HCC/HCF40102B
HCC/H CF4 01 03B

8-STAGEPRESETTABLESYNCHRONOUS DOWN COUNTERS

DESCRIPTION

.SYNCHRONOUS OR ASYNCHRONOUS

PRESET

.MEDIUM-SPEED OPERATION : f

CL

= 3.6MHz

(TYP.) @ VDD=10V

.CASCADABLE

.QUIESCENT CURRENT SPECIFIED TO 20V

FOR HCC DEVICE

.5V, 10V AND 15VPARAMETRIC RATINGS

.INPUTCURRENTOF100nAAT18VAND25°C

FOR HCC DEVICE

.100% TESTEDFOR QUIESCENTCURRENT

.MEETSALLREQUIREMENTSOFJEDECTEN-

TATIVE STANDARD No. 13 A, ”STANDARD
SPECIFICATIONS FOR DESCRIPTIONOF ”B”
SERIESCMOS DEVICES”

June 1989

TheHCC40102B, HCC40103B, (extended tempera-
turerange) andthe HCF40102B,HCF40103B (inter-
mediatetemperature range)aremonolithicintegrated
circuits,available in16-lead dual in-line plasticorce­ramic package. The HCC/HCF40102B,and
HCC/HCF40103Bconsistofan 8-stagesynchronous
downcounterwithasingleoutputwhichisactivewhen
the internal count is zero. The HCC/HCF40102B is
configured astwocascaded 4-bit BCDcounters, and
theHCC/HCF40103B contains a single 8-bit binary
counter. Each typehas controlinputsforenabling or
disabling the clock, for clearing the counter to its
maximum count, and for presetting the counter
eithersynchronously orasynchronously. All control
inputs and the CARRY-OUT/ZERO-DETECT out­put are active-low logic. In normal operation, the
counter is decremented byone count on eachposi­tive transition of the CLOCK. Counting is inhibited
when the CARRY-IN/COUNTER ENABLE (CI/CE)
input is high. The CARRY-OUT/ZERO-DETEC
(CO/ZD) output goes low whenthe count reaches
zero if the CI/CE input is low, and remains low for
one full clock period. When the SYNCHRONOUS
PRESET-ENABLE (SPE) input is low, data at the
JAM input is clocked into the counter on the next
positiveclocktransitionregardless ofthestateofthe
CI/CE input. When the ASYNCHRONOUS
PRESET-ENABLE (APE) input is low, data at the

EY

(Plastic Package)

F

(CeramicPackage)

C1

(ChipCarrier)

ORDERCODES :

HCC401XXBF HCF401XXBEY

HCF401XXBC1

PIN CONNEC TI O NS

40102B 2-DECADE BCD TYPE
40103B 8-BIT BINARY TYPE

1/13

FUNCTIONAL DIAGRAM

ABSOLUTE MAXI MU M RATINGS

Symbol Parame ter Val ue Unit

V

DD

* Supply Voltage :HC C Types

HCF Types

– 0.5to + 20
– 0.5to + 18

V
V

V

i

Input Voltage – 0.5 to VDD+ 0.5 V

I

I

DC Input Current (any one input) ± 10 mA

P

tot

Total Power Dissipation (per package)
Dissipation per Output Transistor
for T

op

= Full Package-temperature Range

200
100

mW
mW

T

op

Operating Temperature : HCC Types

HCF Types

–55to+125

–40to+85

°C
°C

T

stg

Storage Temperature – 65 to + 150 °C

RECOMMENDED OPERATING CONDITIONS

Symbol Parameter Value Unit

V

DD

Supply Voltage : HCC Types

HCF Types

3to18
3to15

V
V

V

I

Input Voltage 0 to V

DD

V

T

op

Operating Temperature : HCC Types

HCF Types

– 55 to + 125

–40to+85

°C
°C

Stresses above those listed under ”Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating only
and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification
is not implied. Exposure to absolute maximum rating conditions for external periods may affect device reliability.
* All voltages are with respect to VSS(GND).

JAM inputs is asynchronously forced into the
counterregardless of the state of the SPE, CI/CE,
or CLOCK inputs. JAM inputsJO-J7 represent two
4-bit BCD words for the HCC/HCF40102B and a
single 8-bit binary word for the HCC/HCF40103B.
When the CLEAR (CLR) input is low, the counter
is asynchronously cleared to its maximum count
(9910for the HCC/HCF40102B and 25510for

theHCC/HCF40103B) regardless of the state of
any other input. The precedence relationship be­tween control input is indicated in thetruth table. If
all control inputs are high atthetiemeofzerocount,
the counterswilljump to themaximum count, giving
a counting sequence of 100 or 256 clock pulses
long.TheHCC/HCF40102B andHCC/HCF40103B
may be cascaded using the CI/CE input and the

HCC/HCF40102B/40103B

2/13

LOGIC DIAGRAMS

40102B

40103B

Detail logic diagram for flip-flops, FF0-FF7used in logic diagrams for 40102B and 40103B.

HCC/HCF40102B/40103B

3/13

LOGIC DIAGRAMS (continued)

40102B

TRUTH TABLE

Control Inputs

CLR APE SPE CI/CE

Preset Mod e Action

1 1 1 1 Inhibit Counter
1 1 1 0 Count Down
110X

Synchronous

Preset on Next Positive Clock Transition
1 0 X X Preset Asynchrounously
0XXX

Asynchronous

Clear to Maximum Count

TimingDiagram for 40102B and 40103B

Notes : 1. 0 = Low level

1 = Highlevel
X = Don’tcare

2. Clock connected toclock input.

3. Synchronous operation : changes occuron negative-to-positive clock transitions..
JAM inputs: HCC/HCF010B ; MSD = J7, J6,J5, J4 (J7 is MSB)

LSD = J3,J2, J1,J0 (J3is MSB)

HCC/HCF40103B Binary ; MSB =J7, LSB =J0

HCC/HCF40102B/40103B

4/13

STATIC ELECTRICAL CHARACTERISTICS (over recommended operatingconditions)

Test Conditions Value

V

I

V

O

|IO|V

DD

T

Low

* 25°CT

High

*

Symbol Parameter

(V) (V) (µA) (V)

Min. Max. Min. Typ. Ma x. Min . Max.

Unit

I

L

Quiescent
Current

HCC
Types

0/ 5 5 5 0.04 5 150

µA

0/10 10 10 0.04 10 300
0/15 15 20 0.04 20 600
0/20 20 100 0.08 100 3000

HCF
Types

0/ 5 5 20 0.04 20 150
0/10 10 40 0.04 40 300
0/15 15 80 0.04 80 600

V

OH

Output High
Voltage

0/ 5 < 1 5 4.95 4.95 4.95

V

0/10 < 1 10 9.95 9.95 9.95
0/15 < 1 15 14.95 14.95 14.95

V

OL

Output Low
Voltage

5/0 < 1 5 0.05 0.05 0.05

V

10/0 < 1 10 0.05 0.05 0.05
15/0 < 1 15 0.05 0.05 0.05

V

IH

Input High
Voltage

0.5/4.5 < 1 5 3.5 3.5 3.5
V

1/9 < 1 10 7 7 7

1.5/13.5 < 1 15 11 11 11

V

IL

Input Low
Voltage

4.5/0.5 < 1 5 1.5 1.5 1.5
V

9/1 < 1 10 3 3 3

13.5/1.5 < 1 15 4 4 4

I

OH

Output
Drive
Current

HCC
Types

0/ 5 2.5 5 – 2 – 1.6 – 3.2 – 1.15

mA

0/ 5 4.6 5 – 0.64 – 0.51 – 1 – 0.36
0/10 9.5 10 – 1.6 – 1.3 – 2.6 – 0.9
0/15 13.5 15 – 4.2 – 3.4 – 6.8 – 2.4

HCF
Types

0/ 5 2.5 5 – 1.53 – 1.36 – 3.2 – 1.1
0/ 5 4.6 5 – 0.52 – 0.44 – 1 – 0.36
0/10 9.5 10 – 1.3 – 1.1 – 2.6 – 0.9
0/15 13.5 15 – 3.6 – 3.0 – 6.8 – 2.4

I

OL

Output
Sink
Current

HCC
Types

0/ 5 0.4 5 0.64 0.51 1 0.36

mA

0/10 0.5 10 1.6 1.3 2.6 0.9
0/15 1.5 15 4.2 3.4 6.8 2.4

HCF
Types

0/ 5 0.4 5 0.52 0.44 1 0.36
0/10 0.5 10 1.3 1.1 2.6 0.9
0/15 1.5 15 3.6 3.0 6.8 2.4

I

IH,IIL

Input
Leakage
Current

HCC

Types

0/18

Any Input

18 ± 0.1 ±10

–5

± 0.1 ± 1

µA

HCF

Types

0/15

15 ± 0.3 ±10

–5

± 0.3 ± 1

C

I

Input Capacitance Any Input 5 7.5 pF

*T

Low

=–55°CforHCC device : – 40°C for HCF device.

*T

High

= + 125°C for HCC device : + 85°C for HCF device.

TheNoise Marginfor both ”1” and”0” levelis : 1V min.with VDD= 5V, 2V min. with VDD= 10V, 2.5 V min.with VDD=15V.

HCC/HCF40102B/40103B

5/13

DYNAMIC ELECTRICAL CHARACTERISTICS (T

amb

=25°C, CL= 50pF, RL= 200kΩ,

typical temperature coefficientfor all VDDvalues is 0.3%/°C, all inputrise and fall time = 20ns)

Test Conditions Value

Symbol Parameter

V

DD

(V) Min. Typ . Max.

Unit

t

PHL

,

t

PLH

Propagation
Delay Time

Clock to-out 5 300 600

ns

10 130 260
15 95 190

Carry In/Counter
Enable-to-output

5200400

ns

10 90 180
15 65 130

Asynchronous
Preset
Enable-to-output

5 650 1300
10 300 600
15 200 400

Clear-to-output 5 375 750

ns

10 180 360
15 100 200

t

THL,tTLH

Transition Time 5 100 200

10 50 100 ns
15 40 80

t

W

Pulse Width Clock Pulse

Width

5 300 150

ns

10 180 90
15 80 40

CLR Pulse
Width

5 320 160

ns

10 160 80
15 100 50

APE Pulse Width 5 360 180

10 160 80

ns

15 120 60

t

se tu p

Setup Time SPE Setup Time 5 280 140

ns

10 140 70
15 100 50

JAM Setup Time 5 200 100

ns

10 80 40
15 60 30

f

CL

Maximum Clock Input Frequency 5 0.7 1.4

10 1.8 3.6 MHz
15 2.4 4.8

HCC/HCF40102B/40103B

6/13

OutputLow (sink)Current Characteristics. Output High (source) Current Characteristics.

Typical Transition Time vs. Load Capacitance. Typical Propagation Delay Timevs. LoadCapacit-

ance (clock to CO/ZD).

TypicalDynamicPower Dissipationvs. Fre­quency.

TypicalMaximum Clock Input Frequency vs.
Supply Voltage.

HCC/HCF40102B/40103B

7/13

TYPICAL APPLICATIONS

Divide-by-”N” Counter. Programmable Timer.

Microprocessor Interrupt Timer.

Microprocessor Interrupt Timer.

Synchronous Cascading.

* An output spike (160ns @ V

DD

= 5V) occurs whenever two or
more devices are cascaded in the parallel-clocked mode be­cause the clock-to-carry out delay is greater than the carry-in-to­carry out delay. This spike is eliminated by gating the out put
of the last device with the clock as shown.

HCC/HCF40102B/40103B

8/13

Input Current.

Input Voltage.

TEST CIRCUITS

QuiescentDevice Current.

Maximum Clock Frequency.

Dynamic Power Dissipation.

HCC/HCF40102B/40103B

9/13

Plastic DIP16(0.25) MECHANICAL DATA

DIM.

mm inch

MIN. TYP. MAX. MIN. TYP. MAX.

a1 0.51 0.020

B 0.77 1.65 0.030 0.065
b 0.5 0.020

b1 0.25 0.010

D 20 0.787
E 8.5 0.335

e 2.54 0.100

e3 17.78 0.700

F 7.1 0.280

I 5.1 0.201
L 3.3 0.130
Z 1.27 0.050

P001C

HCC/HCF40102B/40103B

10/13

Ceramic DIP16/1 MECHANICAL DATA

DIM.

mm inch

MIN. TYP. MAX. MIN. TYP. MAX.

A 20 0.787
B 7 0.276
D 3.3 0.130
E 0.38 0.015

e3 17.78 0.700

F 2.29 2.79 0.090 0.110

G 0.4 0.55 0.016 0.022

H 1.17 1.52 0.046 0.060

L 0.22 0.31 0.009 0.012

M 0.51 1.27 0.020 0.050

N 10.3 0.406
P 7.8 8.05 0.307 0.317

Q 5.08 0.200

P053D

HCC/HCF40102B/40103B

11/13

PLCC20 MECHANICAL DATA

DIM.

mm inch

MIN. TYP. MAX. MIN. TYP. MAX.

A 9.78 10.03 0.385 0.395
B 8.89 9.04 0.350 0.356

D 4.2 4.57 0.165 0.180
d1 2.54 0.100
d2 0.56 0.022

E 7.37 8.38 0.290 0.330

e 1.27 0.050

e3 5.08 0.200

F 0.38 0.015
G 0.101 0.004
M 1.27 0.050

M1 1.14 0.045

P027A

HCC/HCF40102B/40103B

12/13
