KSC2500
Medium Power Amplifier & Low Saturation
KSC2500
1
1. Emitter 2. Collector 3. Base
TO-92L
NPN Epitaxial Silicon Transistor
Absolute Maximum Ratings
Symbol Parameter Ratings Units
V
CBO
V
CES
V
CEO
Emitter-Base Voltage 6 V
V
EBO
I
C
I
CP
I
B
P
C
T
J
T
STG
* PW≤10ms, Duty Cycle≤30%
Collector-Base Voltage 30 V
Collector-Emitter Voltage 30 V
Collector-Emitter Voltage 10 V
Collector Current (DC) 2 A
* Collector Current (Pulse) 5 A
Base Current 0.5 A
Collector Power Dissipation 900 mW
Junction Temperature 150 °C
Storage Temperature -55 ~ 150 °C
Electrical Characteristics
Symbol Parameter Test Condition Min. Typ. Max. Units
I
CBO
I
EBO
BV
CBO
BV
EBO
h
FE 1
h
FE 2
V
(sat) Collector-Emitter Saturation Voltage IC=2A, IB=50mA 0.2 0.5 V
CE
(on) Base-Emitter On Voltage VCE=1V, IC=2A 0.86 1.5 V
V
BE
f
T
C
ob
Collector Cut-off Current VCB=30V, IE=0 100 nA
Emitter Cut-off Current VEB=6V, IC=0 100 nA
Collector-Emitter Breakdown Voltage IC=10mA, IB=0 10 V
Emitter-Base Breakdown Voltage IE=1mA, IC=0 6 V
DC Current Gain VCE=1V, IC=0.5A
Current Gain Bandwidth Product VCE=1V, IC=0.5A 150 MHz
Output Capacitance VCB=10V, IE=0, f=1MHz 27 pF
Ta=25°C unless otherwise noted
Ta=25°C unless otherwise noted
=1V, IC=2A
V
CE
140
70 200
600
h
Classification
FE1
Classification A B C D
h
FE1
©2002 Fairchild Semiconductor Corporation Rev. A2, September 2002
140 ~ 240 200 ~ 330 300 ~ 450 420 ~ 600
Page 2
Typical Characteristics
KSC2500
5
IB = 50mA
IB = 40mA
4
3
IB = 30mA
IB = 20mA
EMITTER COMMON
Ta=25oC
10000
1000
2
[A], COLLECTOR CURRENT
C
1
I
0
012345
VCE[V], COLLECTOR-EMITTER VOLTAGE
IB = 10mA
IB = 0mA
IB = 5mA
100
, DC CURRENT GAIN
FE
h
10
0.01 0.1 1 10
IC[A], COLLECTOR CURRENT
Figure 1. Static Characteristic Figure 2. DC current Gain
1
0.1
EMITTER COMMON
IC/IB=40
5
EMITTER COMMON
VCE=1V
4
3
2
EMITTER COMMON
VCE=1V
(sat)[V], SATURATION VOLTAGE
CE
V
0.01
0.1 1
IC[A], COLLECTOR CURRENT
1
[A], COLLECTOR CURRENT
C
I
0
0.0 0.2 0.4 0.6 0.8 1.0
VBE[V], BASE-EMITTER VOLTAGE
Figure 3. Collector-Emitter Saturation Voltage Figure 4. Base-Emitter On Voltage
DC (T
10ms
100ms
a
=25
o
C)
10
IC MAX. (Pulse)
IC MAX. (Continuous)
1
0.1
[A], COLLECTOR CURRENT
C
I
0.01
0.1 1 10 100
VCE[V], COLLECTOR-EMITTER VOLTAGE
Figure 5. Safe Operating Area
©2002 Fairchild Semiconductor Corporation
Rev. A2, September 2002
Page 3
Package Dimensions
±0.20
8.00
±0.20
±0.10
1.70
±0.40
1.00
4.90
±0.20
TO-92L
0.70MAX.
0.80
±0.10
1.00MAX.
KSC2500
13.50
0.50
±0.20
3.90
±0.10
±0.20
1.45
3.90
±0.20
1.27TYP
[1.27
2.54 TYP
±0.10
0.45
±0.20
]
±0.10
0.45
Dimensions in Millimeters
©2002 Fairchild Semiconductor Corporation Rev. A2, September 2002
