FFAF10U40DN
Features
• Ultrafast with soft recovery
• Low forward voltage
Applications
• Power switching circuits
• Output rectifiers
• Freewheeling diodes
• Switc hing mod e po w er supply
1 2 3
ULTRA FAST RECOVERY POWER RECTIFIER
TO-3PF
FFAF10U40DN
1. Anode 2.Cathode 3. Anod e
Absolute Maximum Ratings
Symbol Parameter Value Units
V
RRM
I
F(AV)
I
FSM
T
J, TSTG
Peak Repetit iv e Reve rse Voltage 400 V
Average Rectified Forward Current @ TC = 100°C10 A
Non-repetitive Peak Surge Current
60Hz Single H a lf- Sine Wave
Operating Junction and Storage Temperature - 65 to +150 °C
(per diode) TC=25°°°°C unless otherwise noted
100 A
Thermal Characteristics
Symbol Parameter Value Units
R
θJC
Electrical C haract eri stics
Symbol Parameter Min. Typ. Max. Units
V
FM
*
I
RM
*
t
rr
I
rr
Q
rr
W
AVL
* Pulse Test: Pulse Width=300µs, Duty Cycle=2%
Maxi mum Ther m al Resis t ance, Junct ion to C ase 4.0 °C/W
(per diode) TC=25 °°°°C unless oth erw is e note d
Maximum Instantaneous Forward Voltage
I
I
Maximum Instantaneous Reverse Current
Maximum Reverse Recovery Time
Maximum Reverse Recovery Current
Maximum Reverse Recovery Charge
(I
=10A, di/dt = 200A/µs)
F
Avalanche Energy 1.0 - - mJ
= 10A
F
= 10A
F
@ rated V
= 25 °C
T
C
T
= 100 °C
C
TC = 25 °C
R
T
= 100 °C
C
-
-
-
-
-
-
-
-
-
-
-
-
-
-
1.4
1.3
30
300
50
4.5
113
V
µA
ns
A
nC
©2000 Fai r ch i ld Semiconductor Inter national
Rev. F, September 2000
Page 2
Typical C h aracteristic sTypical C h aracteristic s
FFAF10U40DN
40
10
[A]
F
1
TC = 100oC
TC = 25oC
Forward Current , I
0.1
0.0 0.5 1.0 1.5 2.0
Forward Voltage , VF [V]
Figure 1. Typical Forward Voltage Drop
vs. Forward Current
500
450
400
350
300
250
200
150
Capacitance , Cj [pF]
100
50
0.1 1 10 100
Reverse Voltage , VR [V]
Typical Capacitance
at 0V = 450 pF
1000
TC = 100oC
100
A]
µ
[
R
10
TC = 25oC
Reverse Current , I
0.01
0.001
1
0.1
50 100 150 200 250 300 350 400
Reverse Voltage , VR [V]
Figure 2. Typical Reverse Current
vs. Revers e Voltag e
55
IF = 10A
50
[ns]
rr
45
40
35
30
Reverse Recovery Time , t
25
100 500
di/dt [A/µs]
TC = 25oC
Figure 3. Typical Junction Capacitance
Figure 4. Typical Reverse Recovery Time
vs. di/dt
9
8
[A]
rr
7
6
5
4
3
2
Reverse Recovery Current , I
1
100 500
IF = 10A
TC = 25oC
di/dt [A/µs]
Figure 5. Typical Reverse Recovery Current
16
[A]
14
F(AV)
12
10
8
6
4
2
Averag e Forwa rd Cur rent , I
0
60 80 100 120 140 160
DC
Case Temperature , TC [oC]
Figure 6. Forward Current Derati ng Curve
vs. di/dt
©2000 Fai r ch i ld Semiconductor Inter national Rev. F, September 2000
Page 3
Package Di men sio n s
±0.20
4.50
15.50
TO-3PF
±0.20
ø3.60
±0.20
±0.20
10.00
10°
5.50
3.00
(1.50)
FFAF10U40DN
±0.20
±0.20
±0.20
26.50
±0.20
14.80
±0.20
±0.20
14.50
16.50
2.00
2.00
4.00
0.75
5.45TYP
[5.45
±0.20
3.30
±0.20
±0.20
±0.20
+0.20
–0.10
±0.30
±0.20
2.00
]
±0.20
2.00
2.00
5.45TYP
[5.45
±0.20
2.50
±0.20
±0.30
±0.20
5.50
]
0.85
±0.20
16.50
±0.03
0.90
±0.20
1.50
2.00
3.30
+0.20
–0.10
±0.20
±0.20
±0.20
23.00
±0.20
22.00
©2000 Fairchild Semiconductor International
Dimensions in Millimeters
Rev. F, September 2000
