ISSUED
October 10, 2019
TYPE
AESV3W
PERFORMANCE DATA
3-PHASE INDUCTION MOTOR
NAMEPLATE INFORMATION
OUTPUT
HP KW
75 56.0 60
POLE
6
FRAME
SIZE
VOLTAGE
280M 230/460
TYPICAL PERFORMANCE
FULL
LOAD
RPM
1185
FULL LOAD
MIN. %
93.7 94.0
EFFICIENCY
3/4 LOAD
NOM. %
%
94.5 94.5 84.5
HZ
AMBIENT
1/2 LOAD
%
RATED
40oC
INS.
CLASS
F
POWER FACTOR
F. L.
%
3/4 LOAD%1/2 LOAD
80.5
NEMA
DESIGN
B
ENCLOSURE
CATALOG#
TIME
RATING
CONT.
%
71.0
TEFC
MP0756
SERVICE
FACTOR
1.15
MAXIMUM
POWER FACTOR
CORRECTION
KVAR23.8
NO LOAD FULL LOAD
AT
230
VOLT
59.8
FULL LOAD
lb-ft
LOCKED
ROTOR
%FLT
AT
460
VOLT
29.9
PULL
UP
%FLT
450.9 220 190 280
SAFE STALL
TIME IN
SECONDS
COLD HOT
15 11
ALLOWABLE
STARTS
PER HOUR
COLD HOT
2 1
AT
230
VOLT
172.8
BREAK
DOWN
%FLT
CURRENTS
ROTOR
2
WR
2
lb-ft
SOUND
PRESSURE
LEVEL @ 3 FT
dB(A)
78
AT
460
VOLT
86.4
NEMA
LOAD
WK
lb-ft
1814.0
LOCKED ROTOR
AT
230
VOLT
1360
MAX
2
2
ALLOWABLE
WK
lb-ft
2
2
3628.1
460
VOLT
680
NEMA
LOAD
WK
Sec
6.87.600
AT
ACCEL TIMEINERTIATORQUE
2
NEMA
KVA
CODE
LETTER
J
MAX
ALLOWABLE
WK
Sec
2
13.5
APPROVED:
K. Lo
DRAWING NO.
31057MP0756
REVISION
0
