Datasheet ECL06B03 Datasheet (NIHON)



SBD Type : EEEECL06B03

FEATURES

* TO-251AA Case
* Dual Diodes Cathode Common
* Extremely Low Forward Voltage drop
* Low Power Loss,High Efficiency
* High Surge Capability

CL06B03

CL06B03CL06B03

OUTLINE DRAWING

Maximum Ratings Approx Net Weight:0.35g

Rating

Repetitive Peak Reverse Voltage V
Average Rectified Output Current IO 6.0
RMS Forward Current I
Surge Forward Current I
Operating JunctionTemperature Range

Storage Temperature Range

Symbol ECL06B03 Unit

RRM

Tc=70°C

6.66 A

F(RMS)

45

FSM

Tjw - 40 to + 100

Tstg - 40 to + 125

50Hz Full Sine Wave,1cycle,
Non-repetitive

30 V

50Hz Full Sine Wave

Resistive Load

Electrical • Thermal Characteristics

Characteristics Symbol Conditions Min Typ Max Unit

Peak Reverse Current IRM
Peak Forward Voltage VFM
Thermal Resistance Junction to Case Rth(j-c) - - - 5

Tj=25°C,V
Tj=25°C,I

RM=VRRM

= 3 A per Arm

FM

per Arm

- - 3.0 mA

- - 0.47 V

A

A

°C
°C

°C/W





ECL06B03 OUTLINE DRAWING (Dimensions in mm)


