Datasheet No. 5 Specification

Technical Datasheet

Create Date:17.08.2020 - Seite1/

Wire Stripper No. 5

The WEICON wire strippers allow flexible and solid conductors
to be stripped easily, quickly and evenly. The wire strippers are
ergonomically shaped and have an automatic scanner system to
determine the cable diameter. This prevents damage to the inner
conductor. The product family of wire strippers includes various
types which are used in different fields and are tailored to the
individual needs of the users. The pincers are used both in trades
and in industry and are also suitable for private use.

The WEICON Wire Stripper No. 5 has an adjustable length stop
from 5 – 12 mm. This allows all flexible and solid conductors of

0.2 – 6.0 mm² (24 – 10 AWG) to be stripped. The length stop
can be removed if required. An easy-to-access side cutter is
integrated into the tool and can be used up to a cable diameter
of 2 mm. It also has exchangeable blades.

Technical Data

Cable types Fine-wired and solid conductors with

Cable types PVC insulation

Application range 0,2 - 6,0 mm² (24 - 10 AWG)

Inner blade Replaceable

Additional benefit Side cutter up to max. 2mm Ø

Additional value Seitenschneider, bis max. 2mm Ø, Feststellfunktion

Related products Ersatzmesser Satz, Art.Nr. 51100002

Approval/Certificate Safety tested by TÜV NORD

Length 165 mm

Weight 105 g

500_ArtNr 51000005

IMPA-Code 611762

Note
Working with WEICON Stripping tools is only permitted with potential free wires and conductions.
