Organic Conductive Polymer Capacitors
Features
‧
105℃, 2000 hours assured
‧
Ultra low ESR with large permissible ripple current
‧
RoHS Compliance
SPECIFICATIONS
Items Performance
Category Temperature Range
Capacitance Tolerance
Leakage Current (at 20℃)*
Dissipation Factor
(Tanδ at 120Hz, 20 )℃
ESR (at 100k ~ 300k Hz, 20℃)
Test Time 2,000 Hrs
Capacitance Change
Endurance Dissipation Factor Less than 150% of specified value
ESR Less than 150% of specified value
Leakage Current Within specified value
Test Time 1,000 Hrs
Capacitance Change
Moisture Resistance Dissipation Factor Less than 150% of specified value
ESR Less than 150% of specified value
Leakage Current Within specified value
Resistance to Soldering Heat *
(Please refer to page 10 for soldering
conditions)
Ripple Current &
Frequency Multipliers
* For any doubt about measured values, measure the leakage current again after the following voltage treatment.
Voltage treatment: Applying DC rated voltage to the capacitors for 2 hours at 105 oC.
DIAGRAM OF DIMENSIONS
6.3φ×6 ~ 8L and 8φ×8L
LEAD SPACING AND DIAMETER
MARKING
L+α max
d
φ
15 min
8φ×12L and 10φ×12.5L
φ
Marking color: Blue
-55℃ ~ +105℃
±20% (at 120Hz, 20℃)
Rated voltage applied, after 2 minutes at 20℃.
See Standard Ratings
See Standard Ratings
See Standard Ratings
Within ±20% of initial value
* The above specifications shall be satisfied when the capacitors are restored to 20℃ after the rated voltage applied
for 2000 hours at 105℃.
Within ±20%of initial value
* The above specifications shall be satisfied when the capacitors are restored to 20℃ after subjecting them at 60℃,
90 to 95% RH for 1,000 hours. Leakage current should be tested after voltage treatment*.
Frequency (Hz) 120 f < 1≦ k 1k f < 10≦ k 10k f < 100≦ k 100k f < 500≦ k
Multiplier 0.05 0.3 0.7 1.0
Capacitance Change
Dissipation Factor Less than 130% of specified value
ESR Less than 130% of specified value
Leakage Current Within specified value
Within ±10% of initial value
Unit: mm
φD+β
d
φ
15 min
4 min
4 min
max
φD+β
φD
L 6 8 8 12 12.5
P 2.5 3.5 3.5 5.0
0.5
±
P
maxL+α max
0.5
±
P
D = 6.3
Negative
polarity
a1
10
16Z
φd
α 1.0 1.5
β 0.5
Date code
Rated cap.
Rated voltage
6.3 8 8 10
0.45 0.6
φ
D = 8 ~ 10
Negative
polarity
a1
OCRZ
470
6.3V
OCRZ
Date code
Series name
Rated cap.
Rated voltage
2011 Verison
Page 2
STANDARD RATINGS
W. V. (V)
2.5V (0E)
4V (0G)
6.3V (0J)
10V (1A)
16V (1C)
Capacitance
(µF)
330 6.3×8 0.10 500 7 5,600
390 6.3*6 0.10 500 10 3,900
470 8×8 0.10 235 7 5,000
1,200 8×8 0.12 600 7 6,200
1,500 10×12.5 0.12 750 7 6,500
2,700 10×12.5 0.12 1,350 7 7,200
560
820 8×8 0.10 656 7 6,200
1,000 8×8 0.10 800 7 6,200
1,200
1,500 10×12.5 0.12 1,200 7 6,500
2,200 10×12.5 0.12 1,760 8 7,200
220 8×8 0.10 277 10 5,000
560
1,000
1,500 10×12.5 0.12 1,890 7 6,200
390 8×12 0.12 780 8 5,000
470 10×12.5 0.12 940 8 6,000
560 10×12.5 0.12 1,120 8 6,000
820 10×12.5 0.12 1,640 8 6,000
100
180 8×8 0.10 576 10 5,000
270
330 10×12.5 0.12 1,056 8 6,000
470
Organic Conductive Polymer Capacitors
OCRZ
Dimension: φD×L(mm)
Ripple Current: mA/rms at 100k Hz, 105℃
Size
φD×L(mm)
6.3×6 0.10 500 10 4,000
6.3×8 0.10 500 7 5,600 560
8×8 0.12 280 7 6,200
6.3×8 0.10 500 7 5,600
8×8 0.10 410 7 6,200 820
8×12 0.12 410 7 6,200
8x8 0.12 500 7 6,200
8×12 0.12 500 7 6,200 1,000
10×12.5 0.12 500 7 6,200
6.3×8 0.10 500 7 5,600
8×8 0.10 448 7 6,200
8×12 0.12 448 7 6,200
8×12 0.12 960 7 6,200
10×12.5 0.12 960 7 6,200
6.3×8 0.10 592 7 5,600
8×8 0.12 592 7 6,200 470
8×12 0.12 592 7 6,200
6.3×8 0.10 706 7 5,600
8×8 0.10 706 7 6,200
8×12 0.12 706 7 6,200
8×8 0.10 1,033 7 6,200
8×12 0.10 1,033 8 5,500 820
10×12.5 0.12 1,033 7 6,200
8x8 0.10 1,260 7 6,200
8×12 0.12 1,260 8 5,500
6.3×6 0.10 320 24 2,490
6.3×8 0.10 500 10 4,680
8×8 0.10 864 10 5,000
8×12 0.12 864 8 5,000
8×12 0.12 1,504 10 5,400
10×12.5 0.12 1,504 8 6,000
Tanδ
(120Hz, 20 )℃
LC
(µA)
(mΩ/at 100k ~ 300k Hz, 20 Ma℃ x)
E S R
Rated R. C.
(mA/rms at 100k Hz, 105 )℃
2011 Version
