FDC37B72x

128 Pin Enhanced Super I/O Controller with

ACPI Support

FEATURES

• 5 Volt Operation

• PC98/99 and ACPI 1.0 Compliant

• Battery Back-up for Wake-Events

• ISA Host Interface

• ISA Plug-and-Play Compatible Register

Set

- 12 IRQ Options

- 15 Serial IRQ Options

- 16 Bit Address Qualification

- Four DMA Options

- 12mA AT Bus Drivers

• BIOS Buffer

• 20 GPI/O Pins

• 32 kHz Standby Clock Output

• Soft Power Management

• ACPI/PME Support

• SCI/SMI Support

- Watchdog timer

- Power Button Override Event

- Either Edge Triggered Interrupts

• Intelligent Auto Power Management

- Shadowed Write-only Registers

- Programmable Wake-up Event Interface

• 8042 Keyboard Controller

- 2K Program ROM

- 256 Bytes Data RAM

- Asynchronous Access to Two Data

Registers and One Status Register

- Supports Interrupt and Polling Access

- 8 Bit Timer/Counter

- Port 92 Support

- Fast Gate A20 and Hardware Keyboard

Reset

• 2.88MB Super I/O Floppy Disk Controller

- Relocatable to 480 Different Addresses

- Licensed CMOS 765B Floppy Disk

Controller

- Advanced Digital Data Separator

- SMSC's Proprietary 82077AA

Compatible Core

- Sophisticated Power Control Circuitry

(PCC) Including Multiple Powerdown Modes for Reduced Power Consumption

- Supports Two Floppy Drives Directly

- Software Write Protect

- FDC on Parallel Port

- Low Power CMOS Design

- Supports Vertical Recording Format

- 16 Byte Data FIFO

- 100% IBM® Compatibility

- Detects All Overrun and Underrun

Conditions

- 24mA Drivers and Schmitt Trigger Inputs

• Enhanced FDC Digital Data Separator

- Low Cost Implementation

- No Filter Components Required

- 2 Mbps, 1 Mbps, 500 Kbps, 300 Kbps,

250 Kbps Data Rates

Page 2

- Programmable Precompensation

Modes

• Serial Ports

- Relocatable to 480 Different

Addresses

- Two High Speed NS16C550A Compatible UARTs with Send/Receive 16 Byte FIFOs

- Programmable Baud Rate

Generator

- Modem Control Circuitry Including

230K and 460K Baud

- IrDA 1.0, HP-SIR, ASK-IR Support

- Ring Wake Filter

• Multi-Mode Parallel Port with ChiProtect



- Relocatable to 480 Different Addresses

- Standard Mode

- IBM PC/XT®, PC/AT®, and PS/2 Compatible Bidirectional ParallelPort



- Enhanced Mode

- Enhanced Parallel Port (EPP) Compatible EPP 1.7 and EPP 1.9 (IEEE 1284 Compliant)

- High Speed Mode

- Microsoft and Hewlett Packard Extended Capabilities Port (ECP) Compatible (IEEE 1284 Compliant)

- Incorporates ChiProtect Circuitry for Protection Against Damage Due to Printer Power-On

- 14 mA Output Drivers

• 128 Pin QFP Package

Page 3

TABLE OF CONTENTS

FEATURES....................................................................................................................................... 1

GENERAL DESCRIPTION................................................................................................................. 5

DESCRIPTION OF PIN FUNCTIONS ................................................................................................ 7

BUFFER TYPE DESCRIPTIONS........................................................................................ 10

GENERAL PURPOSE I/O PINS....................................................................................................... 11

REFERENCE DOCUMENTS ........................................................................................................... 12

FUNCTIONAL DESCRIPTION.........................................................................................................14

SUPER I/O REGISTERS.................................................................................................... 14

HOST PROCESSOR INTERFACE..................................................................................... 14

FLOPPY DISK CONTROLLER ........................................................................................................ 15

FDC INTERNAL REGISTERS.......................................................................................................... 15

COMMAND SET/DESCRIPTIONS................................................................................................... 38

INSTRUCTION SET ........................................................................................................................ 41

DATA TRANSFER COMMANDS........................................................................................ 53

CONTROL COMMANDS.................................................................................................... 62

SERIAL PORT (UART).................................................................................................................... 69

INFRARED INTERFACE.................................................................................................... 85

PARALLEL PORT............................................................................................................................ 86

IBM XT/AT COMPATIBLE, BI-DIRECTIONAL AND EPP MODES ....................................... 88

EXTENDED CAPABILITIES PARALLEL PORT................................................................................ 94

OPERATION.....................................................................................................................102

PARALLEL PORT FLOPPY DISK CONTROLLER...........................................................................107

POWER MANAGEMENT ................................................................................................................109

UART POWER MANAGEMENT........................................................................................113

PARALLEL PORT.............................................................................................................113

INTERNAL PWRGOOD....................................................................................................113

32.768 KHZ STANDBY CLOCK OUTPUT...........................................................................114

SERIAL IRQ...................................................................................................................................115

BIOS BUFFER................................................................................................................................120

GENERAL PURPOSE I/O...............................................................................................................121

DESCRIPTION .................................................................................................................121

RUN STATE GPIO DATA REGISTER ACCESS................................................................122

GPIO CONFIGURATION..................................................................................................123

WATCH DOG TIMER.....................................................................................................................126

8042 KEYBOARD CONTROLLER DESCRIPTION..........................................................................128

SOFT POWER MANAGEMENT......................................................................................................136

BUTTON OVERRIDE FEATURE.......................................................................................139

Page 4

ACPI/PME/SMI FEATURES ............................................................................................................141

ACPI FEATURES..............................................................................................................141

PME SUPPORT................................................................................................................143

ACPI, PME AND SMI REGISTERS ...................................................................................143

EITHER EDGE TRIGGERED INTERRUPTS...................................................................................155

CONFIGURATION..........................................................................................................................158

SYSTEM ELEMENTS .......................................................................................................158

CONFIGURATION SEQUENCE......................................................................................... 10

CONFIGURATION REGISTERS .......................................................................................161

OPERATIONAL DESCRIPTION......................................................................................................204

MAXIMUM GUARANTEED RATINGS*..............................................................................204

DC ELECTRICAL CHARACTERISTICS.............................................................................204

AC TIMING.......................................................................................................................209

CAPACITIVE LOADING....................................................................................................209

ECP PARALLEL PORT TIMING........................................................................................234

80 Arkay Dr. Hauppauge, NY 11788 (516) 435-6000 FAX: (516) 273-3123

Page 5

GENERAL DESCRIPTION

The FDC37B72x incorporates a keyboard interface, SMSC's true CMOS 765B floppy disk controller, advanced digital data separator, 16 byte data FIFO, two 16C550 compatible UARTs, one Multi-Mode parallel port which includes ChiProtect circuitry plus EPP and ECP support, on-chip 12 mA AT bus drivers, and two floppy direct drive support, soft power management and SMI support and Intelligent Power Management including PME and SCI/ACPI support. The true CMOS 765B core provides 100% compatibility with IBM PC/XT and PC/AT architectures in addition to providing data overflow and underflow protection. The SMSC advanced digital data separator incorporates SMSC's patented data separator technology, allowing for ease of testing and use. Both onchip UARTs are compatible with the NS16C550. The parallel port is compatible with IBM PC/AT architecture, as well as EPP and ECP. The FDC37B72x incorporates sophisticated power control circuitry (PCC) which includes support for keyboard, mouse, modem ring, power button support and other wake-up events. The PCC supports multiple low power down modes.

The FDC37B72x provides features for compliance with the “Advanced Configuration and Power Interface Specification” (ACPI).

These features include support of both legacy and ACPI power management models through the selection of SMI or SCI. It implements a power button override event (4 second button hold to turn off the system) and either edge triggered interrupts.

The FDC37B72x provides support for the ISA Plug-and-Play Standard (Version 1.0a) and provides for the recommended functionality to support Windows '95/’98 and PC98/PC99. Through internal configuration registers, each of the FDC37B72x's logical device's I/O address, DMA channel and IRQ channel may be programmed. There are 480 I/O address location options, 12 IRQ pin options or Serial IRQ option, and four DMA channel options for each logical device.

The FDC37B72x Floppy Disk Controller and data separator do not require any external filter components and are therefore easy to use, offer lower system cost and reduced board area. The FDC is software and register compatible with SMSC's proprietary 82077AA core.

IBM, PC/XT and PC/AT are registered trademarks and PS/2 is a trademark of International Business Machines Corporation SMSC is a registered trademark and Ultra I/O, ChiProtect, and Multi-Mode are trademarks of Standard Microsystems Corporation

Page 6

PD7

12345678910111213141516171819202122232425262728293031333435363738

DRVDEN0

DRVDEN1/GP52/IRQ8/nSMI

nMTR0

nDS1/GP17

nDS0

nMTR1/GP16

VSS

nDIR

nSTEP

nWDATA

nWGATE

nHDSEL

nINDEX

nTRK0

nWRTPRT

nRDATA

nDSKCHG

CLK32OUT

nPOWERON

BUTTON_IN

nPME/SCI/IRQ9

CLOCKI

SA9

SA0

SA1

SA2

SA4

SA6

SA7

SA8

SA3

SA5

SA10

SA11

SA12

SA13

SA14

SA15

PD0

nSLCTIN

nINIT

VCC

nROMOE/IRQ12/GP54/EETI

nROMCS/IRQ11/GP53/EETI

RD7/IRQ10/GP67

RD6/IRQ8/GP66

RD5/IRQ7/GP65

RD4/IRQ6/GP64/P17

RD3/IRQ5/GP63/WDT

RD2/IRQ4/GP62/nRING

RD1/IRQ3/GP61/LED

RD0/IRQ1/GP60/nSMI

KCLK

KDAT

VTR

XTAL2

AVSS

XTAL1

GP15/IRTX2

VBAT

GP14/IRRX2

GP13/LED

GP12/WDT/P17/EETI

GP11/nRING/EETI

GP10/nSMI

A20M

KBDRST

VSS

MCLK

MDAT

PD6

PD5

PD4

PD3

PD2

PD1

102

101

100

VSS

SLCT

BUSY nACK

nERROR

nALF

nSTROBE

RXD1

TXD1

nDSR1

nRTS1/SYSOP

nCTS1 nDTR1

nRI1

nDCD1

nRI2 VCC

nDCD2

RXD2/IRRX

TXD2/IRTX

nDSR2

nRTS2

nCTS2

nDTR2

103 104 105 106

107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128

FDC37B72x

128 Pin QFP

63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39

IOCHRDY TC VCC DRQ3 nDACK3 DRQ2 nDACK2 DRQ1 nDACK1 DRQ0 nDACK0 RESET_DRV SD7 SD6 SD5 SD4 VSS SD3 SD2 SD1 SD0 AEN nIOW nIOR SER_IRQ/IRQ15 PCI_CLK/IRQ14/GP50

FIGURE 1 - FDC37B72x PIN CONFIGURATION

Page 7

DESCRIPTION OF PIN FUNCTIONS

TABLE 1 - DESCRIPTION OF PIN FUNCTIONS

No./QFP NAME TOTAL SYMBOL BUFFER TYPE

PROCESSOR/HOST INTERFACE (40)

44-47,

49-52 23-38 16-bit System Address Bus 16 SA[0:15] I

43 Address Enable 1 AEN I 64 I/O Channel Ready 1 IOCHRDY OD12 53 ISA Reset Drive 1 RESET_DRV IS 40 Serial IRQ/IRQ15 1 SER_IRQ IO12 39 PCI Clock/IRQ14/GP50 1 PCI_CLK IO12 55 DMA Request 0 1 DRQ0 O12 57 DMA Request 1 1 DRQ1 O12 59 DMA Request 2 1 DRQ2 O12 54 DMA Acknowledge 0 1 nDACK0 I 56 DMA Acknowledge 1 1 nDACK1 I 58 DMA Acknowledge 2 1 nDACK2 I 61 DMA Request 3 1 DRQ3 O12 60 DMA Acknowledge 3 1 nDACK3 I 63 Terminal Count 1 TC I 41 I/O Read 1 nIOR I 42 I/O Write 1 nIOW I

22 14.318MHz Clock Input 1 CLOCKI ICLK 66 32.768kHz Crystal Input 1 XTAL1 ICLK 68 32.768kHz Crystal Driver 1 XTAL2 OCLK2 18 32.768kHz Clock Out 1 CLK32OUT O8

62, 93,

121

7, 48,

74, 104

67 Analog Ground 1 AVSS 69 Trickle Supply Voltage 1 VTR 65 Battery Voltage 1 VBAT

19 Power On 1 nPOWERON OD24 20 Button In 1 BUTTON_IN I 21 Power Management Event/SCI/IRQ9 1 nPME O12

16 Read Disk Data 1 nRDATA IS 11 Write Gate 1 nWGATE O24

System Data Bus 8 SD[0:7] IO12

CLOCKS (4)

POWER PINS (10)

+5V Supply Voltage 3 VCC Digital Ground 4 VSS

POWER MANAGEMENT (3)

FDD INTERFACE (16)

Page 8

No./QFP NAME TOTAL SYMBOL BUFFER TYPE

10 Write Disk Data 1 nWDATA O24 12 Head Select 1 nHDSEL O24

8 Step Direction 1 nDIR O24 9 Step Pulse 1 nSTEP O24

17 Disk Change 1 nDSKCHG IS

5 Drive Select 0 1 nDS0 O24 6 Drive Select 1/GP17 1 nDS1 IO24 3 Motor On 0 1 nMTR0 O24

4 Motor On 1/GP16 1 nMTR1 IO24 15 Write Protected 1 nWRTPRT IS 14 Track 0 1 nTRKO IS 13 Index Pulse Input 1 nINDEX IS

1 Drive Density Select 0 1 DRVDEN0 O24

2 Drive Density Select 1/GP52/IRQ8/nSMI 1 DRVDEN1 IO24

GENERAL PURPOSE I/O (6)

77 General Purpose 10/nSMI 1 GP10 IO12 78 General Purpose 11/nRING/EETI (Note 4) 1 GP11 IO4 79 General Purpose 12/WDT/P17/P12/EETI

1 GP12 IO4

(Note 4) 80 General Purpose 13/LED Driver 1 GP13 IO24 81 General Purpose 14/Infrared Rx 1 GP14 IO4 82 General Purpose 15/Infrared Tx (Note 3) 1 GP15 IO24

BIOS INTERFACE (10)

83 ROM Bus 0/IRQ1/GP60/nSMI 1 RD0 IO12 84 ROM Bus 1/IRQ3/GP61/LED 1 RD1 IO24 85 ROM Bus 2/IRQ4/GP62/nRING 1 RD2 IO12 86 ROM Bus 3/IRQ5/GP63/WDT 1 RD3 IO12 87 ROM Bus 4/IRQ6/GP64/P17/P12 1 RD4 IO12 88 ROM Bus 5/IRQ7/GP65 1 RD5 IO12 89 ROM Bus 6/IRQ8/GP66 1 RD6 IO12 90 ROM Bus 7/IRQ10/GP67 1 RD7 IO12 91 nROMCS/IRQ11/GP53/EETI (Note 4) 1 nROMCS IO12 92 nROMOE/IRQ12/GP54/EETI (Note 4) 1 nROMOE IO12

SERIAL PORT 1 INTERFACE (8)

112 Receive Serial Data 1 1 RXD1 I 113 Transmit Serial Data 1 1 TXD1 O4 115 Request to Send 1 1 nRTS1/

IO4

SYSOP 116 Clear to Send 1 1 nCTS1 I 117 Data Terminal Ready 1 1 nDTR1 O4 114 Data Set Ready 1 1 nDSR1 I 119 Data Carrier Detect 1 1 nDCD1 I 118 Ring Indicator 1 1 nRI1 I

Page 9

No./QFP NAME TOTAL SYMBOL BUFFER TYPE

SERIAL PORT 2 INTERFACE (8)

123 Receive Serial Data 2/Infrared Rx 1 RXD2/IRRX I 124 Transmit Serial Data 2/Infrared Tx (Note 3) 1 TXD2/IRTX O24 126 Request to Send 2 1 nRTS2 O4 127 Clear to Send 2 1 nCTS2 I 128 Data Terminal Ready 1 nDTR2 O4 125 Data Set Ready 2 1 nDSR2 I 122 Data Carrier Detect 2 1 nDCD2 I 120 Ring Indicator 2 1 nRI2 I

PARALLEL PORT INTERFACE (17)

96-103 Parallel Port Data Bus 8 PD[0:7] IOP14

95 Printer Select 1 nSLCTIN OP14

94 Initiate Output 1 nINIT OP14 110 Auto Line Feed 1 nALF OP14 111 Strobe Signal 1 nSTROBE OP14 107 Busy Signal 1 BUSY I 108 Acknowledge Handshake 1 nACK I 106 Paper End 1 PE I 105 Printer Selected 1 SLCT I 109 Error at Printer 1 nERROR I

KEYBOARD/MOUSE INTERFACE (6)

70 Keyboard Data 1 KDAT IOD16

71 Keyboard Clock 1 KCLK IOD16

72 Mouse Data 1 MDAT IOD16

73 Mouse Clock 1 MCLK IOD16

75 Keyboard Reset 1 KBDRST

(Note 2)

76 Gate A20 1 A20M O4

Note 1: The “n” as the first letter of a signal name indicates an “Active Low” signal. Note 2: KBDRST is active low. Note 3: This pin defaults to an output and low. When configured as IRTX (or IRTX2), this pin is low

when the IR block is not transmitting.

Note 4: EETI is the Either Edge Triggered Interrupt Input function.

Page 10

BUFFER TYPE DESCRIPTIONS

SYMBOL DESCRIPTION

I Input, TTL compatible. IS Input with Schmitt trigger. ICLK Clock Input. OCLK2 Clock Output, 2mA sink, 2mA source. IO4 Input/Output, 4mA sink, 2mA source. IOP4 Input/Output, 4mA sink, 2mA source. Backdrive Protected. O4 Output, 4mA sink, 2mA source. O8 Output, 8mA sink, 4mA source. IO12 Input/Output, 12mA sink, 6mA source. O12 Output, 12mA sink, 6mA source. OP12 Output, 12mA sink, 6mA source. Backdrive Protected. OD12 Output, Open Drain, 12 mA sink. IOP14 Input/Output, 14mA sink, 14mA source. Backdrive Protected. OD14 Output, Open Drain, 14mA sink. OP14 Output, 14mA sink, 14mA source. Backdrive Protected. IOD16 Input/Output, Open Drain, 16mA sink O24 Output, 24mA sink, 12mA source. OD24 Output, Open Drain, 24mA sink.

TABLE 2 - BUFFER TYPES

Page 11

GENERAL PURPOSE I/O PINS

TABLE 3 - GENERAL PURPOSE I/O PIN FUNCTIONS

PIN NO.

QFP

77 GPIO nSMI - - IOP4/(OP12/ 78 GPIO nRING EETI

79 GPIO WDT P17/P12 80 GPIO LED - - IOP4/O24 GP1 GP13 81 GPIO IRRX2 - - IOP4/I GP1 GP14 82 GPIO IRTX2 - - IOP4/O24 GP1 GP15

4 nMTR1 GPIO - - (O24/OD24)/ 6 nDS1 GPIO - - (O24/OD24)/

39 PCI_CLK IRQ14 GPIO - CLKIN/(O12/

2 DRVDEN1 GPIO IRQ8 nSMI (O24/OD24)

91 nROMCS 92 nROMOE 83 RD0

84 RD1

85 RD2 86 RD3

87 RD4

88 RD5 89 RD6 90 RD7

Note 1: Either Edge Triggered Interrupt Inputs. Note 2: At power-up, RD0-7, nROMCS and nROMOE function as the XD Bus. To use RD0-7 for

Note 3: These pins cannot be programmed as open drain pins in their original function. Note 4: The function of P17 or P12 is selected via the P17/P12 select bit in the Ring Filter Select

DEFAULT

FUNCTION

ALTERNATE FUNCTION 1

ALTERNATE FUNCTION 2

ALTERNATE FUNCTION 3

BUFFER

TYPE

INDEX

REG. GPIO

GP1 GP10

- IOP4/I/I GP1 GP11

EETI

OD12)

IOP4/O4/IO4/I GP1 GP12

GP1 GP16

IOP4

GP1 GP17

IOP4

GP5 GP50

OD12)/IOP4

GP5 GP52 /IOP4/ (OP12/OD12)/

IRQ11 GPIO EETI

IRQ12 GPIO EETI

2,3

IRQ1 GPIO nSMI IO12/(O12/

(OP12/OD12) IO12/(O12/ OD12)/IOP4/I IO12/(O12/ OD12)/IOP4/I

GP5 GP53

GP5 GP54

GP6 GP60 OD12)/IOP4/

2,3

IRQ3 GPIO LED IO12/(O12/

(OP12/OD12)

GP6 GP61 OD12)/IOP4/

2,3

IRQ4 GPIO nRING IO12/(O12/ IRQ5 GPIO WDT IO12/(O12/

O24

GP6 GP62 OD12)/IOP4/I

GP6 GP63 OD12)/IOP4/

2,3

IRQ6 GPIO P17/P12

O4 IO12/(O12/

GP6 GP64 OD12)/IOP4/

2,3

IRQ7 GPIO - IO12/(O12/ IRQ8 GPIO - IO12/(OP12/ IRQ10 GPIO - IO12/(O12/

IO4

GP6 GP65 OD12)/IOP4

GP6 GP66 OD12)/IOP4

GP6 GP67 OD12)/IOP4

alternate functions, nROMCS must stay high until those pins are finished being programmed.

Page 12

Note 5: Buffer types per function are separated by a forward slash “/”. Multiple buffer types per

function are separated by a forward slash “/” and enclosed in parentheses; e.g., IRQ outputs can be open drain or push-pull and are shown as “(O12/OD12)”.

REFERENCE DOCUMENTS

§ IEEE 1284 Extended Capabilities Port Protocol and ISA Standard, Rev. 1.14, July 14, 1993.

§ Hardware Description of the 8042, Intel 8 bit Embedded Controller Handbook.

§ PCI Bus Power Management Interface Specification, Rev. 1.0, Draft, March 18, 1997.

Page 13

nPowerOn

Button_In

SER_IRQ

PCI_CLK

nIOR

nIOW

SA[0:15]

SD[O:7]

DRQ[0:3]

nDACK[0:3]

IRQ[1,3-12,14]

RESET_DRV

IOCHRDY

nPME/SCI

SOFT

POWER

MANAGEMENT

POWER

MANAGEMENT

SERIAL

IRQ

AEN

HOST

CPU

INTERFACE

PME/ ACPI

nSMI*

nSMI

ADDRESS BUS

SMSC

PROPRIETARY

82077

COMPATIBLE

VERTICAL

FLOPPYDISK

CONTROLLER

CORE

DATA BUS

CONFIGURATION

REGISTERS

CONTROL BUS

WDATA

WCLOCK

RCLOCK

RDATA

BIOS

BUFFER

nROMOE* nROMCS* RD[0:7]*

DIGITAL

DATA SEPARATOR WITH WRITE

PRECOM-

PENSATION

MULTI-MODE

PARALLEL PORT/FDC

MUX

GENERAL PURPOSE

I/O

16C550

COMPATIBLE

SERIAL PORT 1

16C550

COMPATIBLE

SERIAL

PORT 2 WITH

INFRARED

8042

PD0-7

BUSY, SLCT, PE, nERROR, nACK nSTB, nSLCTIN,

nINIT, nALF

GP1[0:7]* GP5[0,2:4]* GP6[0:7]*

TXD1

RXD1

nDSR1, nDCD1, nRI1, nDTR1

nCTS1, nRTS1

IRTX IRRX

TXD2(IRTX)

RXD2(IRRX)

nDSR2, nDCD2, nRI2, nDTR2

nCTS2, nRTS2

KCLK KDATA

MCLK MDATA P20, P21 P17/P12*

VCC

XTAL1 XTAL2

CLK32OUT

CLOCKI (14.318)

DENSEL

nINDEX nTRK0

nDSKCHG

nWRPRT

VBAT

VTR

VSS

nWGATE

nDIR

nSTEP

nHDSEL

nDS0,1

nMTR0,1

DRVDEN0 DRVDEN1

nWDATA nRDATA

*Multi-Function I/O Pin - Optional

CLOCK

GEN

FIGURE 2 - FDC37B72x BLOCK DIAGRAM

Page 14

FUNCTIONAL DESCRIPTION

SUPER I/O REGISTERS

The address map, shown below in Table 1, shows the addresses of the different blocks of the Super I/O immediately after power up. The base addresses of the FDC, serial and parallel ports can be moved via the configuration registers. Some addresses are used to access more than one register.

TABLE 4 - SUPER I/O BLOCK ADDRESSES

ADDRESS BLOCK NAME

Base+(0-5) and +(7) Floppy Disk 0

Parallel Port Base+(0-3) Base+(0-7) Base+(0-3), +(400-402) Base+(0-7), +(400-402) Base+(0-7) Serial Port Com 1 4 Base+(0-7) Serial Port Com 2 5 IR Support 60, 64 KYBD 7 Base + (0-17h) ACPI, PME, SMI A Base + (0-1) Configuration

Note 1: Refer to the configuration register descriptions for setting the base address

SPP

EPP

ECP

ECP+EPP+SPP

HOST PROCESSOR INTERFACE

The host processor communicates with the FDC37B72x through a series of read/write registers. The port addresses for these registers are shown in Table 1. Register access is accomplished through programmed I/O or DMA transfers. All registers are 8 bits wide. All host interface output buffers are capable of sinking a minimum of 12 mA.

LOGICAL

DEVICE NOTES

Page 15

FLOPPY DISK CONTROLLER

The Floppy Disk Controller (FDC) provides the interface between a host microprocessor and the floppy disk drives. The FDC integrates the functions of the Formatter/Controller, Digital Data Separator, Write Precompensation and Data Rate Selection logic for an IBM XT/AT compatible FDC. The true CMOS 765B core guarantees 100% IBM PC XT/AT compatibility in addition to providing data overflow and underflow protection.

TABLE 5 - STATUS, DATA AND CONTROL REGISTERS

(Shown with base addresses of 3F0 and 370)

PRIMARY

ADDRESS

3F0 3F1 3F2 3F3 3F4 3F4 3F5 3F6 3F7 3F7

SECONDARY

ADDRESS R/W REGISTER

370 371 372 373 374 374 375 376 377 377

The FDC is compatible to the 82077AA using SMSC's proprietary floppy disk controller core.

FDC INTERNAL REGISTERS

The Floppy Disk Controller contains eight internal registers that facilitate the interfacing between the host microprocessor and the disk drive. TABLE 5 shows the addresses required to access these registers. Registers other than the ones shown are not supported. The rest of the description assumes that the primary addresses have been selected.

Status Register A (SRA)

Status Register B (SRB) R/W R/W

R/W

Digital Output Register (DOR)

Tape Drive Register (TSR)

Main Status Register (MSR)

Data Rate Select Register (DSR)

Data (FIFO)

Reserved

Digital Input Register (DIR)

Configuration Control Register (CCR)

Page 16

STATUS REGISTER A (SRA)

Address 3F0 READ ONLY

This register is read-only and monitors the state of the FINTR pin and several disk interface pins in PS/2 and Model 30 modes. The SRA can

7 6 5 4 3 2 1 0

INT

nDRV2 STEP nTRK0 HDSEL nINDX nWP DIR

PENDING

RESET

0 1 0 N/A 0 N/A N/A 0

COND.

be accessed at any time when in PS/2 mode. In the PC/AT mode the data bus pins D0 - D7 are held in a high impedance state for a read of address 3F0.

PS/2 Mode

BIT 0 DIRECTION

Active high status indicating the direction of head movement. A logic "1" indicates inward direction; a logic "0" indicates outward direction.

BIT 1 nWRITE PROTECT

Active low status of the WRITE PROTECT disk interface input. A logic "0" indicates that the disk is write protected. (See also Force Write Protect Function)

BIT 2 nINDEX

Active low status of the INDEX disk interface input.

BIT 3 HEAD SELECT

Active high status of the HDSEL disk interface input. A logic "1" selects side 1 and a logic "0" selects side 0.

BIT 4 nTRACK 0

Active low status of the TRK0 disk interface input.

BIT 5 STEP

Active high status of the STEP output disk interface output pin.

BIT 6 nDRV2

Active low status of the DRV2 disk interface input pin, indicating that a second drive has been installed. Note: This function is not

supported in this chip. (Always 1, indicating 1 drive)

BIT 7 INTERRUPT PENDING

Active high bit indicating the state of the Floppy Disk Interrupt output.

Page 17

PS/2 Model 30 Mode

RESET COND.

7 6 5 4 3 2 1 0

INT

PENDING

0 0 0 N/A 1 N/A N/A 1

DRQ STEP

F/F

TRK0 nHDSEL INDX WP nDIR

BIT 0 nDIRECTION

Active low status indicating the direction of head movement. A logic "0" indicates inward direction; a logic "1" indicates outward direction.

BIT 1 WRITE PROTECT

Active high status of the WRITE PROTECT disk interface input. A logic "1" indicates that the disk is write protected. (See also Force Write Protect Function)

BIT 2 INDEX

Active high status of the INDEX disk interface input.

BIT 3 nHEAD SELECT

Active low status of the HDSEL disk interface input. A logic "0" selects side 1 and a logic "1" selects side 0.

BIT 4 TRACK 0

Active high status of the TRK0 disk interface input.

BIT 5 STEP

Active high status of the latched STEP disk interface output pin. This bit is latched with the STEP output going active, and is cleared with a read from the DIR register, or with a hardware or software reset.

BIT 6 DMA REQUEST

Active high status of the DRQ output pin.

BIT 7 INTERRUPT PENDING

Active high bit indicating the state of the Floppy Disk Interrupt output.

Page 18

STATUS REGISTER B (SRB)

Address 3F1 READ ONLY

This register is read-only and monitors the state of several disk interface pins in PS/2 and Model 30 modes. The SRB can be accessed at any

7 6 5 4 3 2 1 0

RESET

1 1 DRIVE

SEL0

1 1 0 0 0 0 0 0

WDATA

TOGGLE

COND.

time when in PS/2 mode. In the PC/AT mode the data bus pins D0 - D7 are held in a high impedance state for a read of address 3F1.

PS/2 Mode

RDATA

TOGGLE

WGATE MOT

EN1

MOT

EN0

BIT 0 MOTOR ENABLE 0

Active high status of the MTR0 disk interface output pin. This bit is low after a hardware reset and unaffected by a software reset.

BIT 1 MOTOR ENABLE 1

Active high status of the MTR1 disk interface output pin. This bit is low after a hardware reset and unaffected by a software reset.

BIT 2 WRITE GATE

Active high status of the WGATE disk interface output.

BIT 3 READ DATA TOGGLE

Every inactive edge of the RDATA input causes this bit to change state.

BIT 4 WRITE DATA TOGGLE

Every inactive edge of the WDATA input causes this bit to change state.

BIT 5 DRIVE SELECT 0

Reflects the status of the Drive Select 0 bit of the DOR (address 3F2 bit 0). This bit is cleared after a hardware reset and it is unaffected by a software reset.

BIT 6 RESERVED

Always read as a logic "1".

BIT 7 RESERVED

Always read as a logic "1".

Page 19

PS/2 Model 30 Mode

nDRV2 nDS1 nDS0 WDATA

RESET COND.

7 6 5 4 3 2 1 0

F/F

RDATA

F/F

WGATE

F/F

nDS3 nDS2

N/A 1 1 0 0 0 1 1

BIT 0 nDRIVE SELECT 2

The DS2 disk interface is not supported. (Always 1)

BIT 1 nDRIVE SELECT 3

The DS3 disk interface is not supported. (Always 1)

BIT 2 WRITE GATE

Active high status of the latched WGATE output signal. This bit is latched by the active going edge of WGATE and is cleared by the read of the DIR register.

BIT 3 READ DATA

Active high status of the latched RDATA output signal. This bit is latched by the inactive going edge of RDATA and is cleared by the read of the DIR register.

BIT 4 WRITE DATA

Active high status of the latched WDATA output signal. This bit is latched by the inactive going edge of WDATA and is cleared by the read of the DIR register. This bit is not gated with WGATE.

BIT 5 nDRIVE SELECT 0

Active low status of the DS0 disk interface output.

BIT 6 nDRIVE SELECT 1

Active low status of the DS1 disk interface output.

BIT 7 nDRV2

Active low status of the DRV2 disk interface input, this is not supported. (Always 1).

Page 20

DIGITAL OUTPUT REGISTER (DOR)

Address 3F2 READ/WRITE

The DOR controls the drive select and motor enables of the disk interface outputs. It also

7 6 5 4 3 2 1 0

MOT

EN3

RESET

MOT

EN2

MOT

EN1

0 0 0 0 0 0 0 0

COND.

contains the enable for the DMA logic and a software reset bit. The contents of the DOR are unaffected by a software reset. The DOR can be written to at any time.

MOT

EN0

DMAEN nRESETDRIVE

SEL1

DRIVE

SEL0

BIT 0 and 1 DRIVE SELECT

These two bits are binary encoded for the drive selects, thereby allowing only one drive to be selected at one time.

BIT 2 nRESET

A logic "0" written to this bit resets the Floppy disk controller. This reset will remain active until a logic "1" is written to this bit. This software reset does not affect the DSR and CCR registers, nor does it affect the other bits of the DOR register. The minimum reset duration required is 100ns, therefore toggling this bit by consecutive writes to this register is a valid method of issuing a software reset.

BIT 3 DMAEN

PC/AT and Model 30 Mode: Writing this bit to logic "1" will enable the DRQ, nDACK, TC and FINTR outputs. This bit being a logic "0" will disable the nDACK and TC inputs, and hold the DRQ and FINTR outputs in a high impedance state. This bit is a logic "0" after a reset and in these modes.

TABLE 6 - DRIVE ACTIVATION VALUES

PS/2 Mode: In this mode the DRQ, nDACK, TC and FINTR pins are always enabled. During a reset, the DRQ, nDACK, TC, and FINTR pins will remain enabled, but this bit will be cleared to a logic "0".

BIT 4 MOTOR ENABLE 0

This bit controls the MTR0 disk interface output. A logic "1" in this bit will cause the output pin to go active.

BIT 5 MOTOR ENABLE 1

This bit controls the MTR1 disk interface output. A logic "1" in this bit will cause the output pin to go active.

BIT 6 MOTOR ENABLE 2

The MTR2 disk interface output is not. (Always

BIT 7 MOTOR ENABLE 3

The MTR3 disk interface output is not. (Always

DRIVE DOR VALUE

0 1

1CH 2DH

Page 21

TAPE DRIVE REGISTER (TDR)

Address 3F3 READ/WRITE

TABLE 7 - TAPE SELECT BITS

TAPE SEL1

(TDR.1)

0 0 1 1

The Tape Drive Register (TDR) is included for 82077 software compatibility and allows the user to assign tape support to a particular drive during initialization. Any future references to that drive automatically invokes tape support. The TDR Tape Select bits TDR.[1:0] determine

TAPE SEL0

(TDR.0)

0 1 0 1

the tape drive number. TABLE 7 illustrates the Tape Select Bit encoding. Note that drive 0 is the boot device and cannot be assigned tape support. The remaining Tape Drive Register bits TDR.[7:2] are tristated when read. The TDR is unaffected by a software reset.

DRIVE

SELECTED

None

1 2 3

TABLE 8 - INTERNAL 2 DRIVE DECODE - NORMAL

DIGITAL OUTPUT REGISTER

DRIVE SELECT

OUTPUTS (ACTIVE LOW)

MOTOR ON OUTPUTS

(ACTIVE LOW)

Bit 7 Bit 6 Bit 5 Bit 4 Bit1 Bit 0 nDS1 nDS0 nMTR1 nMTR0

X X X 1 0 0 1 0 nBIT 5 nBIT 4 X X 1 X 0 1 0 1 nBIT 5 nBIT 4 X 1 X X 1 0 1 1 nBIT 5 nBIT 4

1 X X X 1 1 1 1 nBIT 5 nBIT 4 0 0 0 0 X X 1 1 nBIT 5 nBIT 4

TABLE 9 - INTERNAL 2 DRIVE DECODE - DRIVES 0 AND 1 SWAPPED

DIGITAL OUTPUT REGISTER

DRIVE SELECT OUTPUTS

(ACTIVE LOW)

MOTOR ON OUTPUTS

(ACTIVE LOW)

Bit 7 Bit 6 Bit 5 Bit 4 Bit1 Bit 0 nDS1 nDS0 nMTR1 nMTR0

X X X 1 0 0 0 1 nBIT 4 nBIT 5 X X 1 X 0 1 1 0 nBIT 4 nBIT 5 X 1 X X 1 0 1 1 nBIT 4 nBIT 5

1 X X X 1 1 1 1 nBIT 4 nBIT 5 0 0 0 0 X X 1 1 nBIT 4 nBIT 5

Page 22

Normal Floppy Mode

Normal mode. Register 3F3 contains only bits 0 and 1. When this register is read, bits 2 - 7 are a high impedance.

DB7 DB6 DB5 DB4 DB3 DB2 DB1 DB0

REG 3F3 Tri-state Tri-state Tri-state Tri-state Tri-state Tri-state tape sel1 tape sel0

Enhanced Floppy Mode 2 (OS2)

DB7 DB6 DB5 DB4 DB3 DB2 DB1 DB0

REG 3F3 Reserved Reserved Drive Type ID Floppy Boot Drive tape sel1 tape sel0

TABLE 10 - DRIVE TYPE ID

DIGITAL OUTPUT REGISTER REGISTER 3F3 - DRIVE TYPE ID

Bit 1 Bit 0 Bit 5 Bit 4

0 0 L0-CRF2 - B1 L0-CRF2 - B0 0 1 L0-CRF2 - B3 L0-CRF2 - B2 1 0 L0-CRF2 - B5 L0-CRF2 - B4 1 1 L0-CRF2 - B7 L0-CRF2 - B6

Note:L0-CRF2-Bx = Logical Device 0, Configuration Register F2, Bit x.

Page 23

DATA RATE SELECT REGISTER (DSR)

Address 3F4 WRITE ONLY

This register is write only. It is used to program the data rate, amount of write precompensation, power down status, and software reset. The data rate is programmed using the Configuration Control Register (CCR) not the DSR, for PC/AT and PS/2 Model 30 and

7 6 5 4 3 2 1 0

S/W

RESET

POWER

0 PRE-

DOWN

0 0 0 0 0 0 1 0

COND.

Microchannel applications. Other applications can set the data rate in the DSR. The data rate of the floppy controller is the most recent write of either the DSR or CCR. The DSR is unaffected by a software reset. A hardware reset will set the DSR to 02H, which corresponds to the default precompensation setting and 250 Kbps.

COMP2

PRE-

COMP1

PRE-

COMP0

DRATE

SEL1

DRATE

SEL0

BIT 0 and 1 DATA RATE SELECT

These bits control the data rate of the floppy controller. See Table 11 for the settings corresponding to the individual data rates. The data rate select bits are unaffected by a software reset, and are set to 250 Kbps after a hardware reset.

BIT 2 through 4 PRECOMPENSATION SELECT

These three bits select the value of write precompensation that will be applied to the WDATA output signal. Table 10 shows the precompensation values for the combination of these bits settings. Track 0 is the default starting track number to start precompensation. this starting track number can be changed by the configure command.

BIT 5 UNDEFINED

Should be written as a logic "0".

BIT 6 LOW POWER

A logic "1" written to this bit will put the floppy controller into manual low power mode. The floppy controller clock and data mode after a software reset or access to the Data Register or Main Status Register.

BIT 7 SOFTWARE RESET

This active high bit has the same function as the DOR RESET (DOR bit 2) except that this bit is self clearing.

Note: The DSR is Shadowed in the Floppy Data Rate Select Shadow Register, LD8:CRC2[7:0]. separator circuits will be turned off. The controller will come out of manual low power.

Page 24

TABLE 11 - PRECOMPENSATION DELAYS

PRECOMP

432

PRECOMPENSATION

DELAY (nsec)

<2Mbps 2Mbps 111 001 010 011 100 101 110 000

0.00

41.67

83.34

125.00

166.67

208.33

250.00

Default

20.8

41.7

62.5

83.3

104.2 125

Default

Default: See Table 11

TABLE 12 - DATA RATES

DRIVE RATE DATA RATE DATA RATE

DRATE(1)

DENSEL

DRT1 DRT0 SEL1 SEL0 MFM FM 1 0

0 0 1 1 1Meg --- 1 1 1 0 0 0 0 500 250 1 0 0 0 0 0 1 300 150 0 0 1 0 0 1 0 250 125 0 1 0

0 1 1 1 1Meg --- 1 1 1 0 1 0 0 500 250 1 0 0 0 1 0 1 500 250 0 0 1 0 1 1 0 250 125 0 1 0

1 0 1 1 1Meg --- 1 1 1 1 0 0 0 500 250 1 0 0 1 0 0 1 2Meg --- 0 0 1 1 0 1 0 250 125 0 1 0

Drive Rate Table (Recommended)00 = 360K, 1.2M, 720K, 1.44M and 2.88M Vertical Format

01 = 3-Mode Drive 10 = 2 Meg Tape

Note 1:The DRATE and DENSEL values are mapped onto the DRVDEN pins.

Page 25

TABLE 13 - DRVDEN MAPPING

DT1 DT0 DRVDEN1 (1) DRVDEN0 (1) DRIVE TYPE

0 0 DRATE0 DENSEL 4/2/1 MB 3.5"

2/1 MB 5.25" FDDS

2/1.6/1 MB 3.5" (3-MODE) 1 0 DRATE0 DRATE1 0 1 DRATE0 nDENSEL PS/2 1 1 DRATE1 DRATE0

TABLE 14 - DEFAULT PRECOMPENSATION DELAYS

PRECOMPENSATION

DATA RATE

2 Mbps

1 Mbps 500 Kbps 300 Kbps 250 Kbps

DELAYS

20.8 ns

41.67 ns 125 ns 125 ns 125 ns

Page 26

MAIN STATUS REGISTER

Address 3F4 READ ONLY

The Main Status Register is a read-only register and indicates the status of the disk controller. The Main Status Register can be read at any

7 6 5 4 3 2 1 0

RQM DIO

NON DMA

CMD

BUSY Reserved Reserved

time. The MSR indicates when the disk controller is ready to receive data via the Data Register. It should be read before each byte transferring to or from the data register except in DMA mode. No delay is required when reading the MSR after a data transfer.

DRV1 BUSY

DRV0 BUSY

BIT 0 - 1 DRV x BUSY

These bits are set to 1s when a drive is in the seek portion of a command, including implied and overlapped seeks and recalibrates.

BIT 4 COMMAND BUSY

This bit is set to a 1 when a command is in progress. This bit will go active after the command byte has been accepted and goes inactive at the end of the results phase. If there is no result phase (Seek, Recalibrate commands), this bit is returned to a 0 after the last command byte.

BIT 5 NON-DMA

This mode is selected in the SPECIFY command and will be set to a 1 during the execution phase of a command. This is for polled data transfers and helps differentiate between the data transfer phase and the reading of result bytes.

BIT 6 DIO

Indicates the direction of a data transfer once a RQM is set. A 1 indicates a read and a 0 indicates a write is required.

BIT 7 RQM

Indicates that the host can transfer data if set to a 1. No access is permitted if set to a 0.

DATA REGISTER (FIFO)

Address 3F5 READ/WRITE

All command parameter information, disk data and result status are transferred between the host processor and the floppy disk controller through the Data Register.

Data transfers are governed by the RQM and DIO bits in the Main Status Register.

The Data Register defaults to FIFO disabled mode after any form of reset. This maintains PC/AT hardware compatibility. The default values can be changed through the Configure command (enable full FIFO operation with threshold control). The advantage of the FIFO is that it allows the system a larger DMA latency without causing a disk error. Table 14 gives several examples of the delays with a FIFO. The data is based upon the following formula:

Threshold # x 1

DATA RATE

x 8 - 1.5 s = DELAY

At the start of a command, the FIFO action is always disabled and command parameters must be sent based upon the RQM and DIO bit settings. As the command execution phase is entered, the FIFO is cleared of any data to ensure that invalid data is not transferred.

Page 27

An overrun or underrun will terminate the current command and the transfer of data. Disk writes will complete the current sector by

TABLE 15 - FIFO SERVICE DELAY

FIFO THRESHOLD

MAXIMUM DELAY TO SERVICING

EXAMPLES

1 byte 2 bytes 8 bytes

15 bytes

1 x 4 µs - 1.5 µs = 2.5 µs 2 x 4 µs - 1.5 µs = 6.5 µs 8 x 4 µs - 1.5 µs = 30.5 µs 15 x 4 µs - 1.5 µs = 58.5 µs

generating a 00 pattern and valid CRC. Reads require the host to remove the remaining data so that the result phase may be entered.

AT 2 Mbps DATA RATE

FIFO THRESHOLD

EXAMPLES

1 byte 2 bytes 8 bytes

15 bytes

FIFO THRESHOLD

EXAMPLES

1 byte 2 bytes 8 bytes

15 bytes

MAXIMUM DELAY TO SERVICING

AT 1 Mbps DATA RATE

1 x 8 µs - 1.5 µs = 6.5 µs 2 x 8 µs - 1.5 µs = 14.5 µs 8 x 8 µs - 1.5 µs = 62.5 µs 15 x 8 µs - 1.5 µs = 118.5 µs

MAXIMUM DELAY TO SERVICING

AT 500 Kbps DATA RATE

1 x 16 µs - 1.5 µs = 14.5 µs 2 x 16 µs - 1.5 µs = 30.5 µs 8 x 16 µs - 1.5 µs = 126.5 µs 15 x 16 µs - 1.5 µs = 238.5 µs

Page 28

DIGITAL INPUT REGISTER (DIR)

Address 3F7 READ ONLY

This register is read-only in all modes.

PC-AT Mode

7 6 5 4 3 2 1 0

DSK

CHG

RESET

N/A N/A N/A N/A N/A N/A N/A N/A

COND.

BIT 0 - 6 UNDEFINED

The data bus outputs D0 - 6 will remain in a high impedance state during a read of this register.

7 6 5 4 3 2 1 0

DSK

1 1 1 1 DRATE

CHG

RESET

N/A N/A N/A N/A N/A N/A N/A 1

COND.

BIT 0 nHIGH DENS

This bit is low whenever the 500 Kbps or 1 Mbps data rates are selected, and high when 250 Kbps and 300 Kbps are selected.

BITS 1 - 2 DATA RATE SELECT

BIT 7 DSKCHG

This bit monitors the pin of the same name and reflects the opposite value seen on the disk cable or the value programmed in the Force Disk Change Register (see Configuration Register LD8:CRC1[1:0]).

PS/2 Mode

SEL1

DRATE

SEL0

nHIGH

nDENS

BITS 3 - 6 UNDEFINED

Always read as a logic "1"

BIT 7 DSKCHG

This bit monitors the pin of the same name and reflects the opposite value seen on the disk cable or the value programmed in the Force Disk Change Register (see Configuration Register LD8:CRC1[1:0]).

Page 29

Model 30 Mode

RESET

COND.

7 6 5 4 3 2 1 0

DSK

CHG

N/A 0 0 0 0 0 1 0

0 0 0 DMAEN NOPREC DRATE

SEL1

DRATE

SEL0

BITS 0 - 1 DATA RATE SELECT

BIT 2 NOPREC

This bit reflects the value of NOPREC bit set in the CCR register.

BIT 3 DMAEN

This bit reflects the value of DMAEN bit set in the DOR register bit 3.

BITS 4 - 6 UNDEFINED

Always read as a logic "0"

BIT 7 DSKCHG

This bit monitors the pin of the same name and reflects the opposite value seen on the disk cable or the value programmed in the Force Disk Change Register (see Configuration Register LD8:CRC1[1:0]).

Page 30

CONFIGURATION CONTROL REGISTER (CCR)

Address 3F7 WRITE ONLY

PC/AT and PS/2 Modes

7 6 5 4 3 2 1 0

RESET

N/A N/A N/A N/A N/A N/A 1 0

COND.

DRATE

SEL1

DRATE

SEL0

BIT 0 and 1 DATA RATE SELECT 0 and 1

These bits determine the data rate of the floppy controller. See Table 11 for the appropriate values.

7 6 5 4 3 2 1 0

RESET

N/A N/A N/A N/A N/A N/A 1 0

COND.

BIT 0 and 1 DATA RATE SELECT 0 and 1

These bits determine the data rate of the floppy controller. See Table 11 for the appropriate values.

BIT 2 NO PRECOMPENSATION

This bit can be set by software, but it has no functionality. It can be read by bit 2 of the DSR when in Model 30 register mode. Unaffected by software reset.

BIT 2 - 7 RESERVED

Should be set to a logical "0"

PS/2 Model 30 Mode

NOPREC DRATE

SEL1

DRATE

SEL0

BIT 3 - 7 RESERVED

Should be set to a logical "0" Table 12 shows the state of the DENSEL pin.

The DENSEL pin is set high after a hardware reset and is unaffected by the DOR and the DSR resets.

STATUS REGISTER ENCODING

During the Result Phase of certain commands, the Data Register contains data bytes that give the status of the command just executed.

Page 31

TABLE 16 - STATUS REGISTER 0

BIT NO. SYMBOL NAME DESCRIPTION

7,6 IC Interrupt

Code

5 SE Seek End The FDC completed a Seek, Relative Seek or

4 EC Equipment

Check

3 Unused. This bit is always "0". 2 H Head

Address

1,0 DS1,0 Drive Select The current selected drive.

00 - Normal termination of command. The specified command was properly executed and completed without error. 01 - Abnormal termination of command. Command execution was started, but was not successfully completed. 10 - Invalid command. The requested command could not be executed. 11 - Abnormal termination caused by Polling.

Recalibrate command (used during a Sense Interrupt Command). The TRK0 pin failed to become a "1" after:

1. 80 step pulses in the Recalibrate command.

2. The Relative Seek command caused the FDC to step outward beyond Track 0.

The current head address.

Page 32

TABLE 17 - STATUS REGISTER 1

BIT NO. SYMBOL NAME DESCRIPTION

7 EN End of

Cylinder

6 Unused. This bit is always "0". 5 DE Data Error The FDC detected a CRC error in either the ID field or

4 OR Overrun/

Underrun

3 Unused. This bit is always "0". 2 ND No Data Any one of the following:

1 NW Not Writeable WP pin became a "1" while the FDC is executing a

0 MA Missing

Address Mark

The FDC tried to access a sector beyond the final sector of the track (255D). Will be set if TC is not issued after Read or Write Data command.

the data field of a sector. Becomes set if the FDC does not receive CPU or DMA service within the required time interval, resulting in data overrun or underrun.

1. Read Data, Read Deleted Data command - the FDC did not find the specified sector.

2. Read ID command - the FDC cannot read the ID field without an error.

3. Read A Track command - the FDC cannot find the proper sector sequence.

Write Data, Write Deleted Data, or Format A Track command. Any one of the following:

1. The FDC did not detect an ID address mark at the specified track after encountering the index pulse from the IDX pin twice.

2. The FDC cannot detect a data address mark or a deleted data address mark on the specified track.

Page 33

TABLE 18 - STATUS REGISTER 2

BIT NO. SYMBOL NAME DESCRIPTION

7 Unused. This bit is always "0". 6 CM Control Mark Any one of the following:

1. Read Data command - the FDC encountered a deleted data address mark.

2. Read Deleted Data command - the FDC encountered a data address mark.

5 DD Data Error in

Data Field

4 WC Wrong

Cylinder 3 Unused. This bit is always "0". 2 Unused. This bit is always "0". 1 BC Bad Cylinder The track address from the sector ID field is different

0 MD Missing Data

Address Mark

TABLE 19 - STATUS REGISTER 3

BIT NO. SYMBOL NAME DESCRIPTION

7 Unused. This bit is always "0". 6 WP Write

Protected 5 Unused. This bit is always "1". 4 T0 Track 0 Indicates the status of the TRK0 pin. 3 Unused. This bit is always "1". 2 HD Head

Address

1,0 DS1,0 Drive Select Indicates the status of the DS1, DS0 pins.

The FDC detected a CRC error in the data field. The track address from the sector ID field is different

from the track address maintained inside the FDC.

from the track address maintained inside the FDC and is equal to FF hex, which indicates a bad track with a hard error according to the IBM soft-sectored format. The FDC cannot detect a data address mark or a deleted data address mark.

Indicates the status of the WP pin.

Indicates the status of the HDSEL pin.

Page 34

RESET

There are three sources of system reset on the FDC: the RESET pin of the FDC, a reset generated via a bit in the DOR, and a reset generated via a bit in the DSR. At power on, a Power On Reset initializes the FDC. All resets take the FDC out of the power down state.

All operations are terminated upon a RESET, and the FDC enters an idle state. A reset while a disk write is in progress will corrupt the data and CRC.

On exiting the reset state, various internal registers are cleared, including the Configure command information, and the FDC waits for a new command. Drive polling will start unless disabled by a new Configure command.

RESET Pin (Hardware Reset)

PC/AT mode - (IDENT high, MFM a "don't

care") The PC/AT register set is enabled, the DMA

enable bit of the DOR becomes valid (FINTR and DRQ can be hi Z), and TC and DENSEL become active high signals.

PS/2 mode - (IDENT low, MFM high) This mode supports the PS/2 models 50/60/80 configuration and register set. The DMA bit of the DOR becomes a "don't care", (FINTR and DRQ are always valid), TC and DENSEL become active low.

Model 30 mode - (IDENT low, MFM low) This mode supports PS/2 Model 30 configuration and register set. The DMA enable bit of the DOR becomes valid (FINTR and DRQ can be hi Z), TC is active high and DENSEL is active low.

The RESET pin is a global reset and clears all registers except those programmed by the Specify command. The DOR reset bit is enabled and must be cleared by the host to exit the reset state.

DOR Reset vs. DSR Reset (Software Reset)

These two resets are functionally the same. Both will reset the FDC core, which affects drive status information and the FIFO circuits. The DSR reset clears itself automatically while the DOR reset requires the host to manually clear it. DOR reset has precedence over the DSR reset. The DOR reset is set automatically upon a pin reset. The user must manually clear this reset bit in the DOR to exit the reset state.

MODES OF OPERATION

The FDC has three modes of operation, PC/AT mode, PS/2 mode and Model 30 mode. These are determined by the state of the IDENT and MFM bits 3 and 2 respectively of LD8CRF0.

DMA TRANSFERS

DMA transfers are enabled with the Specify command and are initiated by the FDC by activating the FDRQ pin during a data transfer command. The FIFO is enabled directly by asserting nDACK and addresses need not be valid.

Note that if the DMA controller (i.e. 8237A) is programmed to function in verify mode, a pseudo read is performed by the FDC based only on nDACK. This mode is only available when the FDC has been configured into byte mode (FIFO disabled) and is programmed to do a read. With the FIFO enabled, the FDC can perform the above operation by using the new Verify command; no DMA operation is needed.

Two DMA transfer modes are supported for the FDC: Single Transfer and Burst Transfer. In the case of the single transfer, the DMA Req goes active at the start of the DMA cycle, and the DMA Req is deasserted after the nDACK. In the case of the burst transfer, the Req is held active

Page 35

until the last transfer (independent of nDACK). See timing diagrams for more information.

Burst mode is enabled via Bit[1] of CRF0 in Logical Device 0. Setting Bit[1]=0 enables burst mode; the default is Bit[1]=1, for non-burst mode.

CONTROLLER PHASES

For simplicity, command handling in the FDC can be divided into three phases: Command, Execution, and Result. Each phase is described in the following sections.

Command Phase

After a reset, the FDC enters the command phase and is ready to accept a command from the host. For each of the commands, a defined set of command code bytes and parameter bytes has to be written to the FDC before the command phase is complete. (Please refer to TABLE 20 for the command set descriptions). These bytes of data must be transferred in the order prescribed.

Before writing to the FDC, the host must examine the RQM and DIO bits of the Main Status Register. RQM and DIO must be equal to "1" and "0" respectively before command bytes may be written. RQM is set false by the FDC after each write cycle until the received byte is processed. The FDC asserts RQM again to request each parameter byte of the command unless an illegal command condition is detected. After the last parameter byte is received, RQM remains "0" and the FDC automatically enters the next phase as defined by the command definition.

The FIFO is disabled during the command phase to provide for the proper handling of the "Invalid Command" condition.

Execution Phase

All data transfers to or from the FDC occur during the execution phase, which can proceed in DMA or non-DMA mode as indicated in the Specify command.

After a reset, the FIFO is disabled. Each data byte is transferred by an FINT or FDRQ depending on the DMA mode. The Configure command can enable the FIFO and set the FIFO threshold value.

The following paragraphs detail the operation of the FIFO flow control. In these descriptions, <threshold> is defined as the number of bytes available to the FDC when service is requested from the host and ranges from 1 to 16. The parameter FIFOTHR, which the user programs, is one less and ranges from 0 to 15.

A low threshold value (i.e. 2) results in longer periods of time between service requests, but requires faster servicing of the request for both read and write cases. The host reads (writes) from (to) the FIFO until empty (full), then the transfer request goes inactive. The host must be very responsive to the service request. This is the desired case for use with a "fast" system.

A high value of threshold (i.e. 12) is used with a "sluggish" system by affording a long latency period after a service request, but results in more frequent service requests.

Non-DMA Mode - Transfers from the FIFO to the Host

The FINT pin and RQM bits in the Main Status Register are activated when the FIFO contains (16-<threshold>) bytes or the last bytes of a full sector have been placed in the FIFO. The FINT pin can be used for interrupt-driven systems, and RQM can be used for polled systems. The host must respond to the request by reading data from the FIFO. This process is repeated until the last byte is transferred out of the FIFO.

Page 36

The FDC will deactivate the FINT pin and RQM bit when the FIFO becomes empty.

Non-DMA Mode - Transfers from the Host to the FIFO

The FINT pin and RQM bit in the Main Status Register are activated upon entering the execution phase of data transfer commands. The host must respond to the request by writing data into the FIFO. The FINT pin and RQM bit remain true until the FIFO becomes full. They are set true again when the FIFO has <threshold> bytes remaining in the FIFO. The FINT pin will also be deactivated if TC and nDACK both go inactive. The FDC enters the result phase after the last byte is taken by the FDC from the FIFO (i.e. FIFO empty condition).

DMA Mode - Transfers from the FIFO to the Host

The FDC activates the DDRQ pin when the FIFO contains (16 - <threshold>) bytes, or the last byte of a full sector transfer has been placed in the FIFO. The DMA controller must respond to the request by reading data from the FIFO. The FDC will deactivate the DDRQ pin when the FIFO becomes empty. FDRQ goes inactive after nDACK goes active for the last byte of a data transfer (or on the active edge of nIOR, on the last byte, if no edge is present on nDACK). A data underrun may occur if FDRQ is not removed in time to prevent an unwanted cycle.

DMA Mode - Transfers from the Host to the FIFO.

The FDC activates the FDRQ pin when entering the execution phase of the data transfer

commands. The DMA controller must respond by activating the nDACK and nIOW pins and placing data in the FIFO. FDRQ remains active until the FIFO becomes full. FDRQ is again set true when the FIFO has <threshold> bytes remaining in the FIFO. The FDC will also deactivate the FDRQ pin when TC becomes true (qualified by nDACK), indicating that no more data is required. FDRQ goes inactive after nDACK goes active for the last byte of a data transfer (or on the active edge of nIOW of the last byte, if no edge is present on nDACK). A data overrun may occur if FDRQ is not removed in time to prevent an unwanted cycle.

Data Transfer Termination

The FDC supports terminal count explicitly through the TC pin and implicitly through the underrun/overrun and end-of-track (EOT) functions. For full sector transfers, the EOT parameter can define the last sector to be transferred in a single or multi-sector transfer.

If the last sector to be transferred is a partial sector, the host can stop transferring the data in mid-sector, and the FDC will continue to complete the sector as if a hardware TC was received. The only difference between these implicit functions and TC is that they return "abnormal termination" result status. Such status indications can be ignored if they were expected.

Note that when the host is sending data to the FIFO of the FDC, the internal sector count will be complete when the FDC reads the last byte from its side of the FIFO. There may be a delay in the removal of the transfer request signal of up to the time taken for the FDC to read the last 16 bytes from the FIFO. The host must tolerate this delay.

Page 37

Result Phase

The generation of FINT determines the beginning of the result phase. For each of the commands, a defined set of result bytes has to be read from the FDC before the result phase is complete. These bytes of data must be read out for another command to start.

RQM and DIO must both equal "1" before the result bytes may be read. After all the result bytes have been read, the RQM and DIO bits switch to "1" and "0" respectively, and the CB bit is cleared, indicating that the FDC is ready to accept the next command.

Page 38

COMMAND SET/DESCRIPTIONS

Commands can be written whenever the FDC is in the command phase. Each command has a unique set of needed parameters and status results. The FDC checks to see that the first byte is a valid command and, if valid, proceeds with the command. If it is invalid, an interrupt is issued. The user sends a Sense Interrupt

TABLE 20 - DESCRIPTION OF COMMAND SYMBOLS

SYMBOL NAME DESCRIPTION

C Cylinder Address The currently selected address; 0 to 255. D Data Pattern The pattern to be written in each sector data field during

formatting.

D0, D1 Drive Select 0-1 Designates which drives are perpendicular drives on the

Perpendicular Mode Command. A "1" indicates a perpendicular drive.

DIR Direction Control If this bit is 0, then the head will step out from the spindle during a

relative seek. If set to a 1, the head will step in toward the spindle.

DS0, DS1 Disk Drive Select DS1 DS0 Drive Selected

0 0 Drive 0 0 1 Drive 1

DTL Special Sector

Size

EC Enable Count When this bit is "1" the "DTL" parameter of the Verify command EFIFO Enable FIFO This active low bit when a 0, enables the FIFO. A "1" disables the EIS Enable Implied

Seek

EOT End of Track The final sector number of the current track. GAP Alters Gap 2 length when using Perpendicular Mode. GPL Gap Length The Gap 3 size. (Gap 3 is the space between sectors excluding

H/HDS Head Address Selected head: 0 or 1 (disk side 0 or 1) as encoded in the sector

By setting N to zero (00), DTL may be used to control the number of bytes transferred in disk read/write commands. The sector size (N = 0) is set to 128. If the actual sector (on the diskette) is larger than DTL, the remainder of the actual sector is read but is not passed to the host during read commands; during write commands, the remainder of the actual sector is written with all zero bytes. The CRC check code is calculated with the actual sector. When N is not zero, DTL has no meaning and should be set to FF HEX.

becomes SC (number of sectors per track). FIFO (default).

When set, a seek operation will be performed before executing any read or write command that requires the C parameter in the command phase. A "0" disables the implied seek.

the VCO synchronization field). ID field.

Status command which returns an invalid command error. Refer to TABLE 20 for explanations of the various symbols used. TABLE 21 lists the required parameters and the results associated with each command that the FDC is capable of performing.

Page 39

SYMBOL NAME DESCRIPTION

HLT Head Load Time The time interval that FDC waits after loading the head and before

initializing a read or write operation. Refer to the Specify command for actual delays.

HUT Head Unload

Time

The time interval from the end of the execution phase (of a read or write command) until the head is unloaded. Refer to the Specify command for actual delays.

LOCK Lock defines whether EFIFO, FIFOTHR, and PRETRK parameters

of the CONFIGURE COMMAND can be reset to their default values by a "software Reset". (A reset caused by writing to the appropriate bits of either the DSR or DOR)

MFM MFM/FM Mode

Selector

MT Multi-Track

Selector

A one selects the double density (MFM) mode. A zero selects single density (FM) mode. When set, this flag selects the multi-track operating mode. In this mode, the FDC treats a complete cylinder under head 0 and 1 as a single track. The FDC operates as this expanded track started at the first sector under head 0 and ended at the last sector under head 1. With this flag set, a multitrack read or write operation will automatically continue to the first sector under head 1 when the FDC finishes operating on the last sector under head 0.

N Sector Size Code This specifies the number of bytes in a sector. If this parameter is

"00", then the sector size is 128 bytes. The number of bytes transferred is determined by the DTL parameter. Otherwise the sector size is (2 raised to the "N'th" power) times 128. All values up to "07" hex are allowable. "07"h would equal a sector size of 16k. It is the user's responsibility to not select combinations that are not possible with the drive. N Sector Size 0 128 Bytes 1 256 Bytes 2 512 Bytes 3 1024 Bytes … …

NCN New Cylinder

The desired cylinder number.

Number

ND Non-DMA Mode

Flag

When set to 1, indicates that the FDC is to operate in the nonDMA mode. In this mode, the host is interrupted for each data transfer. When set to 0, the FDC operates in DMA mode, interfacing to a DMA controller by means of the DRQ and nDACK signals.

OW Overwrite The bits D0-D3 of the Perpendicular Mode Command can only be

modified if OW is set to 1. OW id defined in the Lock command.

PCN Present Cylinder

Number

The current position of the head at the completion of Sense Interrupt Status command.

POLL Polling Disable When set, the internal polling routine is disabled. When clear,

polling is enabled.

Page 40

SYMBOL NAME DESCRIPTION

PRETRK Precompensation

Start Track Number

R Sector Address The sector number to be read or written. In multi-sector transfers,

RCN Relative Cylinder

Number

SC Number of

Sectors Per Track

SK Skip Flag When set to 1, sectors containing a deleted data address mark will

SRT Step Rate Interval The time interval between step pulses issued by the FDC.

ST0 ST1 ST2 ST3 WGATE Write Gate Alters timing of WE to allow for pre-erase loads in perpendicular

Status 0 Status 1 Status 2 Status 3

Programmable from track 00 to FFH.

this parameter specifies the sector number of the first sector to be read or written. Relative cylinder offset from present cylinder as used by the Relative Seek command. The number of sectors per track to be initialized by the Format command. The number of sectors per track to be verified during a Verify command when EC is set.

automatically be skipped during the execution of Read Data. If Read Deleted is executed, only sectors with a deleted address mark will be accessed. When set to "0", the sector is read or written the same as the read and write commands.

Programmable from 0.5 to 8 milliseconds in increments of 0.5 ms at the 1 Mbit data rate. Refer to the SPECIFY command for actual delays. Registers within the FDC which store status information after a command has been executed. This status information is available to the host during the result phase after command execution.

drives.

Page 41

INSTRUCTION SET

TABLE 21 - INSTRUCTION SET

READ DATA

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W MT MFM SK 0 0 1 1 0 Command Codes

W 0 0 0 0 0 HDS DS1 DS0 W -------- C -------- Sector ID information prior to

Command execution. W -------- H -------W -------- R -------W -------- N -------W ------- EOT ------W ------- GPL ------W ------- DTL -------

Execution Data transfer between the

FDD and system.

Result R ------- ST0 ------- Status information after

Command execution.

R ------- ST1 ------R ------- ST2 ------R -------- C -------- Sector ID information after

Command execution.

R -------- H -------R -------- R -------R -------- N --------

Page 42

READ DELETED DATA

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W MT MFM SK 0 1 1 0 0 Command Codes

W 0 0 0 0 0 HDS DS1 DS0 W -------- C -------- Sector ID information prior to

Command execution. W -------- H -------W -------- R -------W -------- N -------W ------- EOT ------W ------- GPL ------W ------- DTL -------

Execution Data transfer between the

FDD and system.

Result R ------- ST0 ------- Status information after

Command execution.

R ------- ST1 ------R ------- ST2 ------R -------- C -------- Sector ID information after

Command execution.

R -------- H -------R -------- R -------R -------- N --------

Page 43

WRITE DATA

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W MT MFM 0 0 0 1 0 1 Command Codes

W 0 0 0 0 0 HDS DS1 DS0 W -------- C -------- Sector ID information prior to

Command execution. W -------- H -------W -------- R -------W -------- N -------W ------- EOT ------W ------- GPL ------W ------- DTL -------

Execution Data transfer between the

FDD and system.

Result R ------- ST0 ------- Status information after

Command execution.

R ------- ST1 ------R ------- ST2 ------R -------- C -------- Sector ID information after

Command execution.

R -------- H -------R -------- R -------R -------- N --------

Page 44

WRITE DELETED DATA

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W MT MFM 0 0 1 0 0 1 Command Codes

W 0 0 0 0 0 HDS DS1 DS0 W -------- C -------- Sector ID information

prior to Command

execution. W -------- H -------W -------- R -------W -------- N -------W ------- EOT ------W ------- GPL ------W ------- DTL -------

Execution Data transfer between

the FDD and system.

Result R ------- ST0 ------- Status information after

Command execution.

R ------- ST1 ------R ------- ST2 ------R -------- C -------- Sector ID information

after Command

execution.

R -------- H -------R -------- R -------R -------- N --------

Page 45

READ A TRACK

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 MFM 0 0 0 0 1 0 Command Codes

W 0 0 0 0 0 HDS DS1 DS0 W -------- C -------- Sector ID information

prior to Command

execution. W -------- H -------W -------- R -------W -------- N -------W ------- EOT ------W ------- GPL ------W ------- DTL -------

Execution Data transfer between

the FDD and system.

FDC reads all of

cylinders' contents from

index hole to EOT.

Result R ------- ST0 ------- Status information after

Command execution.

R ------- ST1 ------R ------- ST2 ------R -------- C -------- Sector ID information

after Command

execution.

R -------- H -------R -------- R -------R -------- N --------

Page 46

VERIFY

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W MT MFM SK 1 0 1 1 0 Command Codes

W EC 0 0 0 0 HDS DS1 DS0 W -------- C -------- Sector ID information

prior to Command

execution. W -------- H -------W -------- R -------W -------- N -------W ------- EOT ------W ------- GPL ------W ------ DTL/SC ------

Execution No data transfer takes

place.

Result R ------- ST0 ------- Status information after

Command execution.

R ------- ST1 ------R ------- ST2 ------R -------- C -------- Sector ID information

after Command

execution.

R -------- H -------R -------- R -------R -------- N --------

VERSION

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 1 0 0 0 0 Command Code Result R 1 0 0 1 0 0 0 0 Enhanced Controller

Page 47

FORMAT A TRACK

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 MFM 0 0 1 1 0 1 Command Codes

W 0 0 0 0 0 HDS DS1 DS0 W -------- N -------- Bytes/Sector W -------- SC -------- Sectors/Cylinder W ------- GPL ------- Gap 3 W -------- D -------- Filler Byte

Execution for Each Sector Repeat:

Result R ------- ST0 ------- Status information after

W -------- C -------- Input Sector

Parameters W -------- H --------

W -------- R -------W -------- N --------

FDC formats an entire

cylinder

Command execution

R ------- ST1 ------R ------- ST2 ------R ------ Undefined -----R ------ Undefined -----R ------ Undefined -----R ------ Undefined ------

Page 48

RECALIBRATE

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 0 0 1 1 1 Command Codes

W 0 0 0 0 0 0 DS1 DS0

Execution Head retracted to Track 0

Interrupt.

SENSE INTERRUPT STATUS

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 0 1 0 0 0 Command Codes Result R ------- ST0 ------- Status information at the end

of each seek operation.

R ------- PCN -------

SPECIFY

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 0 0 0 1 1 Command Codes

W --- SRT --- --- HUT --W ------ HLT ------ ND

Page 49

SENSE DRIVE STATUS

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 0 0 1 0 0 Command Codes

W 0 0 0 0 0 HDS DS1 DS0

Result R ------- ST3 ------- Status information about

FDD

SEEK

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 0 1 1 1 1 Command Codes

W 0 0 0 0 0 HDS DS1 DS0 W ------- NCN -------

Execution Head positioned over

proper cylinder on diskette.

CONFIGURE

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 1 0 0 1 1 Configure

Information W 0 0 0 0 0 0 0 0 W 0 EIS EFIFO POLL --- FIFOTHR ---

Execution W --------- PRETRK ---------

Page 50

RELATIVE SEEK

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 1 DIR 0 0 1 1 1 1

W 0 0 0 0 0 HDS DS1 DS0 W ------- RCN -------

DUMPREG

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 0 1 1 1 0 *Note:

Registers placed in

FIFO Execution Result R ------ PCN-Drive 0 -------

R ------ PCN-Drive 1 ------R ------ PCN-Drive 2 ------R ------ PCN-Drive 3 ------R ---- SRT ---- --- HUT --R ------- HLT ------- ND R ------- SC/EOT ------R LOCK 0 D3 D2 D1 D0 GAP WGATE R 0 EIS EFIFO POLL -- FIFOTHR -R -------- PRETRK --------

Page 51

READ ID

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 MFM 0 0 1 0 1 0 Commands

W 0 0 0 0 0 HDS DS1 DS0

Execution The first correct ID

information on the Cylinder is stored in Data Register

Result R -------- ST0 -------- Status information after

Command execution.

Disk status after the Command has

completed R -------- ST1 -------R -------- ST2 -------R -------- C -------R -------- H -------R -------- R -------R -------- N --------

Page 52

PERPENDICULAR MODE

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W 0 0 0 1 0 0 1 0 Command Codes

OW 0 D3 D2 D1 D0 GAP WGATE

INVALID CODES

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W ----- Invalid Codes ----- Invalid Command Codes

(NoOp - FDC goes into Standby State)

Result R ------- ST0 ------- ST0 = 80H

LOCK

DATA BUS

PHASE R/W D7 D6 D5 D4 D3 D2 D1 D0 REMARKS

Command W LOCK 0 0 1 0 1 0 0 Command Codes Result R 0 0 0 LOCK 0 0 0 0

SC is returned if the last command that was issued was the Format command. EOT is returned if the last command was a Read or Write.

Note: These bits are used internally only. They are not reflected in the Drive Select pins. It is the user's responsibility to maintain correspondence between these bits and the Drive Select pins (DOR).

Page 53

DATA TRANSFER COMMANDS

All of the Read Data, Write Data and Verify type commands use the same parameter bytes and return the same results information, the only difference being the coding of bits 0-4 in the first byte.

An implied seek will be executed if the feature was enabled by the Configure command. This seek is completely transparent to the user. The Drive Busy bit for the drive will go active in the Main Status Register during the seek portion of the command. If the seek portion fails, it is reflected in the results status normally returned for a Read/Write Data command. Status Register 0 (ST0) would contain the error code and C would contain the cylinder on which the seek failed.

Read Data

A set of nine (9) bytes is required to place the FDC in the Read Data Mode. After the Read Data command has been issued, the FDC loads the head (if it is in the unloaded state), waits the specified head settling time (defined in the Specify command), and begins reading ID Address Marks and ID fields. When the sector

address read off the diskette matches with the sector address specified in the command, the FDC reads the sector's data field and transfers the data to the FIFO.

After completion of the read operation from the current sector, the sector address is incremented by one and the data from the next logical sector is read and output via the FIFO. This continuous read function is called "MultiSector Read Operation". Upon receipt of TC, or an implied TC (FIFO overrun/underrun), the FDC stops sending data but will continue to read data from the current sector, check the CRC bytes, and at the end of the sector, terminate the Read Data Command.

N determines the number of bytes per sector (see Table 21 below). If N is set to zero, the sector size is set to 128. The DTL value determines the number of bytes to be transferred. If DTL is less than 128, the FDC transfers the specified number of bytes to the host. For reads, it continues to read the entire 128-byte sector and checks for CRC errors. For writes, it completes the 128-byte sector by filling in zeros. If N is not set to 00 Hex, DTL should be set to FF Hex and has no impact on the number of bytes transferred.

TABLE 22 - SECTOR SIZES

N SECTOR SIZE

00 01 02 03

The amount of data which can be handled with a single command to the FDC depends upon MT (multi-track) and N (number of bytes/sector).

128 bytes 256 bytes 512 bytes

1024 bytes

...

16 Kbytes

The Multi-Track function (MT) allows the FDC to read data from both sides of the diskette. For a particular cylinder, data will be transferred starting at Sector 1, Side 0 and completing the last sector of the same track at Side 1.

Page 54

If the host terminates a read or write operation in the FDC, the ID information in the result phase is dependent upon the state of the MT bit and EOT byte. Refer to Table 20.

"01" indicating abnormal termination, sets the ND bit in Status Register 1 to "1" indicating a sector not found, and terminates the Read Data Command.

At the completion of the Read Data command, the head is not unloaded until after the Head Unload Time Interval (specified in the Specify command) has elapsed. If the host issues another command before the head unloads, then the head settling time may be saved between subsequent reads.

If the FDC detects a pulse on the nINDEX pin twice without finding the specified sector (meaning that the diskette's index hole passes through index detect logic in the drive twice), the FDC sets the IC code in Status Register 0 to

TABLE 24 - EFFECTS OF MT AND N BITS

MAXIMUM TRANSFER

256 x 26 = 6,656

256 x 52 = 13,312

512 x 15 = 7,680

512 x 30 = 15,360

1024 x 8 = 8,192

1024 x 16 = 16,384

CAPACITY

After reading the ID and Data Fields in each sector, the FDC checks the CRC bytes. If a CRC error occurs in the ID or data field, the FDC sets the IC code in Status Register 0 to "01" indicating abnormal termination, sets the DE bit flag in Status Register 1 to "1", sets the DD bit in Status Register 2 to "1" if CRC is incorrect in the ID field, and terminates the Read Data Command. Table 21 describes the effect of the SK bit on the Read Data command execution and results. Except where noted in Table 21, the C or R value of the sector address is automatically incremented (see Table 23).

FINAL SECTOR READ

FROM DISK

26 at side 0 or 1 26 at side 1 15 at side 0 or 1 15 at side 1 8 at side 0 or 1 16 at side 1

Page 55

SK BIT VALUE

0 0

1 1

TABLE 25 - SKIP BIT VS READ DATA COMMAND

DATA ADDRESS

MARK TYPE

RESULTS

ENCOUNTERED

Normal Data Deleted Data

SECTOR

READ?

Yes Yes

Yes

CM BIT OF

ST2 SET?

Yes

DESCRIPTION

OF RESULTS

Normal termination. Address not incremented. Next sector not searched for. Normal termination. Normal termination. Sector not read ("skipped").

Page 56

Read Deleted Data

This command is the same as the Read Data command, only it operates on sectors that contain a Deleted Data Address Mark at the beginning of a Data Field.

TABLE 26 - SKIP BIT VS. READ DELETED DATA COMMAND

DATA ADDRESS SK BIT VALUE

MARK TYPE

ENCOUNTERED

SECTOR

READ?

Normal Data

Deleted Data

Normal Data

Deleted Data

Table 22 describes the effect of the SK bit on the Read Deleted Data command execution and results.

Except where noted in Table 22, the C or R value of the sector address is automatically incremented (see Table 23).

RESULTS

Yes

CM BIT OF

ST2 SET?

Yes

DESCRIPTION

OF RESULTS

Address not incremented. Next sector not searched for.

Yes

Normal termination.

Yes

Normal termination. Sector not read ("skipped").

Yes

Normal termination.

Page 57

Read A Track

flag of Status Register 1 to a "1" if there is no

comparison. Multi-track or skip operations are This command is similar to the Read Data command except that the entire data field is read continuously from each of the sectors of a

not allowed with this command. The MT and SK

bits (bits D7 and D5 of the first command byte

respectively) should always be set to "0". track. Immediately after encountering a pulse on the nINDEX pin, the FDC starts to read all data fields on the track as continuous blocks of data without regard to logical sector numbers. If the FDC finds an error in the ID or DATA CRC check bytes, it continues to read data from the track and sets the appropriate error bits at the end of the command. The FDC compares the ID information read from each sector with the

This command terminates when the EOT

specified number of sectors has not been read.

If the FDC does not find an ID Address Mark on

the diskette after the second occurrence of a

pulse on the IDX pin, then it sets the IC code in

Status Register 0 to "01" (abnormal

termination), sets the MA bit in Status Register

1 to "1", and terminates the command. specified value in the command and sets the ND

TABLE 27 - RESULT PHASE

FINAL SECTOR

MT HEAD

TRANSFERRED TO ID INFORMATION AT RESULT PHASE

HOST C H R N

0 0 Less than EOT NC NC R + 1 NC

Equal to EOT C + 1 NC 01 NC

1 Less than EOT NC NC R + 1 NC

Equal to EOT C + 1 NC 01 NC

1 0 Less than EOT NC NC R + 1 NC

Equal to EOT NC LSB 01 NC

1 Less than EOT NC NC R + 1 NC

Equal to EOT C + 1 LSB 01 NC NC: No Change, the same value as the one at the beginning of command execution. LSB: Least Significant Bit, the LSB of H is complemented.

Page 58

Write Data After the Write Data command has been issued,

the FDC loads the head (if it is in the unloaded state), waits the specified head load time if unloaded (defined in the Specify command), and begins reading ID fields. When the sector address read from the diskette matches the sector address specified in the command, the FDC reads the data from the host via the FIFO and writes it to the sector's data field.

After writing data into the current sector, the FDC computes the CRC value and writes it into the CRC field at the end of the sector transfer. The Sector Number stored in "R" is incremented by one, and the FDC continues writing to the next data field. The FDC continues this "MultiSector Write Operation". Upon receipt of a terminal count signal or if a FIFO over/under run occurs while a data field is being written, then the remainder of the data field is filled with zeros. The FDC reads the ID field of each sector and checks the CRC bytes. If it detects a CRC error in one of the ID fields, it sets the IC code in Status Register

0 to "01" (abnormal termination), sets the DE bit of Status Register 1 to "1", and terminates the Write Data command.

The Write Data command operates in much the same manner as the Read Data command. The following items are the same. Please refer to the Read Data Command for details:

• Transfer Capacity

• EN (End of Cylinder) bit

• ND (No Data) bit

• Head Load, Unload Time Interval

• ID information when the host terminates the

command

• Definition of DTL when N = 0 and when N does not = 0

Write Deleted Data This command is almost the same as the Write

Data command except that a Deleted Data Address Mark is written at the beginning of the Data Field instead of the normal Data Address Mark. This command is typically used to mark a bad sector containing an error on the floppy disk.

Verify The Verify command is used to verify the data

stored on a disk. This command acts exactly like a Read Data command except that no data is transferred to the host. Data is read from the disk and CRC is computed and checked against the previously-stored value.

Because data is not transferred to the host, TC

(pin 89) cannot be used to terminate this command. By setting the EC bit to "1", an implicit TC will be issued to the FDC. This implicit TC will occur when the SC value has decremented to 0 (an SC value of 0 will verify 256 sectors). This command can also be terminated by setting the EC bit to "0" and the EOT value equal to the final sector to be checked. If EC is set to "0", DTL/SC should be programmed to 0FFH. Refer to Table 23 and Table 24 for information concerning the values of MT and EC versus SC and EOT value.

Definitions: # Sectors Per Side = Number of formatted

sectors per each side of the disk.

# Sectors Remaining = Number of formatted

sectors left which can be read, including side 1 of the disk if MT is set to "1".

Page 59

TABLE 28 - VERIFY COMMAND RESULT PHASE

MT EC SC/EOT VALUE TERMINATION RESULT

0 0 SC = DTL

EOT  # Sectors Per Side

0 0 SC = DTL

EOT > # Sectors Per Side

0 1 SC  # Sectors Remaining AND

EOT  # Sectors Per Side

0 1 SC > # Sectors Remaining OR

EOT > # Sectors Per Side

1 0 SC = DTL

EOT  # Sectors Per Side

1 0 SC = DTL

EOT > # Sectors Per Side

1 1 SC  # Sectors Remaining AND

EOT  # Sectors Per Side

1 1 SC > # Sectors Remaining OR

EOT > # Sectors Per Side

Success Termination Result Phase Valid Unsuccessful Termination Result Phase Invalid Successful Termination Result Phase Valid Unsuccessful Termination Result Phase Invalid Successful Termination Result Phase Valid Unsuccessful Termination Result Phase Invalid Successful Termination Result Phase Valid Unsuccessful Termination Result Phase Invalid

Note: If MT is set to "1" and the SC value is greater than the number of remaining formatted sectors

on Side 0, verifying will continue on Side 1 of the disk.

Format A Track The Format command allows an entire track to

be formatted. After a pulse from the IDX pin is detected, the FDC starts writing data on the disk including gaps, address marks, ID fields, and data fields per the IBM System 34 or 3740 format (MFM or FM respectively). The particular values that will be written to the gap and data field are controlled by the values programmed into N, SC, GPL, and D which are specified by the host during the command phase. The data field of the sector is filled with the data byte specified by D. The ID field for each sector is supplied by the host; that is, four data bytes per sector are needed by the FDC for C, H, R, and

N (cylinder, head, sector number and sector size respectively).

After formatting each sector, the host must send

new values for C, H, R and N to the FDC for the next sector on the track. The R value (sector number) is the only value that must be changed by the host after each sector is formatted. This allows the disk to be formatted with nonsequential sector addresses (interleaving). This incrementing and formatting continues for the whole track until the FDC encounters a pulse on the IDX pin again and it terminates the command.

Table 29 contains typical values for gap fields

which are dependent upon the size of the sector and the number of sectors on each track. Actual values can vary due to drive electronics.

Page 60

S E

C R

3x C2

3x A1

3x A1 FB

S E

C R

S E

C R

3x C2

3x A1

3x A1 FB

FORMAT FIELDS

SYSTEM 34 (DOUBLE DENSITY) FORMAT

GAP4a

80x

SYNC

12x

IAM

GAP1

50x

SYNC

12x

IDAM

GAP2

22x

SYNC

12x

DATAAM

DATA

SYSTEM 3740 (SINGLE DENSITY) FORMAT

GAP4a

40x

SYNC

6x 00

IAM

GAP1

26x

SYNC

6x 00

IDAM

GAP2

11x

SYNC

6x 00

DATAAM

DATA

FC FE FB orF8

PERPENDICULAR FORMAT

GAP4a

80x

SYNC

12x

IAM

GAP1

50x

SYNC

12x

IDAM

GAP2

41x

SYNC

12x

DATAAM

DATA

GAP3

GAP 4b

Page 61

TABLE 29 - TYPICAL VALUES FOR FORMATTING

FORMAT SECTOR SIZE N SC GPL1 GPL2

5.25"

Drives

3.5"

Drives

MFM

128 128

512 1024 2048 4096

...

256

256 512* 1024 2048 4096

... 128 256 512 256

512**

1024

00 00 02 03 04 05

...

01 01 02 03 04 05

...

12 10 08 04 02 01

12 10 09 04 02 01

0 1 2

1 2 3

0F 09 05

07 10 18

46 C8 C8

80 C8 C8

09 19 30 87 FF FF

32 50 F0 FF FF

1B 2A 3A

36 54 74

GPL1 = suggested GPL values in Read and Write commands to avoid splice point

between data field and ID field of contiguous sections.

GPL2 = suggested GPL value in Format A Track command. *PC/AT values (typical) **PS/2 values (typical). Applies with 1.0 MB and 2.0 MB drives. NOTE: All values except sector size are in hex.

Page 62

CONTROL COMMANDS

Control commands differ from the other

commands in that no data transfer takes place. Three commands generate an interrupt when complete: Read ID, Recalibrate, and Seek. The other control commands do not generate an interrupt.

Read ID The Read ID command is used to find the

present position of the recording heads. The FDC stores the values from the first ID field it is able to read into its registers. If the FDC does not find an ID address mark on the diskette after the second occurrence of a pulse on the nINDEX pin, it then sets the IC code in Status Register 0 to "01" (abnormal termination), sets the MA bit in Status Register 1 to "1", and terminates the command.

The following commands will generate an

interrupt upon completion. They do not return any result bytes. It is highly recommended that control commands be followed by the Sense Interrupt Status command. Otherwise, valuable interrupt status information will be lost.

Recalibrate This command causes the read/write head

within the FDC to retract to the track 0 position. The FDC clears the contents of the PCN counter and checks the status of the nTR0 pin from the FDD. As long as the nTR0 pin is low, the DIR pin remains 0 and step pulses are issued. When the nTR0 pin goes high, the SE bit in Status Register 0 is set to "1" and the command is terminated. If the nTR0 pin is still low after 79 step pulses have been issued, the FDC sets the SE and the EC bits of Status Register 0 to "1" and terminates the command. Disks capable of handling more than 80 tracks per side may require more than one Recalibrate command to return the head back to physical Track 0.

The Recalibrate command does not have a

result phase. The Sense Interrupt Status command must be issued after the Recalibrate command to effectively terminate it and to provide verification of the head position (PCN). During the command phase of the recalibrate operation, the FDC is in the BUSY state, but during the execution phase it is in a NON-BUSY state. At this time, another Recalibrate command may be issued, and in this manner parallel Recalibrate operations may be done on up to four drives at once.

Upon power up, the software must issue a

Recalibrate command to properly initialize all drives and the controller.

Seek The read/write head within the drive is moved

from track to track under the control of the Seek command. The FDC compares the PCN, which is the current head position, with the NCN and performs the following operation if there is a difference:

PCN < NCN: Direction signal to drive set to "1" (step in) and issues step pulses. PCN > NCN: Direction signal to drive set to "0" (step out) and issues step pulses.

The rate at which step pulses are issued is

controlled by SRT (Stepping Rate Time) in the Specify command. After each step pulse is issued, NCN is compared against PCN, and when NCN = PCN the SE bit in Status Register 0 is set to "1" and the command is terminated. During the command phase of the seek or recalibrate operation, the FDC is in the BUSY state, but during the execution phase it is in the NON-BUSY state. At this time, another Seek or Recalibrate command may be issued, and in this manner, parallel seek operations may be done on up to four drives at once.

Page 63

Note that if implied seek is not enabled, the read

and write commands should be preceded by:

1) Seek command - Step to the proper track

2) Sense Interrupt Status command -

Terminate the Seek command

3) Read ID - Verify head is on proper track

4) Issue Read/Write command. The Seek command does not have a result

phase. Therefore, it is highly recommended that the Sense Interrupt Status command is issued after the Seek command to terminate it and to provide verification of the head position (PCN). The H bit (Head Address) in ST0 will always return to a "0". When exiting POWERDOWN mode, the FDC clears the PCN value and the status information to zero. Prior to issuing the POWERDOWN command, it is highly recommended that the user service all pending interrupts through the Sense Interrupt Status command.

Sense Interrupt Status An interrupt signal on FINT pin is generated by

the FDC for one of the following reasons:

1. Upon entering the Result Phase of: a. Read Data command b. Read A Track command c. Read ID command d. Read Deleted Data command e. Write Data command f. Format A Track command g. Write Deleted Data command h. Verify command

2. End of Seek, Relative Seek, or Recalibrate

command

3. FDC requires a data transfer during the

execution phase in the non-DMA mode

The Sense Interrupt Status command resets the

interrupt signal and, via the IC code and SE bit of Status Register 0, identifies the cause of the interrupt.

TABLE 30 - INTERRUPT IDENTIFICATION

SE IC INTERRUPT DUE TO

0 1

Polling

Normal termination of Seek

or Recalibrate command

Abnormal termination of

Seek or Recalibrate command

The Seek, Relative Seek, and Recalibrate

commands have no result phase. The Sense Interrupt Status command must be issued immediately after these commands to terminate them and to provide verification of the head position (PCN). The H (Head Address) bit in ST0 will always return a "0". If a Sense Interrupt Status is not issued, the drive will continue to be BUSY and may affect the operation of the next command.

Sense Drive Status Sense Drive Status obtains drive status

information. It has not execution phase and goes directly to the result phase from the command phase. Status Register 3 contains the drive status information.

Specify The Specify command sets the initial values for

each of the three internal times. The HUT (Head Unload Time) defines the time from the end of the execution phase of one of the read/write commands to the head unload state. The SRT (Step Rate Time) defines the time interval between adjacent step pulses. Note that the spacing between the first and second step pulses may be shorter than the remaining step pulses. The HLT (Head Load Time) defines the time between when the Head Load signal goes high and the read/write operation starts. The values change with the data rate speed selection and are documented in Table 27. The values are the same for MFM and FM.

Page 64

TABLE 30 - DRIVE CONTROL DELAYS (MS)

2M 1M 500K 300K 250K 2M 1M 500K 300K 250K

64 1 .. E

56 F

128 4 ..

.. 112 120

256

.. 224 240

HUT

426

26.7 ..

373 400

00 01 02

.. 7F 7F

2M 1M 500K 300K 250K

0.5 1 ..

63.5

128

1 2

.. 126 127

The choice of DMA or non-DMA operations is

made by the ND bit. When this bit is "1", the non-DMA mode is selected, and when ND is "0", the DMA mode is selected. In DMA mode, data transfers are signaled by the FDRQ pin. NonDMA mode uses the RQM bit and the FINT pin to signal data transfers.

Configure The Configure command is issued to select the

special features of the FDC. A Configure command need not be issued if the default values of the FDC meet the system requirements.

Configure Default Values: EIS - No Implied Seeks

EFIFO - FIFO Disabled POLL - Polling Enabled FIFOTHR - FIFO Threshold Set to 1 Byte PRETRK - Pre-Compensation Set to Track 0

512

.. 448 480

3.75 ..

0.5

0.25

7.5 .. 1

0.5

16 15

.. 2 1

SRT

26.7 25

3.33

1.67

32 30

HLT

256

2 4

.. 252 254

426

3.3

6.7 ..

420 423

512

4 8

. 504 508

EIS - Enable Implied Seek. When set to "1", the

FDC will perform a Seek operation before executing a read or write command. Defaults to no implied seek.

EFIFO - A "1" disables the FIFO (default). This

means data transfers are asked for on a byteby-byte basis. Defaults to "1", FIFO disabled. The threshold defaults to "1".

POLL - Disable polling of the drives. Defaults to

"0", polling enabled. When enabled, a single interrupt is generated after a reset. No polling is performed while the drive head is loaded and the head unload delay has not expired.

FIFOTHR - The FIFO threshold in the execution

phase of read or write commands. This is programmable from 1 to 16 bytes. Defaults to one byte. A "00" selects one byte; "0F" selects 16 bytes.

PRETRK - Pre-Compensation Start Track

Number. Programmable from track 0 to 255. Defaults to track 0. A "00" selects track 0; "FF" selects track 255.

4 2

Page 65

Version The Version command checks to see if the

controller is an enhanced type or the older type (765A). A value of 90 H is returned as the result byte.

Relative Seek The command is coded the same as for Seek,

except for the MSB of the first byte and the DIR bit.

DIR ACTION

0 1 Step Head Out

Step Head In

DIR Head Step Direction Control RCN Relative Cylinder Number that

determines how many tracks to step the head in or out from the current track number.

The Relative Seek command differs from the

Seek command in that it steps the head the absolute number of tracks specified in the command instead of making a comparison against an internal register. The Seek command is good for drives that support a maximum of 256 tracks. Relative Seeks cannot be overlapped with other Relative Seeks. Only one Relative Seek can be active at a time. Relative Seeks may be overlapped with Seeks and Recalibrates. Bit 4 of Status Register 0 (EC) will be set if Relative Seek attempts to step outward beyond Track 0.

As an example, assume that a floppy drive has

300 useable tracks. The host needs to read track 300 and the head is on any track (0-255). If a Seek command is issued, the head will stop at track 255. If a Relative Seek command is issued, the FDC will move the head the specified number of tracks, regardless of the internal cylinder position register (but will increment the register). If the head was on track

40 (d), the maximum track that the FDC could position the head on using Relative Seek will be 295 (D), the initial track + 255 (D). The maximum count that the head can be moved with a single Relative Seek command is 255 (D).

The internal register, PCN, will overflow as the

cylinder number crosses track 255 and will contain 39 (D). The resulting PCN value is thus (RCN + PCN) mod 256. Functionally, the FDC starts counting from 0 again as the track number goes above 255 (D). It is the user's responsibility to compensate FDC functions (precompensation track number) when accessing tracks greater than 255. The FDC does not keep track that it is working in an "extended track area" (greater than 255). Any command issued will use the current PCN value except for the Recalibrate command, which only looks for the TRACK0 signal. Recalibrate will return an error if the head is farther than 79 due to its limitation of issuing a maximum of 80 step pulses. The user simply needs to issue a second Recalibrate command. The Seek command and implied seeks will function correctly within the 44 (D) track (299-255) area of the "extended track area". It is the user's responsibility not to issue a new track position that will exceed the maximum track that is present in the extended area.

To return to the standard floppy range (0-255) of

tracks, a Relative Seek should be issued to cross the track 255 boundary.

A Relative Seek can be used instead of the

normal Seek, but the host is required to calculate the difference between the current head location and the new (target) head location. This may require the host to issue a Read ID command to ensure that the head is physically on the track that software assumes it to be. Different FDC commands will return different cylinder results which may be difficult to keep track of with software without the Read ID command.

Page 66

Perpendicular Mode The Perpendicular Mode command should be

issued prior to executing Read/Write/Format commands that access a disk drive with perpendicular recording capability. With this command, the length of the Gap2 field and VCO enable timing can be altered to accommodate the unique requirements of these drives. Table 28 describes the effects of the WGATE and GAP bits for the Perpendicular Mode command. Upon a reset, the FDC will default to the conventional mode (WGATE = 0, GAP = 0).

Selection of the 500 Kbps and 1 Mbps

perpendicular modes is independent of the actual data rate selected in the Data Rate Select Register. The user must ensure that these two data rates remain consistent.

The Gap2 and VCO timing requirements for

perpendicular recording type drives are dictated by the design of the read/write head. In the design of this head, a pre-erase head precedes the normal read/write head by a distance of 200 micrometers. This works out to about 38 bytes at a 1 Mbps recording density. Whenever the write head is enabled by the Write Gate signal, the pre-erase head is also activated at the same time. Thus, when the write head is initially turned on, flux transitions recorded on the media for the first 38 bytes will not be preconditioned with the pre-erase head since it has not yet been activated. To accommodate this head activation and deactivation time, the Gap2 field is expanded to a length of 41 bytes. The format field shown on Page 58 illustrates the change in the Gap2 field size for the perpendicular format.

On the read back by the FDC, the controller

must begin synchronization at the beginning of the sync field. For the conventional mode, the internal PLL VCO is enabled (VCOEN) approximately 24 bytes from the start of the Gap2 field. But, when the controller operates in the 1 Mbps perpendicular mode (WGATE = 1, GAP = 1), VCOEN goes active after 43 bytes to accommodate the increased Gap2 field size.

For both cases, and approximate two-byte cushion is maintained from the beginning of the sync field for the purposes of avoiding write splices in the presence of motor speed variation.

For the Write Data case, the FDC activates

Write Gate at the beginning of the sync field under the conventional mode. The controller then writes a new sync field, data address mark, data field, and CRC as shown on page 57. With the pre-erase head of the perpendicular drive, the write head must be activated in the Gap2 field to insure a proper write of the new sync field. For the 1 Mbps perpendicular mode (WGATE = 1, GAP = 1), 38 bytes will be written in the Gap2 space. Since the bit density is proportional to the data rate, 19 bytes will be written in the Gap2 field for the 500 Kbps perpendicular mode (WGATE = 1, GAP =0).

It should be noted that none of the alterations in

Gap2 size, VCO timing, or Write Gate timing affect normal program flow. The information provided here is just for background purposes and is not needed for normal operation. Once the Perpendicular Mode command is invoked, FDC software behavior from the user standpoint is unchanged.

The perpendicular mode command is enhanced

to allow specific drives to be designated Perpendicular recording drives. This enhancement allows data transfers between Conventional and Perpendicular drives without having to issue Perpendicular mode commands between the accesses of the different drive types, nor having to change write precompensation values.

When both GAP and WGATE bits of the

PERPENDICULAR MODE COMMAND are both programmed to "0" (Conventional mode), then D0, D1, D2, D3, and D4 can be programmed independently to "1" for that drive to be set automatically to Perpendicular mode. In this mode the following set of conditions also apply:

1. The GAP2 written to a perpendicular drive

during a write operation will depend upon the programmed data rate.

Page 67

2. The write pre-compensation given to a

perpendicular mode drive will be 0ns.

3. For D0-D3 programmed to "0" for

conventional mode drives any data written will be at the currently programmed write pre-compensation.

Note: Bits D0-D3 can only be overwritten when

OW is programmed as a "1".If either GAP or WGATE is a "1" then D0-D3 are ignored.

TABLE 31 - EFFECTS OF WGATE AND GAP BITS

WGATE

0 0

1 1

GAP

0 1

MODE Conventional Perpendicular (500 Kbps) Reserved (Conventional) Perpendicular (1 Mbps)

Software and hardware resets have the

following effect on the PERPENDICULAR MODE COMMAND:

1. "Software" resets (via the DOR or DSR

registers) will only clear GAP and WGATE bits to "0". D0-D3 are unaffected and retain their previous value.

2. "Hardware" resets will clear all bits

(GAP, WGATE and D0-D3) to "0", i.e all conventional mode.

LENGTH OF

GAP2 FORMAT

FIELD

22 Bytes 22 Bytes

22 Bytes 41 Bytes

PORTION OF

GAP 2 WRITTEN

BY WRITE DATA

OPERATION

0 Bytes

19 Bytes

0 Bytes

38 Bytes

Page 68

LOCK In order to protect systems with long DMA

latencies against older application software that can disable the FIFO the LOCK Command has been added. This command should only be used by the FDC routines, and application software should refrain from using it. If an application calls for the FIFO to be disabled then the CONFIGURE command should be used.

The LOCK command defines whether the

EFIFO, FIFOTHR, and PRETRK parameters of the CONFIGURE command can be RESET by the DOR and DSR registers. When the LOCK bit is set to logic "1" all subsequent "software RESETS by the DOR and DSR registers will not change the previously set parameters to their default values. All "hardware" RESET from the RESET pin will set the LOCK bit to logic "0" and return the EFIFO, FIFOTHR, and PRETRK to their default values. A status byte is returned immediately after issuing a LOCK command. This byte reflects the value of the LOCK bit set by the command byte.

ENHANCED DUMPREG The DUMPREG command is designed to

support system run-time diagnostics and application software development and debug.

To accommodate the LOCK command and the enhanced PERPENDICULAR MODE command the eighth byte of the DUMPREG command has been modified to contain the additional data from these two commands.

COMPATIBILITY This chip was designed with software

compatibility in mind. It is a fully backwardscompatible solution with the older generation 765A/B disk controllers. The FDC also implements on-board registers for compatibility with the PS/2, as well as PC/AT and PC/XT, floppy disk controller subsystems. After a hardware reset of the FDC, all registers, functions and enhancements default to a PC/AT, PS/2 or PS/2 Model 30 compatible operating mode, depending on how the IDENT and MFM bits are configured by the system BIOS.

FORCE WRITE PROTECT The Force Write Protect function forces the FDD

nWRTPRT input active if the FORCE WRTPRT bit is active. The Force Write Protect function applies to the nWRTPRT pin in the FDD Interface as well as the nWRTPRT pin in the Parallel Port FDC. Refer to Configuration Register L8CR_C5 for more information.

Page 69

SERIAL PORT (UART)

The chip incorporates two full function UARTs.

They are compatible with the NS16450, the 16450 ACE registers and the NS16C550A. The UARTS perform serial-to-parallel conversion on received characters and parallel-to-serial conversion on transmit characters. The data rates are independently programmable from

460.8K baud down to 50 baud. The character options are programmable for 1 start; 1, 1.5 or 2 stop bits; even, odd, sticky or no parity; and prioritized interrupts. The UARTs each contain a programmable baud rate generator that is capable of dividing the input clock or crystal by a number from 1 to 65535. The UARTs are also capable of supporting the MIDI data rate. Refer to the Configuration Registers for information on disabling, power down and changing the base address of the UARTs. The interrupt from a UART is enabled by programming OUT2 of that UART to a logic "1". OUT2 being a logic "0"

disables that UART's interrupt. The second UART also supports IrDA 1.0, HP-SIR and ASKIR infrared modes of operation.

Note: The UARTs may be configured to share

an interrupt. Refer to the Configuration section for more information.

Serial Port is shown below. The configuration registers (see Configuration section) define the base addresses of the serial ports. The Serial Port registers are located at sequentially increasing addresses above these base addresses. The chip contains two serial ports, each of which contain a register set as described below.

TABLE 32 - ADDRESSING THE SERIAL PORT

DLAB* A2 A1 A0 REGISTER NAME

0 0 0 0 Receive Buffer (read) 0 0 0 0 Transmit Buffer (write) 0 0 0 1 Interrupt Enable (read/write) X 0 1 0 Interrupt Identification (read) X 0 1 0 FIFO Control (write) X 0 1 1 Line Control (read/write) X 1 0 0 Modem Control (read/write) X 1 0 1 Line Status (read/write) X 1 1 0 Modem Status (read/write) X 1 1 1 Scratchpad (read/write) 1 0 0 0 Divisor LSB (read/write) 1 0 0 1 Divisor MSB (read/write

*Note: DLAB is Bit 7 of the Line Control Register

The following section describes the operation of the registers.

Page 70

RECEIVE BUFFER REGISTER (RB) Address Offset = 0H, DLAB = 0, READ ONLY This register holds the received incoming data

byte. Bit 0 is the least significant bit, which is transmitted and received first. Received data is double buffered; this uses an additional shift register to receive the serial data stream and convert it to a parallel 8 bit word which is transferred to the Receive Buffer register. The shift register is not accessible.

TRANSMIT BUFFER REGISTER (TB) Address Offset = 0H, DLAB = 0, WRITE ONLY

This register contains the data byte to be

transmitted. The transmit buffer is double buffered, utilizing an additional shift register (not accessible) to convert the 8 bit data word to a serial format. This shift register is loaded from the Transmit Buffer when the transmission of the previous byte is complete.

INTERRUPT ENABLE REGISTER (IER) Address Offset = 1H, DLAB = 0, READ/WRITE

The lower four bits of this register control the

enables of the five interrupt sources of the Serial Port interrupt. It is possible to totally disable the interrupt system by resetting bits 0 through 3 of this register. Similarly, setting the appropriate bits of this register to a high, selected interrupts can be enabled. Disabling the interrupt system inhibits the Interrupt Identification Register and disables any Serial Port interrupt out of the chip. All other system functions operate in their normal manner, including the Line Status and MODEM Status Registers. The contents of the Interrupt Enable Register are described below.

Bit 0 This bit enables the Received Data Available

Interrupt (and timeout interrupts in the FIFO mode) when set to logic "1".

Bit 1 This bit enables the Transmitter Holding

Bit 2 This bit enables the Received Line Status

Interrupt when set to logic "1". The error sources causing the interrupt are Overrun, Parity, Framing and Break. The Line Status Register must be read to determine the source.

Bit 3 This bit enables the MODEM Status Interrupt

when set to logic "1". This is caused when one of the Modem Status Register bits changes state.

Bits 4 through 7 These bits are always logic "0".

FIFO CONTROL REGISTER (FCR) Address Offset = 2H, DLAB = X, WRITE

This is a write only register at the same location

as the IIR. This register is used to enable and clear the FIFOs, set the RCVR FIFO trigger level. Note: DMA is not supported. The UART1 and UART2 FCR’s are shadowed in the UART1 FIFO Control Shadow Register (LD8:CRC3[7:0]) and UART2 FIFO Control Shadow Register (LD8:CRC4[7:0]).

Bit 0 Setting this bit to a logic "1" enables both the

XMIT and RCVR FIFOs. Clearing this bit to a logic "0" disables both the XMIT and RCVR FIFOs and clears all bytes from both FIFOs. When changing from FIFO Mode to non-FIFO (16450) mode, data is automatically cleared from the FIFOs. This bit must be a 1 when other bits in this register are written to or they will not be properly programmed.

Bit 1 Setting this bit to a logic "1" clears all bytes in

the RCVR FIFO and resets its counter logic to 0. The shift register is not cleared. This bit is selfclearing.

Page 71

Bit 2 Setting this bit to a logic "1" clears all bytes in

the XMIT FIFO and resets its counter logic to 0. The shift register is not cleared. This bit is selfclearing.

Bit 3 Writing to this bit has no effect on the operation

of the UART. The RXRDY and TXRDY pins are not available on this chip.

Bit 4,5 Reserved Bit 6,7 These bits are used to set the trigger level for

the RCVR FIFO interrupt.

Bit 7

Bit 6

RCVR FIFO

Trigger Level (BYTES)

0 0 1 0 1 4 1 0 8 1 1 14

INTERRUPT IDENTIFICATION REGISTER

(IIR)

Address Offset = 2H, DLAB = X, READ By accessing this register, the host CPU can

determine the highest priority interrupt and its source. Four levels of priority interrupt exist. They are in descending order of priority:

1. Receiver Line Status (highest priority)

2. Received Data Ready

3. Transmitter Holding Register Empty

4. MODEM Status (lowest priority)

Information indicating that a prioritized interrupt

is pending and the source of that interrupt is stored in the Interrupt Identification Register (refer to Interrupt Control Table). When the CPU accesses the IIR, the Serial Port freezes all interrupts and indicates the highest priority pending interrupt to the CPU. During this CPU access, even if the Serial Port records new interrupts, the current indication does not change until access is completed. The contents of the IIR are described below.

Bit 0 This bit can be used in either a hardwired

prioritized or polled environment to indicate whether an interrupt is pending. When bit 0 is a logic "0", an interrupt is pending and the contents of the IIR may be used as a pointer to the appropriate internal service routine. When bit 0 is a logic "1", no interrupt is pending.

Bits 1 and 2 These two bits of the IIR are used to identify the

highest priority interrupt pending as indicated by the Interrupt Control Table.

Bit 3 In non-FIFO mode, this bit is a logic "0". In

FIFO mode this bit is set along with bit 2 when a timeout interrupt is pending.

Bits 4 and 5 These bits of the IIR are always logic "0".

Bits 6 and 7 These two bits are set when the FIFO

CONTROL Register bit 0 equals 1.

Page 72

TABLE 33 - INTERRUPT CONTROL

FIFO

MODE

ONLY

BIT 3 BIT 2 BIT 1 BIT 0

INTERRUPT

IDENTIFICATION

PRIORITY

LEVEL

INTERRUPT SET AND RESET FUNCTIONS

INTERRUPT

TYPE

INTERRUPT

SOURCE

0 0 0 1 - None None - 0 1 1 0 Highest Receiver Line

Status

0 1 0 0 Second Received

Data Available

1 1 0 0 Second Character

Timeout Indication

0 0 1 0 Third Transmitter

Holding Register Empty

0 0 0 0 Fourth MODEM

Status

Overrun Error,

Parity Error, Framing Error or Break Interrupt

Receiver Data

Available

No Characters

Have Been Removed From or Input to the RCVR FIFO during the last 4 Char times and there is at least 1 char in it during this time

Transmitter

Holding Register Empty

Clear to Send or

Data Set Ready or Ring Indicator or Data Carrier Detect

INTERRUPT

RESET CONTROL

Reading the Line

Status Register

Read Receiver

Buffer or the FIFO drops below the trigger level.

Reading the

Receiver Buffer Register

Reading the IIR

Reading the

MODEM Status Register

Page 73

BIT 2 WORD LENGTH

0 -- 1 1 5 bits 1.5 1 6 bits 2 1 7 bits 2 1 8 bits 2

LINE CONTROL REGISTER (LCR) Address Offset = 3H, DLAB = 0, READ/WRITE

This register contains the format information of

the serial line. The bit definitions are:

BIT 1 BIT 0 WORD LENGTH

0 0 1 1

0 1 0 1

Bit 2 This bit specifies the number of stop bits in each

transmitted or received serial character. The following table summarizes the information. Note: The receiver will ignore all stop bits beyond the first, regardless of the number used in transmitting.

Bit 3 Parity Enable bit. When bit 3 is a logic "1", a

parity bit is generated (transmit data) or checked (receive data) between the last data word bit and the first stop bit of the serial data. (The parity bit is used to generate an even or odd number of 1s when the data word bits and the parity bit are summed).

Bit 4 Even Parity Select bit. When bit 3 is a logic "1"

and bit 4 is a logic "0", an odd number of logic "1"'s is transmitted or checked in the data word bits and the parity bit. When bit 3 is a logic "1" and bit 4 is a logic "1" an even number of bits is transmitted and checked.

NUMBER OF

STOP BITS

Bits 0 and 1 These two bits specify the number of bits in

each transmitted or received serial character. The encoding of bits 0 and 1 is as follows:

The Start, Stop and Parity bits are not included

in the word length.

5 Bits 6 Bits 7 Bits 8 Bits

Bit 5 Stick Parity bit. When bit 3 is a logic "1" and bit

5 is a logic "1", the parity bit is transmitted and then detected by the receiver in the opposite state indicated by bit 4.

Bit 6 Set Break Control bit. When bit 6 is a logic "1",

the transmit data output (TXD) is forced to the Spacing or logic "0" state and remains there (until reset by a low level bit 6) regardless of other transmitter activity. This feature enables the Serial Port to alert a terminal in a communications system.

Bit 7 Divisor Latch Access bit (DLAB). It must be set

high (logic "1") to access the Divisor Latches of the Baud Rate Generator during read or write operations. It must be set low (logic "0") to access the Receiver Buffer Register, the Transmitter Holding Register, or the Interrupt Enable Register.

Page 74

MODEM CONTROL REGISTER (MCR) Address Offset = 4H, DLAB = X, READ/WRITE This 8 bit register controls the interface with the

MODEM or data set (or device emulating a MODEM). The contents of the MODEM control register are described below.

Bit 0 This bit controls the Data Terminal Ready

(nDTR) output. When bit 0 is set to a logic "1", the nDTR output is forced to a logic "0". When bit 0 is a logic "0", the nDTR output is forced to a logic "1".

Bit 1 This bit controls the Request To Send (nRTS)

output. Bit 1 affects the nRTS output in a manner identical to that described above for bit

Bit 2 This bit controls the Output 1 (OUT1) bit. This

bit does not have an output pin and can only be read or written by the CPU.

Bit 3 Output 2 (OUT2). This bit is used to enable an

UART interrupt. When OUT2 is a logic "0", the serial port interrupt output is forced to a high impedance state - disabled. When OUT2 is a logic "1", the serial port interrupt outputs are enabled.

Bit 4 This bit provides the loopback feature for

diagnostic testing of the Serial Port. When bit 4 is set to logic "1", the following occur:

1. The TXD is set to the Marking State(logic

"1").

2. The receiver Serial Input (RXD) is

disconnected.

3. The output of the Transmitter Shift Register

is "looped back" into the Receiver Shift Register input.

4. All MODEM Control inputs (nCTS, nDSR,

nRI and nDCD) are disconnected.

5. The four MODEM Control outputs (nDTR,

nRTS, OUT1 and OUT2) are internally connected to the four MODEM Control inputs (nDSR, nCTS, RI, DCD).

6. The Modem Control output pins are forced

inactive high.

7. Data that is transmitted is immediately

received.

This feature allows the processor to verify the

transmit and receive data paths of the Serial Port. In the diagnostic mode, the receiver and the transmitter interrupts are fully operational. The MODEM Control Interrupts are also operational but the interrupts' sources are now the lower four bits of the MODEM Control Register instead of the MODEM Control inputs. The interrupts are still controlled by the Interrupt Enable Register.

Bits 5 through 7 These bits are permanently set to logic zero.

LINE STATUS REGISTER (LSR) Address Offset = 5H, DLAB = X, READ/WRITE

Bit 0 Data Ready (DR). It is set to a logic "1"

whenever a complete incoming character has been received and transferred into the Receiver Buffer Register or the FIFO. Bit 0 is reset to a logic "0" by reading all of the data in the Receive Buffer Register or the FIFO.

Bit 1 Overrun Error (OE). Bit 1 indicates that data in

the Receiver Buffer Register was not read before the next character was transferred into the register, thereby destroying the previous character. In FIFO mode, an overrun error will occur only when the FIFO is full and the next character has been completely received in the shift register, the character in the shift register is overwritten but not transferred to the FIFO. The OE indicator is set to a logic "1" immediately upon detection of an overrun condition, and reset whenever the Line Status Register is read.

Bit 2 Parity Error (PE). Bit 2 indicates that the

received data character does not have the correct even or odd parity, as selected by the even parity select bit. The PE is set to a logic "1" upon detection of a parity error and is reset to a logic "0" whenever the Line Status Register is read. In the FIFO mode this error is

Page 75

associated with the particular character in the FIFO it applies to. This error is indicated when the associated character is at the top of the FIFO.

Bit 3 Framing Error (FE). Bit 3 indicates that the

received character did not have a valid stop bit. Bit 3 is set to a logic "1" whenever the stop bit following the last data bit or parity bit is detected as a zero bit (Spacing level). The FE is reset to a logic "0" whenever the Line Status Register is read. In the FIFO mode this error is associated with the particular character in the FIFO it applies to. This error is indicated when the associated character is at the top of the FIFO. The Serial Port will try to resynchronize after a framing error. To do this, it assumes that the framing error was due to the next start bit, so it samples this 'start' bit twice and then takes in the 'data'.

Bit 4 Break Interrupt (BI). Bit 4 is set to a logic "1"

whenever the received data input is held in the Spacing state (logic "0") for longer than a full word transmission time (that is, the total time of the start bit + data bits + parity bits + stop bits). The BI is reset after the CPU reads the contents of the Line Status Register. In the FIFO mode this error is associated with the particular character in the FIFO it applies to. This error is indicated when the associated character is at the top of the FIFO. When break occurs only one zero character is loaded into the FIFO. Restarting after a break is received, requires the serial data (RXD) to be logic "1" for at least 1/2 bit time.

Note: Bits 1 through 4 are the error conditions

that produce a Receiver Line Status Interrupt whenever any of the corresponding conditions are detected and the interrupt is enabled.

Bit 5 Transmitter Holding Register Empty (THRE).

Bit 5 indicates that the Serial Port is ready to accept a new character for transmission. In addition, this bit causes the Serial Port to issue an interrupt when the Transmitter Holding Register interrupt enable is set high. The THRE bit is set to a logic "1" when a character is transferred from the Transmitter Holding Register into the Transmitter Shift Register. The bit is reset to logic "0" whenever the CPU loads the Transmitter Holding Register. In the FIFO mode this bit is set when the XMIT FIFO is empty, it is cleared when at least 1 byte is written to the XMIT FIFO. Bit 5 is a read only bit.

Bit 6 Transmitter Empty (TEMT). Bit 6 is set to a

logic "1" whenever the Transmitter Holding Register (THR) and Transmitter Shift Register (TSR) are both empty. It is reset to logic "0" whenever either the THR or TSR contains a data character. Bit 6 is a read only bit. In the FIFO mode this bit is set whenever the THR and TSR are both empty,

Bit 7 This bit is permanently set to logic "0" in the 450

mode. In the FIFO mode, this bit is set to a logic "1" when there is at least one parity error, framing error or break indication in the FIFO. This bit is cleared when the LSR is read if there are no subsequent errors in the FIFO.

MODEM STATUS REGISTER (MSR) Address Offset = 6H, DLAB = X, READ/WRITE

This 8 bit register provides the current state of

the control lines from the MODEM (or peripheral device). In addition to this current state information, four bits of the MODEM Status Register (MSR) provide change information. These bits are set to logic "1" whenever a control input from the MODEM changes state. They are reset to logic "0" whenever the MODEM Status Register is read.

Page 76

Bit 0 Delta Clear To Send (DCTS). Bit 0 indicates

that the nCTS input to the chip has changed state since the last time the MSR was read.

Bit 1 Delta Data Set Ready (DDSR). Bit 1 indicates

that the nDSR input has changed state since the last time the MSR was read.

Bit 2 Trailing Edge of Ring Indicator (TERI). Bit 2

indicates that the nRI input has changed from logic "0" to logic "1".

Bit 3 Delta Data Carrier Detect (DDCD). Bit 3

indicates that the nDCD input to the chip has changed state.

Note: Whenever bit 0, 1, 2, or 3 is set to a logic

"1", a MODEM Status Interrupt is generated.

Bit 4 This bit is the complement of the Clear To Send

(nCTS) input. If bit 4 of the MCR is set to logic "1", this bit is equivalent to nRTS in the MCR.

Bit 5 This bit is the complement of the Data Set

Ready (nDSR) input. If bit 4 of the MCR is set to logic "1", this bit is equivalent to DTR in the MCR.

Bit 6 This bit is the complement of the Ring Indicator

(nRI) input. If bit 4 of the MCR is set to logic "1", this bit is equivalent to OUT1 in the MCR.

Bit 7 This bit is the complement of the Data Carrier

Detect (nDCD) input. If bit 4 of the MCR is set

to logic "1", this bit is equivalent to OUT2 in the MCR.

SCRATCHPAD REGISTER (SCR) Address Offset =7H, DLAB =X, READ/WRITE This 8 bit read/write register has no effect on the

operation of the Serial Port. It is intended as a scratchpad register to be used by the programmer to hold data temporarily.

PROGRAMMABLE BAUD RATE GENERATOR

(AND DIVISOR LATCHES DLH, DLL)

The Serial Port contains a programmable Baud

Rate Generator that is capable of taking any clock input (DC to 3 MHz) and dividing it by any divisor from 1 to 65535. This output frequency of the Baud Rate Generator is 16x the Baud rate. Two 8 bit latches store the divisor in 16 bit binary format. These Divisor Latches must be loaded during initialization in order to insure desired operation of the Baud Rate Generator. Upon loading either of the Divisor Latches, a 16 bit Baud counter is immediately loaded. This prevents long counts on initial load. If a 0 is loaded into the BRG registers the output divides the clock by the number 3. If a 1 is loaded the output is the inverse of the input oscillator. If a two is loaded the output is a divide by 2 signal with a 50% duty cycle. If a 3 or greater is loaded the output is low for 2 bits and high for the remainder of the count. The input clock to the BRG is a 1.8462 MHz clock.

Table 31 shows the baud rates possible with a

1.8462 MHz crystal.

Page 77

Table 34 - Baud Rates Using 1.8462 MHz Clock for <= 38.4K; Using 1.8432MHz Clock

for 115.2k ; Using 3.6864MHz Clock for 230.4k; Using 7.3728 MHz Clock for 460.8k

DESIRED

BAUD RATE

DIVISOR USED TO

GENERATE 16X CLOCK

PERCENT ERROR DIFFERENCE

BETWEEN DESIRED AND ACTUAL

SPEED BIT

HIGH

50 2304 0.001 X 75 1536 - X 110 1047 - X

134.5 857 0.004 X 150 768 - X 300 384 - X 600 192 - X

1200 96 - X 1800 64 - X 2000 58 0.005 X 2400 48 - X 3600 32 - X 4800 24 - X 7200 16 - X

9600 12 - X 19200 6 - X 38400 3 0.030 X 57600 2 0.16 X

115200 1 0.16 X 230400 32770 0.16 1 460800 32769 0.16 1

Note

: The percentage error for all baud rates, except where indicated otherwise, is 0.2%.

Note

: The High Speed bit is located in the Device Configuration Space.

Effect Of The Reset on Register File The Reset Function Table (Table 35) details the effect of the Reset input on each of the registers of

the Serial Port.

Page 78

FIFO INTERRUPT MODE OPERATION When the RCVR FIFO and receiver interrupts

are enabled (FCR bit 0 = "1", IER bit 0 = "1"), RCVR interrupts occur as follows:

A. The receive data available interrupt will be

issued when the FIFO has reached its programmed trigger level; it is cleared as soon as the FIFO drops below its programmed trigger level.

B. The IIR receive data available indication also

occurs when the FIFO trigger level is reached. It is cleared when the FIFO drops below the trigger level.

C. The receiver line status interrupt (IIR=06H),

has higher priority than the received data available (IIR=04H) interrupt.

D. The data ready bit (LSR bit 0) is set as soon

as a character is transferred from the shift register to the RCVR FIFO. It is reset when the FIFO is empty.

When RCVR FIFO and receiver interrupts are

enabled, RCVR FIFO timeout interrupts occur as follows:

A. A FIFO timeout interrupt occurs if all the

following conditions exist:

- At least one character is in the FIFO.

- The most recent serial character received was longer than 4 continuous character times ago. (If 2 stop bits are programmed, the second one is included in this time delay).

- The most recent CPU read of the FIFO was longer than 4 continuous character times ago.

This will cause a maximum character received

to interrupt issued delay of 160 msec at 300 BAUD with a 12 bit character.

B. Character times are calculated by using the

RCLK input for a clock signal (this makes the delay proportional to the baudrate).

C. When a timeout interrupt has occurred it is

cleared and the timer reset when the CPU reads one character from the RCVR FIFO.

D. When a timeout interrupt has not occurred

the timeout timer is reset after a new character is received or after the CPU reads the RCVR FIFO.

When the XMIT FIFO and transmitter interrupts

are enabled (FCR bit 0 = "1", IER bit 1 = "1"), XMIT interrupts occur as follows:

A. The transmitter holding register interrupt

(02H) occurs when the XMIT FIFO is empty; it is cleared as soon as the transmitter holding register is written to (1 of 16 characters may be written to the XMIT FIFO while servicing this interrupt) or the IIR is read.

B. The transmitter FIFO empty indications will

be delayed 1 character time minus the last stop bit time whenever the following occurs: THRE=1 and there have not been at least two bytes at the same time in the transmitter FIFO since the last THRE=1. The transmitter interrupt after changing FCR0 will be immediate, if it is enabled.

Character timeout and RCVR FIFO trigger level

interrupts have the same priority as the current received data available interrupt; XMIT FIFO empty has the same priority as the current transmitter holding register empty interrupt.

Page 79

FIFO POLLED MODE OPERATION With FCR bit 0 = "1" resetting IER bits 0, 1, 2 or

3 or all to zero puts the UART in the FIFO Polled Mode of operation. Since the RCVR and XMITTER are controlled separately, either one or both can be in the polled mode of operation. In this mode, the user's program will check RCVR and XMITTER status via the LSR. LSR definitions for the FIFO Polled Mode are as follows:

- Bit 0=1 as long as there is one byte in the RCVR FIFO.

- Bits 1 to 4 specify which error(s) have

occurred. Character error status is handled the same way as when in the interrupt mode, the IIR is not affected since EIR bit 2=0.

- Bit 5 indicates when the XMIT FIFO is empty.

- Bit 6 indicates that both the XMIT FIFO and shift register are empty.

- Bit 7 indicates whether there are any errors in the RCVR FIFO.

There is no trigger level reached or timeout

condition indicated in the FIFO Polled Mode, however, the RCVR and XMIT FIFOs are still fully capable of holding characters.

Page 80

TABLE 35 - RESET FUNCTION

REGISTER/SIGNAL RESET CONTROL RESET STATE Interrupt Enable Register RESET All bits low Interrupt Identification Reg. RESET Bit 0 is high; Bits 1 - 7 low FIFO Control RESET All bits low Line Control Reg. RESET All bits low MODEM Control Reg. RESET All bits low Line Status Reg. RESET All bits low except 5, 6 high MODEM Status Reg. RESET Bits 0 - 3 low; Bits 4 - 7 input TXD1, TXD2 RESET High INTRPT (RCVR errs) RESET/Read LSR Low INTRPT (RCVR Data Ready) RESET/Read RBR Low INTRPT (THRE) RESET/ReadIIR/Write THR Low OUT2B RESET High RTSB RESET High DTRB RESET High OUT1B RESET High RCVR FIFO RESET/

All Bits Low

FCR1*FCR0/_FCR0

XMIT FIFO RESET/

All Bits Low

FCR1*FCR0/_FCR0

Page 81

TABLE 36 - REGISTER SUMMARY FOR AN INDIVIDUAL UART CHANNEL

ADDRESS*

ADDR = 0

Receive Buffer Register (Read Only) RBR Data Bit 0

DLAB = 0 ADDR = 0

DLAB = 0 ADDR = 1

Transmitter Holding Register (Write

Only)

Interrupt Enable Register IER Enable

DLAB = 0

ADDR = 2

Interrupt Ident. Register (Read Only) IIR "0" if

ADDR = 2 FIFO Control Register (Write Only) FCR

ADDR = 3

Line Control Register LCR

ADDR = 4

MODEM Control Register MCR Data

ADDR = 5

Line Status Register LSR

ADDR = 6

MODEM Status Register MSR

SYMBOL

BIT 0

BIT 1

Data Bit 1

(Note 1)

THR Data Bit 0 Data Bit 1

Enable

Received Data Available Interrupt (ERDAI)

Transmitter Holding Register Empty Interrupt (ETHREI)

Interrupt ID

(Note 7)

Interrupt Pending

FIFO

Enable

Word

Length Select Bit 0 (WLS0)

Bit

RCVR FIFO

Reset

Word

Length Select Bit 1 (WLS1)

Request to

Terminal Ready (DTR)

Data Ready

(DR)

Delta Clear

to Send (DCTS)

Send (RTS)

Overrun

Error (OE)

Delta Data

Set Ready (DDSR)

ADDR = 7 Scratch Register (Note 4) SCR Bit 0 Bit 1 ADDR = 0

Divisor Latch (LS) DDL Bit 0 Bit 1 DLAB = 1 ADDR = 1

Divisor Latch (MS) DLM Bit 8 Bit 9 DLAB = 1

*DLAB is Bit 7 of the Line Control Register (ADDR = 3). Note 1: Bit 0 is the least significant bit. It is the first bit serially transmitted or received. Note 2: When operating in the XT mode, this bit will be set any time that the transmitter shift

Page 82

TABLE 37 - REGISTER SUMMARY FOR AN INDIVIDUAL UART CHANNEL (CONTINUED)

BIT 2 BIT 3 BIT 4 BIT 5 BIT 6 BIT 7 Data Bit 2 Data Bit 2 Enable

Receiver Line Status Interrupt (ELSI)

Interrupt ID

Bit

XMIT FIFO

Reset

Number of

Stop Bits (STB)

OUT1 (Note 3)

Parity Error

(PE)

Trailing Edge

Ring Indicator (TERI)

Bit 2 Bit 2 Bit 10

Data Bit 3 Data Bit 4 Data Bit 5 Data Bit 6 Data Bit 7 Data Bit 3 Data Bit 4 Data Bit 5 Data Bit 6 Data Bit 7 Enable

MODEM Status Interrupt (EMSI)

Interrupt ID

Bit (Note 5)

DMA Mode

Select (Note

Parity Enable

(PEN)

OUT2

0 0 0

0 0 FIFOs

Enabled (Note 5)

Reserved Reserved RCVR Trigger

LSB

Even Parity

Select (EPS)

Stick Parity Set Break

Loop 0 0 0

FIFOs

Enabled (Note 5)

RCVR Trigger

MSB

Divisor Latch

Access Bit (DLAB)

(Note 3) Framing Error

(FE)

Delta Data

Carrier Detect (DDCD)

Break

Interrupt (BI)

Clear to Send

(CTS)

Transmitter

Holding Register (THRE)

Data Set

Ready (DSR)

Transmitter

Empty (TEMT) (Note 2)

Ring Indicator

(RI)

Error in

RCVR FIFO (Note 5)

Data Carrier

Detect (DCD)

Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 11 Bit 12 Bit 13 Bit 14 Bit 15

Note 3: This bit no longer has a pin associated with it. Note 4: When operating in the XT mode, this register is not available. Note 5: These bits are always zero in the non-FIFO mode. Note 6: Writing a one to this bit has no effect. DMA modes are not supported in this chip. Note 7: The UART1 and UART2 FCR’s are shadowed in the UART1 FIFO Control Shadow

Page 83

NOTES ON SERIAL PORT OPERATION FIFO MODE OPERATION: GENERAL The RCVR FIFO will hold up to 16 bytes

regardless of which trigger level is selected.

TX AND RX FIFO OPERATION The Tx portion of the UART transmits data

through TXD as soon as the CPU loads a byte into the Tx FIFO. The UART will prevent

loads to the Tx FIFO if it currently holds 16 characters. Loading to the Tx FIFO will again

be enabled as soon as the next character is transferred to the Tx shift register. These capabilities account for the largely autonomous operation of the Tx.

The UART starts the above operations typically

with a Tx interrupt. The chip issues a Tx interrupt whenever the Tx FIFO is empty and the Tx interrupt is enabled, except in the following instance. Assume that the Tx FIFO is empty and the CPU starts to load it. When the first byte enters the FIFO the Tx FIFO empty interrupt will transition from active to inactive. Depending on the execution speed of the service routine software, the UART may be able to transfer this byte from the FIFO to the shift register before the CPU loads another byte. If this happens, the Tx FIFO will be empty again and typically the UART's interrupt line would transition to the active state. This could cause a system with an interrupt control unit to record a Tx FIFO empty condition, even though the CPU is currently servicing that interrupt. Therefore,

after the first byte has been loaded into the FIFO the UART will wait one serial character transmission time before issuing a new Tx FIFO empty interrupt. This one character Tx interrupt delay will remain active until at least two bytes have the Tx FIFO empties after this condition, the Tx been loaded into the FIFO, concurrently. When interrupt will be activated without a one character delay.

Rx support functions and operation are quite

different from those described for the transmitter. The Rx FIFO receives data until the number of bytes in the FIFO equals the selected interrupt trigger level. At that time if Rx interrupts are enabled, the UART will issue an interrupt to the CPU. The Rx FIFO will continue to store bytes until it holds 16 of them. It will not accept any more data when it is full. Any more data entering the Rx shift register will set the Overrun Error flag. Normally, the FIFO depth and the programmable trigger levels will give the CPU ample time to empty the Rx FIFO before an overrun occurs.

One side-effect of having a Rx FIFO is that the

selected interrupt trigger level may be above the data level in the FIFO. This could occur when data at the end of the block contains fewer bytes than the trigger level. No interrupt would be issued to the CPU and the data would remain in the UART. To prevent the software from

having to check for this situation the chip incorporates a timeout interrupt.

The timeout interrupt is activated when there is

a least one byte in the Rx FIFO, and neither the CPU nor the Rx shift register has accessed the Rx FIFO within 4 character times of the last byte. The timeout interrupt is cleared or reset when the CPU reads the Rx FIFO or another character enters it.

These FIFO related features allow optimization

of CPU/UART transactions and are especially useful given the higher baud rate capability (256 kbaud).

Ring Wake Filter

An optional filter is provided to prevent glitches

to the wakeup circuitry and prevent unnecessary wakeup of the system when a phone is picked up or hung up. If enabled, this filter will be placed into the soft power management, SMI and PME/SCI wakeup event path of either of the UART ring indicator pins (nRI1, nRI2), or the

Page 84

nRING pin, which is an alternate function on GP11 and GP62.

This feature is enabled onto the nRING pin or

one of the ring indicator pins (nRI1, nRI2) via the Ring Filter Select Register defined below. If enabled, a frequency detection filter is placed in the path to the soft power management block, SMI and PME interface that generates an active low pulse for the duration of a signal that produces 3 edges in a 200msec time period i.e., detects a pulse train of frequency 15Hz or higher.

This filter circuit runs off of the 32 kHz clock.

This circuit is powered by the VTR power supply. When this circuit is disabled, it will draw no current.

The nRING function is part of the soft power

management block as an additional wakeup event, and the SMI and PME interface logic.

1. A status and enable bit is in the soft power status and enable registers as follows:

• RING Status bit - R/W: RING_STS, Bit 3 of Soft Power Status Register 2 (Logical Device 8, 0xB3); latched, cleared on read. 1= Ring indicator input occurred on the nRING pin and, if enabled, caused the wakeup (activated nPowerOn). 0= nRING input did not occur.

• RING Enable bit - R/W: RING_EN, Bit 3 of Soft Power Enable Register 2 (Logical Device 8, 0xB1). 1=Enable ring indication

on nRING pin as wakeup function to activate nPowerOn. 0=Disable.

2. An enable bit is in the SMI Enable Register 1 as follows:

• RING Enable bit - R/W: RING_EN, Bit 0 of SMI Register 1 (System I/O Space, at <PM1_BLK>+14h). 1=Enable ring indication on nRING pin as SMI function. 0=Disable. Note: The PME status bit for RING is used as the SMI status bit for RING (see PME Status Register).

3. A status and enable bit is in the PME status and enable registers as follows:

• RING Status bit - R/W: RING_STS, Bit 5 of PME Status Register 1 (System I/O Space, at <PM1_BLK>+Ch); latched, cleared by writing a “1” to this bit. 1= Ring indicator input occurred on the nRING pin and, if enabled, caused the nPME/SCI or SMI. 0= nRING input did not occur.

• RING Enable bit - R/W: RING_EN, Bit 5 of PME Enable Register 1 (System I/O Space, at <PM1_BLK>+Eh). 1=Enable ring indication on nRING pin as PME wakeup function. 0=Disable.

Refer to Logical Device 8, 0xC6 for

programming information The ring wakeup filter will produce an active low

pulse for the period of time that nRING, nRI1 and/or nRI2 is toggling. See figure below.

Page 85

nRING

Ring Wakeup Filter Output

FIGURE 3 - RING WAKEUP FILTER OUTPUT

INFRARED INTERFACE

The infrared interface provides a two-way

wireless communications port using infrared as a transmission medium. Several IR implementations have been provided for the second UART in this chip (logical device 5), IrDA 1.0 and Amplitude Shift Keyed IR. The IR transmission can use the standard UART2 TXD2 and RXD2 pins or optional IRTX and IRRX pins. These can be selected through the configuration registers.

IrDA 1.0 allows serial communication at baud

rates up to 115.2 kbps. Each word is sent serially beginning with a zero value start bit. A zero is signaled by sending a single IR pulse at the beginning of the serial bit time. A one is signaled by sending no IR pulse during the bit time. Please refer to the AC timing for the parameters of these pulses and the IrDA waveform.

The Amplitude Shift Keyed IR allows

asynchronous serial communication at baud rates up to 19.2K Baud. Each word is sent serially beginning with a zero value start bit. A

zero is signaled by sending a 500KHz waveform for the duration of the serial bit time. A one is signaled by sending no transmission during the bit time. Please refer to the AC timing for the parameters of the ASK-IR waveform.

If the Half-Duplex option is chosen, there is a time-out when the direction of the transmission is changed. This time-out starts at the last bit transferred during a transmission and blocks the receiver input until the timeout expires. If the transmit buffer is loaded with more data before the time-out expires, the timer is restarted after the new byte is transmitted. If data is loaded into the transmit buffer while a character is being received, the transmission will not start until the time-out expires after the last receive bit has been received. If the start bit of another character is received during this time-out, the timer is restarted after the new character is received. The IR half-duplex time-out is programmable via CRF2 in Logical Device 5. This register allows the time-out to be programmed to any value between 0 and 10msec in 100usec increments.

Page 86

PARALLEL PORT

This chip incorporates an IBM XT/AT compatible

parallel port. This supports the optional PS/2 type bi-directional parallel port (SPP), the Enhanced Parallel Port (EPP) and the Extended Capabilities Port (ECP) parallel port modes. Refer to the Configuration Registers for information on disabling, power down, changing the base address of the parallel port, and selecting the mode of operation.

This chip also provides a mode for support of

the floppy disk controller on the parallel port. The parallel port also incorporates SMSC's ChiProtect circuitry, which prevents possible damage to the parallel port due to printer powerup.

The functionality of the Parallel Port is achieved

through the use of eight addressable ports, with their associated registers and control gating. The control and data port are read/write by the CPU, the status port is read/write in the EPP mode. The address map of the Parallel Port is shown below:

DATA PORT BASE ADDRESS + 00H STATUS PORT BASE ADDRESS + 01H CONTROL PORT BASE ADDRESS + 02H EPP ADDR PORT BASE ADDRESS + 03H EPP DATA PORT 0 BASE ADDRESS + 04H EPP DATA PORT 1 BASE ADDRESS + 05H EPP DATA PORT 2 BASE ADDRESS + 06H EPP DATA PORT 3 BASE ADDRESS + 07H

The bit map of these registers is:

D0 D1 D2 D3 D4 D5 D6 D7 Note DATA PORT PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7 1 STATUS

PORT

CONTROL

PORT

EPP ADDR

PORT

EPP DATA

PORT 0

EPP DATA

PORT 1

EPP DATA

PORT 2

EPP DATA

PORT 3

TMOUT 0 0 nERR SLCT PE nACK nBUSY 1

STROBE AUTOFD nINIT SLC IRQE PCD 0 0 1

PD0 PD1 PD2 PD3 PD4 PD5 PD6 AD7 2,3 PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7 2,3 PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7 2,3 PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7 2,3 PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7 2,3

Note 1: These registers are available in all modes. Note 2: These registers are only available in EPP mode. Note 3: For EPP mode, IOCHRDY must be connected to the ISA bus.

Page 87

TABLE 38 - PARALLEL PORT CONNECTOR

HOST

CONNECTOR

PIN NUMBER

STANDARD

EPP

ECP

1 111 nStrobe nWrite nStrobe

2-9 96-103 PData<0:7> PData<0:7> PData<0:7>

10 108 nAck Intr nAck 11 107 Busy nWait Busy, PeriphAck(3) 12 106 PE (NU) PError,

nAckReverse(3) 13 105 Select (NU) Select 14 110 nAutofd nDatastb nAutoFd,

HostAck(3) 15 109 nError (NU) nFault(1)

nPeriphRequest(3) 16 94 nInit (NU) nInit(1)

nReverseRqst(3) 17 95 nSelectin nAddrstrb nSelectIn(1,3)

(1) = Compatible Mode (3) = High Speed Mode

Note: For the cable interconnection required for ECP support and the Slave Connector pin

numbers, refer to the IEEE 1284 Extended Capabilities Port Protocol and ISA Standard, Rev.

1.14, July 14, 1993. This document is available from Microsoft.

Page 88

IBM XT/AT COMPATIBLE, BIDIRECTIONAL AND EPP MODES

DATA PORT ADDRESS OFFSET = 00H

The Data Port is located at an offset of '00H'

from the base address. The data register is cleared at initialization by RESET. During a WRITE operation, the Data Register latches the contents of the data bus with the rising edge of the nIOW input. The contents of this register are buffered (non inverting) and output onto the PD0 - PD7 ports. During a READ operation in SPP mode, PD0 - PD7 ports are buffered (not latched) and output to the host CPU.

STATUS PORT ADDRESS OFFSET = 01H

The Status Port is located at an offset of '01H'

from the base address. The contents of this register are latched for the duration of an nIOR read cycle. The bits of the Status Port are defined as follows:

BIT 0 TMOUT - TIME OUT This bit is valid in EPP mode only and indicates

that a 10 usec time out has occurred on the EPP bus. A logic O means that no time out error has occurred; a logic 1 means that a time out error has been detected. This bit is cleared by a RESET. Writing a one to this bit clears the time out status bit. On a write, this bit is self clearing and does not require a write of a zero. Writing a zero to this bit has no effect.

BITS 1, 2 - are not implemented as register bits,

during a read of the Printer Status Register these bits are a low level.

BIT 3 nERR - nERROR The level on the nERROR input is read by the

CPU as bit 3 of the Printer Status Register. A logic 0 means an error has been detected; a logic 1 means no error has been detected.

BIT 4 SLCT - PRINTER SELECTED STATUS The level on the SLCT input is read by the CPU

as bit 4 of the Printer Status Register. A logic 1 means the printer is on line; a logic 0 means it is not selected.

BIT 5 PE - PAPER END The level on the PE input is read by the CPU as

bit 5 of the Printer Status Register. A logic 1 indicates a paper end; a logic 0 indicates the presence of paper.

BIT 6 nACK - nACKNOWLEDGE The level on the nACK input is read by the CPU

as bit 6 of the Printer Status Register. A logic 0 means that the printer has received a character and can now accept another. A logic 1 means that it is still processing the last character or has not received the data.

BIT 7 nBUSY - nBUSY The complement of the level on the BUSY input

is read by the CPU as bit 7 of the Printer Status Register. A logic 0 in this bit means that the printer is busy and cannot accept a new character. A logic 1 means that it is ready to accept the next character.

CONTROL PORT ADDRESS OFFSET = 02H

The Control Port is located at an offset of '02H'

from the base address. The Control Register is initialized by the RESET input, bits 0 to 5 only being affected; bits 6 and 7 are hard wired low.

BIT 0 STROBE - STROBE This bit is inverted and output onto the

nSTROBE output.

BIT 1 AUTOFD - AUTOFEED This bit is inverted and output onto the

nAUTOFD output. A logic 1 causes the printer to generate a line feed after each line is printed. A logic 0 means no autofeed.

Page 89

BIT 2 nINIT - nINITIATE OUTPUT This bit is output onto the nINIT output without

inversion.

BIT 3 SLCTIN - PRINTER SELECT INPUT This bit is inverted and output onto the nSLCTIN

output. A logic 1 on this bit selects the printer; a logic 0 means the printer is not selected.

BIT 4 IRQE - INTERRUPT REQUEST ENABLE The interrupt request enable bit when set to a

high level may be used to enable interrupt requests from the Parallel Port to the CPU. An interrupt request is generated on the IRQ port by a positive going nACK input. When the IRQE bit is programmed low the IRQ is disabled.

BIT 5 PCD - PARALLEL CONTROL

DIRECTION

Parallel Control Direction is not valid in printer

mode. In printer mode, the direction is always out regardless of the state of this bit. In bidirectional, EPP or ECP mode, a logic 0 means that the printer port is in output mode (write); a logic 1 means that the printer port is in input mode (read).

Bits 6 and 7 during a read are a low level, and

cannot be written.

EPP ADDRESS PORT ADDRESS OFFSET = 03H

The EPP Address Port is located at an offset of

'03H' from the base address. The address register is cleared at initialization by RESET. During a WRITE operation, the contents of DB0DB7 are buffered (non inverting) and output onto the PD0 - PD7 ports, the leading edge of nIOW causes an EPP ADDRESS WRITE cycle to be performed, the trailing edge of IOW latches the data for the duration of the EPP write cycle. During a READ operation, PD0 - PD7 ports are read, the leading edge of IOR causes an EPP ADDRESS READ cycle to be performed and the data output to the host CPU, the deassertion of ADDRSTB latches the PData for the duration of

the IOR cycle. This register is only available in EPP mode.

EPP DATA PORT 0 ADDRESS OFFSET = 04H

The EPP Data Port 0 is located at an offset of

'04H' from the base address. The data register is cleared at initialization by RESET. During a WRITE operation, the contents of DB0-DB7 are buffered (non inverting) and output onto the PD0

- PD7 ports, the leading edge of nIOW causes an EPP DATA WRITE cycle to be performed, the trailing edge of IOW latches the data for the duration of the EPP write cycle. During a READ operation, PD0 - PD7 ports are read, the leading edge of IOR causes an EPP READ cycle to be performed and the data output to the host CPU, the deassertion of DATASTB latches the PData for the duration of the IOR cycle. This register is only available in EPP mode.

EPP DATA PORT 1 ADDRESS OFFSET = 05H

The EPP Data Port 1 is located at an offset of

'05H' from the base address. Refer to EPP DATA PORT 0 for a description of operation. This register is only available in EPP mode.

EPP DATA PORT 2 ADDRESS OFFSET = 06H

The EPP Data Port 2 is located at an offset of

'06H' from the base address. Refer to EPP DATA PORT 0 for a description of operation. This register is only available in EPP mode.

EPP DATA PORT 3 ADDRESS OFFSET = 07H

The EPP Data Port 3 is located at an offset of

'07H' from the base address. Refer to EPP DATA PORT 0 for a description of operation. This register is only available in EPP mode.

Page 90

EPP 1.9 OPERATION When the EPP mode is selected in the

configuration register, the standard and bidirectional modes are also available. If no EPP Read, Write or Address cycle is currently executing, then the PDx bus is in the standard or bi-directional mode, and all output signals (STROBE, AUTOFD, INIT) are as set by the SPP Control Port and direction is controlled by PCD of the Control port.

In EPP mode, the system timing is closely

coupled to the EPP timing. For this reason, a watchdog timer is required to prevent system lockup. The timer indicates if more than 10usec have elapsed from the start of the EPP cycle (nIOR or nIOW asserted) to nWAIT being deasserted (after command). If a time-out occurs, the current EPP cycle is aborted and the time-out condition is indicated in Status bit 0.

During an EPP cycle, if STROBE is active, it

overrides the EPP write signal forcing the PDx bus to always be in a write mode and the nWRITE signal to always be asserted.

Software Constraints Before an EPP cycle is executed, the software

must ensure that the control register bit PCD is a logic "0" (ie a 04H or 05H should be written to the Control port). If the user leaves PCD as a logic "1", and attempts to perform an EPP write, the chip is unable to perform the write (because PCD is a logic "1") and will appear to perform an EPP read on the parallel bus, no error is indicated.

EPP 1.9 Write The timing for a write operation (address or

data) is shown in timing diagram EPP Write Data or Address cycle. IOCHRDY is driven active low at the start of each EPP write and is released when it has been determined that the

write cycle can complete. The write cycle can complete under the following circumstances:

1. If the EPP bus is not ready (nWAIT is active

low) when nDATASTB or nADDRSTB goes active then the write can complete when nWAIT goes inactive high.

2. If the EPP bus is ready (nWAIT is inactive

high) then the chip must wait for it to go active low before changing the state of nDATASTB, nWRITE or nADDRSTB. The write can complete once nWAIT is determined inactive.

Write Sequence of operation

1. The host selects an EPP register, places

data on the SData bus and drives nIOW active.

2. The chip drives IOCHRDY inactive (low).

3. If WAIT is not asserted, the chip must wait

until WAIT is asserted.

4. The chip places address or data on PData

bus, clears PDIR, and asserts nWRITE.

5. Chip asserts nDATASTB or nADDRSTRB

indicating that PData bus contains valid information, and the WRITE signal is valid.

6. Peripheral deasserts nWAIT, indicating that

any setup requirements have been satisfied and the chip may begin the termination phase of the cycle.

7. a) The chip deasserts nDATASTB or

nADDRSTRB, this marks the beginning of the termination phase. If it has not already done so, the peripheral should latch the information byte now.

b) The chip latches the data from the

SData bus for the PData bus and asserts (releases) IOCHRDY allowing the host to complete the write cycle.

8. Peripheral asserts nWAIT, indicating to the

host that any hold time requirements have been satisfied and acknowledging the termination of the cycle.

9. Chip may modify nWRITE and nPDATA in

preparation for the next cycle.

Page 91

EPP 1.9 Read The timing for a read operation (data) is shown

in timing diagram EPP Read Data cycle. IOCHRDY is driven active low at the start of each EPP read and is released when it has been determined that the read cycle can complete. The read cycle can complete under the following circumstances:

1 If the EPP bus is not ready (nWAIT is active

low) when nDATASTB goes active then the read can complete when nWAIT goes inactive high.

2. If the EPP bus is ready (nWAIT is inactive

high) then the chip must wait for it to go active low before changing the state of WRITE or before nDATASTB goes active. The read can complete once nWAIT is determined inactive.

Read Sequence of Operation

1. The host selects an EPP register and drives

nIOR active.

2. The chip drives IOCHRDY inactive (low).

3. If WAIT is not asserted, the chip must wait

until WAIT is asserted.

4. The chip tri-states the PData bus and

deasserts nWRITE.

5. Chip asserts nDATASTB or nADDRSTRB

indicating that PData bus is tri-stated, PDIR is set and the nWRITE signal is valid.

6. Peripheral drives PData bus valid.

7. Peripheral deasserts nWAIT, indicating that

PData is valid and the chip may begin the termination phase of the cycle.

8. a) The chip latches the data from the

PData bus for the SData bus and deasserts nDATASTB or nADDRSTRB. This marks the beginning of the termination phase.

b) The chip drives the valid data onto the

SData bus and asserts (releases) IOCHRDY allowing the host to complete the read cycle.

9. Peripheral tri-states the PData bus and

asserts nWAIT, indicating to the host that the PData bus is tri-stated.

10. Chip may modify nWRITE, PDIR and

nPDATA in preparation for the next cycle.

EPP 1.7 OPERATION When the EPP 1.7 mode is selected in the

In EPP mode, the system timing is closely

coupled to the EPP timing. For this reason, a watchdog timer is required to prevent system lockup. The timer indicates if more than 10usec have elapsed from the start of the EPP cycle (nIOR or nIOW asserted) to the end of the cycle nIOR or nIOW deasserted). If a time-out occurs, the current EPP cycle is aborted and the time-out condition is indicated in Status bit 0.

Software Constraints Before an EPP cycle is executed, the software

must ensure that the control register bits D0, D1 and D3 are set to zero. Also, bit D5 (PCD) is a logic "0" for an EPP write or a logic "1" for and EPP read.

EPP 1.7 Write The timing for a write operation (address or

data) is shown in timing diagram EPP 1.7 Write Data or Address cycle. IOCHRDY is driven active low when nWAIT is active low during the EPP cycle. This can be used to extend the cycle time. The write cycle can complete when nWAIT is inactive high.

Page 92

Write Sequence of Operation

1. The host sets PDIR bit in the control

2. The host selects an EPP register, places

data on the SData bus and drives nIOW active.

3. The chip places address or data on PData

bus.

4. Chip asserts nDATASTB or nADDRSTRB

indicating that PData bus contains valid information, and the WRITE signal is valid.

5. If nWAIT is asserted, IOCHRDY is

deasserted until the peripheral deasserts nWAIT or a time-out occurs.

6. When the host deasserts nIOW the chip

deasserts nDATASTB or nADDRSTRB and latches the data from the SData bus for the PData bus.

7. Chip may modify nWRITE, PDIR and

nPDATA in preparation of the next cycle.

EPP 1.7 Read The timing for a read operation (data) is shown

in timing diagram EPP 1.7 Read Data cycle.

IOCHRDY is driven active low when nWAIT is

active low during the EPP cycle. This can be used to extend the cycle time. The read cycle can complete when nWAIT is inactive high.

Read Sequence of Operation

1. The host sets PDIR bit in the control

2. The host selects an EPP register and drives

nIOR active.

3. Chip asserts nDATASTB or nADDRSTRB

indicating that PData bus is tri-stated, PDIR is set and the nWRITE signal is valid.

4. If nWAIT is asserted, IOCHRDY is

deasserted until the peripheral deasserts nWAIT or a time-out occurs.

5. The Peripheral drives PData bus valid.

6. The Peripheral deasserts nWAIT, indicating

that PData is valid and the chip may begin the termination phase of the cycle.

7. When the host deasserts nIOR the chip

deasserts nDATASTB or nADDRSTRB.

8. Peripheral tri-states the PData bus.

9. Chip may modify nWRITE, PDIR and

nPDATA in preparation of the next cycle.

Page 93

TABLE 39 - EPP PIN DESCRIPTIONS

EPP

SIGNAL

EPP NAME TYPE

EPP DESCRIPTION nWRITE nWrite O This signal is active low. It denotes a write operation. PD<0:7> Address/Data I/O Bi-directional EPP byte wide address and data bus. INTR Interrupt I This signal is active high and positive edge triggered. (Pass

through with no inversion, Same as SPP).

WAIT nWait I This signal is active low. It is driven inactive as a positive

acknowledgement from the device that the transfer of data is completed. It is driven active as an indication that the device is ready for the next transfer.

DATASTB nData Strobe O This signal is active low. It is used to denote data read or

write operation.

RESET nReset O This signal is active low. When driven active, the EPP

device is reset to its initial operational mode.

ADDRSTB nAddress

Strobe

O This signal is active low. It is used to denote address read

or write operation.

PE Paper End I Same as SPP mode. SLCT Printer

Selected Status

I Same as SPP mode.

nERR Error I Same as SPP mode. PDIR Parallel Port

Direction

O This output shows the direction of the data transfer on the

parallel port bus. A low means an output/write condition and a high means an input/read condition. This signal is normally a low (output/write) unless PCD of the control register is set or if an EPP read cycle is in progress.

Note 1: SPP and EPP can use 1 common register. Note 2: nWrite is the only EPP output that can be over-ridden by SPP control port during an EPP

cycle. For correct EPP read cycles, PCD is required to be a low.

Page 94

EXTENDED CAPABILITIES PARALLEL PORT

ECP provides a number of advantages, some of

which are listed below. The individual features are explained in greater detail in the remainder of this section.

• High performance half-duplex forward and reverse channel

• Interlocked handshake, for fast reliable transfer

• Optional single byte RLE compression for improved throughput (64:1)

• Channel addressing for low-cost peripherals

• Maintains link and data layer separation

• Permits the use of active output drivers

• Permits the use of adaptive signal timing

• Peer-to-peer capability

Vocabulary The following terms are used in this document:

assert: When a signal asserts it transitions to a

"true" state, when a signal deasserts it transitions to a "false" state.

forward: Host to Peripheral communication. reverse: Peripheral to Host communication

Pword: A port word; equal in size to the width

of the ISA interface. For this implementation, PWord is always 8 bits.

1 A high level. 0 A low level.

These terms may be considered synonymous:

• PeriphClk, nAck

• HostAck, nAutoFd

• PeriphAck, Busy

• nPeriphRequest, nFault

• nReverseRequest, nInit

• nAckReverse, PError

• Xflag, Select

• ECPMode, nSelectln

• HostClk, nStrobe

Reference Document: IEEE 1284 Extended

Capabilities Port Protocol and ISA Interface Standard, Rev 1.14, July 14, 1993. This document is available from Microsoft.

The bit map of the Extended Parallel Port

registers is:

D7 D6 D5 D4 D3 D2 D1 D0 Note data PD7 PD6 PD5 PD4 PD3 PD2 PD1 PD0 ecpAFifo Addr/RLE Address or RLE field 2 dsr nBusy nAck PError Select nFault 0 0 0 1 dcr 0 0 Direction ackIntEn SelectIn nInit autofd strobe 1 cFifo Parallel Port Data FIFO 2 ecpDFifo ECP Data FIFO 2 tFifo Test FIFO 2 cnfgA 0 0 0 1 0 0 0 0 cnfgB compress intrValue Parallel Port IRQ Parallel Port DMA ecr MODE nErrIntrEn dmaEn serviceIntr full empty

Note 1: These registers are available in all modes. Note 2: All FIFOs use one common 16 byte FIFO. Note 3: The ECP Parallel Port Config Reg B reflects the IRQ and DRQ selected by the Configuration

Registers.

Page 95

ISA IMPLEMENTATION STANDARD This specification describes the standard ISA

interface to the Extended Capabilities Port (ECP). All ISA devices supporting ECP must meet the requirements contained in this section or the port will not be supported by Microsoft. For a description of the ECP Protocol, please refer to the IEEE 1284 Extended Capabilities Port Protocol and ISA Interface Standard, Rev.

1.14, July 14, 1993. This document is available

from Microsoft.

Description The port is software and hardware compatible

with existing parallel ports so that it may be used as a standard LPT port if ECP is not required. The port is designed to be simple and requires a small number of gates to implement. It does not do any "protocol" negotiation, rather

it provides an automatic high burst-bandwidth channel that supports DMA for ECP in both the forward and reverse directions.

Small FIFOs are employed in both forward and

reverse directions to smooth data flow and improve the maximum bandwidth requirement. The size of the FIFO is 16 bytes deep. The port supports an automatic handshake for the standard parallel port to improve compatibility mode transfer speed.

The port also supports run length encoded

(RLE) decompression (required) in hardware. Compression is accomplished by counting identical bytes and transmitting an RLE byte that indicates how many times the next byte is to be repeated. Decompression simply intercepts the RLE byte and repeats the following byte the specified number of times. Hardware support for compression is optional.

Page 96

TABLE 40 - ECP PIN DESCRIPTIONS

NAME TYPE DESCRIPTION

nStrobe O During write operations nStrobe registers data or address into the slave

on the asserting edge (handshakes with Busy).

PData 7:0 I/O Contains address or data or RLE data. nAck I Indicates valid data driven by the peripheral when asserted. This signal

handshakes with nAutoFd in reverse.

PeriphAck (Busy) I This signal deasserts to indicate that the peripheral can accept data.

This signal handshakes with nStrobe in the forward direction. In the reverse direction this signal indicates whether the data lines contain ECP command information or data. The peripheral uses this signal to flow control in the forward direction. It is an "interlocked" handshake with nStrobe. PeriphAck also provides command information in the reverse direction.

PError (nAckReverse)

I Used to acknowledge a change in the direction the transfer (asserted =

forward). The peripheral drives this signal low to acknowledge nReverseRequest. It is an "interlocked" handshake with nReverseRequest. The host relies upon nAckReverse to determine when it is permitted to drive the data bus.

Select I Indicates printer on line. nAutoFd

(HostAck)

nFault (nPeriphRequest)

O Requests a byte of data from the peripheral when asserted,

handshaking with nAck in the reverse direction. In the forward direction this signal indicates whether the data lines contain ECP address or data. The host drives this signal to flow control in the reverse direction. It is an "interlocked" handshake with nAck. HostAck also provides command information in the forward phase.

I Generates an error interrupt when asserted. This signal provides a

mechanism for peer-to-peer communication. This signal is valid only in the forward direction. During ECP Mode the peripheral is permitted (but not required) to drive this pin low to request a reverse transfer. The request is merely a "hint" to the host; the host has ultimate control over the transfer direction. This signal would be typically used to generate an interrupt to the host CPU.

nInit O Sets the transfer direction (asserted = reverse, deasserted = forward).

This pin is driven low to place the channel in the reverse direction. The peripheral is only allowed to drive the bi-directional data bus while in ECP Mode and HostAck is low and nSelectIn is high.

nSelectIn O Always deasserted in ECP mode.

Page 97

standard IBM addresses for LPT. All of the standard printer ports are supported. The additional registers attach to an upper bit decode of the standard LPT port definition to

avoid conflict with standard ISA devices. The port is equivalent to a generic parallel port interface and may be operated in that mode. The port registers vary depending on the mode field in the ecr. The table below lists these dependencies. Operation of the devices in modes other that those specified is undefined.

TABLE 41 - ECP REGISTER DEFINITIONS

NAME ADDRESS (Note 1) ECP MODES FUNCTION data +000h R/W 000-001 Data Register ecpAFifo +000h R/W 011 ECP FIFO (Address) dsr +001h R/W All Status Register dcr +002h R/W All Control Register cFifo +400h R/W 010 Parallel Port Data FIFO ecpDFifo +400h R/W 011 ECP FIFO (DATA) tFifo +400h R/W 110 Test FIFO cnfgA +400h R 111 Configuration Register A cnfgB +401h R/W 111 Configuration Register B ecr +402h R/W All Extended Control Register

Note 1: These addresses are added to the parallel port base address as selected by configuration

Note 2: All addresses are qualified with AEN. Refer to the AEN pin definition.

TABLE 42 - MODE DESCRIPTIONS

MODE DESCRIPTION*

000 SPP mode 001 PS/2 Parallel Port mode 010 Parallel Port Data FIFO mode 011 ECP Parallel Port mode 100 EPP mode (If this option is enabled in the configuration registers) 101 Reserved 110 Test mode 111 Configuration mode

*Refer to ECR Register Description

Page 98

DATA and ecpAFifo PORT ADDRESS OFFSET = 00H

Modes 000 and 001 (Data Port) The Data Port is located at an offset of '00H'

from the base address. The data register is cleared at initialization by RESET. During a WRITE operation, the Data Register latches the contents of the data bus on the rising edge of the nIOW input. The contents of this register are buffered (non inverting) and output onto the PD0 - PD7 ports. During a READ operation, PD0 - PD7 ports are read and output to the host CPU.

Mode 011 (ECP FIFO - Address/RLE) A data byte written to this address is placed in

the FIFO and tagged as an ECP Address/RLE. The hardware at the ECP port transmits this byte to the peripheral automatically. The operation of this register is ony defined for the forward direction (direction is 0). Refer to the ECP Parallel Port Forward Timing Diagram, located in the Timing Diagrams section of this data sheet .

DEVICE STATUS REGISTER (dsr) ADDRESS OFFSET = 01H

The Status Port is located at an offset of '01H'

from the base address. Bits 0 - 2 are not implemented as register bits, during a read of the Printer Status Register these bits are a low level. The bits of the Status Port are defined as follows:

BIT 3 nFault The level on the nFault input is read by the CPU

as bit 3 of the Device Status Register.

BIT 4 Select The level on the Select input is read by the CPU

as bit 4 of the Device Status Register.

BIT 5 PError The level on the PError input is read by the CPU

as bit 5 of the Device Status Register. Printer Status Register.

BIT 6 nAck The level on the nAck input is read by the CPU

as bit 6 of the Device Status Register.

BIT 7 nBusy The complement of the level on the BUSY input

is read by the CPU as bit 7 of the Device Status Register.

DEVICE CONTROL REGISTER (dcr) ADDRESS OFFSET = 02H

The Control Register is located at an offset of

'02H' from the base address. The Control Register is initialized to zero by the RESET input, bits 0 to 5 only being affected; bits 6 and 7 are hard wired low.

BIT 0 STROBE - STROBE This bit is inverted and output onto the

nSTROBE output.

BIT 1 AUTOFD - AUTOFEED This bit is inverted and output onto the

nAUTOFD output. A logic 1 causes the printer to generate a line feed after each line is printed. A logic 0 means no autofeed.

BIT 2 nINIT - nINITIATE OUTPUT This bit is output onto the nINIT output without

inversion.

BIT 3 SELECTIN This bit is inverted and output onto the nSLCTIN

output. A logic 1 on this bit selects the printer; a logic 0 means the printer is not selected.

BIT 4 ackIntEn - INTERRUPT REQUEST

ENABLE

The interrupt request enable bit when set to a

high level may be used to enable interrupt requests from the Parallel Port to the CPU due to a low to high transition on the nACK input. Refer to the description of the interrupt under Operation, Interrupts.

BIT 5 DIRECTION If mode=000 or mode=010, this bit has no effect

and the direction is always out regardless of the state of this bit. In all other modes, Direction is valid and a logic 0 means that the printer port is in output mode (write); a logic 1 means that the printer port is in input mode (read).

Page 99

BITS 6 and 7 during a read are a low level, and

cannot be written.

cFifo (Parallel Port Data FIFO) ADDRESS OFFSET = 400h Mode = 010

Bytes written or DMAed from the system to this

FIFO are transmitted by a hardware handshake to the peripheral using the standard parallel port protocol. Transfers to the FIFO are byte aligned. This mode is only defined for the forward direction.

ecpDFifo (ECP Data FIFO) ADDRESS OFFSET = 400H Mode = 011

Bytes written or DMAed from the system to this

FIFO, when the direction bit is 0, are transmitted by a hardware handshake to the peripheral using the ECP parallel port protocol. Transfers to the FIFO are byte aligned.

Data bytes from the peripheral are read under

automatic hardware handshake from ECP into this FIFO when the direction bit is 1. Reads or DMAs from the FIFO will return bytes of ECP data to the system.

tFifo (Test FIFO Mode) ADDRESS OFFSET = 400H Mode = 110

Data bytes may be read, written or DMAed to or

from the system to this FIFO in any direction. Data in the tFIFO will not be transmitted to the to the parallel port lines using a hardware protocol handshake. However, data in the tFIFO may be displayed on the parallel port data lines.

The tFIFO will not stall when overwritten or

underrun. If an attempt is made to write data to a full tFIFO, the new data is not accepted into the tFIFO. If an attempt is made to read data from an empty tFIFO, the last data byte is re-

read again. The full and empty bits must always keep track of the correct FIFO state. The tFIFO will transfer data at the maximum ISA rate so that software may generate performance metrics.

The FIFO size and interrupt threshold can be

determined by writing bytes to the FIFO and checking the full and serviceIntr bits.

The writeIntrThreshold can be determined by

starting with a full tFIFO, setting the direction bit to 0 and emptying it a byte at a time until serviceIntr is set. This may generate a spurious interrupt, but will indicate that the threshold has been reached.

The readIntrThreshold can be determined by

setting the direction bit to 1 and filling the empty tFIFO a byte at a time until serviceIntr is set. This may generate a spurious interrupt, but will indicate that the threshold has been reached.

Data bytes are always read from the head of

tFIFO regardless of the value of the direction bit. For example if 44h, 33h, 22h is written to the FIFO, then reading the tFIFO will return 44h, 33h, 22h in the same order as was written.

cnfgA (Configuration Register A) ADDRESS OFFSET = 400H Mode = 111

This register is a read only register. When read,

10H is returned. This indicates to the system that this is an 8-bit implementation. (PWord = 1 byte)

cnfgB (Configuration Register B) ADDRESS OFFSET = 401H Mode = 111

BIT 7 compress This bit is read only. During a read it is a low

level. This means that this chip does not support hardware RLE compression. It does support hardware de-compression!

Page 100

BIT 6 intrValue Returns the value on the ISA IRq line to

determine possible conflicts.

BITS [5:3] Parallel Port IRQ (read-only) Refer to Table 39B. BITS [2:0] Parallel Port DMA (read-only) Refer to Table 39C.

ecr (Extended Control Register) ADDRESS OFFSET = 402H Mode = all This register controls the extended ECP parallel

port functions.

BITS 7,6,5 These bits are Read/Write and select the Mode. BIT 4 nErrIntrEn Read/Write (Valid only in ECP Mode) 1: Disables the interrupt generated on the

asserting edge of nFault.

0: Enables an interrupt pulse on the high to

low edge of nFault. Note that an interrupt will be generated if nFault is asserted (interrupting) and this bit is written from a 1 to a 0. This prevents interrupts from being lost in the time between the read of the ecr and the write of the ecr.

BIT 3 dmaEn Read/Write 1: Enables DMA (DMA starts when serviceIntr

is 0).

0: Disables DMA unconditionally.

BIT 2 serviceIntr Read/Write 1: Disables DMA and all of the service

interrupts.

0: Enables one of the following 3 cases of

interrupts. Once one of the 3 service interrupts has occurred serviceIntr bit shall be set to a 1 by hardware. It must be reset to 0 to re-enable the interrupts. Writing this bit to a 1 will not cause an interrupt.

case dmaEn=1: During DMA (this bit is set to a 1 when

terminal count is reached).

case dmaEn=0 direction=0: This bit shall be set to 1 whenever there are

writeIntrThreshold or more bytes free in the FIFO.

case dmaEn=0 direction=1: This bit shall be set to 1 whenever there are

readIntrThreshold or more valid bytes to be read from the FIFO.

BIT 1 full Read only 1: The FIFO cannot accept another byte or the

FIFO is completely full.

0: The FIFO has at least 1 free byte. BIT 0 empty Read only 1: The FIFO is completely empty. 0: The FIFO contains at least 1 byte of data.

100

Datasheet FDC37B72X Datasheet (Standard Microsystems Corporation)

Specifications and Main Features

Frequently Asked Questions

User Manual
