IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01
FEATURES

• Histogram and Hough Transform Calculation

• Four 512 X 9 Look-up Tables Provided to Perform User-defined Point -wise

Transformations

• Real-time Histogram Equalization

• High Data Rates

• 512 X 24 Accumulation RAM

• Pixel Location Function

The IA64250 is a "plug -and -play" drop -in replacement for the original LSI L64250. This replacement IC
has been developed using innovASIC’s MILESTM, or Managed IC Lifetime Extension System, cloning
technology. This technology produces replacement ICs far more complex than "emulation" while ensuring
they are compatible with the original IC. MILESTM captures the design of a clone so it can be produced even
as silicon technology advances. MILESTM also verifies the clone against the original IC so that even the
"undocumented features" are duplicated. This data sheet documents all necessary engineering information
about the IA64250 including functional and I/O descriptions, electrical characteristics, and applicable timing.

Package Pinout for 68 PLCC PACKAGE:

10

11
12

13
14

15
16
17
18

19
20

21
22

23
24

25
26

27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43

123456789

6162636465666768

60

59
58

57
56

55
54

53
52

51
50
49

48
47
46
45

44

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 1 of 21 1-888-824-4184

IA64250 Data Sheet

GRID #

Histogram/Hough Transform Processor As of Production Ver. 01

PIN DESIGNATOR:

PIN
NAME GRID #

GND 1 GND 18 GND 35 DO.5 52
CI.5 2 VDD 19 STARTIO 36 DO.6 53
CI.4 3 VDO.6 20 VDD 37 DO.7 54
CI.3 4 VDO.5 21 CLK2 38 DO.8 55
CI.2 5 VDO.4 22 PO 39 DI.0 56
CI.1 6 VDO.3 23 IODV 40 DI.1 57
CI.0 7 VDO.2 24 DV 41 DI.2 58
WE 8 VDO.1 25 AT 42 DI.3 59
REGADR.5 9 VDO.0 26 GND 43 DI.4 60
VDD 10 VDD 27 VDD 44 VDD 61
REGADR.4 11 RESET FP 28 DO.0 45 DI.5 62
REGADR.3 12 GND 29 DO.1 46 DI.6 63
REGADR.2 13 RY 30 DO.2 47 DI.7 64
REGADR.1 14 CY 31 DO.3 48 DI.8 65
REGADR.0 15 RX 32 DO.4 49 CI.8 66
VDO.8 16 CX 33 VDD 50 CI.7 67
VDO.7 17 CLK1 34 GND 51 CI.6 68

PIN
NAME

GRID #

PIN
NAME

PIN
NAME

GRID #

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 2 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

BLOCK DIAGRAM:

Figure 1

AT

REGADR

6

STARTIO_N

RESETFP

DI

9

CLOCK

IODV

CI

9

CONTROLLER

RAMADDR

RAMDATA

HCLR

SAT
SEL

LUT

LUTADDR
LUTDATA

OUT_SEL

2

MOD_RAMDATA

9

24

2

4

2

9

9

CY

CLOCK

RY

24

ACC RAM

512 X 24

LUT RAM

4 X 512 X 9

Y

COUNTER

24
CLOCK

CLOCK

LUTOUT

9

Y

SYNC

ADDER SYNC SHIFT

24

DV

ADDER SHIFT

9

10

24

9

DO

9

OUT_SEL

9

VDO

RESET

CLOCK

COUNTER

FP

9

FP

CX

CLOCK

RX

CI

AT

REGADR

X

COUNTER

MARKER

MEMORY

WE_N

X

9

MODE

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 3 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

Description

The IA64250 performs three separate tasks, histogram generation, modified Hough transforms, and
pixel location. There are three modes of operation for the IA64250: computation, I/O, and
initialization.

The controller block in the block diagram decodes the instructions and contains the mode registers.
After decoding the mode, the controller generates all of the control signals to the rest of the part.
These control signals include the addresses and input data for the LUT and ACC RAMs, the select
lines for both the output mux and the shifter, and the reset for the FP counter. This block also
controls the clearing of the ACC RAM.

The ACC RAM stores the video data that is to be output during the I/O mode. This data can be
modified, depending on mode, by several methods prior to being output. These methods are
described in the computation mode section.

The LUT RAM can store up to four different data modifying functions. These functions are used to
modify the video data coming in and access the appropriate data in the ACC RAM through the ACC
RAM address. This data is then sent out on the DO output.

During the initialization mode, the functions to be performed are defined. This is accomplished by
setting the values in the mode registers contained in the controller block.

During the computation mode, the histogram, Hough transform, or pixel location data is computed.
Data equalization also occurs during this mode if desired. The controller block controls the adders
and shifters during this mode to ensure correct data manipulation. This is accomplished through the
data stored in the mode registers as well as the DV input. The controller block also generates the
addresses to both the RAMs.

The I/O mode allows data to be transferred to the Accumulation RAM (ACC RAM) and/or to and
from the Look Up Table RAM (LUT RAM). The user can also update the marker memory during
the I/O mode. The marker memory is used to quickly find points of interest on the histogram,
Hough transform, or accumulated histogram curves. Up to seven points of interest can be specified
on the grey level axis or parameter axis. The corresponding value on the accumulation axis will then
be available. The reverse is also true, where the user can specify accumulation values of interest and
obtain the corresponding grey values. The memory map located in the I/O mode description shows
the configuration of the data stored in the memory. The transfer of data from an external source to
either of the RAMs is done through either the CI or DI input bus. The controller block takes in the
data and passes it along to the appropriate RAM. The controller block also supplies the RAM with
the address and control signals needed to write the data. During a data transfer from one RAM to
the other, the controller block performs a similar task, overseeing the transfer and supplying the
necessary control signals and address.

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 4 of 21 1-888-824-4184

IA64250 Data Sheet

Selects marker and maximum registers when HIGH or mode latches when LOW.

Histogram/Hough Transform Processor As of Production Ver. 01

I/O SIGNAL DESCRIPTION:

The diagram below describes the I/O characteristics for each signal on the IC. The signal
names correspond to the signal names on the pinout diagrams provide.

I/O Characteristics:

IODV O When HIGH, ACC RAM or LUT RAM data on the DO bus is valid.
VDO.0 - VDO.8 O
CIO.0 - CIO.8 I
WE I Used to strobe data into mode latches when LOW.
REGADR.0 - REGADR.5 I Selects mode latch, marker or maximum registers.

LUT RAM data output (uses CLK1).
Control register and LUT input data bus.

AT I

CLK1 I
CLK2 I

AT must be LOW to access the LUT or ACC RAMs via the DO bus.
Pixel clock active at rising edge.
User I/O clock (may be connected to CLK1)

STARTIO I Initiates RAM I/O at HIGH to LOW transition.
CX,CY I Used to increment X or Y counters when HIGH.
RX,RY I

RESET FP I
PO O

Resets X or Y counters(overrides CX, CY) when HIGH.
Resets FP counter when HIGH.

Test pin should be left unconnected.

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 5 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

INITIALIZATION MODE:

Initialization defines the operation of the IA64250. The mode and marker memories store
66 nine-bit words that define the operation of the part and contain marker information. The
REGADR input is used to select the proper register. Data is written over the CI bus and
read on the DO bus. The AT pin controls whether data is a mode word or a marker. When
AT is low, the data written is mode information, which is stored in the mode registers
contained in the controller block. When AT is high, the data is a marker, and is stored in the
marker memory. To prevent erroneous operation STARTIOn should be high, and IODV
and DV should be low during initialization.

Mode Register Table:

AT REGA

DR

0 0 W sel0 sel1 sel2 sel3 lut0 lut1 sh1 sat TESTn
0 1 W fn0 fn1 Eq io0 io1 hclr0 hclr1 func pdwn

Marker Memory Table:

AT REGADR R/W CONTENTS

1

0

1

1

1

2

1

3

1

16

1

17

1

18

1

19

1

32

1

33

1

34

1

35

1

36

1

37

1

38

1

39

1

56

1

57

1

58

1

59

*ACC COUNT BIT 18-23 APPEARS ON BIT LOCATION 0-5 RESPECTIVELY

R/W BIT LOCATION

W ci0 ci1 ci2 ci3 ci4 ci5 ci6 ci7 ci8
R do0 do1 do2 do3 do4 do5 do6 do7 do8

R
R
R
R

W
W
W
W

R/W
R/W
R/W
R/W

R/W
R/W
R/W
R/W

R/W
R/W
R/W
R/W

GREY LEVEL OF MAXIMUM ACC COUNT BITS 0-8
MAXIMUM ACC COUNT BITS 0-8
MAXIMUM ACC COUNT BITS 9-17
MAXIMUM ACC COUNT BITS 18-23*

TEST MODE, DO NOT ACCESS
TEST MODE, DO NOT ACCESS
TEST MODE, DO NOT ACCESS
TEST MODE, DO NOT ACCESS

R/W MARKER 0 GREY LEVEL BITS 0-8
R/W MARKER 0 ACC COUNT BITS 0-8
R/W MARKER 0 ACC COUNT BITS 9-17
R/W MARKER 0 ACC COUNT BITS 18-23*

R/W MARKER 1 GREY LEVEL BITS 0-8
R/W MARKER 1 ACC COUNT BITS 0-8
R/W MARKER 1 ACC COUNT BITS 9-17
R/W MARKER 1 ACC COUNT BITS 18-23*

.
.
.

R/W MARKER 6 GREY LEVEL BITS 0-8
R/W MARKER 6 ACC COUNT BITS 0-8
R/W MARKER 6 ACC COUNT BITS 9-17
R/W MARKER 6 ACC COUNT BITS 18-23*

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 6 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

Mode Definition:

The controller block decodes the instructions brought in to the IA64250 on the CI bus, with
the REGADR input determining which instructions are being read in. The Mode Memory
table shows the configuration of the CI bus encoded instruction depending on the state of
REGADR. A brief description of the instruction bits follows:

sel(3:0) selects the nine bits of the ACC RAM to be transferred to the DO output or to the LUT

RAM.

sel0 sel1 sel2 sel3 Sel window

0
1
0
1
0

…

1

lut(1:0) defines one of the four 512 X 9 LUTs as active.
sh1 When low, the least significant nine bits of the 10 bit LUT and Y count sum will address the

sat When high, the nine bits selected from the 24 bit ACC RAM output will be forced to 511

test Used for testing when low. Should be high for normal operation.
fn(1:0) Determines the operation performed during the computational mode.

fn0 fn1 FUNCTION

0
0
1
1

eq When high, causes the output of the ACC RAM to be accumulated as it is read. This is

0
0
1
1
0

1

0
0
0
0
1

1

0
0
0
0
0

1

0
1
2
3
4

15

select bits 0-8
select bits 1-9
select bits 2-10
select bits 3-11
select bits 4-12

select bits 15-23

ACC RAM. When high, the nine most significant bits of the sum will be used.

(111111111) if the 24 bit ACC RAM output contains a 1 in the range of bits from the sel + 9
to 23. Otherwise the nine bits selected from the ACC RAM output will be unchanged.

0
1
0
1

modified Hough transform computation
undefined
histogram computation
pixel location

commonly used to compute the histogram equalization transfer function. When low, the
ACC RAM output is not modified.

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 7 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

io(1:0) Control the operations of the ACC and LUT RAMs during I/O mode (when the
STARTIOn signal has been asserted).

io0 io1 FUNCTION

0
0
1
1

hclr(1:0) Control the clearing of the ACC RAM during I/O mode

hclr0 hclr1 FUNCTION

0

0
1
1

func Determines the function performed by the marker processor. When high, each marker

pdwn When high, the ACC and LUT RAMs are placed in an inactive mode. Should be low for

MEMORY CONFIGURATIONS:

ACC RAM Histogram Mode:

Grey Level Memory Contents

0 Count for Grey Value 0
1 Count for Grey Value 1

.
.
.
.

511 Count for Grey Value 511

0
1
0
1

0

1
0
1

transfer data from the ACC RAM to the LUT RAM
read the ACC RAM
read the LUT RAM
write the LUT RAM

ACC RAM cleared when either the ACC RAM or LUT RAM is
accessed
Undefined
ACC RAM cleared only when the ACC RAM is accessed
ACC RAM not cleared during an i/o operation

circuit within the processor will locate an accumulated count from the ACC RAM
corresponding to the previously given grey value. When low, each marker will locate the
grey value corresponding to a previously given accumulation count from the ACC RAM.

normal operation.

The following memory maps specify the configuration of the ACC RAM and the LUT RAM in the
various computational modes.

.
.
.
.

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 8 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

ACC RAM Modified Hough Transform Mode:

Hough Transform
Parameter Axis

0 Projection Along r = 0
1 Projection Along r = 1

.
.
.
.

511 Projection Along r = 511

ACC RAM Find Pixel Mode:

Memory Contents Address
0-8 9-17 18-23

0 X0 Y0 FLAG
1 X1 Y1 FLAG

.
.
.
.

N XN YN FLAG
N + 1 0 0 0

.
.
.
.

511 0 0 0

Memory Contents

.
.
.
.

LUT RAM Histogram Computation:

Histogram Transfer Function Memory Contents

0 f(0)
1 f(1)

.
.
.
.

511 f(511)

.
.
.
.

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 9 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

LUT RAM Hough Transform Mode
(45 < φ ≤ 90):

Address Memory Contents

0
1

.
.
.
.

511

LUT RAM Find Pixel Mode:

0 Flag for Grey Value 0 t0

0*cotφ
1*cotφ

.
.
.
.

511*cotφ

Memory Contents Address
0-5 6-7 8

Not Used

1 Flag for Grey Value 1 t1

.
.
.
.

511 Flag for Grey Value

.
.
.
.

511

Tag
Bit

t511

COMPUTATION MODE:
Histogram Computation:

During histogram computation, the ACC RAM and LUT RAM form the active elements of
the data path. The ACC RAM is addressed by the controller block. The ACC RAM address
is the DI input signal. The data addressed by the DI signal is incremented if the DV input
signal is high, otherwise the data is left unchanged. The LUT is not used in the computation
of the histogram and can concurrently modify the image by a user-defined transfer function.
The DI signal addresses the LUT and the LUT data appears on the VDO output pins two
clock cycles later.

Histogram equalization can be performed in real time. The histogram is stored in the ACC
RAM. The equalization transfer function must be computed and transferred into the LUT
RAM. Then during the next frame as a new histogram is being computed, data will also be
equalized in real time and passed to the VDO output pins.

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 10 of 21 1-888-824-4184

IA64250 Data Sheet

Case

r(X,Y,

)

LUT[i]

CX,RX

Controls

CY,RY

Controls

1a

0 ≤ Φ < 45

X tan

Φ

+ Y

itanΦXY1b

45 ≤ Φ < 90

Y cot

Φ + X

icotΦYX1c

90 ≤ Φ < 135

(YMAX - Y) cot (180 -

Φ

) + X

(YMAX - I) cot (180 -

Φ)YX1d

135 ≤ Φ < 180

(XMAX - X) tan (180 -

Φ

) + Y

(XMAX - I) tan (180 -

Φ)X

Y

Histogram/Hough Transform Processor As of Production Ver. 01

Hough Tran sform Computation:

During Hough Transform computation, the ACC RAM stores the projection image, and the LUT
RAM is loaded with the function listed in the Modified Hough Transform Parameterization Table.

Φ

During initialization, the LUT is loaded with the appropriate transfer function to compute
either f(x) or f(y). Once the LUT is loaded, the X and Y counters are used to generate the
proper memory addresses. The X counter is incremented at each valid pixel and reset at the
beginning of each line. The Y counter is incremented at the beginning of each line and reset
at the beginning of each frame. The control signals for these two counters are generated in
the controller block. As each pixel location along a line is addressed, the grey value at that
point is added to the partial sum in the memory location.

Intensity Averaging:

Another computational mode is possible by generating ACC RAM addresses differently. An
example of this is to compute the average intensity of an image as a function of position.
Consider a 512 X 512 pixel image divided into 256 blocks (16 X 16) of 32 X 32 pixels each.
To compute the average intensity, the Y counter would be incremented every 32 pixels and
reset at the beginning of each line. The X counter would be incremented every 32 lines and
reset at the beginning of a frame. The proper addresses will be generated by multiplying the
X counter output by 16 (this is done via the LUT). After processing, the first 256 locations
of the ACC RAM will hold the accumulated intensity in each 32 X 32 region. Setting sel(3:0)
= 10 will give the average intensity in each region.

Pixel Location:

Pixel location is used to determine the X and Y coordinates of up to 64 specific pixels or
group of pixels in an image. When performing pixel location, the user first loads one of the
LUTs with a table indicating which pixels are of interest. Each pixel in the table is assigned a
6 bit flag that allows the user to distinguish groups of pixels.

Each time an interesting pixel (as specified in the LUT) is found, the X, Y, and flag values
are stored in the ACC RAM at the address given by the FP counter. The FP counter is then
incremented. Note that only 512 values can be stored at any instance. In the event that
more values are stored, the first RAM locations will be overwritten.

Pixel location uses the LUT and the X and Y counters to store a six-bit code and location
information about pixels of interest. The X and Y counters hold the coordinates of the grey
value on the DI pins and are controlled in the same manner described in the Hough
transform section. DI addresses the LUT producing a one-bit tag and a six bit flag
associated with the grey value. If the tag bit is high and DV is high the six bit flag and X, Y

Φ

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 11 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

coordinates are stored in th e ACC RAM. Storage space is assigned sequentially as defined by
the FP counter.

I/O Mode:

Once a computation has taken place, the user reads data from the LUT or the ACC RAM.
These operations typically take place during a vertical retrace or some other period when the
processor is not busy and AT is low. This mode is also to load the LUT with the desired
transfer function. Generally, these operations are controlled by CLK2 so that data may be
read or written at a different rate than the pixel clock. If the ACC RAM is accessed, the
marker values will be updated.

The internal signals hclr(1:0) control whether or not the ACC RAM is cleared during I/O
operations. These values are stored in the mode registers of the controller block during the
initialization mode. If both hclr0 and hclr1 are high then the ACC RAM will not be cleared
during any I/O operation. If hclr0 is high and hclr1 is low, then each ACC RAM location
will be cleared after it is read. If both hclr0 and hclr1 are low then each ACC RAM location
is cleared when either the ACC RAM location or the corresponding LUT RAM location is
accessed.

Read/Transfer ACC RAM:

Once the histogram has been computed and stored in the ACC RAM, the user asserts
STARTIOn low to initiate reading of the data. One data value is read out of the ACC RAM
during each clock cycle of CLK2 starting with address 0. The address counter for the ACC
RAM is contained in the controller block. If STARTIO remains low, all 512 data values will
be read in sequential address order and the processor will return to pixel processing mode
after 512 clock cycles. If STARTIOn is returned high, the I/O mode halts and the user can
return to pixel processing operations. When the output flag IODV is high, the processor
has placed valid data from the LUT or ACC RAMs onto the I/O bus.

The user controls the destination of the ACC RAM data via the io(1:0) bits in the mode
registers located in the control memory. Code 01 signifies that histogram data will be placed
on the DO output bus, while code 00 will transfer data from the ACC RAM to the LUT
RAM.

In both cases the user can modify the histogram data. By setting the internal EQ control bit
high, an accumulated histogram will be output. The shifter allows the user to determine
which nine bits of the 24 bit ACC RAM output will be directed to the DO bus and LUT
RAM. The shifter control data is stored in the mode registers. The control signals for the
shifter are generated in the controller block. Additional control over the output forma t can
be obtained via the SAT pin in the control memory. When SAT is high, the resultant nine
bit shifted output will be forced to 511 (111111111) if overflow occurs in the shifter.

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 12 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

Marker Circuitry:

When ACC RAM is accessed, the marker circuitry in the marker memory is updated. The
user can specify up to seven values of grey level and the associated count will be stored in
the mode memory. Setting func = 1 in the control memory register will accomplish this. By
setting func = 0, the user can specify a particular count and the marker memory will be
updated with the last grey value whose count is equal to (or just exceeds) the count of
interest.

The maximum count, and the grey value which it occurred at, are also updated during each
I/O cycle and stored in mode memory locations 0-3.

If the accumulated histogram is being computed, i.e. the EQ bit in the mode register is set,
then the maximum count register will be equal to the number of pixels scanned, and the grey
value will be the maximum grey level occurring in the image.

Reading and Writing the LUT:

Data input to and output from the LUT RAM is also controlled by CLK2 and STARTIOn.
On the falling edge of STARTIOn, the I/O cycle is initiated with the LUT RAM addresses
being read or written sequentially with each cycle of CLK2. This process is controlled by the
address counter in the controller block.

LUT read/write operations are defined by the io0 -1 bits in the control memory. Code 10 is
used to read the LUT RAM. Data will be read sequentially and output on the DO bus. To
write the LUT RAM, code 11 is used in the control memory. Input from the CI bus is
stored in successive addresses with each cycle of CLK2.

The LUT RAM can also be addressed from the DI bus. A typical application would be
histogram equalization. The LUT would contain the equalized transfer function generated
by transferring ACC RAM data to the LUT with EQ high. Setting the FN0 -FN1 bits for
histogram computation configures data from the DI bus to address both the ACC RAM and
the LUT. Equalized data is then output on the VDO bus. Histogram computation is taking
place concurrently. In this case CLK2 should be connected to CLK1 to achieve an
equalization rate equal to the pixel rate.

I/O SEQUENCES:
Read ACC, Read LUT, Transfer ACC to LUT

I/O operations can be divided into two groups: those that end before all 512 elements of
the ACC or LUT RAM have been accessed (short cycle) and those that end after all 512
elements have been accessed (long cycle). All I/O cycles are initiated by a high to low
transition on the STARTIOn input signal. AT must be low in each case.

The short cycle is terminated when STARTIOn is returned high before all elements of the
RAM have been read. The first data value appears on the DO pins three CLK2 cycles after
STARTIOn goes low. The IODV flag also goes high after three cycles, indicating that the

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 13 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

data is valid. After the desired number of memory elements have been read, the user returns
STARTIOn high. The I/O mode completes three cycles later and IODV returns low to
indicate the end of the I/O operation. As soon as IODV returns low, the processor returns
to the pixel processing mode specified by the mode register.

The long cycle is terminated without user intervention after all elements of the ACC or LUT
RAMs have been accessed. Again, valid data appears on the DO pins three CLK2 cycles
after STARTIOn goes low. In this case, IODV is high for 512 CLK2 cycles and goes low
after the last RAM element has been read. After IODV returns low, STARTIOn can remain
low or be raised high at any time without affecting the operation of the IA64250.

READING ACC/LUT
RAM OR TRANSFERING
ACC TO LUT:

Short I/O Cycle:

CLK2

STARTIO

D0

IODV

CLK2

DO

IODV

XXXX XXXX XXXX RAM0 RAM1 RAM2 XXXXXXXX

End of Long I/O Cycle:

RAM508 RAM509 RAM510 RAM511 XXXX XXXX XXXXXXXX

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 14 of 21 1-888-824-4184

IA64250 Data Sheet

RAM0

RAM1

RAM2

XXXX

XXXX

XXXX

XXXXXXXX

Histogram/Hough Transform Processor As of Production Ver. 01

WRITE LUT

The writing of data into the LUT RAM is similar to the operations described above, except
that the data to write into the RAM is placed on the CI bus when STARTIOn is low.
However, as described above, the processor will not return to the pixel processing mode
until IODV returns low.

The net result of this is that the IA64250 enters the I/O mode as soon as the STARTIOn
pin is pulled low and does not return to the pixel processing mode until IODV returns low.
The I/O mode will last N + 3 CLK2 cycles, where N is the number of RAM elements
written.

WRITING LUT RAM:

Short I/O Cycle:

STARTIO

CLK2

STARTIO

CI[7:0]

IODV

CLK2

CI

IODV

CLK2

STARTIO

Start of Long I/O Cycle:

RAM0 RAM1 RAM2 RAM3 RAM4 RAM5 RAM6RAM6

End of Long I/O Cycle:

CI

RAM508 RAM509 RAM510 RAM511 XXX XXXX XXXXXXXX

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 15 of 21 1-888-824-4184

IA64250 Data Sheet

RY

Histogram/Hough Transform Processor As of Production Ver. 01

PIXEL PROCESSING

(SMALL 2 x 2 IMAGE):

CLK1

RX.CY

CX

DV

DI

I(0,0) I(1,0) I(0,1) I(1,1) XXXXXXXX

F(I(0,0)) F(I(1,0)) F(I(01))F(I(01))

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 16 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

AC/DC Parameters:

Military (TA = -55 to 125 C, VDD = 4.5 to 5.5V). All times in ns.

SYMBOL PARAMETER MIN MAX

tCYCLE Minimum clock cycle time 60
tPWH Minimum clock pulse width HIGH 28
tPWL Minmum clock pulse width LOW 25
tDIS Input data setup time 25 0.38
tDIH Input data hold time 7 2.28
tOD Output delay 17.78
tWC Minimum WE cycle time 180
tPWW Minimum WE pulse width LOW 75
tAS AT Address setup time 75
tAH AT Address hold time 75
tCS Coefficient setup time 75
tCH Coefficient hold time 75
tADO Output delay from address valid 24.53
tWD Output Delay from WE 24.53

DC CHARACT ERISTICS:

Specified at VDD = 5V over the specified temperature and voltage ranges1.

SYMBOL PARAMETER CONDITION MIN TYP MAX UNIT

VIL Low level input voltage 0.8 V
VIH High level input voltage

Military temperature

range
IIN Input current VIN = VDD -150 200 uA
VOH High level output voltage IOH = -3.2 mA 2.4 4.5 V
VOL Low level output voltage IOL = 3.2 mA 0.2 0.4 V
IOS Output short circuit

current2
IDDQ Quiescent supply current
IDD Operating supply current tCYCLE = 50ns 200 mA
CIN Input capacitance Any input 5 pF
COUT Output capacitance Any output 10 pF

Notes:

1. Military temperature range is –55 to 125 C, +/- 10% power supply.

2. Not more than one output should be shorted at a time. Duration of short circuit test must not exceed
one second.

3. In power down mode.

2.25

VDD = Max, VO = VDD
VDD = Max, VO = 0V

3

VIN = VDD or VSS 15 mA

15

-5

130

-100

V

mA
mA

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 17 of 21 1-888-824-4184

IA64250 Data Sheet

t

PWH

PWL

PWHtPWL

tODt

t

CI

WC

CH

CS

Histogram/Hough Transform Processor As of Production Ver. 01

AC Characteristics:

Pixel Processing Operation:

t

t

DIH

CLK1

t

DIS

VDO

OD

I/O Timing:

CLK2

DIS

CI/STARTIO

t

DIH

Control Memory Timing – Writing Mode Data:

WE

ADDR

t

AS

t

PWW

t

AT

t

AS

t

CYCLE

t

t

WC

t

t

AH

t

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 18 of 21 1-888-824-4184

IA64250 Data Sheet

CH

CS

Histogram/Hough Transform Processor As of Production Ver. 01

Control Memory Timing – Reading and Writing Markers:

t

WC

WE

ADDR

AT

CI

t

AS

t

PWW

t

t

AS

t

AH

t

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 19 of 21 1-888-824-4184

IA64250 Data Sheet

MILLIMETER

INCH

Histogram/Hough Transform Processor As of Production Ver. 01

Packaging Information

68 PLCC Package:

.254X45°1.14X45°

SEE DETAIL A

PIN 1 IDENTIFIER

b

E1 E

e

68 PLCC, (17X17 pins):

Symbol

A 4.02 5.08 0.165 0.2

A1 2.29 3.3 0.09 0.13

b 0.331 0.53 0.013 0.021

c 0.2 0.008

D 25.02 25.27 0.985 0.995

D1 24.13 24.33 0.95 0.958

E 25.02 25.27 0.985 0.995

E1 24.13 24.33 0.95 0.958

e 1.27 BSC 0.05

D1

A

D

DETAIL A

A1

SEATING PLANE

c

MIN NOM MAX MIN NOM MAX

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 20 of 21 1-888-824-4184

IA64250 Data Sheet

Histogram/Hough Transform Processor As of Production Ver. 01

Ordering Information:

Part Number Temperature Grade Package Description

IA64250-PLC68M Military 68 lead Plastic Leaded Chip Carrier

Cross Reference to Original Manufacturer Part Numbers:

innovASIC Part Number LSI Part Number

IA64250-PLC68M q L64250JC15

q L64250JC20

Copyright  2000 ENG211001219-01 www.innovasic.com

innovASIC Customer Support:

 The End of Obsolescence Page 21 of 21 1-888-824-4184
