ESS Technology, Inc. SAM0355-061201 1

ESS Technology, Inc.

ES1992 Canyon3D2 PCI Audio Accelerator

Product Brief

DESCRIPTION

The ES1992 Canyon3D™2 PCI audio accelerator combines advanced audio functionality in a highly integrated single-chip PCI solution for advanced multichannel PC audio. With key features including hardware acceleration, 3D audio support, digital output capability, and integrated quad DAC AC‘97 codec, the Canyon3D-2 will engulf the user in a 3D world of sound when used with general applications, digital music, or games.

The ES1992 combines the advantages of a highbandwidth PCI bus interface, proven Canyon3D digital signal processing (DSP) hardware architecture, five-band speaker equalization (EQ), high-fidelity quad DAC AC‘97 codec into a single-chip package with an external AC-link for additional future functionality (i.e., 6-speaker, 5.1 channel output). A Sony/Philips digital interface (S/PDIF) output provides for digital output of multichannel AC-3 content. The result is robust PC audio functionality, which features digital mixing, sample rate conversion, realtime

effects processing, multistream DirectSound



hardware acceleration, and head-related transfer function (HRTF) filtering.

The 3D audio support and HRTF filtering are licensed through Sensaura™ Ltd. HRTF filtering is supported for 2, 4, and 6 speaker outputs, using MultiDrive technology. 3D audio is supported through DirectSound 3D, A3D 1.0, EAX 1.0, EAX 2.0, and I3DL2 advanced programming interfaces (APIs). Additional 3D audio enhancements are available through MacroFX, EnvironmentalFX, and ZoomFX.

The ES1992 meets PC99/PC2001 and Microsoft WHQL specifications. Device drivers for the ES1992 are optimized for use on the Microsoft Windows operating systems and are designed specifically to take advantage of new features available through Microsoft’s DirectX 8.

Operating at 3.3V digital and 5.0V analog, the ES1992 is compliant with the Advanced Power Management (APM)

1.2, Advanced Configuration and Power Interface (ACPI)

2.0, and PCI Power Management Interface (PPMI) 1.1 specifications.

The ES1992 Canyon3D-2 is available in an industrystandard 100-pin low-profile quad flat pack (LQFP) package.

FEATURES

• High-performance single-chip PCI audio acceleration

• Four-speaker analog output

• S/PDIF digital output

• Integrated high-fidelity AC‘97 codec

• High-quality sample rate conversion and digital mixing

• External AC-Link interface for 6-speaker, 5.1 channel

support

• Multistream DirectSound

3D hardware acceleration

• Sensaura 3D positional audio

• Realtime effects processing

• Full-legacy DOS game support, using TDMA, PC/PCI, or

DDMA hardware implementation methods

• Five-band hardware equalization

POWER MANAGEMENT

•

Compliance with APM 1.2, ACPI 2.0, and PPMI 1.1

• 3.3-volt digital operation with 5V-tolerant inputs

• 5.0-volt analog operation

COMPATIBILITY

•

Supports PC DOS games and applications for SoundBlaster and SoundBlaster Pro

• Supports Microsoft Windows DirectSound

• Meets PC99/PC2001 and Windows Hardware Quality

Laboratory (WHQL) specifications

• Supports A3D 1.0, EAX 1.0, EAX 2.0, and I3DL2 APIs

Page 2

2 SAM0355-061201 ESS Technology, Inc.

ES1992 PRODUCT BRIEF

BLOCK DIAGRAM

Figure 1 shows the ES1992 Canyon3D-2 device block diagram.

Figure 1 ES1992 Canyon3D-2 Block Diagram.

PINOUT

Figure 2 shows the ES1992 Canyon3D-2 pinout diagram.

Figure 2 ES1992 Canyon3D-2 Pinout Diagram

Integrated

System

DRAM

Chipset CPU

3.3V PCI master

SB Pro legacy

audio

TDMA

HRTF 3D positional

audio

Sample Rate

Converter and Mixer

Game port

ACPI 1.0 PPMI 1.0

PCI BUS

RING BUS

Mic in CD audio Line out (front)

APM 1.2

Secondary

EEPROM

SID/SVID customization

Audio CODEC

interface

PC/PCI

DDMA

Effects

Processing

ASSP

AC-Link

MPU-401

MIDI device

Joystick

S/PDIF

Digital audio output

output

Line out (surround)

Phone

Line in

6-Speaker, 5.1 channel support

EAPD GD7/GPIO15

GD6/GPIO14 GD5/GPIO13 GD4

GD3/ECLK GD2/EDIN GD1/EDOUT GD0

ECS

GND

AD0 AD1 AD2 AD3 AD4 AD5 AD6 AD7

LINE_OUT_R

RXD

TXD

RST#

INT#

GND

PCICLK

VCC

GNT#

REQ#

AD31 AD30 AD29 AD28 AD27 AD26 AD25 AD24

OSCO

PC GN T#/ GP IO1 2

LI NE_ OU T_R-L

LI NE_ OU T_R-R

PC _BEEP

PH ONE

CD _L

CD _GN D

CD _R

MI C

LI NE_ IN_L

LI NE_ IN_R

AV DD1

AV SS 1

VR EF

AF ILT1

AFILT2

CAP1 CAP2

LINE_OUT_L

PC REQ#/ GP IO7

SP DIFO

VC C

SD I2/ GP IO8

OSCI

SR ES ET2#

SD FS2/G PI O9

SC LK2/G PI O10

SD O2 /GP IO 11

ES1992S

PA R

ST OP#

DE VS EL#

TR DY#

IR DY#

FR AME#

C/ BE2#

VC C

AD 16

AD 17

AD 18

AD 19

AD 20

AD 21

AD 22

AD 23

GN D

IDSEL

C/ BE3#

C/BE0# AD8

AD9 AD10 AD11

AD 12

AD 13

AD 14

AD 15

C/B E1#

2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

75 5174 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52

100

100-Pin LQFP

GND

MONO_OUT

VCC

AVSS2

AVDD2

Page 3

ESS Technology, Inc. SAM0355-061201 3

ES1992 PRODUCT BRIEF

ES1992 PIN DESCRIPTIONS

Table 1 lists the ES1992 pin descriptions. Table 1 ES1992 Pin Descriptions

Names Pin Numbers I/O Descriptions

C/BE[3:0]#

1, 13, 20, 30

I/O PCI command/byte enable. During address phase of a transaction, these pins define the bus

command. During data phase, these pins define the byte enable. IDSEL 2 I ID Select. GND 3, 21, 40, 89 I Digital ground. AD[31:0] 4:11, 22:29,

31:38, 93:100

I/O Address and data lines from the PCI bus.

VCC 12, 41, 53, 90 I Digital supply voltage, 3.3V FRAME# 14 I/O Cycle frame. IRDY# 15 I/O Initiator ready. TRDY# 16 I/O Target ready. DEVSEL# 17 I/O Device select. STOP# 18 I/O Stop transaction. PAR 19 I/O Parity. ECS 39 O EEPROM chip select. Connects to EEPROM chip select input pin. ECS is active after power-

on reset and goes inactive automatically after EEPROM cycle is complete. GD[0] 42 I/O Game port data input/output. GD[1]

I/O Game port data input/output.

EDOUT O EEPROM data output. Connects to EEPROM data input. EDOUT goes active after power-on

reset and goes inactive automatically after EEPROM cycle is complete. GD[2]

I/O Game port data input/output.

EDIN I EEPROM data input. Connects to EEPROM data output. EDIN goes active after power-on

reset and goes inactive automatically after EEPROM cycle is complete. GD[3]

I/O Game port data input/output.

ECLK O EEPROM clock. Connects to EEPROM clock input. ECLK goes active after power-on reset

and goes inactive automatically after EEPROM cycle is complete. GD[4] 46 I Game port data input. GD[5:7]

47:49

I Game port data input. GPIO[15:13] I/O General-purpose input/output. EAPD 50 I/O External amplifier power down (active low). PCREQ#

O PC/PCI request output. Enable PCREQ# by setting PCI 50h [10:8]. GPIO7 I/O General-purpose input/output. SPDIFO 52 O S/PDIF output. Enable SPDIFO by setting PCI 53h [0]. SDI2

I External AC-link serial data input. Select external codec by enabling Canyon_Base+38h [5]. GPIO8 I/O General-purpose input/output. OSCI 55 I 49.152-MHz crystal input. OSCO 56 O 49.152-MHz crystal output. SRESET2# 57 I Reset output for AC-link interface. Select external codec by enabling Canyon_Base+38h [5]. SDFS2

O Serial data frame sync output for AC-link interface. Select external codec by enabling

Canyon_Base+38h [5].

GPIO9 I/O General-purpose input/output.

Page 4

ES1992 PRODUCT BRIEF

No part of this publication may be reproduced, stored in a retrieval system, transmitted, or translated in any form or by any means, electronic, mechanical, manual, optical, or otherwise, without the prior written permission of ESS Technology, Inc.

ESS Technology, Inc. makes no representations or warranties regarding the content of this document.

All specifications are subject to change without prior notice.

ESS Technology, Inc. assumes no responsibility for any errors contained herein.

U.S. patent pending. Canyon3D is a trademark of ESS Technology, Inc. All other trademarks are owned by their respective

holders and are used for identification purposes only.

ESS Technology, Inc. 48401 Fremont Blvd. Fremont, CA 94538 Tel: (510) 492-1088 Fax: (510) 492-1898

SCLK2

O Serial clock for AC-link interface. Select external codec by enabling Canyon_Base+38h [5]. GPIO10 I/O General-purpose input/output. SDO2

O External AC-link serial data output. Select external codec by enabling Canyon_Base+38h [5]. GPIO11 I/O General-purpose input/output. PCGNT

I PC/PCI grant input. Enable PC/PCI by setting PCI 50h [10:8]. GPIO12 I/O General-purpose input/output. LINE_OUT_R-L 62 O Line output: surround, left channel. LINE_OUT_R-R 63 O Line output: surround, right channel. PC_BEEP 64 I PC Speaker input. PHONE 65 I Mono input. CD_L 66 I CD-audio input: left channel. CD_GND 67 I CD-audio input: ground. CD_R 68 I CD-audio input: right channel. MIC 69 I Microphone input. LINE_IN_L 70 I Line input: left channel. LINE_IN_R 71 I Line input: right channel. AVDD[2:1] 72, 83 I Analog supply voltage, 5V. AVSS[2:1] 73, 82 I Analog ground. VREF 74 O Reference voltage. AFILT[2:1] 75, 76 O Anti-aliasing filter cap for the ADC channel. CAP[2:1] 77, 78 O ADC and DAC reference caps. LINE_OUT_L 79 O Line output: front, left channel. LINE_OUT_R 80 O Line output: front, right channel. MONO_OUT 81 O Mono output. RXD 84 I MIDI receive data input. Enable MIDI I/O (MPU-401 I/O) by setting PCI 40h [3]. TXD 85 O MIDI transmit data output. Enable MIDI I/O (MPU-401 I/O) by setting PCI 40h [3]. RST# 86 I PCI reset input. INT# 87 O Interrupt request output. PCICLK 88 I PCI bus clock input. GNT# 91 I Bus master grant input. REQ# 92 O Bus master request output.

Part Number Description Package

ES1992S PCI Audio Accelerator 100-pin LQFP

Table 1 ES1992 Pin Descriptions (Continued)

Names Pin Numbers I/O Descriptions
