Datasheet HSP45256 Datasheet (Intersil Corporation)

HSP45256

Data Sheet May 1999 File Number

Binary Correlator

The Intersil HSP45256 is a high-speed, 256 tap binary
correlator. It can be configured to perform one-dimensional
or two-dimensional correlations of selectable data precision
and length. Multiple HSP45256’s can be cascaded for
increased correlation length. Unused taps can be masked
out for reduced correlation length.

The correlation array consists of eight 32-tap stages. These
may be cascaded internally to compare 1, 2, 4 or 8-bit input
data with a 1-bit reference. Depending on the numberofbits
in the input data, the length of the correlation can be up to
256, 128, 64, or 32 taps. The HSP45256 can also be
configured as two separate correlators with window sizes
from 4 by 32 to 1 by 128 each. The mask register can be
used to prevent any subset of the 256 bits from contributing
to the correlation score.

The output of the correlation array (correlation score) feeds
the weight and sum logic, which gives added flexibilitytothe
data format. In addition, an offset register is providedsothat
a preprogrammed value can be added to the correlation
score. This result is then passed through a user
programmable delay stage to the cascade summer. The
delay stage simplifies the cascading of multiple correlators
by compensating for the latency of previous correlators.

The Binary Correlatorisconfigured by writing a set of control
registers via a standard microprocessor interface. Tosimplify
operation, both the control and reference registers are
double buffered. This allows the user to load new mask and
reference data while the current correlation is in progress.

2814.4

Features

• Reconfigurable 256 Stage Binary Correlator

• 1-Bit Reference x 1, 2, 4, or 8-Bit Data

• Separate Control and Reference Interfaces

• 25.6, 33MHz Versions

• Configurable for 1-D and 2-D Operation

• Double Buffered Mask and Reference

• Programmable Output Delay

• Cascadable

• Standard Microprocessor Interface

Applications

• Radar/Sonar

• Spread Spectrum Communications

• Pattern/Character Recognition

- Error Correction Coding

Ordering Information

TEMP.

PART NUMBER

HSP45256JC-25 0 to 70 84 Ld PLCC N84.1.15
HSP45256JC-33 0 to 70 84 Ld PLCC N84.1.15
HSP45256GC-25 0 to 70 85 Ld PGA G85.A
HSP45256GC-33 0 to 70 85 Ld PGA G85.A
HSP45256JI-25 -40 to 85 84 Ld PLCC N84.1.15
HSP45256JI-33 -40 to 85 84 Ld PLCC N84.1.15

RANGE (oC) PACKAGE

PKG.

NO.

Block Diagram

DIN0-7

DREF0-7

DCONT0-7

A0-2

CASIN0-12

256 TAP

CORRELATION

ARRAY

CONTROL

1

DOUT

DREFOUT
CSCORE

WEIGHT

AND SUM

DELAY

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

http://www.intersil.com or 407-727-9207

MUX

CASCADE

SUMMER

| Copyright © Intersil Corporation 1999

DOUT0-7

AUXOUT0-8

CASOUT0-12

Pinouts

HSP45256

85 PIN PGA

BOTTOM VIEW

L

DREF0 GND

K

DREF2 A0 DCONTDCONTRLOAD CLOAD

J

H

DREF4 AUXOUT AUXOUTDREF5

G

DIN0 DREF7 DIN1 DOUT6 DOUT5

F

DIN3 DIN2 DOUT4DREF6 DOUT7 DOUT3

E

D

C

CLK CASIN0 CASIN CASIN OEC CASOUT

B

A

2457
1234567891011

TXFR A2 DCONT7 DCONT1 DCONT0DCONT3 AUX AUX AUX

V

CC

A1 DCONT DCONT GNDDREF1DREF3

V

CC

PIN 8 12

CASIN6CASIN1 CASINCASIN3GND CASOUT

10

62

54

CASOUT

CASOUT

29

CASINCASINCASINCASIN CASIN CASIN GND CASOUT

11

1

CASOUTCASOUT

0

OUT8 OUT7 OUT5

OEA

OUT6 OUT4

V

CC

DOUT0 DOUT1 DOUT2DIN4 DIN6DIN5

4

CASOUT

3

5

AUXAUX

GNDDIN7 CASOUT

CASOUTINDEX

9

CASOUTCASOUTCASOUT

7

AUX

OUT3

AUX

OUT2

01

12

11

10

8

85 PIN PGA

TOP VIEW

2173 4 5 6 8 9 10 11

2

GND

CLK

DIN7

DIN4

DREF

6

DIN0

DREF

5

DREF

3

DREF

2

DREF

0

CASIN

CASIN

CASIN

DREF

DREF

DREF

CASIN

A

B

C

D

E

F

G

H

J

K

L

4

1

0

V

CC

DIN5

DIN3

7

4

1

V

CC

GND

CASIN

CASIN

INDEX

5

3

PIN

DIN6

DIN2

DIN1

R

LOAD

TXFR

CASIN

CASIN

LOAD

A2

CASIN

7

CASIN

6

CASIN

C

DCONT

10

A1

A0

CASIN

CAS

9

OUT2

CASIN

8

DCONT

DCONT

DCONT

7

CAS
OUT

11

CAS

OUT1

OEC

12

DCONT

5

DCONT

6

DCONT

1

CAS

OUT3

CAS

OUT4

4

OEA

2

DCONT

3

CAS

OUT5

CAS

OUT6

DOUT0

DOUT

V

AUX

OUT6

AUX

0

OUT8

4

CC

GND

CAS

OUT7

CAS

OUT9

GND

DOUT

DOUT

DOUT

AUX

OUT1

GND

AUX

OUT4

AUX

OUT7

CAS

OUT8

CAS

OUT10

CAS

OUT11

CAS

OUT12

DOUT2

DOUT

7

6

3

DOUT

5

AUX

OUT0

AUX

OUT2

AUX

OUT3

AUX

OUT5

2

HSP45256

Pinouts

(Continued)

CASIN1
CASIN0

GND

CLK

V
DIN7
DIN6
DIN5
DIN4
DIN3
DIN2
DIN1
DIN0

DREF7
DREF6
DREF5
DREF4
DREF3
DREF2
DREF1
DREF0

84 PIN PLCC

TOP VIEW

CASIN2

CASIN3

CASIN4

CASIN5

CASIN6

CASIN7

CASIN8

CASIN9

CASIN10

CASIN11

CASIN12

OEC#

CASOUT0

CASOUT1

CASOUT2

CASOUT3

CASOUT4

CASOUT5

GND

CASOUT7

CASOUT6

111098765432184838281807978777675

12
13
14
15
16

CC

17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53

74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54

CASOUT8
CASOUT9
CASOUT10
CASOUT11
GND
CASOUT12
DOUT0
DOUT1
DOUT2
DOUT3
DOUT4
V

CC

DOUT5
DOUT6
DOUT7
AUXOUT0
AUXOUT1
AUXOUT2
AUXOUT3
GND
AUXOUT4

GND

TXFR

CLOAD

A2A1A0

DCONT7

DCONT6

DCONT5

DCONT4

DCONT3

DCONT2

DCONT1

DCONT0

OEA

AUXOUT8

AUXOUT7

AUXOUT5

AUXOUT6

CC

V

RLOAD

3

HSP45256

Pin Descriptions

SYMBOL PLCC PIN NUMBER TYPE DESCRIPTION

V

CC

GND 14, 35, 55, 70, 77 Ground.

DIN0-7 17-24 I The DIN0-7 bus consists of eight single data input pins. The assignment of the active pins is

DOUT0-7 60-62, 64-68 O The DOUT0-7 bus is the data output of the correlation array.The format of the output is de-

CLK 15 I System Clock. Positive edge triggered.

CASIN0-12 1-13 I CASIN0-12 allows multiple correlators to be cascaded by connecting CASOUT0-12 of one

CASOUT0-12 69, 71-76, 78-83 O CASOUT0-12 is the output correlation score. This value is the delayed sum of all the 256

OEC 84 I OEC is the output enable for CASOUT0-12. When OEC is high, the output is three-stated.

TXFR 36 I TXFR is a synchronous clock enable signal that allows the loading ofthe referenceandmask

DREF0-7 25-32 I DREF0-7 is an 8-bit wide data reference input. This is the input data bus used to load the

RLOAD 34 I RLOADenables loading of the reference registers. Data on DREF0-7 is loaded into the pre-

DCONT0-7 41-48 I DCONT0-7 is the control data input which is used to load the mask bit for each tap, as well

CLOAD 37 I CLOAD enables the loading of the data on DCONT0-7. The destination of this data is con-

A0-2 38-40 I A0-2 is a 3-bit address that determines what function will be performed when CLOAD is ac-

AUXOUT0-8 50-54, 56-59 O AUXOUT0-8 is a 9-bit bus that provides either the data reference output in the single corre-

OEA 49 I The OEA signal is the output enable for the AUXOUT0-8 output. When OEA is high, the out-

16, 33, 63 The +5V power supply pin.

determined by the configuration. Data is loaded synchronous to the rising edge of CLK. DIN0
is the LSB.

pendent on the window configuration and bit weighting. DOUT0 is the LSB.

correlator to CASIN0-12 of another. The CASIN bus is added internally to the correlation
score to form CASOUT. CASIN0 is the LSB.

taps of one chip and CASIN0-12. When the part is configured to act as two independent cor­relators, CASOUT0-8 represents the correlation score for the first correlator while the sec­ond correlation score is available on the AUXOUT0-8 bus. In this configuration, the
cascading feature is no longer an option. CASOUT0 is the LSB.

Processing is not interrupted by this pin (active low).

inputs from the preload register to the correlation array.Data is transferredonthe rising edge
of CLK while TXFR is low (active low).

reference data. RLOAD going active initiates the loading of the reference registers. This in­put bus is used to load the reference registers of the correlation array.The manner in which
the reference data is loaded is determined by the window configuration. If the window con­figuration is 1 x 256, the reference bits are loaded one at a time over DREF7. When the
HSP45256 is configured as an8x32array,thedata is loaded into all stages in parallel. In
this case, DREF7 is the reference data for the first stage and DREF0 is the reference data
for the eighth stage. The contents of the reference data registers are not affected by chang­ing the window configuration. DREF0 is the LSB.

load registers on the rising edge of RLOAD. This data is transferred into the correlation array
by TXFR (active low).

as the configuration registers. The mask data is sequentially loaded into the eight stages in
the same manner as the reference data. DCONT0 is the LSB.

trolled by A0-2 (active low).

tive.This address bus is set up with respect to the rising edge of the load signal, CLOAD. A0
is the LSB.

lation configuration or the 9-bit correlation score of the second correlator, in the dual corre­lator configuration. When the user programs the chip to be two separate correlators, the
score of the second correlator is output on this bus. When the user has programmed the chip
to be one correlator, AUXOUT0-7 represents the reference data out, with the state of
AUXOUT8 undefined. AUXOUT0 is the LSB.

put is disabled. Processing is not interrupted by this pin (active low).

4

Block Diagram

HSP45256

A(2:0)

CLOAD

DCONT(7:0)

RLOAD
TXFR

DIN7

DREF7

DIN6

DREF6

>

>

>

>

R
E
G

R
E
G

R
E
G

R
E
G

DECODE

TC

DO7

CONFIG(4:0)

RO7

CONFIG
OFFAL
OFFAM
DELAY
OFFBL
OFFBM

MASK

(001)

R
E

G

>

(000)

8

R
E
G

>

32 TAP CORRELATOR STAGE

MR7

32 TAP CORRELATOR STAGE

MR6

6 CONFIG(4:0)

R
E
G

>

DO7
RO7

+

R
E
G

>

DO6
RO6

5

TC

DATA OUT

RO7

CORRELATION

SCORE OUT

CO7

DATA OUT

RO6

+

R

E

G

>

CO6

DO1

DIN0

DREF0

CLK

CASIN(12:0)
OEA
OEC

R
E
G

R
E
G

CONFIG(4:0)

RO1

>

>

32 TAP CORRELATOR STAGE

MR0

NOTE: All registers clocked with CLK unless otherwise specified.

CORRELATOR BLOCK DIAGRAM

5

DO0
RO0

RO0

+

R
E
G

>

MUX

ARRAY

>

G

E

R

CO0

REFERENCE OUT

CASIN(12:0)
OEA
OEC
DOUT(7:0)

HSP45256

Block Diagram

OFFSET

REGISTER A

OFFAM
OFFAL
OFFBM

OFFBL
DELAY

CONFIG(4:0)

CORRELATION

SCORE OUT

CO7

(Continued)

(010)

(011)

(101)

(110)

R
E
G

>

R
E
G

>

R
E
G

>

R
E
G

>

5

8

1

8

OFFSET

REGISTER B

R
E

G

>

CO6

CO0

REFERENCE OUT

CASIN(12:0)
OEA

OEC
DOUT(7:0)

WEIGHT

CASCADE
REGISTER

4

DELAY

R
E
G

>

R
E
G

>

SUM

R
E
G

>

RO(0-7)

PROGRAMMABLE

>

>

RLOAD

R
E

G

R
E

G

DELAY

(100)

CONFIG(4:0)

CASOUT(12:0)

R

+

E
G

>

OEA

OEC

AUXOUT(8:0)

DOUT(7:0)

NOTE: All registers clocked with CLK unless otherwise specified.

6

HSP45256

Functional Description

The correlation array consists of eight 32-bit stages. The first
stage receives data directly from input pin DIN7. The other
seven stages receive input data from either an external data
pin, DIN0-6, or from the Shift Register output of the previous
stage, as determined by the Configuration Register. When
the part is configured as a single correlator the sum of
correlation score, Offset Register and cascade input
appears on CASOUT0-12. Delayed versions of the data and
reference inputs appear on DOUT0-7 and AUXOUT0-7,
respectively. The input and output multiplexers of the
correlation array are controlled together; for example, in a 1
x 256 correlation, the input data is loaded into DIN7 and the
output appears on DOUT7. The configuration of the data
bits, the length of the correlation (and in the two-dimensional
data, the number of rows), is commonly called the
correlation window. A top level Block Diagram of the single
correlator configuration is shown in Figure 1. Compare the
single correlator configuration data output and correlation
output to the top level Block Diagram of the dual correlator
configuration shown in Figure 2.

DIN(7:0)

DREF(7:0)

OFFA

8 32-BIT

CORRELATORS

• • • • • • • • • • • •

SUM

CORR SCORE

WEIGHT

AND
SUM

DOUT(7:0)

AUXOUT(7:0)

Correlator Array

The core of the HSP45256 is the correlation array, which
consists of eight 32-tap stages. A single correlator cell
consists of an XNOR gate for the individual bit comparison;
i.e., if the data and reference bits are either both high or both
low, the output of the correlator cell is high. Figure 3 details
the circuitry of a single correlation cell and Figure 4 shows
the timing for that single correlation cell. In addition, two
latches, one for the reference and one for the control data
path are contained in this cell. These latches are loaded
from the Preload Registers on the rising edge of CLK when
TXFR is low so that the reference and mask values are
updated without interrupting data processing.

The mask function is implemented with an AND gate. When
a mask bit is a logic low, the corresponding correlator cell
output is low.

DIN(7:4)

DREF(7:4)

OFFA

4 32-BIT

CORRELATORS

• • • • • • • • • • • •

SUM

CORR SCORE

WEIGHT

AND
SUM

DELAY

= 0000

DOUT(7:4)

DELAY

CASIN(12:0) CASOUT(12:0)

FIGURE 1. SINGLE CORRELATOR CONFIGURATION

SUM

7

CASIN(12:0)

DIN(3:0) DOUT (3:0)

DREF(3:0)

OFFB

FIGURE 2. DUAL CORRELATOR CONFIGURATION

SUM

CORRELATOR #1

4 32-BIT

CORRELATOR

• • • • • • • • • • • •

SUM

CORR SCORE

WEIGHT

AND
SUM

CORRELATOR #2

CASOUT(8:0)

AUXOUT(8:0)

HSP45256

The function performed by one correlation cell is:

(D

XNOR R

i,n

) AND M

i,n

i,n

where:
D

= Bit i of data register n

i,n

R

= Bit i of reference register n

i,n

M

= Bit i of mask register n

i,n

The reference and mask bits are loaded sequentially, N bits
at a time, where N depends on the current configuration (see
Tables 2 and 9). New reference data is loaded on the rising
edge of

RLOAD and new mask data is loaded on the rising

A

DREF

RLOAD

DCONT
(MASK)

CLOAD

TXFR
DAT A

CLK

R
E
G

>

R
E
G

>

R
E
G

>

B

R
E
G

>

R
E

G

>

edge of

CLOAD. The mask and reference bits are stored
internally in Shift Registers, so that the mask and reference
information that was loaded most recently will be used to
process the newestdata. When new information is loaded in,
the previous contents of the mask and reference bits are
shifted over by one sample, and the oldest information is
lost. There are no registers in the multiplexer array (see
Block Diagram), so the data on DOUT0-7 corresponds to the
data in the last element of the correlation array. When
monitoring DOUT0-7, AUXOUT0-8, and REFOUT0-7, only
those bits listed in Table 9 are valid.

DREFOUT

DCONTOUT

DATAOUT

DCONT

CLOAD

DREF

RLOAD

TXFR

DAT A

COROUT

FIGURE 3. CORRELATION CELL BLOCK DIAGRAM

DATA CONTROL

DR8DR7DR6DR5DR4DR3DR2DR1DR0

A

B

DR7DR6DR5DR4DR3DR2DR1DR0

DR7DR6DR5DR4DR3DR2DR1DR0DR-1

D7D6D5D4D3D2D1D0D-1

CLK

FIGURE 4. CORRELATION CELL TIMING DIAGRAM

8

HSP45256

Weight and Sum Logic

The Weight and Sum Logic provides the bit weighting and
the final correlator score from the eight stages of the
correlation array. For a 1 x 256 1-D configuration, the outputs
of each of the stages are given a weight of 1 and then added
together. In a 8 x 32 (8-bit data) configuration, the output of
each stage will be shifted so that the output data represents
an 8-bit word, with stage seven being the MSB.

The 13-bit Offset Register is loaded from the control data
bus. Its output is added to the correlation score obtained
from the correlator array. This sum then goes to the
programmable delay register data input.

When the chip is configured as dual correlators, the user has
the capability of loading two different offset values, one for
each of the two correlators.

The Programmable Delay Register sets the number of
pipeline stages between the output of the weight and sum
logic and the input of the Cascade Summer. This delay
register is used to align the correlation scores of multiple
correlators in HSP45256 cascaded configurations (see
Applications Section). The number of delays is
programmable from 1 to 16, allowing for up to 16 correlators
to be cascaded. When the HSP45256 is configured as dual
correlators, the delay must be set to 0000, which specifies a
delay of 1.

Control Registers

The 3-bit address value, A0-2, is used to determine which
internal register will be loaded with the data on DCONT0-7.
The function is initiated when
register is loaded on the rising edge of
indicates the function associated with each address. Tables
2 - 8 define the function of the bits in each of the control
registers.

TABLE 1. ADDRESS MAPPING

A2 A1 A0 DESTINATION

0 0 0 Mask Register
0 0 1 Configuration Register
0 1 0 Offset Register A-Most Significant Bits
0 1 1 Offset Register A-Least Significant Bits
1 0 0 Programmable Delay Register
1 0 1 Offset Register B-Most Significant Bits
1 1 0 Offset Register B-Least Significant Bits
1 1 1 Reserved

CLOAD is brought low, and the

CLOAD. Table 1

Cascade Summer

The Cascade Summer is used for cascading several
correlator chips together. The value present on this bus
represents the correlation score from the previous
HSP45256 that will be summed with the current score to
provide the final correlation score. When several correlator
chips are cascaded, the CASOUT0-12 of each correlator is
connected to the CASIN0-12 of the next correlator in the
chain. The CASIN0-12 of the first chip is tied low. The
following function represents the correlation score present
on CASOUT0-12 of each correlator:

CASOUT(n) = (W7 x CO7)(n-Delay) + (W6 x CO6)(n-Delay) +

(W5 x CO5)(n-Delay) + (W4 x CO4)(n-Delay) +
(W3 x CO3)(n-Delay) + (W2 x CO2)(n-Delay) +
(W1 x CO1)(n-Delay) + (W0 x CO0)(n-Delay) +
Offset (n-Delay) + CASIN.

where:
CO0-CO7 are the correlation score outputs out of the

correlation stages; W0-W7 is the weight givento each stage;
n-Delay represents the delay on the weighted and summed
correlation score through the ProgrammableDelay Register;
Offset is the value programmed into the Offset register;
CASIN is the cascade input.

9

HSP45256

TABLE 2. MASK REGISTER

DESTINATION ADDRESS = 0 (000)

BIT

POSITIONS FUNCTION DESCRIPTION

7-0 Mask Register

Bit Enable

BIT

POSITION FUNCTION DESCRIPTION

7-6 Reserved Reserved; Program to zero.

5 TC Configures correlator for twos complement input format, where the position of the MSB is depends on

4 CONFIG(4) CONFIG4: The state of CONFIG4 configures the HSP45256 as either one or two correlators. When

3-2 CONFIG(3:2): CONFIG(3:2): Control the number of data bits to be correlated. See Table 9.
1-0 CONFIG(1:0) CONFIG(1:0):CONFIG1 and CONFIG0 represent the length of the correlation window as indicated in

MR(7:0): Mask Register. When mask register bit N = 1, the corresponding reference register bit is en­abled. Mask register data is loaded from the DCONT(7:0) bus into a holding register on the rising edge
of CLOAD and is written to the mask register on the rising edge of TXFR.

TABLE 3. CONFIGURATION REGISTER

DESTINATION ADDRESS = 1 (001)

the current configuration. TC = 1 is twos complement; TC = 0 is offset binary.

CONFIG4 = 0, the HSP45256 is configured as one correlator with the correlation score available on
CASOUT0-12.

When CONFIG4 = 1, the HSP45256 is configured as dual correlators with the first correlators score
available on CASOUT0-8 and the second score available on AUXOUT0-8. When the chip is configured
as dual correlators, the Programmable Delay must be set to 0000 for a delay of 1.

Table 9.

TABLE 4. MS OFFSET REGISTER A

DESTINATION ADDRESS = 2 (010)

BIT

POSITION FUNCTION DESCRIPTION

7-5 Reserved Reserved. Program to zero.
4-0 Offset Register A MSB OFFA(12:8): Most significant bits of Offset Register A. This is the register used in single correlator

mode.

TABLE 5. LS OFFSET REGISTER A

DESTINATION ADDRESS = 3 (011)

BIT

POSITION FUNCTION DESCRIPTION

7-0 Offset Register A LSB OFFA(7:0): Least significant bits of Offset Register A.

TABLE 6. PROGRAMMABLE DELAY REGISTER

DESTINATION ADDRESS = 4 (100)

BIT

POSITION FUNCTION DESCRIPTION

7-4 Reserved Reserved. Program to zero.
3-0 Programmable Delay PDELAY(3:0): Controls amount of delay from the weight and sum logic to the cascade summer. The

number of delays is 1-16, with PDELAY = 0000 corresponding to a delay of 1 and PDELAY = 1111 cor­responding to a delay of 16.

10

HSP45256

TABLE 7. MS OFFSET REGISTER B

DESTINATION ADDRESS = 5 (101)

BIT

POSITION FUNCTION DESCRIPTION

7-1 Reserved Reserved. Program to zero.

0 Offset Register B MSB OFFB8: Most significant bit of Offset Register B. In dual correlator mode, this register is used for the

correlator whose output appears on the AUXOUT pins.

TABLE 8. LS OFFSET REGISTER B

DESTINATION ADDRESS = 6 (110)

BIT

POSITION FUNCTION DESCRIPTION

7-0 Offset Register B LSB OFFB0-7: Least significant bits of Offset Register B.

11

TABLE 9. CONFIGURATION SETUP

CONFIGURATION NO.

43210 DINDREF DOUT AUXOUT CASOUT CO7 CO6 CO5 CO4 CO3 CO2 CO1 CO0

00000 1 1 1 256 - 7 7 7 7 12-0 11111111

00001 1 1 2 128 - 7, 3 7, 3 7, 3 7, 3 12-0 11111111

OF

CORRE-

LATORS

DATA

BITS ROWS LENGTH

CORRE-

LATOR

ACTIVE INPUTS ACTIVE OUTPUTS OUTPUT WEIGHTING

12

00010 1 1 4 64 -7, 5, 3, 17, 5, 3, 17, 5, 3, 17, 5, 3, 112-0 11111111

00011 1 1 8 32 - 7-0 7-0 7-0 7-0 12-0 11111111

00101 1 2 1 128 - 7, 3 7 7, 3 7, 3 12-0 22221111

00110 1 2 2 64 -7, 5, 3, 17, 57, 5, 3, 17, 5, 3, 112-0 22221111

00111 1 2 4 32 - 7-07, 6, 5, 47-0 7-0 12-0 22221111

01010 1 4 1 64 -7, 5, 3, 17 7, 5, 3, 17, 5, 3, 112-0 88224411

01011 1 4 2 32 - 7-0 7, 6 7-0 7-0 12-0 88224411

01111 1 8 1 32 - 7-0 7 7-0 7-0 12-0 128 8 32 4 64 2 16 1

10001 2 1 1 128 AB7

3

10010 2 1 2 64 AB7, 5

3, 1

10011 2 1 4 32 AB7-4

3-0

10110 2 2 1 64 AB7, 5

3, 1

10111 2 2 2 32 AB7-4

3-0

7, 5
3, 1

7-4
3-0

7, 6
3, 2

7
3

7
3

7, 5
3, 1

7-4
3-0

7, 5
3, 1

7-4
3-0

7
3

8-0

8-0

8-0

8-0

8-0

-

-

-

-

-

12-0

-

12-0

-

12-0

-

12-0

-

12-0

-

1-1- 1-1- -

1-1- 1-1- -

1-1- 1-1- -

2-2- 1-1- -

2

2

1

-

-

1

-

-

-

1

1 -1

1- 1 -1

-

1

1 -1

-

2

2 - 1-1

-

-

2

2-1

-

1

-

1

-

1

-

1

HSP45256

11011 2 4 1 32 AB7-4

3-0

7
3

7-4
3-0

8-0

-

12-0

-

8-2- 4-1- -

-

8

2 -4

-

1

HSP45256

During reference register loading, the 8-bits, DREF0-7 are
used as reference data inputs. The falling edge of
initiates reference data loading; when

RLOAD returns high,

RLOAD

the data on DREF0-7 is latched into the selected correlation
stages. The active bits on DREF0-7 are determined by the

During initialization, the loading configuration for the
reference data is set by the user. Table 9 shows the loading
options. These load controls specify whether the reference
data for a given stage comes from the shift register output of
the previous stage or from an external data pin.

current configuration.
The window configuration is determined by the state of control

signals upon programming the Control Register. Table 9
represents the programming information required for each
window configuration. In Table 9, note that the data listed for
Output Weighting refers to the weights given to each of the
Correlation Sum Outputs (CO0-7 in the Block Diagram).

TABLE 10. CORRELATION SCORE FORMULAS FOR SINGLE CORRELATOR CONFIGURATIONS

CONFIGURATION

BITS x ROWS x

FIGURE NUMBER

Figure 5 1 x 1 x 256 256 CS=CO7+CO6+CO5+CO4+CO3+CO2+CO1+CO0
Figure 6 1 x 2 x 128 256 CS=CO7+CO6+CO5+CO4+CO3+CO2+CO1+CO0
Figure 7 1 x 4 x 64 256 CS=CO7+CO6+CO5+CO4+CO3+CO2+CO1+CO0
Figure 8 1 x 8 x 32 256 CS=CO7+CO6+CO5+CO4+CO3+CO2+CO1+CO0
Figure 9 2 x 1 x 128 384 CS=2(CO7+CO6+CO5+CO4)+CO3+ CO2+CO1+CO0
Figure 10 2 x 2 x 64 384 CS=2(CO7+CO6+CO5+CO4)+CO3+CO2+CO1+CO0
Figure 11 2 x 4 x 32 384 CS=2(CO7+CO6+CO5+CO4)+CO3+CO2+CO1+CO0
Figure 12 4 x 1 x 64 960 CS=8(CO7+CO6)+4(CO5+CO4)+2(CO3+CO2)+CO1+CO0
Figure 13 4 x 2 x 32 960 CS=8(CO7+CO6)+4(CO5+CO4)+2(CO3+CO2)+CO1+CO0
Figure 14 8 x 1 x 32 8160 CS=128C07+64CO6+32C05+16CO4+8CO3+4CO2+2CO1+CO0
Figure 15 1 x 1 x 128

Figure 16 1 x 2 x 64

Figure 17 1 x 4 x 32

Figure 18 2 x 1 x 64

Figure 19 2 x 2 x 32

Figure 20 4 x 1 x 32

LENGTH

1 x 1 x 128

1 x 2 x 64

1 x 4 x 32

2 x 1 x 64

2 x 2 x 32

4 x 1 x 32

HIGHEST POSSIBLE

TOTAL CORRELA-

TION SCORE CORRELATION SCORE

128 CS=CO7+CO6+CO5+CO4CS=CO31CO2+CO1+CO0

128 CS=CO7+CO6+CO5+CO4CS=CO31CO2+CO1+CO0

128 CS=CO7+CO6+CO5+CORCS=CO31CO2+CO1+CO0

192 CS=2(CO7+CO6)+CO5+CO4CS=(CO3+CO2)+CO1+CO0

192 CS=2(CO7+CO6)+CO5+CO4CS=(CO3+CO2)+CO1+CO0

480 CS=8CO7+4CO6+2CO5+CO4CS= 8CO3+4CO2+2CO1+CO0

Applications

There are 10 single correlator configurations possible with
the HSP45256. There are six dual correlator configurations
possible with the HSP45256. Table 10 details the
configuration (bits x rows x length) and the maximum
correlation sums of all combinations.

Single Correlator Configurations

1-Bit Data, Single Row, 256 Samples Configuration

A 1 x 256 (1-D configuration) correlation requires only 1
HSP45256. To initialize the correlator, all the reference bits,
control bits, the delay value of the variable delay, and the
window configuration must be specified. Table 11 details
these settings for the 1-bit data, 256 Samples Configuration.
Figure 5 illustrates the data flow through the correlator.

13

TABLE 11. REGISTER CONTENTS FOR 1 X 256 CORRELATOR

WITH EQUAL WEIGHTING

A0-2 DCONT0-7 NOTES

001 00000000 1 256-tap correlator: 1 x 256 window con-

figuration, reference loaded from DREF7,
eight stages weighted equally, DIN 7 and
DOUT7 are the data input and output, re-

spectively.
010 000000f00 Offset Register A = 0.
011 00000000
100 00000000 Programmable Delay = 0.
101 00000000 Offset Register B = 0 (Loading of this reg­110 00000000

ister optional in this mode).

HSP45256

The loading of the Reference and Mask Registers may be
done simultaneously by setting A0-2 = 000, setting the
DREF and DCONT inputs to their proper values and pulsing
RLOAD and CLOAD low. In this configuration, DREF7 loads
the reference data and DCONT7 loads the mask
information; both sets of data are loaded serially. It will take
256 load pulses (
256

CLOAD pulses to load the mask array.Upon completion

of the mask and register loading,

RLOAD) to load the reference array, and

TXFR is pulsed low, which
transfers the reference and control data from the preload
registers to the Reference and Mask Registers, updating the
data that will be used in the correlation. Reference and mask
data can be loaded more quickly by configuring the
correlator as an 8 row by 32 sample array, loading the bits
eight at a time, then changing the configuration back to 1 x
256 to perform the correlation.

REF <7>

DATA <7>

CS = (CO7+CO6+CO5+CO4+CO3+CO2+CO1+CO0)

FIGURE 5. 1-BIT, 1 ROW OF 256 TAPS

7
6
5
4
3
2
1
0

REFOUT <7>
DATAOUT <7>

Other 1-Bit Configurations

1-Bit, Dual Row, 128 Sample Configuration

1-Bit, Quad Row, 64 Sample Configuration

REF <7>

DATA <7>

REF <5>

DATA <5>

REF <3>

DATA <3>

REF <1>

DATA <1>

CS = (CO7+CO6+CO5+CO4+CO3+CO2+CO1+CO0)

FIGURE 7. 1-BIT, 4 ROWS OF 64 TAPS

7
6

5

4

3

2

1

0

REFOUT <7>
DATAOUT <7>

REFOUT <5>
DATAOUT <5>

REFOUT <3>
DATAOUT <3>

REFOUT <1>
DATAOUT <1>

1-Bit, Octal Row, 32 Sample Configuration

REF <7>

DATA <7>

REF <6>

DATA <6>

REF <5>

DATA <5>

REF <4>

DATA <4>

REF <3>

DATA <3>

REF <2>

DATA <2>

REF <1>

DATA <1>

REF <0>

DATA <0>

CS = (CO7+CO6+CO5+CO4+CO3+CO2+CO1+CO0)

FIGURE 8. 1-BIT, 8 ROWS OF 32 TAPS

7

6

5

4

3

2

1

0

REFOUT <7>
DATAOUT <7>

REFOUT <6>
DATAOUT <6>

REFOUT <5>
DATAOUT <5>

REFOUT <4>
DATAOUT <4>

REFOUT <3>
DATAOUT <3>

REFOUT <2>
DATAOUT <2>

REFOUT <1>
DATAOUT <1>

REFOUT <0>
DATAOUT <0>

2-Bit Configurations

REF <7>

DATA <7>

REF <3>

DATA <3>

CS = (CO7+CO6+CO5+CO4+CO3+CO2+CO1+CO0)

7
6
5
4

3
2
1
0

REFOUT <7>
DATAOUT <7>

REFOUT <3>
DATAOUT <3>

FIGURE 6. 1-BIT, 2 ROWS OF 128 TAPS

14

2-Bit, Single Row, 128 Sample Configuration

REF <7>

DATA <7>

DATA <3>

CS = 2(CO7+CO6+CO5+CO4)+(CO3+CO2+CO1+CO0)

FIGURE 9. 2 BITS, 1 ROW OF 128 TAPS

7

6

5

4

3

2

1

0

REFOUT <7>
DATAOUT <7>

REFOUT <3>
DATAOUT <3>

HSP45256

2-Bit Data, Dual Row, 64 Samples

REF <7>

DATA <7>

REF <5>

DATA <5>

DATA <3>

DATA <1>

CS = 2(CO7+CO6+CO5+CO4)+(CO3+CO2+CO1+CO0)

FIGURE 10. 2-BITS, 2 ROWS OF 64 TAPS

7

6
5

4

3

2
1

0

REFOUT <7>
DATAOUT <7>

REFOUT <5>
DATAOUT <5>

REFOUT <3>
DATAOUT <3>

REFOUT <1>
DATAOUT <1>

4-Bit Configurations

4-Bit, Single Row, 64 Sample Configuration

REF <7>

DATA <7>

DATA <5>

DATA <3>

DATA <1>

CS = 8(CO7+CO6)+4(CO5+CO4)+2(CO3+CO2)+(CO1+CO0)

7

6

5

4

3

2

1

0

REFOUT <7>
DATAOUT <7>

REFOUT <5>
DATAOUT <5>

REFOUT <3>
DATAOUT <3>

REFOUT <1>
DATAOUT <1>

2-Bit, Quad Row, 32 Sample Configuration

REF <7>

DATA <7>

REF <6>

DATA <6>

REF <5>

DATA <5>

REF <4>

DATA <4>

DATA <3>
DATA <2>

DATA <1>
DATA <0>

CS = 2(CO7+CO6+CO5+CO4)+(CO3+CO2+CO1+CO0)

7
6

5
4

3
2

1
0

FIGURE 11. 2-BITS, 4 ROWS OF 32 TAPS

REFOUT <7>
DATAOUT <7>
REFOUT <6>
DATAOUT <6>

REFOUT <5>
DATAOUT <5>

REFOUT <4>
DATAOUT <4>

REFOUT <3>
DATAOUT <3>

REFOUT <2>
DATAOUT <2>

REFOUT <1>
DATAOUT <1>
REFOUT <0>
DATAOUT <0>

4-Bit Dual Row, 32 Sample Configurations

REF <7>

DATA <7>

REF <6>

DATA <6>

DATA <5>

DATA <4>

DATA <3>

DATA <2>

DATA <1>

DATA <0>

CS = 8(CO7+CO6)+4(CO5+CO4)+2(CO3+CO2)+(CO1+CO0)

7

6

5

4

3

2

1

0

REFOUT <7>
DATAOUT <7>

REFOUT <6>
DATAOUT <6>

REFOUT <5>
DATAOUT <5>

REFOUT <4>
DATAOUT <4>

REFOUT <3>
DATAOUT <3>

REFOUT <2>
DATAOUT <2>

REFOUT <1>
DATAOUT <1>

REFOUT <0>
DATAOUT <0>

FIGURE 12. 4-BITS, 1 ROW OF 64 TAPS

15

FIGURE 13. 4 BITS, 2 ROWS OF 32 TAPS

HSP45256

8-Bit Configurations

8-Bit Data, Single Row, 32 Sample Configurations

An 8 x 32 correlation also requires only 1 HSP45256. To
initialize the correlator, all the ref erence bits , control bits , the
valueof the programmable delay,and the window configuration
must be specified. Table 12 details these settings .

Again, the loading of the reference and mask registers can
be done simultaneously. Due to the programming
initialization, DREF0-7 are used to load the reference data 8­bits at a time. It will take 32 load pulses each of
CLOAD to load both arrays. Upon completion of the mask
and register loading,

TXFR is pulsed low,which transfers the
reference and control data from the preload registers to the
registers that store the active data.

This configuration performs correlation of an 8-bit number
with a 1-bit reference. Each byte out of the correlation array
gives an 8-bit level of confidence that the data corresponds
to the reference. The correlation score is the sum of these
confidence levels.

RLOAD and

TABLE 12. REGISTER LOADING FOR 8 X 32 CORRELATOR

WITH BINARY WEIGHTING

A0-2 DCONT0-7 NOTES

001 00001111 1 256-tap correlator; 8 x 32 window configu-

ration,8-bitdatastream; referenceregisteris
loaded from DREF7 for all stages. Correlator
score = (128 x CO7) + (64 x CO3) + (32 x
CO5) + (16 x CO1) + (8 x CO6) + (4 x CO4)

+ (2 x CO2) + CO0.
010 00000000 Offset Register A = 0000000010000.
011 00010000
100 00000000 Programmable Delay = 0.
101 00000000 Offset Register B = 0 (Loading optional in
110 00000000

this mode).

REF <7>

DATA <7>
DATA <6>

DATA <5>
DATA <4>

DATA <3>
DATA <2>

DATA <1>
DATA <0>

CS = 128CO7+64CO6+32CO5+16CO4+8CO3+4CO2+2CO1+CO0

7
6

5
4

3
2

1
0

REFOUT <7>
DATAOUT <7>
REFOUT <6>
DATAOUT <6>

REFOUT <5>
DATAOUT <5>

REFOUT <4>
DATAOUT <4>

REFOUT <3>
DATAOUT <3>

REFOUT <2>
DATAOUT <2>

REFOUT <1>
DATAOUT <1>
REFOUT <0>
DATAOUT <0>

FIGURE 14. 8 BITS, 1 ROW OF 32 TAPS

16

Dual Correlator Configurations

1-Bit, Single Row, 128 Sample Configuration

HSP45256

REF <7>

DATA <7>

CSA = (CO7+CO6+CO5+CO4); (CASOUT)

7
6
5
4

DATAOUT <7>

FIGURE 15. DUAL 1-BIT, 1 ROW OF 128 TAPS

1-Bit, Dual Row, 64 Sample Configuration

REF <7>

DATA <7>

REF <5>

DATA <5>

CSA = (CO7+CO6+CO5+CO4); (CASOUT)

7
6
5
4

DATAOUT <7>

DATAOUT <5>

FIGURE 16. 1-BIT, 2 ROWS OF 64 TAPS

1-Bit, Quad Row, 32 Sample Configuration

REF <3>

DATA <3>

CSB = (CO3+CO2+CO1+CO0); (AUXOUT)

REF <3>

DATA <3>

REF <1>

DATA <1>

CSB = (CO3+CO2+CO1+CO0); (AUXOUT)

3
2
1
0

3
2
1
0

DATAOUT <3>

DATAOUT <3>

DATAOUT <1>

REF <7>

DATA <7>

REF <6>

DATA <6>

REF <5>

DATA <5>

REF <4>

DATA <4>

CSA = (CO7+CO6+CO5+CO4); (CASOUT)

7
6

5

4

DATAOUT <7>
DATAOUT <6>

DATAOUT <5>

DATAOUT <4>

FIGURE 17. 1-BIT, 4 ROWS OF 32 TAPS

REF <3>

DATA <3>

REF <2>

DATA <2>

REF <1>

DATA <1>

REF <0>

DATA <0>

CSB = (CO3+CO2+CO1+CO0); (AUXOUT)

3

2

1

0

DATAOUT <3>
DATAOUT <2>

DATAOUT <1>

DATAOUT <0>

17

2-Bit, Dual Row, 64 Sample Configuration

Dual 2 x 64 correlators require only one HSP45256. To
initialize the correlator, all the reference bits, control bits,
the delay value of the variable delay, and the window
configuration must be specified. Table 13 details the
settings for the 2-bit Dual Row, 64 Sample Configuration.

HSP45256

In this example, each of the dual correlators compares 2-bit
data to a 1-bit reference. It will take 64 load pulses
(

RLOAD/CLOAD) to completely load the reference and
mask registers in the array. The programmable delay must
be set to 0 for the output of the two correlators to be aligned.

REF <7>

DATA <7>

DATA <5>

CSA = 2(CO7+CO6)+CO5+CO4); (CASOUT)

7

6

5

4

DATAOUT <7>

DATAOUT <5>

REF <3>

DATA <3>

DATA <1>

CSB = 2(CO3+CO2)+CO1+CO0); (AUXOUT)

3

2

1

0

DATAOUT <3>

DATAOUT <1>

FIGURE 18. 2-BITS, 1 ROW OF 64 TAPS

TABLE 13. REGISTER LOADING FOR DUAL 2 X 64 CORRELATORS WITH EQUAL WEIGHTING

AO-2 DCONT0-7 NOTES

001 00010110 Dual correlators: Each 2 bit data, 64 taps; reference register for correlation A is loaded from DREF7 and DREF5, the

reference register for correlator B is loaded from DREF3 and DREF1. Correlator #1 = 2x C07 + 2 x CO6 + CO5 + CO4,

correlator #2 = 2 x CO3 + 2x CO2 + CO1 + CO0.
010 00000000 Offset Register A = 0000000010000.
011 00010000
100 00000000 Programmable Delay = 0.
101 00000000 Offset Register B = 0.
110 00000000

2-Bit, Dual Row, 32 Sample Configuration

REF <7>

DATA <7>

REF <6>

DATA <6>

DATA <5>

DATA <4>

CSA = 2(CO7+CO6)+CO5+CO4); (CASOUT)

7

6

5

4

DATAOUT <7>

DATAOUT <6>

DATAOUT <5>

DATAOUT <4>

FIGURE 19. 2-BITS, 2 ROWS OF 32 TAPS

4-Bit, Single Row, 32 Sample Configuration

REF <7>

DATA <7>
DATA <6>

DATA <5>
DATA <4>

CSA = 8(CO7)+4(CO6)+2(CO5)+(CO4); (CASOUT)

7

6

5

4

DATAOUT <7>

DATAOUT <5>

DATAOUT <5>

DATAOUT <4>

FIGURE 20. 4-BITS, 1 ROW OF 32 TAPS

REF <3>

DATA <3>

REF <2>

DATA <2>

DATA <1>

DATA <0>

CSB = 2(CO3+CO2)+CO1+CO0); (AUXOUT)

REF <3>

DATA <3>

DATA <2>

DATA <1>

DATA <0>

CSB = 8(CO3)+4(CO2)+2(CO1)+(CO0); (AUXOUT)

3

DATAOUT <3>

2

DATAOUT <2>

1

DATAOUT <1>

0

DATAOUT <0>

3

2

1

0

DATAOUT <3>

DATAOUT <2>

DATAOUT <1>

DATAOUT <0>

18

HSP45256

Cascading Multiple Correlator Devices

Correlators can be cascaded in either a serial or parallel
fashion. Longer correlations can be achieved by connecting
several correlators together as shown in Figures 21- 23. In
Figure 21, each correlator is in a one data bit, one row, 256
tap configuration. The number of bits of significance at the
CASOUT output of each correlator builds up from one
correlation to the next, that is, the maximum score out of the
first correlator is 256, the maximum output of the second
correlator is 512, etc. In this configuration, the maximum
length of the correlation is 4096. This would be implemented
with 16 HSP45256’s. The Programmable Delay Register in
the first correlator would be set for one delay, the second
would be set for two, and so on, with the final HSP45256
being set for a delay of 16.

Correlations of more bits can be calculated by connecting
CASOUT of each chip to the CASIN of the following chip

DATA INPUT

DIN7
CASIN0-12 CASOUT0-12

DOUT7 DIN7

CASIN0-12 CASOUT0-12

DOUT7 DIN7

FIGURE 21. 1-BIT, 1024 SAMPLE CONFIGURATION

(Figure 21). The data on the CASOUT lines accumulates in
a similar manner as in the 1 x 256 mode, except that the
maximum output of the first correlator is decimal 960,
(hexadecimal 3C0); in the general case, the maximum
number of correlators that can be cascaded in this manner is
eight, since the maximum output of the last one would be
1E00, which nearly uses up the 13-bit range of the cascade
summer.More parts could be cascaded together if some bits
are to be masked out or if the user has a prior knowledge of
the maximum value of the correlation score. As before, the
delay in the first correlator would be set to one, the second
correlator would be set for a delay of two, and so on.

Multiple HSP45256’s can be cascaded for two dimensional
one bit data (Figure 22). The maximum output for each chip
is the same as in the 1 x 256 case; the only difference is in
the manner in which the correlators are connected. The
programmable delay registers would be set as before.

DOUT7

CASIN0-12 CASOUT0-12

DIN7
CASIN0-12 CASOUT0-12

DOUT7

CORRELATOR
SCORE
OUTPUT

DATA INPUT

DIN7, 5, 3, 1
CASIN0-12 CASOUT0-12

DATA INPUT
ROWS 0 - 7

DIN0-7
CASIN0-12 CASOUT0-12

DOUT7, 5, 3, 1 DIN7, 5, 3, 1

CASIN0-12 CASOUT0-12

FIGURE 22. 4-BIT, 256 SAMPLE CONFIGURATION

DATA INPUT
ROWS 8 - 15

DIN0-7
CASIN0-12 CASOUT0-12

FIGURE 23. 1-BIT, 32 x 32 WINDOW CONFIGURATION

DOUT7, 5, 3, 1 DIN7, 5, 3, 1

CASIN0-12 CASOUT0-12

DATA INPUT
ROWS 16 - 23

DIN0-7
CASIN0-12 CASOUT0-12

DOUT7, 5, 3, 1

DIN7, 5, 3, 1
CASIN0-12 CASOUT0-12

DATA INPUT
ROWS 24 - 31

DIN0-7
CASIN0-12 CASOUT0-12

DOUT7, 5, 3, 1

CORRELATOR
SCORE
OUTPUT

CORRELATOR
SCORE
OUTPUT

19

HSP45256

Reloading Data During Operation

RLOAD and CLOAD are asynchronous signals that are
designed to be driven by the memory interface signals of a
microprocessor.
mask or reference data is updated on a specific clock cycle.
In the normal mode of operation, the user loads the
reference and mask memories, then pulses
that data. The correlator uses the new mask or reference
information immediately. Loading of the reference and mask
data remains asynchronous as long as there is at least one
cycle of CLK between the rising edge of
and the

TXFR pulse.

If the system timing makes it necessary for TXFR and
RLOAD and/or CLOAD to be active during the same clock
cycle, then they must be treated as synchronous signals; the
timing for this case is shown in Figure 24 and given in the AC
Timing Specifications (t
data is loaded during clock cycle 1 and transferred on the
rising edge of CLK that occurs in clock cycle two. Another
set of data is loaded during clock cycle 2, which will be

TXFR is synchronized to CLK so that the

TXFR to use

RLOAD or CLOAD

THCL

and t

). In this example,

CLLH

transferredby a later

TXFR pulse. The sequence of eventsis

as follows:

1. In clock cycle 1,

TXFR becomes active at least tTHnano-

seconds after the rising edge of CLK.

2. RLOAD and/or

CLOAD pulses low; the timing is not
critical as long as its rising edge occurs before the end of
clock cycle 1. If this condition is not met, it is undeter­mined whether the data loaded by this pulse will be trans­ferred by the current

3. The rising edge of

TXFR pulse.

TXFR occurs while CLK is high during
clock cycle 2. The margin between the rising edge of
TXFR and the falling edge of CLK is defined by t

4.

RLOAD and/or CLOAD pulses low. The rising edge of
RLOAD and CLOAD must occur after the falling edge of
CLK. The margin between the two is defined by t

The time from the rising edge of
CLK must be greater than t
falling edge of CLK to the rising edge of
must be greater than t
being transferred by the

. If this timing is violated, the data

s

TXFR pulse shown may or may not

TXFR to the falling edge of

, and the time from the

THCL

RLOAD or CLOAD

include the data loaded in clock cycle 2.

THCL

CLLH

.

.

CLOCK CYCLE 1

CLK

t

TH

1.

TXFR

RLOAD,

CLOAD

2.

FIGURE 24. LOADING AND TRANSFERRING DATA DURING THE SAME CLOCK CYCLE

CLOCK CYCLE 2

t

THCL

3.

t

CLLH

4.

20

HSP45256

Absolute Maximum Ratings Thermal Information

Supply Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +8.0V

Input, Output or I/O Voltage. . . . . . . . . . . .GND -0.5V to VCC+0.5V

ESD Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Class 1

Operating Conditions

Voltage Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . +4.75V to +5.25V

Temperature Range

Commercial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0oC to 70oC

Industrial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40oC to 85oC

CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operationofthe
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.

NOTE:

1. θJA is measured with the component mounted on an evaluation PC board in free air.

DC Electrical Specifications

PARAMETER SYMBOL TEST CONDITIONS MIN MAX UNITS

Logical One Input Voltage V
Logical Zero Input Voltage V
High Level Clock Input V
Low Level Clock Input V
Output High Voltage V
Output Low Voltage V
Input Leakage Current I
Output Leakage Current I
Standby Power Supply Current I
Operating Power Supply Current I

CCSB
CCOP

IHC

ILC
OH

IH
IL

OL

O

VCC = 5.25V 2.0 - V
VCC = 4.75V - 0.8 V
VCC = 5.25V 3.0 - V
VCC = 4.75V - 0.8 V
IOH = 400µA, VCC = 4.75V 2.6 - V
IOL = +2.0mA, VCC = 4.75V - 0.4 V
VIN = VCC or GND, VCC = 5.25V -10 10 µA

I

V

= VCC or GND, VCC= 5.25V -10 10 µA

OUT

VIN = VCC or GND, VCC = 5.25V - 500 µA
f = 25.6MHz, VIN = VCC or GND, VCC = 5.25V,

Note 2, 4

Thermal Resistance (Typical, Note 1) θJA (oC/W) θJC (oC/W)

PLCC Package. . . . . . . . . . . . . . . . . . . 34 -

PGA Package. . . . . . . . . . . . . . . . . . . . 36 10

Maximum Package Power Dissipation

Commercial PGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.9W

Commercial PLCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.3W

Industrial PLCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.9W

Maximum Storage Temperature Range. . . . . . . . . . -65oC to 150oC

Maximum Junction Temperature

PLCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150oC

PGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175oC

Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . .300oC

Gate Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13,000 Gates

- 179 mA

Capacitance T

= 25oC, Note 3

A

PARAMETER SYMBOL MIN MAX UNITS TEST CONDITIONS

Input Capacitance C

Output Capacitance C

IN

O

- 10 pF Frequency = 1MHz, VCC = Open

-10pF

NOTES:

2. Power supply current is proportional to operating frequency. Typical rating for I

CCOP

3. Not tested, but characterized at initial design and at major process/design changes.

4. Output load per test load circuit and CL = 40pF.

AC Electrical Specifications V

= 5.0V ±5%, TA = 0oC to 70oC, TA = -40oC to 85oC, Note 5

CC

PARAMETER SYMBOL NOTES

CLK Period t
CLK High t
CLK Low t

CP
CH
CL

21

All measurements are referenced to device ground.

is 7mA/MHz.

33MHz 25.6MHz

UNITSMIN MAX MIN MAX

30-39-ns
12-15-ns
12-15-ns

HSP45256

AC Electrical Specifications V

= 5.0V ±5%, TA = 0oC to 70oC, TA = -40oC to 85oC, Note 5 (Continued)

CC

33MHz 25.6MHz

PARAMETER SYMBOL NOTES

Set-Up Time DIN to CLK High t
Hold Time CLK High to DIN t
TXFR Set-Up Time t
TXFR Hold Time t
Output Delay DOUT, AUXOUT, CASOUT t
CLOAD Cycle Time t
CLOAD High t
CLOAD Low t
Set-Up Time, A to RLOAD, CLOAD t
Hold Time, RLOAD, CLOAD to A t
RLOAD Cycle Time t
RLOAD High t
RLOAD Low t
Set-Up Time, DCONT to CLOAD t
Hold Time, CLOAD to DCONT t
Set-Up Time, DREF to RLOAD t
Hold Time, RLOAD to DREF t
Output Enable Time t
Output Disable Time t
Output Rise, Fall Time t
TXFR High to CLK Low t
CLK Low to RLOAD, CLOAD High t

DS
DH
TS
TH

DO
CLC
CLH

CLL

AS

AH
RLC
RLH

RLL
DCS
DCH

RS
RH
OE
OD

RF
THCL
CLLH

12-13-ns

0-0-ns

12-13-ns

0-0-ns

- 15 - 20 ns
30-39-ns
12-15-ns
12-15-ns
12-13-ns

0-0-ns
30-39-ns
12-15-ns
12-15-ns
12-13-ns

0-0-ns
12-13-ns

0-0-ns

- 15 - 15 ns
Note 6 - 15 - 15 ns
Note 6 - 6 6 ns
Note 6 3 - 3 - ns
Note 6 1 - 1 - ns

UNITSMIN MAX MIN MAX

NOTES:

5. AC testing is performed as follows: Input levels (CLK Input) 4.0V and 0V; Input levels (all other inputs) 0V and 3.0V; Timing reference levels
(CLK) 2.0V; All others 1.5V. Output load per test load circuit with CL = 40pF. Output transition is measured at VOH > 1.5V and
VOL < 1.5V.

6. Controlled via design or process parameters and not directly tested. Characterized upon initial design and after major process and/or design
changes.

Test Load Circuit

DUT

†

INCLUDES STRAY
AND JIG
CAPACITANCE

22

†C

S

1

L

1.5V I

±

TEST

OL

SWITCH S

OPEN FOR I

1

I

OH

EQUIVALENT CIRCUIT

AND I

CCSB

CCOP

Timing Waveforms

CLK

t

t

DS

DIN0-7

tTSt

DH

TH

HSP45256

t

CP

t

CH

t

CL

t

CLC

t

CLH

t

TS

CLOAD

t

t

AH

AS

t

CLL

TXFR

DOUT0-7

CASOUT0-12,

AUXOUT0-8

DLOAD

A0-2

DREF0-7

A0-2

t

t

DO

CS

t

CH

DCONT0-7

FIGURE 25. INPUT, OUTPUT TIMING FIGURE 26. CONTROL INPUT TIMING

t

RLC

t

RLL

t

RLH

t

t

AH

AS

t

t

RH

RS

OEA, OEC

AUXOUT0-8

CASOUT0-12

DOUT0-7,

CASOUT0-12,

AUXOUT0-8

0.8V

t

OD

2.0V

tr, t

f

FIGURE 27. REFERENCE INPUT TIMING FIGURE 28. OUTPUT TIMING

t

OE

1.7V

1.3V

t

THCL

t

CLLH

CLK

TXFR

RLOAD,

CLOAD

FIGURE 29. TRANSFER, LOAD TIMING WHEN BOTH OCCUR ON A SINGLE CYCLE

All Intersil semiconductor products are manufactured, assembled and tested under ISO9000 quality systems certification.

Intersil semiconductor products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design and/or specifications at any time with­out notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be accurate and
reliable. However ,no responsibility is assumed by Intersil or its subsidiaries for its use; nor for any infringements of patents or other rights of third parties which may result
from its use. No license is granted by implication or otherwise under any patent or patent rights of Intersil or its subsidiaries.

For information regarding Intersil Corporation and its products, see web site http://www.intersil.com

23
