MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS

Low impedance, 105℃

KYASeries

Downsized from KY series

・

Newly innovative electrolyte is employed to minimize impedance

・

Endurance with ripple current : 4,000 to 10,000 hours at 105

・

Non solvent resistant type

・

RoHS2 Compliant

・

SPECIFICATIONS

◆

Items Characteristics

Category
Temperature Range

Rated Voltage Range
Capacitance Tolerance
Leakage Current

Dissipation Factor
(tanδ)

Low Temperature
Characteristics
(Max. Impedance Ratio)

Endurance

Shelf Life

-40 to +105

6.3 to 100V

±

I=0.01CV or 3µA, whichever is greater.
Where, I : Max. leakage current (µA), C : Nominal capacitance (µF), V : Rated voltage (V) (at 20℃ after 2 minutes)

Rated voltage (V
tanδ (Max.) 0.22 0.19 0.16 0.14 0.12 0.10 0.09 0.08
When nominal capacitance exceeds 1,000µF, add 0.02 to the value above for each 1,000µF increase. (at 20℃, 120Hz)
Rated voltage (Vdc)
Z(-25℃)/Z(+20℃)
Z(-40℃)/Z(+20℃)
The following specifications shall be satisfied when the capacitors are restored to 20℃ after subjected to DC voltage with the rated

ripple current is applied (the peak voltage shall not exceed the rated voltage) for the specified period of time at 105℃.
Time 6.3 to 10V

Capacitance change
D.F. (tanδ)
Leakage current
The following specifications shall be satisfied when the capacitors are restored to 20℃ after exposing them for 500 hours at 105℃ without

voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change
D.F. (tanδ)
Leakage current

℃

dc

20% (M) (at 20℃, 120Hz)

) 6.3V 10V 16V 25V 35V 50V 63V 100V

dc

6.3V

10V 16V 25V 35V 50V 63V 100V
4
8

16 to 100V

dc

dc

℃

3 2 2 2 2 2 2
6 4 3 3 3 3 3 (at 120Hz)

5 & 6.3 : 4,000hours φ8 & 10 : 6,000hours φ12.5 to 16 : 8,000hours

φ

5 & 6.3 : 5,000hours φ8 & 10 : 7,000hours φ12.5 to 16 : 10,000hours

φ

25% of the initial value

≦±

200% of the initial specified value

≦

The initial specified value

≦

25% of the initial value

≦±

200% of the initial specified value

≦

The initial specified value

≦

KYA

Downsized

DIMENSIONS [mm]

◆

●

Sleeve (PET : Brown)

φD'

Vent

φ5 &φ6.3)

PART NUMBERING SYSTEM

◆

A

E K Y

E M

φd

L' 15min. 4min.

Capacitance code (ex. 1.0µF:1R0,10µF:100,100µ

(φ5 to φ10)

6.3

0.5

2.5

φD+0.5max.

8

0.6

0.6

5.0

3.5

L+1.5max.

5

F±0.5

(φ12.5 to φ16)

F±0.5

φD
φd

φD'

0.5

2.0

F

L'

10

12.5

0.6

5.0

16

0.8

7.5

Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.

CAT. No. E1001U

MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS

KYASeries

STANDARD RATINGS

◆

℃

Rated
ripple

current

(mArms/

105℃,

100kHz)

EKYA6R3E□□101ME11D
EKYA6R3E□□181ME11D
EKYA6R3E□□221ME11D
EKYA6R3E□□331MF11D
EKYA6R3E□□471MF11D
EKYA6R3E□□821MHB5D
EKYA6R3E□□122MJC5S
EKYA6R3E□□122MH15D
EKYA6R3E□□152MH20D
EKYA6R3E□□182MJ16S
EKYA6R3E□□272MJ20S
EKYA6R3E□□332MJ25S
EKYA6R3E□□392MK20S
EKYA6R3E□□472MK25S
EKYA6R3E□□562MK25S
EKYA6R3E□□103ML25S
EKYA6R3E□□123MLN3S
EKYA6R3E□□153MLP1S
EKYA100E□□101ME11D
EKYA100E□□121ME11D
EKYA100E□□331MF11D
EKYA100E□□561MHB5D
EKYA100E□□821MH15D
EKYA100E□□821MJC5S
EKYA100E□□102MJC5S
EKYA100E□□122MH20D
EKYA100E□□122MJ16S
EKYA100E□□182MJ20S
EKYA100E□□222MJ25S
EKYA100E□□332MK20S
EKYA100E□□392MK25S
EKYA100E□□682ML25S
EKYA100E□□103MLN3S
EKYA100E□□123MLP1S
EKYA160E□□470ME11D
EKYA160E□□101ME11D
EKYA160E□□221MF11D
EKYA160E□□271MF11D
EKYA160E□□471MHB5D
EKYA160E□□681MH15D
EKYA160E□□681MJC5S
EKYA160E□□821MH20D
EKYA160E□□102MJ16S
EKYA160E□□152MJ20S
EKYA160E□□182MJ25S
EKYA160E□□222MK20S
EKYA160E□□332MK25S
EKYA160E□□472ML25S
EKYA160E□□562ML25S
EKYA160E□□682MLN3S
EKYA160E□□822MLN3S
EKYA160E□□103MLP1S
EKYA250E□□330ME11D
EKYA250E□□470ME11D
EKYA250E□□680ME11D
EKYA250E□□151MF11D
EKYA250E□□331MHB5D
EKYA250E□□391MH15D
EKYA250E□□471MJC5S
EKYA250E□□561MH20D
EKYA250E□□681MJ16S
EKYA250E□□102MJ20S
EKYA250E□□122MJ25S
EKYA250E□□152MK20S
EKYA250E□□222MK25S

Impedance

WV

Cap

(Vdc)

6.3

10,000 16×25 0.021 0.060 2,930
12,000 16×31.5 0.017 0.050 3,450
15,000 16×35.5 0.015 0.044 3,610

10

10,000 16×31.5 0.017 0.050 3,450
12,000 16×35.5 0.015 0.044 3,610

16

10,000 16×35.5 0.015 0.044 3,610

25

Case size

(µF)

φD×

100 5×11 0.90 3.6 150
180 5×11 0.40 1.6 250
220 5×11 0.40 1.6 250
330 6.3×11 0.22 0.87 400
470 6.3×11 0.22 0.87 400

820 8×11.5 0.13 0.52 640
1,200 10×12.5 0.080 0.32 865
1,200 8×15 0.087 0.35 840
1,500 8×20 0.069 0.27 1,050
1,800 10×16 0.060 0.24 1,300
2,700 10×20 0.046 0.18 1,400
3,300 10×25 0.042 0.17 1,650
3,900 12.5×20 0.035 0.12 1,900
4,700 12.5×25 0.027 0.089 2,230
5,600 12.5×25 0.027 0.089 2,230

100 5×11 0.90 3.6 150

120 5×11 0.40 1.6 250

330 6.3×11 0.22 0.87 400

560 8×11.5 0.13 0.52 640

820 8×15 0.087 0.35 840

820 10×12.5 0.080 0.32 865
1,000 10×12.5 0.080 0.32 865
1,200 8×20 0.069 0.27 1,050
1,200 10×16 0.060 0.24 1,300
1,800 10×20 0.046 0.18 1,400
2,200 10×25 0.042 0.17 1,650
3,300 12.5×20 0.035 0.12 1,900
3,900 12.5×25 0.027 0.089 2,230
6,800 16×25 0.021 0.060 2,930

47 5×11 0.40 1.6 250
100 5×11 0.40 1.6 250
220 6.3×11 0.22 0.87 400
270 6.3×11 0.22 0.87 400
470 8×11.5 0.13 0.52 640
680 8×15 0.087 0.35 840
680 10×12.5 0.080 0.32 865
820 8×20 0.069 0.27 1,050

1,000 10×16 0.060 0.24 1,300
1,500 10×20 0.046 0.18 1,400
1,800 10×25 0.042 0.17 1,650
2,200 12.5×20 0.035 0.12 1,900
3,300 12.5×25 0.027 0.089 2,230
4,700 16×25 0.021 0.060 2,930
5,600 16×25 0.021 0.060 2,930
6,800 16×31.5 0.017 0.050 3,450
8,200 16×31.5 0.017 0.050 3,450

33 5×11 0.40 1.6 250

47 5×11 0.40 1.6 250

68 5×11 0.40 1.6 250
150 6.3×11 0.22 0.87 400
330 8×11.5 0.13 0.52 640
390 8×15 0.087 0.35 840
470 10×12.5 0.080 0.32 865
560 8×20 0.069 0.27 1,050
680 10×16 0.060 0.24 1,300

1,000 10×20 0.046 0.18 1,400
1,200 10×25 0.042 0.17 1,650
1,500 12.5×20 0.035 0.12 1,900
2,200 12.5×25 0.027 0.089 2,230

(Ω max./100kHz)

L(mm)

20℃-10

□□ : Enter the appropriate lead forming or taping code.

Part No.

Impedance

WV

Cap

(Vdc)

3,300 16×25 0.021 0.060 2,930
3,900 16×25 0.021 0.060 2,930

25

4,700 16×31.5 0.017 0.050 3,450
5,600 16×35.5 0.015 0.044 3,610

35

1,000 12.5×20 0.035 0.12 1,900
1,500 12.5×25 0.027 0.089 2,230
2,200 16×25 0.021 0.060 2,930
2,700 16×25 0.021 0.060 2,930
3,300 16×31.5 0.017 0.050 3,450
3,900 16×35.5 0.015 0.044 3,610

50

1,000 16×25 0.025 0.075 2,555
1,200 16×25 0.025 0.075 2,555
1,800 16×31.5 0.022 0.066 3,010
2,200 16×35.5 0.019 0.057 3,150

63

1,000 16×25 0.025 0.075 2,730
1,200 16×31.5 0.021 0.063 2,850
1,500 16×35.5 0.019 0.057 2,900

100

Case size

(µF)

φD×

33 5×11 0.40 1.6 250

47 5×11 0.40 1.6 250
100 6.3×11 0.22 0.87 400
220 8×11.5 0.13 0.52 640
270 8×15 0.087 0.35 840
330 10×12.5 0.080 0.32 865
390 8×20 0.069 0.27 1,050
470 10×16 0.060 0.24 1,300
680 10×20 0.046 0.18 1,400
820 10×25 0.042 0.17 1,650

1.0 5×11 4.0 16 30

2.2 5×11 2.5 10 43

3.3 5×11 2.2 8.8 53

4.7 5×11 1.9 7.6 88
10 5×11 1.5 6.0 100
22 5×11 0.70 2.8 180
27 5×11 0.70 2.8 250
47 6.3×11 0.30 1.2 295
56 6.3×11 0.30 1.2 295

100 8×11.5 0.17 0.68 555
150 8×15 0.12 0.48 730
180 10×12.5 0.12 0.48 760
180 8×20 0.091 0.36 910
220 10×16 0.084 0.34 1,050
330 10×20 0.060 0.24 1,220
470 10×25 0.055 0.22 1,440
470 12.5×20 0.045 0.15 1,660
560 12.5×20 0.045 0.15 1,660
820 12.5×25 0.034 0.11 1,950

10 5×11 0.88 3.5 173
15 5×11 0.88 3.5 173
33 6.3×11 0.35 1.4 278
56 8×11.5 0.22 0.88 500
82 8×15 0.16 0.64 665

100 10×12.5 0.11 0.44 725
120 8×20 0.12 0.48 820
120 10×16 0.076 0.31 950
220 10×20 0.056 0.23 1,200
330 10×25 0.046 0.19 1,350
330 12.5×20 0.041 0.13 1,570
390 12.5×20 0.041 0.13 1,570
470 12.5×25 0.031 0.093 1,990
560 12.5×25 0.031 0.093 1,990

1.0 5×11 4.5 15 20

2.2 5×11 3.0 13 30

3.3 5×11 2.7 11 40

4.7 5×11 2.5 10 65

6.8 5×11 1.4 5.6 125

(Ω max./100kHz)

L(mm)

20℃-10

Low impedance, 105℃

Rated
ripple

current

(mArms/

105℃,

℃

100kHz)

EKYA250E□□332ML25S
EKYA250E□□392ML25S
EKYA250E□□472MLN3S
EKYA250E□□562MLP1S
EKYA350E□□330ME11D
EKYA350E□□470ME11D
EKYA350E□□101MF11D
EKYA350E□□221MHB5D
EKYA350E□□271MH15D
EKYA350E□□331MJC5S
EKYA350E□□391MH20D
EKYA350E□□471MJ16S
EKYA350E□□681MJ20S
EKYA350E□□821MJ25S
EKYA350E□□102MK20S
EKYA350E□□152MK25S
EKYA350E□□222ML25S
EKYA350E□□272ML25S
EKYA350E□□332MLN3S
EKYA350E□□392MLP1S
EKYA500E□□1R0ME11D
EKYA500E□□2R2ME11D
EKYA500E□□3R3ME11D
EKYA500E□□4R7ME11D
EKYA500E□□100ME11D
EKYA500E□□220ME11D
EKYA500E□□270ME11D
EKYA500E□□470MF11D
EKYA500E□□560MF11D
EKYA500E□□101MHB5D
EKYA500E□□151MH15D
EKYA500E□□181MJC5S
EKYA500E□□181MH20D
EKYA500E□□221MJ16S
EKYA500E□□331MJ20S
EKYA500E□□471MJ25S
EKYA500E
EKYA500E□□561MK20S
EKYA500E□□821MK25S
EKYA500E□□102ML25S
EKYA500E□□122ML25S
EKYA500E□□182MLN3S
EKYA500E□□222MLP1S
EKYA630E□□100ME11D
EKYA630E□□150ME11D
EKYA630E□□330MF11D
EKYA630E□□560MHB5D
EKYA630E□□820MH15D
EKYA630E□□101MJC5S
EKYA630E□□121MH20D
EKYA630E□□121MJ16S
EKYA630E□□221MJ20S
EKYA630E□□331MJ25S
EKYA630E□□331MK20S
EKYA630E□□391MK20S
EKYA630E□□471MK25S
EKYA630E□□561MK25S
EKYA630E□□102ML25S
EKYA630E□□122MLN3S
EKYA630E□□152MLP1S
EKYA101E□□1R0ME11D
EKYA101E□□2R2ME11D
EKYA101E□□3R3ME11D
EKYA101E□□4R7ME11D
EKYA101E□□6R8ME11D

Part No.

471MK20S

□□

Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.

CAT. No. E1001U

MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS

KYASeries

STANDARD RATINGS

◆

℃

Rated
ripple

current

(mArms/

105℃,

100kHz)

EKYA101E□□100MF11D
EKYA101E□□150MF11D
EKYA101E□□270MHB5D
EKYA101E□□390MH15D
EKYA101E□□470MJC5S
EKYA101E□□560MH20D
EKYA101E□□680MJ16S
EKYA101E□□101MJ20S
EKYA101E□□151MJ25S
EKYA101E□□181MK20S
EKYA101E□□221MK25S
EKYA101E□□331ML25S
EKYA101E□□471MLN3S
EKYA101E□□561MLP1S

Impedance

WV

Cap

(Vdc)

100

Case size

(µF)

φD×

10 6.3×11 0.57 2.3 205
15 6.3×11 0.57 2.3 205
27 8×11.5 0.36 1.4 355
39 8×15 0.25 1.0 450
47 10×12.5 0.17 0.66 480
56 8×20 0.19 0.76 565

68 10×16 0.11 0.47 600
100 10×20 0.084 0.34 800
150 10×25 0.069 0.28 900
180 12.5×20 0.062 0.18 1,100
220 12.5×25 0.047 0.14 1,250
330 16×25 0.038 0.12 1,700
470 16×31.5 0.032 0.095 1,850
560 16×35.5 0.029 0.086 2,000

(Ω max./100kHz)

L(mm)

20℃-10

□□ : Enter the appropriate lead forming or taping code.

Low impedance, 105℃

Part No.

RATED RIPPLE CURRENT MULTIPLIERS

◆

Frequency Multipliers

・

Capacitance(µF)

2,200 to 3,900 0.75 0.90 0.95 1.00
4,700 to 0.85 0.95 0.98 1.00

Frequency(Hz)

1.0 to 180 0.40 0.75 0.90 1.00
220 to 560 0.50 0.85 0.94 1.00
680 to 1,800 0.60 0.87 0.95 1.00

120 1k 10k 100k

The endurance of capacitors is reduced with internal heating produced by ripple current at the rate of halving the lifetime with every 5℃ rise.
When long life performance is required in actual use, the rms ripple current has to be reduced.

Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.

CAT. No. E1001U
