Page 1
3 Pins
D
C
B
A
1 2 3
H
21
G
Unit:mm
RoHS compliant
F
RECOMMEND ED P.C.B. PATTERN LAYOUT
TOP VIEW (TOLERANCE: ±0,05)
RECOMMENDED P.C.B. PATTERN LAYOUT
TOP VIEW (TOLERANCE: ±0,05)
E
6
Angle
TOL
Id.
X.X°
±X°
2 Update
X.°
±1°
3 Change the manufacture plant
DIM
TOL
X.XXX
±0.15
4 Update
X.XX
X.X
±0.25
±0.38
5 Correct the pin out Winnie29.04.2014
6 Add the dimension 4.00
Scale
TOLERANCE
Free
7 Update
5
4 Pins
6
3
RECOMMENDED P.C.B. PATTERN LAYOUT
TOP VIEW (TOLERANCE: ±0,05)
Modification NameDate
5
5 Pins
4
15.07.2009
25.11.2010
Rale
Alex
31.07.2012
Lucas
Approved
03.06.2016
S.Bölling
Winnie08.12.2015
Drawn
RECOMMENDED P.C.B. PATTERN LAYOUT
TOP VIEW (TOLERANCE: ±0,05)
6
5
6 Pins
4
6
5.Environmental
Order Code:
Temperature Range -55°C~+85°C
Shell: Nickel
19.03.2004
08.12.2015
Winnie
65
Replace
Drawing-No.
ASSMANN WSW-No.
Hellwig
Date
Name
Customer-No.
RECOMMENDED P.C.B. PATTERN LAYOUT
TOP VIEW (TOLERANCE: ±0,05)
5
8 Pins
A-DIO-FSxx
Shielded
No. of Contacts
03 / 04 / 05 / 06 / 08
4.Plating:
Contacts:Gold Flash Selective over Nickel
Insulation Resistance [ohms] 1000 Megohms min
Contact Resistance [ohms] 30 milliohms max
3.Electrical:
Current-max[amps] 1.0A
Voltage-max[volts] 30V
Withstanding Voltage 750V AC
Durability: 500 cycles min.
Contacts :Brass
Insulator :PBT+30% G.F. UL 94V-0;Black
Shell :Brass
2.Mechanical:
Mating Force: 45N max.
Withdrawal Force: 7N min.
5 6
1.Material:
ASS 1622 CO
6
A-DIO-FSxx
7
Sheet
rev07
H
G
F
E
D
C
B
A
7
