ISSUED
12/27/13
TYPE
AEHH8N
PERFORMANCE DATA
3-PHASE INDUCTION MOTOR
NAMEPLATE INFORMATION
OUTPUT
HP KW
300 224 60
POLE
6
FRAME
SIZE
449T
VOLTAGE
460
TYPICAL PERFORMANCE
FULL
LOAD
RPM
FULL LOAD
MIN. % NOM. %
EFFICIENCY
3/4 LOAD
1/2 LOAD
%
90 95.8 95.4 94.5
HZ
RATED
AMBIENT
40oC
%
INS.
CLASS
F
POWER FACTOR
F. L.
%
3/4 LOAD%1/2 LOAD
84.5
ENCLOSURE
CATALOG#
NEMA
DESIGN
B
%
82 74.5
TEFC
EP3006
TIME
RATING
CONT.
POWER FACTOR
CORRECTION
SERVICE
FACTOR
1.15
MAXIMUM
KVAR851188
CURRENTS
NO LOAD FULL LOAD
107 347
TORQUE
FULL LOAD
lb-ft
LOCKED
ROTOR
%FLT
PULL
UP
%FLT
1325 110 90
SAFE STALL
TIME IN
SECONDS
COLD HOT
ALLOWABLE
STARTS
PER HOUR
COLD
23 17
APPROVED: REVISION
M. PRATER
LOCKED ROTOR
2200
BREAK
DOWN
%FLT
ROTOR
WR
lb-ft
162
SOUND
PRESSURE
LEVEL @ 3 FT
HOT
DRAWING NO.
2
2
dB(A)
852 1
NEMA KVA
CODE LETTER
G
INERTIA
NEMA
LOAD
WK
lb-ft
ALLOWABLE
2
2
3239
3A057EP3006
MAX
WK
lb-ft
7166
ACCEL TIME
NEMA
2
2
LOAD
WK
Sec
ALLOWABLE
2
6.25210 13.47
MAX
WK
Sec
2
1
