Ordering number: EN1521D
Monolithic Linear IC
LA1185
FM Front-end for Radio-cassette Recorder, Home
Stereo Applications
Overview
The LA1185 is an FM receiver front-end IC for radio-cassette
recorder, music center applications. Its mixer is of
double-balanced type. The built-in oscillator and buffer
amplifier improves the strong input characteristic.
Use
.
FM front-end IC for radio-cassette recorders and music
centers
Functions and Features
.
RF amplifier, mixer, local oscillator
.
Improvement in cross modulation characteristics due to the
use of double-balanced mixer.
.
Improvement in strong input characteristic.
.
Minimum number of external parts required.
.
Less spurious radiation from local oscillator.
.
Operating voltage range : 1.5 to 8.0 V
Specifications
Package Dimensions
unit : mm
3017C-SIP9
[LA1185]
SANYO : SIP9
Maximum Ratings at Ta = 25°C
Parameter Symbol Conditions Ratings Unit
Maximum supply voltage V
Maximum pin voltage V
Allowable power dissipation Pd max Ta % 80°C 150 mW
Operating temperature Topr –20 to +80 °C
Storage temperature Tstg –40 to +125 °C
max 8 V
CC
3-5
V
6-5
12 V
VCC+ 0.8 V
Operating Conditions at Ta = 25°C
Parameter Symbol Conditions Ratings Unit
Recommended supply voltage V
Operating voltage range V
CC
op 1.5 to 8.0 V
CC
4.5 V
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN
81096HA(II)/0067KI/N214MW/4124KI/9283KI,TS No.1521-1/5
Page 2
LA1185
Operating Characteristics at Ta = 25°C, VCC= 4.5 V, fr = 108 MHz, f
= 118.7 MHz,
OSC
See specified Test Circuit
Parameter Symbol Conditions min typ max Unit
Current dissipation I
Output saturation voltage Vo 100 dBµ 95 115 135 mVrms
Local oscillation voltage V
Oscillation stop voltage Vstop 1.4 1.6 V
CC
OSC
Allowable power dissipation, Pd max − mW
Quiescent 5.5 8.0 mA
VCC= 2 V 190 235 mVrms
Ambient temperature, Ta − °C
Test Circuit and Equivalent Circuit Block Diagram
(Mitsumi)
(Sumida)
(Mitsumi)
(Sumida)
Unit (resistance: Ω, capacitance: F)
No.1521-2/5
Page 3
LA1185
VCCCharacteristic
– kHz
OSC
Total gain – dB
Specified test circuit
MIX gain – dB ∆f
Supply voltage, VCC–V
Temperature Characteristic Test Circuit
–0–mA
CC
– mVrms, I
OSC
Oscillation output, V
Band Characteristic
Local oscillation voltage
Conversion gain
Saturation output
Saturation output – dBµ
Local oscillation voltage – dBµ
Conversion gain – dB
Specified test circuit
with ANT B.P.F. removed
MIX gain – dB
Receiving frequency, fr− MHz
Oscillation frequency, f
OSC
– MHz
65 dBµ sensitivity – dBµ
–mA
CC-O
Current dissipation, I
Temperature Characteristic
65 dBµ sensitivity
Ambient temperature, Ta − °C
– dBµ
O-100
V
– MHz
OSC
Oscillation frequency, f
Unit (resistance: Ω, capacitance: F)
No.1521-3/5
Page 4
LA1185
Sample Application Circuit: LA1185 + LA1260 US band
AM section
Output – dBm
LA185+LA1260 Overall Characteristic
Output fm= 400 Hz 30% mod
AM output f
LED lightning sensitivity 11.5dB
= 1 kHz
m
ANT input – dBµ
LA1185+LA1260 Band Characteristic
LED lightning sensitivity
0dB
= 100%
Unit (resistance: Ω, capacitance: F)
Mitsumi Sumida
T1 YT-30224 2153-4016-006
T2 YT-30194 2153-4095-339
L1 YT-30196 0708-700
L2 YT-40001 0708-701
B.P.F. YT-30025 SNY-074-2001
THD–%
Usable sensitivity S/N –30 dB input, – dBµ
Usable sensitivity
Saturation output
Remove 1st stage B.P.F. when testing
LED lightning sensitivity, 3 dB L.S.
Receiving frequency, fr– MHz
Saturation output – mVrms
No.1521-4/5
