GS832218(B/E)/GS832236(B/E)/GS832272(C)

119-, 165-, & 209-Pin BGA

2M x 18, 1M x 36, 512K x 72

Commercial Temp
Industrial Temp

36Mb S/DCD Sync Burst SRAMs

Features

• FT pin for user-configurable flow through or pipeline operation

• Single/Dual Cycle Deselect selectable

• IEEE 1149.1 JTAG-compatible Boundary Scan

• ZQ mode pin for user-selectable high

/low output drive

• 2.5 V +10%/–10% core power supply

• 3.3 V +10%/–10% core power supply

• 2.5 V or 3.3 V I/O supply
pin for Linear or Interleaved Burst mode

• LBO

• Internal input resistors on mode pins allow floating mode pins

• Default to SCD x18/x36 Interleaved Pipeline mode

• Byte Write (BW

) and/or Global Write (GW) operation

• Internal self-timed write cycle

• Automatic power-down for portable applications

• JEDEC-standard 119-, 165-, and 209-bump BGA package

Functional Description

Applications

The GS832218/36/72 is a 37,748,736-bit high performance
synchronous SRAM with a 2-bit burst address counter. Although
of a type originally developed for Level 2 Cache applications
supporting high performance CPUs, the device now finds
application in synchronous SRAM applications, ranging from
DSP main store to networking chip set support.

Controls

Addresses, data I/Os, chip enable (E1), address burst control
inputs (ADSP

) are synchronous and are controlled by a positive-edge-

GW
triggered clock input (CK). Output enable (G
control (ZZ) are asynchronous inputs. Burst cycles can be initiated
with either ADSP
burst addresses are generated internally and are controlled by

. The burst address counter may be configured to count in

ADV
either linear or interleave order with the Linear Burst Order (LBO
input. The Burst function need not be used. New addresses can be
loaded on every cycle with no degradation of chip performance.

, ADSC, ADV), and write control inputs (Bx, BW,

) and power down

or ADSC inputs. In Burst mode, subsequent

250 MHz–133 MHz

2.5 V or 3.3 V V

2.5 V or 3.3 V I/O

Flow Through/Pipeline Reads

The function of the Data Output register can be controlled by the
user via the FT mode . Holding the FT mode pin low places the
RAM in Flow Through mode, causing output data to bypass the
Data Output Register. Holding FT
Pipeline mode, activating the rising-edge-triggered Data Output
Register.

SCD and DCD Pipelined Reads

The GS832218/36/72 is a SCD (Single Cycle Deselect) and DCD
(Dual Cycle Deselect) pipelined synchronous SRAM. DCD
SRAMs pipeline disable commands to the same degree as read
commands. SCD SRAMs pipeline deselect commands one stage
less than read commands. SCD RAMs begin turning off their
outputs immediately after the deselect command has been
captured in the input registers. DCD RAMs hold the deselect
command for one full cycle and then begin turning off their
outputs just after the second rising edge of clock. The user may
configure this SRAM for either mode of operation using the SCD
mode input.

Byte Write and Global Write

Byte write operation is performed by using Byte Write enable

) input combined with one or more individual byte write

(BW
signals (Bx

). In addition, Global Write (GW) is available for
writing all bytes at one time, regardless of the Byte Write control
inputs.

FLXDrive™

The ZQ pin allows selection between high drive strength (ZQ low)
for multi-drop bus applications and normal drive strength (ZQ
floating or high) point-to-point applications. See the Output Driver
Characteristics chart for details.

Core and Interface Voltages

The GS832218/36/72 operates on a 2.5 V or 3.3 V power supply.

)

All input are 3.3 V and 2.5 V compatible. Separate output power

) pins are used to decouple output noise from the internal

(V

DDQ

circuits and are 3.3 V and 2.5 V compatible.

high places the RAM in

DD

Parameter Synopsis

-250 -225 -200 -166 -150 -133 Unit

ns

4.0

3.8

3.5

3.0

2.5

3.0

4.0

285
350
440

6.5

6.5

205
235
315

2.7

3.0

4.4

265
320
410

7.0

7.0

195
225
295

3.0

5.0

245
295
370

7.5

7.5

185
210
265

3.5

6.0

220
260
320

8.0

8.0

175
200
255

3.8

6.7

210
240
300

8.5

8.5

165
190
240

4.0

7.5

185
215
265

8.5

8.5nsns

155
175
230

ns
ns

mA
mA
mA

mA
mA
mA

Pipeline

3-1-1-1

Flow

Through

2-1-1-1

t

(x18/x36)

KQ

t

(x72)

KQ

tCycle

Curr (x18)
Curr (x36)
Curr (x72)

t

KQ

tCycle

Curr (x18)
Curr (x36)
Curr (x72)

Rev: 1.06 9/2004 1/41 © 2001, GSI Technology
