Page 1
INTEGRATED CIRCUITS
DATA SH EET
For a complete data sheet, please also download:
•The IC04 LOCMOS HE4000B Logic
Family Specifications HEF, HEC
•The IC04 LOCMOS HE4000B Logic
Package Outlines/Information HEF, HEC
HEF4019B
MSI
Quadruple 2-input multiplexer
Product specification
File under Integrated Circuits, IC04
January 1995
Page 2
Philips Semiconductors Product specification
Quadruple 2-input multiplexer
DESCRIPTION
The HEF4019B provides four multiplexing circuits with
common select inputs (SA, SB); each circuit contains two
inputs (An, Bn) and one output (On). It may be used to
select four bits of information from one of two sources.
HEF4019B
MSI
The A inputs are selected when S
when SBis HIGH. When SAand SBare HIGH, output (On)
is the logical OR of the Anand Bninputs (On= An+ Bn).
When SAand SBare LOW, output (On) is LOW
independent of the multiplexer inputs.
is HIGH, the B inputs
A
Fig.2 Pinning diagram.
FAMILY DATA, I
LIMITS category MSI
DD
See Family Specifications
Fig.1 Functional diagram.
HEF4019BP(N): 16-lead DIL; plastic
HEF4019BD(F): 16-lead DIL; ceramic (cerdip)
HEF4019BT(D): 16-lead SO; plastic
( ): Package Designator North America
PINNING
S
, S
A
B
A
to A
0
3
B
to B
0
3
O
to O
0
3
(SOT38-1)
(SOT74)
(SOT109-1)
select inputs (active HIGH)
multiplexer inputs
multiplexer inputs
multiplexer outputs
January 1995 2
Page 3
Philips Semiconductors Product specification
Quadruple 2-input multiplexer
HEF4019B
MSI
TRUTH TABLE
SELECT INPUTS OUTPUT
S
A
LLXX L
HLLX L
HLHX H
LHXL L
LHXH H
HHHX H
HHXH H
HHLL L
Notes
1. H = HIGH state (the more positive voltage)
L = LOW state (the less positive voltage)
X = state is immaterial
S
B
A
n
B
n
O
n
Fig.3 Logic diagram.
January 1995 3
Page 4
Philips Semiconductors Product specification
Quadruple 2-input multiplexer
HEF4019B
MSI
AC CHARACTERISTICS
V
= 0 V; T
SS
Propagation delays
An,Bn, SA, SB→ O
HIGH to LOW 10 t
LOW to HIGH 10 t
Output transition times 5 60 120 ns 10 ns + (1,0 ns/pF) C
HIGH to LOW 10 t
LOW to HIGH 10 t
=25°C; CL= 50 pF; input transition times ≤20 ns
amb
V
DD
V
n
5 70 145 ns 43 ns + (0,55 ns/pF) C
SYMBOL TYP. MAX.
PHL
15 25 50 ns 17 ns + (0,16 ns/pF) C
5 60 130 ns 33 ns + (0,55 ns/pF) C
PLH
15 15 35 ns 7 ns + (0,16 ns/pF) C
THL
15 20 40 ns 6 ns + (0,28 ns/pF) C
5 60 120 ns 10 ns + (1,0 ns/pF) C
TLH
15 20 40 ns 6 ns + (0,28 ns/pF) C
TYPICAL EXTRAPOLATION
FORMULA
30 60 ns 19 ns + (0,23 ns/pF) C
25 50 ns 14 ns + (0,23 ns/pF) C
30 60 ns 9 ns + (0,42 ns/pF) C
30 60 ns 9 ns + (0,42 ns/pF) C
L
L
L
L
L
L
L
L
L
L
L
L
V
DD
V
TYPICAL FORMULA FOR P (µW)
Dynamic power 5 1200 f
dissipation per 10 5100 f
package (P) 15 18 700 f
APPLICATION INFORMATION
An example of an application for the HEF4019B is:
• True/complement selection.
+∑(foCL) × V
i
+∑(foCL) × V
i
+∑(foCL) × V
i
DD
DD
DD
2
2
2
where
fi= input freq. (MHz)
fo= output freq. (MHz)
C
= load capacitance (pF)
L
) = sum of outputs
∑ (f
oCL
V
= supply voltage (V)
DD
January 1995 4
