Philips Semiconductors Advanced BiCMOS Products Product specification

MB2861Data 10-bit bus transceiver (3-State)

1

August 27, 1993 853-1715 10661

DESCRIPTION

The MB2861 bus transceiver provides high
performance bus interface buffering for wide
data/address paths of buses carrying parity.

The MB2861 10-bit bus transceiver has
NOR-ed transmit and receive output enables
for maximum control flexibility.

FEATURES

•Provides high performance bus interface

buffering for wide data/address paths or
buses carrying parity

•Buffered control inputs for light loading, or

increased fan-in as required with MOS
microprocessors

•Output capability: +64mA/-32mA

•Power-up 3-State

•Live insertion/extraction permitted

•Latch-up protection exceeds 500mA per

Jedec JC40.2 Std 17

•ESD protection exceeds 2000 V per MIL

STD 883 Method 3015 and 200 V per
Machine Model

QUICK REFERENCE DATA

SYMBOL PARAMETER

CONDITIONS

T

amb

= 25°C; GND = 0V

TYPICAL UNIT

t

PLH

t

PHL

Propagation delay
nAx to nBx or nBx to nAx

CL = 50pF; VCC = 5V 3.4 ns

C

IN

Input capacitance VI = 0V or V

CC

4 pF

C

I/O

I/O capacitance VO = 0V or VCC; 3-State 7 pF

I

CCZ

Total supply current Outputs disabled; VCC =5.5V 500 nA

ORDERING INFORMATION

PACKAGES TEMPERATURE RANGE ORDER CODE DRAWING NUMBER

52-Pin Plastic Quad Flat Pack –40°C to +85°C MB2861BB 1418B

PIN CONFIGURATION

LOGIC SYMBOL

Vcc

1B3

1B2

1B1

1B0

1OEAB

1OEBA

1A0

1A1

GND

1A2

1A3

Vcc

Vcc

2B6

2B7

GND

2B8

2B9

2OEAB

2OEBA

2A9

2A8

2A7

2A6

Vcc

19 2220 231716 25 26241514 2118

1B8

2B1

1B9

2B2

GND

1B6

2B4
2B5

2B3

1B5

2B0

1B7

1B4

1
2
3
4
5
6
7

8

9
10
11
12

13

47 4446 434950 41 40425152 4548

1A9

2A2

2A0

GND

1A7

1A6

2A4
2A5

2A3

1A5

2A1

1A8

1A439
38
37
36
35
34
33
32

31
30
29
28

27

MB2861

52-Pin Plastic

Quad Flat Pack

45 44 42 41 39 38 37 36 35 34

46471OEBA

1OEAB

1A0 1A1 1A2 1A3 1A4 1A5 1A6 1A7 1A8 1A9

1B0 1B1 1B2 1B3 1B4 1B5 1B6 1B7 1B8 1B9

48 49 50 51 1 2 3 5 6 7

33 32 31 29 28 27 25 24 23 22

21202OEBA

2OEAB

2A0 2A1 2A2 2A3 2A4 2A5 2A6 2A7 2A8 2A9

2B0 2B1 2B2 2B3 2B4 2B5 2B6 2B7 2B8 2B9

8 9 10 11 12 13 15 16 18 19

Philips Semiconductors Advanced BiCMOS Products Product specification

MB2861Data 10-bit bus transceiver (3-State)

August 27, 1993

2

PIN DESCRIPTION

PIN NUMBER SYMBOL FUNCTION

47, 20

1OEAB,

2OEAB

A side to B side output enable inputs (active-Low)

45, 44, 42, 41, 39,

38, 37, 36, 35, 34

33, 32, 31, 29, 28,

27, 25, 24, 23, 22

1A0-1A9,
2A02nA9

Data inputs/outputs (A side)

48, 49, 50, 51, 1,

2, 3, 5, 6, 7

8, 9, 10, 11, 12,

13, 15, 16, 18, 19

1B0-1B9,
2B02nB9

Data outputs/outputs (B side)

46, 21

1OEBA,

2OEBA

B side to A side output enable inputs (active-Low)

4, 17, 30, 43 GND Ground (0V)

14, 26, 40, 52 V

CC

Positive supply voltage

LOGIC SYMBOL (IEEE/IEC)

1

45 48

44 49
42 50
41 51
39 1
38 2
37 3
36 5

47

46

35 6
34 7

EN1(BA)
EN2(AB)

2

1

33 8

32 9
31 10
29 11
28 12
27 13
25 15
24 16

20

21

23 18
22 19

EN1(BA)
EN2(AB)

2

FUNCTION TABLE LOGIC DIAGRAM

INPUTS OPERATING

nOEAB nOEBA MODE

L H A data to B bus
H L B data to A bus
H H Z

H = High voltage level
L = Low voltage level
X = Don’t care
Z = High impedance “off” state

nAx nBx

1010

nOEAB

nOEBA

Philips Semiconductors Advanced BiCMOS Products Product specification

MB2861Data 10-bit bus transceiver (3-State)

August 27, 1993

3

ABSOLUTE MAXIMUM RATINGS

1, 2

SYMBOL

PARAMETER CONDITIONS RATING UNIT

V

CC

DC supply voltage –0.5 to +7.0 V

I

IK

DC input diode current VI < 0 –18 mA

V

I

DC input voltage

3

–1.2 to +7.0 V

I

OK

DC output diode current VO < 0 –50 mA

V

OUT

DC output voltage

3

output in Off or High state –0.5 to +5.5 V

I

OUT

DC output current output in Low state 128 mA

T

stg

Storage temperature range –65 to 150 °C

NOTES:

1. Stresses beyond those listed may cause permanent damage to the device. These are stress ratings only and functional operation of the
device at these or any other conditions beyond those indicated under “recommended operating conditions” is not implied. Exposure to
absolute-maximum-rated conditions for extended periods may affect device reliability.

2. The performance capability of a high-performance integrated circuit in conjunction with its thermal environment can create junction
temperatures which are detrimental to reliability. The maximum junction temperature of this integrated circuit should not exceed 150°C.

3. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.

RECOMMENDED OPERATING CONDITIONS

SYMBOL PARAMETER LIMITS UNIT

Min Max

V

CC

DC supply voltage 4.5 5.5 V

V

I

Input voltage 0 V

CC

V

V

IH

High-level input voltage 2.0 V

V

IL

Low-level Input voltage 0.8 V

I

OH

High-level output current –32 mA

I

OL

Low-level output current 64 mA

∆t/∆v Input transition rise or fall rate 0 10 ns/V

T

amb

Operating free-air temperature range –40 +85 °C

Philips Semiconductors Advanced BiCMOS Products Product specification

MB2861Data 10-bit bus transceiver (3-State)

August 27, 1993

4

DC ELECTRICAL CHARACTERISTICS

LIMITS

SYMBOL PARAMETER TEST CONDITIONS T

amb

= +25°C

T

amb

= –40°C

to +85°C

UNIT

Min Typ Max Min Max

V

IK

Input clamp voltage VCC = 4.5V; IIK = –18mA –0.9 –1.2 –1.2 V

VCC = 4.5V; IOH = –3mA; VI = VIL or V

IH

2.5 2.9 2.5 V

V

OH

High-level output voltage VCC = 5.0V; IOH = –3mA; VI = VIL or V

IH

3.0 3.4 3.0 V

VCC = 4.5V; IOH = –32mA; VI = VIL or V

IH

2.0 2.4 2.0 V

V

OL

Low-level output voltage VCC = 4.5V; IOL = 64mA; VI = VIL or V

IH

0.42 0.55 0.55 V

I

I

Input leakage Control pins VCC = 5.5V; VI = GND or 5.5V ±0.01 ±1.0 ±1.0 µA
current Data pins VCC = 5.5V; VI = GND or 5.5V ±5 ±100 ±100 µA

I

OFF

Power-off leakage current VCC = 0.0V; VO or VI ≤ 4.5V ±5.0 ±100 ±100 µA

I

PD/PD

Power-up/down
3-State output current

3

VCC = 2.1V; VO = 0.5V; VI = GND or VCC;
V

OE = Don’t care

±5.0 ±50 ±50 µA

I

IH

+ I

OZH

3-State output High current VCC = 5.5V; VO = 2.7V; VI = VIL or V

IH

5.0 50 50 µA

I

IL

+ I

OZL

3-State output Low current VCC = 5.5V; VO = 0.5V; VI = VIL or V

IH

–5.0 –50 –50 µA

I

CEX

Output High leakage current VCC = 5.5V; VO = 5.5V; VI = GND or V

CC

5.0 50 50 µA

I

O

Output current

1

VCC = 5.5V; VO = 2.5V –50 –80 –180 –50 –180 mA

I

CCH

VCC = 5.5V; Outputs High, VI = GND or V

CC

65 250 250 µA

I

CCL

Quiescent supply current VCC = 5.5V; Outputs Low, VI = GND or V

CC

45 72 72 mA

I

CCZ

VCC = 5.5V; Outputs 3-State; VI = GND or V

CC

65 250 250 µA

∆I

CC

Additional supply current per
input pin

2

VCC = 5.5V; one input at 3.4V,
other inputs at VCC or GND

0.5 1.5 1.5 mA

NOTES:

1. Not more than one output should be tested at a time, and the duration of the test should not exceed one second.

2. This is the increase in supply current for each input at 3.4V.

3. This parameter is valid for any V

CC

between 0V and 2.1V with a transition time of up to 10msec. From VCC = 2.1 to VCC = 5V ± 10% a

transition time of up to 100µsec is permitted.

AC CHARACTERISTICS

GND = 0V, tR = tF = 2.5ns, CL = 50pF, RL = 500Ω

LIMITS

SYMBOL PARAMETER WAVEFORM

T

amb

= +25oC

V

CC

= +5.0V

T

amb

= -40 to

+85

o

C

VCC = +5.0V ±0.5V

UNIT

Min Typ Max Min Max

t

PLH

t

PHL

Propagation delay
nAx to nBx or nBx to nAx

1

1.4

1.5

2.9

2.9

4.1

4.1

1.4

1.5

4.6

4.6

ns

t

PZH

t

PZL

Output enable time
to High and Low level

2

1.5

2.0

3.0

3.6

3.9

4.8

1.5

2.0

4.6

5.3

ns

t

PHZ

t

PLZ

Output disable time
from High and Low level

2

1.2

1.7

3.6

3.1

4.8

4.3

1.2

1.7

5.3

4.8

ns

Philips Semiconductors Advanced BiCMOS Products Product specification

MB2861Data 10-bit bus transceiver (3-State)

August 27, 1993

5

AC WAVEFORMS

VM = 1.5V, VIN = GND to 3.0V

nOEXX INPUT

V

M

V

M

t

PZH

t

PHZ

OUTPUT

V

OH

V

M

V

M

OUTPUT

V

OL

t

PZL

t

PLZ

3.5V

0V

V

OL

+ 0.3V

V

OH

– 0.3V

INPUT

V

M

V

M

OUTPUT

V

M

V

M

t

PLH

t

PHL

Waveform 1. Input to Output Propagation Delays Waveform 2. 3-State Output Enable and Disable Times

TEST CIRCUIT AND WAVEFORM

PULSE

GENERATOR

R

T

V

IN

D.U.T

V

OUT

C

L

R

L

V

CC

R

L

7.0V

Test Circuit for 3-State Outputs

V

M

V

M

t

W

AMP (V)

NEGATIVE
PULSE

10% 10%

90%

90%

0V

V

M

V

M

t

W

AMP (V)

POSITIVE
PULSE

90% 90%

10%

10%

0V

t

THL

(tF)

t

TLH

(tR) t

THL

(tF)

t

TLH

(tR)

VM = 1.5V

Input Pulse Definition

DEFINITIONS

RL = Load resistor; see AC CHARACTERISTICS for value.
CL = Load capacitance includes jig and probe capacitance;

see AC CHARACTERISTICS for value.

R

T

= Termination resistance should be equal to Z

OUT

of pulse generators.

INPUT PULSE REQUIREMENTS

FAMILY

Amplitude Rep. Rate t

W

t

R

t

F

MB 3.0V 1MHz 500ns 2.5ns 2.5ns

SWITCH POSITION

TEST SWITCH

t

PLZ

closed

t

PZL

closed

All other open
