SSuuppeerr FFlluuxx PPrreemmiiuumm RReedd LLEED
D
■Features
●
High Luminous Super Flux Output
●
4.55 ø Standard Directivity
●
Long Lifetime Operation
●
Low Thermal Resistance
Superior Weather-Resistance
●
UV Resistant Epoxy
●
Water Clear Type
■Applications
●
Automotive tail, stop, turn signal lamps and inteior lighting
●
Signage and channel letter
●
Decoration and entertainment lighting
●
Architectural lighting
●
Other Lighting
■
Outline Dimension
7.62
2
6
.
7
0.76+0.1
1.5+0.1
5.08+0.2
OSR5PAZE31D
1
.
2
C
Unit:mm
Tolerance:+0.3mm
1,4 Cathode
2,3 Anode
4.55
4
.
3
5
.
5
5
.
4
2
2
2 3
5.08+0.3
2
.
0
+
0
.
5
■Absolute Maximum Rating
Item Symbol
DC Forward Current
Pulse Forward Current*
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Temperature
*Pulse width Max.10ms Duty ratio max 1/10
■Electrical -Optical Characteristics
(Ta=25
℃℃℃℃
))))
Value Unit
IF 50 mA
IFP 120 mA
VR 5 V
PD 130 mW
Topr -30 ~ +85
Tstg -40 ~ +100
Tsol
260℃/5sec
(Ta=25
℃℃℃℃
))))
℃
℃
-
Item Symbol Condition Min. Typ. Max. Unit
DC Forward Voltage VF IF=50mA 1.8 2.1 2.6 V
DC Reverse Current IR VR=5V - - 10 µA
Domi. Wavelength* λD IF=50mA 620 625 630 nm
Luminous Intensity* Iv IF=50mA 10000 12000
50% Power Angle 2θ
*1 Tolerance of measurements of dominant wavelength is +1nm
*2 Tolerance of measurements of luminous intensity is +15%
*3 Tolerance of measurements of forward voltage is±0.1V
1/2
IF=50mA - 30 - deg
- mcd
■
Directivity
60°
90°
1 1
■
Maximum Forward Current
70
)
60
A
m
-
t
50
n
e
r
r
u
40
C
d
r
a
30
w
r
o
F
(
20
f
I
10
0
0
0
30°
0.5
0
30°
0.5
Maximun Permissible Forward Current Tj=115°C
Rth(J-a)=400°C/W
Rth(J-a)=500°C/W
Rth(J-a)=600°C/W
50
30
20
10
Ta(Ambient Temperature -°C)
60
40
70
80 90
60°
90°
LED & Application Technologies
http://www.optosupply.com VER A.0
