Digital transistors (PNP)
FEATURES
1. Built-in bias resistors enable the configuration of an inverter circuit
without connecting external input
2. The bias resistors consist of thin -film resistors with complete isolation
to allow positive biasing of the
almost completely eliminating parasitic effects.
3. Only the on/off conditions need to be set for operation, making device
design easy.
PIN CONNENCTIONS AND MARKING
DTA114EE
DTA114EE/DTA114EUA/DTA114EKA
resistors(see equivalent circuit).
input.They also have the advantage of
DTA114EUA
/DTA114ESA/DTA114ECA
SOT-523
SOT-23-3L
DTA114ESA
TO-92S
Addreviated symbol: 14
Addreviated symbol: 14
SOT-323
DTA114ECA DTA114ECA DTA114EKA
SOT-23
Addreviated symbol: 14
Addreviated symbol: 14
1
JinYu
semiconductor
www.htsemi.com
Date:2011/05

Absolute maximum ratings(Ta=25℃)
Parameter Symbol
DTA114EE/DTA114EUA/DTA114EKA
Limits (DTA114E□)
E UA CA KA SA
-50 V
Supply voltage
Input voltage
Output current
Power dissipation
Junction temperature
Storage temperature
V
CC
-40~10 V
V
IN
IO -50
I
-100
C(MAX)
Pd 150 200 300 mW
Tj 150 ℃
Tstg -55~150 ℃
Electrical characteristics (Ta=25℃)
Parameter Symbol Min. Typ Max. Unit Conditions
V
-0.5 VCC=-5V ,IO=-100µA
Input voltage
Output voltage
Input current
Output current
DC current gain
Input resistance
Resistance ratio
Transition frequency
I(off)
-3
V
I(on)
-0.3 V IO/II=-10mA/-0.5mA
V
O(on)
-0.88 mA VI=-5V
I
I
-0.5 µA VCC=-50V, VI=0
I
O(off)
30 VO=-5V ,IO=-5mA
G
I
7 10 13 KΩ
R
1
0.8 1 1.2
R
2/R1
250 MHz VCE=-10V ,IE=5mA,f=100MHz
f
T
/DTA114ESA/ DTA114ECA
V
VO=-0.3V ,IO=-10 mA
Unit
mA
Typical Characteristics
