PRODUCT INFORMATION PACKET
Model No: 256TTDR16038
Catalog No: E761A
20,1800,DP,256T,3/60/575
Open Drip Proof (ODP)
Regal and Marathon are trademarks of Regal Beloit Corporation or one of its affiliated companies.
©2019 Regal Beloit Corporation, All Rights Reserved. MC017097E
1 of 4
Page 2
Product Information Packet: Model No: 256TTDR16038, Catalog No:E761A 20,1800,DP,256T,3/60/575
Nameplate Specifications
Output HP
Frequency 60 Hz Voltage 575 V
Current
Service Factor
Efficiency 93.6 % Duty Continuous
Insulation Class
KVA Code F Frame 256T
Enclosure Drip Proof Overload Protector No
Ambient Temperature
Opp Drive End Bearing Size 6207 UL Recognized
CSA
IP Code
20 Hp
19.6 A
1.15
F
40 °C
Y
12
Output KW
Speed
Phase
Design Code
Drive End Bearing Size
CE
14.9 kW
1765 rpm
3
B
6309
Y
Technical Specifications
Electrical Type
Poles 4 Rotation Reversible
Squirrel Cage Induction Run
Starting Method
Across The Line
Mounting
Drive End Bearing Ball Opp Drive End Bearing Ball
Frame Material Rolled Steel Shaft Type T
Shaft Diameter
Outline Drawing 037977-1300 Connection Diagram EE7300
Rigid Base
1.625 in
Motor Orientation
Assembly/Box Mounting
Horizontal
F1/F2 CAPABLE
