May 1992
DP8420V/21V/22V-33, DP84T22-25 microCMOS Programmable 256k/1M/4M Dynamic RAM Controller/Drivers
General Description
low time during refreshes and RAS precharge time after refreshes and back to back accesses are guaran­teed through the insertion of wait states. Separate on-chip precharge counters for each RAS memory interleaving to avoid delayed back to back access­es because of precharge. An additional feature of the DP8422V, DP84T22 is two access ports to simplify dual ac­cessing. Arbitration among these ports and refresh is done on chip. To make board level circuit testing easier the DP84T22 incorporates TRI-STATE
Control
Ý
DP8420V 68 9 256 kbit 4 Mbytes Single Access Port
DP8421V 68 10 1 Mbit 16 Mbytes Single Access Port
DP8422V 84 11 4 Mbit 64 Mbytes Dual Access Ports (A and B)
DP84T22 84 11 4 Mbit 64 Mbytes Dual Access and TRI-STATE
or DTACK output inserts wait
output can be used for
output buffers.
É
of Pins
Ý
of Address
(PLCC) Outputs
Features
Y
On chip high precision delay line to guarantee critical DRAM access timing parameters
Y
microCMOS process for low power
Y
High capacitance drivers for RAS, CAS,WEand DRAM address on chip
Y
On chip support for nibble, page and static column DRAMs
Y
TRI-STATE outputs (DP84T22 only)
Y
Byte enable signals on chip allow byte writing in a word size up to 32 bits with no external logic
Y
Selection of controller speeds: 25 MHz and 33 MHz
Y
On board Port A/Port B (DP8422V, DP84T22 only)/re­fresh arbitration logic
Y
Direct interface to all major microprocessors (applica­tion notes available)
Y
4 RAS and 4 CAS drivers (the RAS and CAS configura­tion is programmable)
Largest Direct Drive Access
DRAM Memory Ports
Possible Capacity Available
DP8420V/21V/22V-33, DP84T22-25 microCMOS Programmable
256k/1M/4M Dynamic RAM Controller/Drivers
Block Diagram
DP8420V/21V/22V, DP74T22 DRAM Controller
TRI-STATEÉis a registered trademark of National Semiconductor Corporation. Staggered Refresh
C
1995 National Semiconductor Corporation RRD-B30M105/Printed in U. S. A.
TM
is a trademark of National Semiconductor Corporation.
TL/F/11109
FIGURE 1
TL/F/11109– 1
Page 2
Table of Contents
1.0 INTRODUCTION
2.0 SIGNAL DESCRIPTIONS
2.1 Address, R/W and Programming Signals
2.2 DRAM Control Signals
2.3 Refresh Signals
2.4 Port A Access Signals
2.5 Port B Access Signals (DP8422V, DP84T22)
2.6 Common Dual Port Signals (DP8422V, DP84T22)
2.7 Power Signals and Capacitor Input
2.8 Clock Inputs
3.0 PROGRAMMING AND RESETTING
3.1 External Reset
3.2 Programming Methods
3.2.1 Mode Load Only Programming
3.2.2 Chip Selected Access Programming
3.3 Internal Programming Modes
4.0 PORT A ACCESS MODES
4.1 Access Mode 0
4.2 Access Mode 1
4.3 Extending CAS with Either Access Mode
4.4 Read-Modify-Write Cycles with Either Access Mode
4.5 Additional Access Support Features
4.5.1 Address Latches and Column Increment
4.5.2 Address Pipelining
4.5.3 Delay CAS
5.0 REFRESH OPTIONS
5.1 Refresh Control Modes
5.1.1 Automatic Internal Refresh
5.1.2 Externally Controlled/Burst Refresh
5.1.3 Refresh Request/Acknowledge
5.2 Refresh Cycle Types
5.2.1 Conventional Refresh
5.2.2 Staggered Refresh
5.2.3 Error Scrubbing Refresh
during Write Accesses
TM
5.3 Extending Refresh
5.4 Clearing the Refresh Address Counter
5.5 Clearing the Refresh Request Clock
6.0 PORT A WAIT STATE SUPPORT
6.1 WAIT
6.2 DTACK
Type Output
Type Output
6.3 Dynamically Increasing the Number of Wait States
6.4 Guaranteeing RAS
Low Time and RAS Precharge
Time
7.0 RAS
AND CAS CONFIGURATION MODES
7.1 Byte Writing
7.2 Memory Interleaving
7.3 Address Pipelining
7.4 Error Scrubbing
7.5 Page/Burst Mode
8.0 TEST MODE
9.0 DRAM CRITICAL TIMING PARAMETERS
9.1 Programmable Values of t
9.2 Calculation of t
RAH
and t
RAH
ASC
and t
ASC
10.0 DUAL ACCESSING (DP8422V and DP84T22V)
10.1 Port B Access Mode
10.2 Port B Wait State Support
10.3 Common Port A and Port B Dual Port Functions
10.3.1 GRANTB Output
10.3.2 LOCK
Input
10.4 TRI-STATE Outputs (DP84T22 Only)
11.0 ABSOLUTE MAXIMUM RATINGS
12.0 DC ELECTRICAL CHARACTERISTICS
13.0 AC TIMING PARAMETERS
14.0 FUNCTIONAL DIFFERENCES BETWEEN THE DP8420V/21V/22V, DP84T22 AND THE DP8420/21/22
15.0 DP8420V/21V/22V, DP84T22 USER HINTS
2
Page 3
1.0 Introduction
Reset:
Due to the differences in power supplies, an External (hard­ware) Reset must be performed before programming the chip.
Programming:
After resetting the chip, the user can program the controller by either one of two methods: Mode Load Only Program­ming or Chip Select Access Programming.
Initialization Period:
Once the DP8420V/21V/22V, DP84T22 has been pro­grammed for the first time, a 60 ms initialization period is entered. During this time the DRC performs refreshes to the DRAM array so further warm up cycles are unnecessary. The initialization period is entered only after the first pro­gramming after a reset.
Accessing Modes:
After resetting and programming the chip, the DP8420V/21V/22V, DP84T22 is ready to access the DRAM. There are two modes of accessing with these con­trollers. Mode 0, which indicates RAS Mode 1, which indicates RAS
Refresh Modes:
The DP8420V/21V/22V, DP84T22 have expanded refresh capabilities compared to previous DRAM controllers. There are three modes of refreshing available: Internal Automatic Refreshing, Externally Controlled/Burst Refreshing and Re­fresh Request/Acknowledge Refreshing. Any of these modes can be used together or separately to achieve the desired results.
Refresh Types:
These controllers have three types of refreshing available: Conventional, Staggered and Error Scrubbing. Any refresh control mode can be used with any type of refresh.
Wait Support:
The DP8420V/21V/22V, DP84T22 have wait support avail­able as DTACK Data Transfer ACKnowledge, is useful for processors whose wait signal is active high. WAIT processors whose wait signal is active low. The user can choose either at programming. These signals are used by the on chip arbiter to insert wait states to guarantee the arbitration between accesses, refreshes and precharge. Both signals are independent of the access mode chosen and both signals can be dynamically delayed further through the WAITIN
Sequential Accesses (Static Column/Page Mode):
The DP8420V/21V/22V, DP84T22 have address latches, used to latch the bank, row and column address inputs.
or WAIT. Both are programmable. DTACK,
signal to the DP8420V/21V/22V, DP84T22.
asynchronously.
synchronously and
is useful for those
Once the address is latched, a COLumn INCrement (COL­INC) feature can be used to increment the column address. The address latches can also be programmed to be fall through. COLINC can be used for Sequential Accesses of Static Column DRAMs. Also, COLINC in conjunction with ECAS
inputs can be used for Sequential Accesses to Page
Mode DRAMs.
RAS
and CAS Configuration (Byte Writing):
The RAS and CAS drivers can be configured to drive a one, two or four bank memory array up to 32 bits in width. The ECAS
signals can then be used to select one of four CAS
drivers for Byte Writing with no extra logic.
Memory Interleaving:
When configuring the DP8420V/21V/22V, DP84T22 for more than one bank, Memory Interleaving can be used. By tying the low order address bits to the bank select lines B0 and B1, sequential back to back accesses will not be de­layed since these controllers have separate precharge counters per bank.
Address Pipelining:
The DP8420V/21V/22V, DP84T22 are capable of perform­ing Address Pipelining. In address pipelining, the DRC will guarantee the column address hold time and switch the in­ternal multiplexor to place the row address on the address bus. At this time, another memory access to another bank can be initiated.
Dual Accessing:
The DP8422V, DP84T22 have all the features previously mentioned and unlike the DP8420V/21V, the DP8422V, DP84T22 have a second port to allow a second CPU to access the same memory array. The DP8422V, DP84T22 have four signals to support Dual Accessing, these signals are AREQB for the two ports and refresh is done on chip by the control­ler through the insertion of wait states. Since the DP8422V, DP84T22 have only one input address bus, the address lines must be multiplexed externally. The signal GRANTB can be used for this purpose.
TRI-STATE Outputs:
The DP84T22 implements TRI-STATE outputs. When the input OE OE (high Z).
Terminology:
The following explains the terminology used in this data sheet. The terms negated and asserted are used. Asserted refers to a ‘‘true’’ signal. Thus, ‘‘ECAS0 the ECAS0 ed’’ means the COLINC input is at a logic 1. The term negat­ed refers to a ‘‘false’’ signal. Thus, ‘‘ECAS0 means the ECAS0 negated’’ means the input COLINC is at a logic 0. The table shown below clarifies this terminology.
, ATACKB, LOCK and GRANTB. All arbitration
is asserted the output buffers are enabled, when
is negated, logic 1, the output buffers at TRI-STATE
asserted’’ means
input is at a logic 0. The term ‘‘COLINC assert-
negated’’
input is at a logic 1. The term ‘‘COLINC
Signal Action Logic Level
Active High Asserted High
Active High Negated Low
Active Low Asserted Low
Active Low Negated High
3
Page 4
Connection Diagrams
Top View
FIGURE 2
Order Number DP8420V-33
See NS Package Number V68A
Order Number DP8422V-33 or DP84T22-25
TL/F/11109– 2
Top View
FIGURE 4
See NS Package Number V84A
Top View
TL/F/11109– 3
FIGURE 3
Order Number DP8421V-33
See NS Package Number V68A
TL/F/11109– 4
4
Page 5
2.0 Signal Descriptions
Pin Device (If Not Input/
Name Applicable to All) Output
2.1 ADDRESS, R/W AND PROGRAMMING SIGNALS
R0–10 DP8422V/T22 I ROW ADDRESS: These inputs are used to specify the row address during an access R0–9 DP8420V/21V I
C0–10 DP8422V/T22 I COLUMN ADDRESS: These inputs are used to specify the column address during an C0–9 DP8420V/21V I
B0, B1 I BANK SELECT: Depending on programming, these inputs are used to select a group
ECAS0–3 I ENABLE CAS: These inputs are used to enable a single or group of CAS outputs
WIN I WRITE ENABLE IN: This input is used to signify a write operation to the DRAM. If
COLINC I COLUMN INCREMENT: When the address latches are used, and RFIP is negated, (EXTNDRF) I
ML I MODE LOAD: This input signal, when low, enables the internal programming register
2.2 DRAM CONTROL SIGNALS
Q0–10 DP8422V/T22 O DRAM ADDRESS: These outputs are the multiplexed output of the R0 – 9, 10 and Q0–9 DP8421V O Q0–8 DP8421V O
RAS0–3 O ROW ADDRESS STROBES: These outputs are asserted to latch the row address
CAS0–3 O COLUMN ADDRESS STROBES: These outputs are asserted to latch the column
WE O WRITE ENABLE or REFRESH REQUEST: This output asserted specifies a write (RFRQ
)O
OE DP84T22 I OUTPUT ENABLE: This input asserted, enables the output buffers for the row,
(Only)
to the DRAM. They are also used to program the chip when ML R10).
access to the DRAM. They are also used to program the chip when ML (except C10).
of RAS and CAS outputs to assert during an access. They are also used to program the chip when ML
when asserted. In combination with the B0, B1 and the programming bits, these inputs select which CAS ECAS
signals can also be used to toggle a group of CAS outputs for page/nibble mode accesses. They also can be used for byte write operations. If ECAS negated during programming, continuing to assert the ECAS or AREQB during an access, will cause the CAS outputs to be extended while the RAS
outputs are negated (the ECASn inputs have no effect during scrubbing
refreshes).
ECAS
0 is asserted during programming, the WE output will follow this input. This input asserted will also cause CAS bit C9 is asserted during programming.
this input functions as COLINC. Asserting this signal causes the column address to be incremented by one. When RFIP refresh cycle by any number of periods of CLK until it is negated.
that stores the programming information.
C0–9, 10 and form the DRAM address bus. These outputs contain the refresh address whenever RFIP series damping resistors.
contained on the outputs Q0–8, 9, 10 into the DRAM. When RFIP RAS
outputs are used to latch the refresh row address contained on the Q0–8, 9, 10 outputs in the DRAM. These outputs contain high capacitive drivers with 20X series damping resistors.
address contained on the outputs Q0–8, 9, 10 into the DRAM. These outputs have high capacitive drivers with 20X series damping resistors.
operation to the DRAM. When negated, this output specifies a read operation to the DRAM. When the controller is programmed in address pipelining mode or when ECAS0 is negated during programming, this output will function as RFRQ. When asserted, this pin specifies that 13 msor15ms have passed. If DISRFSH the DP8420V/21V/22V, DP84T22 will perform an internal refresh as soon as possible. If DISRFRSH through the input RFSH damping resistor.
column RASs, CASs and WE. If this input is disabled, logic 1, the output buffers are at TRI-STATE facilitating the board level circuit testing.
is asserted.
output or CAS outputs will assert during an access. The
is asserted. They contain high capacitive drivers with 20X
is asserted, RFRQ can be used to externally request a refresh
. This output has a high capacitive driver and a 20X series
Description
is asserted (except
is asserted
0is
0 while negating AREQ
to delay to the next positive clock edge if address
is asserted, this signal is used to extend the
is asserted, the
is negated,
5
Page 6
2.0 Signal Descriptions (Continued)
Pin Device (If Not Input/
Name Applicable to All) Output
2.3 REFRESH SIGNALS
RFIP O REFRESH IN PROGRESS: This output is asserted prior to a refresh cycle and is
RFSH I REFRESH: This input asserted with DISRFRSH already asserted will request a
DISRFSH I DISABLE REFRESH: This input is used to disable internal refreshes and must be
2.4 PORT A ACCESS SIGNALS
ADS I ADDRESS STROBE or ADDRESS LATCH ENABLE: Depending on programming, (ALE) I
CS I CHIP SELECT: This input signal must be asserted to enable a Port A access.
AREQ I ACCESS REQUEST: This input signal in Mode 0 must be asserted some time after
WAIT O WAIT or DTACK: This output can be programmed to insert wait states into a CPU (DTACK
)O
WAITIN I WAIT INCREASE: This input can be used to dynamically increase the number of
negated when all the RAS
refresh. If this input is continually asserted, the DP8420V/21V/22V, DP84T22 will perform refresh cycles in a burst refresh fashion until the input is negated. If RFSH asserted with DISRFSH (useful for burst refreshes).
asserted when using RFSH
this input can function as ADS when asserted along with CS an access will start from the positive clock edge of CLK as soon as possible. In Mode 1, the input functions as ADS RAS
to assert if no other event is taking place. If an event is taking place, RAS will be asserted from the positive edge of CLK as soon as possible. In both cases, the low going edge of this signal latches the bank, row and column address if programmed to do so.
the first positive clock edge after ALE has been asserted. When this signal is negated, RAS before ADS access.
access cycle. With R7 negated during programming, the output will function as a WAIT With R7 asserted during programming, the output will function as DTACK case, the output will be negated to signify a wait condition and will be asserted to signify the access has taken place. Each of these signals can be delayed by a number of positive clock edges or negative clock levels of CLK to increase the microprocessor’s access cycle through the insertion of wait states.
positive clock edges of CLK until DTACK during a DRAM access.
is negated for the access. In Mode 1, this signal must be asserted
can be negated. When this signal is negated, RAS is negated for the
type output. In this case, the output will be active low to signal a wait condition.
outputs are negated for that refresh.
negated, the internal refresh address counter is cleared
Description
for externally requested refreshes.
or ALE. In mode 0, the input functions as ALE and
causes an internal latch to be set. Once this latch is set
and when asserted along with CS, causes the access
. In this
will be asserted or WAIT will be negated
is
6
Page 7
2.0 Signal Descriptions (Continued)
Pin Device (If Not Input/
Name Applicable to All) Output
2.5 PORT B ACCESS SIGNALS
AREQB DP8422V/T22 I PORT B ACCESS REQUEST: This input asserted will latch the row, column and bank
ATACKB DP8422V/T22 O ADVANCED TRANSFER ACKNOWLEDGE PORT B: This output is asserted when
2.6 COMMON DUAL PORT SIGNALS
GRANTB DP8422V/T22 O GRANT B: This output indicates which port is currently granted access to the DRAM
LOCK DP8422V/T22 I LOCK: This input can be used by the currently granted port to ‘‘lock out’’ the other
2.7 POWER SIGNALS AND CAPACITOR INPUT
V
CC
GND I GROUND: Supply Voltage Reference.
CAP I CAPACITOR: This input is used by the internal PLL for stabilization. The value of the
2.8 CLOCK INPUTS
There are two clock inputs to the DP8420V/21V/22V, DP84T22 CLK and DELCLK. These two clocks may both be tied to the same clock input, or they may be two separate clocks, running at different frequencies, asynchronous to each other.
CLK I SYSTEM CLOCK: This input may be in the range of 0 Hz up to 33 MHz (up to 25 MHz
DELCLK I DELAY LINE CLOCK: The clock input DELCLK, may be in the range of 6 MHz to
only
only
only
only
address if programmed, and requests an access to take place for Port B. If the access can take place, RAS RAS
will assert as soon as possible from a positive edge of CLK.
the access RAS the appropriate DTACK
array. When GRANTB is asserted, Port B has access to the array. When GRANTB is negated, Port A has access to the DRAM array. This signal is used to multiplex the signals R0–8, 9, 10; C0 –8, 9, 10; B0 – 1; WIN when using dual accessing.
port from the DRAM array by inserting wait states into the locked out port’s access cycle until LOCK is negated.
I POWER: Supply Voltage.
ceramic capacitor should be 0.1 mF and should be connected between this input and ground.
in the DP84T22V). This input is generally a constant frequency but it may be controlled externally to change frequencies or perhaps be stopped for some arbitrary period of time.
This input provides the clock to the internal state machine that arbitrates between accesses and refreshes. This clock’s positive edges and negative levels are used to extend the WAIT RAS
precharge time and RAS low time during refresh.
All Port A and Port B accesses are assumed to be synchronous to the system clock CLK.
20 MHz and should be a multiple of 2 (i.e., 6, 8, 10, 12, 14, 16, 18, 20 MHz) to have the DP8420V/21V/22V, DP84T22 switching characteristics hold. If DELCLK is not one of the above frequencies the accuracy of the internal delay line will suffer. This is because the phase locked loop that generates the delay line assumes an input clock frequency of a multiple of 2 MHz.
For example, if the DELCLK input is at 7 MHz and we choose a divide by 3 (program bits C0–2) this will produce 2.333 MHz which is 16.667% off of 2 MHz. Therefore, the DP8420V/21V/22V, DP84T22 delay line would produce delays that are shorter (faster delays) than what is intended. If divide by 4 was chosen the delay line would be longer (slower delays) than intended (1.75 MHz instead of 2 MHz). (See Section 9 for more information.)
This clock is also divided to create the internal refresh clock.
is asserted for a Port B access. This signal can be used to generate
or WAIT type signal for Port B’s CPU or bus.
(DTACK) signals. This clock is also used as the reference for the
Description
will assert immediately. If the access has to be delayed,
; LOCK and ECAS0–3 to the DP8422V
7
Page 8
3.0 Programming and Resetting
Due to the variety in power supplies power-up times, an EXTERNAL RESET must be performed before the DRAM controller can be programmed and used.
After going through the reset procedure, the DP8420V/ 21V/22V, DP84T22 can be programmed by either of two methods; Mode Load Only Programming or Chip Select Ac­cess Programming. After programming the DRC for the first time after reset, the chip enters a 60 ms initialization period, during this period the controller performs refreshes every 13 msor15ms, this makes further DRAM warm up cycles unnecessary. After this stage the chip can be repro­grammed as many times as the user wishes and the 60 ms period will not be entered into unless the chip is reset and programmed again.
During the 60 ms initialization period, RFIP and RAS programming bit for refresh (C3). CAS
1) and the ‘‘Q’’ outputs will count from 0 to 2047 refreshing the entire DRAM array. The actual initialization time period is given by the following formula. T Select)* (Refresh Clock Fine Tune)/(DELCLK Frq.)
toggles every 13 msor15ms depending on the
is asserted low
will be inactive (logic
e
4096* (Clock Divisor
3.1 EXTERNAL RESET
At power up, if the internal power up reset worked, all inter­nal latches and flip-flops are cleared and the part is ready to be programmed. The power up state can also be achieved by performing an External Reset, which is required to insure proper operation. External Reset is achieved by asserting ML
and DISRFSH for at least 16 positive clock edges. In order to perform simply a Reset, the ML negated before DISRFSH This procedure will only reset the controller which now is ready for programming.
The DRC may be programmed any time on the fly, but the user must make sure that No Access or Refresh is in prog­ress. Reset is asynchronous.
at least one clock period before negating ML,as
Figure 5b
is negated.
is negated as shown in
,MLnegated will program the DP8420V/
signal must be
Figure 5a
.
FIGURE 5a. Chip Reset but Not Programmed
FIGURE 5b. Chip Reset and Programmed
TL/F/11109– 5
TL/F/11109– 6
8
Page 9
3.0 Programming and Resetting (Continued)
3.2 PROGRAMMING METHODS
3.2.1 Mode Load Only Programming
To use this method the user asserts ML nal programming register. After ML gramming selection is placed on the address bus, B0, B1 and ECAS0 ed the programming bits are latched into the internal pro­gramming register and the DP8420V/21V/22V, DP84T22 is programmed, see the controller must not be refreshing, RFIP to have a successful programming.
inputs, then ML is negated. When ML is negat-
Figure 6
. When programming the chip,
enabling the inter-
is asserted, a valid pro-
must be high (1)
3.2.2 Chip Selected Access Programming
The chip can also be programmed by performing a chip selected access. To program the chip using this method, ML
is asserted, then CS is asserted and a valid program­ming selection is placed on the address bus. When AREQ asserted, the programming bits affecting the wait logic be­come effective immediately, then DTACK ing the access to terminate. After the access, ML and the rest of the programming bits take effect.
is asserted allow-
is negated
is
FIGURE 6. ML Only Programming
FIGURE 7. CS Access Programming
TL/F/11109– 7
TL/F/11109– 8
9
Page 10
3.0 Programming and Resetting (Continued)
3.3 PROGRAMMING BIT DEFINITIONS
Symbol Description
ECAS0 Extend CAS/Refresh Request Select
0 The CASn outputs will be negated with the RASn outputs when AREQ (or AREQB, DP8422V, DP84T22 only) is
1 The CASn outputs will be negated, during an acccess (Port A (or Port B, DP8422V, DP84T22 only)) when their
B1 Access Mode Select
0 ACCESS MODE 0: ALE pulsing high sets an internal latch. On the next positive edge of CLK, the access (RAS)
1 ACCESS MODE 1: ADS asserted starts the access (RAS) immediately. AREQ will terminate the access.
B0 Address Latch Mode
0 ADS or ALE asserted for Port A or AREQB asserted for Port B with the appropriate GRANT latch the input row,
1 The row, column and bank latches are fall through.
C9 Delay CAS during WRITE Accesses
0 CAS is treated the same for both READ and WRITE accesses.
1 During WRITE accesses, CAS will be asserted by the event that occurs last: CAS asserted by the internal delay
C8 Row Address Hold Time
0 Row Address Hold Timee25 ns minimum
1 Row Address Hold Time
C7 Column Address Setup Time
0 Column Address Setup Timee10 ns miniumum
1 Column Address Setup Timee0 ns minimum
C6, C5, C4 RAS
0, 0, 0 RAS0– 3 and CAS0 –3 are all selected during an access. ECASn must be asserted for CASn to be asserted.
0, 0, 1 RAS
0, 1, 0 RAS and CAS singles are selected during an access by B0 – 1. ECAS
0, 1, 1 RAS
1, 0, 0 RAS pairs are selected by B1. CAS0 – 3 are all selected. ECASn must be asserted for CASn to be asserted.
negated. The WE
corresponding ECAS outputs negating. Scrubbing refreshes are NOT affected. During scrubbing refreshes the CAS outputs will negate along with the RAS
The WE output will function as ReFresh ReQuest (RFRQ) when this mode is programmed.
will start. AREQ
column and bank address.
line or CAS
and CAS Configuration Modes/Error Scrubbing during Refresh
B0 and B1 are not used during an access. Error scrubbing during refresh.
and CAS pairs are selected during an access by B1. ECASn must be asserted for CASn to be asserted.
e
B1
0 during an access selects RAS0–1 and CAS0–1. B1e1 during an access selects RAS2–3 and CAS2–3. B0 is not used during an Access. Error scrubbing during refresh.
e
B1
0, B0e0 during an access selects RAS0 and CAS0.
e
B1
0, B0e1 during an access selects RAS1 and CAS1.
e
B1
1, B0e0 during an access selects RAS2 and CAS2. B1e1, B0e1 during an access selects RAS3 and CAS3. Error scrubbing during refresh.
0–3 and CAS0 –3 are all selected during an access. ECASn must be asserted for CASn to be asserted. B1, B0 are not used during an access. No error scrubbing. (RAS
e
B1
0 during an access selects RAS0–1 and CAS0–3. B1e1 during an access selects RAS2–3 and CAS0–3. B0 is not used during an access. No error scrubbing.
output pin will function as write enable.
n inputs are negated. This feature allows the CAS outputs to be extended beyond the RAS
outputs regardless of the state of the ECAS inputs.
will terminate the access.
asserted on the positive edge of CLK after RAS is asserted.
e
15 ns minimum
n must be asserted for CASn to be asserted.
only refreshing)
10
Page 11
3.0 Programming and Resetting (Continued)
3.3 PROGRAMMING BIT DEFINITIONS (Continued)
Symbol Description
C6, C5, C4 RAS and CAS Configuration Modes (Continued)
1, 0, 1 RAS and CAS pairs are selected by B1. ECASn must be asserted for CASn to be asserted.
1, 1, 0 RAS singles are selected by B0 – 1. CAS0–3 are all selected. ECASn must be asserted for CASntobe
1, 1, 1 RAS and CAS singles are selected by B0, 1. ECASn must be asserted for CASn to be asserted.
C3 Refresh Clock Fine Tune Divisor
0 Divide delay line/refresh clock further by 30 (If DELCLK/Refresh Clock Clock Divisore2 MHze15 ms
1 Divide delay line/refresh clock further by 26 (If DELCLK/Refresh Clock Clock Divisor
C2, C1, C0 Delay Line/Refresh Clock Divisor Select
0, 0, 0 Divide DELCLK by 10 to get as close to 2 MHz as possible. 0, 0, 1 Divide DELCLK by 9 to get as close to 2 MHz as possible. 0, 1, 0 Divide DELCLK by 8 to get as close to 2 MHz as possible. 0, 1, 1 Divide DELCLK by 7 to get as close to 2 MHz as possible. 1, 0, 0 Divide DELCLK by 6 to get as close to 2 MHz as possible. 1, 0, 1 Divide DELCLK by 5 to get as close to 2 MHz as possible. 1, 1, 0 Divide DELCLK by 4 to get as close to 2 MHz as possible. 1, 1, 1 Divide DELCLK by 3 to get as close to 2 MHz as possible.
R9 Refresh Mode Select
0 RAS0–3 will all assert and negate at the same time during a refresh. 1 Staggered Refresh. RAS
R8 Address Pipelining Select
0 Address pipelining is selected. The DRAM controller will switch the DRAM column address back to the row
1 Non-address pipelining is selected. The DRAM controller will hold the column address on the DRAM address
R7 WAIT or DTACK Select
0 WAIT type output is selected. 1 DTACK
R6 Add Wait States to the Current Access if WAITIN is Low
0 WAIT or DTACK will be delayed by one additional positive edge of CLK. 1 WAIT
e
B1
0 during an access selects RAS0–1 and CAS0–1.
e
B1
1 during an access selects RAS2–3 and CAS2–3. B0 is not used during an access. No error scrubbing.
asserted.
e
B1
0, B0e0 during an access selects RAS0 and CAS0–3.
e
B1
0, B0e1 during an access selects RAS1 and CAS0–3.
e
B1
1, B0e0 during an access selects RAS2 and CAS0–3.
e
B1
1, B0e1 during an access selects RAS3 and CAS0–3. No error scrubbing.
e
B1
0, B0e0 during an access selects RAS0 and CAS0.
e
B1
0, B0e1 during an access selects RAS1 and CAS1.
e
B1
1, B0e0 during an access selects RAS2 and CAS2.
e
B1
1, B0e1 during an access selects RAS3 and CAS3. No error scrubbing.
refresh period).
refresh period).
outputs during refresh are separated by one positive clock edge. Depending on the
configuration mode chosen, either one or two RAS
s will be asserted.
address after guaranteeing the column address hold time.
bus until the access RAS
s are negated.
(Data Transfer ACKnowledge) type output is selected.
or DTACK will be delayed by two additional positive edges of CLK.
e
2 MHze13 ms
11
Page 12
3.0 Programming and Resetting (Continued)
3.3 PROGRAMMING BIT DEFINITIONS (Continued)
Symbol Description
R5, R4 WAIT/DTACK during Burst (See Section 5.1.2 or 5.2.2)
0, 0 NO WAIT STATES; If R7e0 during programming, WAIT will remain negated during burst portion of access.
0, 1 1T; If R7e0 during programming, WAIT will assert when the ECAS inputs are negated with AREQ asserted.
1, 0 (/2T; If R7e0 during programming, WAIT will assert when the ECAS inputs are negated with AREQ asserted.
1, 1 0T; If R7e0 during programming, WAIT will assert when the ECAS inputs are negated. WAIT will negate when
R3, R2 WAIT/DTACK Delay Times (See Section 5.1.1 or 5.2.1)
0, 0 NO WAIT STATES; If R7e0 during programming, WAIT will remain high during non-delayed accesses. WAIT
0, 1 (/2T; If R7e0 during programming, WAIT will negate on the negative level of CLK, after the access RAS.
1, 0 NO WAIT STATES, (/2T; If R7
1, 1 1T; If R7e0 during programming, WAIT will negate on the positive edge of CLK after the access RAS.
R1, R0 RAS Low and RAS Precharge Time
0, 0 RAS asserted during refreshe2 positive edges of CLK.
0, 1 RAS
1, 0 RAS asserted during refreshe2 positive edges of CLK.
1, 1 RAS asserted during refreshe4 positive edges of CLK.
e
If R7
1 programming, DTACK will remain asserted during burst portion of access.
WAIT
will negate from the positive edge of CLK after the ECASs have been asserted.
If R7e1 during programming, DTACK will negate when the ECAS inputs are negated with AREQ asserted. DTACK
will assert from the positive edge of CLK after the ECASs have been asserted.
WAIT
will negate on the negative level of CLK after the ECASs have been asserted.
e
If R7
1 during programming, DTACK will negate when the ECAS inputs are negated with AREQ asserted.
DTACK
will assert from the negative level of CLK after the ECASs have been asserted.
the ECAS If R7e1 during programming, DTACK will negate when the ECAS inputs are negated. DTACK will assert when
the ECAS
will negate when RAS is negated during delayed accesses. NO WAIT STATES; If R7
1T; If R7e1 during programming, DTACK will be asserted on the positive edge of CLK after the access RAS.
WAIT (/2T; If R7
1(/2T; If R7 of CLK after the access RAS
RAS RAS
RAS RAS
RAS RAS
RAS RAS
inputs are asserted.
inputs are asserted.
e
1 during programming, DTACK will be asserted when RAS is asserted.
e
will negate on the negative level of CLK, after the access RAS, during delayed accesses.
e
1 during programming, DTACK will be asserted on the negative level of CLK after the access RAS.
e
1 during programming, DTACK will be asserted on the negative level of CLK after the positive edge
precharge timee1 positive edge of CLK. will start from the first positive edge of CLK after GRANTB transitions (DP8422V, DP84T22).
asserted during refreshe3 positive edges of CLK. precharge timee2 positive edges of CLK. will start from the second positive edge of CLK after GRANTB transitions (DP8422V, DP84T22).
precharge timee2 positive edges of CLK. will start from the first positive edge of CLK after GRANTB transitions (DP8422V, DP84T22).
precharge timee3 positive edges of CLK. will start from the second positive edge of CLK after GRANTB transitions (DP8422V, DP84T22).
0 during programming, WAIT will remain high during non-delayed accesses.
.
12
Page 13
4.0 Port A Access Modes
The DP8420V/21V/22V, DP84T22 have two general pur­pose access modes. Mode 0 RAS RAS
asynchronous. One of these modes is selected at pro­gramming through the B1 input. A Port A access to DRAM is initiated by two input signals: ADS cess is always terminated by one signal: AREQ signals should be synchronous to the input clock.
4.1 ACCESS MODE 0
Mode 0, synchronous access, is selected by negating the input B1 during programming (B1 access, ALE is pulse high and CS time was met, a refresh of DRAM or a Port B access was not in progress, the RAS
synchronous and Mode 1
(ALE) and CS. The ac-
e
0). To initiate a Mode 0
is asserted. If precharge
(RASs) would be asserted on the
. These input
first rising edge of clock. If a refresh or a Port B access is in progress or precharge time is required, the controller will wait until these events have taken place and assert RAS (RASs) on the next positive edge of clock.
Sometime after the first positive edge of clock after ALE and CS
have been asserted, the input AREQ must be asserted. In single port applications, once AREQ be negated. On the other hand, ALE can stay asserted sev­eral periods of clock; however, ALE must be negated before or during the period of CLK in which AREQ
The controller samples AREQ on the every rising edge of clock after DTACK AREQ
is sampled negated.
is asserted. The access will end when
is asserted, CS can
is negated.
FIGURE 8a. Access Mode 0
13
TL/F/11109– 9
Page 14
4.0 Port A Access Modes (Continued)
4.2 ACCESS MODE 1
Mode 1, asynchronous access, is selected by asserting the input B1 during programming (B1 cesses to start immediately from the access request input, ADS
. To initiate a Mode 1 access, CS is asserted followed
by ADS
asserted. If precharge time was met, a refresh of the DRAM or a Port B access was not in progress, the RAS (RASs) would be asserted from ADS being asserted. If a refresh or Port B access is in progress or precharge time is required, the controller will wait until these events have tak-
e
1). This mode allows ac-
en place and assert RAS of clock.
When ADS asserted. At this time, ADS continue the access. Also, ADS after AREQ new access will not start until ADS again. When address pipelining is not implemented, ADS and AREQ can be tied together.
The access will end when AREQ is negated.
is asserted or sometime after, AREQ must be
has been asserted and negated; however, a
(RASs) from the next rising edge
can be negated and AREQ will
can continue to be asserted
is negated and asserted
FIGURE 8b. Access Mode 1
14
TL/F/11109– 10
Page 15
4.0 Port A Access Modes (Continued)
4.3 EXTENDING CAS WITH EITHER ACCESS MODE
In both access modes, once AREQ DTACK
if programmed will be negated. If ECAS0 was as-
serted (0) during programming, CAS
is negated, RAS and
(CASs) will be negated
with AREQ CAS been negated, given that the appropriate ECAS
. If ECAS0 was negated (1) during programming,
(CASs) will continue to be asserted after RAS has
inputs are asserted. This allows a DRAM to have data present on the data out bus while gaining RAS
precharge time.
FIGURE 9a. Access Mode 0 Extending CAS
FIGURE 9b. Access Mode 1 Extending CAS
TL/F/11109– 11
TL/F/11109– 12
15
Page 16
4.0 Port A Access Modes (Continued)
4.4 READ-MODIFY-WRITE CYCLES WITH EITHER ACCESS MODE
There are 2 methods by which this chip can be used to do read-modify-write access cycles. The first method involves doing a late write access where the WIN some delay after CAS volves doing a page mode read access followed by a page mode write access with RAS
CASn must be toggled using the ECASn inputs and WIN has to be changed from negated to asserted (read to write)
is asserted. The second method in-
held low (see
input is asserted
Figure 9c
).
while CAS WIN cause here a problem may arise with DATA IN and DATA OUT being valid at the same time. This may result in a data line trying to drive two different levels simultaneously. The page mode method of a read-modify-write access allows the user to have transceivers in the system because the data in (read data) is guaranteed to be high impedance dur­ing the time the data out (write data) is valid.
is negated. This method is better than changing
from negated to asserted in a late write access be-
*There may be idle states inserted here by the CPU.
TL/F/11109– 13
FIGURE 9c. Read-Modify-Write Access Cycle
16
Page 17
4.0 Port A Access Modes (Continued)
4.5 ADDITIONAL ACCESS SUPPORT FEATURES
To support the different modes of accessing, the DP8420V/ 21V/22V, DP84T22 offer other access features. These ad­ditional features include: Address Latches and Column In­crement (for page/burst mode support), Address Pipelining, and Delay CAS ensure valid data is present before CAS
4.5.1 Address Latches and Column Increment
The Address Latches can be programmed, through pro­gramming bit B0. They can be programmed to either latch the address or remain in a fall-through mode. If the address latches are used to latch the address, the controller will function as follows:
In Mode 0, the rising edge of ALE places the latches in fall­through, once ALE is negated, the address present in the row, column and bank input is latched.
(to allow the user with a multiplexed bus to
is asserted).
In Mode 1, the address latches are in fall through mode until ADS
is asserted. ADS asserted latches the address.
Once the address is latched, the column address can be incremented with the input COLINC. COLINC can be used for sequential accesses of static column DRAMs. COLINC can also be used with the ECAS tial accesses to page mode DRAMs as shown in COLINC should only be asserted when the signal RFIP negated during an access since this input functions as ex­tended refresh when RFIP negated (0) when the address is being latched (ADS edge in Mode 1). If COLINC is asserted with all of the bits of the column address asserted (ones), the column address will return to zero.
inputs to support sequen-
Figure 10
is asserted. COLINC must be
falling
.
is
FIGURE 10. Column Increment
The address latches function differently with the DP8422V, DP84T22. The DP8422V, DP84T22 will latch the address of the currently granted port. If Port A is currently granted, the address will be latched as described in Section 4.5.1. If Port A is not granted, and requests an access, the address will be latched on the first or second positive edge of CLK after GRANTB has been negated depending on the programming bits R0, R1.
For Port B, if GRANTB is asserted, the address will be latched with AREQB address will latch on the first or second positive edge of CLK after GRANTB is asserted depending on the program­ming bits R0, R1.
17
asserted. If GRANTB is negated, the
TL/F/11109– 14
Page 18
4.0 Port A Access Modes (Continued)
4.5.2 Address Pipelining
Address pipelining is the overlapping of accesses to differ­ent banks of DRAM. If the majority of successive accesses are to a different bank, the accesses can be overlapped. Because of this overlapping, the cycle time of the DRAM accesses are greatly reduced. The DP8420V/21V/22V, DP84T22 can be programmed to allow a new row address to be placed on the DRAM address bus after the column address hold time has been met. At this time, a new access can be initiated with ADS mode, while AREQ The DP8422V and DP84T22 support address pipelining for Port A only. This mode cannot be used with page, static column or nibble modes of operations because the DRAM column address is switched back to the row address after CAS
is asserted. This mode is programmed through ad­dress bit R8 (see output WE
always functions as RFRQ.
or ALE, depending on the access
is used to sustain the current access.
Figures 11a
and
11b
). In this mode, the
During address pipelining in Mode 0, shown in ALE cannot be pulsed high to start another access until AREQ
has been asserted for the previous access for at least one period of CLK. DTACK negated once AREQ insert wait states, will be asserted once ALE and CS asserted.
In Mode 1, shown in AREQ
is asserted. After meeting the minimum negated pulse width for ADS new access. DTACK AREQ
is negated. WAIT, if programmed, will be asserted
once ADS
In either mode with either type of wait programmed, the DP8420V/21V/22V, DP84T22 will still delay the access for precharge if sequential accesses are to the same bank or if a refresh takes place.
is asserted.
is negated. WAIT, if programmed to
Figure 11d
, ADS can again be asserted to start a
, if programmed, will be negated once
, if programmed, will be
, ADS can be negated once
Figure 11c
are
,
FIGURE 11a. Non-Address Pipelined Mode
FIGURE 11b. Address Pipelined Mode
TL/F/11109– 15
TL/F/11109– 16
18
Page 19
4.0 Port A Access Modes (Continued)
TL/F/11109– 17
TL/F/11109– 18
is Sampled at the ‘‘T3’’ Falling Clock Edge)
WAIT
FIGURE 11c. Mode 0 Address Pipelining (WAIT of 0, (/2T Has Been Programmed.
19
FIGURE 11d. Mode 1 Address Pipelining (DTACK 1(/2T Programmed, DTACK is Sampled at the ‘‘T3’’ Falling Clock Edge)
Page 20
4.0 Port A Access Modes (Continued)
4.5.3 Delay CAS
Address bit C9 asserted during programming will cause CAS to be delayed until the first positive edge of CLK after RAS is asserted when the input WIN is asserted. Delaying CAS during write accesses ensures that the data to be written to DRAM will be setup to CAS
during Write Accesses
asserting as shown in
Figures
and
12b.
12a
be present after the first positive edge of CLK, CAS delayed further with the ECAS negated during programming, read and write accesses will be treated the same (with regard to CAS
If the possibility exists that data still may not
can be
inputs. If address bit C9 is
).
FIGURE 12a. Mode 0 Delay CAS
FIGURE 12b. Mode 1 Delay CAS
TL/F/11109– 19
TL/F/11109– 20
20
Page 21
5.0 Refresh Options
The DP8420V/21V/22V, DP84T22 support three refresh control mode options:
1. Automatic Internally Controlled Refresh.
2. Externally Controlled/Burst Refresh.
3. Refresh Request/Acknowledge.
1. All RAS
2. Staggered Refresh.
3. Error Scrubbing During All RAS
There are three inputs, EXTNDRF, RFSH and DISRFSH, and two outputs, RFIP There are also ten programming bits: R0–1, R9, C0 –6 and ECAS0 used to program the various types of refreshing.
Asserting the input EXTNDRF, extends the refresh cycle for a single or multiple integral periods of CLK.
The output RFIP first refresh RAS progress, RFIP before the first refresh RAS ted for the access (see
The DP8420V/21V/22V, DP84T22 will increment the re­fresh address counter automatically, independent of the re­fresh mode used. The refresh address counter will be incre­mented once all the refresh RAS
Refresh.
Refresh.
and RFRQ, associated with refresh.
is asserted one period of CLK before the
is asserted. If an access is currently in
will be asserted up to one period of CLK
, after AREQ or AREQB is nega-
Figure 13
).
s have been negated.
In every combination of refresh control mode and refresh type, the DP8420V/21V/22V, DP84T22 is programmed to keep RAS ues of RAS
asserted a number of CLK periods. The time val-
low during refresh are programmed through pro-
gramming bits R0 and R1.
5.1 REFRESH CONTROL MODES
5.1.1. Automatic Internal Refresh
The DP8420V/21V/22V, DP84T22 have an internal refresh clock. The period of the refresh clock is generated from the programming bits C0 –3. Every period of the refresh clock, an internal refresh request is generated. As long as a DRAM access is not currently in progress and precharge time has been met, the internal refresh request will generate an auto­matic internal refresh. If a DRAM access is in progress, the DP8420V/21V/22V, DP84T22 on-chip arbitration logic will wait until the access is finished before performing the re­fresh. The refresh/access arbitration logic can insert a re­fresh cycle between two address pipelined accesses. How­ever, the refresh arbitration logic can not interrupt an ac­cess cycle to perform a refresh. To enable automatic inter­nally controlled refreshes, the input DISRFSH
must be neg-
ated.
Explanation of Terms
RFRQeReFresh ReQuest internal to the DP8420V/21V/22V, DP84T22. RFRQ has the ability to hold off a pending access.
e
RFSH
Externally requested ReFreSH
e
RFIP
ReFresh in Progress
e
ACIP
Port A or Port B (DP8422V and DP84T22 only) ACcess in Progress. This means that either RAS is low for an access or is in the process of transitioning low for an access.
TL/F/11109– 21
FIGURE 13. DP8420V/21V/22V, DP84T22 Access/Refresh Arbitration State Program
21
Page 22
5.0 Refresh Options (Continued)
5.1.2 Externally Controlled/Burst Refresh
To use externally controlled/burst refresh, the user must disable the automatic internally controlled refreshes by as­serting the input DISRFSH erating the refresh request by asserting the input RFSH Pulsing RFSH
low, sets an internal latch, that is used to
produce the internal refresh request. The refresh cycle will
. The user is responsible for gen-
take place on the next positive edge of CLK as shown in
Figure 14a
. If an access to DRAM is in progress or pre­charge time for the last access has not been met, the re­fresh will be delayed. Since pulsing RFSH the user does not have to keep RFSH
.
starts. When the last refresh RAS
low until the refresh
negates, the internal re-
fresh request latch is cleared.
low sets a latch,
FIGURE 14a. Single External Refreshes (2 Periods of RAS Low during Refresh Programmed)
By keeping RFSH which ends the refresh cycle as shown in
asserted past the positive edge of CLK
Figure 14b
, the user will perform another refresh cycle. Using this tech­nique, the user can perform a burst refresh consisting of any number of refresh cycles. Each refresh cycle during a burst refresh will meet the refresh RAS
low time and the RAS
precharge time (programming bits R0 –1).
FIGURE 14b. External Burst Refresh (2 Periods of RAS Precharge,
2 Periods of Refresh RAS
output. The Qn outputs function as a decode of how many row addresses have been refreshed (Q7 128 refreshes, Q8e256 refreshes, Q9e512 refreshes,
e
Q10
1024 refreshes).
Low during Refresh Programmed)
TL/F/11109– 22
e
TL/F/11109– 23
22
Page 23
5.0 Refresh Options (Continued)
5.1.3 Refresh Request/Acknowledge
The DP8420V/21V/22V, DP84T22 can be programmed to output internal refresh requests. When the user programs ECAS
0 negated (1) and/or address pipelining mode is se­lected, the WE be asserted by one of two events:
First, when the external circuitry pulses low the input RFSH which will request an external refresh.
Second, when the internal refresh clock has expired, which signals that another refresh is needed.
15a
. Notice that RFRQ will be asserted from a positive edge
of clock.
On the second case, when the RFRQ expiration of the internal refresh clock, the user has two options:
output functions as RFRQ. RFRQ (WE) will
is negated (1), is shown in
is asserted from the
Figure
First, if DISRFSH will take place. See
Second, with DISRFSH asserted, RFRQ will stay asserted until RFSH ly requested/burst refresh to take place. See
RFRQ will go high and then assert (toggle) if additional peri­ods of the internal refresh clock have expired and neither an externally controlled refresh nor an automatically controlled internal refresh have taken place, see critical event, or long accesses like page/static column mode can not be interrupted, RFRQ used to increment a counter. This counter can be used to perform a burst refresh of the number of refreshes missed (through the RFSH
is negated, an automatic internal refresh
Figure 15b
is pulsed low . This option will cause an external-
.
Figure 15c
Figure 15d
pulsing high can be
input).
. If a time
.
FIGURE 15a. Externally Controlled Single and Burst Refresh with Refresh Request
(RFRQ
) Output (2 Periods of RAS Low during Refresh Programmed)
FIGURE 15b. Automatic Internal Refresh with Refresh Request (3T of RAS Low during Refresh Programmed)
TL/F/11109– 24
TL/F/11109– 25
23
Page 24
5.0 Refresh Options (Continued)
TL/F/11109– 26
Low during Refresh Programmed)
TL/F/11109– 27
2 Periods of Refresh RAS
FIGURE 15c. External Burst Refresh (2 Periods of RAS Precharge,
24
FIGURE 15d. Refresh Request Timing
Page 25
5.0 Refresh Options (Continued)
5.2 REFRESH CYCLE TYPES
Three different types of refresh cycles are available for use. The three different types are mutually exclusive and can be used with any of the three modes of refresh control. The three different refresh cycle types are: all RAS gered RAS fresh. In all refresh cycle types, the RAS guaranteed: between the previous access RAS the refresh RAS and access RAS
refresh and error scrubbing during all RAS re-
0 starting; between refresh RAS3 ending
beginning; between burst refresh RASs.
refresh, stag-
precharge time is
ending and
5.2.1 Conventional RAS
A conventional refresh cycle causes RAS from the first positive edge of CLK after RFIP shown in number of positive edges of CLK programmed have passed. On the last positive edge, RAS ed. This type of refresh cycle is programmed by negating address bit R9 during programming.
Figure 16
Refresh
0–3 to all assert
is asserted as
. RAS0 –3 will stay asserted until the
0–3, and RFIP will be negat-
FIGURE 16. Conventional RAS Refresh
5.2.2 Staggered RAS
A staggered refresh staggers each RAS or group of RASs by a positive edge of CLK as shown in ber of RAS of CLK, is determined by the RAS programming bits C4 – C6. If single RAS ed during programming, then each RAS cessive positive edges of CLK. If two RAS lected during programming then RAS
s, which will be asserted on each positive edge
Refresh
Figure 17
, CAS configuration mode
0 and RAS1 will assert
. The num-
outputs are select-
will assert on suc-
outputs are se-
FIGURE 17. Staggered RAS Refresh
TL/F/11109– 28
on the first positive edge of CLK after RFIP RAS
2 and RAS3 will assert on the second positive edge of CLK after RFIP during programming, all RAS first positive edge of CLK after RFIP or group of RASs will meet the programmed RAS low time and then negate.
is asserted. If all RAS outputs were selected
outputs would assert on the
is asserted. Each RAS
is asserted.
TL/F/11109– 29
25
Page 26
5.0 Refresh Options (Continued)
5.2.3 Error Scrubbing during Refresh
The DP8420V/21V/22V, DP84T22 support error scrubbing during all RAS fresh is selected through bits C4 –C6 with bit R9 negated during programming. Error scrubbing can not be used with staggered refresh (see Section 8.0). Error scrubbing during refresh allows a CAS all RAS be read from the DRAM array and passed through an Error Detection And Correction Chip, EDAC. If the EDAC deter­mines that the data contains a single bit error and corrects that error, the refresh cycle can be extended with the input
DRAM refreshes. Error scrubbing during re-
refresh as shown in
or group of CASs to assert during the
Figure 18
. This allows data to
extend refresh, EXTNDRF, and a read-modify-write opera­tion can be performed by asserting WE ty of the designer to ensure that WE DP8422V, DP84T22 have a 24-bit internal refresh address counter that contains the 11 row, 11 column and 2 bank addresses. The DP8420V/21V have a 22-bit internal refresh address counter that contains the 10 row, 10 column and 2 bank addresses. These counters are configured as bank, column, row with the row address as the least significant bits. The bank counter bits are then used with the program­ming selection to determine which CAS will assert during a refresh.
. It is the responsibili-
is negated. The
or group of CASs
FIGURE 18. Error Scrubbing during Refresh
26
TL/F/11109– 30
Page 27
5.0 Refresh Options (Continued)
5.3 EXTENDING REFRESH
The programmed number of periods of CLK that refresh RAS
s are asserted can be extended by one or multiple peri­ods of CLK. Only the all RAS bing) type of refresh can be extended. To extend a refresh cycle, the input extend refresh, EXTNDRF, must be assert­ed before the positive edge of CLK that would have negated all the RAS
outputs during the refresh cycle and after the positive edge of CLK which starts all RAS refresh as shown in
Figure 19
the next positive edge of CLK and EXTNDRF will be sam­pled again. The refresh cycle will continue until EXTNDRF is sampled low on a positive edge of CLK.
(with or without error scrub-
outputs during the
. This will extend the refresh to
5.4 CLEARING THE REFRESH ADDRESS COUNTER
The refresh address counter can be cleared by asserting RFSH
while DISRFSH is negated as shown in
Figure 20a
This can be used prior to a burst refresh of the entire memo­ry array. By asserting RFSH DISRFSH
is asserted and then keeping both inputs assert-
one period of CLK before
ed, the DP8420V/21V/22V, DP84T22 will clear the refresh address counter and then perform refresh cycles separated by the programmed value of precharge as shown in
20b
. An end-of-count signal can be generated from the Q
Figure
DRAM address outputs of the DP8420V/21V/22V, DP84T22 and used to negate RFSH
.
.
FIGURE 19. Extending Refresh with the Extend Refresh (EXTNDRF) Input
TL/F/11109– 32
FIGURE 20a. Clearing the Refresh Address Counter
FIGURE 20b. Clearing the Refresh Counter during Burst
TL/F/11109– 31
TL/F/11109– 33
27
Page 28
5.0 Refresh Options (Continued)
5.5 CLEARING THE REFRESH REQUEST CLOCK
The refresh request clock can be cleared by negating DISRFSH internal 2 MHz clock as shown in
and asserting RFSH for 500 ns, one period of the
Figure 21
. By clearing the
refresh request clock, the user is guaranteed that an inter­nal refresh request will not be generated for approximately 15 ms, one refresh clock period, from the time RFSH ated. This action will also clear the refresh address counter.
is neg-
FIGURE 21. Clearing the Refresh Request Clock Counter
6.0 Port A Wait State Support
Wait states allow a CPU’s access cycle to be increased by one or multiple CPU clock periods. The wait or ready input is named differently by CPU manufacturers. However, any CPU’s wait or ready input is compatible with either the WAIT or DTACK output of the DP8420V/21V/22V, DP84T22. The user determines whether to program WAIT and which value to select for WAIT pending upon the CPU used and where the CPU samples its wait input during an access cycle.
The decision to terminate the CPU access cycle is directly affected by the speed of the DRAMs used. The system de­signer must ensure that the data from the DRAMs will be present for the CPU to sample or that the data has been written to the DRAM before allowing the CPU access cycle to terminate.
The insertion of wait states also allows a CPU’s access cy­cle to be extended until the DRAM access has taken place. The DP8420V/21V/22V, DP84T22 insert wait states into CPU access cycles due to; guaranteeing precharge time, refresh currently in progress, user programmed wait states, the WAITIN valid (DP8422V, DP84T22 only). If one of these events is taking place and the CPU starts an access, the DP8420V/ 21V/22V, DP84T22 will insert wait states into the access
signal being asserted and GRANTB not being
or DTACK (R7)
or DTACK (R2, R3) de-
TL/F/11109– 34
cycle, thereby increasing the length of the CPU’s access. Once the event has been completed, the DP8420V/21V/ 22V, DP84T22 will allow the access to take place and stop inserting wait states.
There are six programming bits, R2–R7; an input, WAITIN and an output that functions as WAIT
6.1 WAIT
With the R7 address bit negated during programming, the user selects the WAIT asserted by the CPU, wait states (extra clock periods) are inserted into the current access cycle as shown in
22
completed by the CPU. WAIT a chip selected access and is programmed to negate a number of positive edges and/or negative levels of CLK from the event that starts the access. WAIT programmed to function in page/burst mode applications. Once WAIT inputs are negated with AREQ asserted, WAIT can be pro­grammed to toggle, following the ECAS is negated, ending the access, WAIT will stay negated until the next chip selected access. For more details about WAIT Type Output, see Application Note AN-773.
TYPE OUTPUT
output. As long as WAIT is sampled
. Once WAIT is sampled negated, the access cycle is
is negated during an access, and the ECAS
or DTACK.
Figure
is asserted at the beginning of
can also be
inputs. Once AREQ
;
FIGURE 22. WAIT Type Output
28
TL/F/11109– 35
Page 29
6.0 Port A Wait State Support (Continued)
6.2 DTACK
With the R7 address bit asserted during programming, the user selects the DTACK sampled negated by the CPU, wait states are inserted into the current access cycle as shown in DTACK by the CPU. DTACK grammed to assert a number of positive edges and/or neg­ative levels from the event that starts RAS DTACK burst mode accesses. Once DTACK ECAS be programmed to negate and assert from the ECAS toggling to perform a page/burst mode operation. Once AREQ ed and stays negated until the next chip selected access. For more details about DTACK Note AN-773.
TYPE OUTPUT
type output. As long as DTACK is
is sampled asserted, the access cycle is completed
Figure 23.
, which is normally negated, is pro-
for the access.
can also be programmed to function during page/
is asserted and the
inputs are negated with AREQ asserted, DTACK can
is negated, ending the access, DTACK will be negat-
type output, see Application
Once
inputs
6.3 DYNAMICALLY INCREASING THE NUMBER OF WAIT STATES
Figure 24b
is asserted or WAIT is negated. With the
asserted, the user can delay DTACK asserting
negating either one or two more positive edges of
of (/2T, asserting WAITIN, pro-
of 2(/2T as shown in
can increase the number of positive edges in
can be permanently asserted
can also be asserted and negated, depending on
line from the CPU and connect the output to
. This could be used to perform write accesses with
.
Figure 24a
. Simi-
FIGURE 23. DTACK Type Output
FIGURE 24a. WAITIN Example (DTACK is Sampled at the ‘‘T3’’ Falling Clock Edge)
29
TL/F/11109– 36
TL/F/11109– 37
Page 30
6.0 Port A Wait State Support (Continued)
FIGURE 24b. WAITIN Example (WAIT is Sampled at the End of ‘‘T2’’).
6.4 GUARANTEEING RAS AND RAS
The DP8420V/21V/22V, DP84T22 will guarantee RAS charge time between accesses; between refreshes; and be­tween access and refreshes. The programming bits R0 and R1 are used to program combinations of RAS time and RAS CLK. RAS ing an access, the system designer guarantees the time RAS wait logic. Since inserting wait states into an access in­creases the length of the CPU signals which are used to create ADS ed can be guaranteed.
The precharge time is also guaranteed by the DP8420V/ 21V/22V, DP84T22. Each RAS
PRECHARGE TIME
low time referenced by positive edges of
low time is programmed for refreshes only. Dur-
is asserted through the DP8420V/21V/22V, DP84T22
or ALE and AREQ, the time that RAS is assert-
LOW TIME
pre-
precharge
output has a separate posi-
TL/F/11109– 38
tive edge of CLK counter. AREQ tive edge of CLK to terminate the access. That positive edge is 1T. The next positive edge is 2T. RAS asserted until the programmed number of positive edges of CLK have passed as shown in grammed precharge time has been met, RAS ed from the positive edge of CLK. However, since there is a precharge counter per RAS will not be delayed. Precharge time before a refresh is al­ways referenced from the access RAS RAS
0 for the refresh asserting. After a refresh, precharge time is referenced from RAS the access RAS
asserting.
is negated setup to a posi-
will not be
Figure 25
, an access using another RAS
3 negating, for the refresh, to
. Once the pro-
will be assert-
negating before
FIGURE 25. Guaranteeing RAS Precharge (DTACK is Sampled at the ‘‘T2’’ Falling Clock Edge)
30
TL/F/11109– 39
Page 31
7.0 RAS and CAS Configuration Modes
The DP8420V/21V/22V, DP84T22 allow the user to config­ure the DRAM array to contain one, two or four banks of DRAM. Depending on the functions used, certain considera­tions must be used when determining how to set up the DRAM array. Programming address bits C4, C5 and C6 along with bank selects, B0 –1, and CAS 3, determine which RAS or group of CASs will be asserted during an access. Differ­ent memory schemes are described. The DP8420V/21V/ 22V, DP84T22 is specified driving a heavy load of 72 DRAMs, representing four banks of DRAM with 16-bit words and 2 parity bits. The DP8420V/21V/22V, DP84T22 can drive more than 72 DRAMs, but the AC timing must be in­creased. Since the RAS all RAS
and CAS outputs should be used for the maximum
amount of drive.
or group of RASs and which CAS
and CAS outputs are configurable,
enables, ECAS0–
7.1 BYTE WRITING
By selecting a configuration in which all CAS selected during an access, the ECAS or group of CAS size of up to 32 bits. In this case, the RAS to select which of up to 4 banks is to be used as shown in
Figures 26a
the byte enables can be gated with a high order address bit to produce four byte enables which gives an equivalent to 8 banks of 16-bit words as shown in ry is required, each CAS in the 16-bit word as shown in
outputs to select a byte (or bytes) in a word
and
26b
. In systems with a word size of 16 bits,
should be used to drive each nibble
inputs enable a single
Figure 26d
Figure 26c
outputs are
outputs are used
. If less memo-
.
FIGURE 26a. DRAM Array Setup for 32-Bit System (C6, C5, C4e1, 1, 0 during Programming)
FIGURE 26b. DRAM Array Setup for 32-Bit, 1 Bank System (C6, C5, C4e0, 0, 0 Allowing Error Scrubbing
or C6, C5, C4
e
0, 1, 1 No Error Scrubbing during Programming)
31
TL/F/11109– 40
TL/F/11109– 41
Page 32
7.0 RAS and CAS Configuration Modes (Continued)
FIGURE 26c. DRAM Array Setup for 16-Bit System (C6, C5, C4e1, 1, 0 during Programming)
TL/F/11109– 42
FIGURE 26d. 8 Bank DRAM Array for 16-Bit System (C6, C5, C4e1, 1, 0 during Programming)
TL/F/11109– 43
32
Page 33
7.0 RAS and CAS Configuration Modes (Continued)
7.2 MEMORY INTERLEAVING
Memory interleaving allows the cycle time of DRAMs to be reduced by having sequential accesses to different memory banks. Since the DP8420V/21V/22V, DP84T22 have sepa­rate precharge counters per bank, sequential accesses will not be delayed if the accessed banks use different RAS outputs. To ensure different RAS outputs will be used, a mode is selected where either one or two RAS be asserted during an access. The bank select or selects, B0 and B1, are then tied to the least significant address bits, causing a different group of RAS sequential access as shown in should be at least one clock period of all RAS between different RAS tion of a CAS
’s being asserted to avoid the condi-
before RAS refresh cycle.
s to assert during each
Figure 27
outputs will
. In this figure there
’s negated
7.3 ADDRESS PIPELINING
Address pipelining allows several access RAS serted at once. Because RAS quires either a mode where one RAS per bank as shown in two CAS writing can be accomplished in a 16-bit word system if two RAS
s and two CASs are used per bank. In other systems,
WE
s (or external gating on the CAS outputs) must be used to perform byte writing. If WE and data out buffers must be used. If the array is not layed out this way, a CAS will cause a refresh of the DRAM, not an access. To take full advantage of address pipelining, memory interleaving is used. To memory interleave, the least significant address bits should be tied to the bank select inputs to ensure that all ‘‘back to back’’ sequential accesses are not delayed, since different memory banks are accessed.
s can overlap, each bank re-
s are used per bank as shown in
Figure 28a
to a bank can be low before RAS, which
and one CAS are used
or where two RASs and
s are used separate data in
stobeas-
Figure 28b
. Byte
FIGURE 27. Memory Interleaving (C6, C5, C4e1, 1, 0 during Programming)
33
TL/F/11109– 44
Page 34
7.0 RAS and CAS Configuration Modes (Continued)
FIGURE 28a. DRAM Array Setup for 4 Banks Using Address Pipelining (C6, C5, C4e1, 1, 1
or C6, C5, C4
FIGURE 28b. DRAM Array Setup for Address Pipelining with 2 Banks (C6, C5, C4e1, 0, 1
or C6, C5, C4
e
0, 1, 0 (Also Allowing Error Scrubbing) during Programming)
e
0, 0, 1 (Also Allowing Error Scrubbing) during Programming)
7.4 ERROR SCRUBBING
In error scrubbing during refresh, the user selects one, two or four RAS
and CAS outputs per bank. When performing
error detection and correction, memory is always accessed
as words. Since the CAS individual bytes, the ECAS in
Figures 29a
and
29b
.
TL/F/11109– 45
TL/F/11109– 46
signals are not used to select
inputs can be tied low as shown
FIGURE 29a. DRAM Array Setup for 4 Banks Using Error Scrubbing (C6, C5, C4e0, 1, 0 during Programming)
TL/F/11109– 47
FIGURE 29b. DRAM Array Setup for Error Scrubbing with 2 Banks (C6, C5, C4e0, 0, 1 during Programming)
TL/F/11109– 48
34
Page 35
7.0 RAS and CAS Configuration Modes (Continued)
7.5 PAGE/BURST MODE
In a static column, page or burst mode system, the least significant bits must be tied to the column address in order to ensure that the page/burst accesses are to sequential memory addresses, as shown in
Figure 30.
In a nibble mode system, the least significant bits must be tied to the highest column and row address bits in order to ensure that sequential address bits are the ‘‘nibble’’ bits for nibble mode accesses
(Figure 30)
. The ECAS inputs may then be tog-
gled with the DP8420V/21V/22V’s, DP84T22’s address
*See table below for row, column & bank address bit map. A0, A1 are used for byte addressing in this example.
Addresses Nibble Mode*
Column C9,R9eA2,A3 C0– 7eA2–9 C0–8eA2–10 C0–9eA2–11
Address C0 –8
Row
Address
B0 A4 A10 A11 A12 A13 B1 A5 A11 A12 A13 A14
Assume that the least significant address bits are used for byte addressing. Given a 32-bit system A0,A1 would be used for byte addressing.
e
X
DON’T CARE, the user can do as he pleases.
*Nibble mode values for R and C assume a system using 1 Mbit DRAMs.
XXX X X
256 Bits/Page 512 Bits/Page 1024 Bits/Page 2048 Bits/Page
e
X C8–10eX C9,10eX C10eX
FIGURE 30. Page, Static Column, Nibble Mode System
latches in fall-through mode, while AREQ ECAS
inputs can also be used to select individual bytes. When using nibble mode DRAMS, the third and fourth ad­dress bits can be tied to the bank select inputs to perform memory interleaving. In page or static column modes, the two address bits after the page size can be tied to the bank select inputs to select a new bank if the page size is ex­ceeded.
Page Mode/Static Column Mode Page Size
C0–10
e
is asserted. The
TL/F/11109– 49
A2–12
35
Page 36
8.0 Test Mode
Staggered refresh in combination with the error scrubbing mode places the DP8420V/21V/22V, DP84T22 in test mode. In this mode, the 24-bit refresh counter is divided into a 13-bit and 11-bit counter. During refreshes both counters are incremented to reduce test time.
9.0 DRAM Critical Timing Parameters
The two critical timing parameters, shown in must be met when controlling the access timing to a DRAM are the row address hold time, t dress setup time, t DP84T22 contain a precise internal delay line, the values of
ASC
RAH
. Since the DP8420V/21V/22V,
these parameters can be selected at programming time. These values will also increase and decrease if DELCLK varies from 2 MHz.
9.1 PROGRAMMABLE VALUES OF t
The DP8420V/21V/22V, DP84T22 allow the values of t and t rameter, two choices can be selected. t
to be selected at programming time. For each pa-
ASC
dress hold time, is measured from RAS address starting to change to the column address. The two choices for t through address bit C8.
t
, the column address setup time, is measured from the
ASC
column address valid to CAS t
are 0 ns and 10 ns, programmable through address bit
ASC
C7.
are 15 ns and 25 ns, programmable
RAH
asserted. The two choices for
Figure 31
, that
, and the column ad-
AND t
RAH
ASC
RAH
, the row ad-
RAH
asserted to the row
9.2 CALCULATION OF t
RAH
AND t
ASC
There are two clock inputs to the DP8420V/21V/22V, DP84T22. These two clocks, DELCLK and CLK can either be tied together to the same clock or be tied to different clocks running asynchronously at different frequencies.
The clock input, DELCLK, controls the internal delay line and refresh request clock. DELCLK should be a multiple of 2 MHz. If DELCLK is not a multiple of 2 MHz, t will change. The new values of t lated by the following formulas:
If t
was programmed to equal 15 ns then t
RAH
15*(((DELCLK Divisor)* 2 MHz/(DELCLK Frequency))b1)
a
15 ns.
was programmed to equal 25 ns then t
If t
RAH
25*(((DELCLK Divisor)* 2 MHz/(DELCLK Frequency))b1)
a
25 ns.
If t
was programmed to equal 0 ns then t
ASC
12.5* ((DELCLK Divisor)* 2 MHz/(DELCLK Frequency))
RAH
and t
RAH
can be calcu-
ASC
and t
RAH
RAH
ASC
ASC
12.5 ns.
If t
was programmed to equal 10 ns then t
ASC
22.5* ((DELCLK Divisor)* 2 MHz/(DELCLK Frequency))
ASC
22.5 ns.
Since the values of t creased, the time to CAS
and t
RAH
asserted will also increase or de-
are increased or de-
ASC
crease. These parameters can be adjusted by the following formula:
Delay to CAS Programmed t
e
Actual Spec.aActual t
a
Actual t
RAH
ASC
b
b
RAH
Programmed t
ASC
.
e
e
e b
e b
FIGURE 31. t
36
RAH
and t
ASC
TL/F/11109– 50
Page 37
10.0 Dual Accessing (DP8422V, DP84T22)
The DP8422V, DP84T22 has all the functions previously de­scribed. In addition to those features, the DP8422V, DP84T22 also has the capabilities to arbitrate among re­fresh, Port A and a second port, Port B. This allows two CPUs to access a common DRAM array. DRAM refresh has the highest priority followed by the currently granted port. The ungranted port has the lowest priority. The last granted port will continue to stay granted even after the access has terminated, until an access request is received from the un­granted port (see tion assumes that both Port A and Port B are synchronous to the system clock. If they are not synchronous to the sys­tem clock they should be externally synchronized (Ex. By running the access requests through several Flip-Flops, see
Figure 34a
10.1 PORT B ACCESS MODE
Port B accesses are initiated from a single input, AREQB When AREQB If GRANTB is asserted and a refresh is not taking place or precharge time is not required, RAS AREQB
is asserted. Once AREQB is asserted, it must stay asserted until the access is over. AREQB RAS
as shown in programming the CAS yond RAS ate ECAS is not granted, the access will begin on the first or second positive edge of CLK after GRANTB is asserted (See R0, R1 programming bit definitions) as shown in suming that Port A is not accessing the DRAM (CS ALE and AREQ
Figure 32a
). The dual access configura-
).
is asserted, an access request is generated.
will be asserted when
negated, negates
Figure 32b
. Note that if ECAS0e1 during
outputs may be held asserted (be-
n negating) by continuing to assert the appropri-
n inputs (the same as Port A accesses). If Port B
Figure 32c
, as-
, ADS/
) and RAS precharge for the particular bank
.
has completed. It is important to note that for GRANTB to transition to Port B, Port A must not be requesting an ac­cess at a rising clock edge (or locked) and Port B must be requesting an access at that rising clock edge. Port A can request an access through CS AREQ
. Therefore during an interleaved access where CS and ADS/ALE become asserted before AREQ from the pre­vious access is negated, Port A will retain GRANTB whether AREQB
is asserted or not.
and ADS/ALE or CS and
e
Since there is no chip select for Port B, AREQB must incor­porate this signal. This mode of accessing is similar to Mode 1 accessing for Port A.
Explanation of Terms
e
AREQA
AREQB
LOCK
Chip Selected access request from Port A
e
Chip Selected access request from Port B
e
Externally controlled LOCKing of the Port
that is currently GRANTed.
TL/F/11109– 51
FIGURE 32a. DP8422V, DP84T22 Port A/Port B
Arbitration State Diagram. This arbitration
may take place during the ‘‘ACCESS’’ or
‘‘REFRESH’’ state (see
Figure 13
).
0
FIGURE 32b. Access Request for Port B
FIGURE 32c. Delayed Port B Access
37
TL/F/11109– 52
TL/F/11109– 53
Page 38
10.0 Dual Accessing (DP8422V, DP84T22) (Continued)
10.2 PORT B WAIT STATE SUPPORT
Advanced transfer acknowledge for Port B, ATACKB
,is used for wait state support for Port B. This output will be asserted when RAS shown in
Figures 33a
will stay asserted until AREQB logic, ATACKB input as shown in
for the Port B access is asserted, as
and
33b
. Once asserted, this output
is negated. With external
can be made to interface to any CPU’s wait
Figure 33c
.
10.3 COMMON PORT A AND PORT B DUAL PORT FUNCTIONS
An input, LOCK functionality to the dual port arbitration logic. LOCK
, and an output, GRANTB, add additional
allows
Port A or Port B to lock out the other port from the DRAM. When a Port is locked out of the DRAM, wait states will be inserted into its access cycle until it is allowed to access memory. GRANTB is used to multiplex the input control sig­nals and addresses to the DP8422V, DP84T22.
10.3.1 GRANTB Output
The output GRANTB determines which port has current ac­cess to the DRAM array. GRANTB asserted signifies Port B has access. GRANTB negated signifies Port A has access to the DRAM array.
FIGURE 33a. Non-Delayed Port B Access
FIGURE 33b. Delayed Port B Access
B. Extend ATACK to 1T after RAS goes low.
TL/F/11109– 56
A. Extend ATACK to (/2T((/2 Clock) after RAS goes low.
C. Synchronize ATACKB to CPU B Clock. This is useful if CPU B runs asynchronous to the DP8422V, DP84T22.
FIGURE 33c. Modifying Wait Logic for Port B
TL/F/11109– 54
TL/F/11109– 55
TL/F/11109– 57
TL/F/11109– 58
38
Page 39
10.0 Dual Accessing (DP8422V, DP84T22) (Continued)
Since the DP8422V, DP84T22 has only one set of address inputs, the signal is used, with the addition of buffers, to allow the currently granted port’s addresses to reach the DP8422V, DP84T22. The signals which need to be buf­ferred are R0– 10, C0–10, B0 –1, ECAS LOCK
. All other inputs are not common and do not have to
be buffered as shown in
Figure 34a.
0–3, WE, and
If a Port, which is not
currently granted, tries to access the DRAM array, the GRANTB output will transition from a rising clock edge from AREQ
or AREQB negating and will precede the RAS for the access by one or two clock periods. GRANTB will then stay in this state until the other port requests an access and the currently granted port is not accessing the DRAM as shown in
Figure 34b
.
*If Port B is synchronous the Request Synchronizing logic will not be required.
FIGURE 34a. Dual Accessing with the DP8422V, DP84T22 (System Block Diagram)
TL/F/11109– 59
39
Page 40
10.0 Dual Accessing (DP8422V, DP84T22) (Continued)
FIGURE 34b. Wait States during a Port B Access
40
TL/F/11109– 60
Page 41
10.0 Dual Accessing (DP8422V, DP84T22) (Continued)
10.3.2 LOCK
When the LOCK input is asserted, the currently granted port can ‘‘lock out’’ the other port through the insertion of wait states to that port’s access cycle. LOCK
Input
does not disable
can be used by either port.
Figure 35
.
FIGURE 35. LOCK Function
10.4 TRI-STATE OUTPUTS (DP84T22V Only)
This version is a metal option on the DP8420V/21V/22V-33 DRAM controllers. It comes in a 84-pin PLCC and imple­ments TRI-STATE output capabilities. It has only one extra pin OE
. When OE is asserted the output buffers are enabled allowing the DRAM controller to interface to the DRAM ar­ray.
TRI-STATE Output Drivers
TL/F/11109– 61
If OE
is negated, the output buffers are at TRI-STATE (high­Z) making the board level circuit testing easier. The time penalty for the TRI-STATE option has been minimized mak­ing this option attractive to high performance designs. This part is functionally compatible to the DP8422A-20, -25.
TL/F/11109– 62
41
Page 42
11.0 Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required, please contact the National Semiconductor Sales Office/Distributors for availability and specifications.
Temperature under Bias 0
Storage Temperature
Ctoa70§C
§
b
65§Ctoa150§C
All Input or Output Voltage
with Respect to GND
b
0.5V toa7V
Power Dissipation@20 MHz 0.5W
Temp Cycle 3000 of 0/125§C
12.0 DC Electrical Characteristics T
e
0§Ctoa70§C, V
A
e
5Vg10%, GNDe0V
CC
Symbol Parameter Conditions Min Typ Max Units
V
IH
V
IL
V
OH1
V
OL1
V
OH2
V
OL2
I
IN
I
IL ML
I
CC1
I
CC1
I
CC1
I
CC2
I
CC2
I
CC2
I
OZH
I
OZL
Logical 1 Input Voltage Tested with a Limited
Functional Pattern
Logical 0 Input Voltage Tested with a Limited
Functional Pattern
Q and WE Outputs I
Q and WE Outputs I
All Outputs except Qs, WE I
All Outputs except Qs, WE I
Input Leakage Current V
ML Input Current (Low) V
Standby Current CLK at 8 MHz (V
Standby Current CLK at 20 MHz (V
Standby Current CLK at 33 MHz (V
eb
10 mA V
OH
e
10 mA 0.5 V
OL
eb
3mA V
OH
e
3 mA 0.5 V
OL
e
VCCor GND
IN
e
GND 200 mA
IN
e
VCCor GND) 6 15 mA
IN
e
VCCor GND) 8 17 mA
IN
e
VCCor GND) 10 20 mA
IN
Supply Current CLK at 8 MHz (Inputs Active)
(I
LOAD
e
25 pF) (V
e
IN
VCCor GND)
Supply Current CLK at 20 MHz (Inputs Active)
(I
LOAD
e
25 pF) (V
e
IN
VCCor GND)
Supply Current CLK at 33 MHz (Inputs Active)
Leakage Current V
Leakage Current V
(I
LOAD
V
V
CC
O
CC
O
e
25 pF) (V
e
Max
e
b
V
CC
e
Max
e
0.5V
1.0V
e
IN
VCCor GND)
2.0 V
b
0.5 0.8 V
b
1.0 V
CC
b
1.0 V
CC
b
10 10 mA
CC
a
0.5 V
25 45 mA
65 90 mA
115 150 mA
10 mA
b
10 mA
CIN* Input Capacitance fINat 1 MHz 10 pF
*CINis not 100% tested.
Note 1: ‘‘Absolute Maximum Ratings’’ are the values beyond which the safety of the device cannot be guaranteed. They are not meant to imply that the device should be operated at these limits. The table of ‘‘Electrical Characteristics’’ provides conditions for actual device operation.
Note 2: Input pulse 0V to 3V; tR
Note 3: AC Production testing is done at 50 pF.
etFe
2.5 ns. Input reference point on AC measurements is 1.5V. Output reference point is 1.5V.
42
Page 43
13.0 AC Timing Parameters
Two speed selections are given, the DP8420V/21V/22V-33 and the DP84T22-25. The differences between the two parts are the maximum operating frequencies of the input CLKs and the maximum delay specifications. Low frequency applications may use the ‘‘-33’’ part to gain improved timing.
The AC timing parameters are grouped into sectional num­bers as shown below. These numbers also refer to the tim­ing diagrams.
1–36 Common parameters to all modes of operation
50–56 Difference parameters used to calculate;
100–121 Common dual access parameters used for Port
200–212 Refresh parameters
RAS
low time,
RAS
precharge time,
CAS
high time and
CAS
low time
B accesses and inputs and outputs used only in dual accessing
300–315 Mode 0 access parameters used in both single
and dual access applications
400–416 Mode 1 access parameters used in both single
and dual access applications
450–455 Special Mode 1 access parameters which super-
sede the 400 –416 parameters when dual ac­cessing
500–506 Programming parameters
Unless otherwise stated V 70§C, the output load capacitance is typical for 4 banks of
e
5.0Vg10%, 0kT
CC
A
18 DRAMs per bank, including trace capacitance (see Note
2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
380 pF loads on Q0 –8, 9, 10 and WE.
C
H
k
FIGURE 36. Clock, DELCLK Timing
43
TL/F/11109– 63
Page 44
13.0 AC Timing Parameters (Continued)
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
5.0Vg10%, 0§CkT
CC
A
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
DP8420V/21V/22V and DP84T22V
C
L
C
H
Number Symbol
Common Parameter
Description
Min Max Min Max
1f
CLK
CLK Frequency 0 33 0 33
2 tCLKP CLK Period 30 30
3, 4 tCLKPW CLK Pulse Width 12 12
5 fDCLK DELCLK Frequency 6 20 6 20
6 tDCLKP DELCLK Period 50 166 50 166
7, 8 tDCLKPW DELCLK Pulse Width 12 12
9a tPRASCAS0 RAS Asserted to CAS
e
(tRAH
15 ns, tASCe0 ns)
9b tPRASCAS1 RAS Asserted to CAS Asserted
(tRAHe15 ns, tASCe10 ns)
9c tPRASCAS2 (RAS Asserted to CAS Asserted
e
(tRAH
25 ns, tASCe0 ns)
9d tPRASCAS3 (RAS Asserted to CAS Asserted
e
(tRAH
25 ns, tASCe10 ns)
Asserted
30 30
40 40
40 40
50 50
10a tRAH Row Address Hold Time (tRAHe15) 15 15
10b tRAH Row Address Hold Time (tRAHe25) 25 25
11a tASC Column Address Setup Time (tASCe0) 0 0
11b tASC Column Address Setup Time (tASCe10) 10 10
12 tPCKRAS CLK High to RAS Asserted
following Precharge
18 22
13 tPARQRAS AREQ Negated to RAS Negated 25 29
14 tPENCL ECAS0– 3 Asserted to CAS Asserted 15 22
15 tPENCH ECAS0– 3 Negated to CAS Negated 14 21
16 tPARQCAS AREQ Negated to CAS Negated 36 43
17 tPCLKWH CLK to WAIT Negated 25 25
18 tPCLKDL0 CLK to DTACK Asserted
(Programmed as DTACK of 1/2, 1, 1(/2 23 23 or if WAITIN is Asserted)
19 tPEWL ECAS Negated to WAIT Asserted
during a Burst Access
29 29
20 tSECK ECAS Asserted Setup to CLK High to
Recognize the Rising Edge of CLK 13 13 during a Burst Access
44
Page 45
13.0 AC Timing Parameters (Continued)
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
5.0Vg10%, 0§CkT
CC
A
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
DP8420V/21V/22V and DP84T22V
C
L
C
H
Number Symbol
Common Parameter
Description
Min Max Min Max
21 tPEDL ECAS Asserted to DTACK
Asserted during a Burst Access 29 29 (Programmed as DTACK
22 tPEDH ECAS Negated to DTACK
Negated during a Burst Access
0)
30 30
23 tSWCK WAITIN Asserted Setup to CLK 5 5
24 tPWINWEH WIN Asserted to WE Asserted 18 28
25 tPWINWEL WIN Negated to WE Negated 18 28
26 tPAQ Row, Column Address Valid to
Q0–8, 9, 10 Valid
27 tPCINCQ COLINC Asserted to Q0 – 8, 9, 10
Incremented
28 tSCINEN COLINC Asserted Setup to ECAS
e
Asserted to Ensure tASC
0ns
29a tSARQCK1 AREQ, AREQB Negated Setup to CLK
High with 1 Period of Precharge
29b tSARQCK2 AREQ, AREQB Negated Setup to CLK High
withl1 Period of Precharge Programmed
14 16
25 25
11 11
20 29
24 33
30 tPAREQDH AREQ Negated to DTACK Negated 20 20
31 tPCKCAS CLK High to CAS Asserted
when Delayed by WIN
32 tSCADEN Column Address Setup to ECAS
Asserted to Guarantee tASCe0
10 11
21 28
33 tWCINC COLINC Pulse Width 10 10
34a tPCKCL0 CLK High to CAS Asserted following
Precharge (tRAH
e
15 ns, tASCe0 ns)
34b tPCKCL1 CLK High to CAS Asserted following
Precharge (tRAHe15 ns, tASCe10 ns)
34c tPCKCL2 CLK High to CAS Asserted following
Precharge (tRAH
e
25 ns, tASCe0 ns)
34d tPCKCL3 CLK High to CAS Asserted following
Precharge (tRAH
e
25 ns, tASCe10 ns)
35 tCAH Column Address Hold Time
(Interleave Mode Only)
36 tPCQR CAS Asserted to Row Address
Valid (Interleave Mode Only)
25 25
65 73
75 83
75 83
85 93
70 70
45
Page 46
13.0 AC Timing Parameters (Continued)
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
5.0Vg10%, 0§CkT
CC
A
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
Number Symbol
Difference
Parameter Description
50 tD1 (AREQ or AREQB Negated to RAS
Negated) Minus (CLK High to RAS 99 Asserted)
51 tD2 (CLK High to Refresh RAS Negated)
Minus (CLK High to RAS Asserted)
52 tD3a (ADS Asserted to RAS Asserted
(Mode 1)) Minus (AREQ to RAS
Negated)
Negated 4 4
53 tD3b (CLK High to RAS Asserted (Mode 0))
Minus (AREQ Negated to RAS Negated)
54 tD4 (ECAS Asserted to CAS Asserted)
Minus (ECAS
Negated to CAS Negated)
55 tD5 (CLK to Refresh RAS Asserted) Minus
(CLK to Refresh RAS
Negated)
52 tD6 (AREQ Negated to RAS Negated)
Minus (ADS
Asserted to RAS 55
Asserted (Mode 1))
Number Symbol
80 t
81 t
82 t
83 t
PZL
PZH
PLZ
PHZ
Delay from TRI-STATE to Low Level
Delay from TRI-STATE to High Level
Delay from TRI-STATE to TRI-STATE
Delay from TRI-STATE to TRI-STATE
TRI-STATE
Parameter Description
DP8420V/21V/22V and DP84T22V
C
L
C
H
Min Max Min Max
77
22
b
55
b
55
44
DP8420V/21V/22V-33 DP84T22-25
C
L
C
H
C
L
C
H
Min Max Min Max Min Max Min Max
15 22
18 25
18 25
18 25
46
Page 47
13.0 AC Timing Parameters (Continued)
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
Number Symbol
5.0Vg10%, 0§CkT
CC
Common Dual Access
Parameter Description
100 tHCKARQB AREQB Negated Held from CLK High 2 2
101 tSARQBCK AREQB Asserted Setup to CLK High 5 5
102 tPAQBRASL AREQB Asserted to RAS Asserted 29 33
103 tPAQBRASH AREQB Negated to RAS Negated 24 28
105 tPCKRASG CLK High to RAS Asserted for
Pending Port B Access
106 tPAQBATKBL AREQB Asserted to ATACKB Asserted 37 37
107 tPCKATKB CLK High to ATACKB Asserted
for Pending Access
108 tPCKGH CLK High to GRANTB Asserted 28 28
109 tPCKGL CLK High to GRANTB Negated 26 26
110 tSADDCKG Row Address Setup to CLK High That
Asserts RAS
following a GRANTB 7 11
Change to Ensure tASR
111 tSLOCKCK LOCK
Asserted Setup to CLK Low
to Lock Current Port
112 tPAQATKBH AREQ Negated to ATACKB Negated 16 16
113 tPAQBCASH AREQB Negated to CAS Negated 38 45
114 tSADAQB Address Valid Setup to AREQB Asserted 6 10
116 tHCKARQG AREQ Negated Held from CLK High 5 5
117 tWAQB AREQB High Pulse Width
to Guarantee tASR
118a tPAQBCAS0 AREQB Asserted to CAS Asserted
(tRAH
e
15 ns, tASCe0 ns)
118b tPAQBCAS1 AREQB Asserted to CAS Asserted
(tRAHe15 ns, tASCe10 ns)
118c tPAQBCAS2 AREQB Asserted to CAS Asserted
(tRAH
e
25 ns, tASCe0 ns)
118d tPAQBCAS3 AREQB Asserted to CAS Asserted
(tRAHe25 ns, tASCe10 ns)
120a tPCKCASG0 CLK High to CAS Asserted
for Pending Port B Access 84 91 (tRAHe15 ns, tASCe0 ns)
120b tPCKCASG1 CLK High to CAS Asserted
for Pending Port B Access 94 101
e
(tRAH
15 ns, tASCe10 ns)
120c tPCKCASG2 CLK High to CAS Asserted
for Pending Port B Access 94 101 (tRAHe25 ns, tASCe0 ns)
120d tPCKCASG3 CLK High to CAS Asserted
for Pending Port B Access 104 111
e
(tRAH
25 ns, tASCe10 ns)
121 tSBADDCKG Bank Address Valid Setup to CLK
High That Starts RAS for Pending Port B Access
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
A
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
DP8420V/21V/22V and DP84T22V
C
L
Min Max Min Max
37 41
45 45
e
0 ns for Port B
44
e
0ns
17 19
79 86
89 96
89 96
99 106
55
C
H
47
Page 48
13.0 AC Timing Parameters (Continued)
FIGURE 37. 100: Dual Access Port B
FIGURE 38. 100: Port A and Port B Dual Access
TL/F/11109– 64
TL/F/11109– 65
48
Page 49
13.0 AC Timing Parameters (Continued)
ASC
ASC
ASC
ASC
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
A
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
DP8420V/21V/22V and DP84T22V
C
L
Min Max Min Max
e
0 ns)
e
10 ns)
e
0 ns)
e
10 ns)
C
H
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
Number Symbol
5.0Vg10%, 0§CkT
CC
Refresh Parameter
Description
200 tSRFCK RFSH Asserted Setup to CLK High 16 16
201 tSDRFCK DISRFSH Asserted Setup to CLK High 16 16
202 tSXRFCK EXTENDRF Setup to CLK High 8 8
204 tPCKRFL CLK High to RFIP Asserted 26 26
205 tPARQRF AREQ Negated to RFIP Asserted 38 38
206 tPCKRFH CLK High to RFIP Negated 41 41
207 tPCKRFRASH CLK High to Refresh RAS Negated 26 30
208 tPCKRFRASL CLK High to Refresh RAS Asserted 20 24
209a tPCKCL0 CLK High to CAS Asserted
during Error Scrubbing 64 73
e
15 ns, t
(t
RAH
209b tPCKCL1 CLK High to CAS Asserted
during Error Scrubbing 74 83
e
15 ns, t
(t
RAH
209c tPCKCL2 CLK High to CAS Asserted
during Error Scrubbing 74 83
e
25 ns, t
(t
RAH
209d tPCKCL3 CLK High to CAS Asserted
during Error Scrubbing 85 94
e
25 ns, t
(t
RAH
210 tWRFSH RFSH Pulse Width 9 9
211 tPCKRQL CLK High to RFRQ Asserted 22 22
212 tPCKRQH CLK High to RFRQ Negated 22 22
FIGURE 39. 200: Refresh Timing
49
TL/F/11109– 66
Page 50
13.0 AC Timing Parameters (Continued)
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
Number Symbol
5.0Vg10%, 0§CkT
CC
Parameter Description
Mode 0 Access
300 tSCSCK CS Asserted to CLK High 8 8
301a tSALECKNL ALE Asserted Setup to CLK High
Not Using On-Chip Latches or if Using On-Chip Latches and B0, B1, Are Constant, Only 1 Bank
301b tSALECKL ALE Asserted Setup to CLK High,
if Using On-Chip Latches if B0, B1 20 20 Can Change, More Than One Bank
302 tWALE ALE Pulse Width 10 10
303 tSBADDCK Bank Address Valid Setup to CLK High 10 10
304 tSADDCK Row, Column Valid Setup to
CLK High to Guarantee 6 10
e
tASR
0ns
305 tHASRCB Row, Column, Bank Address
Held from ALE Negated 6 6 (Using On-Chip Latches)
306 tSRCBAS Row, Column, Bank Address
Setup to ALE Negated 1 1 (Using On-Chip Latches)
307 tPCKRL CLK High to RAS Asserted 19 23
308a tPCKCL0 CLK High to CAS Asserted
308b tPCKCL1 CLK High to CAS Asserted
308c tPCKCL2 CLK High to CAS Asserted
308d tPCKCL3 CLK High to CAS Asserted
e
(t
15 ns, t
RAH
e
(t
RAH
e
(t
RAH
e
(t
RAH
15 ns, t
25 ns, t
25 ns, t
ASC
ASC
ASC
ASC
309 tHCKALE ALE Negated Hold from CLK High 0 0
310 tSWINCK WIN Asserted Setup to CLK High
to Guarantee CAS
311 tPCSWL CS Asserted to WAIT Asserted 20 20
312 tPCSWH CS Negated to WAIT Negated 20 20
313 tPCLKDL1 CLK High to DTACK Asserted
(Programmed as DTACK0
314 tPALEWL ALE Asserted to WAIT Asserted
(CS
is Already Asserted)
315 AREQ Negated to CLK High That Starts
Access RAS to Guarantee tASRe0ns 27 31 (Non-Interleaved Mode Only)
316 tPCKCV0 CLK High to Column
Address Valid 58 67
e
(t
15 ns, t
RAH
ASC
317 tPCKCV1 CLK High to Column
Address Valid 68 75
e
(t
25 ns, t
RAH
ASC
A
e
0 ns)
e
10 ns)
e
0 ns)
e
10 ns)
is Delayed
)
e
0 ns)
e
0 ns)
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
DP8420V/21V/22V and DP84T22V
C
L
C
H
Min Max Min Max
11 11
65 72
75 82
75 82
85 92
b
16
b
16
27 27
21 21
50
Page 51
13.0 AC Timing Parameters (Continued)
FIGURE 40. 300: Mode 0 Timing
51
TL/F/11109– 67
Page 52
13.0 AC Timing Parameters (Continued)
(Programmed as C4e1, C5e1, C6e1)
TL/F/11109– 68
FIGURE 41. 300: Mode 0 Interleaving
52
Page 53
13.0 AC Timing Parameters (Continued)
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
Number Symbol
5.0Vg10%, 0§CkT
CC
Parameter Description
Mode 1 Access
400a tSADSCK1 ADS Asserted Setup to CLK High 9 9
400b tSADSCKW ADS Asserted Setup to CLK
(to Guarantee Correct WAIT or DTACK Output; Doesn’t Apply for DTACK0)
401 tSCSADS CS Setup to ADS Asserted 4 4
402 tPADSRL ADS Asserted to RAS Asserted 20 24
403a tPADSCL0 ADS Asserted to CAS Asserted
e
15 ns, tASCe0 ns)
(tRAH
403b tPADSCL1 ADS Asserted to CAS Asserted
(tRAHe15 ns, tASCe10 ns)
403c tPADSCL2 ADS Asserted to CAS Asserted
e
25 ns, tASCe0 ns)
(tRAH
403d tPADSCL3 ADS Asserted to CAS Asserted
e
25 ns, tASCe10 ns)
(tRAH
404 tSADDADS Row Address Valid Setup to ADS
Asserted to Guarantee tASR
405 tHCKADS ADS Negated Held from CLK High 0 0
406 tSWADS WAITIN Asserted Setup to ADS
Asserted to Guarantee DTACK00 0 Is Delayed
407 tSBADAS Bank Address Setup to ADS Asserted 6 6
408 tHASRCB Row, Column, Bank Address Held from
ADS Asserted (Using On-Chip Latches)
409 tSRCBAS Row, Column, Bank Address Setup to
Asserted (Using On-Chip Latches)
ADS
410 tWADSH ADS Negated Pulse Width 12 17
411 tPADSD ADS Asserted to DTACK Asserted
(Programmed as DTACK0
412 tSWINADS WIN Asserted Setup to ADS Asserted
(to Guarantee CAS Delayed during Writes Accesses)
413 tPADSWL0 ADS Asserted to WAIT Asserted
(Programmed as WAIT
414 tPADSWL1 ADS Asserted to WAIT Asserted
(Programmed WAIT
415 tPCLKDL1 CLK High to DTACK Asserted
(Programmed as DTACK0, 27 27 Delayed Access)
416 AREQ Negated to ADS Asserted
to Guarantee tASR
e
(Non Interleaved Mode Only)
417 tPADSCV0 ADS Asserted to Column
Address Valid 51 60
e
(t
15 ns, t
RAH
ASC
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
A
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
DP8420V/21V/22V and DP84T22V
C
L
Min Max Min Max
19 19
70 77
80 87
80 87
90 97
e
0ns
611
66
11
)
0, Delayed Access)
1/2 or 1)
b
10
29 29
19 19
22 22
0ns 27 29
e
0 ns)
53
C
H
b
10
Page 54
13.0 AC Timing Parameters (Continued)
FIGURE 42. 400: Mode 1 Timing
54
TL/F/11109– 69
Page 55
13.0 AC Timing Parameters (Continued)
FIGURE 43. 400: COLINC Page/Static Column Access Timing
55
TL/F/11109– 70
Page 56
13.0 AC Timing Parameters (Continued)
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
Number Symbol
5.0Vg10%, 0§CkT
CC
Mode 1 Dual Access
Parameter Description
450 tSADDCKG Row Address Setup to CLK High That
Asserts RAS
following a GRANTB 10 12
Port Change to Ensure tASR
451 tPCKRASG CLK High to RAS Asserted
for Pending Access
452 tPCLKDL2 CLK to DTACK Asserted for Delayed
Accesses (Programmed as DTACK
453a tPCKCASG0 CLK High to CAS Asserted
for Pending Access 81 88
e
(t
15 ns, t
RAH
ASC
453b tPCKCASG1 CLK High to CAS Asserted
for Pending Access 91 98
e
(t
15 ns, t
RAH
ASC
453c tPCKCASG2 CLK High to CAS Asserted
for Pending Access 91 98
e
(t
25 ns, t
RAH
ASC
453d tPCKCASG3 CLK High to CAS Asserted
for Pending Access 101 108
e
(t
25 ns, t
RAH
ASC
454 tSBADDCKG Bank Address Valid Setup to CLK High
that Asserts RAS
455 tSADSCK0 ADS Asserted Setup to CLK High 8 8
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
A
e
0ns
e
0 ns)
e
10 ns)
e
0 ns)
e
10 ns)
for Pending Access
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
DP8420V/21V/22V and DP84T22V
C
L
Min Max Min Max
30 34
0)
37 37
33
C
H
56
Page 57
13.0 AC Timing Parameters (Continued)
e
Unless otherwise stated V per bank, including trace capacitance (Note 2).
Two different loads are specified:
e
C
50 pF loads on all outputs except
L
e
C
150 pF loads on Q0 –8, 9, 10 and WE;or
L
5.0Vg10%, 0§CkT
CC
A
k
70§C, the output load capacitance is typical for 4 banks of 18 DRAMs
e
C
50 pF loads on all outputs except
H
e
C
125 pF loads on RAS0 –3 and CAS0–3 and
H
e
C
380 pF loads on Q0 –8, 9, 10 and WE.
H
DP8420V/21V/22V and DP84T22V
C
L
Number Symbol
Programming
Parameter Description
Min Max Min Max
500 tHMLADD Mode Address Held from ML Negated 6 6
501 tSADDML Mode Address Setup to ML Negated 6 6
502 tWML ML Pulse Width 12 12
503 tSADAQML Mode Address Setup to AREQ Asserted 0 0
504 tHADAQML Mode Address Held from AREQ Asserted 30 30
505 tSCSARQ CS Asserted Setup to
AREQ
Asserted
66
506 tSMLARQ ML Asserted Setup to AREQ Asserted 6 6
C
H
FIGURE 44. 500: Programming
57
TL/F/11109– 71
Page 58
14.0 Functional Differences between the DP8420V/21V/22V, DP84T22 and the DP8420/21/22
1. Extending the Column Address Strobe (CAS) after AREQ
Transitions High
The DP8420V/21V/22V, DP84T22 allows CAS to be as­serted for an indefinite period of time beyond AREQ AREQB
, DP8422V, DP84T22 only. Scrubbing refreshes are not affected.) being negated by continuing to assert the appropriate ECAS long as the ECAS ming. The DP8420/21/22 does not allow this feature.
2. Dual Accessing
The DP8420V/21V/22V, DP84T22 asserts RAS one or two clock periods after GRANTB has been assert­ed or negated depending upon how the R0 bit was pro­grammed during the mode load operation. The DP8420/21/22 will always start RAS after GRANTB is asserted or negated. The above state­ments assume that RAS by the time GRANTB is asserted or negated.
3. Refresh Request Output (RFRQ
The DP8420V/21V/22V, DP84T22 allows RFRQ request) to be output on the WE ECAS
0 was negated during programming or the control­ler was programmed to function in the address pipelining (memory interleaving) mode. The DP8420/21/22 only al­lows RFRQ mode.
4. Clearing the Refresh Request Clock Counter
The DP8420V/21V/22V, DP84T22 allows the internal re­fresh request clock counter to be cleared by negating DISRFSH DP8420/21/22 clears the internal refresh request clock counter if DISRFSH the internal refresh request clock counter is cleared the user is guaranteed that an internally generated RFRQ not be generated for at least 13 ms–15 ms (depending upon how programming bits C0, 1, 2, 3 were pro­grammed).
to be output during the address pipelining
and asserting RFSH for at least 500 ns. The
inputs. This feature is allowed as
0 input was negated during program-
one clock period
precharge has been completed
)
output pin given that
remains low for at least 500 ns. Once
(or
either
(refresh
will
15.0 DP8420V/21V/22V, DP84T22 User Hints
1. All inputs to the DP8420V/21V/22V, DP84T22 should be tied high, low or the output of some other device.
Note: One signal is active high. COLINC (EXTNDRF) should be tied low
to disable.
2. Each ground on the DP8420V/21V/22V, DP84T22 must be decoupled to the closest on-chip supply (V
0.1 mF ceramic capacitor. This is necessary because these grounds are kept separate inside the DP8420V/ 21V/22V, DP84T22. The decoupling capacitors should be placed as close as possible with short leads to the ground and supply pins of the DP8420V/21V/22V, DP84T22.
3. The output called ‘‘CAP’’ should have a 0.1 mF capacitor to ground.
4. The DP8420V/21V/22V, DP84T22 has 20X series damping resistors built into the output drivers of RAS CAS
, address and WE/RFRQ. Space should be provided
CC
) with
for external damping resistors on the printed circuit board (or wire-wrap board) because they may be needed. The value of these damping resistors (if needed) will vary de­pending upon the output, the capacitance of the load, and the characteristics of the trace as well as the routing of the trace. The value of the damping resistor also may vary between the wire-wrap board and the printed circuit board. To determine the value of the series damping re­sistor it is recommended to use an oscilloscope and look at the furthest DRAM from the DP8420V/21V/22V, DP84T22. The undershoot of RAS dresses should be kept to less than 0.5V below ground by varying the value of the damping resistor. The damp­ing resistors should be placed as close as possible with short leads to the driver outputs of the DP8420V/21V/ 22V, DP84T22.
5. The circuit board must have a good V plane connection. If the board is wire-wrapped, the V and ground pins of the DP8420V/21V/22V, DP84T22, the DRAM associated logic and buffer circuitry must be soldered to the V
6. The traces from the DP8420V/21V/22V, DP84T22 to the DRAM should be as short as possible.
7. ECAS
0 should be held low during programming if the user wishes that the DP8420V/21V/22V, DP84T22 be com­patible with a DP8420/21/22 design.
8. Parameter Changes due to Loading All A.C. parameters are specified with the equivalent load
capacitances, including traces, of 64 DRAMs organized as 4 banks of 18 DRAMs each. Maximums are based on worst-case conditions. If an output load changes then the A.C. timing parameters associated with that particular output must be changed. For example, if we changed our output load to
e
C
250 pF loads on RAS0 –3 and CAS0–3
e
C
760 pF loads on Q0 –9 and WE
we would have to modify some parameters (not all calcu­lated here)
$308a clock to CAS
e
(t
15 ns, t
RAH
A ratio can be used to figure out the timing change per change in capacitance for a particular parameter by using the specifications and capacitances from heavy and light load timing.
$308a w/Heavy Loadb$308a w/Light Load
e
Ratio
79 nsb72 ns
e
$308a (actual)
9. It is required that the user perform a hardware reset to the DP8420V/21V/22V, DP84T22 before programming and using the chip. A hardware reset consists of assert­ing both ML
,
edges of CLK, see Section 3.1.
125 pFb50 pF
and ground planes.
CC
asserted
e
0 ns)
ASC
CH(CAS)bCL(CAS)
e
(capacitance difference
ratio)a$308a (specified)
e
(250 pFb125 pF)
e
11.7 nsa79 ns
e
90.7 ns@250 pF load
and DISRFSH for a minimum of 16 positive
, CAS,WEand the ad-
7ns
e
75 pF
75 pF
7ns
and ground
CC
c
a
79 ns
CC
58
Page 59
Physical Dimensions inches (millimeters)
Order Number DP8420V-33 or DP8421V-33
Plastic Chip Carrier (V)
NS Package Number V68A
59
Page 60
Physical Dimensions inches (millimeters) (Continued)
Order Number DP8422V-33 or DP84T22-25
Plastic Chip Carrier (V)
NS Package Number V84A
256k/1M/4M Dynamic RAM Controller/Drivers
DP8420V/21V/22V-33, DP84T22-25 microCMOS Programmable
LIFE SUPPORT POLICY
NATIONAL’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF THE PRESIDENT OF NATIONAL SEMICONDUCTOR CORPORATION. As used herein:
1. Life support devices or systems are devices or 2. A critical component is any component of a life systems which, (a) are intended for surgical implant support device or system whose failure to perform can into the body, or (b) support or sustain life, and whose be reasonably expected to cause the failure of the life failure to perform, when properly used in accordance support device or system, or to affect its safety or with instructions for use provided in the labeling, can effectiveness. be reasonably expected to result in a significant injury to the user.
National Semiconductor National Semiconductor National Semiconductor National Semiconductor Corporation Europe Hong Kong Ltd. Japan Ltd.
1111 West Bardin Road Fax: ( Arlington, TX 76017 Email: cnjwge@tevm2.nsc.com Ocean Centre, 5 Canton Rd. Fax: 81-043-299-2408 Tel: 1(800) 272-9959 Deutsch Tel: ( Fax: 1(800) 737-7018 English Tel: (
National does not assume any responsibility for use of any circuitry described, no circuit patent licenses are implied and National reserves the right at any time without notice to change said circuitry and specifications.
Fran3ais Tel: ( Italiano Tel: (
a
49) 0-180-530 85 86 13th Floor, Straight Block, Tel: 81-043-299-2309
a
49) 0-180-530 85 85 Tsimshatsui, Kowloon
a
49) 0-180-532 78 32 Hong Kong
a
49) 0-180-532 93 58 Tel: (852) 2737-1600
a
49) 0-180-534 16 80 Fax: (852) 2736-9960
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
