Page 1
Advanced Technical Information
DSEC 30-04A
HiPerFREDTM Epitaxial Diode
with common cathode and soft recovery
V
RSM
V V
400 400 DSEC 30-04A
Symbol Conditions Maximum Ratings
I
FRMS
I
FAVM
I
FSM
E
AS
I
AR
T
VJ
T
VJM
T
stg
P
tot
M
d
Weight typical 6 g
Symbol Conditions Characteristic Values
I
① TVJ = 25°C; VR = V
R
VF② IF = 15 A; TVJ= 150°C 1.06 V
R
thJC
R
thCH
t
rr
I
RM
Pulse test: ① Pulse Width = 5 ms, Duty Cycle < 2.0 %
V
RRM
Type
A C A
50 A
TC = 145°C; rectangular, d = 0.5 15 A
TVJ = 45°C; tp = 10 ms (50 Hz), sine tbd A
TVJ = 25°C; non-repetitive tbd mJ
IAS = tbd A; L = tbd µH
VA = 1.5·VR typ.; f = 10 kHz; repetitive tbd A
-55...+175 °C
175 °C
-55...+150 °C
TC = 25°C 95 W
mounting torque 0.8...1.2 Nm
typ. max.
100 µA
0.5 mA
TVJ = 150°C; VR = V
RRM
RRM
TVJ= 25°C 1.47 V
1.6 K/W
0.25 K/W
IF = 1 A; -di/dt = 100 A/µs; 30 ns
VR = 30 V; TVJ = 25°C
VR = 100 V; IF = 25 A; -diF/dt = 100 A/µs 5.0 6.3 A
TVJ = 100°C
② Pulse Width = 300 µs, Duty Cycle < 2.0 %
I
V
t
FAV
rr
= 2x15 A
=400 V
RRM
= 30 ns
TO-247 AD
A
C
A
A = Anode, C = Cathode, TAB = Cathode
C (TAB)
Features
●
International standard package
●
Planar passivated chips
●
Very short recovery time
●
Extremely low switching losses
●
Low IRM-values
●
Soft recovery behaviour
●
Epoxy meets UL 94V-0
Applications
●
Antiparallel diode for high frequency
switching devices
●
Antisaturation diode
●
Snubber diode
●
Free wheeling diode in converters
and motor control circuits
●
Rectifiers in switch mode power
supplies (SMPS)
●
Inductive heating
●
Uninterruptible power supplies (UPS)
●
Ultrasonic cleaners and welders
Advantages
●
Avalanche voltage rated for reliable
operation
●
Soft reverse recovery for low
EMI/RFI
●
Low IRM reduces:
- Power dissipation within the diode
- Turn-on loss in the commutating
switch
Dimensions see pages IXYS Data Book
Data according to IEC 60747 and per diode unless otherwise specified
IXYS reserves the right to change limits, test conditions and dimensions.
© 2001 IXYS All rights reserved
127
1 - 1
