GC70…F
BAR CLAMP FOR HOCKEY PUKS
Various lenghts of bolts and insulators
Pre-loaded to the specific clamping force
Flat clamping head for minimum
clamping head height
Four clamps styles
Gold iridite plating
User friendly clamping force indicator
UL94 certified insulation material
Dimensions in millimeters
T:
Max total height (see table)
S:
Clearance allowed ( see table)
Document GC70…FT001
GPS - Green Power Semiconductors SPA
Factory: Via Ungaretti 10, 16157 Genova, Italy
Phone: +39-010-667 8800
Fax: +39-010-667 8812
Web: www.gpsemi.it
E-mail: info@gpsemi.it
Green Power
Semic onduct ors
T
95
S15
14
50 up to 120
70
12
70
12
T
95
50 up to 120
14
S29
12
70
95
50 up to 120
14
T
S
95
T
S
70
14
50 up to 120
12
GC70BN...F GC70BR...F
GC70SR...FGC70SN...F
49
16.4±0.2
16.4±0.2
16.4±0.2
16.4±0.2
BAR CLAMP FOR HOCKEY PUKS GC70…F
Min Max
GC70S…F 620 770
GC70B…F 1100 1270
GC70…03F
GC70…05F
GC70…08F
GC70…10F
GC70…12F
V
RMS
1 min
UL File: E121562
°C
°C
°C
* Other clamping forces available: contact factory
ORDERING INFORMATION TABLE
Clamps can be ordered using the following part numbering system GC70 B N A B 20 F S
(1) (2) (3) (4) (5) (6)
(1) Construction type:
(2) Insulator position:
(3) Insulator code:
(4) Bolt code:
(5) Clamping force (in kN):
(6) Special accessories K: Total thickness of the assembly to be clamped
For thicknesses S'
Min
< K < S
Min
an additional 4 mm thick
metal spacer is needed ( see list of special accessories)
Type GC70BN…F: suggested insulator/bolt types
S' Min[mm]** S Min [mm] SMax [mm] (3) Ins. Lenght [mm] Bolt Lenght [mm]
47 51 58 B 70
57 61 68 B/C 70/95*
67 71 78 C 95
77 81 88 C 95
87 91 98 C/D 95/120
97 101 108 D 120
** with additional metal spacer only
Type GC70BR…F: suggested insulator/bolt types
S' Min[mm]** S Min [mm] SMax [mm] (3) Ins. Lenght [mm] Bolt Lenght [mm]
47 51 58 B 70
57 61 68 B/C 70/95*
67 71 78 C 95
77 81 88 C 95
87 91 98 C/D 95/120
97 101 108 D 120
** with additional metal spacer only
Document GC70…FT001
R = lower side
see table below
see table below
03
Values
g
12
N = upper side
Weight
Types/Testing
conditions/Notes
UnitParameter
Insulation Voltage 3000
Insulating Material Noryl
Clamping Force* kN
03
05
08
10
Max. working temperature 110
Min. working temperature -30
Storage temp. -40/110
B = with double bar
S = with single bar
05
08
12
blank = no accessories
S = extra metal spacer
10
Allowed clearance S Insulator choice Bolt choice
Max height
(4)
A
E
F
B
C
D
130
D
Allowed clearance S Insulator choice Bolt choice
(4)
A
E
B
C
D
110
120
130
140
150
160
110
120
T [mm]
120
130
140
150
160
170
Max height
T [mm]
130
140
150
150 170
160
180
140
160
Green Power
Semiconductors
K
3
4
K
In the interest of product improvement Green Power Semiconductors reserves the right to change any specification given in this data
sheet without notice.
BAR CLAMP FOR HOCKEY PUKS GC70…F
Type GC70SN…F: suggested insulator/bolt types
S' Min[mm]** S Min [mm] SMax [mm] (3) Ins. Lenght [mm] Bolt Lenght [mm]
47 51 58 B 70
57 61 68 B/C 70/95*
67 71 78 C 95
77 81 88 C 95
87 91 98 C/D 95/120
97 101 108 D 120
** with additional metal spacer only
Type GC70SR…F: suggested insulator/bolt types
S' Min[mm]** S Min [mm] SMax [mm] (3) Ins. Lenght [mm] Bolt Lenght [mm]
62 66 73 B 70
72 76 83 B 70
82 86 93 B/C 70/95
92 96 103 C/D 95
102 106 113 C/D 95/120
112 116 123 D 120
** with additional metal spacer only
SPECIAL ACCESSORIES
The following special accessories are available
Metal spacer
Document GC70…FT001
F 160
(4)
C 130
D 140
A 110
B
Allowed clearance S Insulator choice Bolt choice
E 150
120
E 150
F 160
C 130
D 140
(4)
A 110
B 120
Allowed clearance S Insulator choice Bolt choice Max height
T [mm]
122
132
142
152
162
172
Max height
167
177
187
T [mm]
137
147
157
Green Power
Semiconductors
In the interest of product improvement Green Power Semiconductors reserves the right to change any specification given in this data
sheet without notice.
3
4
