NTE969
Linear Integrated Circuit
Voltage Regulator, Negative, –15V, 1A
Description:
The NTE969 voltage regulator employs current limiting, thermal shutdown, and safe–area compensation which makes it remarkably rugged under most operating conditions. With adequate heat–
sinking they can deliver output currents in excess of 1.0 amperes.
Features:
D No External Components Required
D Internal Thermal Overload Protection
D Internal Short–Circuit Current Limiting
D Output Transistor Safe–Area Compensation
Absolute Maximum Ratings:
Input Voltage, V
IN
Internal Power Dissipation, P
(TA = +25°C unless otherwise specified)
D
Derate Above +25°C 15.4mW/°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermal Resistance, Junction–to–Ambient, R
Internal Power Dissipation (T
= +25°C), P
C
D
Derate Above +25°C 200mW/°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermal Resistance, Junction–to–Ambient (T
Maximum Junction Temperature Range, T
Storage Temperature Range, T
Electrical Characteristics:
Parameter Symbol Test Conditions Min Typ Max Unit
Output Voltage V
Line Regulation Reg
stg
(VIN = –23V, IO = 500mA, 0°C ≤ TJ ≤ +125°C unless otherwise specified)
O
TJ = +25°C –14.4 –15.0 –15.6 V
5mA ≤ IO ≤ 1A, PO ≤ 15W,
–17.5V ≤ V
LineTJ
= +25°C
J
IN
Internally Limited. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
thJA
Internally Limited. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
= +25°C), R
C
thJA
–55° to +150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
–65° to +150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
–14.25 – –15.75 V
≤ –30V
–17.5V ≤ VIN ≤ –30V – 57 300
–20V ≤ VIN ≤ –26V – 27 150
–35V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
65°C/W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5°C/W. . . . . . . . . . . . . . . . . . . . . . . .
mV
Page 2
Electrical Characteristics: (VIN = –23V, IO = 500mA, 0°C ≤ TJ ≤ +125°C unless otherwise specified)
Parameter Symbol Test Conditions Min Typ Max Unit
Load Regulation Reg
LoadTJ
= +25°C
5mA ≤ IO ≤ 1.5A – 68 300
mV
250mA ≤ IO ≤ 750mA – 25 150
Quiescent Current I
Quiescent Current Change ∆I
B
TJ = +25°C – 4.4 8.0 mA
–17.5V ≤ VIN ≤ –30V – – 1.0 mA
B
5mA ≤ IO ≤ 1A – – 0.5
Ripple Rejection RR IO = 20mA, f = 120Hz – 60 – dB
Dropout Voltage VIN – VOTJ = +25°C, IO = 1A – 2 – V
Output Noise Voltage V
Output Resistance r
Short–Circuit Current Limit I
Peak Output Current I
Average Temperature
TCV
O
sc
max
TA = +25°C, 10Hz ≤ f ≤ 100kHz – 90 – µV/V
n
f = 1kHz – 19 – mΩ
TA = +25°C, VIN = –35V – 0.2 – A
TJ = +25°C – 2.2 – A
O
– –1.0 – mV/°C
Coefficient of Output
Voltage
.420 (10.67)
Max
O
.147 (3.75)
Dia Max
.070 (1.78)
Max
.100 (2.54)
GND
.110 (2.79)
V
IN
.500
(12.7)
Max
.250 (6.35)
Max
.500
(12.7)
Min
V
OUT
V
IN
