Audio Frequency Amplifier
• Complement to KSB810
KSD1020
KSD1020
1
1.Emitter 2. Collector 3. Base
TO-92S
NPN Epitaxial Silicon Transistor
Absolute Maximum Ratings
Symbol Parameter Ratings Units
V
CBO
V
CEO
V
EBO
I
C
* Collector Current (Pulse) 1.0 A
I
CP
P
C
T
J
T
STG
* PW≤10ms, Duty Cycle≤50%
Collector-Base Voltage 30 V
Collector-Emitter Voltage 25 V
Emitter-Base Voltage 5.0 V
Collector Current (DC) 700 mA
Collector Power Dissipation 350 mW
Junction Temperature 150 °C
Storage Temperature -55 ~ 150 °C
Electrical Characteristics
Symbol Parameter T est Condition Min. Typ . Max. Units
I
CBO
I
EBO
h
FE1
h
FE2
V
(on) Base-Emitter On Voltage VCE=6V, IC=10mA 600 640 700 mV
BE
(sat) Collector-Emitter Saturation Voltage IC=700mA, IB=70mA 0.2 0.4 V
V
CE
(sat) Base-Emitter Saturation Voltage IC=700mA, IB=70mA 0.95 1.2 V
V
BE
C
ob
f
T
* Pulse Test: PW≤350µs, Duty Cycle≤ 2%
Collector Cut-off Current VCB=30V, IE=0 100 nA
Emitter Cut-off Current VEB=5V, IC=0 100 nA
* DC Current Gain VCE=1V, IC=100mA
Output Capacitance VCB=6V, IE=0, f=1MHz 13 25 pF
Current Gain Bandwidth Product VCE=6V, IC=10mA 50 170 MHz
Ta=25°C unless otherwise noted
Ta=25°C unless otherwise noted
=1V, IC=700mA
V
CE
120
35
200
140
400
h
Classification
FE1
Classification Y G
h
FE1
©2004 Fairchild Semiconductor Corporation Rev. B2, April 2004
120 ~ 240 200 ~ 400
Page 2
Typical Characteristics
KSD1020
20
18
16
14
12
10
8
6
4
[mA], COLLECTOR CURRENT
C
I
2
0
0 1020304050
IB = 140µA
IB = 120µA
IB = 100µA
IB = 80µA
IB = 60µA
IB = 40µA
IB = 20µA
VCE[V], COLLECTOR-EMITTER VOLTAGE
Figure 1. Static Characteristic Figure 2. DC current Gain
10000
1000
100
(sat)[V], SATURATION VOLTAGE
CE
(sat), V
BE
V
10
1 10 100 1000 10000
IC[mA], COLLECTOR CURRENT
VBE(sat)
VCE(sat)
IC=10I
1000
100
10
, DC CURRENT GAIN
FE
h
1
1 10 100 1000 10000
VCE= 1V
IC[mA], COLLECTOR CURRENT
B
1000
100
10
1
1 10 100 1000 10000
[MHz], CURRENT GAIN-BANDWIDTH PRODUCT
T
f
VCE = 6V
IC[mA], COLLECTOR CURRENT
Figure 3. Base-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
©2004 Fairchild Semiconductor Corporation
Figure 4. Current Gain-Bandwidth Product
Rev. B2, April 2004
Page 3
Package Dimensions
4.00
(1.10)
0.66 MAX.
±0.20
TO-92S
±0.20
3.70
±0.30
2.31
KSD1020
±0.20
14.47
0.49
±0.10
1.27TYP
[1.27±0.20] [1.27±0.20]
3.72
2.86
±0.20
1.27TYP
±0.20
±0.10
0.77
0.35
+0.10
–0.05
Dimensions in Millimeters
Rev. B2, April 2004©2004 Fairchild Semiconductor Corporation
