• COMPATIBLE WITH PWM FREQUENCIES UP TO 50KHZ

• 10V TO 100 V MOTOR SUPPLY

• 10A CONTINUOUS OUTPUT CURRENT

• HCMOS COMPATIBLE SCHMITT TRIGGER LOGIC INPUTS

• SEPARATE SOURCE OUTPUTS FOR NEGATIVE RAIL

CURRENT SENSE

• SLEEP MODE

• WIDE RANGE FOR GATE DRIVE AND LOGIC SUPPLIES

APPLICATIONS

HIGH POWER CIRCUITS FOR DIGITAL CONTROL OF:

• THREE AXIS MOTION USING BRUSH TYPE MOTORS

• THREE PHASE BRUSHLESS DC MOTOR DRIVE

• THREE PHASE AC MOTOR DRIVE

• THREE PHASE STEP MOTOR DRIVE

DESCRIPTION

The EB02 consists of three independent FET half

bridges with drivers. The drivers may be interfaced with CMOS or HCMOS level logic.

FEATURES

HTTP://WWW.APEXMICROTECH.COM (800) 546-APEX (800) 546-2739

MICROTECHNOLOGY

TRIPLE INDEPENDENT LOGIC INTERFACED HALF BRIDGES

EBO2

FIGURE 1. BLOCK DIAGRAM

Half

Bridge

Driver

Half

Bridge

Driver

Half

Bridge

Driver

FET

Half Bridge Output

FET

Half Bridge Output

FET

Half Bridge Output

Hin 1

HV1

OUT1

Lin 1

HVRTN1

Hin 2

HV2

OUT2

HVRTN2

Lin2

HV3

OUT3

HVRTN3

Hin3

Lin 3

V 1

V 2

V 3

,Logic Supply

,Logic Ground

Page 2

APEX MICROTECHNOLOGY CORPORATION • 5980 NORTH SHANNON ROAD • TUCSON, ARIZONA 85741 • USA • APPLICATIONS HOTLINE: 1 (800) 546-2739 2

ABSOLUTE MAXIMUM RATINGS

SPECIFICATIONS

ABSOLUTE MAXIMUM RATINGS

MOTOR VOLTAGE SUPPLY, HV 100V OUTPUT CURRENT, peak 20A OUTPUT CURRENT, continuous1 10A GATE SUPPLY VOLTAGE, Vcc 20V LOGIC SUPPLY VOLTAGE, Vdd 20V POWER DISSIPATION, internal1 51 Watts LOGIC INPUT VOLTAGE -0.3V to Vdd + 0.3V THERMAL RESISTANCE TO CASE3 2.1°C/Watt TEMPERATURE, pin solder, 10s 300°C TEMPERATURE, junction2 150°C TEMPERATURE RANGE, storage –55 to +150°C OPERATING TEMPERATURE, case –25 to +85°C

EB02

SPECIFICATIONS

PARAMETER TEST CONDITIONS MIN TYP MAX UNITS

POSITIVE OUTPUT VOLTAGE I

OUT

=10A; Vcc=10.8V , Vdd=5V; 99.2 101.5 Volts HV=100V, Fpwm=50kHz, L=100 µH NEGATIVE OUTPUT VOLTAGE " -1.5 .8 Volts POSITIVE EDGE DELAY " 260 n-second RISETIME " 50 n-second NEGATIVE EDGE DELAY " 310 n-second FALLTIME " 5 0 n-second PWM FREQUENCY Set by external circuitry 50 kHz INPUT IMPEDANCE Set by internal resistors 50 k-ohm

INPUT

A logic level input independently controls each FET in the half bridge. A logic level high turns on the FET and low turns it off. A common shut down input turns off all FETs when high.

All inputs are Schmitt triggers with the upper threshold at 2/3 V

and the lower threshold at 1/3 Vdd. This comfortably interfaces with CMOS or HCMOS provided that the Vdd for the logic family and the EB02 are the same.

TTL families may be used if a pull-up to Vcc is added to the TTL gates driving the EB02, and Vdd for the EB02 is the same supply as V

for the TTL family.

An open signal connector pulls the shut down input high and all other inputs low, insuring that all outputs are off.

However, input impedance is 50k on all inputs; therefore, if one input is open circuited a high radiated noise level could spuriously turn on a FET.

OUTPUT

Each output section consists of a switching mode FET half bridge. Separate HV supply, emitter, and HV return lines are provided for each section.

The FETs are conservatively rated to carry 10A. At 10A the saturation voltage is 1.5 V maximum, over the full environmental range.

Each FET has an intrinsic diode connected in anti-parallel. When switching an inductive load this diode will conduct, and the drop at 10A will be 1.5V maximum, over the full environmental range.

INPUT AND OUTPUT SIGNALS

NOTES: 1. Over full operating temperature range.

2. Long term operation at the maximum junction temperature will result in reduced product life. Lower internal temperature by reducing internal dissipation or using better heatsinking to achieve high MTTF.

3. Each FET.

PIN SYMBOL FUNCTION PIN SYMBOL FUNCTION

1 V

3 Gate supply 3 13 HV1 High Voltage supply 1 2 Lin3 Low drive logic in 3 14 OUT1 Section 1 output 3 Hin3 High drive logic in 3 15 S1 Section 1 source 4 V

Logic supply 16 HVRTN1 Section 1 return

5 V

2 Gate supply 2 17 HV2 High voltage supply 2 6 Lin2 Low drive logic in 2 18 OUT 2 Section 2 output 7 V

Signal ground 19 S2 Section 2 source 8 Hin2 High drive logic in 2 20 HVRTN2 Section 2 return 9 V

1 Gate supply 1 21 HV3 High voltage supply 3 10 Lin1 Low drive logic in 1 22 OUT 3 Section 3 output 11 SD Shut down logic in 23 S3 Section 3 source 12 Hin1 High drive logic in 1 24 HVRTN 3 Section 3 return

Page 3

APEX MICROTECHNOLOGY CORPORATION • TELEPHONE (520) 690-8600 • FAX (520) 888-3329 • ORDERS (520) 690-8601 • EMAIL prodlit@apexmicrotech.com

EB02

PACKAGE SPECIFICATIONS

PACKAGE SPECIFICATIONS DIP9 PACKAGE

WEIGHT: 69 g or 2.4 oz DIMENSIONS ARE IN INCHES ALTERNATE UNITS ARE [MM]

Page 4

APEX MICROTECHNOLOGY CORPORATION • 5980 NORTH SHANNON ROAD • TUCSON, ARIZONA 85741 • USA • APPLICATIONS HOTLINE: 1 (800) 546-2739 4

This data sheet has been carefully checked and is believed to be reliable, however, no responsibility is assumed for possible inaccuracies or omissions. All speciﬁ ciations are subject to change without notice.

EB02

OPERATING CONSIDERATIONS

POWER SUPPLY REQUIREMENTS

SUPPLY VOLTAGE MAX CURRENT HV1 10V to 100V 10A, continuous, 20A peak HV2 10V to 100V 10A, continuous, 20A peak HV3 10V to 100V 10A, continuous, 20A peak Vcc1 10V to 20V 10mA Vcc2 10V to 20V 10mA Vcc3 10V to 20V 10mA Vdd 4.5 to 20V 10mA

HV1, HV2, and HV3 may be used independently, or may

be one supply. Also V

1, Vcc2, and Vcc3 may be used

independently or tied together. The V

supply must be compatible with the input logic. If a high v oltage logic such as CMOS is used it may be tied with the V

supplies. HCMOS

requires a 5V±10% supply

SPECIAL CONSIDERATIONS GENERAL

The EB02 is designed to give the user maximum ﬂ exibility in a digital or DSP based motion control system. Ther mal, overvoltage, ov ercurrent, and crossﬁ re protection circuits are part of the user’s design.

Users should read Application Note 1, "General Operating Considerations;” and Application Note 30, “PWM Basics” for much useful information in applying this part. These Application Notes are in the “Power Integrated Circuits Data Book” and on line at www.apexmicrotech.com.

GROUNDING AND BYPASSING

As in any high power PWM system, grounding and bypassing are some of the keys to success. The EB02 is capable of generating 2 kW pulses with 40 n-second rise and

fall times. If improperly grounded or bypassed this can cause horrible conducted and radiated EMI.

In order to reduce conducted EMI, the EB02 provides a separate power ground, named HVRTN, f or each high voltage supply. These grounds are electrically isolated from the logic ground and each other. This isolation eliminates high current ground loops. However, more than 5V offset between the grounds will destroy the EB02. Apex recommends back to back high current diodes between logic and power grounds; this will maintain isolation but keep offset at a safe level. All grounds should tie together at one common point in the system.

In order to reduce radiated EMI, Apex recommends a 100 µF or larger capacitor between HV and HVRTN. This capacitor should be a switching power grade capacitor with ESR rated at 20kHz. This capacitor should be placed ph ysically as close to the EB02 as possible.

However, such a capacitor will typically have a few hundred milli-ohms or so ESR. Therefore, each section must also be bypassed with a low ESR 1µF or larger ceramic capacitor.

In order to minimize radiated noise, it is necessary to minimize the area of the loop containing high frequency

current. (The size of the antenna.) Therefore, the 1µF ceramic capacitors should bypass each HV to its return at the pins of the EB02.

SHOOT THROUGH PROTECTION

Power FETs have a relatively short turn on delay, and a long turn off delay. Therefore , if the turn on input to an FET in a half bridge circuit is applied simultaneously with the turn off input to the other FET in that half bridge, there will be a time when both FETs are simultaneously on. This "shoot through condition" will short the power rails through the FETs, causing excessive power dissipation and very high EMI.

T o a void the shoot through condition the turn on of one FET must be delayed long enough for the other FET in the same half bridge to have completely turned off.

A delay of at least 0.5 µ-seconds is required for the EB02. This delay is required for both the Hin and Lin inputs.

PROTECTION CIRCUITS

The EB02 does not include protection circuits.

However, there is a shut down input which will turn off all FETs when at logic “1”. This input may be used with user designed temperature sensing and current sensing circuits to shut down the FETs in the event of a detected unsafe condition. This is recommended since the FETs may be turned off this way even if the normal input logic or DSP programming is faulty.

START UP CONSIDERATIONS

The lower rail FET in the half bridge must be turned on for at least 2 µ-seconds to charge the bootstrap capacitor before the top rail FET can be turned on. This must be done no more than 330 µ-seconds prior to turning on the top rail FET. However, a grounded load will give the same purpose as turning on the lower rail FET. However a grounded load will give the same purpose as turning on the lower rail FET. Therefore a grounded load may be operated without this consideration.

An internal ﬂ oating supply is used to enhance the operation of the bootstrap bias circuit. This allows the top rail FETs to be held on indeﬁ nitely once turned on.

HEATSINK

The EB02 should be provided with sufﬁ cient heatsink to dissipate 51 watts when operating at 100V, 10A, 50kHz and 3 sections simultaneously providing maximum current.

The dissipation is composed of conduction losses (I

outxVsat

) up to 16 watt per half bridge and switching losses of about 1 watt per half bridge. The conduction losses are propor tional to I

out

; s witching losses are proportional to HV supply voltage,

load capacitance, and switching frequency.
