ISSUED
June 7, 2007
TYPE
ASHH
PERFORMANCE DATA
3-PHASE INDUCTION MOTOR
NAMEPLATE INFORMATION
OUTPUT
HP KW
50 37.3 60
POLE
6
FRAME
SIZE
365T
VOLTAGE
575
TYPICAL PERFORMANCE
FULL
LOAD
RPM
FULL LOAD
MIN. % NOM. %
93.0 94.1
EFFICIENCY
3/4 LOAD
%
94.1 94.5
RATED
HZ
AMBIENT
40oC
1/2 LOAD
%
INS.
CLASS
F
POWER FACTOR
F. L.
%
86.0
3/4 LOAD%1/2 LOAD
83.0 75.0
NEMA
DESIGN
B
ENCLOSURE
CATALOG#
DHP05065
TIME
RATING
CONT.
POWER FACTOR
%
CORRECTION
ODP
SERVICE
FACTOR
1.15
MAXIMUM
KVAR16.01180
NO LOAD FULL LOAD LOCKED ROTOR
AT
575
VOLT
15.60
TORQUE
FULL LOAD
lb-ft
LOCKED
ROTOR
%FLT
PULL
UP
%FLT
222.5 225 180 235
SAFE STALL
TIME IN
SECONDS
COLD HOT
17 12
ALLOWABLE
STARTS
PER HOUR
COLD HOT
21
BREAK
DOWN
%FLT
CURRENTS
AT
575
VOLT
46.30 290.00
ROTOR
2
WR
2
lb-ft
NEMA
18.626
SOUND
PRESSURE
LEVEL @ 3 FT
dB(A)
LOAD
WK
lb-ft
620
2
2
MAX
ALLOWABLE
WK
lb-ft
2
2
1074
64
AT
575
VOLT
ACCEL TIMEINERTIA
NEMA
LOAD
2
WK
Sec
5.26
NEMA
KVA
CODE
LETTER
G
MAX
ALLOWABLE
WK
Sec
2
8.99
APPROVED: REVISION
M. PRATER
DRAWING NO.
31057DHP05065
0
