Features

 The most easy used linear constant current LED driver
 15mA~ 60mA, 1 to 2 channel constant current

regulator

 No external current setting resistor is needed
 1.5V ~ 12V wide supply voltage range supports self

power structure in lighting application

 Very low dropout voltage

IPN ≦ 40mA → VPN ≒ 0.4V
IPN ＞ 40mA → VPN ≒ 0.6V

 PWM dimming by VDD pin
 2uS/2uS current rising/falling time
 -40℃ ~ 120℃ junction operating temperature
 Cascade-able for higher voltage applications*

( type 1Axx only)

 Current leak/no leak design for lighting/display

Application

 Low chip to chip current skew

IPN ≦ 40mA → chip current skew < ±5%
IPN ＞ 40mA → chip current skew < ±6%

 Less than 1%/V load (or line) regulation
 Minimized footprint
 Green package

* Patent pending

Product Description

MT501 is a simple general purpose current regulation

component that can be easily used in various LED lighting

applications. With the excellent load/line regulation and

minimized chip current skew, MT501 keep LED’s current

very stable even when power or load fluctuate in a wide

range and make light intensity very uniform in large area of

LED light source.

Except power supply function, the VDD pin of MT501 is

output enable (OE) also, and can be used in digital PWM

controlled circuit to achieve more precise current adjusting

in gray level applications.

The minimized power supply voltage let MT501 be used

as a current regulative diode (CRD) when VDD and VP pin

are tight together. This application makes MT501 very easy

to be used. Just like a diode, when this diode is inserted in

LED series, the current in circuit is regulated.

In high supply voltage and low LED load voltage

applications, two or more single channel MT501 (A type)

can be connected in series to share redundant high voltage.

With the unique share voltage technology of MOS-TECH

Semiconductor, the extra redundant voltage can be shared

by each MT501 by a reasonable mechanism. This special

capability let MT501 very suit for the usage of wide range

power supply that many liner type LED drivers cannot work.

Applications

Type A – For lighting application

 General LED lighting
 LCD back lighting
 LED torch / flashlight
 RGB lighting

Type B – For display application (No current leak)

 RGB display pixel driver

Package Type

 SOT 23-3 (single channel, type A/B)

 SOT23-5 (dual channel, type A) – two independent

driver in single package.

 SOT89-3 (single channel, type A, package option)

MOS-TECH Semiconductor Co.,LTD

  

LOW POWER LIGHTING LED DRIVER DATA SHEET

MT501

15 ~ 60mA Single/Dual channel LED Driver

V

1 A X X

V

P

N

V

DD

V

1 B X X

V

P

N

V

DD

V

DD1

V

DD2

2 A X X

V

P1

V

P

1AXX
XXXX

V

V

P2

N

V

V

DD

N

Pin Name

Function

VDD

Power supply

VP

Current in

VN

Current out

Part Number: MT501

Example: “1A25” is single channel cascade-able MT501, current 25mA.

“1B25” is single channel NU501, current 25mA

“2A20” is dual channel NU501, current 20mA.

PS: Before you issue your P.O., please contact your agent or

MOS-TECH Semiconductor to make sure the channel and center current

that is available.

Characteristic

Symbol

Rating

Unit

Supply voltage

VDD

0 ~ 16

V

Output voltage

VP

-0.2 ~ 17

V

Output current

IPN

IS** +10%

mA

Power Dissipation (Ta=25°C)

PD

SOT 23

0.25

W

SOT 89

0.7

Thermal Resistance (On PCB, Ta=25°C)

RTH(j-a)

SOT 23

300

°C /W

SOT 89

180

Operating temperature

TOPR

-40~+85

°C

Storage temperature

TSTG

-55~+150

°C

Terminal Description

Ordering Information

Top marking

A xx

x

Channels

Product type

Output current (mA)

Block Diagram per channel and Ideal IV characteristic

V

DD

Ipn

Vp

Vrefence

Vn

Maximum Ratings (T = 25°C)

Ip

Is

Vt Viboost

Type A – IV curve Type B – IV curve

Ip

Iboost

Is

Vp

Vt

Vp

Electrical Characteristics and Recommended Operating Conditions

Characteristic Symb

Supply voltage V

ol Condition Min. Typ. Max. Unit

Room Temp.

DD

Supply current IDD - 100 150 250 uA

Minimum dropout voltage V

Maximum output voltage V

Output breakdown voltage V

Output current I

Leakage I

Line regulation %/V

Load regulation %/V

Thermal regulation

Threshold voltage (Type A only) V

Current boost (Type A only) I

Chip current skew I

**

is output saturation current.

I

S

VDD >=3.8V 0.4 - 0.6 V

PNmin

IPN = I

PNmax

IPN = 0, VDD = 0V - - 17 V

PNBD

S

Leakage

DD

P

0V < VDD < 0.4V,

%/10℃

iboost

boost

Skew

V

DD

Switching Characteristics (T = 25°°°°C)

IS <= 25mA 1.5 - 12

V

>= 1V

PN

IS > 40mA 2.5 - 12

S

- - 0.25 / I

Spec. 15 - 60 mA

Type A 1 - 5 uA

VP = 10V

12V > V

Type B 0 - 0.5 uA

> 1.6V - -

DD

8V > VP > 1.6V - -

V

= VP = 2V - -

DD

IP = IS*1.1 11 12 13 V

VP = V

7 10 13 % * IS

iboost

IPN <= 40mA - - 5

= VP = 2V

IPN > 40mA - - 6

±

±
±

0.5

V IS <= 40mA 2 - 12

PN

1

1

V

%/V

%/V

%/10

℃

%

Characteristic Symbol Condition Min. Typ. Max. Unit

Propagation Delay Time

VDD from “L” to “H”

Output current rising time t

Propagation Delay Time

VDD from “H” to “L”

Output current falling time t

Test Circuit

Function

generator

t

pLH

Rise

t

VP=1V, V

pHL

VP=1V, V

Fall

VP=1V, V

VP=1V, V

V

DD

= 0V → 3V - 1 - uS

DD

= 0V → 3V - 1.5 5 uS

DD

= 3V → 0V - 1 - uS

DD

= 3V → 0V - 1.5 5 uS

DD

+V

R

Load

V

P

MT501

V

N

0.1

0.511.8

2.6

3.4

4.255.8

6.6

7.4

8.299.8

10.6

11.4

12.21313.8

14.6

15.4

16.2

17

V

V

V

V

V

V

V

V

V

V

Timing Waveform

V

DD

V

P

I/V curve

50%

t

Rise

t

50%

10%

50%

pHL

90%

t

Fall

t

pLH

90%

50%

10%

V

DD

DD

MT501

N

P

70.00

60.00

(mA)

50.00

PN

40.00

30.00

20.00

Output current I

10.

00

0.00

Load regulation characteristic (A type)

1A60

1A55

1A2

1A18

1A50

1A30

1A25

0

1A40

1A35

1A45

V

DD

= 3.8V

Output voltage V

PN

(V)

V

DD

Load regulation characteristic (B type)

DD

MT501

N

P

(mA)

PN

1B30

1B25

Output current I

V

= 3.8V

DD

Output voltage V

PN

(V)

70.0

0.9

1.4

1.9

2.4

2.9

3.5

4.4

5.2

6.2

7.2

8.2

9.2

IDD

Vs. V

DD

Characteristic (Room Temp)

V

PN

= 2V

Line regulation characteristic

60.0

50.0

(mA)

PN

40.0

30.0

20.0

Output current I

10.

0

1A60

1A5
1A50

1A45
1A40

1A35

1A30
1A25

1A2

1A18

5

0

V

= 1V

PN

0.0

Supply voltage V

DD

(V)

IDD Vs. Temperature Characteristic

VDD= 5V

(uA)

DD

I

Supply voltage V

DD

(V)

(uA)

DD

I

Temperature (°C)

Application design consideration

MT501 is a linear constant current driver. While this device is designed in lighting system, the heat generation should be

considered. Generally, the higher current designed in system, the higher power will suffer by this

power consuming by MT501 and to increase the whole system efficiency, the drop voltage across

minimized. The following design note can reduce the heat generation from

output constant current and the needed supply voltage (normal operation condition).

1. Drop the power supply voltage as low as possible in the normal operation condition.

2. Get the LEDs in current loop as many as possible in the normal operation condition.

3. Get a voltage sharing resistor in series in current loop .

4. If system power is greater that 24V, it suggests to connect a small SMD type capacitor (0.1uF~10uF) between VDD and

VN pin. That will greatly improve the stability of system.

1AXX

V

V

V

1AXX

V

+24

V

1A20

V

generator

1B20

V

V

V

V

12V

V

V

generator

RGB PWM signal

1B20

V

1B20

V

1B20

V

1B20

1B20

1B20

1B20

1B20

1B20

PWM R

PWM R

PWM G

PWM G

PWM B

PWM B

V

12V

V

12V

V

P

Application Circuits

 5V PWM indicator application

+5V

PWM

DD

MT501

N

V

P

 24V PWM lighting with dimming application

With the special designed character of leak, the A type
NU501 can be used in dimming application even when
system power is higher than the maximum VP voltage.

PWM

generator

V

MT501

P

V

N

DD

 12V

lighting application

V

V

DD

P

MT501 MT501

N

V

DD1 VDD2

P1

V

N

 High voltage drop application

DD

V

P

MT501

V

DD

N

P

MT501

8V ~ 24V

 Parallel application

DD

MT501

V

N

DD

P

MT501

V

N

P

 RGB display pixel application

+5V

PWM

PWM R

V

DD

MT501

V

N

PWM G

V

V

DD

P

MT501 MT501

V

N

PWM B

V

V

P

V

DD

P

V

N

V

DD

P

MT501 MT501 MT501

V

N

V

DD

V

N

DD

P

V

V

P

N

2

V

DD

MT501

V

N

V

P

V

DD

MT501

V

N

V

V

V

P

DD

MT501

V

N

P

N

 36V light tube application

LED Vf = 3.3V ~ 3.5V

V

= 35.5V ~ 40V

LED

Package Dimensions

Taping Specification

 SOT23-3

PACKAGE Q’TY/REEL

SOT23-3 3,000 ea

SOT23-5 3,000 ea

SOP89 1,000 ea

 SOT23-5

 SOT89

MOS-TECH Semiconductor Co.,LTD

  

Notes regarding these materials

1. This document is provided for reference purposes only so that Mos-tech customers may select the appropriate
Mos-tech products for their use. Mos-tech neither makes warranties or representations with respect to the
accuracy or completeness of the information contained in this document nor grants any license to any
intellectual property rights or any other rights of Mos-tech or any third party with respect to the information in
this document.

2. Mos-tech shall have no liability for damages or infringement of any intellectual property or other rights arising
out of the use of any information in this document, including, but not limited to, product data, diagrams, charts,
programs, algorithms, and application circuit examples.

3. You should not use the products or the technology described in this document for the purpose of military
applications such as the development of weapons of mass destruction or for the purpose of any other military
use. When exporting the products or technology described herein, you should follow the applicable export
control laws and regulations, and procedures required by such laws and regulations.

4. All information included in this document such as product data, diagrams, charts, programs, algorithms, and
application circuit examples, is current as of the date this document is issued. Such information, however, is
subject to change without any prior notice. Before purchasing or using any Mos-tech products listed in this
document, please confirm the latest product information with a Mos-tech sales office. Also, please pay regular
and careful attention to additional and different information to be disclosed by Mos-tech such as that disclosed
through our website. (http://www.mtsemi.com )

5. Mos-tech has used reasonable care in compiling the information included in this document, but Mos-tech
assumes no liability whatsoever for any damages incurred as a result of errors or omissions in the information
included in this document.

6. When using or otherwise relying on the information in this document, you should evaluate the information in
light of the total system before deciding about the applicability of such information to the intended application.
Mos-tech makes no representations, warranties or guaranties regarding the suitability of its products for any
particular application and specifically disclaims any liability arising out of the application and use of the
information in this document or Mos-tech products.

7. With the exception of products specified by Mos-tech as suitable for automobile applications, Mos-tech
products are not designed, manufactured or tested for applications or otherwise in systems the failure or
malfunction of which may cause a direct threat to human life or create a risk of human injury or which require
especially high quality and reliability such as safety systems, or equipment or systems for transportation and
traffic, healthcare, combustion control, aerospace and aeronautics, nuclear power, or undersea communication
transmission. If you are considering the use of our products for such purposes, please contact a Mos-tech
sales office beforehand. Mos-tech shall have no liability for damages arising out of the uses set forth above.

8. Notwithstanding the preceding paragraph, you should not use Mos-tech products for the purposes listed below:
(1) artificial life support devices or systems
(2) surgical implantations
(3) healthcare intervention (e.g., excision, administration of medication, etc.)
(4) any other purposes that pose a direct threat to human life
Mos-tech shall have no liability for damages arising out of the uses set forth in the above and purchasers who
elect to use Mos-tech products in any of the foregoing applications shall indemnify and hold harmless Mos-tech
Technology Corp., its affiliated companies and their officers, directors, and employees against any and all
damages arising out of such applications.

9. You should use the products described herein within the range specified by Mos-tech, especially with respect
to the maximum rating, operating supply voltage range, movement power voltage range, heat radiation
characteristics, installation and other product characteristics. Mos-tech shall have no liability for malfunctions or
damages arising out of the use of Mos-tech products beyond such specified ranges.

10. Although Mos-tech endeavors to improve the quality and reliability of its products, IC products have specific
characteristics such as the occurrence of failure at a certain rate and malfunctions under certain use
conditions. Please be sure to implement safety measures to guard against the possibility of physical injury, and
injury or damage caused by fire in the event of the failure of a Mos-tech product, such as safety design for
hardware and software including but not limited to redundancy, fire control and malfunction prevention,
appropriate treatment for aging degradation or any other applicable measures. Among others, since the
evaluation of microcomputer software alone is very difficult, please evaluate the safety of the final products or
system manufactured by you.

11. In case Mos-tech products listed in this document are detached from the products to which the Mos-tech
products are attached or affixed, the risk of accident such as swallowing by infants and small children is very
high. You should implement safety measures so that Mos-tech products may not be easily detached from your
products. Mos-techshall have no liability for damages arising out of such detachment.

12. This document may not be reproduced or duplicated, in any form, in whole or in part, without prior written
approval from Mos-tech.

13. Please contact a Mos-tech sales office if you have any questions regarding the information contained in this
document, Mos-tech semiconductor products, or if you have any other inquiries.

©2010 MOS-TECH Semiconductor Corporation www.mtsemi.com

MOS-TECH Semiconductor Co.,LTD

  

⊼ᛣ

ᴀ᭛াᰃখ㗗䆥᭛ˈࠡ义᠔䕑㣅᭛⠜“Cautions”݋᳝ℷᓣᬜ࡯DŽ

݇Ѣ߽⫼ᴀ䌘᭭ᯊⱘ⊼ᛣџ乍

1. ᴀ䌘᭭ᰃЎњ䅽⫼᠋ḍ᥂⫼䗨䗝ᢽড়䗖ⱘᴀ݀ৌѻકⱘখ㗗䌘᭭ˈᇍѢᴀ䌘᭭Ё᠔䆄䕑ⱘᡔᴃֵᙃˈᑊ䴲ᛣ
ⴔᇍᴀ݀ৌ៪㗙㄀ϝ㗙ⱘⶹ䆚ѻᴗঞ݊Ҫᴗ߽خߎֱ䆕៪ᇍᅲᮑᴗ࡯䖯㸠ⱘᡓ䇎DŽ

2. ᇍѢ಴Փ⫼ᴀ䌘᭭᠔䆄䕑ⱘѻક᭄᥂ǃ೒ǃ㸼ǃ⿟ᑣǃㅫ⊩ঞ݊Ҫᑨ⫼⬉䏃՟㗠ᓩ䍋ⱘᤳᆇ៪㗙ᇍ㄀ϝ㗙ⱘ
ⶹ䆚ѻᴗঞ݊Ҫᴗ߽䗴៤։⢃ˈᴀ݀ৌϡᡓᢙӏԩ䋷ӏDŽ

3. ϡ㛑ᇚᴀ䌘᭭᠔䆄䕑ⱘѻકᡔᴃ⫼Ѣ໻㾘῵⸈ണᗻ℺఼ⱘᓔথㄝⳂⱘǃݯџⳂⱘ៪݊Ҫⱘݯ䳔⫼䗨ᮍ䴶DŽ
঺໪ˈ೼ߎষᯊᖙ乏䙉ᅜ中国ⱘlj໪∛ঞ໪೑䌌ᯧ⊩NJঞ݊ҪߎষⱘⳌ݇⊩Ҹᑊሹ㸠䖭ѯ⊩ҸЁ㾘ᅮⱘᖙ㽕
᠟㓁DŽ

4. ᴀ䌘᭭᠔䆄䕑ⱘѻક᭄᥂ǃ೒ǃ㸼ǃ⿟ᑣǃㅫ⊩ҹঞ݊Ҫᑨ⫼⬉䏃՟ㄝ᠔ֵ᳝ᙃഛЎᴀ䌘᭭থ㸠ᯊⱘݙᆍˈ
ᴀ݀ৌ᳝ৃ㛑೼᳾خџܜ䗮ⶹⱘᚙމϟˈᇍᴀ䌘᭭᠔䆄䕑ⱘѻક៪㗙ѻક㾘Ḑ䖯㸠᳈ᬍDŽ᠔ҹ೼䌁фՓ⫼
ᴀ݀ৌⱘᇐԧѻકПࠡˈ䇋џܜ৥ᴀ݀ৌⱘ㧹Ϯにষ⹂䅸᳔ᮄⱘֵᙃᑊ㒣ᐌ⬭ᛣᴀ݀ৌ䗮䖛݀ৌЏ义

(http://www.mtsemi.com)ㄝ݀ᓔⱘ᳔ᮄֵᙃDŽ

5. ᇍѢᴀ䌘᭭Ё᠔䆄䕑ⱘֵᙃˈࠊ԰ᯊ៥Ӏሑ࡯ֱ䆕ߎ⠜ᯊⱘ㊒⹂ᗻˈԚϡᡓᢙ಴ᴀ䌘᭭ⱘভ䗄ϡᔧ㗠㟈Փ乒

ᅶ䙁ফᤳ༅ㄝⱘӏԩⳌ݇䋷ӏDŽ

6. ೼Փ⫼ᴀ䌘᭭᠔䆄䕑ⱘѻક᭄᥂ǃ೒ǃ㸼ㄝ᠔⼎ⱘᡔᴃݙᆍǃ⿟ᑣǃㅫ⊩ঞ݊Ҫᑨ⫼⬉䏃՟ᯊˈϡҙ㽕ᇍ᠔
Փ⫼ⱘᡔᴃֵᙃ䖯㸠⣀䆘Ӌˈ䖬㽕ᇍᭈϾ㋏㒳䖯㸠ܙߚⱘ䆘ӋDŽ䇋乒ᅶ㞾㸠䋳䋷ˈ䖯㸠ᰃ৺䗖⫼ⱘ߸ᮁDŽ
ᴀ݀ৌᇍѢᰃ৺䗖⫼ϡ䋳ӏԩ䋷ӏDŽ

7. ᴀ䌘᭭Ё᠔䆄䕑ⱘѻકᑊ䴲䩜ᇍϛϔߎ⦄ᬙ䱰៪ᰃ䫭䇃䖤㸠ህӮ࿕㚕ࠄҎⱘ⫳៪㒭Ҏԧᏺᴹᆇⱘᴎ఼ǃ
㋏㒳བ৘⾡ᅝܼ㺙㕂៪㗙䖤䕧Ѹ䗮⫼ⱘǃ⭫ǃ➗⚻᥻ࠊǃ㟾໽఼ẄǃḌ㛑ǃ⍋ᑩЁ㒻⫼ⱘᴎ఼㋏㒳ㄝ
㗠䆒䅵ࠊ䗴ⱘ⡍߿ᰃᇍѢક䋼ৃ䴴ᗻ㽕∖ᵕ催ⱘᴎ఼㋏㒳ㄝ˄ᇚᴀ݀ৌᣛᅮ⫼Ѣ≑䔺ᮍ䴶ⱘѻક⫼
Ѣ≑䔺ᯊ䰸໪˅DŽབᵰ㽕⫼ѢϞ䗄ⱘⳂⱘˈ䇋ࡵᖙџܜ৥ᴀ݀ৌⱘ㧹Ϯにষ䆶DŽ঺໪ˈᇍѢ⫼ѢϞ䗄Ⳃⱘ
㗠䗴៤ⱘᤳ༅ㄝˈᴀ݀ৌὖϡ䋳䋷DŽ

8. 䰸Ϟ䗄㄀乍ݙᆍ໪ˈϡ㛑ᇚᴀ䌘᭭Ё䆄䕑ⱘѻક⫼Ѣҹϟ⫼䗨DŽབᵰ⫼Ѣҹϟ⫼䗨㗠䗴៤ⱘᤳ༅ˈᴀ݀ৌ
ὖϡ䋳䋷DŽ

1˅⫳㓈ᣕ㺙㕂DŽ
2˅ỡඟѢҎԧՓ⫼ⱘ㺙㕂DŽ
3˅⫼Ѣ⊏⭫˄ߛ䰸ᙷ䚼ǃ㒭㥃ㄝ˅ⱘ㺙㕂DŽ
4˅݊ҪⳈ᥹ᕅડࠄҎⱘ⫳ⱘ㺙㕂DŽ

9. ೼Փ⫼ᴀ䌘᭭᠔䆄䕑ⱘѻકᯊˈᇍѢ᳔໻乱ᅮؐǃᎹ԰⬉⑤⬉ⱘ㣗ೈǃᬒ⛁⡍ᗻǃᅝ㺙ᴵӊঞ݊Ҫᴵӊ䇋
೼ᴀ݀ৌ㾘ᅮⱘֱ䆕㣗ೈݙՓ⫼DŽབᵰ䍙ߎњᴀ݀ৌ㾘ᅮⱘֱ䆕㣗ೈՓ⫼ᯊˈᇍѢ⬅ℸ㗠䗴៤ⱘᬙ䱰ߎ⦄
ⱘџᬙˈᴀ݀ৌᇚϡᡓᢙӏԩ䋷ӏDŽ

10.ᴀ݀ৌϔⳈ㟈࡯Ѣᦤ催ѻકⱘ䋼䞣ৃ䴴ᗻˈԚϔ㠀ᴹ䇈ˈᇐԧѻકᘏӮҹϔᅮⱘὖ⥛থ⫳ᬙ䱰ǃ៪㗙⬅
ѢՓ⫼ᴵӊϡৠ㗠ߎ⦄䫭䇃䖤㸠ㄝDŽЎњ䙓ܡ಴ᴀ݀ৌⱘѻકথ⫳ᬙ䱰៪㗙䫭䇃䖤㸠㗠ᇐ㟈Ҏ䑿џᬙ☿♒
៪䗴៤⼒Ӯᗻⱘᤳ༅ˈᏠᳯᅶ᠋㛑㞾㸠䋳䋷䖯㸠ݫԭ䆒䅵ǃ䞛পᓊ⚻ᇍㄪঞ䖯㸠䰆ℶ䫭䇃䖤㸠ㄝⱘᅝܼ䆒䅵
˄ࣙᣀ⹀ӊ䕃ӊϸᮍ䴶ⱘ䆒䅵˅ҹঞ㗕࣪໘⧚ㄝˈ䖭ᰃ԰Ўᴎ఼㋏㒳ⱘߎֱ䆕DŽ⡍߿ᰃ⠛ᴎⱘ䕃ӊˈ
⬅Ѣ⣀䖯㸠偠䆕ᕜೄ䲒ˈ᠔ҹ㽕∖೼乒ᅶࠊ䗴ⱘ᳔㒜ⱘᴎ఼ঞ㋏㒳Ϟ䖯㸠ᅝܼẔ偠Ꮉ԰DŽ

11. བᵰᡞᴀ䌘᭭᠔䆄䕑ⱘѻકҢ݊䕑ԧ䆒໛Ϟϟˈ᳝ৃ㛑䗴៤၈ܓ䇃৲ⱘ䰽DŽ乒ᅶ೼ᇚᴀ݀ৌѻકᅝ㺙ࠄ
乒ᅶⱘ䆒໛Ϟᯊˈ䇋乒ᅶ㞾㸠䋳䋷ᇚᴀ݀ৌѻક䆒㕂Ўϡᆍᯧ࠹㨑ⱘᅝܼ䆒䅵DŽབᵰҢ乒ᅶⱘ䆒໛Ϟ࠹㨑㗠
䗴៤џᬙᯊˈᴀ݀ৌᇚϡᡓᢙӏԩ䋷ӏDŽ

12.೼᳾ᕫࠄᴀ݀ৌⱘџܜк䴶䅸ৃᯊˈϡৃᇚᴀ䌘᭭ⱘϔ䚼ߚ៪㗙ܼ䚼䕀䕑៪㗙໡ࠊDŽ

13.བᵰ䳔㽕њ㾷݇Ѣᴀ䌘᭭ⱘ䆺㒚ݙᆍˈ៪㗙᳝݊Ҫ݇ᖗⱘ䯂乬ˈ䇋৥ᴀ݀ৌⱘ㧹Ϯにষ䆶DŽ

Keep safety first in your circuit designs!

1. MOS-TECH Semiconductor Corp. puts the maximum effort into making semiconductor products better
and more reliable, but there is always the possibility that trouble may occur with them. Trouble with
semiconductors may lead to personal injury, fire or property damage.
Remember to give due consideration to safety when making your circuit designs, with appropriate
measures such as (i) placement of substitutive, auxiliary circuits, (ii) use of nonflammable material or
(iii) prevention against any malfunction or mishap.

©2010 MOS-TECH Semiconductor Corporation www.mtsemi.com
