ICS307

Serially Programmable Clock Source

Description

The ICS307-01 and ICS307-02 are versatile
serially programmable clock sources which take
up very little board space.

They can generate any frequency from 6 to
200 MHz, and have a second configurable
output. The outputs can be reprogrammed on
the fly, and will lock to a new frequency in 10 ms
or less. Smooth transitions (in which the clock
duty cycle remains roughly 50%) are guaranteed
if the output divider is not changed.

The devices include a PDTS pin which tri-states
the output clocks and powers down the entire
chip.

The ICS307-02 features a default clock output
at start-up and is recommended for all new
designs.

Features

• Packaged as 16 pin narrow SOIC

• Highly accurate frequency generation

• Serially programmable: user determines
the output frequency via a 3 wire interface.

• Eliminates need for custom quartz

• Input crystal frequency of 5 - 27 MHz

• Output clock frequencies up to 200 MHz

• Power Down Tri-State mode

• Very low jitter

• Operating voltages of 3.0 to 5.5 V

• 25 mA drive capability at TTL levels

• Industrial temperature available

Block Diagram

SCLK

DATA

STROBE

Crystal or
clock input

X1/ICLK

X2

Shift

Register

R6:R0

Crystal

Oscillator

C1:C0

Reference

Divider

VDD GND

TTL

2

C1:C0

3
2

7

S2:S0
F1:F0

Phase Comparator,

Charge Pump,

and Loop Filter

9

V8:V0

VCO

Divider

Function

VCO

Select

2

F1:F0

Output

S2:S0

3

Output
Divider

Output

TTL

Buffer

Buffer

CLK1

PDTS

CLK2

MDS 307 D 1 Revision 042501

Integrated Circuit Systems, Inc. • 525 Race Street • San Jose •CA•95126•[phone]tel •www.icst.com

Pin Assignment

ICS307

Serially Programmable Clock Source

ICS307

X1/ICLK

NC

VDD

NC

GND

CLK2

NC

SCLK STROBE

1
2

3
4

5
6

7
8

16
15

14

13
12

11
10

X2

NC
NC

PDTS
DATA

CLK1

NC

9

16 pin Narrow

(0.150”) SOIC

Pin Description

Number Name Type Description

1 X1/ICLK XI Crystal connection (REF frequency). Connect to a parallel resonant crystal, or an input clock .
2 NC - No Connect.
3 VDD P Connect to +3.3V or +5V.
4 NC - No Connect.
5 GND P Connect to ground.
6 CLK2 O Output clock 2, determined by F0-F1. Can be reference, ref/2, CLK1/2 or off.
7 NC - No Connect.
8 SCLK I Serial clock. See timing diagram.

9 STROBE I Strobe to load data. See timing diagram.
10 NC - No Connect.
11 CLK1 O Output clock 1, determined by R0-R6, V0-V8, S0-S2 and input frequency.
12 DATA I Data Input. Serial input for three words which set the output clock(s).
13 PDTS I Powers down entire chip, tri-states CLK1 and CLK2 outputs, when low. Internal pull-up.
14 NC - No Connect.
15 NC - No Connect.
16 X2 XO Input crystal connection. Connect to a crystal, or leave unconnected for clock input.

Type: XI, XO=crystal connections, I = Input, O = output, P = power supply connection

MDS 307 D 2 Revision 042501

Integrated Circuit Systems, Inc. • 525 Race Street • San Jose •CA•95126•[phone]tel •www.icst.com

ICS307

Serially Programmable Clock Source

Determining the Output Frequency

On power-up the ICS307-01 on-chip registers can have random values, so almost any frequency may be
output from the part. CLK1 will always have some clock signal present, but CLK2 could possibly be OFF
(low).

The ICS307-02 on-chip registers are initially configured to provide a x1 output clock on both the CLK1
and CLK2 outputs. The output frequency will be the same as the input clock or crystal. This is useful if
the ICS307 will provide the initial system clock at power-up. Since this feature is an advantage in most
systems, the ICS307-02 is recommended for new designs.

With programming, the user has full control in changing the desired output frequency to any value over the
range shown in Table 1 on page 4. The output of the ICS307 can be determined by the following simple
equation:

CLK1 frequency = Input frequency • 2 •

Where VCO Divider Word (VDW) = 4 to 511 (0, 1, 2, 3 are not permitted)

Reference Divider Word (RDW) = 1 to 127 (0 is not permitted)
Output Divider = values on page 4

Also, the following operating ranges should be observed:

55 MHz < Input frequency • 2 •

200 kHz <

To determine the best combination of VCO, reference, and output dividers, contact ICS application
engineering. You may also fax this page to ICS at 408 295 9818(fax). Be sure to indicate the following:

Your Name ________________ Company Name___________________ Telephone_________________

Input Frequency
(RDW+2)

(VDW+8)
(RDW+2)

(VDW+8)
(RDW+2)(OD)

< 400 MHz

Commercial temperature range.
Industrial temperature limits are
60 MHz to 360 MHz.

Respond by e-mail (list your e-mail address) __________________or fax number ___________________
Desired input crystal_______ or clock_______ (in MHz) Desired output frequency_______________
REF Output_______VDD = 3.3V or 5V _______ Duty Cycle: 40-60% _____ or 45-55% required____

MDS 307 D 3 Revision 042501

Integrated Circuit Systems, Inc. • 525 Race Street • San Jose •CA•95126•[phone]tel •www.icst.com

ICS307

Serially Programmable Clock Source

Setting the Device Characteristics

The tables below show the settings which can be configured, in addition to the VCO and Reference dividers.

Table 1. Output Divide and
Maximum Output Frequency

CLK1

S2 S1 S0 Output

Divide

0 0 0 10 40 36
0 0 1 2 200 180
0 1 0 8 50 45
0 1 1 4 100 90
1 0 0 5 80 72
1 0 1 7 55 50
1 1 0 3 135 120
1 1 1 6 67 60

Maximum Max. Freq.
Frequency Industrial
5 V or 3.3 V Version

Table 2. CLK2 Output

F1 F0 CLK2

0 0 REF
0 1 REF/2
1 0 OFF (Low)
1 1 CLK1/2

0 = Connect directy to ground
1 = Connect directly to VDD

Table 3. Output Duty Cycle Configuration

TTL Duty cycle measured at Recommended VDD

0 1.4V 5 V
1 VDD/2 3.3 V

Note: The TTL bit optimizes the duty cycle at
different VDD. When VDD is 5 V, set to 0
for a near-50% duty cycle with TTL levels.
When VDD is 3.3 V, set this bit to a 1, so the
50% duty cycle is achieved at VDD/2.

Table 4. Crystal Load Capacitance

C1 C0 VDD = 5 V VDD = 3.3 V

0 0 22.3 - 0.083 f 22.1 - 0.094 f
0 1 23.1 - 0.093 f 22.9 - 0.108 f
1 0 23.7 - 0.106 f 23.5 - 0.120 f
1 1 24.4 - 0.120 f 24.2 - 0.135 f

Note: f is the crystal frequency, between 10 and
27 MHz. Effective load capacitance will be higher
for crystal frequencies lower than 10 MHz. If a
clock input is used, set C1 = 0 and C0 = 0.

MDS 307 D 4 Revision 042501

Integrated Circuit Systems, Inc. • 525 Race Street • San Jose •CA•95126•[phone]tel •www.icst.com

ICS307

Serially Programmable Clock Source

Configuring the ICS307

The ICS307 can be programmed to set the output functions and frequencies. The three data bytes are
written to the DATA pin, in this order:

C1 C0

MSB LSB

TTL

F1 F0 S2 S1 S0

V8 V7 V6 V5 V4 V3 V2 V1 V0 R6 R5 R4 R3 R2 R1 R0

MSB LSB MSB LSB

C1 is loaded into the port first and R0 last.

R6:R0 Reference Divider Word (RDW)
V8:V0 VCO Divider Word (VDW)
S2:S0 Output Divider Select (OD)
F1:F0 Function of CLK2 Output
TTL Duty Cycle Setting
C1:C0 Internal Load Capacitance for Crystal

Power up default values for ICS 307-02

0 0

1

0 0 0 1 1 0 0

The input frequency will come from both outputs.

0

0 0 1 0 0 0 0

0

0 0 1 1 0

Programming Example

To generate 66.66 MHz from a 14.31818 MHz input, the RDW should be 59, the VDW should be 276,
and the Output Divide is 2. Selecting the minimum internal load capacitance, CMOS duty cycle, and CLK2
to be OFF means that the following three bytes are sent to the ICS307:

00110001 10001010 00111011
Byte 1 Byte 2 Byte 3

As shown in Figure 2, after these 24 bits are clocked into the ICS307, taking STROBE high will send this data
to the internal latch, and the CLK output will lock within 10 ms.

NOTE: If STROBE is in the high state and SCLK is pulsed, DATA is clocked directly to the internal latch
and the output conditions will change accordingly. Although this will not damage the ICS307, it is
recommended that STROBE be kept low while DATA is being clocked into the ICS307 in order to avoid
unintended changes on the output clocks.

MDS 307 D 5 Revision 042501

Integrated Circuit Systems, Inc. • 525 Race Street • San Jose •CA•95126•[phone]tel •www.icst.com

ICS307

Serially Programmable Clock Source

DATA

t

setup

SCLK

STROBE

C1 C0 TTL F1 R1 R0

t

hold

Figure 2. Timing Diagram for Programming the ICS307

AC Parameters for Writing to the ICS307

• • •

• • •

t

w

t

s

Parameter Condition Min Max Units

t

SETUP

t

HOLD

t

w

t

s

Setup time. 10
Hold time after SCLK. 10
Data wait time. 10
Strobe pulse width 40

ns
ns
ns
ns

External Components / Crystal Selection

The ICS307 require a 0.01µF decoupling capacitor to be connected between VDD and GND. It must be
connected close to the ICS307 to minimize lead inductance. A 33 Ω terminating resistor can be used in
series with the CLK1 and CLK2 outputs. A parallel resonant, fundamental mode crystal with a load
(correlation) capacitance of C should be used, where C is the value calculated from Table 4. For crystals
with a specified load capacitance greater than C, additional crystal capacitors may be connected from each
of the pins X1 and X2 to Ground as shown in the Block Diagram on page 1. The value (in pF) of these
crystal caps should be = (CL-C)*2, where CL is the crystal load capacitance in pF. These external

capacitors are only required for applications where the exact frequency is critical. For a clock input,
connect to X1 and leave X2 unconnected (no capacitors on either pin).

MDS 307 D 6 Revision 042501

Integrated Circuit Systems, Inc. • 525 Race Street • San Jose •CA•95126•[phone]tel •www.icst.com

DC CHARACTERISTICS (VDD = 5.0 V unless otherwise noted)

ICS307

Serially Programmable Clock Source

Electrical Specifications

Parameter Conditions Minimum Typical Maximum Units
ABSOLUTE MAXIMUM RATINGS (Note 1)

Supply Voltage, VDD Referenced to GND 7 V
Inputs Referenced to GND -0.5 VDD+0.5 V
Clock Output Referenced to GND -0.5 VDD+0.5 V
Ambient Operating Temperature 0 70 °C
Ambient Operating Temperature, Industrial I version -40 85 °C
Soldering Temperature Max of 10 seconds 260 °C
Storage temperature -65 150 °C

Operating Voltage, VDD 3 5.5 V
Input High Voltage, VIH, X1/ICLK only ICLK (Pin 1) (VDD/2)+1 VDD/2 V
Input Low Voltage, VIL, X1/ICLK only ICLK (Pin 1) VDD/2 (VDD/2)-1 V
Input High Voltage, VIH 2 V
Input Low Voltage, VIL PDTS, ICS307-01 only 0.4 V

All other inputs,-01 & -02 0.8
Output High Voltage, VOH, CMOS level IOH=-4 mA VDD-0.4 V
Output High Voltage, VOH IOH=-25 mA 2.4 V
Output Low Voltage, VOL IOL=25 mA 0.4 V
IDD Operating Supply Current, 20 MHz crystal No Load, 100 MHz out 26 mA

100MHz out,VDD=3.3V 13 mA
Short Circuit Current CLK1 and CLK2 outputs ±70 mA
On-Chip Pull-up Resistor Pin 13 270 kΩ
Input Capacitance 4 pF

AC CHARACTERISTICS

Input Frequency, crystal input (must be fundamental) 5 27 MHz
Input Frequency, clock input 2 50 MHz
Output Frequency (See Table 1) VDD = 3.0 to 5.5V 6 200 MHz
Output Frequency (see Table 1), I version VDD = 3.0 to 5.5V
Output Clock Rise Time 0.8 to 2.0V 1 ns
Output Clock Fall Time 2.0 to 0.8V 1 ns
Output Clock Duty Cycle, even output divides At duty cycle level 45 49 to 51 55 %
Output Clock Duty Cycle, odd output divides At duty cycle level 40 60 %
Power-up time, STROBE goes high until CLK out 3 10 ms
Absolute Maximum Clock Period Jitter Deviation from mean ±120 ps
One Sigma Clock Period Jitter 50 ps

6

180 MHz

Notes:

1. Stresses beyond those listed under Absolute Maximum Ratings could cause permanent damage to the device. Prolonged exposure
to levels above the operating limits but below the Absolute Maximums may affect device reliability.

2. Typical values are at 25°C.

MDS 307 D 7 Revision 042501

Integrated Circuit Systems, Inc. • 525 Race Street • San Jose •CA•95126•[phone]tel •www.icst.com

Serially Programmable Clock Source

Inches

Millimeters

Package Outline and Package Dimensions
(For current dimensional specifications, see JEDEC Publication No. 95.)

16 pin SOIC narrow

Symbol Min Max Min Max

A 0.0532 0.0688 1.35 1.75

A1

E H

INDEX

AREA

1 2

h x 45°

D

B 0.0130 0.0200 0.33 0.51

C

D 0.3859 0.3937 9.80 10.00

E 0.1497 0.1574 3.80 4.00

e

H 0.2284 0.2440 5.80 6.20

h 0.0099 0.0195 0.25 0.50
L 0.0160 0.0500 0.41 1.27

ICS307

0.0040 0.0098 0.10 0.24

0.0075 0.0098 0.19 0.24

A1 C

A

e

B

L

Ordering Information

Part/Order Number Marking Package Temperature

ICS307M-01 ICS307M-01 16 pin SOIC 0 to 70 °C

ICS307M-01T ICS307M-01 16 pin SOIC on tape and reel 0 to 70 °C

ICS307M-01I ICS307M-01I 16 pin SOIC -40 to 85°C

ICS307M-01IT ICS307M-01I 16 pin SOIC on tape and reel -40 to 85°C

ICS307M-02 ICS307M-02 16 pin SOIC 0 to 70 °C

ICS307M-02T ICS307M-02 16 pin SOIC on tape and reel 0 to 70 °C

ICS307M-02I ICS307M-02I 16 pin SOIC -40 to 85°C

ICS307M-02IT ICS307M-02I 16 pin SOIC on tape and reel -40 to 85°C

While the information presented herein has been checked for both accuracy and reliability, Integrated Circuit Systems, Inc. (ICS) assumes no responsibility for either its use or for the
infringement of any patents or other rights of third parties, which would result from its use. No other circuits, patents, or licenses are implied. This product is intended for use in
normal commercial applications. Any other applications such as those requiring extended temperature range, high reliability, or other extraordinary environmental requirements are
not recommended without additional processing by ICS. ICS reserves the right to change any circuitry or specifications without notice. ICS does not authorize or warrant any ICS
product for use in life support devices or critical medical instruments.

MDS 307 D 8 Revision 042501

Integrated Circuit Systems, Inc. • 525 Race Street • San Jose •CA•95126•[phone]tel •www.icst.com
