Datasheet Maxcap [screw-terminal] LSS Series Datasheet

LSS ㋏߫

㋏߫

೒ᔶሎᇌ

㒍⊶⬉⌕㸹ٓ㋏᭄

䢕 䳏 㾷 䳏 ᆍ ఼

㶎󰶈ᔶ᥹㒓ッᄤ. Screw Type.

••催ৃ䴴ᗻ, 催㒍⊶⬉⌕.

High Riliability, High Ripple Current.

• 85°C, 㗤Йᗻ 3,000 ᇣᯊ.

85°C, Load Life: 3,000 Hours.

䢕䳏㾷䳏ᆍ఼

Aluminum Electrolytic Capacitor

Ⳃ Item

乍
乱ᅮᎹ԰⬉ Rated Voltage Range 10 ~ 450 VDC
Ꮉ԰⏽ᑺ㣗ೈ Temperature Range
ᆍ䞣ܕ䆌䇃Ꮒ Capacitance Tolerance ± 20% (M) (೼ 20°C, 120 Hz)

᳔໻⊘ⓣ⬉⌕ Leakage Current

᳔໻ᤳ༅㾦ℷߛ Dissipation Factor
(tan¥) (೼ 20°C, 120 Hz)

㗤Йᗻ Load Life

ټᄬᗻ Shelf Life

݊ᅗ Others ⒵䎇 JIS C5141 П W 乍㾘ᅮ. Satisfies characteristic W of JIS C5141.

೒ᔶሎᇌ

Figure and Dimensions

-40 ~ +85°C (10 ~ 250V) -25 ~ +85°C (350 ~ 450V)

5 ߚ䩳ৢ, 3 CV (µA) ៪ 5mA, প䕗ᇣؐ. (C: 󰵼ޚ⬉ᆍ䞣, V: 乱ᅮ⬉) (೼ 20ć)

After 5 minutes, 3 CV (µA) or 5mA, whichever is smaller.

V

ØD

35 0.75 0.60 0.40 0.30 0.25 0.20 0.20 0.15 0.15 0.20
51 1.00 0.70 0.50 0.50 0.30 0.25 0.20 0.20 0.15 0.20

63.5 1.30 0.80 0.70 0.60 0.50 0.30 0.25 0.25 0.20 0.25
76 1.50 1.00 0.80 0.70 0.60 0.40 0.30 0.25 0.20 0.25
89 1.50 1.00 0.80 0.70 0.60 0.40 0.30 0.25 0.20 0.25

⬉ᆍ఼೼ 85°C ⦃๗Ёᮑࡴ乱ᅮ⬉䖲㓁 3,000 ᇣ
ᯊৢ, ދ㟇 20°C ⌟䞣,⡍ᗻᑨ⒵䎇:

The following specifications shall be satisfied when
the capacitors are restored to 20°C after the rated

voltage is applied for 3,000 hours at 85°C

᳾ࡴ⬉ⱘ⬉ᆍ఼ᬒ㕂೼ 85°C ⦃๗Ё䖲㓁 500 ᇣᯊ, ✊ৢދ㟇 20°C ⌟䞣, ⡍ᗻᑨ⒵䎇㗤Йᗻ㾘ᅮ.
When the capacitors are restored to 20°C after exposing them at 85°C for 500 hours without voltage applied, the
specifications shall satisfy the specifications of the load life.

10 16 25 35 50 63 80 100 160~250 315~450

⡍ ᗻ Specifications

ᆍ䞣ব࣪

Capacitance Change

ᤳ༅㾦(tan¥)
D.F

⊘ⓣ⬉⌕
Leakage Current

± 150%ҹݙ

± 150% of the initial value

≤

ᇣѢ߱ྟ㾘ᅮؐⱘ 175%

≤

175% of the initial specified value

ᇣѢ߱ྟ㾘ᅮؐ

the initial specified value

≤

ԡ

Unit: mm

Ⳉᕘ: Ø35 Ⳉᕘ: Ø51, Ø63.5, Ø76, Ø89

߶ᜈ݂

౛

PLATE

D+2.0 MAX

ØD W1 W2 W3 W4 W5 P

35 24.0 29.0 3.5 6 10 12.7
51 32.5 37.0 4.5 8 14 21.8

63.5 38.0 43.5 4.5 8 14 28.2
76 44.5 50.0 4.5 8 14 31.4
89 50.8 56.5 4.5 8 16 31.4

㒍⊶⬉⌕㸹ٓ㋏᭄
⏽ᑺ㋏᭄

⦃๗⏽ᑺ(°C)

Temperature
⏽ᑺ㋏᭄

Factor

ᑚክ

CLAMP

SLEEVE

L+3 MAX

Temperature Factor

ᛂಞଋቪ

ᨷܦ

SCREW

CASE

TERMINAL

W1±1

󰪙ྏ܊

VENT

W3

Multiplying Factor of Ripple Current

85 70 60 ঞҹϟ

1.00 1.60 1.80

W5

P±1

M5

ᛂಞ

M5 BOLT

W4

W2±1

㶎󰶈㾘Ḑ

݁㾦㶎󰶈

1.

᳔໻ᡁⶽ

2.

乥⥛㋏᭄

⬉ (V)

Voltage

10 ~ 50 0.80 1.00 1.03 1.05 1.08

63 ~ 100 0.80 1.00 1.05 1.07 1.10

160 ~ 450 0.80 1.00 1.10 1.13 1.18

߶ᜈ݂

ᑚክ

CLAMP

౛

PLATE

D+2.0 MAX

SLEEVE

L+3 MAX

ᨷܦ

CASE

SCREW TERMINAL

ᛂಞଋቪ

Bolt Specificstion:

Bolt: M5x0.8x10

MAX Torqe: 33Kg.cm(3.23N.m)

Frequency Factor

乥⥛ Frequency (Hz)

60 120 400 1K 10K

W2±1

󰪙ྏ܊

VENT

W1±1

P±1

W4

W5

M5

M5 BOLT

W3

ᛂಞ

48

බᔳႂߔథᬌМՂMAXCAP Electronics Co., Ltd.

LSS ㋏߫

㋏߫

໪໇ሎᇌ᳔໻㒍⊶⬉⌕

䢕 䳏 㾷 䳏 ᆍ ఼

䢕䳏㾷䳏ᆍ఼

Aluminum Electrolytic Capacitor

໪໇ሎᇌ᳔໻㒍⊶⬉⌕

V
µF

3,300 35×50 2.5
3,900 35×50 2.6
4,700 35×50 2.8
5,600 35×50 3.0 35×60 2.9
6,800 35×50 3.3 35×50 3.2 35×80 3.7

8,200 35×50 3.7 35×60 3.8 35×80 4.2
10,000 35×50 3.6 35×50 4.3 35×80 4.1 35×100 5.0
12,000 35×50 3.7 35×60 5.3 35×80 4.4 35×120 5.4
15,000 35×50 4.0 35×80 5.5 35×100 5.5 51×80 7.7
18,000 35×50 5.0 35×60 4.7 35×80 5.7 35×120 6.2 51×80 7.8
22,000 35×60 5.4 35×80 5.6 35×100 6.1 51×80 7.1 51×80 8.0
27,000 35×50 5.1 35×80 5.8 35×80 6.2 35×120 6.7 51×80 7.4 51×100 8.7
33,000 35×60 5.5 35×80 6.0 35×80 6.3 51×80 7.1 51×100 8.8 51×120 10.5
39,000 35×50 5.3 35×80 7.0 35×80 6.7 35×100 7.6 51×80 7.4 51×120 10.0 63.5×100 12.1
47,000 35×60 6.0 35×80 7.3 35×100 8.0 35×120 8.7 51×100 8.7 63.5×100 11.9 63.5×100 14.4
56,000 35×80 6.3 35×100 7.6 35×120 8.4 51×80 10.0 51×100 9.8 63.5×100 12.6 63.5×120 15.0
68,000 35×80 7.9 35×100 10.3 51×80 9.3 51×80 10.8 51×120 12.0 63.5×120 15.0 63.5×140 16.8
82,000 35×80 8.4 35×120 10.5 51×80 10.0 51×100 12.0 63.5×100 12.3 76×100 16.4 76×120 19.4

100,000 35×120 9.3 51×80 10.9 51×100 12.0 51×120 13.6 63.5×120 14.2 76×120 18.9 76×140 21.5
120,000 51×80 10.0 51×100 11.1 51×120 12.9 63.5×100 13.8 63.5×120 16.0 76×140 21.6 89×140 22.3
150,000 51×80 11.0 51×100 12.6 63.5×100 15.3 63.5×100 14.6 76×120 18.6 89×140 26.0
180,000 51×100 12.1 51×120 13.2 63.5×100 15.5 63.5×120 16.7 76×140 19.5
220,000 51×100 14.0 63.5×100 14.7 63.5×120 18.0 76×100 17.4 89×140 23.3
270,000 51×120 14.2 63.5×120 15.4 76×100 18.8 76×140 23.1 89×140 24.8
330,000 63.5×100 17.3 63.5×140 18.3 76×120 23.2 76×150 25.9
390,000 63.5×120 18.0 76×120 19.0 76×140 23.5 89×140 26.5
470,000 63.5×140 19.3 76×140 22.0 89×140 24.7 89×150 28.3
560,000 76×120 20.1 76×150 23.0 89×140 26.2
680,000 76×140 24.0

10 16 25 35 50 63 80

Case Size and Rated Ripple Current

V
µF

270 35×50 1.3 35×50 1.6
330 35×50 1.7 35×60 1.8
390 35×50 1.9 35×60 1.8 35×80 2.2
470 35×50 1.6 35×60 2.1 35×80 2.3 35×80 2.4
560 35×50 1.6 35×80 2.4 35×80 2.7 35×100 2.8
680 35×50 1.6 35×50 1.7 35×80 2.9 35×100 2.9 35×120 3.1

820 35×50 1.7 35×60 1.8 35×100 3.4 35×100 3.4 51×80 3.5
1,000 35×60 2.2 35×80 2.4 35×100 3.8 35×120 3.9 51×80 4.0
1,200 35×50 2.3 35×60 2.3 35×80 2.4 35×120 4.2 51×80 4.2 51×100 4.8
1,500 35×60 3.2 35×80 2.9 35×100 3.1 51×80 4.7 51×100 4.8 51×120 5.7
1,800 35×80 3.4 35×80 2.9 35×120 3.4 51×100 6.3 51×100 5.7 63.5×100 6.5
2,200 35×50 2.5 35×80 3.6 35×100 3.6 51×80 3.9 51×100 6.4 51×120 7.0 63.5×100 7.2
2,700 35×50 2.7 35×100 3.8 35×120 4.0 51×80 4.0 63.5×100 8.8 63.5×100 7.9 63.5×120 8.7
3,300 35×50 3.2 35×120 4.7 51×80 4.6 51×100 5.4 63.5×100 8.8 63.5×120 9.5 76×120 10.5
3,900 35×60 3.3 51×80 5.3 51×80 4.7 51×120 6.6 63.5×120 10.3 76×100 10.7 76×120 12.0
4,700 35×80 3.5 51×80 5.6 51×100 7.1 63.5×100 7.3 76×100 12.0 76×120 12.8 76×140 13.3
5,600 35×80 3.8 51×100 6.4 51×120 8.3 63.5×100 7.3 76×120 12.7 76×140 14.5 89×140 15.8
6,800 35×100 4.5 51×100 7.5 63.5×100 9.5 63.5×120 8.9 76×140 16.0 76×150 17.5 89×150 18.7
8,200 35×120 6.0 51×120 8.1 63.5×100 10.0 76×100 8.9 89×140 19.0 89×140 18.0

10,000 35×120 6.3 63.5×100 9.9 63.5×120 11.1 76×120 11.8 89×140 20.0 89×150 20.5
12,000 51×80 6.6 63.5×120 1.8 76×100 11.6 76×140 13.1
15,000 51×80 8.5 76×100 12.7 76×120 12.9 89×140 16.5
18,000 51×100 8.9 76×120 14.1 76×140 15.2
22,000 51×120 10.2 76×140 16.6 89×140 15.6
27,000 63.5×100 11.0 89×140 17.7
33,000 63.5×120 11.7 89×140 18.9
39,000 76×100 12.5
47,000 76×120 14.5
56,000 76×140 16.2
68,000 76×150 18.3
82,000 89×140 20.1

100,000 89×140 21.0

100 160 200 250 350 400 450

㒍⊶⬉⌕ Ripple Current (A rms) ೼ 85°C, 120Hz
໪໇ሎᇌ Case Size ØD x L(mm)

49බᔳႂߔథᬌМՂMAXCAP Electronics Co., Ltd.
