DS2103SY
DS2103SY
Rectifier Diode
Replaces October 2001 version, DS4172-5.0 DS4172-5.1 December 2001
FEATURES
■ Double Side Cooling
■ High Surge Capability
APPLICATIONS
■ Rectification
■ Freewheel Diode
■ DC Motor Control
■ Power Supplies
■ Welding
■ Battery Chargers
VOLTAGE RATINGS
Type Number Repetitive Peak
Reverse Voltage
V
RRM
V
DS2103SY26
DS2103SY25
DS2103SY24
DS2103SY23
DS2103SY22
DS2103SY21
Lower voltage grades available.
2600
2500
2400
2300
2200
2100
Conditions
= V
V
RSM
RRM
+ 100V
KEY PARAMETERS
V
2600V
RRM
I
5788A
F(AV)
I
81000A
FSM
Outline type code: F
See Package Details for further information.
Fig. 1 Package outline
ORDERING INFORMATION
When ordering, select the required part number shown in the
Voltage Ratings selection table, e.g.:
DS2103SY22
Note: Please use the complete part number when ordering and
quote this number in any future correspondance relating to your
order.
www.dynexsemi.com
1/7
Page 2
DS2103SY
CURRENT RATINGS
T
= 75oC unless otherwise stated
case
Symbol Parameter Conditions
Double Side Cooled
I
F(AV)
I
F(RMS)
I
Mean forward current
RMS value
F
Continuous (direct) forward current
Half wave resistive load 5788 A
Single Side Cooled (Anode side)
I
F(AV)
I
F(RMS)
I
F
= 100oC unless otherwise stated
T
case
Mean forward current
RMS value
Continuous (direct) forward current
Half wave resistive load 3751 A
Symbol Parameter Conditions
Double Side Cooled
I
F(AV)
Mean forward current
Half wave resistive load 4785 A
UnitsMax.
- 9076 A
- 8278 A
- 5892 A
- 4955 A
UnitsMax.
I
F(RMS)
I
F
RMS value
Continuous (direct) forward current
Single Side Cooled (Anode side)
I
F(AV)
I
F(RMS)
I
F
Mean forward current
RMS value
Continuous (direct) forward current
- 7516 A
T
= 100oC 6725 A
case
Half wave resistive load 3060 A
- 4807 A
- 3950 A
2/7
www.dynexsemi.com
Page 3
SURGE RATINGS
DS2103SY
Symbol
I
FSM
2
tI
I
I
FSM
2
I
t
Surge (non-repetitive) forward current
2
t for fusing
Surge (non-repetitive) forward current
2
I
t for fusing A2s
Parameter
THERMAL AND MECHANICAL DATA
Symbol
R
th(j-c)
R
th(c-h)
Thermal resistance - junction to case
Thermal resistance - case to heatsink
Parameter
Conditions
10ms half sine; T
VR = 50% V
10ms half sine; T
VR = 0
Conditions Min. Max. Units
Double side cooled
Single side cooled
Clamping force 43.0kN
with mounting compound
case
- 1/4 sine
RRM
case
= 175oC
=175oC
dc
Cathode dc
Double side
Single side
Max. Units
65.0 kA
6
21.1 x 10
A2s
81.0 kA
6
33 x 10
- 0.0095oC/W
o
C/W- 0.019Anode dc
o
- 0.019
0.002
-
C/W
o
C/W
- 0.004oC/W
Forward (conducting) 200
T
vj
Virtual junction temperature
Reverse (blocking)
T
stg
-
Storage temperature range
Clamping force
-
175
-
–55 175
38.0 47.0 kN
o
C
o
C
o
C
www.dynexsemi.com
3/7
Page 4
DS2103SY
CHARACTERISTICS
Symbol
V
FM
I
RM
Q
S
I
rr
V
TO
r
T
CURVES
10000
Measured under pulse conditions
T
8000
- (A)
F
6000
Parameter
Forward voltage
Peak reverse current
Total stored charge
Peak reverse recovery current
Threshold voltage
Slope resistance 0.063 mΩ
= 175˚C
j
At V
, T
RRM
= 2000A, dIRR/dt = 3A/µs
I
F
T
= 175˚C, VR = 100V
case
= 175˚C - 0.75 V
At T
vj
At Tvj = 175˚C -
12000
10000
Conditions Min. Max. Units
= 25oC
case
= 175oC - 150 mA
case
- 1.05 VAt 3000A peak, T
-
- 125 A
8000
µC3000
4000
Instantaneous forward current, I
2000
0
0.5 0.6 0.7 0.8 0.9 1.1 1.2 1.3 1.41.0 1.5
Instantaneous forward voltage, V
Fig.2 Maximum (limit) forward characteristics Fig.3 Dissipation curves
VFM Equation:-
= A + Bln (IF) + C.IF+D.√I
V
FM
F
- (V)
F
6000
4000
Mean power dissipation - (W)
2000
0
0 2000 4000 6000 8000
Mean forward current, I
Where A = –0.51826
B = 0.195881
C = 6.39 x 10
–5
D = –0.00544
these values are valid for T
= 125˚C for IF 500A to 9000A
j
F(AV)
dc
Half wave
3 phase
6 phase
10000
- (A)
4/7
www.dynexsemi.com
Page 5
DS2103SY
1 101 2351020 50
20
40
60
80
100
120
140
10
15
5
0
20
25
I
2
t value - (A
2
s x 10
6
)
ms Cycles at 50Hz
Duration
Peak half sine forward current - (kA)
I2t = Î2 x t
2
I2t
100000
- (µC)
S
dIF/dt
I
F
Q
S
I
RM
Max. I
rr
10000
Max. Q
Stored charge Q
1000
0.1 1.0 10 100
Rate of decay of forward current, dI/dt - (A/µs)
Fig.4 Total stored charge and maximum reverse
recovery current
0.1
Conditions:
Tj = 175˚C
VR = 100V
IF = 2000A
S
1000
Reverse recovery current, I
100
rr
- (A)
10
Fig.5 Surge (non-repetitive) forward current vs time
(with 50% V
RRM
at T
case
175˚C)
0.01
0.001
Thermal impedance - (˚C/W)
0.0001
Fig.6 Maximum (limit) transient thermal impedance -
www.dynexsemi.com
Conduction
d.c.
Halfwave
3 phase 120˚
6 phase 60˚
Time - (s)
junction to case
Anode side cooled
Double side cooled
Effective thermal resistance
Junction to case ˚C/W
Double side
0.0095
0.0105
0.0112
0.0139
Single side
0.019
0.020
0.0207
0.0234
1010.10.010.001
100
5/7
Page 6
DS2103SY
PACKAGE DETAILS
For further package information, please contact your nearest Customer Service Centre. All dimensions in mm, unless stated otherwise.
DO NOT SCALE.
Hole Ø3.6 x 2.0 deep (One in each electrode)
Cathode
Note:
1. Package maybe supplied with pins and/or tags.
Ø112.5 max
Ø73 nom
Ø73 nom
Nominal weight: 1600g
Clamping force: 50kN ±10%
Package outine type code: Y
Anode
37.7
36.0
6/7
www.dynexsemi.com
Page 7
DS2103SY
POWER ASSEMBLY CAPABILITY
The Power Assembly group was set up to provide a support service for those customers requiring more than the basic semiconductor,
and has developed a flexible range of heatsink / clamping systems in line with advances in device types and the voltage and current
capability of our semiconductors.
We offer an extensive range of air and liquid cooled assemblies covering the full range of circuit designs in general use today. The
Assembly group continues to offer high quality engineering support dedicated to designing new units to satisfy the growing needs of our
customers.
Using the up to date CAD methods our team of design and applications engineers aim to provide the Power Assembly Complete solution
(PACs).
DEVICE CLAMPS
Disc devices require the correct clamping force to ensure their safe operation. The PACs range offers a varied selection of pre-loaded
clamps to suit all of our manufactured devices. This include cube clamps for single side cooling of ‘T’ 22mm
Clamps are available for single or double side cooling, with high insulation versions for high voltage assemblies.
Please refer to our application note on device clamping, AN4839
HEATSINKS
Power Assembly has its own proprietary range of extruded aluminium heatsinks. They have been designed to optimise the performance
or our semiconductors. Data with respect to air natural, forced air and liquid cooling (with flow rates) is available on request.
For further information on device clamps, heatsinks and assemblies, please contact your nearest Sales Representative or Customer
Services.
http://www.dynexsemi.com
e-mail: [email protected]
HEADQUARTERS OPERATIONS
DYNEX SEMICONDUCTOR LTD
Doddington Road, Lincoln.
Lincolnshire. LN6 3LF. United Kingdom.
Tel: 00-44-(0)1522-500500
Fax: 00-44-(0)1522-500550
DYNEX POWER INC.
99 Bank Street, Suite 410,
Ottawa, Ontario, Canada, K1P 6B9
Tel: 613.723.7035
Fax: 613.723.1518
Toll Free: 1.888.33.DYNEX (39639)
