modular enclosure MUREVA, IP65
aesthetics
c Elegant and robust design.
c Colour easy to integrate in any environment.
multi-functional
c Different solutions for: industrial control,
electrical distribution, automation, etc.
c
evolutionary
c Add-on possibility.
c The association kit allows the cable passage
while maintaining IP65.
ergonomics and time saving
c Ample space allowing clear cable assembly.
c Easy to label.
c Back with PG and ISO concentric knock-
outs.
c Removable chassis.
c Screwed or clipped terminals.
weatherproof & versatile enclosures
security
c Total insulation (class 2).
c Heat resistance: 750 °C.
c Halogen free.
c Provision of earthing terminals in all
models.
c Can be sealed and/or locked.
complete range
c From economical mini-enclosures of
reduced dimensions, up to 54 modules
available.
c Polyvalent enclosures for non-modular
equipment.
c Wide range of accessories.
robust and weatherproof
c IP65 as per IEC 60529: protection against
ingress of solid bodies and liquid.
c IK09 as per EN 50102: protection against
shocks.
flexibility
c A large number of configurations are
possible.
c Possibility of combine modular and not-
modular devices.
1
Page 2
modular enclosure MUREVA, IP65
suitable for all the environments
c Kitchens: humid environments. c Harbours, seaside: saline & corrosive
atmosphere.
mini-ED
c Weatherproof mini-enclosures for modular
switchgear, economic and compact.
ED
c Weatherproof enclosures for modular
switchgear. up to 54 modules. With 1, 2 or 3
lines of 12 or 18 modules.
c Fairs, amusement park: outdoor. c Greenhouses: humid and dusty places.
c Garages, parking lot: atmospheres
plenty of dust and smoke.
c Swimming pool: humid and chlorinated
ambiance.
mixta
c Provides a row for modular switchgear and a
zone to install non-modular switchgear.
universal
c The opaque door versatile enclosure
provides a zone to install non-modular
switchgear.
2
Page 3
modular enclosure MUREVA, IP65
enclosure's characteristic
c The Coupling kit can be used to combine
two enclosures while maintaining IP65 and
allowing the cable passage.
c Back with PG and ISO concentric
knock-outs.
82502
c Direct wall fixing by means of the holes in
the rear of enclosure or with use of the wall
fixing brackets.
c Wiring strap used for simplified cabling.
3
c Labels for a clear and easy identification.
Page 4
modular enclosure MUREVA, IP65
1
1
2
2
3
3
4
4
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
c Screewed or clipped terminals block.
c Easy chassis removable allowing quick
cabling and components assembly.
c Two possible depth position for rail
assembly.
c Security kit used to seal the front face.
c The chassis can be cut allowing the
installation of a mounting plate for nonmodular switchgear.
180¡
c Reversible front section allowing lid to be
open left or right.
c Optional keylock available for further
security.
CLACK !
c Quick hinges disassembly allowing easy
removal of the lid.
4
Page 5
modular enclosure MUREVA, IP65
mini-ED
Weatherproof mini-enclosures for modular
switchgear, economic and compact.
technical data
c Self-extinguishing insulating material, flame
and abnormal heat resistance: 750 °C as per
IEC 60695-2-1.
c Operating temperature: –25 °C to +60 °C.
c Color: light grey RAL 7035 and semi-
transparent door.
c IP65 as per IEC 60529.
c IK09 as per EN 50102.
c Class 2: total insulation.
c Complies with standard IEC 60439-3 (low
voltage switchgear and control assemblies).
c Resistance to chemicals and atmospherics
agents.
c Stainless steel screws.
constructive characteristics
c Clip-on terminal block support.
c Provision of additional neutral or earthing
terminals in all models.
c Possibility of coupling two enclosures while
maintaining IP65 and allowing the cable
passage.
c Back with PG and ISO concentric knock-
outs.
c Optional keylock available for further
security.
c Possibility of seal the front face.
mini modulari.tif
references
external dimensions (mm)
height width depth reference number of number of
150 80 98 82001 31
200 123 112 82002 41
200 159 112 82003 61
200 195 112 82004 81
200 267 112 82005 12 1
modules rows
Delivered with
c Terminal block support.
c Earth terminal block.
c Marking kit.
c Caps for class 2 isolation.
number of terminal blocks delivered with a box
reference number of number of earth terminal
modules rows terminal block support
82001 3 1 4 holes –
82002 4 1 4 holes 1
82003 6 1 8 holes 1
82004 8 1 8 holes 1
82005 12 1 16 holes 1
1
Page 6
modular enclosure MUREVA, IP65
159
=
=
45
45
M20
M16
M25/Pg16
25
22
enclosures mini-ED
DminiA.eps
3, 4 and 6 modules
DminiD.eps
=
DminiC.eps
49
42.4
42.4
M20
43.5
A
B
DminiB.eps
3.5
35.5
22
98/112
8 and 12 modules
external dimensions (mm)
reference height width depth number of weight
140
30
=
DminiE.eps
=
= =
D
140
30
=
82001 150 80 98 3 – 300
82002 200 123 112 4 – 450
82003 200 159 112 6 – 500
82004 200 195 112 8 88 700
82005 200 267 112 12 160 900
(A) (B) (C) modules D (g)
M25/Pg16
DminiF.eps
DminiI.eps
3 modules 4 modules 6 modules
M25/Pg16
M20
27.5
DminiG.eps
=
=
80
=
65
123
M16
25
DminiH.eps
=
8 modules 12 modules
M16
M20
M16
M25/Pg16M20
20.5
25
=
35
35
65
195
65
=
M16
30
DminiL.eps
M20
M25/Pg16
42.5 42.5
7527= 75 27 =
M32/Pg21
267
M25/Pg16
M20
M16
20.5
25
2
Page 7
modular enclosure MUREVA, IP65
modular enclosure
Weatherproof enclosures for modular
switchgear.
Up to 54 modules. With 1, 2 or 3 lines of 12 or
18 modules.
technical data
c Self-extinguishing insulating material, flame
and abnormal heat resistance: 750 °C as per
IEC 60695-2-1.
c Operating temperature: –25 °C ... +60 °C.
c Colour: light grey RAL 7035 and semi
transparent door.
c IP65 as per IEC 60529.
c IK09 as per EN 50102.
c Class 2: Total insulation.
c Complies with standard IEC 60439-3 (low
voltage switchgear and control assemblies).
c Resistance to chemicals and atmospherics
agents.
c Stainless steel screws.
constructive characteristics
c Reversible front face for opening of door to
the left or right.
c Screwed terminal block support.
c Provision of additional neutral or earthing
terminals in all models.
c Possibility of coupling two enclosures while
maintaining IP65 and allowing the cable
passage.
c Back with PG and ISO concentric
knock-outs.
c Direct wall fixing by means of the holes in
the rear of enclosure or with use of the wall
fixing brackets (not included).
c Ergonomic and sure lock that allow the
installation of a key for further security.
c Possibility of seal the front face.
c Possibility of adding wiring strap for
simplified cabling.
derivered with
c Terminal block support.
c Earth terminal block.
c Marking kit.
c Wiring strap.
c Caps for class 2 isolation.
c Blanking plate (5 modules of 18 mm).
modulari.tif
references
external dimensions (mm)
height width depth reference number of number of
280 340 160 82010 12 1
280 448 160 82020 18 1
460 340 160 82011 24 2
460 448 160 82021 36 2
610 340 160 82012 36 3
610 448 160 82022 54 3
number of terminal blocks delivered with a box
reference number of number earth terminal terminal
modules of rows block support
82010 12 1 8 holes 1
82020 18 1 16 holes 1
82011 24 2 22 holes 1
82021 36 2 32 holes 1
82012 36 3 32 holes 1
82022 54 3 2x22 holes 2
modules rows
1
Page 8
modular enclosure MUREVA, IP65
modular enclosures
Width 12 modules
D212fm.eps
D212r.eps
external dimensions (mm)
references heightwidth depth number of weight
M32(*)
81
D212l.eps
118
62
118
32
164
81
Dbase1f.eps
118
A
D
81
118
280
62
118
460
82010 280 340 160 12 118 81 1900
82011 460 340 160 24 251 104,5 3100
82012 610 340 160 36 401 104,5 4100
(*) Knock-outs for coupling enclosures.
81
118
62
88
62
118
(A) (B) (C) modules D E (g)
M32/Pg21(*)
24.5
46
17
D212s.eps
610
M25/Pg16
37
64
92
106
119
M32/Pg21
37
64
92
106
119
32
17
60
72
M16
M20/Pg11
340
Width 18 modules
D218fm.eps
D218r.eps
E
140140
D
A
101
32
81
D218l.eps
118
62
118
81
81
118
M32(*)
164
Dbase1f.eps
280
101
81
81
118
62
118
460
81
101
external dimensions (mm)
references heightwidth depth number of weight
82020 280 448 160 18 118 81 2400
82021 460 448 160 36 251 104,5 3850
82022 610 448 160 54 401 104,5 4150
(*) Knock-outs for coupling enclosures.
81
118
62
88
62
118
(A) (B) (C) modules D E (g)
M32/Pg21(*)
M25/Pg16
M50/Pg36/Pg29
47
47
81
169
160
118
81
118
160
169
D218s.eps
610
27
32
70
M20/Pg11
448
E
194194
81
101
101
81
81
101
2
Page 9
modular enclosure MUREVA, IP65
mini-ED
Weatherproof mini-enclosures for modular
switchgear, economic and compact.
technical data
c Self-extinguishing insulating material, flame
and abnormal heat resistance: 650 °C as per
IEC 60695-2-1.
c Operating temperature: –25 °C to +60 °C.
c Color: light grey RAL 7035 and semi-
transparent door.
c IP65 as per IEC 60529.
c IK09 as per EN 50102.
c Class 2: total insulation.
c Complies with standard IEC 60439-3 (low
voltage switchgear and control assemblies).
c Resistance to chemicals and atmospherics
agents.
c Stainless steel screws.
constructive characteristics
c Clip-on terminal block support.
c Provision of additional neutral or earthing
terminals in all models.
c Possibility of coupling two enclosures while
maintaining IP65 and allowing the cable
passage.
c Back with PG and ISO concentric knock-
outs.
c Optional keylock available for further
security.
c Possibility of seal the front face.
Delivered with
c Terminal block support.
c Earth terminal block with green
cover, neutral terminal block
with blue cover.
c Marking kit.
c Caps for class 2 isolation.
mini modulari.tif
references
external dimensions (mm)
height width depth reference number of number of
modules rows
150 80 98 82101 31
200 123 112 82102 41
200 159 112 82103 61
200 195 112 82104 81
200 267 112 82105 12 1
number of terminal blocks delivered with a box
reference number of number of terminal block terminal
modules rows earth neutral support
82101 3 1 4 holes 4 holes –
82102 4 1 4 holes 4 holes 2
82103 6 1 8 holes 8 holes 2
82104 8 1 8 holes 8 holes 2
82105 12 1 16 holes 16 holes 2
1
Page 10
modular enclosure MUREVA, IP65
159
=
=
45
45
M20
M16
M25/Pg16
25
22
enclosures mini-ED
DminiA.eps
3, 4 and 6 modules
DminiD.eps
=
DminiC.eps
49
42.4
42.4
M20
43.5
A
B
DminiB.eps
3.5
35.5
22
98/112
8 and 12 modules
external dimensions (mm)
reference height width depth number of weight
140
30
=
DminiE.eps
=
=
=
D
140
30
=
82101 150 80 98 3 – 300
82102 200 123 112 4 – 450
82103 200 159 112 6 – 500
82104 200 195 112 8 88 700
82105 200 267 112 12 160 900
(A) (B) (C) modules D (g)
M25/Pg16
DminiF.eps
DminiI.eps
3 modules 4 modules 6 modules
65
123
M16
25
DminiH.eps
=
M25/Pg16
M20
27.5
DminiG.eps
=
=
80
=
8 modules 12 modules
M16
M20
M16
M25/Pg16M20
20.5
25
=
35
35
65
195
65
=
M16
30
DminiL.eps
M20
M25/Pg16
42.5 42.5
7527= 75 27 =
M32/Pg21
267
M25/Pg16
M20
M16
20.5
25
2
Page 11
modular enclosure MUREVA, IP65
modular enclosure
Weatherproof enclosures for modular
switchgear.
Up to 54 modules. With 1, 2 or 3 lines of 12 or
18 modules.
technical data
c Self-extinguishing insulating material, flame
and abnormal heat resistance: 650 °C as per
IEC 60695-2-1.
c Operating temperature: –25 °C ... +60 °C.
c Colour: light grey RAL 7035 and semi
transparent door.
c IP65 as per IEC 60529.
c IK09 as per EN 50102.
c Class 2: Total insulation.
c Complies with standard IEC 60439-3 (low
voltage switchgear and control assemblies).
c Resistance to chemicals and atmospherics
agents.
c Stainless steel screws.
constructive characteristics
c Reversible front face for opening of door to
the left or right.
c Screwed terminal block support.
c Provision of additional neutral or earthing
terminals in all models.
c Possibility of coupling two enclosures while
maintaining IP65 and allowing the cable
passage.
c Back with PG and ISO concentric
knock-outs.
c Direct wall fixing by means of the holes in
the rear of enclosure or with use of the wall
fixing brackets (not included).
c Ergonomic and sure lock that allow the
installation of a key for further security.
c Possibility of seal the front face.
c Possibility of adding wiring strap for
simplified cabling.
modulari.tif
references
external dimensions (mm)
height width depth reference number of number of
280 340 160 82110 12 1
280 448 160 82120 18 1
460 340 160 82111 24 2
460 448 160 82121 36 2
610 340 160 82112 36 3
610 448 160 82122 54 3
modules rows
derivered with
c Terminal block support.
c Earth terminal block with green cover,
neutral terminal block with blue cover.
c Marking kit.
c Wiring strap.
c Caps for class 2 isolation.
c Blanking plate (5 modules of 18 mm).
1
number of terminal blocks delivered with a box
reference number of number terminal block terminal
modules of rows earth neutral support
82110 12 1 8 holes 8 holes 2
82120 18 1 16 holes 16 holes 2
82111 24 2 22 holes 22 holes 2
82121 36 2 32 holes 32 holes 2
82112 36 3 32 holes 32 holes 2
82122 54 3 22+22 holes 22+22 holes 4
Page 12
modular enclosure MUREVA, IP65
modular enclosures
Width 12 modules
D212fm.eps
D212r.eps
external dimensions (mm)
references heightwidth depth number of weight
M32(*)
81
D212l.eps
118
62
118
32
164
81
Dbase1f.eps
118
A
D
81
118
280
62
118
460
82110 280 340 160 12 118 81 1900
82111 460 340 160 24 251 104,5 3100
82112 610 340 160 36 401 104,5 4100
(*) Knock-outs for coupling enclosures.
81
118
62
88
62
118
(A) (B) (C) modules D E (g)
M32/Pg21(*)
24.5
46
17
D212s.eps
610
M25/Pg16
37
64
92
106
119
M32/Pg21
37
64
92
106
119
32
17
60
72
M16
M20/Pg11
340
Width 18 modules
D218fm.eps
D218r.eps
E
140140
D
A
101
32
81
D218l.eps
118
62
118
81
81
118
M32(*)
164
Dbase1f.eps
280
101
81
81
118
62
118
460
81
101
external dimensions (mm)
references heightwidth depth number of weight
82120 280 448 160 18 118 81 2400
82121 460 448 160 36 251 104,5 3850
82122 610 448 160 54 401 104,5 4150
(*) Knock-outs for coupling enclosures.
81
118
62
88
62
118
(A) (B) (C) modules D E (g)
M32/Pg21(*)
M25/Pg16
M50/Pg36/Pg29
47
47
81
169
160
118
81
118
160
169
D218s.eps
610
27
32
70
M20/Pg11
448
E
194194
101
81
101
81
81
101
2
Page 13
modular enclosure MUREVA, IP65
accessories
association kit
c Used for horizontal or vertical coupling of
two enclosures with one another while
preserving IP65 and allowing the cable
passage.
c Composed of 2 sleeves, 4 nuts and 4 joints.
wall fixing brackets
c Used to fix the enclosures to the wall
without using holes in the back of the
enclosure.
c Each bracket can be assembled in 3 different
positions.
c Set of 4 wall fixing brackets.
reference description
82502 association kit
reference description
82501 wall fixing brackets
terminal block support for mini
enclosures
c Metallic terminal block support clip-on the
bottom of the box.
terminal block support for
enclosures onto pins
c Metallic.
c They can be screwed on to the pins at the
top or bottom of the enclosure.
c They can be superimposed to double
capacity.
c Delivered with screws.
number
of modules reference
4 82751
6 82752
8 82753
12 82754
number
of modules reference
8 82763
12 82764
18 82765
1
Page 14
modular enclosure MUREVA, IP65
accessories
terminal block support for
enclosures onto chassis
c Metallic.
c They can be screwed onto the chassis
simplifying the cables connections.
c Delivered with screws.
terminal block
There are 5 references of terminals blocks with
different possibilities of assembly:
c All models: clipped onto terminal block
support.
c 4 holes: clipsed by means of dovetails.
c 8 holes: clipped onto the DIN rails, screwed
onto the back.
number
of modules reference
12 82774
18 82775
82701
82702
82703
82704
IP2 covers
c The terminal block can be protected and
identified by IP2 coloured (green, red or
blue) covers.
82705
terminal block
composition terminal block
number section in mm
2
width
4
1
2
3
4
5
6
7
8
1
1
2
2
3
3
4
1
2
3
4
5
6
7
8
1
2
3
4
references of holes 10 16 in mm
82701 42229✓✓
82702 84485✓✓✓
82703 16 8 8 202 ✓
82704 22 11 11 202 ✓
82705 32 16 16 202 ✓
references
number
of holes green red blue
4 82711 82721 82731
8 82712 82722 82732
16, 22, 32 82715 82725 82735
2
Page 15
modular enclosure MUREVA, IP65 accessories
sealing kit
Sealing kit:
c Used to seal the front face on the back using
2 screws and 2 caps.
keylock insert
c These are mounted in the handle without
increasing the overall dimensions of the
enclosure.
c Three different references to increase safety.
reference description
82559 sealing kit
descriptions reference
Eurolock nº 850 82550
Eurolock nº 851 82551
Eurolock nº 852 82552
wiring strap
c Used to guide cables along walls for
simplified cabling.
c Clip-on several places at the bottom.
blanking plate
c Set of 10 strips of 5 modules.
c Clipped onto the front plates to cover slots
with no devices.
c Color RAL 7035.
reference description
82506 wiring strap
reference description
82505 blanking plate
3
Page 16
modular enclosure MUREVA, IP65 accessories
plain chassis
c Metallic.
c Screwed onto the back of the enclosure by
means of selftapping screws included with
the enclosure.
c Used to fix non-modular devices.
perforated plate
c Screwed onto the back of the enclosure by
means of selftapping screws included with
the enclosure.
c Used to fix non-modular devices.
for enclosures (mm)
height width reference
(A) (B)
250 150 82604
460 340 82600
460 448 82601
610 340 82602
610 448 82603
for enclosures (mm)
height width reference
(A) (B)
250 150 82614
460 340 82610
460 448 82611
610 340 82612
610 448 82613
clip nut
c Clip on perforated plate, for attachment of
equipment.
selftapping screws
c Set of 4 screws and 4 nuts.
reference for screw
21163 M3
21164 M4
21165 M5
21166 M6
selftapping screws 82609
4
Page 17
modular enclosure MUREVA, IP65 accessories
IP67 cable entries
n IP67.
n Conforming to standard EN 50262.
n Material: EPDM plastic.
n Adapted to wall thicknesses 1 to 4 mm
(0,5 to 2 mm for ref. 08831).
n Fast no-tool installation.
IP55 cable entries
n IP55.
n RAL 7035.
n Material: SBS.
reference ISO cable Ø of
Ø (mm) drilling
08831 M12 3 - 5 13
08832 M16 5 - 7 16
08833 M20 7 - 10 20
08834 M25 10 - 14 24
08835 M32 14 - 20 30
08836 M40 20 - 26 38
08837 M50 26 - 35 48
Ø (mm) references and colours
drilling cable white ligth grey grey
RAL 9010 RAL 7035 RAL 7004
23 4 - 20 08121 08111 08131
29 4 - 25 08122 08112 08132
36 4 - 30 - 08113 44 4 - 40 - 08114 -
cable gland
n IP68, 5 bars.
n Conforming to standard EN 50262.
n Grey RAL 7035.
n Material: PA6, neoprene seal.
n Operating temperature: –30 °C ... +80 °C
and up to +150 °C for short periods.
n Cable glands are supplied with nuts.
n Possibility of insert several cables in a single
cable gland using the multicable insert.
cable gland multicable insert transport plug (for
temporary protection of
box contents)
cable gland multicable joint plug transport
1 cable insert plug
Ø Ø min./max. No./Ø
ref. (mm) ref. (mm)
M12 08071 3/6.5 - - 08091 08101 M16 08072 4/8 08097 2 34 08092 08102 08291
M20 08073 6/12 08098 3 34 08093 08103 08292
M25 08074 11/17 08099 43 5 08094 08104 08293
M32 08075 15/21 08100 63 5 08095 08105 08294
M40 08076 19/28 - - 08096 08106 08295
5
Loading...
