MAG524
AVAILABLE Q2 2021
MAG524
w3
LINUX SET-TOP BOXES
WITH 4K AND HEVC SUPPORT
MAG524 and MAG524w3 are Linux-based
4K set-top boxes. Compared to the previous
MAG STB generation, these devices feature
an Amlogic S905X2 chipset with a 25% faster
ARM Cortex-A53 processor, and a better
GPU. HEVC technology allows providers
to deliver high-res content through their
existing network. The devices are equipped
with 2 USB ports and a built-in Wi-Fi module*
2.4 and 5 GHz.
Our MAG JS API allows easy
earlier MAG set-top boxes to new ones.
Upon request, we can integrate the MAG524
and MAG524w3 with different CAS/DRM and
middleware solutions. Operators, distributors,
and developers can rely on Infomir’s tech
support.
migration from
KEY FEATURES
4K and HEVC
Support
202102 *only in MAG524w3
4x ARM
Cortex-A53
4 GB eMMC 1 GB RAM
Linux OS 18 400
DMIPS
Built-in Wi-Fi
module*
Page 2
SPECIFICATIONS
MAG524
MAG524
w3
HARDWARE
Chipset Amlogic S905X2, 18 400 DMIPS
Processor ARM Cortex-A53 Quad Core 1 900 MHz
RAM / Flash 1 GB / 4 GB eMMC
GPU ARM Mali Dvalin MP2, 850MHz
Supports OpenGL ES 3.2, Vulkan 1.0
and OpenCL 2.0
AUDIO AND VIDEO
Audio сodecs MPEG L1/L2/L3l, AAC-LC, HE AAC V1/V2,
Video modes PAL, NTSC, 576p, 720p,
Video сodecs H.265/HEVC (optional), H.264 (AVC),
Video
containers
APE, FLAC, Dolby Digital Plus
1080p, 1080i, 2160p
MPEG-1/2, MPEG-4, XviD,
3D video support
TS, MTS, AVI, MPEG, MP4,
MOV, MKV, M2TS, VOB, 3GP
TM
SOFTWARE AND CAS/DRM
OS Linux 4.9
DRM/CAS Upon request
MW/UI Pre-integrated with Infomir
Ministra TV platform. Integration
with operator’s applications,
customization or complete
replacement of image is also available
OTHER INTERFACES
Digital AV HDMI 2.1
Ethernet 100 Mbps
USB
Wi-Fi Built-in 2T2R ac (only MAG524w3)
USB 2.0 × 1; USB 3.0 × 1
POWER
Image formats JPEG, PNG, BMP, RAW
Subtitles DVB, PGS, SRT, SSA/ASS, SUB, Teletext
subs, WebVtt, Closed captions
Playlist formats M3U, M3U8, PLS, CUE
PSU DC 12 V 1 A
PHYSICAL CHARACTERISTICS
Width/depth/
height
Weight 170 g
115 × 115 × 28 mm
202102
