Heatshrink
Basic Properties - Thin Walled Heatshrink Tubing
Operating temperature : -40°C to +125°C.
Shrink ratio : 2:1.
Standard colours : Black, blue, red, yellow and transparent.
Other : Flame retardent.Self-extinguishing. Thin dual wall adhesive lining. 3:1 shrink ratio.
Features:
••
Ten size and six colour variations of thin-walled heatshrink tubing in easy to
dispense display cartons.
••
Manufactured from cross-linked semi-flexible polyolefin which shrinks uniformly to
form a permanent insulating covering.
••
Upon recovery, thin wall tube will conform to the shape it is applied over.
••
Ideal for low voltage electrical insulation up to 1000V.
Dimensions : Millimetres
Dimensions : Millimetres
Colour
Minimum
Inner Ø as
Supplied
(D)
Maximum
Inner Ø
Recovered
(d)
Wall
Thickness
Recovered
(W)
Length Per
Box
(M)
Part Number
Black
1.2 0.6
0.45 15
HSB1206BLK
Brown HSB1206BR
Clear HSB1206C
Blue HSB1206BLUE
Grey HSB1206GY
Green/Yellow HSB1206GRY
Black
1.6 0.8
HSB1608BLK
Brown HSB1608BR
Clear HSB1608C
Blue HSB1608BLUE
Grey HSB1608GY
Green/Yellow HSB1608GRY
Specifications
http://www.farnell.com
http://www.newark.com
http://www.cpc.co.uk
Page 2
Heatshrink
Page <2> 28/03/09 V1.0
http://www.farnell.com
http://www.newark.com
http://www.cpc.co.uk
Colour
Minimum
Inner Ø as
Supplied
(D)
Maximum
Inner Ø
Recovered
(d)
Wall
Thickness
Recovered
(W)
Length Per
Box
(M)
Part Number
Black
2.4 1.2
0.45
15
HSB2412BLK
Brown HSB2412BR
Clear HSB2412C
Blue HSB2412BLUE
Grey HSB2412GY
Green/Yellow HSB2412GRY
Black
3.2 1.6
HSB3216BLK
Brown HSB3216BR
Clear HSB3216C
Blue HSB3216BLUE
Grey HSB3216GY
Green/Yellow HSB3216GRY
Black
4.8 2.4 10
HSB4824BLK
Brown HSB4824BR
Clear HSB4824C
Blue HSB4824BLUE
Grey HSB4824GY
Green/Yellow HSB4824GRY
Specifications
Black
6.4 3.2
0.55
10
HSB7030BLK
Brown HSB7030BR
Clear HSB7030C
Blue HSB7030BLUE
Grey HSB7030GY
Green/Yellow HSB7030GRY
Black
9.5 4.7
HSB10050BLK
Brown HSB10050BR
Clear HSB10050C
Blue HSB10050BLUE
Grey HSB10050GY
Green/Yellow HSB10050GRY
Black
12.7 6.4 8
HSB13060BLK
Brown HSB13060BR
Clear HSB13060C
Blue HSB13060BLUE
Grey HSB13060GY
Green/Yellow HSB13060GRY
Dimensions : Millimetres
Page 3
Heatshrink
Page <3> 28/03/09 V1.0
http://www.farnell.com
http://www.newark.com
http://www.cpc.co.uk
Specifications
Dimensions : Millimetres
Disclaimer This data sheet and its contents (the "Information") belong to the Premier Farnell Group (the "Group") or are licensed to it. No licence is granted for the use of it other than for information purposes
in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces all data sheets previously supplied.
The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use made of it. Users of this data
sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted. Liability for loss or damage
resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising) is excluded.
This will not operate to limit or restrict the Group's liability for death or personal injury resulting from its negligence. Pro-Power is the registered trademark of the Group. © Premier Farnell plc 2009.
Colour
Inner Ø as
Supplied D
Minimum
Inner Ø Recovered d
Maximum
Wall Thickness
Recovered W
Length Per Box
(M)
Part Number
Black
19.1 9.5 0.7 7
HSB190100BLK
Brown HSB190100BR
Clear HSB190100C
Blue HSB190100BLUE
Grey HSB190100GY
Green/Yellow HSB190100GRY
Black
25.4 12.7 0.75 4
HSB260120BLK
Brown HSB260120BR
Clear HSB260120C
Blue HSB260120BLUE
Grey HSB260120GY
Green/Yellow HSB260120GRY
