Page 1
LAB
SEME
Prelim. 9/94
IP78M05ADP
IP78M05DPA
Semelab plc. Telephone +44(0)1455 556565. Fax +44(0)1455 552612.
E-mail: [email protected]
Website: http://www.semelab.co.uk
3 TERMINAL
LOW CURRENT
5 VOLT POSITIVE
VOLTAGE REGULATOR
V
I
DC Input Voltage
P
D
Power Dissipation
T
j
Operating Junction Temperature Range
Maximum Junction Temperature
T
stg
Storage Temperature Range
T
L
Lead Temperature (Soldering, 10 sec)
35V
Internally limited
0°C to 125°C
125°C
–65°C to +150°C
300°C
MECHANICAL DATA
Dimensions in mm (inches)
ABSOLUTE MAXIMUM RATINGS (T
case
= 25°C unless otherwise stated)
PostScript Picture
C:\APPROVED\PACKAGES\PLASTIC\D PACK.EPS
FEATURES
• 0.01%/V LINE REGULATION
• 0.3%/A LOAD REGULATION
• THERMAL OVERLOAD PROTECTION
• SHORT CIRCUIT PROTECTION
• SAFE OPERATING AREA PROTECTION
• 1% OUTPUT VOLTAGE TOLERANCE
D–PACK — TO251 plastic package
Pin 1 – V
IN
Pin 2 – GND Pin 3 – V
OUT
Page 2
LAB
SEME
Prelim. 9/94
IP78M05ADP
IP78M05DPA
Semelab plc. Telephone +44(0)1455 556565. Fax +44(0)1455 552612.
E-mail: [email protected]
Website: http://www.semelab.co.uk
4.95 5 5.05
4.85 5.15
310
310
310
550
46
0.1 0.5
0.2 0.8
40 200
65 80
65 80
2 2.5
300 600
0.7 1.0 1.4
0.5 2.0
4.80 5 5.20
4.75 5.25
50
25
50
50
46
0.5
0.8
40 200
62
62
2.5
300 600
1.0 1.6
0.5
IP78M05ADP IP78M05DP
Parameter Test Conditions Unit
Min. Typ. Max. Min. Typ. Max.
V
O
D
V
O
D
V
O
I
d
D
I
Q
V
N
D
V
IN
D
V
O
I
SC
I
PK
IO= 100mA VIN= 10V
IO= 5mA to 350mA
VIN= 7.5 to 20V
Tj= 0 to 125°C PD£
P
MAX
IO= 200mA VIN= 7 to 25V
IO= 200mA VIN= 8 to 25V
Tj= 0 to 125°C
IO= 500mA VIN= 8 to 12V
IO= 5mA to 500mA VIN= 10V
Tj= 0 to 125°C
IO= 350mA VIN= 10V
Tj= 0 to 125°C
IO= 5 to 500mA VIN= 10V
Tj= 0 to 125°C
IO= 200mA VIN= 8 to 25V
Tj= 0 to 125°C
f = 10Hz to 100kHz
VIN= 8 to 18V f = 120Hz
IO= 300mA
VIN= 8 to 18V f = 120Hz
IO= 100mA Tj= 0 to 125°C
IO= 350mA
VIN= 35V
VIN= 10V
IO= 5mA
Output Voltage*
Line Regulation*
Load Regulation*
Quiescent Current*
Quiescent Current
Change*
Output Noise Voltage
Ripple Rejection
Dropout Voltage*
Short Circuit Current*
Peak Output Current*
Average Temperature
Coefficient of Output
Voltage*
ELECTRICAL CHARACTERISTICS (T
j
= 25°C unless stated)
V
mV
mV
mA
mA
m
V
dB
V
mA
A
mV
/ °C
* Pulse Test: tp£
10ms , d£5%.
All characteristics are measured with a capacitor across the input of 0.22mF and a capacitor across the output of 0.1mF.
Output Voltage changes due to changes in internal temperature must be taken into account separately.
