Datasheet No. 400 Specification

Technical Datasheet

Create Date:17.08.2020 - Seite1/

Multi-Stripper No. 400

The WEICON multi-functional tools offer a large number of
options for stripping a wide range of cable types. The product
family of the tools includes various types, which have different
additional functions and thus meet the individual needs of the
users.

Newly developed tool for cable and wire stripping for all common
round cables of 8–13 mm Ø (e.g. NYM 3 x 1,5mm² up to 5 x 2,5
mm²). Allows circular and longitudinal stripping as well as flush
stripping in hard-to-reach areas, e.g. ceilings and walls, junction
and distribution boxes, switch cabinets, etc. For all common
stranded and solid conductors of 0,5 mm², 0,75 mm², 1,5 mm²,
2,5 mm², 4,0 mm² and 6,0 mm² (20–10 AWG). Easily accessible
built-in side cutter for flexible conductors of max. 6,0 m

Technical Data

Cable types Fine-wired and solid conductors with PVC insulatio

Inner blade Glued in fixed, not replaceable

Additional benefit Side cutter, flexible up to 6.0mm², solid up to 4.

Additional benefit Longitudinal cut

Weight 79 g

500_ArtNr 51000400

Note
Working with WEICON Stripping tools is only permitted with potential free wires and conductions.
