KBPC1500 / BR150 SERIES
15 AMPERE SINGLE-PHASE SILICON BRIDGE RECTIFIER
FEATURES
High efficiency
Surge overload rating - 300 amperes peak
Body clad with metal (electrically isolated) or
plastic
Plastic encapsulation has Underwriters
Laboratory flammability classification 94V-0
Universal multipurpose terminals
VOLTAGE RANGE
50 to 1000 Volts PRV
CURRENT
15 Amperes
29.0
28.0
17.6
15.5
~
19.1
17.1
±
terminals
6.35 x 0.8
15.3
13.3
+
~
Ø 4.9
17.6
15.5
29.0
28.0
11.5
MECHANICAL DATA
Case
Terminals
Polarity
Weight
: Metal or Plastic shell with plastic
encapsulation
: 1/4inch, 6.35mm Faston blades *
: Positive symbol printed on body
: 1.1 ounce, 31.6 grams
25.4
max
Dimensions in millimetres
max
Ø 2.4
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load. For capacitive load, derate current by 20%.
KBPC1508
BR158
800
560
800
Maximum Recurrent Peak Reverse Voltage
Maximum Bridge Input Voltage RMS
Maximum DC Blocking Voltage
Maximum Average Forward Current at
T
C = 55°C
Peak Forward Surge Current, 8.3 ms single
half sine - wave superimposed on rated load
Maximum Forward Voltage Drop
per Element at 7.5A
Maximum Reverse Current at Rated DC
Blocking Voltage per Element
RMS Isolation Voltage from Case to Terminals
Operating Temperature Range
Storage Temperature Range
(see Fig 4)
Metal Case
Plastic Case
(see Fig 2)
(see Fig 1)
(see Fig 3)
TA = 25°C
TA = 100°C
VRRM
VRMS
VDC
IF(AV)
IFSM
VF
IR
ISO
V
TJ
TSTG
KBPC15005
BR1505
50
35
50
KBPC1501 KBPC1502
BR151
100
70
100
BR152
200
140
200
KBPC1504 KBPC1506 KBPC1510
BR154
400
280
400
15.0
300
1.2
10.0
1.0
2500
- 55 to + 125
- 55 to + 150
BR156
600
420
600
BR1510
1000
700
1000
V
V
V
A
A
V
µA
mA
V
°C
°C
Lead out wires can be supplied as an alternative to blades - add suffix W to part number e.g. KBPC1506W
*
Reformatted by Anglia 9907
RATING AND CHARACTERISTIC CURVES
KBPC1500/BR150 SERIES
400
300
200
150
100
PEAK FORWARD SURGE
CURRENT, AMPERES
60
1
FIG 1 : MAXIMUM NON-REPETITIVE
SURGE CURRENT PER ELEMENT
8.3ms Single Half Sine Wave
TJ =125°C
10 100
NUMBER OF CYCLES AT 60Hz
FIG 2 : DERATING CURVE FOR
RECTIFIED OUTPUT CURRENT
15
10
5
AVERAGE FORWARD OUTPUT
CURRENT, AMPERES
60 80 100 120 140
40
20
CASE TEMPERATURE °C
Resistive or
Inductive
Load
100
10
1
INSTANTANEOUS FORWARD
CURRENT, AMPERES
0.1
FIG 3 : TYPICAL FORWARD
CHARACTERISTICS PER ELEMENT
TJ = 25°C
Pulse Width = 300µs
0.6 0.8 1.0 1.2 1.4 1.6
INSTANTANEOUS FORWARD
VOLTAGE, VOLTS
FIG 4 : TYPICAL REVERSE
CHARACTERISTICS PER ELEMENT
500
TJ = 125°C
100
10
1.0
INSTANTANEOUS REVERSE
CURRENT, MICROAMPERES
0.1
.01
0
40
20
PERCENT OF RATED PEAK
REVERSE VOLTAGE
60
TJ = 25°C
80
100
120
140
Reformatted by Anglia 9907
