Bulletin PD-20586 rev. C 03/03
MBRS360TR
SCHOTTKY RECTIFIER
Major Ratings and Characteristics
Characteristics MBRS360TR Units
I
Rectangular 3.0 A
F(AV)
waveform
V
RRM
I
@ t p= 5 µs sine 790 A
FSM
VF@ 3.0 Apk, TJ = 125°C 0.61 V
TJrange - 55 to 150 °C
Device Marking: IR36
60 V
3 Amp
SMC
Description/Features
The MBRS360TR surface-mount Schottky rectifier has been
designed for applications requiring low forward drop and small
foot prints on PC boards. Typical applications are in disk
drives, switching power supplies, converters, free-wheeling
diodes, battery charging, and reverse battery protection.
Small foot print, surface mountable
Very low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
www.irf.com
2.75 (.108)
3.15 (.124)
6.60 (.260)
7.11 (.280)
2.00 (.079)
2.62 (.103)
0.76 (.030)
1.52 (.060)
For recommended footprint and soldering techniques refer to Application Note # AN-994
7.75 (.305)
8.13 (.320)
Outline SMC
Dimensions in millimeters and (inches)
5.59 (.220)
6.22 (.245)
.152 (.006)
.305 (.012)
.102 (.004)
.203 (.008)
CATHODE ANODE
1 2
POLARITY PART NUMBER
1
2
1
Page 2
MBRS360TR
Bulletin PD-20586 rev. C 03/03
Voltage Ratings
Part number MBRS360TR
VRMax. DC Reverse Voltage (V) 60
V
Max. Working Peak Reverse Voltage (V)
RWM
Absolute Maximum Ratings
Parameters Value Units Conditions
I
Max. Average Forward Current 3.0 A 50% duty cycle @ TL = 118 °C, rectangular wave form
F(AV)
4.0 50% duty cycle @ TL = 105 °C, rectangular wave form
I
Max. Peak One Cycle Non-Repetitive 790 A 5µs Sine or 3µs Rect. pulse
FSM
Surge Current 80 10ms Sine or 6ms Rect. pulse
EASNon Repetitive Avalanche Energy 5.0 mJ TJ = 25 °C, IAS = 1.0A, L = 10mH
IARRepetitive Avalanche Current 1.0 A Current decaying linearly to zero in 1 µsec
Frequency limited by TJ max. Va = 1.5 x Vr typical
Following any rated
load condition and
with rated V
RRM
applied
Electrical Specifications
Parameters Typ Max Units Conditions
VFMMax. Forward Voltage Drop (1) 0.57 0.74 V @ 3A
0.72 0.9 V @ 6A
0.51 0.61 V @ 3A
0.62 0.77 V @ 6A
IRMMax. Reverse Leakage (1) - 0.5 mA TJ = 25 °C
Current - 20 mA TJ = 100°C
-30mAT
= 125 °C
J
CTMax. Junction Capacitance - 180 pF VR = 5VDC(test signal range 100KHz to 1Mhz) 25°C
LSTypical Series Inductance - 3.0 nH Measured lead to lead 5mm from package body
dv/dt Max. Voltage Rate of Change - 10000 V/µs (Rated VR)
(1) Pulse Width < 300µs, Duty Cycle < 2%
TJ = 25 °C
TJ = 125 °C
VR = rated V
R
Thermal-Mechanical Specifications
Parameters Value Units Conditions
TJMax. Junction Temperature Range (*) - 55 to 150 °C
T
Max. Storage Temperature Range - 55 to 150 °C
stg
R
Max. Thermal Resistance 12 °C/W DC operation
thJL
Junction to Lead (**)
R
Max. Thermal Resistance 46 °C/W DC operation
thJA
Junction to Ambient
wt Approximate Weight 0.24 (0.008) g (oz.)
Case Style SMC Similar to DO-214AB
Device Marking IR36
(*) dPtot 1
< thermal runaway condition for a diode on its own heatsink
dTj Rth( j-a)
(**) Mounted 1 inch square PCB
2 www.irf.com
Page 3
MBRS360TR
Bulletin PD-20586 rev. C 03/03
10
(A)
F
1
Instantaneous Forward Current - I
Tj = 150˚C
Tj = 100˚C
Tj = 25˚C
100
T = 150˚C
10
(mA)
R
0.1
0.01
Reverse Current - I
0.001
J
125˚C
1
100˚C
75˚C
50˚C
25˚C
0 5 10 15 20 25 30 35 40
Reverse Voltage - VR (V)
Fig. 2 - Typical Values Of Reverse Current
Vs. Reverse Voltage (Per Leg)
1000
T = 25˚C
J
(p F)
T
100
0.1
0.2 0.4 0.6 0.8 1 1.2
Fig. 1 - Max. Forward Voltage Drop Characteristics
www.irf.com
Junction Capacitance - C
10
0 10203040506070
Forward Voltage Drop - VFM (V)
Reverse Voltage - VR (V)
Fig. 3 - Typical Junction Capacitance
(Per Leg)
Vs. Reverse Voltage (Per Leg)
100
(°C/W)
thJC
Thermal Impedance Z
D = 0.50
D = 0.33
D = 0.25
D = 0.20
1
Single Pulse
(Thermal Resistance)
0.1
0.00001 0.0001 0.001 0.01 0.1 1 10 100
Notes:
1. Duty factor D = t1/ t2
2. Peak Tj = Pdm x ZthJC + Tc
P
DM
t
1
t
2
D = 0.75
10
t1 , Rectangular Pulse Duration (Seconds)
Fig. 4 - Max. Thermal Impedance Z
Characteristics (Per Leg)
thJC
3
Page 4
MBRS360TR
Bulletin PD-20586 rev. C 03/03
160
150
140
DC
130
120
110
100
Square wave (D = 0.50)
90
Rated Vr applied
80
70
Allowable Lead Temperature (°C)
see note (2)
60
012345
Average Forward Current - I
Fig. 4 - Maximum Average Forward Current
Vs. Allowable Lead Temperature
1000
(A)
FSM
100
D=0.20
D=0.25
D=0.33
D=0.50
D=0.75
F(AV)
(A)
3
2.5
2
RMS Limit
1.5
1
0.5
Average Power Loss (Watts)
0
012345
Average Forward Current - I
D = 0.20
D = 0.25
D = 0.33
D = 0.50
D = 0.75
DC
DC
F(AV)
Fig. 5 - Maximum Average Forward Dissipation
Vs. Average Forward Current
(A)
At Any Rated Load Condition
And With rated Vrrm Applied
Following Surge
Non-Repetitive Surge Current - I
10
10 100 1000 10000
Square Wave Pulse Duration - T
(Microsec)
p
Fig. 6 - Maximum Peak Surge Forward Current Vs. Pulse Duration
(2) Formula used: TC = TJ - (Pd + Pd
Pd = Forward Power Loss = I
Pd
= Inverse Power Loss = VR1 x IR (1 - D); IR @ V
REV
F(AV)
) x R
REV
x VFM @ (I
thJC
;
F(AV)
/ D) (see Fig. 6);
= 80% rated V
R1
R
4 www.irf.com
Page 5
Tape & Reel Information
MBRS360TR
Bulletin PD-20586 rev. C 03/03
330 (13)
8 (0.32)
16 (0.63)
Dimensions in millimetres and (inches)
Marking & Identification Ordering Information
Each device has 2 rows for identification. The first row
designates the device as manufactured by International
Rectifier as indicated by the letters "IR", and the Part
Number (indicates the current and the voltage rating).
The second row indicates the year, the week of
manufacturing and the Site ID.
IR36
VOLTAGE
CURRENT
MBRS360TR - TAPE AND REEL
WHEN ORDERING, INDICATE THE PART NUMBER
AND THE QUANTITY ( IN MULTIPLES OF 3000
PIECES).
EXAMPLE: MBRS360TR - 6000 PIECES
16 (0.63)
FEED DIRECTION
IR LOGO
YYWWX
www.irf.com
SITE ID
WEEK
YEAR
5
Page 6
MBRS360TR
Bulletin PD-20586 rev. C 03/03
This product has been designed and qualified for Industrial Level.
IR WORLD HEADQUARTERS: 233 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105
Data and specifications subject to change without notice.
Qualification Standards can be found on IR's Web site.
Visit us at www.irf.com for sales contact information. 03/03
TAC Fax: (310) 252-7309
