SEMICONDUCTOR TECHNICAL DATA

 

 

The MC100SX1230 device consists of a Binary to CMI Coder and CMI
to Binary Decoder with integrated loop back capability. The device is
designed for CMI (Code Mark Inversion) interfaces in transmission
applications supporting either 139.26 Mbit/s E4 or 155.52 Mbit/s STM1
line rates.

Order this document

from Logic Marketing



• Binary-to-CMI Coder and CMI-to-Binary Decoder

• Internal Loop Back Test Capability

• Supports SDH or PDH Applications

• Low Power

• Fully Differential 100K Compatible I/O

• V

Reference Available

BB

• 75kΩ Input Pulldown Resistors

• +5V PECL or –5V ECL Operation

• 28-Pin Surface Mount PLCC Package

• Asynchronous Reset

In normal operation, the coder and decoder operate independently.
Both the coder and decoder operate from a 2X line rate clock. The device
incorporates test circuitry to support loop back bypass so either the coder
input can be routed to the decoder output or the decoder input can be
routed to the coder output. The part is fabricated using Motorola’s proven
MOSAIC III advanced bipolar process.

The device provides a VBB output for accepting single-ended inputs.
The VBB pin should only be used as a bias for the
current sink/source capability is limited. Whenever used, the VBB pin
should be bypassed to ground via a 0.01µF capacitor.

CCLK

QCMI

QCMI

22

QBIN

21

LCMI

LBIN

V

EE

V

EE

CCLK

26

27

28

1

out

out

24

25

23

Pinout: 28-Lead PLCC

(Top View)

DCLK

DCLK

2

in

3

in

V

4

BB

5

7

6

8

MC100SX1230 as its

QBIN

DCLK

out

19

20

18

17

16

15

14

13

12

11109

DCLK

V

CC

V

CC

V

CCO

V

CCO

N/C

N/C

out

CMI CODER/DECODER

FN SUFFIX

PLASTIC PLCC PACKAGE

CASE 776-02

PIN NAMES

Pins

CMIin, CMI
DCLKin, DCLK
QBIN, QBIN
DCLK

BINin, BIN
CCLKin, CCLK
QCMI, QCMI
CCLK

RESET
LBIN

LCMI

out

out

in

, DCLK

in

, CCLK

Function

CMI Input to Decoder
Decoder Clock Input

in

Binary Output From Decoder
Decoder Clock Output

out

Binary Input to Coder
Coder Clock Input

in

CMI Output from Coder
Coder Clock Output

out

Asynchronous Reset
Control Input for Binary
Loop Back
Control Input for CMI
Loop Back

RESET

MOSAIC III is a trademark of Motorola, Inc.

This document contains information on a new product. Specifications and information herein are subject to
change without notice.

4/94

CMI

CMI

in

in

BIN

BIN

in

in

CCLK

in

CCLK

in

 Motorola, Inc. 1994

REV 0

MC100SX1230

CMI
CMI

DCLK
DCLK

LBIN

RESET

LCMI

BIN
BIN

BLOCK DIAGRAM

in
in

in
in

in
in

DECODER

÷

2

÷

2

H

D

C

R

R

D

C

R

CODER

QBIN
QBIN

DCLK
DCLK

CMI
CMI

out
out

DELAY

CCLK
CCLK

in
in

÷

2

FUNCTION TABLE

RESET LBIN LCMI

H X X Reset, All Output Pairs Set to Logic Low State

L L L Independent Coder and Decoder Operation
L L H CMI Input Routed to Coder Output
L H L Binary Input and Clock Routed to Decoder Outputs

Alarm Indication Signal Output from Coder

L H H Illegal, Undefined Operation

Function

CCLK
CCLK

out
out

MOTOROLA High Performance Frequency
2

Control Products — BR1334

MC100SX1230

ABSOLUTE MAXIMUM RATINGS

1

Symbol Parameter Value Unit

V

EE

V

I

I

OUT

T

A

V

EE

Power Supply (VCC = 0V) –8 to 0 Vdc
Input Voltage (VCC = 0V) 0 to –6 Vdc
Output Current Continuous

Surge

50

100

mA

Operating Temperature Range 0 to +85 °C
Operating Range

2

–5.7 to 4.2 V

1 Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation should be restricted to the

Recommended Operating Conditions.

2 Parametric values specified at: –4.2 to 5.46V

DC CHARACTERISTICS (VCC = V

Symbol Characteristic Min Typ Max Min Typ Max Min Typ Max Unit Condition

V

OH

V

OL

V

OHA

V

OLA

V

IH

V

IL

V

BB

I

IH

I

IL

I

EE

1. 100SX circuits are designed to meet the DC specifications shown in the table after thermal equilibrium has been established. The circuit is mounted in a test socket

or mounted on a printed circuit board and transverse air greater than 500lfm is maintained.

2. All outputs are loaded with 50Ω to VCC – 2V.

Output HIGH Voltage –1025 –955 –880 –1025 –955 –880 –1025 –955 –880 mV Vin = V
Output LOW Voltage –1810 –1705 –1620 –1810 –1705 –1620 –1810 –1705 –1620 mV Vin = V
Output HIGH Voltage –1035 –1035 –1035 mV Vin = V
Output LOW Voltage –1610 –1610 –1610 mV Vin = V
Input HIGH Voltage –1165 –880 –1165 –880 –1165 –880 mV
Input LOW Voltage –1810 –1475 –1810 –1475 –1810 –1475 mV
Reference Voltage –1380 –1260 –1380 –1260 –1380 –1260 V
Input HIGH Current 200 200 200 µA
Input LOW Current 0.5 0.5 0.5 µA
Supply Current 61 122 61 122 70 141 mA

= GND; VEE = –4.2 to 5.46V)

CCO

0°C 25°C 85°C

IH(max)
IH(max)
IH(max)
IH(max)

or V
or V
or V
or V

IL(min)
IL(min)
IL(min)
IL(min)

AC CHARACTERISTICS (VCC = V

= GND; VEE = –4.2 to 5.46V)

CCO

0 to 85°C

Symbol Characteristic Min Typ Max Unit Condition Notes

F

max

t

pd

Propagation CCLKin to CCLK
Delay CCLKin to QCMI

DCLKin to DCLK

DCLKin to QBIN

CCLKin to DCLK

CCLKin to QBIN

DCLKin to QCMI

t

s

Setup Time BINin to CCLK

CMIin to DCLK

t

h

Hold Time CCLKin to BIN

DCLKin to CMI

V

PP

V

CMR

tr, t

1. 100SX circuits are designed to meet the AC specifications shown in the table after thermal equilibrium has been established. The circuit is mounted in a test socket

or mounted on a printed circuit board and transverse air greater than 500lfm is maintained.

2. The CMR range is referenced to the most positive side of the differential input signal. Normal operation is obtained if the HIGH level falls within the specified range

and the peak-to-peak voltage lies between VPPmin and 1V. The lower end of the CMR range is dependent on VEE and is equal to VEE + 3.0V.

Minimum Input Swing 250 mV
Common Mode Range –0.4 Note V
Rise/Fall Times 150 700 ps 20% – 80%

f

700 MHz
650

out

1000

550

out

1000

out

1100

800

–375

in

140

in
in

in

1550
1750
1700
1800

2700
1700

1000

120

ps

LCMI=LBIN=‘L’
LCMI=LBIN=‘L’
LCMI=LBIN=‘L’
LCMI=‘L’, LBIN=‘H’
LCMI=‘L’, LBIN=‘L’
LCMI=‘H’, LBIN=‘L’

ps

ps

Add 3 CCLKin-Cycles to Delay

Add 4 DCLKin-Cycles to Delay

Add 3 CCLKin-Cycles to Delay
Add 5 DCLKin-Cycles to Delay

Control Products — BR1334

MOTOROLAHigh Performance Frequency

3

MC100SX1230

 

CMI Code

The CMI code is a 1B2B code. Each information bit is
coded into two transmission bits. A binary 0 is coded to 01,
and a binary 1 is coded alternately to a 00 or a 1 1, thus there
is at least one transition during every bit period. A typical
data pattern is illustrated in the figure below. Because of the
coding, the data stream is not only DC balanced, but it
contains a rich clock component which aids the clock
recovery process at the receiver. A 2X clock is used by the
MC100SX1230 to ensure that the mid-bit transition of the
data 0 is ideally centered at the CMI encoded output.

00110

Binary

CMI

00110

Figure 1. CMI Code

T ypical Application

In a traditional telecommunications application, the
MC100SX1230 is resident on the line card interface which
contains circuitry to implement the line transmitter and
receiver functions. On the decoder side, a cable equalization
filter followed by a clock recovery/decision circuit are
required to compensate for the cable attenuation and
distortion, extract the 2X clock signal and re-time the CMI
data. On the coder side, a PLL is required to synthesize the
2X coder clock and a conditioning circuit is needed at the
output of the coder to generate the appropriate signal to drive
the cable.

Device Operation

The circuit contains a complete CMI coder and decoder as
well as the support circuitry necessary to perform loop back
of either the Binary input or the CMI input. The operation is
controlled by the LCMI and LBIN inputs. In addition, the
device generates an AIS (Alarm Indication Signal) from the
coder output when the binary loop back state is active
(LBIN=‘H’). The AIS signal indicates to the receiver at the

other end of the cable that ‘real’ data is not being sent. The
device contains a Reset input which should normally be reset
as part of the powering up sequence.

The coder accepts a differential data input (BINin) as well
as a differential clock (CCLKin). The clock signal must be
twice the frequency of the input data signal, i.e. a 155 MBit/s
binary signal requires a 310 MHz clock, for proper operation.
Typical input and output waveforms are shown in Figure 2.
The incoming clock signal is divided by 2 and supplied at the
coder clock output (CLK
before being driven into the input register which clocks in the
binary data. This results in a negative setup time for the
coder. The coded data is output from the coder 3 CCLK
clock cycles plus normal propagation delay after the binary
data has been supplied.

The decoder accepts a differential data input (CMIin) as
well as a differential clock (DCLKin). The clock signal is
supplied from the external clock extraction circuit and runs at
the coded rate of either 280 MHz or 310 MHz depending on
weather the application is for a PDH system or an SDH
system. The decoder has a latency of 4 clock cycles so the
decoded data is output 4 cycles plus the normal propagation
delay after the input data is captured. Figure 3 illustrates the
decoder operation.

Under certain conditions, the user may require that the
binary data to be coded be routed back to the output of the
decoder to verify proper system operation. This is accom­plished through the use of the LBIN input control pin. When
this signal is asserted (LBIN = ‘H’), the BINin signal as well
as a divided by 2 version of the CCLKin input is routed to the
QBIN and DCLK
output has a latency of 3 CCLKin cycles plus internal
propagation delays. In addition, the AIS signal is generated
and output from the QCMI output. To the receiver the AIS
signal is decoded as a constant logic ‘H’ signal. This
operation is seen in Figure 4.

To complement the binary loop back feature, a CMI loop
back function is also supported. This is accomplished by
asserting the LCMI input control pin (LCMI =‘H’). Under this
condition, the CMI coded input is decoded, then routed
through the coder block to the QCMI output. The CMIin to
QCMI output has a latency of 5 DCLKin cycles plus internal
propagation delays. Figure 5 show s t he CM I l oop ba ck
operation.

outputs respectively . The BINin to QBIN

out

). The BINin signal is buffered

out

in

MOTOROLA High Performance Frequency
4

Control Products — BR1334

BIN

CCLK

QCMI

CCLK

MC100SX1230

in

in

out

SCALE:5ns/division (horizontal)

800mV/division (vertical)

Figure 2. Coder Operation for 155Mbit/s Output Data

CMI

DCLK

QBIN

DCLK

in

in

out

SCALE:5ns/division (horizontal)

800mV/division (vertical)

Figure 3. Decoder Operation for 155Mbit Output Data

Control Products — BR1334

MOTOROLAHigh Performance Frequency

5

MC100SX1230

BIN

in

CCLK

in

QCMI

QBIN

SCALE:5ns/division (horizontal)

800mV/division (vertical)

Figure 4. LBIN Active, Alarm Indication Signal Generated on QCMI Output

CMI

DCLK

QBIN

QCMI

in

in

SCALE:5ns/division (horizontal)

800mV/division (vertical)

Figure 5. LCMI Active

MOTOROLA High Performance Frequency
6

Control Products — BR1334

-L-

28 1

Z

-N-

MC100SX1230

OUTLINE DIMENSIONS

FN SUFFIX

PLASTIC PLCC PACKAGE

CASE 776-02

ISSUE D

SNSM

G1

–M

–M

0.010 (0.250) T L

H

0.007 (0.180) T L

SNSM

SNSS

–M

SNSM

–M

0.007 (0.180) T L

Y BRK

B

0.007 (0.180) T L

U

D

Z

-M-

D

W

V

0.007 (0.180) T L

A

R

0.007 (0.180) T L

–M

–M

X

VIEW D-D

SNSM

SNSM

C

G

G1

0.010 (0.250) T L

E

0.004 (0.100)

J

PLANE

SEATING

-T-

VIEW S

SNSS

–M

NOTES:

1. DATUMS -L-, -M-, AND -N- DETERMINED
WHERE TOP OF LEAD SHOULDER EXITS
PLASTIC BODY AT MOLD PARTING LINE.

2. DIM G1, TRUE POSITION TO BE MEASURED
AT DATUM -T-, SEATING PLANE.

3. DIM R AND U DO NOT INCLUDE MOLD FLASH.
ALLOWABLE MOLD FLASH IS 0.010 (0.250)
PER SIDE.

4. DIMENSIONING AND TOLERANCING PER ANSI
Y14.5M, 1982.

5. CONTROLLING DIMENSION: INCH.

6. THE PACKAGE TOP MAY BE SMALLER THAN
THE PACKAGE BOTTOM BY UP TO 0.012
(0.300). DIMENSIONS R AND U ARE
DETERMINED AT THE OUTERMOST
EXTREMES OF THE PLASTIC BODY
EXCLUSIVE OF MOLD FLASH, TIE BAR
BURRS, GATE BURRS AND INTERLEAD
FLASH, BUT INCLUDING ANY MISMATCH
BETWEEN THE TOP AND BOTTOM OF THE
PLASTIC BODY.

7. DIMENSION H DOES NOT INCLUDE DAMBAR
PROTRUSION OR INTRUSION. THE DAMBAR
PROTRUSION(S) SHALL NOT CAUSE THE H
DIMENSION TO BE GREATER THAN 0.037
(0.940). THE DAMBAR INTRUSION(S) SHALL
NOT CAUSE THE H DIMENSION TO BE
SMALLER THAN 0.025 (0.635).

K

VIEW S

INCHES MILLIMETERS

MIN MINMAX MAX

DIM

A

0.485

0.485

0.165

0.090

0.013

0.050 BSC

0.026

0.020

0.025

0.450

0.450

0.042

0.042

0.042
—

°

2

0.410

0.040

0.495

0.495

0.180

0.110

0.019

0.032
—
—

0.456

0.456

0.048

0.048

0.056

0.020

10

0.430

—

°

G1
K1

B
C
E
F
G
H
J
K
R
U
V
W
X
Y
Z

K1

SNSM

0.007 (0.180) T L

F

12.32

12.57

12.32

12.57

4.20

4.57

2.29

2.79

0.33

0.48

1.27 BSC

0.66

0.81

0.51

—

0.64

—

11.43

11.58

11.43

11.58

1.07

1.21

1.07

1.21

1.07

1.42

—

0.50

°

°

2

1.02

10

10.92
—

10.42

–M

Control Products — BR1334

MOTOROLAHigh Performance Frequency

7

MC100SX1230

Motorola reserves the right to make changes without further notice to any products herein. Motorola makes no warranty , representation or guarantee regarding
the suitability of its products for any particular purpose, nor does Motorola assume any liability arising out of the application or use of any product or circuit,
and specifically disclaims any and all liability, including without limitation consequential or incidental damages. “Typical” parameters can and do vary in different
applications. All operating parameters, including “T ypicals” must be validated for each customer application by customer’s technical experts. Motorola does
not convey any license under its patent rights nor the rights of others. Motorola products are not designed, intended, or authorized for use as components in
systems intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of
the Motorola product could create a situation where personal injury or death may occur. Should Buyer purchase or use Motorola products for any such
unintended or unauthorized application, Buyer shall indemnify and hold Motorola and its officers, employees, subsidiaries, affiliates, and distributors harmless
against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death
associated with such unintended or unauthorized use, even if such claim alleges that Motorola was negligent regarding the design or manufacture of the part.
Motorola and are registered trademarks of Motorola, Inc. Motorola, Inc. is an Equal Opportunity/Affirmative Action Employer.

Literature Distribution Centers:

USA: Motorola Literature Distribution; P.O. Box 20912; Phoenix, Arizona 85036.
EUROPE: Motorola Ltd.; European Literature Centre; 88 T anners Drive, Blakelands, Milton Keynes, MK14 5BP, England.
JAPAN: Nippon Motorola Ltd.; 4-32-1, Nishi-Gotanda, Shinagawa-ku, Tokyo 141 Japan.
ASIA-PACIFIC: Motorola Semiconductors H.K. Ltd.; Silicon Harbour Center, No. 2 Dai King Street, Tai Po Industrial Estate, Tai Po, N.T., Hong Kong.

CODELINE TO BE PLACED HERE

MOTOROLA High Performance Frequency
8

◊

*MC100SX1230/D*

Control Products — BR1334

MC100SX1230/D
