Page 1
FFPF10U30DN
Features
• Ultrafast with soft recovery
• Low forward voltage
Applications
• Power switching circuits
• Output rectifiers
• Freewheeling diodes
• Switching mode power supply
1 2 3
ULTRA FAST RECOVERY POWER RECTIFIER
TO-220F
FFPF10U30DN
1. Anode 2.Cathode 3. Anode
Absolute Maximum Ratings (per diode) T
Symbol Parameter Value Units
V
RRM
I
F(AV)
I
FSM
T
J, TSTG
Peak Repetitive Reverse Voltage 300 V
Average Rectified Forward Current @ TC = 100°C10 A
Non-repetitive Peak Surge Current
60Hz Single Half-Sine Wave
Operating Junction and Storage Temperature - 65 to +150 °C
=25°°°°C unless otherwise noted
C
100 A
Thermal Characteristics
Symbol Parameter Value Units
R
θJC
Electrical Characteristics
Symbol Parameter Min. Typ. Max. Units
V
FM
*
I
RM
*
t
rr
I
rr
Q
rr
W
AVL
* Pulse Test: Pulse Width=300µs, Duty Cycle=2%
Maximum Thermal Resistance, Junction to Case 2.1 °C/W
(per diode) TC=25 °°°°C unless otherwise noted
Maximum Instantaneous Forward Voltage
I
I
Maximum Instantaneous Reverse Current
Maximum Reverse Rec overy T ime
Maximum Reverse Recovery Current
Maximum Reverse Recovery Charge
=10A, di/dt = 200A/µs)
(I
F
Avalanche Energy 1.0 - - mJ
= 10A
F
= 10A
F
@ rated V
= 25 °C
T
C
T
= 100 °C
C
TC = 25 °C
R
= 100 °C
T
C
-
-
-
-
-
-
-
-
-
-
-
-
-
-
1.2
1.1
10
100
60
4.5
135
V
µA
ns
A
nC
©2001 Fairchild Semiconductor Corporation
Rev. A1, March 2001
Page 2
Typical CharacteristicsTypical Characteristics
FFPF10U30DN
50
10
[A]
F
1
TC = 100oC
TC = 25oC
Forward Current , I
0.1
0.0 0.5 1.0 1.5 2.0
Forward Voltage , VF [V]
Figure 1. Typical Forward Voltage Drop
vs. Forward Current
250
Typical Capacitance
200
150
100
Capacitance , Cj [pF]
50
at 0V = 239 pF
1000
100
[µA]
R
10
1
0.1
Reverse Current , I
0.01
0.001
0 50 100 150 200 250 300
TC = 100oC
TC = 25oC
Reverse Voltage , VR [V]
Figure 2. Typical Reverse Current
vs. Reverse Voltage
60
[ns]
rr
50
40
IF = 10A
Tc = 25oC
0
0.1 1 10 100
Reverse Voltage , VR [V]
Figure 3. Typical Junction Capacitance
Reverse Recovery Time , t
30
100 500
di/dt [A/µs]
Figure 4. Typical Rever se Recovery Time
vs. di/dt
8
7
[A]
rr
6
5
4
3
2
1
Reverse Recovery Current , I
0
100 500
IF = 10A
TC = 25oC
di/dt [A/µs]
Figure 5. Typical Reverse Recovery Current
15
[A]
F(AV)
10
DC
5
Average Forward Current , I
0
60 80 100 120 140 160
Case Temperature , TC [oC]
Figure 6. Forward Current Derating Curve
vs. di/dt
©2001 Fairchild Semiconductor Corporation Rev. A1, March 2001
Page 3
Package Dimensions
±0.10
3.30
±0.20
15.80
10.16
(7.00)
TO-220F
±0.20
ø3.18
±0.10
±0.20
6.68
(1.00x45°)
2.54
(0.70)
FFPF10U30DN
±0.20
±0.20
15.87
±0.30
9.75
MAX1.47
0.80
0.35
2.54TYP
±0.20
[2.54
±0.10
±0.10
(30°)
#1
0.50
+0.10
–0.05
2.76
±0.20
2.54TYP
]
9.40
±0.20
[2.54
±0.20
±0.20
]
4.70
©2001 Fairchild Semiconductor Corporation
Dimensions in Millimeters
Rev. A, March 2001
