Radial Lead Aluminum Electrolytic Capacitors
Safety vent (Ф8up)
EPS Series
High Frequency , Low impedance with 7mm height 105°C 1000 hours guaranteed.
Specification
Item Characteristics
Operating temperature range -55~+105°C
Voltage range 6.3~35 V.DC
Nominal cap. range 4.7~180uF
Capacitance tolerance -20%~+20% (at 120Hz, 20 °C)
Leakage current I=0.01C V or 3(uA) after 2 minutes.
W V 6.3 10 16 25 35 Dissipation Factor (tg δ)
(at 120Hz, /+20°C)
Low temp. impedance
Stability at 120Hz
Impedance (Ω) See case size table
High temp. Load test
High temp. Non-Load test
Drawing
Insulating Sleeve
max
α
D+
Ф
*Ф6.3 is avai l abl e b y R equ es t
tanδ 0.24 0.20 0.16 0.14 0.12
W.V. 6.3 10 16 25 35
Z(-25°C)/Z(+20°C) 4 3 2 2 2
Z(-40°C)/Z(+20°C) 8 6 4 3 3
After 100 0hrs. Appl ic ation of DC rat ed wor king voltag e at +1 05°C, Th e capaci tor sh all m eet th e
following limits.
Capacitance change …. ≤±25% of the ini tial measur ed value.
δ
…. ≤200% of the initial specified value.
tan
≤
DC leakage current ….
After stor age for 500hours at +10 5°C with n o voltage ap plied, voltag e treat ment of JIS -C-51 02
article 4-4 is to be given and then measurement shal l be made, at which ti me requirements
specified in the table “High temperature loading” can be met.
Ф
d±0.05 Tinned copper-ply wire
15min L + β max
4min
The initial specified v alue.
p±0.5
Unit: (mm)
Φ
D 4 5 6.3
P 1.5 2.0 2.5
Φ
d 0.45
β
1.0
α
0.5
www.kingcap.com
1/2
Page 2
Radial Lead Aluminum Electrolytic Capacitors
Dimension & Maximum Permissible Ripple Current mA (rms) at 105°C, 120Hz
6.3V 10V 16V 25V 35V WV(V)
Impedance
Φ
D×L
uF
(mm)
4.7 4×7 2.20 80
8.2 4×7 2.38 80 4×7 2.00 80
12 4×7 2.40 80 5×7 2.38 80
15 4×7 2.00 150 5×7 1.65 150
18
22 5×7 2.00 150 5×7 1.70 150 5×7 1.02 150
27 4×7 2.42 80 6.3×7 0.85 230
20°C
100KHZ
Ripple
Ω
current
105°C
100khz
Φ
D×L
(mm)
Impedance
Ω
20°C
100KHZ
Ripple
current
105°C
100khz
Φ
D×L
(mm)
Impedance
Ω
20°C
100KHZ
Ripple
current
105°C
100khz
Φ
D×L
(mm)
Impedance
Ω
20°C
100KHZ
Ripple
current
105°C
100khz
Φ
D×L
(mm)
Impedance
Ω
20°C
100KHZ
Ripple
current
105°C
100khz
33 5×5 1.48 150 6.3×7 0.85 230
47 6.3×7 1.20 230 6.3×7 0.80 230
56 4×7 1.51 150
68 6.3×5 0.90 230 6.3×7 0.89 230
100 6.3×7 0.93 230
120 6.3×7 0.76 230
130 6.3×5 0.82 230
180 6.3×5 0.85 230
