FDMS86252

Power 56

Pin 1

Bottom

Top

2 1

and

General Description

This N-Channel MOSFET is produced using Fairchild Semiconductor’s advanced Power Trench been especially tailored to minimize the on-state resistance and yet maintain superior switching performance.

Application

 DC-DC Conversion

N-Channel PowerTrench® MOSFET

150 V, 16 A, 51 mΩ Features

 Max r  Max r  Advanced package and silicon combination for low r

high efficiency

 MSL1 robust package design  100% UIL tested  RoHS Compliant

= 51 mΩ at VGS = 10 V, ID = 4.6 A

DS(on)

= 70 mΩ at VGS = 6 V, ID = 3.9 A

DS(on)

August 2010

process that has

FDMS86252 N-Channel PowerTrench

MOSFET

MOSFET Maximum Ratings T

Symbol Parameter Ratings Units

, T

STG

Drain to Source Voltage 150 V Gate to Source Voltage ±20 V Drain Current -Continuous (Package limited) TC = 25 °C 16

-Continuous (Silicon limited) T

-Continuous T

-Pulsed 20 Single Pulse Avalanche Energy (Note 3) 50 mJ Power Dissipation TC = 25 °C 69 Power Dissipation T Operating and Storage Junction Temperature Range -55 to +150 °C

= 25 °C unless otherwise noted

= 25 °C 24

= 25 °C (Note 1a) 4.6

= 25 °C (Note 1a) 2.5

Thermal Characteristics

θJC

θJA

Package Marking and Ordering Information

Device Marking Device Package Reel Size Tape Width Quantity

FDMS86252 FDMS86252 Power 56 13 ’’ 12

Thermal Resistance, Junction to Case 1.8 Thermal Resistance, Junction to Ambient (Note 1a) 50

mm 3000 units

°C/W

www.fairchildsemi.com

Page 2

FDMS86252 N-Channel PowerTrench

Electrical Characteristics T

= 25 °C unless otherwise noted

Symbol Parameter Test Conditions Min Typ Max Units

Off Characteristics

ΔBV ΔT

DSS

GSS

DSS

DSS J

Drain to Source Breakdown Voltage I Breakdown Voltage Temperature

Coefficient Zero Gate Voltage Drain Current V Gate to Source Leakage Current V

= 250 μA, VGS = 0 V 150 V

= 250 μA, referenced to 25 °C 106 mV/°C

= 120 V, V

= ±20 V, V

= 0 V1μA

= 0 V ±100 nA

On Characteristics

GS(th)

ΔV ΔT

DS(on)

GS(th)

Gate to Source Threshold Voltage VGS = VDS, I Gate to Source Threshold Voltage

Temperature Coefficient

Static Drain to Source On Resistance

Forward Transconductance V

= 250 μA, referenced to 25 °C -9 mV/°C

= 10 V, ID = 4.6 A 43.9 51

= 6 V, ID = 3.9 A 50.5 70

= 10 V, ID = 4.6 A,

= 125 °C

= 10 V, ID = 4.6 A15S

= 250 μA 2.0 2.8 4.0 V

83 96

Dynamic Characteristics

iss

oss

rss

Input Capacitance Output Capacitance 74 115 pF Reverse Transfer Capacitance 4.3 10 pF

= 75 V, VGS = 0 V,

f = 1 MHz

Gate Resistance 0.4 Ω

678 905 pF

mΩ

MOSFET

Switching Characteristics

d(on)

d(off)

Q Q Q Q

g g gs gd

Turn-On Delay Time Rise Time 2.3 10 ns Turn-Off Delay Time 15 27 ns Fall Time 3.2 10 ns Total Gate Charge V Total Gate Charge V Gate to Source Charge 2.8 nC Gate to Drain “Miller” Charge 2.4 nC

= 75 V, ID = 4.6 A,

= 10 V, R

= 0 V to 10 V

= 0 V to 5 V6.18.6nC

GEN

Drain-Source Diode Characteristics

= 0 V, IS = 2 A (Note 2) 0.75 1.2

Notes:

1. R

is determined with the devi ce m ount ed on a 1 in2 pad 2 oz copper pad on a 1.5 x 1.5 in. board of FR-4 material. R

θJA

the user's board design.

Source-Drain Diode Forward Voltage Reverse Recovery Time

Reverse Recovery Charge 61 98 nC

a. 50 °C/W when mounted on a

1 in

pad of 2 oz copper.

= 0 V, IS = 4.6 A (Note 2) 0.80 1.3

= 4.6 A, di/dt = 100 A/μs

= 6 Ω

= 4.6 A

= 75 V,

θJC

7.7 16 ns

11 15 nC

56 90 ns

is guaranteed by design while R

b. 125 °C/W when mounted on a minimum pad of 2 oz copper.

is determined by

θCA

2. Pulse Test: Pulse Width < 300 μs, Duty cycle < 2.0%.

3. Starting TJ = 25 °C, L = 1 mH, IAS = 10 A, VDD = 135 V, VGS = 10 V.

www.fairchildsemi.com

Page 3

FDMS86252 N-Channel PowerTrench

012345

VGS = 4.5 V

VGS = 5.5 V

VGS = 6 V

PULSE DURATION = 80 μs DUTY CYCLE = 0.5% MAX

VGS = 5 V

VGS = 10 V

, DRAIN CURRENT (A)

, DRAIN TO SOURCE VOLTAGE (V)

0 5 10 15 20

VGS = 6 V

VGS = 5 V

PULSE DURATION = 80 μs DUTY CYCLE = 0.5% MAX

NORMALIZED

DRAIN TO SOURCE ON-RESISTANCE

, DRAIN CURRENT (A)

= 5.5 V

VGS = 4.5 V

= 10 V

-75 -50 -25 0 25 50 75 100 125 150

0.4

0.6

0.8

1.0

1.2

1.4

1.6

1.8

2.0

2.2

2.4

ID = 4.6 A V

= 10 V

NORMALIZED

DRAIN TO SOURCE ON-RESISTANC E

, JUNCTION TEMPERATURE (

45678910

100

150

200

TJ = 125 oC

ID = 4.6 A

TJ = 25 oC

, GATE TO SOURCE VOL TAG E (V)

DS(on)

DRAIN TO

SOURCE ON-RESISTANCE

(mΩ)

PULSE DURATION = 80 μs DUTY CYCLE = 0.5% MAX

23456

TJ = 150 oC

= 5 V

PULSE DURATION = 80 μs DUTY CYCLE = 0.5% MAX

TJ = -55 oC

TJ = 25 oC

, DRAIN CURRENT (A)

VGS, GATE TO SOURCE VOLTAGE (V)

0.0 0.2 0.4 0.6 0.8 1.0 1.2

0.001

0.01

0.1

TJ = -55 oC

TJ = 25 oC

TJ = 150 oC

= 0 V

, REVERSE DRAIN CURRENT (A)

VSD, BODY DIODE FORWARD VOLTAGE (V)

Typical Characteristics T

Figure 1.

On Region Characteristics Figure 2.

= 25 °C unless otherwise noted

Norm a l i z e d O n -Resistan c e

vs Drain Current and Gate Voltage

MOSFET

Fi g ure 3 . Nor m aliz e d On R esis t ance

vs Junction Temperature

Figure 5. Transfer Characteristics

Figure 4.

On-Resistance vs Gate to

Source Voltage

Figure 6.

Source to Drain Diode

Forward Voltage vs Source Current

www.fairchildsemi.com

Page 4

FDMS86252 N-Channel PowerTrench

036912

ID = 4.6 A

VDD = 100 VV

= 50 V

, GATE TO SOURCE VOLTAGE (V)

Qg, GATE CHARGE (nC)

VDD = 75 V

0.1 1 10 100

100

1000

f = 1 MHz V

= 0 V

CAPACITANCE (pF)

VDS, DRAIN TO SOURCE VOLTAGE (V)

rss

oss

iss

0.001 0.01 0.1 1 10

TJ = 100 oC

TJ = 25 oC

TJ = 125 oC

tAV, TIME IN AVAL ANCHE (ms)

, AVALANCHE CURRENT (A)

25 50 75 100 125 150

= 6 V

Limited by Package

θJC

= 1.8 oC/W

= 10 V

, DRAIN CURRENT (A)

, CASE TEMPERATURE (

0.01 0.1 1 10 100 800

0.001

0.01

0.1

1 s

100 μs

10 ms

10 s

100 ms

1 ms

, DRAIN CURRENT (A)

VDS, DRAIN to SOURCE VOLTAGE (V)

THIS A REA IS LIMITED BY r

DS(on)

SINGLE PULSE T

= MAX RATED

θJA

= 125

C/W

= 25

10-410-310-210

-1

110

100 1000

0.5

100

1000

2000

SINGLE PULSE R

θJA

= 125

C/W

= 25

VGS = 10 V

), PEAK TRANSIENT POWER (W)

t, PULSE WIDTH (sec)

Typical Characteristics T

Figure 7.

Gate Charge Characteristics

= 25 °C unless otherwise noted

Figure 8.

Capacitance vs Drain

to Source Voltage

MOSFET

Figure 9.

Unc l a m p e d I ndu c t i v e

Switching Capability

Figure 11. Forward Bias Safe

erating Area

Figure 10.

Ma ximum Con tin uous Drai n

Current vs Case Temperature

Figure 12.

Sing le Pulse Maximum

Power Dissipation

www.fairchildsemi.com

Page 5

FDMS86252 N-Channel PowerTrench

-4

-3

-2

-1

110

100 1000

0.0001

0.001

0.01

0.1

SINGLE PULSE R

θJA

= 125 oC/W

DUTY CYCLE-DESCENDING ORDER

NORMALIZED THERMAL

IMPEDANCE,

θJA

t, RECTANGULAR PULSE DURATION (sec)

D = 0.5

0.2

0.1

0.05

0.02

0.01

NOTES: DUTY FACTOR: D = t1/t

PEAK TJ = PDM x Z

θJA

x R

θJA

+ T

Typical Characteristics T

Figure 13.

= 25 °C unless otherwise noted

Junction-to-Ambient Transient Thermal Response Curve

MOSFET

www.fairchildsemi.com

Page 6

FDMS86252 N-Channel PowerTrench

Dimensional Outline and Pad Layout
