GF Series
GF Series Low Impedance
Features
◆ Used in mother board, computer peripheral, etc.
◆ Load life 2000 Hrs aat 105 ℃
◆ Safety vent construction design.
◆ For detail specifications, please refer to Engineering Bulletin No. E127
Specifications
Item Performance Characteristics
Operating Temperature Range
Rate Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current(+20℃, max)
After 2 minutes whichever is greater measured with rated working voltage applied.
-55 to +105℃
6.3 to 100 VDC
4.7 to 4700 μF
±20% (120Hz, +20℃)
I≦0.01 CV or 3 (μA )
Dissipation Factor(tanδ)
Low Temperature Characteristics
(120Hz)
Load Life
Shelf Life
Working Vo l t a g e ( V D C ) 6 . 3 1 0 1 6 2 5 3 5 5 0 6 3 1 0 0
2 2 1 9 1 6 1 4 1 2 1 0 9 8D . F. (%) max.
For capacitance ＞1000 μF, add 2% per another 1000μF.
(+20℃ at 120Hz)
Impedance ratio (max)
Working Vo l t a g e 6 . 3 1 0 1 6 2 5 3 5 5 0 6 3 1 0 0
Z ( - 2 5℃) / Z ( 2 0℃)
Z ( - 4 0℃) / Z ( 2 0℃)
For Capacitance ＞1000 μF, Add 0.5 per another 1000μF for Z-25℃∕Z+20℃
Test conditions
Duration time :2000Hrs
Ambient temperature :+105℃
Applied voltage :Rated DC working voltage
After test requirements at +20℃
Capacitance change :≦± 20% of the initial measured value
Dissipation factor :≦ 200% of the initial specified value
Leakage current :≦ The initial specified value
Test conditions
Duration time :1000Hrs
Ambient temperature :+105℃
Applied voltage :None
After test requirements at +20℃:Same limits as Load life.
Pre-treatment for measurements shall be conducted after application of DC working voltage for 30
minutes.
4 3 3 3 3 3 2 2
8 6 4 3 3 3 3 3
Add 1 per another 1000μF for Z-40℃∕Z+20℃
47
Page 2
CapXon
CapXon
GF Series
Multiplier for Ripple Current vs. Frequency
CAP(μF)﹨Hz
Multiplier
CAP≦10
10＜CAP≦100
100＜CAP≦1000
1000＜CAP
50(60) 120 400 1K 10K 5 0 K - 1 0 0 K
0.47
0.59
0.76
0.85
0.52
0.58
0.63
0.62
0.72
0.78
0.80
0.84
0.87
0.89
0.90
0.91
0.97
0.97
0.98
0.98
1.0
1.0
1.0
1.0
Diagram of Dimensions: (Unit:mm)
Case Size
WV(SV)
μF
6.3
(8)
10
(13)
16
(20)
Multiplier for Ripple Current vs. Temperature
Temperature℃
Multiplier
25
(32)
Dφ
F
dφ
35
(44)
45
1.80601.50701.30851.45951.20
5
6.3
2.0
2.583.5105.0135.0167.5187.5
0.5 0.6 0.8
50
(63)
63
(79)
105
1.00
φDxL(mm)
100
(125)
4.7
10
22
33
47
100
220
330
470 8x11.5 8x11.5
1000 10x12.5
2200 10x25 13x20 13x25 13x35
3300 13x20 13x25 13x35
4700 13x30 13x35
5x11 5x11 6.3x11 6.3x11 8x11.5 8x11.5 10x12.5 10x25
6.3x11 6.3x11 8x11.5 8x11.5
6.3x11 8x11.5 8x11.5
8x16
10x12.5
8x20
10x16
10x20 13x20 13x25 16x25
— — — — — —
5x11 6.3x11 8x11.5 8x11.5 10x12.5
8x16
10x12.5
8x20
10x16
— — — — —
5x11 5x11
5x11 6.3x11
5x11 6.3x11 8x11.5
5x11 6.3x11 6.3x11 8x16
8x16
10x12.5
10x16 10x25 13x25 13x40
10x20 13x20
— — — —
10x16 10x25
13x30
16x20
16x35.5
18x31.5
13x30
16x20
16x35.5
18x31.5
—
48
Page 3
CapXon
CapXon
GF Series
Maximum Ripple Current
WV(SV)
μF
4.7
10
22
33
47
100
220
330
470
1000
2200
6.3
(8)
—
— — — — — —
— — — — —
— — — —
— —
200 242 360 410 560 730 720 890
360 390 575 750
395 540 740 990 1400 1850 1870 1650
600 750
1000
2160 2370 2750 3420
10
(13)
— — — — — —
1220
1400
16
(20)
200
990
1000
1840 2340 2780 3000
25
(32)
240 340 360 400 450
1260
1415
35
(44)
230 280 270 400
1000
1060
1850 2000
— — — —
50
(63)
220 200 320
1385 1315
(mA, 100KHz at 105℃)
63
(79)
135 170
2225
1970
2780
3230
100
(125)
105
1420
1270
1900
1700
—
3300
4700
2290 2720 3490
3200 3450
Maximum Impedance
WV(SV)
μF
4.7
10
22
33
47
100
220
330
470
1000
2200
3300
6.3
(8)
+20℃ -10℃ +20℃ -10℃ +20℃ -10℃ +20℃ -10℃ +20℃ -10℃ +20℃ -10℃ +20℃ -10℃ +20℃ -10℃
— — — — — — — — — — — — — —
— — — — — — — — — — — —
— — — — — — — — — —
— — — — — — — —
— — — —
0.40 1.30 0.28 1.10 0.25 0.55 0.15 0.45 0.09 0.26 0.075 0.22 0.14 0.50 0.12 0.50
0.25 0.90 0.15 0.45 0.14 0.40 0.075 0.25
0.15 0.45 0.11 0.38 0.080 0.25
0.095 0.25 0.075 0.25
0.055 0.15
0.025 0.065 0.025 0.05 0.022 0.045 0.015 0.038
0.026 0.055 0.021 0.045 0.018 0.04
0.050
0.042
10
(13)
— — — — —
— — — — — —
16
(20)
25
(32)
35
(44)
50
(63)
63
(79)
0.95 3.80 0.70 2.50
0.35 1.20 0.75 2.90 0.48 2.10
0.32 1.1 0.32 1.10 0.38 1.45 0.31 1.35
0.40 1.20 0.35 1.20 0.20 0.50 0.25 1.00 0.22 0.85 0.25 1.00
0.056
0.052
0.056
0.17
0.052
0.062
0.058
0.15
0.035 0.07 0.02 0.055 0.019 0.044 0.02 0.058
0.13
0.17
0.16
0.04
0.038
— — — — — — — — — —
0.038 0.12 0.028 0.09 0.045 0.15 0.045 0.014
0.16
0.13
0.022 0.07 0.03 0.07
0.12
0.17
0.045 0.12 0.075 0.30
0.16
— — — —
0.041
0.043
0.026
0.028
0.026
0.028
0.14
0.14
0.065
0.068
— — —
(Ω, 100K Hz)
100
(125)
1.60 5.90
0.065
0.25
0.075
0.25
0.032
0.010
0.038
0.012
— —
4700
0.02 0.04 0.019 0.04
— — — — — — — — — — — —
