SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
Downsized, 85
C
@F4 through F18 case sizes are fully lined up
@Endurance : 2,000 hours at 85C
@Suitable to fi t for downsized equipment
@Solvent resistant type except 100 to 450Vdc (see PRECAUTIONS AND GUIDELINES)
@RoHS Compliant
SPECIFICATIONS
?
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
-
40 to +85C
dc
4 to 450V
P20% (M)
Rated voltage (Vdc)
D55 to JA0
KE0 to MN0
4 to 100V 160 to 450V
I=0.01CV or 3MA, whichever is greater.(after 2 minutes)
I=0.03CV or 4MA, whichever is greater.(after 1 minute)
Characteristics
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V)
Dissipation Factor
(tane)
Rated voltage (V
tanE (Max.)
dc)
D55 to JA0
KE0 to MN0
4V
0.42
-
6.3V
0.35
0.38
10V
0.30
0.34
16V
0.26
0.30
25V
0.16
0.26
When nominal capacitance exceeds 1,000MF, add 0.02 to the value above for each 1,000MF increase.
Low Temperature
Characteristics
(Max. Impedance Ratio)
Endurance
Rated voltage (V
D55 to JA0
KE0 to MN0
The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for 2,000 hours
dc)
Z(
-
25C)/Z(+20C)
Z(
-
40C)/Z(+20C)
Z(
-
25C)/Z(+20C)
Z(
-
40C)/Z(+20C)
4V
17
6.3V
3
4
7
-
-
8
10
4
5
10
12
2
2
4
6
2
3
5
8
25V
16V
10V
at 85C.
Size code
Rated voltage (V
dc)
D55 to JA0
4V & 6.3V
D55 to JA0
10 to 100V
Capacitance change [P30% of the initial value [P20% of the initial value
DF (tanE) [200% of the initial specified value [200% of the initial specified value
Leakage current [The initial specified value [The initial specified value
Shelf Life
The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 85C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Size code
Rated voltage
D55 to JA0
4V & 6.3V
D55 to JA0
10 to 100V
Capacitance change [P30% of the initial value [P20% of the initial value
DF (tanE) [200% of the initial specified value [200% of the initial specified value
Leakage current [The initial specified value [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : A
@Size code : D55 to MN0 @Size code : LH0 to MN0
W
FDP0.5
0.3max.
LP0.3(Note)
Note : LP0.5 for HA0 to MN0
BP0.2
AP0.2
@Terminal Code : G
P
CP0.2
FDP0.5
LP0.5
0.3max.
W
BP0.2
AP0.2
: Dummy terminals
105C
MVE
MVA
-
I=0.04CV+100MA max.(after 1 minute)
35V
0.14
0.22
35V
2
3
2
4
0.12
0.18
50V
2
3
2
3
0.12
0.14
63V
2
3
2
3
0.12
0.10
100V
3
4
2
3
160 to 250V
-
0.20
160 to 250V
-
3
6
100V
63V
50V
KE0 to MN0
6.3 to 450V
KE0 to MN0
6.3 to 450V
A
L
D55
E55
F55
F80
HA0
JA0
KE0
KG5
LH0
LN0
MH0
MN0
D
4
5
6.3
6.3
8
10
12.5
12.5
16
16
18
18
5.2
5.2
5.2
7.7
10.0
10.0
13.5
16.0
16.5
21.5
16.5
21.5
4.3
5.3
6.6
6.6
8.3
10.3
13.0
13.0
17.0
17.0
19.0
19.0
Size code
P
CP0.2
400 & 450V
-
0.25
400 & 450V
-
-
10
C
B
5.1
4.3
5.9
5.3
7.2
6.6
7.2
6.6
9.0
8.3
11.0
10.3
13.7
13.0
13.7
13.0
18.0
17.0
18.0
17.0
20.0
19.0
20.0
19.0
(at 20C, 120Hz)
(at 20C)
(at 20C, 120Hz)
6
(at 120Hz)
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
P
1.0
1.4
1.9
1.9
3.1
4.5
4.2
4.2
6.5
6.5
6.5
6.5
?PART NUMBERING SYSTEM
13426789105121311 16 17 181514
E MV A A A A A A A A A A A A A NM
Capacitance code (ex. 1.0MF:1R0,100MF:101)
Voltage code (ex. 6.3V:6R3,100V:101,450V:451)
Please refer to "Product code guide (surface mount type)"
Supplement code
Size code
Capacitance tolerance code
Taping·Tray code
Terminal code (A, G)
Series code
Category
(1/2)
MARKING
?
D55 to JA0
EX) 16V47MF
7hA
47
16V
KE0 to HN0
EX) 25V1,000MF
0V
MVA
1000
25V
CAT. No. E1001K
Page 2
SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
Downsized, 85
C
STANDARD RATINGS
?
Cap
WV
dc)
(V
33
47
100
4
220
330
470
1,000
33
47
100
220
330
470
680
820
1,000
6.3
1,500
2,200
3,300
3,300
4,700
6,800
6,800
10,000
22
33
47
100
150
220
330
10
470
1,000
2,200
3,300
4,700
4,700
6,800
22
33
47
100
150
220
330
16
470
680
1,000
2,200
3,300
3,300
4,700
10
22
33
47
56
100
150
25
220
330
470
1,000
2,200
2,200
3,300
4.7
10
35
22
: Enter the appropriate terminal code.
S
(mF)
Size code
D55
D55
E55
F55
F80
F80
HA0
D55
D55
E55
F55
F80
HA0
HA0
HA0
JA0
JA0
KE0
KG5
LH0
LH0
LN0
MH0
MN0
D55
D55
E55
F55
F55
F80
HA0
HA0
JA0
KE0
LH0
LN0
MH0
MN0
D55
E55
E55
F55
F80
F80
HA0
HA0
JA0
KE0
LH0
LN0
MH0
MN0
D55
E55
E55
F55
F55
F80
HA0
HA0
HA0
JA0
KE0
LN0
MH0
MN0
D55
D55
E55
tane
0.42 25 EMVA4R0ADA330MD55G
0.42 30 EMVA4R0ADA470MD55G
0.42 50 EMVA4R0ADA101ME55G
0.42 80 EMVA4R0ADA221MF55G
0.42 135 EMVA4R0ADA331MF80G
0.42 150 EMVA4R0ADA471MF80G
0.42 320 EMVA4R0ADA102MHA0G
0.35 30 EMVA6R3ADA330MD55G
0.35 33 EMVA6R3ADA470MD55G
0.35 55 EMVA6R3ADA101ME55G
0.35 88 EMVA6R3ADA221MF55G
0.35 135 EMVA6R3ADA331MF80G
0.35 280 EMVA6R3ADA471MHA0G
0.35 290 EMVA6R3ADA681MHA0G
0.35 320 EMVA6R3ADA821MHA0G
0.35 430 EMVA6R3ADA102MJA0G
0.35 480 EMVA6R3ADA152MJA0G
0.40 890 EMVA6R3ARA222MKE0S
0.42 1,000 EMVA6R3ARA332MKG5S
0.42 1,200 EMVA6R3SDA332MLH0S
0.44 1,400 EMVA6R3SDA472MLH0S
0.48 1,750 EMVA6R3SDA682MLN0S
0.48 1,700 EMVA6R3SDA682MMH0S
0.56 2,000 EMVA6R3SDA103MMN0S
0.30 26 EMVA100ADA220MD55G
0.30 30 EMVA100ADA330MD55G
0.30 44 EMVA100ADA470ME55G
0.30 70 EMVA100ADA101MF55G
0.30 79 EMVA100ADA151MF55G
0.30 130 EMVA100ADA221MF80G
0.30 270 EMVA100ADA331MHA0G
0.30 280 EMVA100ADA471MHA0G
0.30 430 EMVA100ADA102MJA0G
0.36 960 EMVA100ARA222MKE0S
0.38 1,300 EMVA100SDA332MLH0S
0.40 1,550 EMVA100SDA472MLN0S
0.40 1,600 EMVA100SDA472MMH0S
0.44 1,850 EMVA100SDA682MMN0S
0.26 26 EMVA160ADA220MD55G
0.26 37 EMVA160ADA330ME55G
0.26 44 EMVA160ADA470ME55G
0.26 70 EMVA160ADA101MF55G
0.26 110 EMVA160ADA151MF80G
0.26 130 EMVA160ADA221MF80G
0.26 270 EMVA160ADA331MHA0G
0.26 280 EMVA160ADA471MHA0G
0.26 380 EMVA160ADA681MJA0G
0.30 710 EMVA160ARA102MKE0S
0.32 1,150 EMVA160SDA222MLH0S
0.34 1,450 EMVA160SDA332MLN0S
0.34 1,450 EMVA160SDA332MMH0S
0.36 1,750 EMVA160SDA472MMN0S
0.16 24 EMVA250ADA100MD55G
0.16 41 EMVA250ADA220ME55G
0.16 47 EMVA250ADA330ME55G
0.16 60 EMVA250ADA470MF55G
0.16 66 EMVA250ADA560MF55G
0.16 120 EMVA250ADA101MF80G
0.16 210 EMVA250ADA151MHA0G
0.16 260 EMVA250ADA221MHA0G
0.16 300 EMVA250ADA331MHA0G
0.16 400 EMVA250ADA471MJA0G
0.26 820 EMVA250ARA102MKE0S
0.28 1,450 EMVA250SDA222MLN0S
0.28 1,400 EMVA250SDA222MMH0S
0.30 1,800 EMVA250SDA332MMN0S
0.14 18 EMVA350ADA4R7MD55G
0.14 24 EMVA350ADA100MD55G
0.14 41 EMVA350ADA220ME55G
Rated ripple
current
(mArms/
85c,120Hz)
Part No.
is not solvent resistant.
Cap
WV
dc)
(V
33
100
150 HA0 0.14 210 EMVA350ADA151MHA0G
220 HA0 0.14 260 EMVA350ADA221MHA0G
35
330 JA0 0.14 360 EMVA350ADA331MJA0G
470 KE0 0.22 600 EMVA350ARA471MKE0S
1,000 LH0 0.22 1,100 EMVA350SDA102MLH0S
2,200 MN0 0.24 1,700 EMVA350SDA222MMN0S
3.3 D55 0.12 15 EMVA500ADA3R3MD55G
4.7 D55 0.12 18 EMVA500ADA4R7MD55G
10 E55 0.12 30 EMVA500ADA100ME55G
22 F55 0.12 47 EMVA500ADA220MF55G
33 F80 0.12 70 EMVA500ADA330MF80G
47 F80 0.12 85 EMVA500ADA470MF80G
50
100 HA0 0.12 190 EMVA500ADA101MHA0G
220 JA0 0.12 320 EMVA500ADA221MJA0G
330 KE0 0.18 600 EMVA500ARA331MKE0S
470 KG5 0.18 740 EMVA500ARA471MKG5S
470 LH0 0.18 850 EMVA500SDA471MLH0S
1,000 LN0 0.18 1,300 EMVA500SDA102MLN0S
1,000 MN0 0.18 1,400 EMVA500SDA102MMN0S
1.0 D55 0.12 8.0 EMVA630ADA1R0MD55G
2.2 D55 0.12 12 EMVA630ADA2R2MD55G
3.3 E55 0.12 17 EMVA630ADA3R3ME55G
4.7 E55 0.12 20 EMVA630ADA4R7ME55G
10 F55 0.12 32 EMVA630ADA100MF55G
22 F80 0.12 60 EMVA630ADA220MF80G
33 HA0 0.12 110 EMVA630ADA330MHA0G
47 HA0 0.12 130 EMVA630ADA470MHA0G
63
56 JA0 0.12 160 EMVA630ADA560MJA0G
68 JA0 0.12 170 EMVA630ADA680MJA0G
100 KE0 0.14 380 EMVA630ARA101MKE0S
220 KE0 0.14 580 EMVA630ARA221MKE0S
330 KG5 0.14 720 EMVA630ARA331MKG5S
330 LH0 0.14 820 EMVA630SDA331MLH0S
470 LH0 0.14 950 EMVA630SDA471MLH0S
470 MH0 0.14 1,000 EMVA630SDA471MMH0S
22 HA0 0.12 90 EMVA101ADA220MHA0G
33 JA0 0.12 120 EMVA101ADA330MJA0G
68 KE0 0.10 380 EMVA101ARA680MKE0S
100
100 KE0 0.10 440 EMVA101ARA101MKE0S
220 LN0 0.10 850 EMVA101SDA221MLN0S
220 MH0 0.10 800 EMVA101SDA221MMH0S
330 MN0 0.10 1,000 EMVA101SDA331MMN0S
47 KG5 0.20 370 EMVA161ARA470MKG5S
68 LH0 0.20 500 EMVA161SDA680MLH0S
160
100 LN0 0.20 590 EMVA161SDA101MLN0S
100 MH0 0.20 590 EMVA161SDA101MMH0S
22 KE0 0.20 240 EMVA201ARA220MKE0S
33 KG5 0.20 310 EMVA201ARA330MKG5S
47 LH0 0.20 420 EMVA201SDA470MLH0S
200
68 LN0 0.20 510 EMVA201SDA680MLN0S
68 MH0 0.20 510 EMVA201SDA680MMH0S
100 MN0 0.20 590 EMVA201SDA101MMN0S
10 KE0 0.20 150 EMVA251ARA100MKE0S
22 KG5 0.20 240 EMVA251ARA220MKG5S
33 LH0 0.20 340 EMVA251SDA330MLH0S
250
47 LN0 0.20 420 EMVA251SDA470MLN0S
47 MH0 0.20 420 EMVA251SDA470MMH0S
68 MN0 0.20 490 EMVA251SDA680MMN0S
4.7 KE0 0.25 120 EMVA401ARA4R7MKE0S
10 LH0 0.25 140 EMVA401SDA100MLH0S
400
22 LN0 0.25 280 EMVA401SDA220MLN0S
22 MH0 0.25 280 EMVA401SDA220MMH0S
33 MN0 0.25 350 EMVA401SDA330MMN0S
4.7 KE0 0.25 120 EMVA451ARA4R7MKE0S
10 LH0 0.25 140 EMVA451SDA100MLH0S
450
22 LN0 0.25 280 EMVA451SDA220MLN0S
33 MN0 0.25 350 EMVA451SDA330MMN0S
(mF)
Size code
F55
F80
Rated ripple
current
tane
(mArms/
85c,120Hz)
0.14 54 EMVA350ADA330MF55G
0.14 120 EMVA350ADA101MF80G
Part No.
(2/2)
CAT. No. E1001K
