCP2 module is config ured in C omp are mode to generate a “special event trigger” (CCP1M3:CCP1M0 = 1011), this signal will reset Timer1.

Note: The special event triggers from the CCP1

and CCP2 modules will not set interrupt flag bit TMR1IF (PIR1<0>).

Timer1 mu st be confi gured fo r either T ime r or Synchr onized Counter mode to take advantage of this feature. If Timer1 is running in Asynchronous Counter mode, this RESET operation may not work.

In the event that a write t o T imer1 coinc ides with a sp ecial event trigger from CCP1 or CCP2, the write will take precedence.

In this mode of ope rati on, the CCPRxH :CCPRx L regis ter pair effectively becomes the period register for Timer1.

 1998-2013 Microchip Technology Inc. DS30292D-page 53

PIC16F87X

6.7 Resetting of Timer1 Register Pair (TMR1H, TMR1L)

TMR1H and TMR1L registers are not rese t to 00h on a

6.8 Timer1 Prescaler

The prescaler counter is cleared on writes to the TMR1H or TMR1L registers.

POR, or any other RESET, except by the CCP1 and CCP2 special event triggers.

T1CON register is reset to 00h on a Power-on Reset, or a Brown-out Reset, which shuts off the timer and leaves a 1:1 prescale. In all other RESETS, the register is unaffected.

TABLE 6-2: REGISTERS ASSOCIATED WITH TIMER1 AS A TIMER/COUNTER

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh,8Bh, 10Bh, 18Bh

0Ch PIR1 8Ch PIE1 0Eh TMR1L Holding Register for the Least Significant Byte of the 16-bit TMR1 Register 0Fh TMR1H Holding Register for the Most Significant Byte of the 16-bit TMR1 Register 10h T1CON Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the Timer1 module.

Note 1: Bits PSPIE and PSPIF are reserved on the PIC16F873/876; always maintain these bits clear.

INTCON GIE PEIE

(1)

PSPIF PSPIE

— — T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE

T0IE INTE RBIE T0IF INTF RBIF

Value on:

0000 000x 0000 000u

0000 0000 0000 0000

xxxx xxxx uuuu uuuu

--00 0000 --uu uuuu

POR, BOR

Value on

all other

RESETS

DS30292D-page 54  1998-2013 Microchip Technology Inc.

PIC16F87X

Comparator

TMR2

Sets Flag

TMR2 Reg

Output

(1)

RESET

Postscaler

Prescaler

PR2 Reg

OSC/4

1:1 1:16

1:1, 1:4, 1:16

bit TMR2IF

Note 1:TMR2 register output can be software selected by the

SSP module as a baud clock.

T2OUTPS3:

T2OUTPS0

T2CKPS1:

T2CKPS0

7.0 TIMER2 MODULE

Timer2 is an 8-bit timer with a prescaler and a postscaler. It can be used as the PW M time-base f or the PWM mode of the CCP mod ule (s). The T MR2 re gister is readable and writable, and is cleared on any device RESET.

The input clock (F

OSC/4) has a prescale option of 1:1,

the PIC

MCU Mid-Range Family Reference Manual

(DS33023).

FIGURE 7-1: TIMER2 BLOCK DIAGRAM

1:4, or 1:16, selected by control bits T2CKPS1:T2CKPS0 (T2CON<1:0>).

The Timer2 module has an 8-bit period register, PR2. Timer2 increments from 00h until it matches PR2 and then resets to 00h on the next increment cycle. PR2 is a readable and writable register. The PR2 register is initialized to FFh upon RESET.

The match output of TMR2 goes through a 4-bit postscaler (which gives a 1:1 to 1:16 scaling inclusive) to generate a TMR2 interrupt (latched in flag bit TMR2IF, (PIR1<1>)).

Timer2 c an b e s hu t-off by clea ring c ontrol bit TMR2ON (T2CON<2>) , to minimize power consum ption.

U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

— TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0

bit 7 bit 0

bit 7 Unimplemented: Read as '0' bit 6-3 TOUTPS3:TOUTPS0: Timer2 Output Postscale Select bits

0000 = 1:1 Postscale 0001 = 1:2 Postscale 0010 = 1:3 Postscale

•

• 1111 = 1:16 Postscale

bit 2 TMR2ON: Timer2 On bit

1 = Timer2 is on 0 = Timer2 is off

bit 1-0 T2CKPS1:T2CKPS0: Timer2 Clock Prescale Select bits

00 = Prescaler is 1 01 = Prescaler is 4 1x = Prescaler is 16

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

 1998-2013 Microchip Technology Inc. DS30292D-page 55

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

PIC16F87X

7.1 Timer2 Prescaler and Postscaler

The prescaler and postscaler counters are cleared when any of the following occurs:

• a write to the TMR2 register

7.2 Output of TMR2

The output of TMR2 (before the post scaler) is fed to the SSP module, which optionally uses it to generate shift clock.

• a write to the T2CON register

• any device RESET (POR, MCLR

Reset, WDT

Reset, or BOR)

TMR2 is not cleared when T2CON is written.

TABLE 7-1: REGISTERS ASSOCIATED WITH TIMER2 AS A TIMER/COUNTER

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh,8Bh, 10Bh,18Bh

0Ch PIR1 8Ch PIE1 11h TMR2 Timer2 Module’s Register 0000 0000 0000 0000 12h T2CON 92h PR2 Timer2 Period Register 1111 1111 1111 1111 Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the Timer2 module.

Note 1: Bits PSPIE and PSPIF are reserved on the PIC16F873/876; always maintain these bits clear.

INTCON GIE PEIE

(1)

PSPIF PSPIE

— TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 -000 0000

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

Value on:

POR,

BOR

Value on all other RESETS

DS30292D-page 56  1998-2013 Microchip Technology Inc.

PIC16F87X

8.0 CAPTURE/COMPARE/PWM MODULES

Each Capture/Compare/PWM (CCP) module contains a 16-bit register which can operate as a:

• 16-bit Capture register

• 16-bit Compare register

• PWM Master/Slave Duty Cycle register

Both the CCP1 and CCP2 modules are identical in operation, with the e xception being the operation of the special event trigg er. Table 8-1 and Table 8-2 show the resources and interactions of the CCP module(s). In the following sections, the operation of a CCP module is described with respect to CCP1. CCP2 operates the same as CCP1, except where noted.

CCP1 Module: Capture/Compare/PWM Register1 (CCPR1) is com-

prised of two 8-bit registers: CCPR1L (low byte) and CCPR1H (high byte). The CCP1CON register controls the operation of CCP1. The special event trigger is generated by a compare match and will reset Timer1.

TABLE 8-2: INTERACTION OF TWO CCP MODULES

CCP2 Module: Capture/Compare/PWM Register2 (CCPR2) is com-

prised of tw o 8-bit registers: CCPR2L (low byte) and CCPR2H (high byte). The CCP2CON register controls the operation of CCP2. The special event trigger is generated by a compare match and will reset Timer1 and start an A/D conversion (if the A/D module is enabled).

Additional information on CCP modules is available in the PIC (DS33023) and in application note AN594, “Using the CCP Modules” (DS00594).

MCU Mid-Range Family Reference Manual

TABLE 8-1: CCP MODE - TIMER

RESOURCES REQUIRED

CCP Mode Timer Resource

Capture

Compare

PWM

Timer1 Timer1 Timer2

CCPx Mode CCPy Mode Interaction

Capture Capture Same TMR1 time-base Capture Compare The compare should be configured for the special event trigger, which clears TMR1

Compare Compare The compare(s) should be configured for the special event trigger, which clears TMR1

PWM PWM The PWMs will have the same frequency and update rate (TMR2 interrupt) PWM Capture None PWM Compare None

 1998-2013 Microchip Technology Inc. DS30292D-page 57

PIC16F87X

U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

— — CCPxX CCPxY CCPxM3 CCPxM2 CCPxM1 CCPxM0

bit 7 bit 0

bit 7-6 Unimplemented: Read as '0' bit 5-4 CCPxX:CCPxY: PWM Least Significant bits

Capture mode Unused

Compare mode: Unused

PWM mode: These bits are the two LSbs of the PWM duty cycle. The eight MSbs are found in CCPRxL.

bit 3-0 CCPxM3:CCPxM0: CCPx Mode Select bits

0000 =Capture/Compare/PWM disabled (resets CCPx module) 0100 =Capture mode, every falling edge 0101 =Capture mode, every rising edge 0110 =Capture mode, every 4th rising edge 0111 =Capture mode, every 16th rising edge 1000 =Compare mode, set output on match (CCPxIF bit is set) 1001 =Compare mode, clear output on match (CCPxIF bit is set) 1010 =Compare mode, generate software interrupt on match (CCPxIF bit is set, CCPx pin is

1011 = Compare mode, trigger s pecial event (CCPxIF b it is set, CCPx pin is un affected); CCP1

11xx =PWM mode

unaffected) resets TMR1; CCP2 resets TMR1 and starts an A/D conversion (if A/D module is

enabled)

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292D-page 58  1998-2013 Microchip Technology Inc.

PIC16F87X

CCPR1H CCPR1L

TMR1H TMR1L

Set Flag bit CCP1IF

(PIR1<2>)

Capture Enable

CCP1CON<3:0>

RC2/CCP1

Prescaler

 1, 4, 16

and

edge detect

CLRF CCP1CON ; Turn CCP module off MOVLW NEW_CAPT_PS ; Load the W reg with

; the new prescaler ; move value and CCP ON

MOVWF CCP1CON ; Load CCP1CON with this

; value

8.1 Capture Mode

In Capture mode, CCPR1H:CCPR1L captures the 16-bit value of the TMR1 r egister wh en an eve nt occurs on pin RC2/CCP1. An ev ent is defined as on e of the following:

• Every falling edge

• Every rising edge

• Every 4th rising edge

• Every 16th rising edge

The type of event is configured by control bits CCP1M3:CCP1M0 (CCPxCON<3:0>). When a capture is made, the interrupt request flag bit CCP1IF (PIR1<2>) is set. The interrupt flag must be cleared in software. If another capture occurs before the value in register CCPR1 is read, th e old ca ptured v alue is overwritten by the new value.

8.1.1 CCP PIN CONFIGURATION

In Capture mode, the R C2/CCP1 pin should b e co nfi gured as an input by setting the TRIS C<2> bit.

Note: If the RC2/CCP1 pin is configured as an

output, a write t o the port c an cau se a capture condition.

8.1.2 TIMER1 MODE SELECTION

Timer1 must be running in Timer mode, or Synchronized Counter mode, for the CCP module to use the capture feature. In Asynchronous Counter mode, the capture operation may not work.

8.1.3 SOFTWARE INTERRUPT

When the Capture mode is changed, a false capture interrupt may be generated. The user should keep bit CCP1IE (PIE1<2>) clear to avoid false interrupts and should clear the flag bit CCP1IF, following any such change in operating mode.

8.1.4 CCP PRESCALER

There are four prescaler settings, specified by bits CCP1M3:CCP1M0. Whenever the CCP module is turned off, or the CCP module is not in Capture mode, the prescaler counter is cleared. Any RESET will clear the prescaler counter.

Switching from one capture prescaler to another may generate an interrupt. Also, the prescaler counter will not be cleared, therefore, the first cap ture may be from a non-zero prescaler. Example 8-1 shows the recommended method for switching between capture prescalers. This example also clears the prescaler counter and will not generate the “false” interrupt.

FIGURE 8-1: CAPTURE MODE

OPERATION BLOCK DIAGRAM

EXAMPLE 8-1: CHANGING BETWEEN

CAPTURE PRESCALERS

 1998-2013 Microchip Technology Inc. DS30292D-page 59

PIC16F87X

CCPR1H CCPR1L

TMR1H TMR1L

Comparator

Output

Logic

Special Event Trigger

Set Flag bit CCP1IF (PIR1<2>)

Match

RC2/CCP1

TRISC<2>

CCP1CON<3:0> Mode Select

Output Enable

Special event trigger will:

reset Timer1, but not set interrupt flag bit TMR1IF (PIR1<0>), and set bit GO/DONE (ADCON0<2>).

8.2 Compare Mode

In Compare mo de, th e 16- bit CC PR1 re gist er va lue is constantly compared against the TMR1 register pair value. When a match occurs, the RC2/CC P1 pin is:

• Driven high

•Driven low

• Remains unchanged The action on the pin is based on the value of control

bits CCP1M3:CCP1M0 (CCP1CON<3:0>). At the same time, interrupt flag bit CCP1IF is set.

FIGURE 8-2: COMPARE MODE

OPERATION BLOCK DIAGRAM

8.2.2 TIMER1 MODE SELECTION

Timer1 must be running in Timer mode, or Synchronized Counter mode, if the CCP module is using the compare feature. In Asynchronous Counter mode, the compare operation may not work.

8.2.3 SOFTWARE INTERRUPT MODE

When Generate Sof tware Interrupt mod e is chosen, the CCP1 pin is not affecte d. The CCPIF b it is set, c ausing a CCP interrupt (if enabled).

8.2.4 SPECIAL EVENT TRIGGER

In this mode, an internal hardware trigger is generate d, which may be used to initiate an action.

The special event trigger output of CCP1 resets the TMR1 regist er pai r. This al lows the CCP R1 r egis ter to effectively b e a 16-bit progra mmable pe riod registe r for Timer1.

The special event trigger output of CCP2 resets the TMR1 register pai r and starts an A/D co nv ersi on (if the A/D module i s enabled).

Note: The special event trigger from the

CCP1and CCP2 modul es w ill not set int errupt flag bit TMR1IF (PIR1<0>).

8.2.1 CCP PIN CONFIGURATION

The user must configure the RC2/CCP1 pin as an output by clearing the TRISC<2> bit.

Note: Clearing the CCP1CON register will force

the RC2/CCP1 compare output latch to the default low level. This is not the PORT C I/O data latch.

DS30292D-page 60  1998-2013 Microchip Technology Inc.

PIC16F87X

CCPR1L

CCPR1H (Slave)

Comparator

TMR2

Comparator

PR2

(Note 1)

Duty Cycle Registers

CCP1CON<5:4>

Clear Timer, CCP1 pin and latch D.C.

TRISC<2>

RC2/CCP1

Note 1: The 8-bit timer is concatenated with 2-bit internal Q

clock, or 2 bits of the prescaler, to create 10-bit timebase.

Period

Duty Cycle

TMR2 = PR2

TMR2 = Duty Cycle

TMR2 = PR2

log(

FPWM

log(2)

OSC

)

bits

Resolution

8.3 PWM Mode (PWM)

In Pulse Width Modulation mo de, the CCPx pin produces up to a 10-bit resolution PWM output. Since the CCP1 pin is multiplexed with the PORTC data latch, the TRISC<2> bit must be cleared to make the CCP1 pin an output.

Figure 8-3 shows a simplified block diagram of the CCP module in PWM mode.

For a step-by-step procedure on how to set up the C CP module for PWM operation, see Section 8.3.3.

FIGURE 8-3: SIMPLIFIED PWM BLOCK

A PWM output (Figure 8-4) has a time-base (period) and a time that the output stays high (duty cycle). The frequency of the PWM is the inverse of the period (1/period).

FIGURE 8-4: PWM OUTPUT

Note: Clearing the CCP1CON register will force

the CCP1 PWM output latch to the default low level. This is not the PORTC I/O data latch.

DIAGRAM

8.3.1 PWM PERIO D

The PWM period is spec ified by writin g to the PR2 register. The PWM period can be calculated using the following formula:

PWM period = [(PR2) + 1] • 4 • T

OSC •

(TMR2 prescale value)

PWM frequency is defined as 1 / [PWM period]. When TMR2 is eq ual to PR2, t he following three event s

occur on the ne xt increment cycle:

•TMR2 is cleared

• The CCP1 pin is set (exception: if PWM duty cycle = 0%, the CCP1 pin will not be set)

• The PWM duty cycle is latc hed from CC PR1L into CCPR1H

Note: The Tim er2 post sc al er (s ee Sec ti on 7.1) is

not used in the determination of the PWM frequency. The pos tscaler co uld be used to have a servo update rate at a different frequency than the PWM output.

8.3.2 PWM DUTY CYCLE

The PWM duty cycle is specified by writing to the CCPR1L register and to the CCP1CON<5:4> bits. Up to 10-bit re so l uti on is av ai l ab le. T he CC PR 1L c on tai ns the eight MSbs and the CCP1CON<5:4> contains the two LSbs. This 10-bit value is represented by CCPR1L:CCP1CON<5:4>. The following equation is used to calculate the PWM duty cycle in time:

P WM duty cy cl e = (CCP R1 L: CCP1CON<5:4>) •

OSC • (TMR2 prescale value)

CCPR1L and CCP1CON<5:4> can be written to at any time, but the duty cycle value is not latched into CCPR1H until after a match between PR2 and TMR2 occurs (i.e., the period is complete). In PWM mode, CCPR1H is a read-only register.

The CCPR1H register and a 2-bit internal latch are used to double buf fer the PWM duty cycle. Thi s doubl e buffering is essential for glitch-free PWM operation.

When the CCP R1H and 2 -bit latch match T MR2, c oncatenated with an internal 2-b it Q clock , or 2 bits of the TMR2 prescaler, the CCP1 pin is cleared.

The maximum PWM resolution (bits) for a given PWM frequency is given by the formula:

 1998-2013 Microchip Technology Inc. DS30292D-page 61

Note: If the PWM duty cycle value is longer than

the PWM period, the CCP1 pin will not be cleared.

PIC16F87X

8.3.3 SETUP FOR PWM OPERATION

The following steps should be taken when configuring the CCP module for PWM operation:

1. Set the PWM period by writing to the PR2 register.

3. Make the CCP1 pin an output by clearing the TRISC<2> bit.

4. Set the TMR2 prescale value a nd enable T imer2 by writing to T2CON.

5. Configure the CCP1 module for PWM o peration.

2. Set the PWM duty cycle by writing to the CCPR1L register and CCP1CON<5:4> bits.

TABLE 8-3: EXAMPLE PWM FREQUENCIES AND RESOLUTIONS AT 20 MHz

PWM Frequency 1.22 kHz 4.88 kHz 19.53 kHz 78.12kHz 156.3 kHz 208.3 kHz

Timer Prescaler (1, 4, 16) 16 4 1 1 1 1 PR2 Value 0xFFh 0xFFh 0xFFh 0x3Fh 0x1Fh 0x17h Maximum Resolution (bits) 10 10 10 8 7 5.5

TABLE 8-4: REGISTERS ASSOCIATED WITH CAPTURE, COMPARE, AND TIMER1

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh,8Bh, 10Bh, 18Bh

0Ch PIR1 0Dh PIR2 8Ch PIE1 8Dh PIE2 87h TRISC PORTC Data Direction Register 1111 1111 1111 1111 0Eh TMR1L Holding Register for the Least Significant Byte of the 16-bit TMR1 Register xxxx xxxx uuuu uuuu 0Fh TMR1H Holding Register for the Most Significant Byte of the 16-bit TMR1 Register xxxx xxxx uuuu uuuu 10h T1CON 15h CCPR1L Capture/Compare/PWM Register1 (LSB) xxxx xxxx uuuu uuuu 16h CCPR1H Capture/Compare/PWM Register1 (MSB) xxxx xxxx uuuu uuuu 17h CCP1CON 1Bh CCPR2L Capture/Compare/PWM Register2 (LSB) xxxx xxxx uuuu uuuu 1Ch CCPR2H Capture/Compare/PWM Register2 (MSB) xxxx xxxx uuuu uuuu 1Dh CCP2CON Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by Capture and Timer1.

Note 1: The PS P is not implemented on the PIC16F873/876; always maintain these bits clear.

INTCON GIE PEIE

(1)

PSPIF

PSPIE

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

— — — — — — — CCP2IF ---- ---0 ---- ---0

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

— — — — — — — CCP2IE ---- ---0 ---- ---0

— — T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON --00 0000 --uu uuuu

— — CCP1X CCP1Y CCP1M3 CCP1M2 CCP1M1 CCP1M0 --00 0000 --00 0000

— — CCP2X CCP2Y CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 --00 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

Value on:

POR,

BOR

Value on

all other

RESETS

DS30292D-page 62  1998-2013 Microchip Technology Inc.

TABLE 8-5: REGISTERS ASSOCIATED WITH PWM AND TIMER2

PIC16F87X

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh,8Bh, 10Bh, 18Bh

0Ch PIR1 0Dh PIR2 8Ch PIE1 8Dh PIE2 87h TRISC PORTC Data Di re cti o n Regi s t er 1111 1111 1111 1111 11h TMR2 T imer2 Module’s Register 0000 0000 0000 0000 92h PR2 Timer2 Mo dul e’s Period Re gi ste r 1111 1111 1111 1111 12h T2CON 15h CCPR1L Capture/Compare/PWM Register1 (LSB) xxxx xxxx uuuu uuuu 16h CCPR1H Capture/Compare/PWM Register1 (MSB) xxxx xxxx uuuu uuuu 17h CCP1CON 1Bh CCPR2L Capture/Compare/PWM Register2 (LSB) xxxx xxxx uuuu uuuu 1Ch CCPR2H Capture/Compare/PWM Register2 (MSB) xxxx xxxx uuuu uuuu 1Dh CCP2CON Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by PWM and Timer2.

Note 1: Bits PSPIE and PS PIF are reserv ed on the PIC16F873/876; always maintain these bits clear.

INTCON GIE PEIE

(1)

PSPIF

— — — — — — — CCP2IF ---- ---0 ---- ---0

PSPIE

— — — — — — —CCP2IE---- ---0 ---- ---0

— TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 -000 0000

— — CCP1X CCP1Y CCP1M3 CCP1M2 CCP1M1 CCP1M0 --00 0000 --00 0000

— — CCP2X CCP2Y CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 --00 0000

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

Value on:

POR,

BOR

Value on

all other

RESETS

 1998-2013 Microchip Technology Inc. DS30292D-page 63

PIC16F87X

NOTES:

DS30292D-page 64  1998-2013 Microchip Technology Inc.

9.0 MASTER SYNCHRONOUS

SERIAL PORT (MSSP) MODULE

The Master Synchronous Serial Port (MSSP) module is a serial interface, useful for communicating with other peripheral or microc ontroll er dev ices. Th ese p eriphera l devices may be serial EEPROMs, shift registers, display drivers, A/D converters, etc. The MSSP module can operate in one of two modes:

• Serial Peripheral Interface (SPI)

• Inter-Integrated Circuit (I Figure 9-1 shows a block diagram for the SPI mode,

while Figure 9-5 and Figure 9-9 show the block diagrams for the two different I

The Application Note AN734, “Using the PIC SSP for Slave I slave operation of the MSSP module on the PIC16F87X devices. AN735, “Using the PIC® MCU MSSP Module for I the master operation of the MSSP module on the PIC16F87X devices.

CTM Communication” describes the

C modes of operation.

MCU

CTM Communications” describes

PIC16F87X

 1998-2013 Microchip Technology Inc. DS30292D-page 65

PIC16F87X

R/W-0 R/W-0 R-0 R-0 R-0 R-0 R-0 R-0

SMP CKE D/A

bit 7 bit 0

bit 7 SMP: Sample bit

SPI Master mode:

1 = Input data sampled at end of data output time 0 = Input data sampled at middle of data output time

SPI Slave mode: SMP must be cleared when SPI is used in slave mode

C Master or Slave mode:

In I

1 = Slew rate control disabled for standard speed mode (100 kHz and 1 MHz) 0 = Slew rate control enabled for high speed mode (400 kHz)

bit 6 CKE: SPI Clock Edge Select (Figure 9-2, Figure 9-3 and Figure 9-4)

SPI mode: For CKP = 0

1 = Data transmitted on rising edge of SCK 0 = Data transmitted on falling edge of SCK

For CKP = 1

1 = Data transmitted on falling edge of SCK 0 = Data transmitted on rising edge of SCK

C Master or Slave mode:

In I

1 = Input levels conform to SMBus spec 0 = Input levels conform to I

bit 5 D/A: Data/Address

1 = Indicates that the last byte received or transmitted was data 0 = Indicates that the last byte received or transmitted was address

bit 4 P: STOP bit

(I2C mode only. This bit is cleared when the MSSP module is disabled, SSPEN is cleared.)

1 = Indicates that a STOP bit has been detected last (this bit is '0' on RESET) 0 = STOP bit was not detected last

bit 3 S: START bit

bit 2 R/W: Read/Write bit Information (I

bit 1 UA: Update Address (10-bit I

bit BF: Buffer Full Status bit

C mode only. This bit is cleared when the MSSP module is disabled, SSPEN is cleared.)

1 = Indicates that a START bit has been detected last (this bit is '0' on RESET) 0 = START bit was not detected last

This bit holds the R/W bit information following the last address match. This bit is only valid from the address match to the next START bit, STOP bit or not ACK

C Slave mode:

In I

1 = Read 0 = Write

In I

C Master mode:

1 = Transmit is in progress 0 = Transmit is not in progress

Logical OR of this bit with SEN, RSEN, PEN, RCEN, or ACKEN will indicate if the MSSP is in IDLE mode.

1 = Indicates that the user needs to update the address in the SSPADD register 0 = Address does not need to be updated

Receive (SPI and I2 C modes):

1 = Receive complete, SSPBUF is full 0 = Receive not complete, SSPBUF is empty

Transmit (I

1 = Data transmit in progress (does not include the ACK and STOP bits), SSPBUF is full 0 = Data transmit complete (does not include the ACK

bit (I2C mode only)

C mode only):

C specs

C mode only)

PSR/WUA BF

bit.

and STOP bits), SSPBUF is empty

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292D-page 66  1998-2013 Microchip Technology Inc.

PIC16F87X

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0

bit 7 bit 0

bit 7 WCOL: Write Collision Detect bit

Master mode:

1 = A write to SSPBUF was attempted while the I2C conditions were not valid 0 = No collision

Slave mode: 1 = SSPBUF register is written while still transmitting the previous word (must be cleared in software) 0 = No collision

bit 6 SSPOV: Receive Overflow Indicator bit

In SPI mode: 1 = A new byte is received while SSPBUF holds previous data. Data in SSPSR is lost on overflow. In Slave

mode, the user must read the SSPBUF, even if only transmitting data, to avoid overflows. In Master mode, the overflow bit is not set, since each operation is initiated by writing to the SSPBUF register. (Must be cleared in software.)

0 = No overflow

C mode:

In I 1 = A byte is received while the SSPBUF is holding the previous byte. SSPOV is a "don’t care" in Transmit

mode. (Must be cleared in software.)

0 = No overflow

bit 5 SSPEN: Synchronous Serial Port Enable bit

In SPI mode When enabled, these pins must be properly configured as input or output

1 = Enables serial port and configures SCK, SDO, SDI, and SS as the source of the serial port pins 0 = Disables serial port and configures these pins as I/O port pins

C mode,

In I When enabled, these pins must be properly configured as input or output

1 = Enables the serial port and configures the SDA and SCL pins as the source of the serial port pins 0 = Disables serial port and configures these pins as I/O port pins

bit 4 CKP: Clock Polarity Select bit

In SPI mode:

1 = Idle state for clock is a high level 0 = Idle state for clock is a low level

In I

C Slave mode:

SCK release control

1 = Enable clock 0 = Holds clock low (clock stretch). (Used to ensure data setup time.)

C Master mode:

In I Unused in this mode

bit 3-0

SSPM3:SSPM0: Synchronous Serial Port Mode Select bits

0000 = SPI Master mode, clock = F 0001 = SPI Master mode, clock = F 0010 = SPI Master mode, clock = F 0011 = SPI Master mode, clock = TMR2 output/2 0100 = SPI Slave mode, clock = SCK pin. SS 0101 = SPI Slave mode, clock = SCK pin. SS 0110 = I 0111 = I 1000 = I 1011 = I 1110 = I 1111 = I 1001, 1010, 1100, 1101 = Reserved

OSC/4 OSC/16 OSC/64

pin control enabled.

C Slave mode, 7-bit address

C Slave mode, 10-bit address

C Master mode, clock = FOSC / (4 * (SSPADD+1))

C Firmware Controlled Master mode (slave idle)

C Firmware Controlled Master mode, 7-bit address with START and STOP bit interrupts enabled

C Firmware Controlled Master mode, 10-bit address with START and STOP bit interrupts enabled

pin control disabled. SS can be used as I/O pin.

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’ 0’ = Bit is cleared x = Bit is unknown

 1998-2013 Microchip Technology Inc. DS30292D-page 67

PIC16F87X

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN

bit 7 bit 0

bit 7 GCEN: General Call Enable bit (In I

1 = Enable interrupt when a general call address (0000h) is received in the SSPSR 0 = General call address disabled

bit 6 ACKSTAT: Acknowledge Status bit (In I

In Master Transmit mode:

1 = Acknowledge was not received from slave 0 = Acknowledge was received from slave

bit 5 ACKDT: Acknowledge Data bit (In I

In Master Receive mode: Value that will be transmitted when the user initiates an Acknowledg e sequence at the end of a receive.

1 = Not Acknowledge 0 = Acknowledge

bit 4 ACKEN: Acknowledge Sequence Enable bit (In I

In Master Receive mode: 1 = Initiate Acknowledge sequence on SDA and SCL pins and transmit ACKDT data bit.

Automatically cleared by hardware.

0 = Acknowledge sequence idle

bit 3 RCEN: Receive Enable bit (In I

1 = Enables Receive mode for I 0 = Receive idle

bit 2 PEN: STOP Condition Enable bit (In I

SCK Release Control:

1 = Initiate STOP condition on SDA and SCL pins. Automatically cleared by hardware. 0 = STOP condition idle

bit 1 RSEN: Repeated START Condition Enable bit (In I

1 = Initiate Repeated START cond ition on SDA and SCL pins. Automatically cleared by hardware. 0 = Repeated START condition idle

bit 0 SEN: START Conditi on Enab le bit (In I2C Master mode only)

1 = Initiate START condition on SDA and SCL pins. Automatically cleared by hardware. 0 = START condition idle

C Slave mode only)

C Master mode only)

Note: For bits ACKEN, RCEN, PEN, RSEN, SEN: If the I

C module is not in the IDLE mode, this bit may not be set (no spoo lin g), an d t he SSPBUF may not be writte n (or writes to the SSPBUF are disabled).

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292D-page 68  1998-2013 Microchip Technology Inc.

PIC16F87X

Read Write

Internal

Data Bus

SSPSR Reg

SSPM3:SSPM0

bit0

Shift

Clock

Control

Enable

Edge

Select

Clock Select

TMR2 Output

OSC

Prescaler

4, 16, 64

Edge

Select

Data to TX/RX in SSPSR Data Direction bit

SMP:CKE

SDI

SDO

SCK

SSPBUF Reg

9.1 SPI Mode

The SPI mode allo ws 8 bits of data to be sync hronously transmitted and received simultaneously. All four modes of SPI are supported. To accomplish communication, typically three pins are used:

• Serial Data Out (SDO)

• Serial Data In (SDI)

• Serial Clock (SCK) Additionally, a fourth pin may be used when in a Slave

mode of operation:

• Slave Select (SS When initializing the SPI, several options need to be

specified. This is done by pro gramming th e appropriate control bits (SSPCON<5:0> and SSPSTAT<7:6>). These control bits allow the following to be specified:

• Master mode (SCK is the clock output)

• Slave mode (SCK is the clock input)

• Clock Polarity (Idle state of SCK)

• Data input sample phase (middle or end of data output time)

• Clock edge (output data on rising/falling edge of SCK)

• Clock Rate (Master mode only)

• Slave Select mode (Slave mode only)

Figure 9-4 shows the block diagram of th e MSSP module when in SPI mode.

To enable the serial port, MSSP Enable bit, SSPEN (SSPCON<5>) must be set. T o reset or rec onfigure SPI mode, clear bit SSPEN, re-initialize the SSPCON registers, and then set bit SSPEN. This configures the SDI, SDO, SCK and SS pins to behave as the serial port function, some must have their data direction bits (in the TRIS register) appropriately programmed. That is:

• SDI is automaticall y c ontrolled by the SPI mo dul e

• SDO must have TRISC<5> cleared

• SCK (Master mode) must have TRISC<3> cleared

• SCK (Slave mode) must have TRISC<3> set

must have TRISA<5> set and register

•SS ADCON1 (see Section11.0: A/D Modul e) must be set in a way that pin RA5 is confi gured a s a dig it al I/O

)

pins as serial port pins . For the

Any serial port function that is not desired may be overridden by programming the corresponding data direction (TRIS) register to the opposite value.

FIGURE 9-1: MSSP BLOCK DIAGRAM

(SPI MODE)

 1998-2013 Microchip Technology Inc. DS30292D-page 69

PIC16F87X

SCK (CKP = 0,

SDI (SMP = 0)

SSPIF

bit7 bit6 bit5

bit4

bit3

bit2

bit1 bit0

SDI (SMP = 1)

SCK (CKP = 0,

SCK (CKP = 1,

SDO

bit7

bit7 bit0

bit0

CKE = 0)

CKE = 1)

CKE = 0)

CKE = 1)

9.1.1 MASTER MODE

The master can initiate the data transfer at any time because it controls the SCK. The master determines when the slave (Processor 2, Figure 9-5) is to broadcast data by the software protoc ol.

In Master mode, the data is transmitted/received as soon as the SSPBUF register is written to. If the SPI module is only going to receive, the SDO output could be disabled (programmed as an input). The SSPSR register will conti nue to shif t in the signa l present o n the SDI pin at the programmed clock rate. As each byte is received, it will be loaded into the SSPBUF register as if a normal received byte (interrupts and status bits appropriately set). This could be useful in receiver applications as a “line activity monitor”.

The clock polarity is selected by appropriately programming bit CKP (SSPCON<4>). This then, would give waveforms for SPI communication as shown in

FIGURE 9-2: SPI MODE TIMING, MASTER MODE

Figure 9-6, Figure 9-8 and Figure 9-9, where the MSb is transmitted first. In Master mode, the SPI clock rate (bit rate) is user programmable to be one of the following:

OSC/4 (or TCY)

•F

OSC/16 (or 4 • TCY)

•FOSC/64 (or 16 • TCY)

• Timer2 output/2 This allows a maximu m bit clock freq uency (at 20 MHz)

of 5.0 MHz. Figure 9-6 shows the waveforms for Master mode.

When CKE = 1, the SDO data is valid before there is a clock edge on SCK. The change of the input sample is shown based on the state of the SMP bit. The time when the SSPBUF is loaded with the received data is shown.

DS30292D-page 70  1998-2013 Microchip Technology Inc.

PIC16F87X

SCK (CKP = 0)

SDI (SMP = 0)

SSPIF

bit7

bit6 bit5

bit4

bit3

bit2

bit1 bit0

SCK (CKP = 1)

SDO

bit7 bit0

SS (optional)

SCK (CKP = 0)

SDI (SMP = 0)

SSPIF

bit7

bit6 bit5

bit4

bit3

bit2

bit1 bit0

SCK (CKP = 1)

SDO

bit7 bit0

9.1.2 SLAVE MODE

In Slave mode, the data is tra nsmitted and r eceived as the external clock pulses ap pea r on SCK . When th e last bit is latched, the interrupt flag bit SSPIF (PIR1<3>) is set.

While in Slave mode, the external clock is supplied by the external clock source on the SCK pin. This external clock must meet the minimum high and low times as specified in the electrical specifications.

While in SLEEP mode, the slave can transmit/receive data. When a byte is received, the device will wake-up from SLEEP.

Note 1: When the SPI module is in Slave

mode with SS (SSPCON<3:0> = 0100), the SPI module will reset if the SS pin is set to VDD.

2: If the SPI is used in Slave mode with

CKE = '1', then SS enabled.

FIGURE 9-3: SPI MODE TIMING (SLAVE MODE WITH CKE = 0)

pin control enabled

pin control must be

FIGURE 9-4: SPI MODE TIMING (SLAVE MODE WITH CKE = 1)

 1998-2013 Microchip Technology Inc. DS30292D-page 71

PIC16F87X

TABLE 9-1: REGISTERS ASSOCIATED WITH SPI OPERATION

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh, 8Bh, 10Bh,18Bh

0Ch PIR1 8Ch PIE1 13h SSPBUF Synchronous Serial Port Receive Buffer/Transmit Register xxxx xxxx uuuu uuuu 14h SSPCON WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 0000 0000

94h SSPSTAT SMP CKE Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the SSP in SPI mode.

Note 1: These bits are reserved on PCI16F873/876 devices; always maintain these bits clear.

INTCON GIE PEIE

(1)

PSPIF PSPIE

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

D/A P S R/W UA B F 0000 0000 0000 0000

Value on:

POR, BOR

Value on:

MCLR

, WDT

DS30292D-page 72  1998-2013 Microchip Technology Inc.

PIC16F87X

Read Write

SSPSR Reg

Match Detect

SSPADD Reg

START and

STOP bit Detect

SSPBUF Reg

Internal

Data Bus

Addr Match

Set, Reset S, P bits

(SSPSTAT Reg)

SCL

Shift

Clock

MSb

LSb

SDA

9.2 MSSP I2C Operation

The MSSP module in I2C mode, fully implements all master and slav e functions (incl uding general call support) and provides interrupts on ST AR T and STO P bits in hardware, to determine a free bus (multi-master function). The MSSP modul e im plemen ts the s ta ndard m ode specification s, as wel l as 7-bit and 10-bi t addre ssin g.

Refer to Application Note AN578, "Use of the SSP

Module in the I

A "glitch" filter is on the SCL and SDA pins when the pi n is an input. This fil ter operates in both the 100 kH z an d 400 kHz modes. In the 10 0 kHz mode, whe n these pin s are an output, there is a sle w rate control of the pin th at is independent of device frequency.

FIGURE 9-5: I2C SLAVE MODE BLOCK

Two p ins a re use d for dat a tra nsfer. These are the SCL pin, which is the clock, and the SDA pin, which is the data. The SDA and SCL pins are automatically configured when the I functions are enabled by setting SSP Enable bit SSPEN (SSPCON<5>).

The MSSP module has six registers for I They are the:

• SSP Control Register (SSPCON)

• SSP Control Register2 (SSPCON2)

• SSP Status Register (SSPSTAT)

• Serial Receive/Transmit Buffer (SSPBUF)

• SSP Shift Register (SSPSR) - Not directly accessible

• SSP Address Register (SSPADD)

C Multi-Master Environment."

DIAGRAM

C mode is enabled. The SSP module

C operation.

The SSPCON register allows control of the I

C operation. Four mode selection bits (SSPCON<3:0>) allow one of the following I2C modes to be selected:

C Slave mode (7-bit address)

•I

C Slave mode (10-bit address)

•I2C Master mode, cl ock = OSC/4 (SSPADD +1)

•I2C firmware modes (provided for compatibility to

other mid-range product s)

Before selecting any I

C mode, the SCL and SDA pins must be programmed to inputs by setting the appropriate TRIS bits. Selecting an I2C mode by setting the SSPEN bit, enables the SCL and SDA pins to be used as the clock and data lines in I

C mode. Pu ll -u p res i stors must be provided externally to the SCL and SDA pins for the proper operation of the I2C module.

The CKE bit (SSPSTAT<6:7>) sets the levels of the SDA and SCL pins in either Master or Slave mode. When CKE = 1, the levels will conform to the SMBus specification. W hen C KE = 0 , th e le vels will conform to

C specification.

the I The SSPSTAT register gives the status of the data

transfer. This information includes detection of a START (S) or STOP (P) bit, specifies if the received byte was data or address, if the next byte is the completion of 10-bit address, and if this will be a read or write data transfer.

SSPBUF is the register to which the transfer data is written to, or read from. The SSPSR register shifts the data in or ou t of the device. In re ceive oper ations , the SSPBUF and SSPSR create a doubled buffered receiver. This allows reception of the next byte to begin before reading the last by te of receiv ed data. Wh en the complete byte is received, it is transferred to the SSPBUF register and flag bit SSPIF is set. If another complete byte is received before the SSPBUF register is read, a receiver overflow has occurred and bit SSPOV (SSPCON<6>) is set and the byte in the SSPSR is lost.

The SSPADD register holds the slave address. In 10-bit mode, the use r needs to write th e high byte of the address (1111 0 A9 A8 0). Following the high byte address match, the l ow byte of the address nee ds to be loaded (A7:A0).

 1998-2013 Microchip Technology Inc. DS30292D-page 73

PIC16F87X

9.2.1 SLAVE MODE

In Slave mode, the SCL and SDA pins must be confi gured as inputs. The MSSP module will override the input state with the output data, when required (slavetransmitter).

When an address is matched, or the data transfer af ter an address m atch is re ceiv ed, the hard ware aut omati cally will generate the Acknowledge (ACK then load the SSPBUF register with th e re ce ive d valu e currently in the SSPSR register.

There are certain conditions that will cause the MSSP module not to give thi s ACK (or both):

a) The buffer full bit BF (SSPSTAT<0>) was set

before the transfer was received.

b) The overflow bit SS POV (SSPCON<6>) was set

before the transfer was received.

If the BF bit is set, the SSPSR register value is not loaded into the SSPBUF, but bit SSPIF and SSPOV are set. Table 9-2 shows what happens when a data transfer byte is received, given the status of bits BF and SSPOV. The shaded cells show the condition where user software d id no t prope rly c lear th e ove rflo w cond ition. Flag bit BF is cleared by read ing the SSPBUF register, while bit SSPOV is cleared through software.

The SCL clock input must have a minimum high and low time for proper operation. The high and low times

of the I the MSSP module, is shown in timing parameter #100 and parameter #101 of the electrical specifications.

C specification, as well as the requirement of

pulse. These are if either

) pulse, and

9.2.1.1 Addressing

Once the MSSP module has been enabled, it waits for a ST AR T co nditio n to occur. Following the STAR T co ndition, the 8-bits are shif ted into the SSPSR register. All incoming bits are sampled with the rising edge of the clock (SCL) line. The value of register SSPSR<7:1> is compared to the value of the SSPADD register. The address is compared on the falling edge of the eighth clock (SCL) pulse. If the addresses match, and the BF and SSPOV bits are clear, the following events occur:

a) The SSPSR register value is loaded into the

SSPBUF register on the falling edge of the 8th SCL pulse.

b) The buffer full bit, BF, is set on the falling edge

of the 8th SCL pulse. c) An ACK pulse is generated. d) SSP interrupt flag bit, SSPIF (PIR1<3>), is set

(interrupt is generated if enabled) on the falling

edge of the 9th SCL pulse. In 10-bit address mode, two address bytes need to be

received by the slave. The five Most Significant bits (MSbs) of the first address byte specify if this is a 10-bit address. Bit R/W the slave device will receive the second address byte.

(SSPSTA T<2>) must specify a write so

For a 10-bit address, the first byte would equal ‘1111 0 A9 A8 0’, where A9 and A8 are the two MSbs of the address. The sequence of events for a 10-bit address is as follows, with steps 7-9 for slave-transmitter:

1. Receive first (high) byte of Address (bits SSPIF, BF and UA (SSPSTAT<1>) are set).

2. Update the SSPADD register with the second (low) byte of Address (clears bit UA and releases the SCL line ).

3. Read the SSPBUF register (clears bit BF) and clear flag bit SSPIF.

4. Receive second (low) byte of Address (bits SSPIF, BF and UA are set).

5. Update the SSPADD registe r with the f irst (high) byte of Address. This will clear bit UA and release the SCL line.

6. Read the SSPBUF register (clears bit BF) and clear flag bit SSPIF.

7. Receive Repeated Start condition.

8. Receive first (high) byte of Address (bits SSPIF and BF are set).

9. Read the SSPBUF register (clears bit BF) and clear flag bit SSPIF.

Note: Following the Repeated START condition

(step 7) in 10-bit mode, the user only needs to match the fi rst 7-bit ad dress. Th e user does not update the SSPADD for the second half of the address.

9.2.1.2 Slave Reception

When the R/W bit of the addres s byte is clear an d an address match occurs, the R/W register is cleared. Th e receive d addre ss is loa ded in to the SSPBUF register.

When the address byte overflow condition exists, then no Acknowledge (ACK condition is defined as either bit BF (SSPSTAT<0>) is set, or bit SSPOV (SSPCON<6>) is set. Thi s is an error condition due to user firmware.

An SSP interrupt is generated for each data transfer byte. Flag bit SSPIF (PIR1<3>) must be cleared in sof tware. The SSPSTAT register is used to determine the status of the received byte.

Note: The SSPBUF will be loaded if the SSPOV

bit is set and the BF flag is cleared. If a read of the SSPBUF was performed, but the user did not clear the state of the SSPOV bit before the next receive occurred, the ACK SSPBUF is updated.

) pulse is given. An overflow

bit of the SSPSTAT

is not sent and the

DS30292D-page 74  1998-2013 Microchip Technology Inc.

TABLE 9-2: DATA TRANSFER RECEIVED BYTE ACTIONS

D3D4

D6D7

A7 A6 A5 A4

A3 A2 A1SDA

SCL

1234

123

Bus Master Terminates Transfer

Bit SSPOV is set because the SSPBUF register is still full.

Cleared in software

SSPBUF register is read

ACK

Receiving Data

D3D4

D6D7

ACK

R/W=0

Receiving Address

SSPIF

BF (SSPSTAT<0>)

SSPOV (SSPCON<6>)

ACK

ACK is not sent.

Not

PIC16F87X

Status Bits as Data

Transfer is Received

BF SSPOV

SSPSR

SSPBUF

Generate ACK

Pulse

Set bit SSPIF

(SSP Interrupt occurs

if enabled)

0 0 Yes Yes Yes 1 0 No No Yes 1 1 No No Yes 0 1 Yes No Yes

Note: Shaded cells show the conditions where the user software did not properly clear the overflow condition.

9.2.1.3 Slave Transmission

When the R/W bit of the incoming address byte is set and an address match occurs, the R/W SSPSTAT register is set. The received address is loaded into the SSPBUF register. The ACK be sent on the ninth bit, and the SCL pin is held low. The transmit data must be loaded into the SSPBUF register, which also loads the SSPSR register. Then, the SCL pin should be enabled by setting bit CKP (SSPCON<4>). The master must monitor the SCL pin prior to asserting another clock pulse. The slave devices may be holding off the master by stretching the clock. The eight data bits are shifted out on the falling edge of the SCL input. This ensures that the SDA signal is vali d during the SCL high time (Figure 9-7).

bit of the

pulse will

An SSP interrupt is generated for each data transfer byte. The SSPIF flag bit must be cleared in software and the SSPST AT register is used to determine the status of the byte tran sf er. The SSPIF flag bit is set on the falling edge of the ninth clock pulse.

As a slave-transmitter, the ACK

pulse from the master receiver is latched on the rising edge of the ninth SCL input pulse. If the SDA line is high (not ACK), then the data transfer is comple te. Whe n the n ot ACK

is latched by the slave, the slave logic is r ese t a nd t he s lave then monitors for another occurrence of th e ST AR T bit. If the SDA line was low (ACK

), the transmit data must be loaded into the SSPBUF register, which also loads the SSPSR register. Then the SCL pin should be enabled by setting the CKP bit.

FIGURE 9-6: I2C WAVEFORMS FOR RECEPTION (7-BIT ADDRESS)

 1998-2013 Microchip Technology Inc. DS30292D-page 75

PIC16F87X

SDA

SCL

SSPIF BF (SSPSTAT<0>)

CKP (SSPCON<4>)

A7 A6 A5 A4 A3 A2 A1

ACK

D7 D6 D5 D4 D3 D2 D1 D0

Not ACK

Transmitting Data

R/W

= 1

Receiving Address

123456789 123456789

Cleared in software

SSPBUF is written in software

From SSP Interrupt

Service Routine

Set bit after writing to SSPBUF

Data in sampled

SCL held low while CPU

responds t o SSPIF

(the SSPBUF must be written to, before the CKP bit can be set)

R/W

= 0

SDA

SCL

SSPIF

SSPOV

Cleared in software SSPBUF is read

R/W

= 0

ACK

General Call Address

Address is compared to General Call Address

GCEN

Receiving data

ACK

123456789123456789

D7 D6 D5 D4 D3 D2 D1 D0

after ACK, set interrupt flag

'0'

'1'

(SSPSTAT<0>)

(SSPCON<6>)

(SSPCON2<7>)

FIGURE 9-7: I2C WAVEFORMS FOR TRANSMISSION (7-BIT ADDRESS)

9.2.2 GENERAL CALL ADDRESS SUPPORT

The addressing procedure for the I2C bus is such that the first byte after the START condition usually determines which device will be the slave addressed by the master. The exception is the gene ral call address , which can address all devices. When this address is used, all devices should, in theory , respond with an acknowledge.

The general call address is one of eight addresses reserved for specific purposes by the I consists of all 0’s with R/W

= 0.

The general call address is recognized when the General Call Enable bit (GCEN) is enabled (SSPCON2<7> is set). Following a START bit detect, 8 bits are shifted into SSPSR and the address is compared against

C protocol. It

If the general call address matches, the SSPSR is transferred to the SSPBUF, the BF flag is set (eighth bit), and on the falling edge of the ninth bit (ACK

bit),

the SSPIF flag is set. When the interrupt is serv ic ed, the s ou r ce f or the int er-

rupt can be checked by reading the contents of the SSPBUF to determine if the address was device specific, or a general call address.

In 10-bit mode, the SSPADD is required to be updated for the second half of the address to match , and the UA bit is set (SSPSTAT<1>). If the general call address is sampled when GCEN is set, while the slave is configured in 10-bit address mode, then the second half of the address is not ne cessary, the UA bit w il l n ot be set, and the slave will begin receiving data after the Acknowledge (Figure9-8).

SSPADD. It is also compared to the general call address and fixed in hardware.

FIGURE 9-8: SLAVE MODE GENERAL CALL ADDRESS SEQUENCE (7 OR 10-BIT MODE)

DS30292D-page 76  1998-2013 Microchip Technology Inc.

PIC16F87X

9.2.3 SLEEP OPERATION

While in SLEEP mode, the I2C module can receive addresses or data. When an address match or com-

9.2.4 EFFECTS OF A RESET

A RESET disables the SSP module and terminates the

current tran sfer. plete byte transfer occurs, wake the processor from SLEEP (if the SSP interrupt is enabled).

TABLE 9-3: REGISTERS ASSOCIATED WITH I2C OPERATION

C mode.

Value on:

MCLR,

WDT

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh, 8Bh, 10Bh,18Bh

0Ch PIR1 8Ch PIE1

0Dh PIR2 8Dh PIE2 13h SSPBUF Synchronous Serial Port Receive Buffer/Transmit Register xxxx xxxx uuuu uuuu 14h SSPCON WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 0000 0000 91h SSPCON2 GCEN ACKSTA T ACKDT ACKEN RCEN PEN RSEN SEN 0000 0000 0000 0000

93h SSPADD I 94h SSPSTA T SMP CKE D/A

Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the SSP in I Note 1: These bits are reserved on PIC16F873/876 devices; always maintain these bits clear.

INTCON GIE PEIE

(1)

PSPIF

PSPIE

— (2) — EEIF BCLIF — — CCP2IF -r-0 0--0 -r-0 0--0 — (2) — EEIE BCLIE — — CCP2IE -r-0 0--0 -r-0 0--0

C Slave Address/Master Baud Rate Register 0000 0000 0000 0000

2: These bits are reserved on these devices; always maintain these bits clear.

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

PSR/WUA BF 0000 0000 0000 0000

Value on:

POR, BOR

 1998-2013 Microchip Technology Inc. DS30292D-page 77

PIC16F87X

Read Write

SSPSR

START bit, STOP bit,

SSPBUF

Internal

Data Bus

Set/Reset, S, P, WCOL (SSPSTAT)

Shift

Clock

MSb

LSb

SDA

Acknowledge

Generate

SCL

SCL in Bus Collision

SDA in

Receive Enable

Clock Cntl

Clock Arbitrate/WCOL Detect

(hold off clock source)

SSPADD<6:0>

Baud

Set SSPIF, BCLIF Reset ACKSTAT, PEN (SSPCON2)

Rate Generator

SSPM3:SSPM0,

START bit Detect,

STOP bit Detect

Write Collision Detect

Clock Arbitration

State Counter for

end of XMIT/RCV

9.2.5 MASTER MODE

Master mode of operation is supported by interrupt generation on the detection of the START and STOP conditions. The STOP (P) and START (S) bits are cleared from a RESET, or when the MSSP module is disabled. Control of the I P bit is set, or the bus is idle, with bo th the S and P bit s clear.

C bus may be t aken when th e

The following events will cause the SSP Interrupt Flag bit, SSPIF, to be set (an SSP interrupt will occur if enabled):

• START condition

• STOP condition

• Data transfer byte transmitted/received

• Acknowledge transmit

• Repeated START

In Master mode, the SCL and SDA lines are manipulated by the MSSP hardware.

FIGURE 9-9: SSP BLOCK DIAGRAM (I2C MASTER MODE)

9.2.6 MULTI-MASTER MODE

In Multi-Master mode, the interrupt generation on the detection o f the START and STOP conditions al lows the determination of when the bus is free. The STOP (P) and START (S) bits are cleared from a RESET or when the MSSP module is disabled . Control of the I bus may be taken when bit P (SSPSTAT<4>) is set, or the bus is idle with both the S and P bits clear. When the bus is busy, enabling the SSP Interrupt will gener-

ate the interrupt when the STOP condition occurs.

DS30292D-page 78  1998-2013 Microchip Technology Inc.

In Multi-Master operation, the SDA line must be monitored for arbitration to see if the signal level is the expected output leve l. This chec k is perfor med in hardware, with the result placed in the BCLIF bit.

The states where arbitration can be lost are:

• Address Trans fer

• Data Transfer

• A START Condition

• A Repeated START Condition

• An Acknowledge Condition

PIC16F87X

SSPM3:SSPM0

BRG Down Counter

CLKOUT

OSC/4

SSPADD<6:0>

SSPM3:SSPM0

SCL

Reload Control

Reload

9.2.7 I2C MASTER MODE SUPPORT

Master mode is enabled by setting and clearing the appropriate SSPM bits in SSPCON and by setting the SSPEN bit. Once Master mode is enabled, the user has six options:

• Assert a START condition on SDA and SCL.

• Assert a Repeated START condition on SDA and

SCL.

• Write to the SSPBUF register initiating transmis-

sion of data/address.

• Generate a STOP condition on SDA and SCL.

• Configure the I

• Generate an Acknowled ge cond ition at the end of

a received byte of data. Note: The MSSP Module, when confi gured in I2C

C port to receive data.

Master mode, does not allow queueing of events. For instance, the user is not allowed to initiate a START condition and immediately write the SSPBUF register to initiate transmission before the START condition is complete. In this case, the SSPBUF will not be written to and the WCOL bit will be set, indicating that a write to the SSPBUF did not occur.

SSPBUF. Once the given operation is complete (i.e.,

transmission of the last d ata bit is followed b y ACK), the

internal clock will automatically stop counting and the

SCL pin will remain in its last state.

A typical transmit sequence would go as follows:

a) User generates a START condition by setting

the START enable bit (SEN) in SSPCON2.

b) SSPIF is set. The module will wait the required

start time before any other operation takes place. c) User loads SSPBUF with address to transmit. d) Address is s hi f ted o ut the SDA pin until al l 8 bits

are transmitted. e) MSSP module shifts in the ACK bit from the

slave device and writes its value into the

SSPCON2 register (SSPCON2<6>). f) MSSP module generates an interrupt at the end

of the ninth clock cycle by setting SSPIF. g) User loads SSPBUF with eight bits of data. h) DA T A is shifted out the SDA pin unti l all 8 bit s are

transmitted. i) MSSP module shifts in the ACK bit from the

slave device, and writes its value into the

SSPCON2 register (SSPCON2<6>). j) MSSP module genera tes an interru pt at the end

of the ninth clock cycle by setting the SSPIF bit.

9.2.7.1 I2C Master Mode Operation

The master device generates all of the serial clock pulses and the START and STOP conditions. A tran sfer is ended with a STOP condition or with a Repeated

k) User generates a STOP conditi on by setting the

STOP enable bit, PEN, in SSPCON2. l) Interrupt is generated once the STOP condition

is complete.

START condition. Since the Re peated START condition is also the beginning of the nex t s eri al tran sfe r, the

C bus will not be released.

I In Master Transmitter mode, serial data is output through

SDA, while SCL outputs the serial cl ock. The first by te transmitted con tains the slave addres s of the receiving device (7 bit s) and t he Re ad/W rite (R/W the R/W

bit will be logic '0'. Serial data is transmitted 8 bits

) bit. In this case ,

at a time. After each byte is transmitted, an Acknowledge bit is received. START and STOP conditions are output to indicate the beginning and the end of a serial transfer.

9.2.8 BAUD RATE GENERATOR

In I2C Master mode, the reload value for the BRG is located in the lower 7 bits of the SSPADD register (Figure 9-10). When the BRG is loaded with this value, the BRG counts down to 0 and stops until another reload has taken place. The BRG count is decremented twice per instruction cycle (T

C Master mode, the BRG is reloaded automatically. If

In I clock arbitration is taking place, the BRG will be reloaded when the SCL pin is sampled high (Figure 9-11).

CY), on the Q2 and Q4 clock.

In Master Receive mode, the firs t byte transmitt ed contains the slave address of the transmitting device (7 bits) and the R/W

bit. In this case, the R/W bit will be

Note: Baud Rate = FOSC / (4 * (SSPADD + 1) )

logic '1'. Thus, the first byte transmitted is a 7-bit slave address foll owed by a '1' t o indi cate re ceive bit. Se rial data is receiv ed vi a SDA , whi le SC L outp uts th e ser ial clock. Serial dat a is rec eived 8 bits at a tim e. Aft er each

FIGURE 9-10: BAUD RATE GENERATOR

BLOCK DIAGRAM

byte is received, an Acknowledge bit is transmitted. START and STOP conditions indicate the beginning and end of transmission.

The baud rate generator used for SPI mode operation is now used to set the SCL clock frequency for either 100 kHz, 400 kHz, or 1 MHz I rate generator reload value is contained in the lower 7 bits of the SSPADD register. The baud rate generator

C operation. The baud

will automatically begin counting on a write to the

 1998-2013 Microchip Technology Inc. DS30292D-page 79

PIC16F87X

SDA

SCL

SCL de-asserted but slave holds

DX-1DX

BRG

SCL is sampled high, reload takes place, and BRG starts its count

03h 02h 01h 00h (hold off) 03h 02h

Reload

BRG Value

SCL low (clock arbitration)

SCL allowed to transition high

BRG decrements (on Q2 and Q4 cycles)

SDA

SCL

TBRG

1st Bit

2nd Bit

TBRG

SDA = 1,

At completion of START bit,

SCL = 1

Write to SSPBUF occurs here

TBRG

Hardware clears SEN bit

TBRG

Write to SEN bit occurs here

Set S bit (SSPSTAT<3>)

and sets SSPIF bit

FIGURE 9-11: BAUD RATE GENERATOR TIMING WITH CLOCK ARBITRATION

9.2.9 I

C MASTER MODE START

CONDITION TIMING

To initiate a START condi tion, the user sets the START condition enable bit, SEN (SSPCON2<0>). If the SDA and SCL pins are samp led hig h, th e ba ud ra te generator is reloaded with the contents of SSPADD<6:0> and starts it s c oun t. If SCL and SDA are bot h s ampl ed high when the baud rate generator times out (T

BRG), the

SDA pin is driven low. The action of the SDA being driven low while SCL is high is the START condition, and causes the S bit (SSPSTAT<3>) to be set. Following this, the baud rate generator is reloaded with the contents of SSPADD<6:0> and resumes its count. When the baud rate generator times out (T

BRG), the

SEN bit (SSPCON2<0>) will be automatically cleared by hardware. The baud rate generator is suspended, leaving the SDA li ne held low, and the STAR T conditio n is complete .

FIGURE 9-12: FIRST START BIT TIMING

Note: If, at the beginning of START condition, the

SDA and SCL pins are already sampled low, or if during t he START condition the SCL line is sampled low before the SDA line is driven low, a bus collision occurs, the Bus Collision Interrupt Flag (BCLIF) is set, the START condition is aborted, and

C module is reset into its IDLE state.

the I

9.2.9.1 WCOL Status Flag

If the user writes the SSPBUF when a START sequence is in progress, then WCOL is set and the contents of the bu ffe r are un chang ed (the w rite doe sn’t occur).

Note: Because queueing of events is not

allowed, writing to the lower 5 bits of SSPCON2 is disabled until the START condition is complete .

DS30292D-page 80  1998-2013 Microchip Technology Inc.

PIC16F87X

SDA

SCL

Sr = Repeated START

Write to SSPCON2

Write to SSPBUF occurs here

Falling edge of ninth clock

End of Xmit

At completion of START bit, hardware clears RSEN bit

1st bit

Set S (SSPSTAT<3>)

BRG

SDA = 1,

SCL (no change)

SCL = 1

occurs here

TBRG TBRG

TBRG

and sets SSPIF

9.2.10 I2C MASTER MODE REPEATED START CONDITION TIMING

A Repeated START condition occurs when the RSEN bit (SSPCON2<1>) is programmed high and the I module is in the IDLE state. When the RSEN bit is set, the SCL pin is asserted low. When the SCL pin is sampled low, the baud rate generator is loaded with the contents of SSPADD<6:0> and begins counting. The SDA pin is released (brought high) for one baud rate generator count (T

BRG). When the baud rate genera tor

times out, if SD A is sampl ed hi gh, th e SCL pin w ill be de-asserted (brought high). When SCL is sampled high the baud rate genera tor is reloaded w ith the conten ts of SSPADD<6:0> and begins counting. SDA and SCL must be sampled high for one T

BRG. This action is then

followed by assertion of the SDA pin (SDA is low) for

BRG, while SCL is high. Follo wing thi s, t he RSEN

one T bit in the SSPCON2 register will be automatically cleared and the baud rate generator will not be reloaded, leaving the SDA pin held low. As soon as a ST ART cond ition is det ected on the SDA and SCL p ins, the S bit (SSPSTAT<3>) will be set. The SSPIF bit will not be set until the ba ud rate generator has timed out.

Note 1: If RSEN is programmed while any other

event is in progress, it will not take effect.

2: A bus collision during the Repeated

START condition occurs if:

• SDA is sampled low wh en SCL goes from low to high.

• SCL goes low before SDA is asserted low . This may indicate that another master is attempting to transmit a data "1".

Immediately following the SSPIF bit getting set, the user may write the SSPBUF with the 7-bit address in 7-bit mode, or the default first address in 10-bit mode. After the first eight bits are transmitted and an ACK is

received, the use r may then transmi t an additional e ight bits of address (1 0-bit mod e), or ei ght bi t s of dat a (7-b it mode).

9.2.10.1 WCOL Status Flag

If the user writes the SSPBUF when a Repeated START sequence is in progress, then WCOL is set and the contents of the buffer are unchanged (the write doesn’t occur).

Note: Because queueing of events is not

allowed, writing of the lower 5 bits of SSPCON2 is disabled until the Repeated START condition is complete.

FIGURE 9-13: REPEAT START CONDITION WAVEFORM

 1998-2013 Microchip Technology Inc. DS30292D-page 81

PIC16F87X

9.2.11 I2C MASTER MODE TRANSMISSION

Transmission of a data byte, a 7-bit address, or either half of a 10-bit address, is accomplished by simply writing a value to SSPBUF register. This action will set the Buffer Full flag (BF) and allow the baud rate generator to begin counting a nd star t the next trans mission. Eac h bit of address/data will be shifted out onto the SDA pin after the falling edg e of SCL is ass erte d (se e data hold time spec). SCL i s held low for o ne baud rate gen erator rollover count (T is released high (see data setup time spec). When the SCL pin is r eleased high, i t is hel d that w ay for T The data on the SDA pin must remain stable for that duration and some hold ti me after the next fallin g edg e of SCL. After the eighth bit is shifted out (the falling edge of the eighth c lock), the BF f lag is cl eared and th e master releases SDA allowing the slave device being addressed t o res p on d w ith an ACK bit time, if an address match occurs or if data was received properly. The status of ACK is read into the ACKDT on the falling edge of the ninth clock. If the master receives an Acknowledge, the Acknowledge Status bit (ACKSTAT) is cleared. If not, the bit is set. After the ninth clock, the SSPIF is set and the master clock (baud rate gene rator ) is suspended until the next data byte is loaded into the SSPBUF, leaving SCL low and SDA unchanged (Figure 9-14).

After the write to the SSPBUF, each bit of address will be shifted out on the fal ling edge of SC L, until all seve n address bits and the R/W ing edge of the eighth clock, the master will de-assert the SDA pin, allowing the slave to respond with an Acknowledge. On th e falling edge o f the ninth clock , the master will sample the SDA pin to see if the address was recognized by a slave. The status of the ACK bit is loaded into the ACKSTAT status bit (SSPCON2<6>). Following t he falli ng edge o f the ni nth clock transmis sion of the address, the SSPIF is set, the BF flag is cleared, and the baud rate generator is turned off until another write to the SSPBUF takes place, holdi ng SCL low and allowing SDA to float.

BRG). Data should be valid before SCL

BRG.

bit during the ninth

bit are complet ed. On the fall-

9.2.11.1 BF Status Flag

In Transmit mode, the BF bit (SSPSTAT<0>) is set when the CPU writes to SSPBUF and is cleared when all 8 bits are shifted out.

9.2.11.2 WCOL Status Flag

If the user writes the SSPBUF when a transmit is already in progress (i.e., SSPSR is still shifting out a data byte), then WCOL is set and the contents of the buffer are unchanged (the write doesn’t occur).

WCOL must be cleared in software.

9.2.11.3 ACKSTAT Status Flag

In Transmit mod e, the ACKSTAT bit (SSPCON2<6>) is cleared when the slave has sent an Acknowledge (ACK = 0), and is set when the sl ave does not Acknow ledge (ACK it has recognized its address (including a general call), or when the slave has properly received its data.

= 1). A slave sends an Acknowledg e when

DS30292D-page 82  1998-2013 Microchip Technology Inc.

PIC16F87X

SDA

SCL

SSPIF

BF (SSPST AT<0>)

SEN

A7 A6 A5 A4 A3 A2 A1 ACK = 0 D7D6D5D4D3D2D1D0

ACK

Transmitting Data or Second Half

R/W

= 0Transmit Address to Slave

123456789 123456789

Cleared in software service routine

SSPBUF is written in software

From SSP interrupt

After START condition SEN, cleared by hardware.

SSPBUF written with 7-bit address and R/W

start transmit

SCL held low

while CPU

responds to SSPIF

SEN = 0

of 10-bit address

Write SSPCON2<0> SEN = 1

START condition begins

From slave clear ACKSTAT bit SSPCON2<6>

ACKSTAT in

SSPCON2 = 1

Cleared in software

SSPBUF written

PEN

Cleared in software

R/W

FIGURE 9-14: I2C MASTER MODE TIMING (TRANSMISSION, 7 OR 10-BIT ADDRESS)

 1998-2013 Microchip Technology Inc. DS30292D-page 83

PIC16F87X

9.2.12 I2C MASTER MODE RECEPTION

Master mode recepti on is enab led by pr ogrammin g the Receive Enable bit, RCEN (SSPCON2<3>).

Note: The SSP module must be in a n IDL E st a te

before the RCEN bit is set, or the RCEN bit will be disregarded.

The baud rate genera tor b egi ns cou nti ng, and on each rollover, the state of the SCL pin changes (high to low/ low to high), and data is shifted into the SSPSR. After the falling edge of the eighth clock, the receive enable flag is automatically cleared, the contents of the SSPSR are loaded into the SSPBUF, the BF flag is set, the SSPIF is set, and the baud rate generator is suspended from counting, holding SCL low. The SSP is now in IDLE state, awaiting the next command. When the buffer is read by the CPU, the BF flag is automatically cleared. The us er can then s end an Acknowl edge bit at the end of reception, by setting the Acknowledge Sequence Enable bit, ACKEN (SSPCON2<4>).

9.2.12.1 BF Status Flag

In receive operation, BF is set when an address or data byte is loaded into SSPBUF from SSPSR. It is cleared when SSPBUF is read.

9.2.12.2 SSPOV Status Flag

In receive operation, SSPOV is set when 8 bits are received into the SSPSR, and the BF flag i s already set from a previous reception.

9.2.12.3 WCOL Status Flag

If the user writes the SSPBUF when a receive is already in progress (i.e., SSPSR i s still shifting in a dat a byte), then WCOL is set and the contents of the buffer are unchanged (the write doesn’t occur).

DS30292D-page 84  1998-2013 Microchip Technology Inc.

PIC16F87X

6 5

D3D4

D6D7

A7 A6 A5 A4

A3 A2 A1

SDA

SCL

678 9

1234

Bus Master

terminates

transfer

ACK

Receiving Data from Slave

D3D4

D6D7

ACK

R/W

= 1

Transmit Address to Slave

SSPIF

ACK

is not sent

Write to SSPCON2<0> (SEN = 1)

Write to SSPBUF occurs here

ACK from Slave

Master configured as a receiver

by programming SSPCON2<3>, (RCEN = 1)

PEN bit = 1

written here

Data shifted in on falling edge of CLK

Cleared in software

Start XMIT

SEN = 0

SSPOV

SDA = 0, SCL = 1

while CPU

(SSPSTAT<0>)

ACK

Last bit is shifted into SSPSR and

contents are unloaded into SSPBUF

Cleared in software

Set SSPIF interrupt

at end of receive

Set P bit

(SSPSTA T<4>)

and SSPIF

Cleared in

software

ACK from Master

Set SSPIF at end

Set SSPIF interrupt

at end of acknowledge

sequence

Set SSPIF interrupt

at end of Acknow-

ledge sequence

of receive

Set ACKEN to start Acknowledge sequence

SSPOV is set because

SSPBUF is still full

SDA = ACKDT = 1

RCEN cleared

automatically

RCEN = 1 start

next receive

Write to SSPCON2<4>

to start Acknowledge sequence

SDA = ACKDT (SSPCON2<5>) = 0

RCEN cleared

automatically

responds to SSPIF

ACKEN

Begin START Condition

Cleared in software

SDA = ACKDT = 0

FIGURE 9-15: I2C MASTER MODE TIMING (RECEPTION, 7-BIT ADDRESS)

 1998-2013 Microchip Technology Inc. DS30292D-page 85

PIC16F87X

Note: TBRG = one baud rate generator period.

SDA

SCL

Set SSPIF at the end

Acknowledge sequence starts here,

Write to SSPCON2

ACKEN automatically cleared

Cleared in

TBRG

of receive

ACK

ACKEN = 1, ACKDT = 0

SSPIF

software

Set SSPIF at the end of Acknowledge sequence

Cleared in software

9.2.13 ACKNOWLEDGE SEQUENCE TIMING

rate generator cou nts for T pulled low. Following this, t he ACKEN bi t is au to mat ically cleared, the baud rate generator is turned off,

An Acknowledge sequence is enabled by setting the Acknowledge Sequence Enable bit, ACKEN (SSPCON2<4>). When this bit is set, the SCL pin is pulled low and the content s of the Acknowledge dat a bit is presented on the SD A pin . If t he user wishes to ge nerate an Acknowledge, the ACKDT bit should be cleared. If not, the user should set the ACKDT bit before starting an Acknowledge sequence. The baud rate generator then counts for one rollover period

BRG), and the SCL pin is de-asserted high. When the

and the SSP module then goes into IDLE mode (Figure 9-16).

9.2.13.1 WCOL Status Flag

If the user writes the SSPBUF when an Acknowledge sequence is in progress , the WCOL is set and the contents of the buffer are unchanged (the write doesn’t occur).

SCL pin is sampled high (clock arbitration), the baud

FIGURE 9-16: ACKNOWLEDGE SEQUENCE WAVEFORM

BRG. The SCL pin is t hen

DS30292D-page 86  1998-2013 Microchip Technology Inc.

PIC16F87X

SCL

SDA

SDA asserted low before rising edge of clock

Write to SSPCON2

Set PEN

Falling edge of

SCL = 1 for T

BRG, followed by SDA = 1 for TBRG

9th clock

SCL brought high after T

BRG

Note: TBRG = one baud rate generator period.

BRG

TBRG

after SDA sampled high. P bit (SSPSTAT<4>) is set.

BRG

to setup STOP condition

ACK

BRG

PEN bit (SSPCON2<2>) is cleared by hardware and the SSPIF bit is set

9.2.14 STOP CONDITION TIMING

A STOP bit is asserted on the SDA pin at the end of a receive/t ransmi t by s etti ng th e Stop Sequen ce E nable bit, PEN (SSPCON2<2>). At the end of a receive/ transmit, the SCL line is held low after the falling edge of the ninth clock. When the PEN bit is set, the master will assert the SDA line lo w . Whe n the SDA line is sampled low, the baud rate generator is reloaded and counts down to 0. Wh en th e ba ud rat e ge nerator times out, the SCL pin will be brought high, and one T (baud rate generator rollover count) later, the SDA pin will be de-asserted. Wh en the SDA pin is sam pled high

BRG

while SCL is high, the P bit (SSPSTAT<4>) is set. A

BRG later, the PEN bit is cleared and the SSPIF bit is

T set (Figure 9-17).

Whenever the firmware decides to take control of the bus, it will firs t dete rm ine if the bus is bu sy b y ch eck in g the S and P bits in the SSPSTAT register. If the bus is busy, then the CPU can be interrupted (notified) when a STOP bit is detected (i.e., bus is free).

9.2.14.1 WCOL Status Flag

If the user writes the SS PBUF when a ST OP se quence is in progress, then WCOL is set and th e contents o f the buffer are unchanged (the write doesn’t occur).

FIGURE 9-17: STOP CONDITION RECEIVE OR TRANSMIT MODE

 1998-2013 Microchip Technology Inc. DS30292D-page 87

PIC16F87X

SCL

SDA

BRG overflow, Release SCL,

If SCL = 1, Load BRG with SSPADD<6:0>, and start count

BRG overflow occurs, Release SCL, Slave device holds SCL low

SCL = 1, BRG starts counting clock high interval

SCL line sampled once every machine cycle (T

OSC  4).

Hold off BRG until SCL is sampled high.

TBRG

to measure high time interval

9.2.15 CLOCK ARBITRATION

Clock arbitration occurs when the master, during any receive, transmit, or Repeated START/STOP condition, de-asserts th e SCL pin (SCL allowed to float high). When the SCL pin is allowed to floa t high, the baud rate

9.2.16 SLEEP OPERATIO N

While in SLEEP mode, the I2C module can receive addresses or data, and when an address match or complete byte transfer occurs, wake the processor

from SLEEP (if the SSP interrupt is enabled). generator (BRG) is suspended from counting until the SCL pin is actually sam ple d hi gh. W hen the SC L p in i s sampled high, the baud rate gen erator is reloaded with the contents of SSPADD<6:0> and begins counting. This ensures that the SCL high time will always be at

9.2.17 EFFECTS OF A RESET

A RESET disables the SSP module and terminates the

current tran sfer. least one BRG rollover c ount in the e vent that the clock

is held low by an external device (Figure 9-18).

FIGURE 9-18: CLOCK ARBITRATION TIMING IN MASTER TRANSMIT MODE

DS30292D-page 88  1998-2013 Microchip Technology Inc.

PIC16F87X

SDA

SCL

BCLIF

SDA released

SDA line pulled low

by another source

Sample SDA. While SCL is high, data doesn’t match what is driven

Bus collision has occurred.

Set bus collision interrupt

by the master.

by master

Data changes while SCL = 0

9.2.18 MULTI -MASTER COMMUNICATION, BUS COLLISION, AND BUS ARBITRATION

Multi-Master mode support is achieved by bus arbitration. When the master outputs address/data bits onto the SDA pin, arbitration takes place when the master outputs a '1' on SDA, by letting SDA float high and another master asserts a ' 0'. Whe n th e SC L pi n fl oats high, data should be stable. If the expected data on SDA is a '1' and the data s ampl ed on the SD A pin = '0' , a bus collision has t ak en place. The master will set the Bus Collision Interrupt Flag, BCLIF and reset the I port to its IDLE state (Figure 9-19).

If a transmit was in progress when the bus collision occurred, the transmission is halted, the BF flag is cleared, the SDA and SCL lines are de-asserted, and the SSPBUF can be w ritten t o. When the u ser se rvice s the bus collision Interrupt Service Routine, and if the

C bus is free, the user can res ume commu nication b y

If a START, Repeated START, STOP, or Acknowledge condition was in progress when the bus collision occurred, t he condition is aborted, t he SDA and SCL lines are de-assert ed, and t he respe ctiv e contro l bit s in the SSPCON2 register are cleared. When the user services the bus collision Interrupt Service Routine, and if

C bus is free, the use r can resume communicatio n

the I by asserting a START condition.

The master will continue to monitor the SDA and SCL pins and if a STOP condition occurs, the SSPIF bit will be set.

A write to the SSPBUF will start the transmission of data at the first data bit, regardless of where the transmitter left off when the bus collision occurred.

In Multi-Master mode, the interrupt generation on the detection of START and STOP conditions allows the determination of whe n the bus is free. Con trol of the I bus can be taken when the P bit is set in the SSPSTAT register, or the bus is idle and the S and P bits are cleared.

asserting a START conditio n.

FIGURE 9-19: BUS COLLISION TIMING FOR TRANSMIT AND ACKNOWLEDGE

 1998-2013 Microchip Technology Inc. DS30292D-page 89

PIC16F87X

SDA

SCL

SEN

SDA sampled low before

SDA goes low before the SEN bit is set.

S bit and SSPIF set because

SSP module reset into IDLE state.

SEN cleared automatically because of bus collision.

S bit and SSPIF set because

Set SEN, enable START

condition if SDA = 1, SCL = 1

SDA = 0, SCL = 1.

BCLIF

SSPIF

SDA = 0, SCL = 1.

SSPIF and BCLIF are cleared in software

Set BCLIF,

Set BCLIF.

START condition.

9.2.18.1 Bus Collision During a START Condition

During a START condition, a bus collision occurs if: a) SDA or SCL are s ampled low a t the beginning of

the START condition (Figure 9-20).

b) SCL is sampl ed l ow be fore SD A is as se rted low

(Figure 9-21).

During a START condition, both the SDA and the SCL pins are monitored. If e ither the SDA pi n or is already low, then these events all occur:

• the START condition is aborted,

•and

the BCLIF flag is set,

•and the SSP module is reset to its IDLE state

(Figure 9-20).

The START condition begins with the SDA and SCL pins de-asserted. When the SDA pin is sampled high, the baud rate generator is loaded from SSPADD<6:0> and counts down to 0. If the SCL pin is sampled low while SDA is high, a bus collision occurs, because it is assumed that another master is attempting to drive a

the SCL pin

If the SDA pin is sampled low during this count, the BRG is reset and the SDA line is asserted early (Figure 9-22). If, however, a '1' is sampled on the SDA pin, the SDA pin is assert ed low at the end of the BRG count. The baud rate generator is then reloaded and counts down to 0. During this time, if the SCL pins are sampled as '0', a bus collision does not occur. At the end of the BRG count, the SCL pin is asserted low.

Note: The reason that bus coll ision is no t a fact or

during a START condition is that no two bus masters can assert a START condition at the exact same time. Therefore, one master will always assert SDA before the other . T his con dition does not cause a bus collision, becau se the two master s must be allowed to arbitrate t he first add ress following the START condition. If the address is the same, arbitration must be allowed to continue into the data portion, Repeated START, or STOP conditions.

data '1' during the START condition.

FIGURE 9-20: BUS COLLISION DURING START CONDITION (SDA ONLY)

DS30292D-page 90  1998-2013 Microchip Technology Inc.

PIC16F87X

SDA

SCL

SEN

Bus collision occurs, Set BCLIF

SCL = 0 before SDA = 0,

Set SEN, enable START sequence if SDA = 1, SCL = 1

TBRG

SDA = 0, SCL = 1

BCLIF

SSPIF

Interrupts cleared in software

Bus collision occurs, Set BCLIF

SCL = 0 before BRG time-out,

'0'

SDA

SCL

SEN

Set S

Set SEN, enable START sequence if SDA = 1, SCL = 1

Less than T

BRG

TBRG

SDA = 0, SCL = 1

BCLIF

SSPIF

Interrupts cleared in software

Set SSPIF

SDA = 0, SCL = 1

SDA pulled low by other master. Reset BRG and assert SDA.

SCL pulled low after BRG Time-out

Set SSPIF

'0'

FIGURE 9-21: BUS COLLISION DURING START CONDITION (SCL = 0)

FIGURE 9-22: BRG RESET DUE TO SDA COLLISION DURING START CONDITION

 1998-2013 Microchip Technology Inc. DS30292D-page 91

PIC16F87X

SDA

SCL

RSEN

BCLIF

SSPIF

Sample SDA when SCL goes high. If SDA = 0, set BCLIF and release SDA and SCL.

Cleared in software

'0' '0'

SDA

SCL

BCLIF

RSEN

SSPIF

Interrupt cleared in software

SCL goes low before SDA, Set BCLIF. Release SDA and SCL.

TBRG TBRG

'0'

9.2.18.2 Bus Collision During a Repeated ST ART Condition

During a Repeated START condition, a bus collision occurs if:

a) A low level is sampled on SDA when SCL goes

from low level to high level.

b) SCL goes low before SDA is asserted low, indi-

cating that anoth er master is attem pting to transmit a data ’1’.

When the user de-asserts SDA and the pin is allowed to float high, the BRG is loaded with SSPADD<6:0> and counts down to 0. The SCL pin is then de-asserted, and when sampled high, the SDA pin is sampled. If SDA is low, a bus collision has occurred (i.e., another

SDA is sampled high, the BRG is reloaded and begins counting. If SDA goes from high to low befo re the BRG times out, no bus collision occurs, because no two masters can assert SDA at exactly the same time.

If, however , SCL goes from hig h to low before the BRG times out and SDA has not already been asserted, a bus collision occurs. In this case, another master is attempting to transmit a data’1’ during the Repeated START condition.

If at the end of the BRG time-out, both SCL and SDA are still high, the SDA pin is driven low, the BRG is reloaded and begins counting. At the end of the count, regardless of the status of the SCL pin, the SCL pin is driven low and the Repeated START condition is complete (Figure 9-23).

master is attempting to transmit a data’0’). If, however,

FIGURE 9-23: BUS COLLISION DURING A REPEATED START CONDITION (CASE 1)

FIGURE 9-24: BUS COLLISION DURING REPEATED START CONDITION (CASE 2)

DS30292D-page 92  1998-2013 Microchip Technology Inc.

PIC16F87X

SDA

SCL

BCLIF

PEN

SSPIF

TBRG TBRG TBRG

SDA asserted low

SDA sampled low after T

BRG,

Set BCLIF

'0' '0'

SDA

SCL

BCLIF

PEN

SSPIF

TBRG TBRG TBRG

Assert SDA

SCL goes low before SDA goes high, Set BCLIF

'0'

9.2.18.3 Bus Collision During a STOP Condition

Bus collision occurs during a STOP condition if: a) After the SDA pin has been de-asserted and

allowed to float high, SDA is sampled low after the BRG has timed out.

b) After the SCL pin is de-asserted, SCL is sam-

pled low before SDA goes high.

The STOP condition begins with SDA asserted low. When SDA is sampled low, the SCL pin is allowed to float. When th e pin i s sa mple d hi gh (c loc k ar bit rati on) , the baud rate generator is loaded with SSPADD<6:0> and counts down to 0. After the BRG times o ut, SDA i s sampled. If SDA is sampled low, a bus collision has occurred. This is due to another master attempting to drive a data ' 0'. If the SCL pin is sample d low before SDA is allowed to float hi gh, a bus collis ion occurs. Thi s is a case of another master attempting to drive a data '0' (Figure 9-25).

FIGURE 9-25: BUS COLLISION DURING A STOP CONDITION (CASE 1)

FIGURE 9-26: BUS COLLISION DURING A STOP CONDITION (CASE 2)

 1998-2013 Microchip Technology Inc. DS30292D-page 93

PIC16F87X

VDD + 10%

SDA SCL

DEVICE

Cb=10 - 400 pF

Note: I2C devices with input levels related to VDD must have one com mon supply line to which the pull-up resistor is also

connected.

9.3 Connection Considerations for

C Bus

For standard-mode I2C bus devices, the values of resistors R lowing parameters:

• Supply voltage

• Bus capacitance

• Number of connected devices (input current + leakage current)

The supply voltage limits the minimum value of resistor

due to the specified minimum sink current of 3 mA at

OL max = 0.4V, for the specified output stages.

and Rs in Figure 9-27 depend on the fol-

For

example, with a supply voltage of V

OL max = 0.4V at 3 mA, R

V V

DD as a function of R

desired noise margin of 0.1V the maximum value of R and used to improve ESD susceptibility.

The bus capacitance is the total capacitance of wire, connections, an d pins. This capaci tance lim its the m aximum value of R

due to the specified rise time

(Figure 9-27). The SMP bit is the slew rate control enabled bit. This bit

is in the SSPSTAT register, and controls the slew rate of the I/O pins when in I

FIGURE 9-27: SAMPL E DEVICE CONFIGURATION FOR I2C BUS

DD = 5V±10% and

min = (5.5-0.4)/0.003 = 1.7 k

is shown i n Figure 9-27. The

DD for the low level limits

. Series resistors are optional

C mode (master or slave).

DS30292D-page 94  1998-2013 Microchip Technology Inc.

PIC16F87X

10.0 ADDRESSABLE UNIVERSAL SYNCHRONOUS ASYNCHRONOUS RECEIVER T RANSMITTER (USART)

The Universal Synchronous Asynchronous Receiver Transmitter (USART) module is one of the two serial I/O modules . (USA RT is als o know n as a S erial Communications Interface or SCI.) The USART can be configured as a full duplex asynchronous system that can communicate with pe ripheral devi ces s uch as CR T terminals and perso nal comp uters, or it can be configure d as a half duplex s yn chronous system th at c an co mm unicate with periphera l de vi ces su ch as A/ D or D /A in tegrated circuits, serial EEPROMs etc.

The USART can be configured in the following modes:

• Asynchronous (full duplex)

• Synchronous - Master (half duplex)

• Synchronous - Slave (half duplex) Bit SPEN (RCSTA<7>) and bits TRISC<7:6> have to

be set in order to configure pins RC6/TX/CK and RC7/RX/DT as the Universal Synchronous Asynchronous Receiver Transmitter.

The USART module also has a multi-processor communication capability using 9-bit address detection.

R/W-0 R/W-0 R/W-0 R/W-0 U-0 R/W-0 R-1 R/W-0 CSRC TX9 TXEN SYNC — BRGH TRMT TX9D

bit 7 bit 0

bit 7 CSRC: Clock Source Select bit

Asynchronous mode: Don’t care

Synchronous mode:

1 = Master mode (clock generated internally from BRG) 0 = Slave mode (clock from external source)

bit 6 TX9: 9-bit Transmit Enable bit

1 = Selects 9-bit transmission 0 = Selects 8-bit transmission

bit 5 TXEN: Transmit Enable bit

1 = Transmit enabled 0 = Transmit disabled

Note: SREN/CREN overrides TXEN in SYNC mode.

bit 4 SYNC: USART Mode Select bit

1 = Synchronous mode 0 = Asynchronous mode

bit 3 Unimplemented: Read as '0' bit 2 BRGH: High Baud Rate Select bit

Asynchronous mode:

1 = High speed 0 = Low speed

Synchronous mode: Unused in this mode

bit 1 TRMT: Transmit Shift Register Status bit

1 = TSR empty 0 = TSR full

bit 0 TX9D: 9th bit of Transmit Data, can be parity bit

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 1998-2013 Microchip Technology Inc. DS30292D-page 95

PIC16F87X

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R-0 R-0 R-x

SPEN RX9 SREN CREN ADDEN FERR OERR RX9D

bit 7 bit 0

bit 7 SPEN: Serial Port Enable bit

1 = Serial port enabled (configures RC7/RX/DT and RC6/TX/CK pins as serial port pins) 0 = Serial port disabled

bit 6 RX9: 9-bit Receive Enable bit

1 = Selects 9-bit reception 0 = Selects 8-bit reception

bit 5 SREN: Single Receive Enable bit

Asynchronous mode: Don’t care

Synchronous mode - master:

1 = Enables single receive 0 = Disables single receive

This bit is cleared after reception is complete. Synchronous mode - slave:

Don’t care

bit 4 CREN: Continuous Receive Enable bit

Asynchronous mode:

1 = Enables continuous receive 0 = Disables co ntinuous receive

Synchronous mode:

1 = Enables continuous receive until enable bit CREN is cleared (CREN overrides SREN) 0 = Disables co ntinuous receive

bit 3 ADDEN: Address Detect Enable bit

Asynchronous mode 9-bit (RX9 = 1): 1 = Enables address detection, enables interrupt and load of the receive buffer when

RSR<8> is set

0 = Disables address detection, all bytes are received, and ninth bit can be used as parity bit

bit 2 FERR: Framing Error bit

1 = Framing error (can be updated by reading RCREG register and receive next valid byte) 0 = No framing error

bit 1 OERR: Overrun Error bit

1 = Overrun error (can be cleared by clearing bit CREN) 0 = No overrun error

bit 0 RX9D: 9th bit of Received Data (can be parity bit, but must be calculated by user firmware)

Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292D-page 96  1998-2013 Microchip Technology Inc.

PIC16F87X

10.1 USART Baud Rate Generator (BRG)

The BRG supports both the Asynchronous and Synchronous modes of the USART. It is a dedicated 8-bit baud rate generator. The SPBRG register controls the period of a free running 8-bit timer. In Asynchronous mode, bit BRGH (TXSTA<2>) also controls the baud rate. In Synchronous mode, bit BRGH is ignored. Table 10-1 shows the formula for computation of the baud rate for differen t US ART modes which only a ppl y in Master mode (internal clock).

Given the desired baud rate and F integer value for the SPBRG register can be calculated

OSC, the nearest

It may be advantageous to use the high baud rate (BRGH = 1), even for slower baud clocks. This is because the FOSC/(16(X + 1)) equation c an red uce the baud rate error in some cases.

Writing a new value to the SPBRG register causes the BRG timer to be reset (or cleared). This ensures the BRG does not wait for a timer overflow before outputting the new baud rate.

10.1.1 SAMPLING

The data on the RC7/RX/D T pin is sampled three times by a majority detect circuit to determine if a high or a low level is present at the RX pin.

using the formula in Table 10-1. From this, the error in baud rate can be determined.

TABLE 10-1: BAUD RATE FORMULA

SYNC BRGH = 0 (Low Speed) BRGH = 1 (High Speed)

0 1

X = value in SPBRG (0 to 255)

(Asynchronous) Baud R ate = F

(Synchronous) Baud Rate = F

OSC/(64(X+1)) OSC/(4(X+1))

Baud Rate = F

N/A

OSC/(16(X+1))

TABLE 10-2: REGISTERS ASSOCIATED WITH BAUD RATE GENERATOR

Value on:

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

98h TXSTA 18h RCSTA SPEN 99h SPBRG Baud Rate Generator Register 0000 0000 0000 0000 Legend: x = unknown, - = unimplemented, read as '0'. Shaded cells are not used by the BRG.

CSRC TX9 TXEN SYNC —BRGHTRMT TX9D 0000 -010 0000 -010

RX9 SREN CREN ADDEN FERR OERR RX9D 0000 000x 0000 000x

POR,

BOR

Val ue on all other RESETS

 1998-2013 Microchip Technology Inc. DS30292D-page 97

PIC16F87X

TABLE 10-3: BAUD RATES FOR ASYNCHRONOUS MODE (BRGH = 0)

OSC = 20 MHz FOSC = 16 MHz FOSC = 10 MHz

BAUD

RATE

(K)

0.3------- --

1.2 1.221 1.75 255 1.202 0.17 207 1.202 0.17 129

2.4 2.404 0.17 129 2.404 0.17 103 2.404 0.17 64

9.6 9.766 1.73 31 9.615 0.16 25 9.766 1.73 15

19.2 19.531 1.72 15 19.231 0.16 12 19.531 1.72 7

28.8 31.250 8.51 9 27.778 3.55 8 31.250 8.51 4

33.6 34.722 3.34 8 35.714 6.29 6 31.250 6.99 4

57.6 62.500 8.51 4 62.500 8.51 3 52.083 9.58 2

HIGH 1.221 - 255 0.977 - 255 0.610 - 255

LOW 312.500 - 0 250.000 - 0 156.250 - 0

BAUD

RATE

(K)

0.3 0.300 0 207 0.3 0 191

1.2 1.202 0.17 51 1.2 0 47

2.4 2.404 0.17 25 2.4 0 23

9.6 8.929 6.99 6 9.6 0 5

19.2 20.833 8.51 2 19.2 0 2

28.8 31.250 8.51 1 28.8 0 1

33.6 - - - - - -

57.6 62.500 8.51 0 57.6 0 0

HIGH 0.244 - 255 0.225 - 255

LOW 62.500 - 0 57.6 - 0

KBAUD%ERROR

OSC = 4 MHz FOSC = 3.6864 MHz

KBAUD

ERROR

SPBRG

value

(decimal)

SPBRG

value

(decimal) KBAUD

KBAUD%ERROR

ERROR

SPBRG

value

(decimal)

SPBRG

value

(decimal)

KBAUD%ERROR

SPBRG

value

(decimal)

TABLE 10-4: BAUD RATES FOR ASYNCHRONOUS MODE (BRGH = 1)

OSC = 20 MHz FOSC = 16 MHz FOSC = 10 MHz

BAUD

RATE

(K)

0.3---------

1.2---------

2.4 - - - - - - 2.441 1.71 255

9.6 9.615 0.16 129 9.615 0.16 103 9.615 0.16 64

19.2 19.231 0.16 64 19.231 0.16 51 19.531 1.72 31

28.8 29.070 0.94 42 29.412 2.13 33 28.409 1.36 21

33.6 33.784 0.55 36 33.333 0.79 29 32.895 2.10 18

57.6 59.524 3.34 20 58.824 2.13 16 56.818 1.36 10

HIGH 4.883 - 255 3.906 - 255 2.441 - 255

LOW 1250.000 - 0 1000.000 0 625.000 - 0

BAUD

RATE

(K)

0.3------

1.2 1.202 0.17 207 1.2 0 191

2.4 2.404 0.17 103 2.4 0 95

9.6 9.615 0.16 25 9.6 0 23

19.2 19.231 0.16 12 19.2 0 11

28.8 27.798 3.55 8 28.8 0 7

33.6 35.714 6.29 6 32.9 2.04 6

57.6 62.500 8.51 3 57.6 0 3

HIGH 0.977 - 255 0.9 - 255

LOW 250.000 - 0 230.4 - 0

KBAUD%ERROR

OSC = 4 MHz FOSC = 3.6864 MHz

KBAUD

ERROR

SPBRG

value

(decimal)

SPBRG

value

(decimal) KBAUD

KBAUD%ERROR

ERROR

SPBRG

value

(decimal)

SPBRG

value

(decimal)

KBAUD%ERROR

SPBRG

value

(decimal)

DS30292D-page 98  1998-2013 Microchip Technology Inc.

PIC16F87X

TXIF

TXIE

Interrupt

TXEN

Baud Rate CLK

SPBRG

Baud Rate Generator

TX9D

MSb

LSb

Data Bus

TXREG Register

TSR Register

(8)

TX9

TRMT

SPEN

RC6/TX/CK pin

Pin Buffer and Control



10.2 USART Asynchronous Mode

In this mode, the USART uses standard non-return-tozero (NRZ) format (one START bit, eight or nine data bits, and one STOP bit). The most common data format is 8-bits. An on-chip, dedicated, 8-bit baud rate generator can be used to derive standard baud rate fre quencies from the oscillator. The USART transmits and receives the LSb fi rst. The t r ans mitte r and receiver are functionally indep endent, b ut use th e same data f ormat and baud rate. The baud rate generator produces a clock, either x16 or x64 of the bit shift rate, depending on bit BRGH (TXSTA<2>). Parity is not supported by the hardware, but can b e implemented i n softwa re (and stored as the ninth data bit). Asynchronous mode is stopped during SLEEP.

Asynchronous mode is selected by clearing bit SYNC (TXSTA<4>).

The USART Asynchronous module consists of the following important elements:

• Baud Rate Generator

• Sampling Circuit

• Asynchronous Transmitter

• Asynchronous Receiver

10.2.1 USART ASYNCHRONOUS

TRANSMITTER

The USART transmitter block diagram is shown in Figure 10-1. The heart of t he trans mitte r is the t ransm it (serial) shift register (TSR). The shif t register obt ains its data from the read/write transmit buffer, TXREG. The TXREG register is loaded with data in software. The TSR register is not loaded until the STOP bit has been transmitted from the previous load. As soon as the STOP bit is transmitted, the TSR is loaded with new data from the TXREG register (if available). Once the TXREG register transfers the data to the TSR register (occurs in one T flag bit TXIF (PIR1<4>) is set. This interrupt can be

CY), the TXR EG re gist er i s em pty and

enabled/disabled by setting/clearing enable bit TXIE ( PIE1<4>). Flag bit TXIF will be set, regardless of the state of enabl e bit TX IE an d cann ot be cl ear ed in software. It will reset only wh en ne w dat a is loa ded i nto th e TXREG register . While flag bi t TXIF indicates the status of the TXREG register, another bit TRMT (TXSTA<1>) shows the status of the TSR register. Status bit TRMT is a read only bi t, wh ic h i s se t w he n the TSR r egister is empty. No interrupt logic is tied to this bit, so the user has to poll this bit in order to determine if the TSR register is empty.

Note 1: The TSR register is not mapped in data

memory, so it is not available to the user.

2: Flag bit TXIF is set when enabl e bit TXEN

is set. TXIF is cleared by loadi ng TXRE G.

Transmission is enabled by setting enable bit TXEN (TXSTA<5>). The actual transmission will not occur until the TXREG register has been loaded with data and the baud rate generator (BRG) has produced a shift clock (Figure 10-2). The transmission can also be started by first loading the TXREG register and then setting enable bit TXEN. Normally, when transmission is first started, the TSR register is empty. At that point, transfer to the TXREG register will result in an immediate transfe r to TSR, result ing in an empty TXR EG. A back-to-back transfer is thus possible (Figure 10-3). Clearing enable bit TXEN during a transmission will cause the transmis s ion to be ab orte d a nd will reset the transmitter. As a result, the RC6/TX/CK pin will revert to hi-impedance.

In order to select 9-bit transmission, transmit bit TX9 (TXSTA<6>) should be set and the ninth bit should be written to TX9D (TXSTA<0>). The ninth bit must be written before writing the 8-bit data to the TXREG register. This is because a data write to the TXREG register can result in an immediate tra nsfer of the dat a to the TSR register (if the TSR is empty). In such a case, an incorrect ninth data bit may be loaded in the TSR register.

FIGURE 10-1: USART TRANSMIT BLOCK DIAGRAM

 1998-2013 Microchip Technology Inc. DS30292D-page 99

PIC16F87X

Word 1

STOP Bit

Word 1 Transmit Shift Reg

STA RT Bit Bit 0 Bit 1 Bit 7/8

Write to TXREG

Word 1 BRG Output (Shift Clock)

RC6/TX/CK (pin)

TXIF bit (Transmit Buffer Reg. Empty Flag)

TRMT bit (Transmit Shift Reg. Empty Flag)

Transmit Shift Reg.

Write to TXREG BRG Output

(Shift Clock) RC6/TX/CK (pin)

TXIF bit (Interrupt Reg. Flag)

TRMT bit (Transmit Shift Reg. Empty Flag)

Word 1

Word 2

Word 1

Word 2

STAR T Bit

STOP Bit

STAR T Bit

Transmit Shift Reg.

Word 1

Word 2

Bit 0 Bit 1

Bit 7/8 Bit 0

Note: This timing diagram shows two conse cutive transmissions.

When setting up an Asynchronous Transmission, follow these steps:

1. Initialize the SPBRG register for the ap prop ria te baud rate. If a high speed baud rate is desired, set bit BRGH (Section 10.1).

2. Enable the asynchronous serial port by clearing bit SYNC and setting bit SPEN.

3. If interrupts are desired, then set enable bit

5. Enable the transmission by setting bit TXEN, which will also set bit TXIF.

6. If 9-bit transmission is selected, the ninth bit should be loaded in bit TX9D.

7. Load data to the TXREG register (starts transmission).

8. If using interrupts, ensure that GIE and PEIE (bits 7 and 6) of the INTCON register are set.

TXIE.

4. If 9-bit transmission is desired, then set transmit bit TX9.

FIGURE 10-2: ASYNCHRONOUS MASTER TRANSMISSION

FIGURE 10-3: ASYNCHRONOUS MASTER TRANSMISSION (BACK TO BACK)

TABLE 10-5: REGISTERS ASSOCIATED WITH ASYNCHRONOUS TRANSMISSION

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh, 8Bh, 10Bh,18Bh

0Ch PIR1 18h RCSTA 19h TXREG 8Ch PIE1 98h TXSTA 99h SPBRG Baud Rate Generator Register 0000 0000 0000 0000 Legend: x = unknown, - = unimplemented locations read as '0'. Shaded cells are not used for asynchronous transmission.

Note 1: Bits PSPIE and PSPIF are reserved on the PIC16F873/876; always maintain these bits clear.

DS30292D-page 100  1998-2013 Microchip Technology Inc.

INTCON GIE PEIE

(1)

PSPIF

SPEN RX9 SREN CREN — FERR OERR RX9D 0000 -00x 0000 -00x

USART Transmit Register 0000 0000 0000 0000

(1)

PSPIE

CSRC TX9 TXEN SYNC — BRGH TRMT TX9D 0000 -010 0000 -010

T0IE INTE RBIE T0IF INTF R0IF 0000 000x 0000 000u

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

ADIE RCIE TXIE SSPIE CCP1IE TM R2IE TMR1IE 0000 0000 0000 0000

Value on:

POR, BOR

Value on

all other

RESETS

Datasheet PIC16F873, PIC16F874, PIC16F876, PIC16F877 Datasheet

Specifications and Main Features

Frequently Asked Questions

User Manual

Devices Included in this Data Sheet:

Pin Diagram

Microcontroller Core Features:

Peripheral Features:

Pin Diagrams

Table of Contents

TO OUR VALUED CUSTOMERS

Most Current Data Sheet

Errata

Customer Notification System

1.0 DEVICE OVERVIEW

2.0 MEMORY ORGANIZATION

2.1 Program Memory Organization

2.2 Data Memory Organization

2.2.1 GENERAL PURPOSE REGISTER FILE

2.2.2 SPECIAL FUNCTION REGISTERS

2.2.2.1 STATUS Register

2.2.2.2 OPTION_REG Register

2.2.2.3 INTCON Register

2.2.2.4 PIE1 Register

2.2.2.5 PIR1 Register

2.2.2.6 PIE2 Register

2.2.2.7 PIR2 Register

2.2.2.8 PCON Register

2.3 PCL and PCLATH

2.3.1 COMP UT ED GOTO

2.4 Program Memory Paging

2.3.2 STACK

2.5 Indirect Addressing, INDF and FSR Registers

3.0 I/O PORTS

3.1 PORTA and the TRISA Register

3.2 PORTB and the TRISB Register

3.3 PORTC and the TRISC Register

3.4 PORTD and TRISD Registers

3.5 PORTE and TRISE Register

3.6 Parallel Slave Port

4.0 DATA EEPROM AND FLASH PROGRAM MEMORY

4.1 EECON1 and EECON2 Registers

4.2 Reading the EEPROM Data Memory

4.3 Writing to the EEPROM Data Memory

4.4 Reading the FLASH Program Memory

4.5 Writing to the FLASH Program Memory

4.6 Write Verify

4.8 Operation While Code Protected

4.9 FLASH Program Memory Write Protection

5.0 TIMER0 MODULE

5.1 Timer0 Interrupt

5.2 Using Timer0 with an External Clock

5.3 Prescaler

6.0 TIMER1 MODULE

6.1 Timer1 Operation in Timer Mode

6.2 Timer1 Counter Operation

6.4 Timer1 Operation in Asynchronous Counter Mode

6.5 Timer1 Oscillator

6.6 Resetting Timer1 using a CCP Trigger Output

6.7 Resetting of Timer1 Register Pair (TMR1H, TMR1L)

6.8 Timer1 Prescaler

7.0 TIMER2 MODULE

7.1 Timer2 Prescaler and Postscaler

7.2 Output of TMR2

8.0 CAPTURE/COMPARE/PWM MODULES

8.1 Capture Mode

8.1.1 CCP PIN CONFIGURATION

8.1.2 TIMER1 MODE SELECTION

8.1.3 SOFTWARE INTERRUPT

8.1.4 CCP PRESCALER

8.2 Compare Mode

8.2.2 TIMER1 MODE SELECTION

8.2.3 SOFTWARE INTERRUPT MODE

8.2.4 SPECIAL EVENT TRIGGER

8.2.1 CCP PIN CONFIGURATION

8.3 PWM Mode (PWM)

8.3.1 PWM PERIO D

8.3.2 PWM DUTY CYCLE

8.3.3 SETUP FOR PWM OPERATION

9.1 SPI Mode
