IGBT
MGD623N July, 2009
■Features
• High Speed tf=200ns typ.
• Low V
F FRD Included VF=1.2V typ.
■Package----TO-3P
■Applications
• Current Resonance Inverter Switching
• Induction Heating Cooking
■Equivalent circuit
Absolute maximum ratings
(Ta=25°C)
G (1)
Characteristic Symbol Rating Unit
C (2)
E (3)
Collector to Emitter Voltage VCES 600 V
Gate to Emitter Voltage VGES ±30 V
Continuous Collector Current IC 50 A
Pulsed Collector Current IC(pulse)1) 100 A
Diode Continuous Forward Current IF 30 A
Diode pulsed Forward Current IF(pulse) 1) 60 A
Maximum Power Dissipation PC 150 (Tc=25°C) W
Thermal Resistance IGBT θj-c IGBT 0.833 °C /W
Thermal Resistance Di θj-c Di 1.67 °C /W
Junction Temperature Tj 150 °C
Storage Temperature Tstg -55 to 150 °C
1) PW≤1ms, Duty cycle≤1%
Sanken Electric Co.,Ltd.
http://www.sanken-ele.co.jp/en/
T04-002EA-090721
Page 2
IGBT
MGD623N July, 2009
Electrical characteristics
●IGBT (Ta=25°C)
Characteristic Symbol Test Conditions
MIN. TYP. MAX.
Limits
Unit
Collector to Emitter Breakdown Voltage
Gate to Emitter Leakage Current
Collector to Emitter Leakage Current
Gate Threshold Voltage
Collector to Emitter Saturation Voltage
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Turn-On Delay Time
Rise Time
Turn-Off Delay Time
V(BR)CES IC=100μA, VGE=0V 600 V
IGES VGE=± 3 0V ±500 nA
I
CES VCE=600V, VGE=0V 100 μA
VGE(th) VCE=10V, IC=1mA 3 6 V
VCE(sat) VGE=15V, IC=50A 1.7 2.3 V
Cies 2500
Coes 150
Cres
td(on)
tr
td(off)
V
DS=20V
GS=0V
V
f=1MHz
Inductive Load
I
C=50A
CC=300V
V
VGS=15V,Rg=39Ω
pF
80
75
100
ns
300
Fall Time
tf
See Fig.1
200
●Di (Ta=25°C)
Characteristic Symbol Test Conditions
Forward Voltage
Reverse Recovery Time
VF IF=30A 1.2 1.6 V
trr
IF=30A di/dt=100A/μs
MIN. TYP. MAX.
Limits
0.3 μs
Sanken Electric Co.,Ltd.
http://www.sanken-ele.co.jp/en/
T04-002EA-090721
Unit
Page 3
IGBT
MGD623N July, 2009
Characteristic Curves
100
80
60
IC (A)
40
IC - VCE  (typical)
15V
10VVGE=20V
Tc=25℃
8V
7V
IC - VCE (typical)
100
80
60
IC (A)
40
15V
=
Tc=125℃
8V
7V
20
0
0123 45
VCE (V)
20
0
0123 45
VCE (V)
6V
VCE(sat) - Tc (typical)
4
VGE=1 5V
100
IC - VGE (typical)
VCE=5V
3
2
VCE(sat) (V)
1
IC=100A
50A
30A
0
-50 0 50 100 150
Tc (℃)
80
60
IC (A)
40
20
0
0 5 10 15
Tc=125℃
-55℃
VGE (V)
25℃
VCE (V)
VCE - VGE (typical)
5
4
3
2
1
0
110100
VGE (V)
Tc=25℃
IC=100A
50A 30A
VCE - VGE (typical)
Tc=125℃
5
4
3
VCE (V)
2
1
0
110100
VGE (V)
IC=100A
50 A 30 A
Sanken Electric Co.,Ltd.
http://www.sanken-ele.co.jp/en/
T04-002EA-090721
Page 4
IGBT
f
t
tf
t
MGD623N July, 2009
Characteristic Curves
Capacitance - VCE (typical)
10000
1000
Tc=25℃ f=1MHz VGE=0V
Cies
VCE,VGE - Qg (typic al)
40
VCE
30
100
Coe s
20
Capacitance (pF)
10
Cres
VCE (×10V) , VGE (V)
10
1
0 1020304050
VCE (V)
0
0 20406080
Qg (nC)
SW Time - IC (typical)
1000
td(off)
SW Time - IC (typical)
Tc = 25℃
1000
d(off)
100
SW Time (ns)
t
td(on)
100
SW Time (ns)
d(on )
10
110100
tr
Inductive Load VCE=300V VG=15V Rg= 39Ω
IC (A)
tr
10
110100
Inductive Load VCE=300V VG=15V Rg=39 Ω
IC (A)
1000
SW Time - RG (typical)
Tc = 25℃
1000
td(off)
SW Time - RG (typical)
tf
Tc=25℃
RL=6Ω
VGE
Tc = 125 ℃
Tc =125℃
tf
100
tr
SW Time (ns)
td(on)
10
110100
Inductive Load IC=50A VCE=300V VG=15V
RG (Ω)
td(off)
tr
100
SW Time (ns)
td(on)
Inductive Load IC=50A VCE=300V VG=15V
10
110100
RG (Ω)
Sanken Electric Co.,Ltd.
http://www.sanken-ele.co.jp/en/
T04-002EA-090721
Page 5
IGBT
MGD623N July, 2009
Characteristic Curves
100
80
IF - VF (typical)
1000
100
60
IF (A)
40
25℃
20
25℃
Tc= 125℃
10
IC (A)
1
0
0123
VF (V)
0.1
SAFE OPERATING AREA
10μs
100μs
IGBT Tc=25℃ 1shot
1 10 100 1000
VCE (V)
1000
Reverse Bias ASO
100
IC (A)
10
IGBT VGE= 15 V Rg= 39Ω 1sh ot Tc=125℃
1
1 10 100 1000
VCE (V)
1.E+02
1.E+01
1.E+00
1.E-01
Rth j-c (℃/W)
1.E-02
1.E-03
1.E-05 1.E-04 1.E-03 1.E-02 1.E-01 1.E+00 1.E+01 1.E+02
TRANSIENT THERMAL RESISTANCE - PULSE WIDTH
PT (sec.)
Di
IGBT
Tc = 25 ℃
1素子 1shot
Sanken Electric Co.,Ltd.
http://www.sanken-ele.co.jp/en/
T04-002EA-090721
Page 6
IGBT
MGD623N July, 2009
Fig.1 Switching Time Test Method
V I V R
VGE
0V
VCC
IC
RG
(a) Test Circuit
(b) Waveforms
L
VCE
CC=300V
C=50A
GE=15V
G=39Ω
Sanken Electric Co.,Ltd.
http://www.sanken-ele.co.jp/en/
T04-002EA-090721
Page 7
IGBT
MGD623N July, 2009
Outline
TO-3P
±0.2
5.0
3.2
φ±0.1
a)
MGD623N
b)
b) c)
1.0
+0.2
-0.1
2
※※
±0.1
5.45
(1) (2) (3)
+0.2
-0.1
15.6
14.0
13.6
9.6
±0.3
±0.3
±0.2
±0.2
±0.3
±0.2
±0.2
1.8
2.0
6.0
2 °2 °
±0.3
19.9
5.0
2.1
MAX
MAX
φ±0.1
3.2
※
0.6
1.7
+0.2
-0.1
+0.2
-0.3
3.5
±0.2
15.8
MIN
20.0
+0.2
-0.1
3
2
+0.2
-0.1
5.45
±0.1
Weight Approx. 6g
(1) Gate
(2) Collector
(3) Emitter
Sanken Electric Co.,Ltd.
http://www.sanken-ele.co.jp/en/
T04-002EA-090721
Page 8
IGBT
MGD623N July, 2009
