Ordering number : EN*4852B

O3095HA (OT)/D1694TH (OT) No. 4852-1/5

Overview

The LC89512W integrates a real-time error correction
circuit and a SCSI interface in a single chip.

Functions

• CD-ROM error correction function, subcode readout
function, SCSI interface

Features

• Support for double-speed drives at an operating
frequency of 16.9344 MHz
Either SRAM (120 ns), DRAM (80 ns) or pseudo
SRAM (85 ns) can be used.

• Support for quad-speed drives at an operating frequency
of 33.8688 MHz
SRAM (70 ns) must be used.

• Built-in SCSI interface with built-in 48 mA sink buffer
(Only the TARGET function is supported.)

• Built-in 12-byte output FIFO for sub-CPU to host
computer data transmission

• Built-in 12-byte input FIFO for host computer to sub­CPU data transmission

• Subcode data can be written to buffer RAM and the sub­CPU can read the subcode values by connecting the
LC89512 to the CD-DSP subcode pin.

• Sub-CPU access of buffer RAM through the LC89512

• Built-in function for buffer RAM internal data transfer

• Pseudo-SRAM (128-kword × 8-bit and smaller) can be
used.

• DRAM (two 256-kword × 4-bit chips or two 1-Mword ×
4-bit chips) can be used.

• Transfer speeds:

2.8 MB/second (asynchronous mode) (for CD-ROM
decode only operation)

4.2 MB/second (synchronous mode) (CD-ROM decode
operation is not supported in synchronous mode)
Both of these transfer modes use a 16.9344 MHz clock.
(The transfer speed depends on the frequency used.)

• Operating frequencies: 16.9344 MHz (up to double
speed), 33.8688 (quad speed)

Package Dimensions

unit: mm

3181A-SQFP100

Preliminary

SANYO: SQFP100

[LC89512W]

LC89512W

SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters

TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN

CD-ROM Error Correction LSI

with Built-In SCSI Interface

CMOS LSI

Block Diagram

No. 4852-2/5

LC89512W

Pin Functions

Type: I: Input pin, O: Output pin, B: Bidirectional pin, P: Power supply pin, NC: No connection pin

No. 4852-3/5

LC89512W

Continued on next page.

Pin No. Pin Type Function

1 DB7 B SCSI connection
2 V

SS

1 P
3 DBP B SCSI connection
4 ATN B SCSI connection
5 V

SS

1 P
6 BSY B SCSI connection
7 ACK B SCSI connection
8 V

SS

1 P
9 RST B SCSI connection

10 MSG B SCSI connection
11 V

SS

1 P

12 SEL B SCSI connection
13 C/D B SCSI connection
14 V

SS

1 P

15 REQ B SCSI connection
16 I/O B SCSI connection
17 V

SS

0 P

18 I

O

0 B

19 I

O

1 B

20 I

O

2 B

21 I

O

3 B Data buffer RAM data signals

22 I

O

4 B These pins have built-in pull-up resistors.

23 I

O

5 B

24 I

O

6 B

25 I

O

7 B
26 INT1 O SCSI block interrupt request signal output (set using a register)
27 V

SS

0 P

28 V

SS

0 P
29 D0 B
30 D1 B
31 D2 B
32 D3 B

Microprocessor data signals

33 D4 B These pins have built-in pull-up resistors.
34 D5 B
35 D6 B
36 D7 B
37 INT0 O Microprocessor interrupt request signal output
38 XTALCK I Crystal oscillator circuit input
39 XTAL O Crystal oscillator circuit output
40 V

SS

0 P
41 V

DD

P
42 RA0 O
43 RA1 O
44 RA2 O
45 RA3 O
46 RA4 O
47 RA5 O
48 RA6 O

Data buffer RAM address signal outputs

49 RA7 O
50 RA8 O
51 RA9 O
52 RA10 O
53 RA11 O

Continued from preceding page.

Type: I: Input pin, O: Output pin, B: Bidirectional pin, P: Power supply pin, NC: No connection pin

Note: 1. NC must be left open. Do not connect any signals to these pins.

2. V

SS

0 is the logic system ground and VSS1 is the SCSI interface ground. (from the standard cell version)

No. 4852-4/5

LC89512W

Pin No. Pin Type Function

54 RA12 O
55 RA13 O
56 RA14 O

Data buffer RAM address signal outputs

57 RA15 O
58 RA16 O
59 RA17 O
60 V

DD

P
61 V

SS

0 P
62 RESET I Reset
63 TEST1 I
64 TEST2 I Test inputs. These pins should be tied low in normal operation.
65 TEST3 I
66 WFCK I
67 SBSO I Subcode I/O
68 SCOR I
69 SDATA I Serial data input
70 BCK I Serial data input clock
71 LRCK I 44.1 kHz strobe signal input
72 C2PO I C2 pointer input
73 RD I Microprocessor data read signal input
74 WR I Microprocessor data write signal input
75 CS I Chip select signal input (from the microprocessor)
76 RS I Register selection signal input
77 V

SS

0 P
78 SWAIT O Sub-CPU wait signal
79 EXCK O Sub code I/O
80 MCK O Crystal oscillator frequency output
81 TEST0 I Test inputs. These pins should be tied low in normal operation

.

82 RCS O RAM chip select
83 RWE O RAM data write signal output
84 ROE O RAM data read signal output
85 NC
86 NC
87 NC
88 NC
89 V

DD

P

90 V

SS

1 P
91 DB0 B SCSI connection
92 DB1 B SCSI connection
93 V

SS

1 P
94 DB2 B SCSI connection
95 DB3 B SCSI connection
96 V

SS

1 P
97 DB4 B SCSI connection
98 DB5 B SCSI connection
99 V

SS

1 P

100 DB6 B SCSI connection

Continued on next page.

No. 4852-5/5

LC89512W

Specifications

Absolute Maximum Ratings at VSS= 0 V

Allowable Operating Ranges at Ta = –30 to +70°C, VSS= 0 V

DC Characteristics at Ta = –30 to +70°C, VSS= 0 V, VDD= 4.5 to 5.5 V

This catalog provides information as of February, 1997. Specifications and information herein are subject to
change without notice.

■ No products described or contained herein are intended for use in surgical implants, life-support systems, aerospace
equipment, nuclear power control systems, vehicles, disaster/crime-prevention equipment and the like, the failure of
which may directly or indirectly cause injury, death or property loss.

■ Anyone purchasing any products described or contained herein for an above-mentioned use shall:
➀ Accept full responsibility and indemnify and defend SANYO ELECTRIC CO., LTD., its affiliates, subsidiaries and

distributors and all their officers and employees, jointly and severally, against any and all claims and litigation and all
damages, cost and expenses associated with such use:

➁ Not impose any responsibility for any fault or negligence which may be cited in any such claim or litigation on

SANYO ELECTRIC CO., LTD., its affiliates, subsidiaries and distributors or any of their officers and employees
jointly or severally.

■ Information (including circuit diagrams and circuit parameters) herein is for example only; it is not guaranteed for
volume production. SANYO believes information herein is accurate and reliable, but no guarantees are made or implied
regarding its use or any infringements of intellectual property rights or other rights of third parties.

Parameter Symbol Conditions Ratings Unit

Maximum supply voltage V

DD

max Ta = 25°C –0.3 to +7.0 V

I/O voltages V

IVO

Ta = 25°C –0.3 to VDD+ 0.3 V
Allowable power dissipation Pd max Ta ≤ 70°C 350 mW
Operating temperature Topr –30 to +70 °C
Storage temperature Tstg –55 to +125 °C
Soldering thermal stress limit (pins only) 10 seconds 260 °C

Parameter Symbol Conditions min typ max Unit

Supply voltage V

DD

4.5 5.0 5.5 V

Input voltage range V

IN

0 V

DD

V

Parameter Symbol Conditions min typ max Unit

Input high level voltage V

IH

1

All input pins other than (1), (3), and XTALCK

2.2 V

Input low level voltage V

IL

1 0.8 V

Input high level voltage V

IH

2

RESET, I

O

0 to IO7, D0 to D7, RD, CS, WR, WFCK,

2.5 V

Input low level voltage VIL2

SBSO and SCOR(1)

0.6 V

Input high level voltage V

IH

3

ACK, ATN and the input pins (3)

2.0 V

Input low level voltage V

IL

3 0.8 V

Output high level voltage V

OH

1

I

OH

1 = –3 mA: IO0 to IO7, D0 to D7 and all output pins

2.4 V

other than (2), (3) and XTALCK

Output low level voltage V

OL

1

I

OL

1 = 3 mA: IO0 to IO7, D0 to D7 and all output pins

0.4 V

other than (2), (3) and XTALCK

Output low level voltage V

OL

2

I

OL

2 = 3 mA: INT1 and INT0

0.4 V

(pull-up resistor open drain) (2)

Output low level voltage V

OL

3

I

OL

3 = 48 mA: DB0 to DB7, DBP, BSY, I/O, MSG, SEL,

0.4 V

RST, REQ, C/D (2)

Input leakage current I

L

VI= VSS, VDD: All input pins –25 +25 µA

Pull-up resistance R

UPIO

0 to IO7, D0 to D7, INT1 and INT0 40 80 160 kΩ
