Low Frequency Power Amplifier
• Complement to KSA1150
• Collector Dissipation : P
=300mW
C
KSC2710
KSC2710
1
1.Emitter 2. Collector 3. Base
TO-92S
NPN Epitaxial Silicon Transistor
Absolute Maximum Ratings
Symbol Parameter Ratings Units
V
V
V
I
P
T
T
CBO
CEO
EBO
C
C
J
STG
Collector-Base Voltage 40 V
Collector-Emitter Voltage 20 V
Emitter-Base Voltage 5 V
Collector Current 500 mA
Collector Power Dissipation 300 mW
Junction Temperature 150 °C
Storage Temperature -55 ~ 150 °C
Electrical Characteristics
Symbol Parameter T est Condition Min. Typ . Max. Units
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
h
FE
(sat) Collector-Emitter Saturation Voltage IC=0.5A, IB=50mA 0.18 0.4 V
V
CE
Collector-Base Breakdown Voltage IC=100µA, IE=0 40 V
Collector-Emitter Breakdown Voltage IC=10mA, IB=0 20 V
Emitter-Base Breakdown Voltage IE=100µA, IC=0 5 V
Collector Cut-off Current VCB=25V, IE=0 0.1 µA
Emitter Cut-off Current VEB=3V, IC=0 0.1 µA
DC Current Gain VCE=1V, IC=0.1A 120 400
Ta=25°C unless otherwise noted
Ta=25°C unless otherwise noted
hFE Classification
Classification Y G
h
FE
©2004 Fairchild Semiconductor Corporation Rev. B2, April 2004
120 ~ 240 200 ~ 400
Page 2
Typical Characteristics
KSC2710
500
IB = 2.0mA
400
IB = 1.8mA
IB = 1.6mA
300
200
[mA], COLLECTOR CURRENT
100
C
I
IB = 1.4mA
IB = 1.2mA
IB = 1.0mA
IB = 0.8mA
IB = 0.6mA
IB = 0.4mA
IB = 0.2mA
0
0246810
VCE[V], COLLECTOR-EMITTER VOLTAGE
Figure 1. Static Characteristic Figure 2. DC current Gain
10
1
0.1
(sat)[V], SATURATION VOLTAGE
CE
(sat), V
BE
V
0.01
1 10 100 1000
VBE(sat)
VCE(sat)
IC[mA], COLLECTOR CURRENT
IC=10I
1000
VCE=1V
100
10
, DC CURRENT GAIN
FE
h
1
1 10 100 1000
IC[mA], COLLECTOR CURRENT
100
B
10
1
[mA], COLLECTOR CURRENT
C
I
0.1
0.00.20.40.60.81.01.2
VCE = 1V
VBE[V], BASE-EMITTER VOLTAGE
Figure 3. Base-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
100
10
[pF], CAPACITANCE
ob
C
1
110100
VCB[V], COLLECTOR BASE VOLTAGE
Figure 5. Collector Output Capacitance
©2004 Fairchild Semiconductor Corporation
Figure 4. Base-Emitter On Voltage
f = 1MHz
IE=0
Rev. B2, April 2004
Page 3
Package Dimensions
4.00
(1.10)
0.66 MAX.
±0.20
TO-92S
±0.20
3.70
±0.30
2.31
KSC2710
±0.20
14.47
0.49
±0.10
1.27TYP
[1.27±0.20] [1.27±0.20]
3.72
2.86
±0.20
1.27TYP
±0.20
±0.10
0.77
0.35
+0.10
–0.05
Dimensions in Millimeters
Rev. B2, April 2004©2004 Fairchild Semiconductor Corporation
